Microtower
1. (2) external 5.25" drive bays for optional optical drives 7. (2) full-height PCI 2.3 slots, (1) PCIe x1 slot,
(1) PCIe x16 slot
2. Reset/recovery button 8. (2) internal 3.5" hard drive bays
3. (1) external 3.5" drive bay for optional media reader or Pocket
Media drive
9. PS/2 Scroll Mouse
4. Front I/O includes: (2) USB 2.0 ports, dedicated headphone
output, microphone jack
10. HP Standard Keyboard
5. Standard efficiency Power Supply or optional energy efficient
Power Supply
11. Monitor (sold separately)
6. Rear I/O includes: (4) USB 2.0 ports, serial port, PS/2 mouse
and keyboard ports, RJ-45 network interface, DVI-D and VGA
video interfaces, microphone jack, audio in/out jacks
QuickSpecs
HP Pro 2000 Business PC
Overview
DA - 13494 Worldwide — Version 5 — November 29, 2010 Page 1

At A Glance
Support for Intel® Core™ 2 Duo and Core™ 2 Quad processors, Intel Pentium® processors, Intel Celeron® processors
Genuine Windows 7 versions, Genuine Windows Vista versions, Genuine Windows XP Professional available through downgrade
rights from Windows 7 Professional, SuSE Linux Enterprise Desktop 11, or FreeDOS
Intel G41 Express Chipset
Legacy serial port support
Intel I/O Controller Hub 7 (ICH7)
Intel Graphics Media Accelerator X4500 with DX10 support
PCI Express I/O bus
Serial ATA controller
Realtek 8111DL Gigabit Ethernet Controller
Choice of hard drives and optical drives
DDR3 SDRAM system memory
Optional energy efficient power supply for Microtower
Protected by HP Services. Terms and conditions vary by country. Certain restrictions and exclusions apply.
QuickSpecs
HP Pro 2000 Business PC
Overview
DA - 13494 Worldwide — Version 5 — November 29, 2010 Page 2

Processor and Speed
One of the following
Intel Celeron Processors:
Intel Celeron 440 Processor (2.0-GHz, 512-KB L2 cache, 800-MHz FSB)
Intel Celeron 450 Processor (2.2-GHz, 512-KB L2 cache, 800-MHz FSB)
Intel Celeron Dual-Core Processors:
Intel Celeron E1500 Processor (2.2-GHz, 512K L2 cache, 800-MHz FSB)
Intel Celeron E1600 Processor (2.4-GHz, 512K L2 cache, 800-MHz FSB)
Intel Celeron E3200 Processor (2.4-GHz, 1-MB L2 cache, 800-MHz FSB)
Intel Celeron E3300 Processor (2.5-GHz, 1-MB L2 cache, 800-MHz FSB)
Intel Pentium Dual-Core Processors:
Intel Pentium E5300 Processor (2.6-GHz, 2-MB L2 cache, 800-MHz FSB)
Intel Pentium E5400 Processor (2.7-GHz, 2-MB L2 cache, 800-MHz FSB)
Intel Pentium E6300 Processor (2.8-GHz, 2-MB L2 cache, 1066-MHz FSB)
Intel Core 2 Duo Processors:
Intel Core 2 Duo E7500 Processor (2.93-GHz, 3 MB L2 cache, 1066-MHz FSB)
Intel Core 2 Duo E7600 Processor (3.06-GHz, 3 MB L2 cache, 1066-MHz FSB)
Intel Core 2 Duo E8400 Processor (3.0-GHz, 6 MB L2 cache, 1333-MHz FSB)
Intel Core 2 Duo E8500 Processor (3.16-GHz, 6-MB L2 cache, 1333-MHz FSB)
Intel Core 2 Duo E8600 Processor (3.33-GHz, 6 MB L2 cache, 1333-MHz FSB)
Intel Core 2 Quad Processors:
Intel Core 2 Quad Q8300 Processor (2.5-GHz, 4 MB L2 cache, 1333-MHz FSB)
Intel Core 2 Quad Q8400 Processor (2.66-GHz, 4 MB L2 cache, 1333-MHz FSB)
Intel Core 2 Quad Q9400 Processor (2.66-GHz, 6 MB L2 cache, 1333-MHz FSB)
Intel Core 2 Quad Q9550 Processor (2.83-GHz, 12 MB L2 cache, 1333-MHz FSB)
Intel Core 2 Quad Q9650 Processor (3.0-GHz, 12 MB L2 cache, 1333-MHz FSB)
NOTE: Intel processor numbers are not a measure of performance. Processor numbers differentiate
features within each processor family, not across different processor families.
QuickSpecs
HP Pro 2000 Business PC
Standard Features and Configurable Components (availability may vary by country)
DA - 13494 Worldwide — Version 5 — November 29, 2010 Page 3

