QuickSpecs
HP Workstation zx6000
Overview
DA - 11664 Canada — Version 18 — August 31, 2004 Page 1

At A Glance
Up to two Intel® Itanium 2 processors,
1.3GHz or 1.5GHz
Up to 6 MB L3 onboard cache
HP zx1 chipset with 400 MHz system bus
Support for three enterprise-class operating systems:
HP-UX 11i v2.0
Red Hat Linux Advanced Workstation 2.1
HP Linux Installation Kit
ECC PC2100 DDR-266 memory, expandable to 24 GB
Ultra320 SCSI hard drives, with up to 438 GB of internal storage
Choice of leadership graphics:
ATI RADEON 7000
ATI FireGL Z1-128p
NVIDIA Quadro4 980 XGL
ATI FireGL X1-256p
Integrated Ethernet adapters: Intel 82550C (10/100 Mbps) and Broadcom 5701 (10/100/1000 Mbps)
AGP 4X Pro50 graphics interface
Three available PCI slots
Four external bays (one slimline and three hot-pluggable)
DVD-ROM Slimline or DVD-ROM/CD-RW Combo Drive
Full Independent Software Vendor (ISV) certification and support for leading technical applications
Protected by HP Services, including a one-year limited warranty. For details, consult the Product Information Centre at 1-888-882-6672.
QuickSpecs
HP Workstation zx6000
Overview
DA - 11664 Canada — Version 18 — August 31, 2004 Page 2

Processor Up to two Intel Itanium 2 processors – 1.3 GHz, or 1.5 GHz (400 MHz system bus)
Operating System HP-UX 11i v2.0
Red Hat Linux Advanced Workstation 2.1
HP Linux Installation Kit
Cache Memory 3 MB L3 on-chip cache (1.3 GHz processor)
6 MB L3 on-chip cache (1.5 GHz processor)
Memory Maximum of 24 GB ECC PC2100 DDR-266 memory (12 DIMMs)
Network Controller Integrated Intel 82550C Wake-on-LAN 10/100 Mbps Ethernet Network Interface
Broadcom 5701 10/100/1000 Mbps Ethernet Network Interface
Expansion Slots I/O (Total) Four available slots
PCI - 32-bit/33 MHz 3 full-length 64-bit/133 MHz PCI-X
AGP 4X Pro 50 1 slot – 32-bit/66 MHz 1.5V 1.06 GB/s
Expansion Bays (Total/Available) 4 total/2 available
External Three hot-pluggable 3.5 inch bays
One slimline 5.25 inch bay
Storage Removable Media DVD+RW Slimline, DVD-ROM Slimline, or DVD-ROM/CD-RW Slimline Combo Drive
Hard Drive 36 GB or 146 GB Ultra320 SCSI (10K rpm)
36 GB or 73 GB Ultra320 SCSI (15K rpm)
Interfaces USB 2.0 (1.1 compatible) Four (2 front, 2 rear)
Serial Two 9-pin DIN connectors (rear)
Ultra320 SCSI Internal and external (rear) connectors
Network interface Two RJ-45 connectors (rear)
Microphone Jack 1 (front)
Line-In Jack 1 (rear)
Line-Out Jack 1 (rear)
Graphics
Choose from:
ATI RADEON 7000
ATI FireGL Z1-128p (2 slots)
NVIDIA Quadro4 980 XGL
ATI FireGL X1-256p (2 slots)
Audio AC97/16-bit stereo full-duplex
QuickSpecs
HP Workstation zx6000
Standard Features
DA - 11664 Canada — Version 18 — August 31, 2004 Page 3

Remote Management Baseboard management controller (integrated) allows power and reset management, health management, event
logging and reporting, hardware and data protection, and highly available management console.
Management processor card (optional) manages resources, diagnostics, system repair, 2D graphics console, and
10/100Base-T LAN for out-of-band management.
Power Supply 650W maximum output
Optional hot-swap 2nd power supply for n+1 redundancy
Service and Support Standard limited warranty: 1 year next business day onsite
Hardware support upgrades available: 3 Years Next Business Day Onsite, 3 Years Same Business Day Onsite, and
3 Years 24 x7 Onsite.
Telephone support upgrade available: 3 Years telephone support for LINUX operating system.
NOTE: Certain restrictions and exclusions may apply. For details, consult the Product Information Centre at 1-888-
882-6672.
QuickSpecs
HP Workstation zx6000
Standard Features
DA - 11664 Canada — Version 18 — August 31, 2004 Page 4

