HP ProOne 600 G3 Installation instructions

EL-MF877-00 Page 1
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Product End-of-Life Disassembly Instructions
Product Category: Personal Computers
Marketing Name / Model
[List multiple models if applicable.]
HP ProOne 600 G3 Non-Touch All-in-One Business PC
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions
for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU
directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
1.0 Items Requiring Selective Treatment
1.1 Items listed below are classified as requiring selective treatment.
1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as
applicable.
Item Description
Notes
Quantity
of items
included
in product
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA)
With a surface greater than 10 sq cm
2
Batteries
All types including standard alkaline and lithium coin
or button style batteries
1
Mercury-containing components
For example, mercury in lamps, display backlights,
scanner lamps, switches, batteries
0
Liquid Crystal Displays (LCD) with a surface greater
than 100 sq cm
Includes background illuminated displays with gas
discharge lamps
1
Cathode Ray Tubes (CRT)
0
Capacitors / condensers (Containing PCB/PCT)
0
Electrolytic Capacitors / Condensers measuring
greater than 2.5 cm in diameter or height
7
External electrical cables and cords
1
Gas Discharge Lamps
0
Plastics containing Brominated Flame Retardants
weighing > 25 grams (not including PCBs or PCAs
already listed as a separate item above)
0
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and toner
Include the cartridges, print heads, tubes, vent
chambers, and service stations.
0
Components and waste containing asbestos
0
Components, parts and materials containing
0

EL-MF877-00 Page 2
Template Revision B
PSG instructions for this template are available at EL-MF877-01
refractory ceramic fibers
Components, parts and materials containing
radioactive substances
0
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Description
Tool Size (if
applicable)
Electric screwdriver (Torx)
T15, Torx
Electric screwdriver (Cross)
#0, Cross
Plastic stick
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. Follow steps described in Disassembly instruction (file attached)
2. If parts can be removed without using a tool, remove it first
3. Use correct screwdriver and torque value before unlock the screw.
4.
5.
6.
7.
8.
9.
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).

MANUFACTURING PROCESS INSTRUCTIONS
MECHANICAL ASSEMBLY
MODEL : Pegasus600
1.00
Station Version Station Version Station Version Station Version Station Version Station Version
11.00 91.00 17 1.00 25 1.00
2 1.00 10 1.00 18 1.00 26 1.00
3 1.00 11 1.00 19 1.00 27 1.00
4 1.00 12 1.00 20 1.00
5 1.00 13 1.00 21 1.00
6 1.00 14 1.00 22 1.00
7 1.00 15 1.00 23 1.00
8 1.00 16 1.00 24 1.00
Station
Ver.
ALL 1.**
2017/5/23
Date
Content
Date:
Porter Zan
First version
2017/5/23
A.Current station version list:
B.Version Modify list:
Sub-assembly name:
Pegasus600 DISASS'Y SOP
Document No.:
Pegasus600 DISASS'Y SOP
Page:
Design
Revision:
Written by:
Ethan Lai
1 of 1
Auditor ：Xin-Xin Chen Tabulator：
Ethan Lai

Standard Operation Procedure
Tabulator：Issue Department：
Xin-Xin Chen NPSU-PPE
Auditor ：Ethan Lai
Steps：
Document No. : Pegasus600 DISASS’Y SOP Station :
Operation Name : Ver. : Date :
Note: If finding anything uncommon, notice foreman or assistant at once.
Fixture list (Specification) Qty. Fixture list (Specification) Qty.
Remove Stand
1. Take out Stand and put into the material box
(Fig. 1, 2).
Follow the steps as Fig. 1 & 2, push the
black button, then pull up Stand.
Glove Requirements: Half-fingered gloves
Fig. 1
Fig. 2
1(1/1)
2017/5/23
1.00
Push the black button
Pull up Stand