Operating Systems and
Application Software
(availability varies by
region)
Genuine Windows 7 Professional Edition (32-bit)
2
Genuine Windows 7 Professional Edition (64-bit)
2
Genuine Windows XP Professional available through downgrade rights from Windows 7
Professional
2,3
Genuine Windows 7 Home Premium Edition (32-bit or 64-bit)
2
Genuine Windows 7 Home Basic Edition (32-bit)
2
Genuine Windows Vista Business (32-bit)
1
Genuine Windows Vista Home Basic (32-bit)
1
Genuine Windows XP Home Basic (China only)
SuSE Linux Enterprise Desktop 11
Red Flag Linux (China only)
FreeDOS
1
Certain Windows Vista product features require advanced or additional hardware. See
www.microsoft.com/windowsvista/getready/hardwarereqs.mspx and
www.microsoft.com/windowsvista/getready/capable.mspx for details. Windows Vista Upgrade Advisor
can help you determine which features of Windows Vista will run on your computer. To download the tool,
visit: www.windowsvista.com/upgradeadvisor .
2
System may require upgraded and/or separately purchased hardware and/or a DVD drive to install the
Windows 7 software and take full advantage of Windows 7 functionality. See
http://www.microsoft.com/windows/windows-7/ for details.
3
Windows 7 Professional disk may be included for future upgrade if desired. To qualify for this downgrade
an end user must be a business (including governmental or educational institutions) and is expected to
order at least 25 customer systems with the same custom image.
2007 Microsoft Office Ready PC
Microsoft Office 2007 Basic
Microsoft Office 2007 Small Business
Microsoft Office 2007 Professional
HP Recovery Manager
Mozilla Firefox for HP Virtual Solutions
Hard Disk Partitioning
Roxio Easy Media Creator 10 **
Core WinDVD 8 **
Core WinDVD BD for Blu-Ray **
McAfee Total Protection Anti-Virus ***
PDF Complete
HP Power Manager v2.0 (Edison)
Credential Manager
HP Total Care Advisor
USB Port Disable
Sun Java Runtime Environment
Welcome Center SMB Offers
** Supporting software available with certain optical drive configurations
*** 60 day trial period for McAfee Total Protection for Small Business software. Internet access required to
receive updates. First update included. Subscription required for updates thereafter.
QuickSpecs
HP Pro 2000 Business PC
Standard Features and Configurable Components (availability may vary by country)
DA - 13494 Worldwide — Version 5 — November 29, 2010 Page 4