HP Workstation zx6000 Base Unit (Partner Prime and Partner Direct)
DM487AV
HP Workstation zx6000 with 1.3 GHz Processor (HIP Partner)
A9664A
HP Workstation zx6000 with 1.5 GHz Processor (HIP Partner)
A9665A
QuickSpecs
HP Workstation zx6000
HP Workstation zx6000 Base System
DA - 11664 Canada — Version 18 — August 31, 2004 Page 5

zx6000/2x900/2/36/
GL4/U
A9373BF#ABA
Processor Dual Intel Itanium 2 processors. 900 MHz
Cache Memory 1.5MB L3
Memory 2 GB ECC PC2100 DDR-266 (4x512 MB)
Optical Drive DVD-ROM drive
Hard Drive 36 GB Ultra320 SCSI 10K rpm
Graphics ATI Fire GL4
Mouse HP scroll mouse
OS HP-UX 11i TCOE
zx6000/2x900/2/36/
R7/U
A9372BF#ABA
Processor Dual Intel Itanium 2 processors. 900 MHz
Cache Memory 1.5MB L3
Memory 2 GB ECC PC2100 DDR-266 (4x512 MB)
Optical Drive DVD-ROM drive
Hard Drive 36 GB Ultra320 SCSI 10K rpm
Graphics ATI RADEON 7000
Mouse HP scroll mouse
OS HP-UX 11i TCOE
zx6000/2x900/2/36/
R7/L
A9374DF#ABA
Processor Dual Intel Itanium 2 processors. 900 MHz
Cache Memory 1.5MB L3
Memory 2 GB ECC PC2100 DDR-266 (4x512 MB)
Optical Drive DVD-ROM drive
Hard Drive 36 GB Ultra320 SCSI 10K rpm
Graphics ATI RADEON 7000
Mouse HP scroll mouse
OS Red Hat Linux Advanced Workstation 2.1
zx6000/2x900/2/36/
Q4980/L
A9375DF#ABA
Processor Intel Itanium 2 processor 900 MHz
Cache Memory 1.5 MB L3
Memory 2GB ECC PC2100 DDR-266 (4x512 MB)
Optical Drive DVD-ROM drive
Hard Drive 36 GB Ultra320 SCSI 10K rpm
Graphics NVIDIA Quadro4 980 XGL
Mouse HP scroll mouse
OS Red Hat Linux Advanced Workstation 2.1
zx6000 LEK/FldRk/
2x900/1G/36G/
DVD/Q2EX
A9680AF#ABA
Processor Intel Itanium 2 processor 900 MHz
Cache Memory 1.5 MB L3
Memory 1GB ECC PC2100 DDR-266 (2x512MB)
Optical Drive DVD-ROM drive
Hard Drive 36 GB Ultra320 SCSI 10K rpm
Graphics NVIDIA Quadro2 EX
Mouse HP scroll mouse
OS Linux Enabled Kit
QuickSpecs
HP Workstation zx6000
Standard Features Pre-Configured Regional Models
DA - 11664 Canada — Version 18 — August 31, 2004 Page 6

zx6000 LEK/FdRk/
2x1.3/1G/36G/
DVD/Q2EX
A9680BF#ABA
Processor Intel Itanium 2 processor 1.3 GHz
Cache Memory 3 MB L3
Memory 1GB ECC PC2100 DDR-266 (2x512MB)
Optical Drive DVD-ROM drive
Hard Drive 36 GB Ultra320 SCSI 10K rpm
Graphics NVIDIA Quadro2 EX
Mouse HP scroll mouse
OS Linux Enabled Kit
QuickSpecs
HP Workstation zx6000
Standard Features Pre-Configured Regional Models
DA - 11664 Canada — Version 18 — August 31, 2004 Page 7

