1 Getting Started
The following important information must be adhered to for proper
removal and replacement of all Hewlett-Packard parts.

6Chapter1
Getting Started
Safety Warnings
Safety Warnings
WARNING Removing the device cover may expose sharp edges in the
equipment chassis. To avoid injury, use care when installing
customer add-on devices.
NOTE Before performing removal/replacement procedures, position the
workstation on a cushioned flat, stable surface, such as a table top or
workbench.
NOTE Installing the recommended HP replacement part in your J5000
workstation does not affect the regulatory and safety classifications or
approvals listed in the original owner’s guide.
Electrostatic Discharge (ESD) Precautions
To prevent damage to the J5000 workstation, observe all of the following
ESD precautions while performing removal and replacement procedures:
• Remove all ESD-generating materials from the work area in which
you will remove and replace the workstation field replaceable unit(s).
• Open the ESD materials provided with the replacement part kit.
Unfold the black conductive sheeting (antistatic mat) and place it
under a corner of the workstation.
• Wear a static strap to ensure that any accumulated electrostatic
charge is discharged from your body to ground. Attach the
static-grounding wrist strap by following the instructions on the
package. Attach the sticky end of the wrist strap to bare metal on the
rear panel of the workstation.
• Connect all equipment together, including the static-free mat, static
strap, clips attached to the wrist strap, nodes, and peripheral units.

Chapter 1 7
Getting Started
Safety Warnings
• Keep uninstalled printed circuit boards in their protective antistatic
bags.
• Once you have removed printed circuit boards from their protective
antistatic bags, handle the printed circuit boards by their edges only.
• Ensure you have a sufficient ESD protected area on which to lay out
the parts you remove from the system.

8Chapter1
Getting Started
Replacement Part Kit Contents
Replacement Part Kit Contents
Take a moment to verify that your kit contains the following contents:
• System board upgrade tray assembly
• Electrostatic Discharge (ESD) materials
• Removal/Replacement Instructions
If you are missing any part or any documentation, please call your
designated service representative.
Required Tools
You will need the following tools for removal/replacement procedures:
• T-10 and/or T-15 Torx drivers
• ESD materials

Chapter 1 9
Getting Started
Upgrade Instructions Overview
Upgrade Instructions Overview
The steps for performing the upgrade are outlined below and should be
performed in the sequence listed. Refer to individual sections of this
guide for step-by-step procedures for upgrading a J5000 to a J5600.
1. Prepare your workstation
- Verify that you have the correct version of HP-UX.
- Determine and WRITE DOWN the LAN ID of your system. You may
need to re-enter it after installing the new system board.
- Power off the workstation and any peripherals.
- Unplug the power.
2. Remove the front panel.
3. Remove the top panel.
4. Remove the side panels.
5. Disconnect the flex cable.
6. Remove the bus bar shield.
7. Remove the memory card(s) (DIMMs).
8. Disconnect the system board cables.
9. Remove the old system board.
10.Install the new system board.
11.Reconnect the system board cables.
12.Reinstall the memory card(s) (DIMMs).
13.Reinstall the bus bar shield.
14.Reconnect the flex cable.
15.Replace the side panels.
16.Replace the top panel.
17.Replace the front panel.
18.Verify system operations.

10 Chapter1
Getting Started
Preparing Your Workstation
Preparing Your Workstation
The workstation must be running HP-UX 10.20 with Additional Core
Enhancements (ACE4) 9906 or later to accommodate the PA8600
upgrade. It should report B.10.20. If the workstation is running an older
version of HP-UX, update the operating system software before
continuing. Use the command /usr/sbin/swlist -l bundle | grep ACE to
view what software products are loaded in your system. If the product
list includes B6193DA, you do not need to update HP-UX.
1. Determine the workstation’s LAN ID by entering the following
command: /usr/sbin/lanscan.
The output is similar to the following:
Hardware Station Crd Hardware Net-Interface NM MAC HP DLPI Mjr
Path Address In# State NameUnit State ID Type Support Num
2.0.2 0x08000970ECC0 0 UP lan0 UP 4 ETHER YES 130
Record the LAN ID here. You will need it after installing the new
system board:
Enter LAN ID: ___ ___ ___ ___ ___ ___ -___ ___ ___ ___ ___ ___
You must supply the dash (-) between the first six digits and the last
six digits
After you install the new system board and power on the system for
the first time, you may be prompted for the LAN ID.
2. Power down the system as described in the next section.

Chapter 1 11
Getting Started
Safely Powering Down the J5000 Workstation
Safely Powering Down the J5000 Workstation
You must complete the following steps before performing any of the
removal and replacement procedures:
CAUTION Do not use the power supply interlock thumbscrew on the rear panel to
power down the workstation. This power down method may hang the
operating system in an unrecoverable state.
NOTE Remove any accessory bag(s) and their black tab screws, if present, from
the rear of the workstation.
1. Power off the workstation by simply pressing the power switch on the
front panel of the workstation. Also, power off the monitor and any
attached peripheral devices.
If necessary, shut down the workstation by executing “shutdown -h”
as user root). This ensures that all programs are terminated and all
data is saved before switching the power off.
2. After 30 seconds, unplug the workstation’s power cord and all
peripheral devices from AC power outlets. Before attempting to move
the workstation to a disassembly area, disconnect all peripherals
from the back of the system.
3. Place the workstation on a flat, stable surface, such as a tabletop or
floor. To protect against scratches, remove miscellaneous debris from
the work surface.