Standard Operation Procedure
Tabulator：Issue Department：
Xin-Xin Chen NPSU-PPE
Auditor ：Ethan Lai
Steps：
Document No. : Pegasus600 DISASS’Y SOP Station :
Operation Name : Ver. : Date :
Note: If finding anything uncommon, notice foreman or assistant at once.
Fixture list (Specification) Qty. Fixture list (Specification) Qty.
Take out Rear Cover
1. Follow the direction of red arrow to push
Rear Cover (Fig. 1).
2. Follow the sequence to pull open Rear Cover
and take it out. (Fig. 1).
Operating sequence: Bottom side → Left
side → Right side.
Glove Requirements: Half-fingered gloves
2(1/1)
2017/5/23
1.00
Fig. 1
Right side
Bottom side
Left side

Standard Operation Procedure
Tabulator：Issue Department：
Xin-Xin Chen NPSU-PPE
Auditor ：Ethan Lai
Steps：
Document No. : Pegasus600 DISASS’Y SOP Station :
Operation Name : Ver. : Date :
Note: If finding anything uncommon, notice foreman or assistant at once.
Fixture list (Specification) Qty. Fixture list (Specification) Qty.
3(1/1)
2017/5/23
1.00
Glove Requirements: Half-fingered gloves
Take out M/B shielding
Fig. 1
1. Take out M/B shielding (Fig. 1).
Follow the direction of red arrow to pull open
the spring, then pull up obliquely to take out
the shielding along the direction of upper left
corner.
Notice the hooks in red box in Fig. 1.
Obliquely take
out the shielding
along the
direction of
upper left corner
Pull open
the spring

Standard Operation Procedure
Tabulator：Issue Department：
Xin-Xin Chen NPSU-PPE
Auditor ：Ethan Lai
Steps：
Document No. : Pegasus600 DISASS’Y SOP Station :
Operation Name : Ver. : Date :
Note: If finding anything uncommon, notice foreman or assistant at once.
Fixture list (Specification) Qty. Fixture list (Specification) Qty.
4(1/1)
2017/5/23
1.00
Glove Requirements: Half-fingered gloves
Electric Screwdriver (S-6000MS) 1
Bits Type: T15,φ=5mm,L=60mm 1
Take out Thermal Module
Fig. 1
1. Unscrew (Torx Pin-Head ×5) all joints to
take out Thermal Module (Fig. 1).
Torsion: 4.0 ±1.0 kgf.cm
Take the screwdriver vertically to the screw
holes.
2. Put Thermal Module into the material box.
5
1
23
4

Standard Operation Procedure
Tabulator：Issue Department：
Xin-Xin Chen NPSU-PPE
Auditor ：Ethan Lai
Steps：
Document No. : Pegasus600 DISASS’Y SOP Station :
Operation Name : Ver. : Date :
Note: If finding anything uncommon, notice foreman or assistant at once.
Fixture list (Specification) Qty. Fixture list (Specification) Qty.
Take out HDD and ODD
5(1/1)
2017/5/23
1.00
Glove Requirements: Half-finger gloves
1. Take out HDD (Fig. 1).
Pull open the HDD bracket softly to the right,
and push upward HDD to disconnect, then
put it into the material box.
2. Take out ODD (Fig. 2).
Press the latch and push ODD to the left
simultaneously to disconnect, then put ODD
into the material box.
Fig. 1
Fig. 2
Push

Standard Operation Procedure
Tabulator：Issue Department：
Xin-Xin Chen NPSU-PPE
Auditor ：Ethan Lai
Steps：
Document No. : Pegasus600 DISASS’Y SOP Station :
Operation Name : Ver. : Date :
Note: If finding anything uncommon, notice foreman or assistant at once.
Fixture list (Specification) Qty. Fixture list (Specification) Qty.
6(1/1)
2017/5/23
1.00
Glove Requirements: Half-fingered gloves
Electric Screwdriver (S-3000MS) 1
Bits Type: #0,φ=5mm,L=60mm 1
Take out I/O board
Fig. 2
1. Unscrew (×2) all joints to take out I/O board
and disconnect I/O cable (Fig. 1, 2).
Torsion: 4.0 ±1.0 kgf.cm
Take the screwdriver vertically to the screw
holes.
Put I/O board and two screws into the
material box.
Switch can’t fall off.
2. Be careful not to make the pin heads of the
I/O connector are crooked (Fig. 3).
Pull out the I/O cable vertically from the top
of the I/O connector.

