HP COMPAQ PRO 4300 ALL-IN-ONE PC
FRONT
1. Webcam Activity LED
2. Webcam & Microphone (optional)
3. Power Button
4. Power Indicator LED
5. Business Quality Speakers
QuickSpecs
HP Compaq Pro 4300 All-in-One PC
Overview
DA - 14287 North America — Version 24 — November 21, 2013 Page 1

HP COMPAQ PRO 4300 ALL-IN-ONE PC
BACK
1. HP SD Media Card Reader
2. (2) USB 2.0 ports
3. Microphone jack
4. Headphone jack
5. Serial Port
6. (4) USB 2.0 ports
7. Stereo audio line out
8. RJ-45 Gigabit Ethernet port
9. Power connector
10. Power connector LED indicator
11. Security lock slot
QuickSpecs
HP Compaq Pro 4300 All-in-One PC
Overview
DA - 14287 North America — Version 24 — November 21, 2013 Page 2

HP COMPAQ PRO 4300 ALL-IN-ONE PC
SIDE
1. Slim tray-load ODD (optional)
2. Brightness increase button
3. Brightness decrease button
4. Hard drive activity LED
QuickSpecs
HP Compaq Pro 4300 All-in-One PC
Overview
DA - 14287 North America — Version 24 — November 21, 2013 Page 3

At A Glance
Windows 7 or Windows 8
20-inch diagonal widescreen WLED backlit anti-glare LCD
Integrated all-in-one form factor
Intel® H61 Express chipset
Intel 2nd & 3rd generation Core™ processors
Integrated Intel HD Graphics
Realtek RTL8111F GbE Ethernet Controller optional wireless connectivity:
Intel Advanced-N 6205 WLAN (mini PCI Express)
Intel 802.11 a/b/g/n
WLAN (mini PCI Express)
HP 802.11 b/g/n
Optional Integrated 1.3 MP webcam & Single Non-Array Microphone
Business quality speakers
Up to 16 GB of DDR3 SDRAM, dual channel memory support, two SODIMM slots
Up to 1 TB SATA hard drive, up to 128GB Solid State Drive and a 256GB Self-Encrypting Drive / Solid State Drive
Slim Tray-load SuperMulti Optical Disc Drive or DVD ROM Optical Disc Drive
SD Media Card Reader
ENERGY STAR® qualified. EPEAT® registered where applicable/supported. See www.epeat.net for registration status by country.
SEPA Certified
QuickSpecs
HP Compaq Pro 4300 All-in-One PC
Overview
DA - 14287 North America — Version 24 — November 21, 2013 Page 4

OPERATING SYSTEM
Preinstalled Windows 8 Pro (64-bit)*
Windows 8 (64-bit)*
Windows® 7 Professional (32-bit or 64-bit)**
Windows® 7 Home Premium (32-bit or 64-bit)**
Windows® 7 Professional (32-bit) (available through downgrade rights from Windows 8 Pro)***
Windows® 7 Professional (64-bit) (available through downgrade rights from Windows 8 Pro)***
Windows® 7 Home Basic (32-bit)**
FreeDOS
Novell SUSE Linux Enterprise Desktop 11
* Not all features are available in all editions of Windows 8. Systems may require upgraded and/or
separately purchased hardware, drivers and/or software to take full advantage of Windows 8
functionality. See http://www.microsoft.com .
**Not all features are available in all editions of Windows 7. This system may require upgraded and/or
separately purchased hardware to take full advantage of Windows 7 functionality. See
http://windows.microsoft.com/en-us/windows7/products/home for details.
***This system is preinstalled with Windows® 7 Pro software and also comes with a license and media
for Windows 8 Pro software. You may only use one version of the Windows software at a time.
Switching between versions will require you to uninstall one version and install the other version. You
must back up all data (files, photos, etc.) before uninstalling and installing operating systems to avoid
loss of your data.
PROCESSOR
Intel® 3rd Generation Core™ i7 Processors
Intel® Core™ i7-3770S
Up to 3.9 GHz Max. Turbo Frequency (3.1 GHz base frequency), 8 MB cache, 4 cores, 8 threads
Intel HD Graphics 4000
Intel Stable Image Platform Program (SIPP)
Intel® 3rd Generation Core™ i5 Processors
Intel® Core™ i5-3570S
Up to 3.8 GHz Max. Turbo Frequency (3.1 GHz base frequency), 6 MB cache, 4 cores, 4 threads
Intel HD Graphics 2500
Intel Stable Image Platform Program (SIPP)
Intel® Core™ i5-3475S
Up to 3.6 GHz Max. Turbo Frequency (2.9 GHz base frequency), 6 MB cache, 4 cores, 4 threads
Intel HD Graphics 4000
Intel Stable Image Platform Program (SIPP)
Intel® Core™ i5-3470S
Up to 3.6 GHz Max. Turbo Frequency (2.9 GHz base frequency), 6 MB cache, 4 cores, 4 threads
Intel HD Graphics 2500
Intel Stable Image Platform Program (SIPP)
QuickSpecs
HP Compaq Pro 4300 All-in-One PC
Standard Features and Configurable Components (availability may vary by country)
DA - 14287 North America — Version 24 — November 21, 2013 Page 5