Hard Drives 160-GB 7200 rpm Serial ATA 3.0-Gb/s NCQ, SMART
250-GB 7200 rpm Serial ATA 3.0-Gb/s NCQ, SMART
320-GB 7200 rpm Serial ATA 3.0-Gb/s NCQ, SMART
500-GB 7200 rpm Serial ATA 3.0-Gb/s NCQ, SMART
System Memory 1-GB DDR3 Synch DRAM PC3-10600 (1066/1333-MHz) Non-ECC (1 x 1GB)
2-GB DDR3 Synch DRAM PC3-10600 (1066/1333-MHz) Non-ECC (2 x 1GB)
2-GB DDR3 Synch DRAM PC3-10600 (1066/1333-MHz) Non-ECC (1 x 2GB)
3-GB DDR3 Synch DRAM PC3-10600 (1066/1333-MHz) Non-ECC (1 x 1GB + 1 x 2GB)
4-GB DDR3 Synch DRAM PC3-10600 (1066/1333-MHz) Non-ECC (2 x 2GB)
NOTE: Memory runs at maximum system supported speed of 1066 MHz, or at 800 MHz when processor
has 800-MHz FSB. For systems configured with more than 3 GB of memory and a 32-bit operating system,
all memory may not be available due to system resource requirements. Addressing memory above 4 GB
requires a 64-bit operating system.
Storage –
One or more of the
following (see Storage
section below)
USB Pocket Media Drive (PMD) and Bay
HP 3.5-inch Pocket Media Drive Bay
HP 320GB 3.5-inch Pocket Media Drive with Bay
Diskette Drive
1.44 MB Diskette Drive
Media Reader
HP 22-in-1 Media Card Reader
Optical Drives (Serial ATA)
SATA DVD-ROM Drive
SATA SuperMulti LightScribe DVD Writer
HP SATA Blu-ray Writer
Input Devices Keyboard – One of the following
HP PS/2 Standard Keyboard
HP USB PS/2 Washable Keyboard
HP USB Standard Keyboard
HP USB Mini Keyboard
HP USB Smartcard Keyboard
Mouse – One of the following
PS/2 2-Button Optical Scroll Mouse
USB 2-Button Optical Scroll Mouse
USB 2-Button Laser Mouse
QuickSpecs
HP Pro 2000 Business PC
Standard Features and Configurable Components (availability may vary by country)
DA - 13494 Worldwide — Version 5 — November 29, 2010 Page 5

Audio Realtek ALC662 High Definition audio codec
Internal PC speaker
HP USB Thin Powered Speakers
Communication Realtek 8111DL GbE Ethernet Controller
Intel Gigabit CT Desktop NIC
LSI PCIe x1 56K International SoftModem
Graphics Intel Graphics Media Accelerator X4500
ATI Radeon HD 4350 (512MB) FH PCIe x16 Card
ATI Radeon HD 4550 (256MB) DH PCIe x16 Graphics Card (available through January 2010)
ATI Radeon HD 4550 (512MB) DH PCIe x16 Graphics Card (available after January 2010)
ATI Radeon HD 4650 1GB Dual Head PCIe x16 Card
NVIDIA GeForce G210 512MB ATX PCIe x16
NVIDIA GeForce GT230 1.5GB PCIe x16 Card
NVIDIA GeForce 205 512MB ATX PCIe x16
NVIDIA GeForce 315 1GB ATX PCIex16
DMS-59 To Dual DVI Y-Cable Adapter
Miscellaneous Hood Sensor
Port Control Cover
HP Chassis Security Kit
HP Parallel Port Adapter
HP Serial Port Full Height Adapter
HP Serial/Parallel PCI Card
HP 1394a FireWire 400 PCI Card
QuickSpecs
HP Pro 2000 Business PC
Standard Features and Configurable Components (availability may vary by country)
DA - 13494 Worldwide — Version 5 — November 29, 2010 Page 6