Fig. 1
Fig. 3
Switch
Follow the
routing to pull
out I/O cable

Standard Operation Procedure
Tabulator：Issue Department：
Xin-Xin Chen NPSU-PPE
Auditor ：Ethan Lai
Steps：
Document No. : Pegasus600 DISASS’Y SOP Station :
Operation Name : Ver. : Date :
Note: If finding anything uncommon, notice foreman or assistant at once.
Fixture list (Specification) Qty. Fixture list (Specification) Qty.
Take out DDR and CPU
1
7(1/1)
2017/5/23
1.00
Ion fan 1
Glove Requirements: Half-finger gloves
1. Take out DDR and put it into the material box
(Fig. 1).
Expand the springs on the both sides of the
DDR socket.
2. Take out CPU illustrated as Fig. 2, then put it
into the tray.
Don’t touch the pin heads of CPU.
Open the bracket by pulling off the link and
take out CPU.
Fig. 1
2. Open the bracket
by pulling off the link
1. Press the link and
push it to the right
Press the fixture, then
take out CPU vertically
CPU DISASS’Y steps:
Diagonally
consistent
Fig. 2
DDR

Standard Operation Procedure
Tabulator：Issue Department：
Xin-Xin Chen NPSU-PPE
Auditor ：Ethan Lai
Steps：
Document No. : Pegasus600 DISASS’Y SOP Station :
Operation Name : Ver. : Date :
Note: If finding anything uncommon, notice foreman or assistant at once.
Fixture list (Specification) Qty. Fixture list (Specification) Qty.
Take out Top Vent
8(1/1)
2017/5/23
1.00
1. Unscrew (×5) all joints of Top Vent illustrated
as Fig. 1.
Torsion: 4.0 ±0.5 kgf.cm
Take the screwdriver vertically to the screw
holes.
Put the screws into the material box.
2. Follow the unscrewing sequence to take out
Top Vent.
Don't pull it using force.
Glove Requirements: Half-finger gloves
Fig. 1
Electric Screwdriver (S-4000MS) 1
Bits Type: T15,φ=5mm,L=60mm 1
15
4
3
2

Standard Operation Procedure
Tabulator：Issue Department：
Xin-Xin Chen NPSU-PPE
Auditor ：Ethan Lai
Steps：
Document No. : Pegasus600 DISASS’Y SOP Station :
Operation Name : Ver. : Date :
Note: If finding anything uncommon, notice foreman or assistant at once.
Fixture list (Specification) Qty. Fixture list (Specification) Qty.
Take out Center IO Door & unscrewing
9(1/1)
2017/5/23
1.00
1. Unscrew (×5) all joints illustrated as Fig. 1 &
Fig. 3.
Torsion: 4.0 ±0.5 kgf.cm
Take the screwdriver vertically to the screw
holes.
Put the screws into the material box.
2. Take out Center IO Door (Fig. 2).
3. Take out Center Cover (Fig. 1).
Glove Requirements: Half-finger gloves
Fig. 3
Electric Screwdriver (S-4000MS) 1
Bits Type: T15,φ=5mm,L=60mm 1
2
3
5
4
Take out to
the right
IO Door
Pull out
vertically
Fig. 1
Fig. 2
1
K-LOCK
screw