Intel® 3rd Generation Core™ i3 Processors
Intel® Core™ i3-3240
Intel HD Graphics 2500
3.40 GHz base frequency, 3 MB cache, 2 cores, 4 threads
Intel® Core™ i3-3225
3.30 GHz base frequency, 3 MB cache, 2 cores, 4 threads
Intel HD Graphics 4000
Intel® Core™ i3-3220
3.30 GHz base frequency, 3 MB cache, 2 cores, 4 threads
Intel HD Graphics 2500
Intel® Core™ i3-3210
3.2 GHz base frequency, 3 MB cache, 2 cores, 4 threads
Intel HD Graphics 2500
Supports DDR3 memory up to 1600 MT/s data rate
Intel® 3rd Generation Pentium® Processors
Intel® Pentium® G2120
3.1 GHz base frequency, 3 MB cache, 2 cores, 2 threads
Intel HD Graphics
Supports DDR3 memory up to 1600 MT/s data rate
Intel® Pentium® G2020
2.9 GHz base frequency, 3 MB cache, 2 cores, 2 threads
Intel HD Graphics
Supports DDR3 memory up to 1333 MT/s data rate
Intel® Pentium® G2010
2.8 GHz base frequency, 3 MB cache, 2 cores, 2 threads
Intel HD Graphics
Supports DDR3 memory up to 1333 MT/s data rate
Intel® 2nd Generation Pentium® Processors
Intel® Pentium® G870
3.10 GHz base frequency , 3 MB cache, 2 cores, 2 threads
Intel HD Graphics
Intel® Pentium® G860
3.00 GHz base frequency , 3 MB cache, 2 cores, 2 threads
Intel HD Graphics
Intel® Pentium® G645
2.9 GHz base frequency, 3 MB cache, 2 cores, 2 threads
Intel HD Graphics
Supports DDR3 memory up to 1066 MT/s data rate
Intel® Pentium® G640
2.80 GHz base frequency , 3 MB cache, 2 cores, 2 threads
Intel HD Graphics
Intel® 3rd Generation Celeron® Processors
QuickSpecs
HP Compaq Pro 4300 All-in-One PC
Standard Features and Configurable Components (availability may vary by country)
DA - 14287 North America — Version 24 — November 21, 2013 Page 6

Intel® Celeron® G1620
2.7 GHz base frequency, 2 MB cache, 2 cores, 2 threads
Intel HD Graphics
Supports DDR3 memory up to 1333 MT/s data rate
Intel® Celeron® G1610
2.6 GHz base frequency, 2 MB cache, 2 cores, 2 threads
Intel HD Graphics
Supports DDR3 memory up to 1333 MT/s data rate
Intel® 2nd Generation Celeron® Processors
Intel® Celeron® G555
2.7 GHz base frequency, 2 MB cache, 2 cores, 2 threads
Intel HD Graphics
Supports DDR3 memory up to 1066 MT/s data rate
Intel® Celeron® G550
2.60 GHz base frequency , 2 MB cache, 2 cores, 2 threads
Intel HD Graphics
Intel® Celeron® G540
2.50 GHz base frequency , 2 MB cache, 2 cores, 2 threads
Intel HD Graphics
Intel® Celeron® G460
1.80 GHz base frequency, 1.5 MB cache, 1 core, 2 threads
Intel HD Graphics
Intel® Celeron® G465
1.90 GHz base frequency, 1.5 MB cache, 1 core, 2 threads
Intel HD Graphics
Supports DDR3 memory up to 1066 MT/s data rate
CHIPSET
Intel® H61 Express
SMBIOS
System Management BIOS, previously known as DMI BIOS, is used to store system management information.
GRAPHICS
Integrated (depends on processor)
Intel HD Graphics: Basic, 2500, or 4000
Models with Intel Core i3/i5/i7 processors include HD 2500 or 4000 graphics. Models with Pentium or Celeron processors include
HD graphics. Please see specific processors for graphics configuration.
QuickSpecs
HP Compaq Pro 4300 All-in-One PC
Standard Features and Configurable Components (availability may vary by country)
DA - 14287 North America — Version 24 — November 21, 2013 Page 7