Base Unit Micro ATX Microtower chassis, including power supply and front bezel; five (5) drive bays and four
expansion slots
Active type heatsink
92 x 92 x 25 mm chassis fan for Microtower chassis
System board with Intel G41 Express chipset, Intel I/O Controller Hub 7 (ICH7), Realtek RTL8111DL
Ethernet controller, Intel GMA X4500 graphics, and Realtek audio, (1) PCI Express x1 slots, (1) PCI
Express x16 slot, (2) PCI, (2) DDR3 DIMM memory slots, (4) Serial ATA data connectors, (6) USB Ports
(see USB support below), (1)VGA, (1)DVI-D port, (1) serial port in the rear IO
Power cord
Slots PCI One (1) PCI Express x1 slots on PCA
One (1) PCI Express x16 slot on PCA (for graphic cards)
Two (2) PCI slots on PCA
Memory Expansion Two (2) DDR3 SDRAM DIMM slots (4 GB maximum memory support)
NOTE: For systems configured with more than 3 GB of memory and a 32-bit operating system, all memory
may not be available due to system resource requirements. Addressing memory above 4 GB requires a 64-
bit operating system.
Bays Internal Two (2) 3.5-inch
External Two (2) 5.25-inch; One (1) 3.5-inch
USB Support EHCI high-speed USB 2.0 controller
Two (2) front ports; Four (4) rear ports
Four (4) internal ports on system board:
2 for front ports
2 for media card reader
Interfaces (Legacy) One (1) PS/2 keyboard port
One (1) PS/2 mouse port
One (1) analog VGA video port
One (1) DVI-D video port
One (1) serial port
One (1) line in; one (1) line out; one (1) microphone in
One (1) RJ45 network port
QuickSpecs
HP Pro 2000 Business PC
System Details
DA - 13494 Worldwide — Version 5 — November 29, 2010 Page 7

Weight & Dimensions Chassis Dimensions
(H x W x D)
15.14 x 7.27 x 16.36 in
385 x 185 x 416 mm
Packaged Dimensions
(D x L x W)
19.63 x 24.13 x 10.56 in
498.6 x 613 x 268.2 mm
System Weight 16.66 lb (7.56 kg)
Shipping Weight 24.63 lb (11.17 kg)
Technology and Features Memory Type PC3-10600 DDR3 SDRAM (1066/1333MHz) non-ECC
Up to 4 GB system memory standard
NOTE: Memory runs at maximum system supported speed of 1066 MHz, or at 800 MHz when processor
has 800-MHz FSB. For systems configured with more than 3 GB of memory and a 32-bit operating system,
all memory may not be available due to system resource requirements. Addressing memory above 4 GB
requires a 64-bit operating system.
Hard Drive Interfaces
Supported
Serial ATA, NCQ support
Chassis Front Panel Power button
Power On LED
HDD Activity LED
Reset/recovery button (MT only) *
Cooling Solutions
Supported
Power Supply Fan (variable speed)
Active heatsink (variable speed)
Chassis fan (variable speed)
Slots Supported Four (4) full-height expansion slots
Front I/O Two (2) USB 2.0 ports, Headphone, Mic
Rear I/O Standard Micro ATX I/O connectors, including four(4) USB 2.0 ports, serial
ports
Drive Bays Two (2) 5.25-inch (13.335 cm) half height external
One (1) 3.5-inch (8.89 cm) half height external
Two (2) 3.5-inch half height internal
Internal Speaker Optional for APJ
Security Padlock loop
Kensington Lock Support
Noble Universal Clamp Lock Cable Kit
Port Control Cover supported
Power Supply 250W PFC HV immunity (410V/s) with a 115v/230v line switch (varies by
country/region) as Standard configuration , and 300W PFC HV immunity
(410V/s) with a 115v/230v line switch and 300W 85% Efficiency power supply
as option
*Reset function will be set for China/Hong Kong/Korea; Recovery function will be set for all other regions.
QuickSpecs
HP Pro 2000 Business PC
System Details
DA - 13494 Worldwide — Version 5 — November 29, 2010 Page 8