Standard Operation Procedure
Tabulator：Issue Department：
Xin-Xin Chen NPSU-PPE
Auditor ：Ethan Lai
Steps：
Document No. : Pegasus600 DISASS’Y SOP Station :
Operation Name : Ver. : Date :
Note: If finding anything uncommon, notice foreman or assistant at once.
Fixture list (Specification) Qty. Fixture list (Specification) Qty.
Take out Speaker
10(1/1)
2017/5/23
1.00
1. Unscrew (Torx Pin-Head ×4) all joints of
Speaker (Fig. 2).
Torsion: 4.0 ±1.0 kgf.cm
Take the screwdriver vertically to the screw
holes.
2. Take out Speaker (Fig. 2).
Don’t lose the four rubber rings of Speaker.
No obvious defect in the surface.
First pull out the cable from the hook and
don't pull it using force (Fig. 1).
Glove Requirements: Half-finger gloves
Fig. 2
Electric Screwdriver (S-4000MS) 1
Bits Type: T15,φ=5mm,L=60mm 1
Fig. 1
3
4
2
1
Don’t pull
out on this
location


Standard Operation Procedure
Tabulator：Issue Department：
Xin-Xin Chen NPSU-PPE
Auditor ：Ethan Lai
Steps：
Document No. : Pegasus600 DISASS’Y SOP Station :
Operation Name : Ver. : Date :
Note: If finding anything uncommon, notice foreman or assistant at once.
Fixture list (Specification) Qty. Fixture list (Specification) Qty.
Take out Vesa Mount
11(1/1)
2017/5/23
1.00
1. Unscrew (×4) all joints to take out Vesa
Mount illustrated as Fig. 1 & 2.
Torsion: 6.0 ±0.5 kgf.cm
Take the screwdriver vertically to the screw
holes.
Put the screws into the material box.
Glove Requirements: Half-finger gloves
Fig. 2
Fig. 1
Electric Screwdriver (S-4000MS) 1
Bits Type: T15,φ=5mm,L=60mm 1
2
1
4
3

Standard Operation Procedure
Tabulator：Issue Department：
Xin-Xin Chen NPSU-PPE
Auditor ：Ethan Lai
Steps：
Document No. : Pegasus600 DISASS’Y SOP Station :
Operation Name : Ver. : Date :
Note: If finding anything uncommon, notice foreman or assistant at once.
Fixture list (Specification) Qty. Fixture list (Specification) Qty.
Take out PSU
12(1/1)
2017/5/23
1.00
1. Disconnect PSU cable from the connector of
M/B side, then take out PSU into the material
box (Fig. 1, 2).
Glove Requirements: Half-finger gloves
Fig. 1
Fig. 2

Standard Operation Procedure
Tabulator：Issue Department：
Xin-Xin Chen NPSU-PPE
Auditor ：Ethan Lai
Steps：
Document No. : Pegasus600 DISASS’Y SOP Station :
Operation Name : Ver. : Date :
Note: If finding anything uncommon, notice foreman or assistant at once.
Fixture list (Specification) Qty. Fixture list (Specification) Qty.
Take out FAN & disconnect LVDS cable
13(1/1)
2017/5/23
1.00
1. Disconnect FAN cable-1 & 2 and LVDS cable
from the connectors of M/B side (Fig. 2, 3).
Pull out FAN cable from the hook carefully.
2. Unscrew (×4) all joints to take out FAN
illustrated as Fig. 1.
Torsion: 4.0 ±0.5 kgf.cm
Take the screwdriver vertically to the screw
holes.
Glove Requirements: Half-finger gloves
Fig. 1
Electric Screwdriver (S-4000MS) 1
Bits Type: T15,φ=5mm,L=60mm 1
Fig. 2
Pull out
counterclockwise
from the hooks
Pull black PIN1
Pull white PIN2
Fig. 2