12 Chapter1
Getting Started
Product Exploded Diagram
Product Exploded Diagram
Refer to the figure below for a basic parts overview of the J5000/J7000
workstation.
Power supply fo
r
J7000 (top) and
J5000 (bottom)
Flex cable
Flex cable
retainer
Top panel
CD
EMI
cover
Front bezel
I/O board
PCI
retainer
clip
Bus bar shield
Right side panel
DC/DC converter
units and
tie downs
for J7000
Left side panel Chassis
DDS-3/floppy
EMI cover
SCA hard
disk interface
CD drive
carrier
I/O cooling fan
and speaker
Hard disk
drive carrier
Power
switch/LCD
J5000 system board
tray assembly
DDS-3/floppy
drive carrier
Rear and
front air dividers
for J7000 J7000 system board
tray assembly
System board
cooling fans

13
2 System Board
Removal/Replacement
This chapter describes how to remove and replace the System Board for
the J5000 workstation.

14 Chapter2
System Board Removal/Replacement
Removing the Front Panel
Removing the Front Panel
1. Power down your workstation as described in “Getting Started.” If
locked, unlock the door on the front of the system and swing it to the
right (see Step 1 in the figure below).
2. Once the door is open, unscrew the two panel-detach screws in the top
and bottom corners of the right edge of the panel. These screws are
visible when the door is open (Step 2 in the figure below).
3. Swing the entire front panel 45oto 90oto the left (Step 3 in the figure
below).
4. Pull the panel straight out to remove it (Step 4 in the figure below).
Set the panel and its screws aside.
Figure 2-1 Removing the Front Panel
1
4
3
2
4

Chapter 2 15
System Board Removal/Replacement
Removing the Front Panel
Figure 2-2 Front Panel Removed
Panel Hinge Holes
Panel-Detach Screw Holes

16 Chapter2
System Board Removal/Replacement
Removing the Top and Side Panels
Removing the Top and Side Panels
1. Facing the back of the workstation, remove the T-15 Torx thumbscrew
located in each top corner of the back of the workstation. The upper
left one (when facing the back of the workstation) is the power supply
interlock—a safety feature that disengages the power supply when
the thumbscrew is removed.
Figure 2-3 Back View of the Workstation
2. Slide the top panel toward the back of the workstation. Lift up to
remove it. Set the panel and screws aside.
3. Tip one of the side panels out and away from the chassis. Lift it out of
the groove in the bottom of the chassis. Remove the other side panel
in the same way. Set the panels aside.
CAUTION To avoid damage to internal components, leave the system in the upright
position
1
2
Top Panel
Right Side Panel
Hole for T-15
(Power Supply Interlock)
3
3
Left Side Pane
Torx Thumbscrew

Chapter 2 17
System Board Removal/Replacement
Removing the Top and Side Panels
Disconnecting the Flex Cable
1. Locate the flex cable.
2. Remove the flex cable retainer by grasping it and lifting up as shown
below.
Figure 2-4 Removing the Flex Cable Retainer
3. Remove the flex cable by grasping the connector handles on each side
and pulling them outward as shown below. This will loosen the
connectors; lift the flex cable away and set it aside.

18 Chapter2
System Board Removal/Replacement
Removing the Bus Bar Shield
Removing the Bus Bar Shield
1. Remove the bus bar shield by pulling outward on its latch, and then
lifting it up. This shield can be used to hold the screws you will
remove in the next step.
Figure 2-5 Removing the Bus Bar Shield
2. Remove the four T-15 Torx thumbscrews from the power supply bus
bar. The bus bar screws are longer than the other T-15 Torx screws.
Step 1: Remove Bus bar Shield Step 2: Remove Bus bar Screws

Chapter 2 19
System Board Removal/Replacement
Removing the Memory Card(s) (DIMMs)
Removing the Memory Card(s) (DIMMs)
1. Press downward on the ejector tabs located on each side of the
memory card (DIMM) slot.
Figure 2-6 Removing a DIMM
2. Grasp the memory card by its edges and lift it straight out. Place the
card on the conductive sheeting.
3. Refer to the label inside the system for reference.
4. Repeat steps 1 and 2 for all memory cards.
Ejector Tab
Ejector Tab

20 Chapter2
System Board Removal/Replacement
Disconnecting the System Board Cables
Disconnecting the System Board Cables
Figure 2-7 Location of the Cable Connections
The location of the cables is shown above. The cables are keyed. Squeeze
the clips to unlock each cable.
F