Unit Environment and
Operating Conditions
General Unit Operating Guidelines
Keep the computer away from excessive moisture, direct moisture and the extremes of heat and
cold, to ensure that unit is operated within the specified operating range.
Leave a 4 in (10.2 cm) clearance on all vented sides of the computer to permit the required airflow.
Never restrict airflow into the computer by blocking any vents or air intakes.
Do not stack computers on top of each other or place computers so near each other that they are
subject to each other's re-circulated or preheated air.
Occasionally clean the air vents on the front, back, and any other vented side of the computer. Lint,
dust and other foreign matter can block the vents and limit the airflow.
If the computer is to be operated within a separate enclosure, intake and exhaust ventilation must
be provided on the enclosure, and the same operating guidelines listed above will still apply.
Temperature Range Operating 41° to 95° F (5° to 35° C)
Non-operating -22° to 149° F (-30° to 65° C)
Relative Humidity Operating 10% to 90% (non-condensing at ambient)
Non-operating 5% to 95% (non-condensing at ambient)
Maximum Altitude
(unpressurized)
Operating 10,000 ft (3048 m)
Non-operating 30,000 ft (9144 m)
NOTE: Operating temperature is de-rated 1.0 deg C per 1000 ft (300 m) to 7500 ft (2286 m) above sea
level, no direct sustained sunlight. Maximum rate of change is 7.5 deg C/Hr. The upper limit may be limited
by the type and number of options installed.
System Board Processor Socket T; LGA775 industry standard Micro ATX form factor
Support single Intel Core 2 Duo and Core 2 Quad, Pentium dual-core, or
Celeron processors
Chipset Intel G41 Express
Intel I/O Controller Hub 7 (ICH7)
Front Side Bus Frequency 800/1066/1333 MHz
Memory DDR3 SDRAM
2 x DIMM slots
Integrated Graphics Intel Graphics Media Accelerator (GMA) X4500
Audio Realtek ALC662 HD Audio compatible codec with two channel audio 3D audio
compliant with AC'97 rev. 2.3
LOM Realtek RTL8111DL
Storage Four Serial ATA interfaces
Expansion Slots 1 x PCI Express x1 slots
1 x PCI Express x16 slot
2 X PCI
BIOS SPI FLASH ROM
Industrial Standard PCIe compliant
USB 2.0
Rear I/O Ports 1 x PS/2 keyboard port
1 x PS/2 mouse port
4 x USB 2.0 ports
QuickSpecs
HP Pro 2000 Business PC
System Details
DA - 13494 Worldwide — Version 5 — November 29, 2010 Page 9

1 x RJ-45 10/100/1000 port
1 x serial port
1 x DVI-D video port
1 x DB 15-pin analog VGA port
3 x audio ports
On Board I/O Interfaces 1 x ATX power connector
1 x +12V power connector
1 x Floppy connector
1 x header (1 – 1x3) to support hood sensor
1x COM2 header
1x Parallel header
1 x Front panel connector, Switch, LED (ON/Flash/OFF)
2 x Fan headers for CPU, chassis, with voltage/fan speed control
1 x header (1 – 2x5, ) to support 2 USB 2.0 ports at front side
1 x header (1 – 2x5) to support USB Card Media Reader
1 x header (1 – 1x2) to support one touch reset
1 x header (1 –- 1x2) to support one touch recovery
1 x header to support 2 front (Headphone/Mic) audio ports
Board Size Micro-ATX, PCB Size: 9.6 x 9.6 in (24.38 x 24.38 cm)
4-layer PCB with green color
Additional Features Bootable without keyboard, mouse or monitor
Keyboard/mouse/USB wake up
Support S3, S4 and S5
ACPI status
Hardware monitor capability
CPU fan speed control
One button reset/recovery *
*Reset function will be set for China/Hong Kong/Korea; Recovery function will
be set for the other regions.
Network Interface Realtek 8111DL GbE Ethernet Controller
Intel Gigabit CT Desktop NIC
Modem LSI PCIe x1 56K International SoftModem
QuickSpecs
HP Pro 2000 Business PC
System Details
DA - 13494 Worldwide — Version 5 — November 29, 2010 Page 10