Standard Operation Procedure
Tabulator：Issue Department：
Xin-Xin Chen NPSU-PPE
Auditor ：Ethan Lai
Steps：
Document No. : Pegasus600 DISASS’Y SOP Station :
Operation Name : Ver. : Date :
Note: If finding anything uncommon, notice foreman or assistant at once.
Fixture list (Specification) Qty. Fixture list (Specification) Qty.
Unscrew ODD SATACNTR
14(1/1)
2017/5/23
1.00
1. Unscrew (Torx Pin-Head ×2) all joints of
ODD SATACNTR, then take out ODD cable
(Fig. 1, 2).
Don't pull the cable using force.
Torsion: 4.0 ±0.5 kgf.cm
Take the screwdriver vertically to the screw
holes.
Glove Requirements: Half-finger gloves
Fig. 2
Electric Screwdriver (S-4000MS) 1
Bits Type: T15,φ=5mm,L=60mm 1
Fig. 1
1
2
ODD cable

Standard Operation Procedure
Tabulator：Issue Department：
Xin-Xin Chen NPSU-PPE
Auditor ：Ethan Lai
Steps：
Document No. : Pegasus600 DISASS’Y SOP Station :
Operation Name : Ver. : Date :
Note: If finding anything uncommon, notice foreman or assistant at once.
Fixture list (Specification) Qty. Fixture list (Specification) Qty.
Disconnect cables
15(1/1)
2017/5/23
1.00
1. Disconnect ODD SATA cable, HDD SATA
cable and Power cable from the connectors
of M/B side (Fig. 2).
2. Pull out Backlight cable from the hooks, then
pull out it vertically from the top of connector
on M/B (Fig. 1).
Be careful not to make the pin heads of the
connector are crooked.
Glove Requirements: Half-finger gloves
Fig. 1
Fig. 2
白線
HDD SATA
ODD SATA
Power
CNTR

Standard Operation Procedure
Tabulator：Issue Department：
Xin-Xin Chen NPSU-PPE
Auditor ：Ethan Lai
Steps：
Document No. : Pegasus600 DISASS’Y SOP Station :
Operation Name : Ver. : Date :
Note: If finding anything uncommon, notice foreman or assistant at once.
Fixture list (Specification) Qty. Fixture list (Specification) Qty.
Take out Wireless LAN/ M.2 SSD
16(1/1)
2017/5/23
1.00
1. Tear off the acetate tapes (×2) illustrated as
Fig. 2.
2. Disconnect WLAN antenna cables illustrated
as Fig. 1.
3. Unscrew (Cross ×1) one screw to take out
M.2 SSD (Fig. 4).
Torsion: 2.5 ±0.5 kgf.cm
Take the screwdriver vertically to the screw
holes.
4. Unscrew (Cross ×1) one screw to take out
WLAN card (Fig. 1, 3).
Torsion: 2.5 ±0.5 kgf.cm
Take the screwdriver vertically to the screw
holes.
Glove Requirements: Half-finger gloves
Fig. 1
Electric Screwdriver (S-3000MS) 1
Bits Type: #0,Cross,φ=5mm,L=60mm 1
Screw Fig. 2
Fig. 3
Tear off the
acetate tape-2
Tear off the
acetate tape-1
Screw
Pull out white
antenna-2
Pull out black
antenna-1
Screw
”Intel” Fig. 4

Standard Operation Procedure
Tabulator：Issue Department：
Xin-Xin Chen NPSU-PPE
Auditor ：Ethan Lai
Steps：
Document No. : Pegasus600 DISASS’Y SOP Station :
Operation Name : Ver. : Date :
Note: If finding anything uncommon, notice foreman or assistant at once.
Fixture list (Specification) Qty. Fixture list (Specification) Qty.
Take out Middle Band-R
17(1/1)
2017/5/23
1.00
1. Unscrew (×6) all joints to take out Middle
Band-R illustrated as Fig. 1.
Torsion: 4.0 ±0.5 kgf.cm
Take the screwdriver vertically to the screw
holes.
Glove Requirements: Half-finger gloves
Fig. 1
Electric Screwdriver (S-4000MS) 1
Bits Type: T15,φ=5mm,L=60mm 1
1
2
3
4
5
6