DISPLAY
20" diagonal TN widescreen WLED backlit anti-glare LCD; optional integrated 1.3 MP webcam & single non-array microphone;
maximum resolution of 1600 x 900
Display Panel Type TN (Twisted Nematic) LED Backlit LCD
Viewable image area
(horizontal & vertical)
442.8(H) x 249.075(V) [mm]
Screen opening
(H x V)
446.8(H)×253.2(V) [mm]
Resolution 1600 × 900
Aspect ratio 16:9
Contrast ratio
(typical)
1000:1
Brightness
(typical)
250 nits (cd/m
2
)
Viewing angle
(typical)
85/85/80/80 (L/R/U/D)
Pixel pitch 0.27675(H) x 0.27675(V) [mm]
Backlight lamp life
(to half brightness)
30,000 hours minimum
Color support Over 16 million colors (through FRM)
Color gamut
(typical)
72%
Anti-glare Yes
Default color temperature Warm (6500K)
NOTE: All performance specifications represent the typical specifications provided
by HP's component manufacturers; actual performance may vary either higher or
lower.
Supported Display Modes & Resolutions 1600 x 900
1440 x 900
1366 x 768
1360 x 768
1280 x 800
1280 x 768
1280 x 720
1280 x 600
1152 x 864
1024 x 768
800 x 600
Adjustable Tilt Stand/Tilt Angle -5º to +25º to the vertical plane
QuickSpecs
HP Compaq Pro 4300 All-in-One PC
Standard Features and Configurable Components (availability may vary by country)
DA - 14287 North America — Version 24 — November 21, 2013 Page 8

STORAGE
SATA Hard Drive
250 GB, 7200 rpm, SATA 6.0 Gb/s, SMART IV
500 GB, 7200 rpm, SATA 6.0 Gb/s, SMART IV
1 TB, 7200 rpm, SATA 6.0 Gb/s, SMART IV
Solid State Drive
120 GB, SATA, Solid State Drive
128 GB, SATA, Solid State Drive
160 GB, SATA, Solid State Drive
Self-Encrypting Drive
500 GB, SATA, Self-Encrypting Drive
Self-Encrypting Solid State Drive
256 GB, SATA, Self-Encrypting Solid State Drive
Removable
HP Slim Removable SATA HDD frame/carrier
Optical Disc Drive
Slim Tray-load SATA DVD-ROM
Slim Tray-load SATA SuperMulti DVD Writer
No included ODD
Media Card Reader
HP 4-in-1
Supports Secure Digital (SD, SDHC), Memory Stick, Memory Stick Pro
QuickSpecs
HP Compaq Pro 4300 All-in-One PC
Standard Features and Configurable Components (availability may vary by country)
DA - 14287 North America — Version 24 — November 21, 2013 Page 9

MEMORY
Type
Non-ECC, DDR3 SDRAM, 1600 MHz, SODIMM (runs at 1333 MHz due to chipset)
Maximum
16 GB
# of Slots
2
204-pin supporting dual-channel memory
Maximized dual-channel performance requires SODIMMs of the same size and speed in both memory slots.
NOTE: Full availability of 4 GB or more of memory requires a 64-bit operating system. With Windows 32-bit operating systems,
the amount of usable memory is dependent upon your configuration, so that above 3 GB all memory may not be available due to
system resource requirements.
NETWORKING/COMMUNICATIONS
Ethernet (RJ-45)
Integrated Realtek RTL8111F GbE 10/100/1000
With Wake-on-LAN
NOTE: The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for Gigabit Ethernet, and
does not connote actual operating speed of 1 Gb/s. For high-speed transmission, connection to a Gigabit Ethernet server and
network infrastructure is required.
Wireless
Intel 802.11 a/b/g/n wireless 6205 PCIe minicard (optional)
Up to 300 mbps data rate
HP 802.11 b/g/n wireless PCIe minicard (optional)
Up to 300 mbps data rate
AUDIO/MULTIMEDIA
Realtek ALC269 codec - 16 & 24-bit PCM
Integrated business class 2.0 speakers (2W x 2) with Basic Business Audio
Volume control and mute buttons
Stereo headphone jack
Microphone in
Stereo line out
Optional integrated 1.3 MP webcam & Single Non-Array Microphone - Up to 30 frames/sec
Business quality speakers
QuickSpecs
HP Compaq Pro 4300 All-in-One PC
Standard Features and Configurable Components (availability may vary by country)
DA - 14287 North America — Version 24 — November 21, 2013 Page 10