When buying a basic system, you have many configuration options. Base System includes one processor, no RAM, no disk, Ultra320 SCSI, external
SCSI connector, 10/100/1000BT LAN, 10/100BT LAN, 2 serial, 4 USB, 1 AGP-4X slot, 3 PCI-X slots, and all required power cords.
HP-UX Linux
HP workstation zx6000
base system
HP Workstation zx6000, Intel Itanium 2 processor, 1.3GHz 3.0MB cache X X
HP Workstation zx6000, Intel Itanium 2 processor, 1.5GHz 6.0MB cache X X
Second Processor 1.3GHz Intel Itanium 2 processor with 3.0MB integrated cache X X
1.5GHz Intel Itanium 2 processor with 6.0MB integrated cache X X
Operating System HP-UX 11i v2 X
Red Hat Linux Advanced Workstation 2.1 X
Graphics Card ATI RADEON 7000 (32 MB, dual display, AGP) X X
ATI FireGL Z1-128p (128MB, dual display, AGP 8X) X X
NVIDIA Quadro4 980 XGL (128 MB, dual display, AGP 8X) X
ATI FireGL X1-256p (256 MB, dual display, AGP 8X) X X
NOTE: ATI FireGL graphics cards occupy 2 physical slots in the system.
Memory 512 MB PC2100 DDR SDRAM memory kit (2x256MB DIMMs) X X
1 GB PC2100 DDR SDRAM memory kit (2x512MB DIMMs) X X
2 GB PC2100 DDR SDRAM memory kit (2x1GB DIMMs) X X
4 GB PC2100 DDR SDRAM memory kit (2x2GB DIMMs) X X
Monitors HP p1230 22-inch (20.0-inch vis) Performance Natural-flat CRT Monitor X X
HP L1925 19-inch TFT Flat Panel Display – Analog/Digital X X
HP L2035 20-inch TFT Flat Panel Display Analog mode
only
X
HP L2335 23-inch TFT Widescreen Flat Panel Display 1600x1200 or
lower
resolution only
X
Internal hard disks
(minimum 1, maximum 3)
Ultra320 SCSI Drives
36 GB Ultra320 SCSI 10,000 rpm (hot plug) X X
36 GB Ultra320 SCSI 15,000 rpm (hot plug) X X
73 GB Ultra320 SCSI 15,000 rpm (hot plug) X X
146 GB Ultra320 SCSI 10,000 rpm (hot plug) X X
Storage Controllers Ultra160 SCSI Adapter for HP-UX, 1 channel X
Ultra160 SCSI Adapter for HP-UX, 2-channel X
Fibre Channel Adapter for Linux - (no boot) X
Fibre Channel Adapter, 2GB, for HP-UX X
FWD SCSI Adapter, 2-channel (no boot) X
Ultra160 SCSI Adapter for Linux, 1-channel X
Ultra160 SCSI Adapter for Linux, 2-channel X
QuickSpecs
HP Workstation zx6000
Configure to order options (custom configurations)
DA - 11664 Canada — Version 18 — August 31, 2004 Page 8

Optical Drive 4.7GB DVD+RW, 4X Max, Slimline Drive X
DVD-ROM Drive, 8X Max, Slimline, Carbon X X
CD-RW/DVD-ROM Combo Drive, 12X/8X Max, Slimline, Carbon X X
Input Devices HP USB Keyboard Kit, includes USB scroll mouse X X
HP USB Keyboard Kit, includes USB 3-button mouse X X
HP USB scroll mouse X X
SpaceBall 5000, Serial Interface X X
USB to PS/2 Adapter X X
Network Adapters 1000BaseTX PCI LAN Adapter for HP-UX (Required for HP-UX) X
1000BaseSX (Fibre) PCI LAN Adapter for HP-UX X
100BaseT PCI LAN Adapter for HP-UX (Does not support boot.) X
100BaseT PCI LAN Adapter, Quad Port X
HyperFabric2 PCI Fiber Adapter for HP-UX X
1000BaseTX PCI LAN Adapter for Linux X
1000BaseSX (Fibre) PCI LAN Adapter for Linux X
LAN, MUX, 8-port (1.3 and 1.5GHz models only) X
I/O and Networking Documentation kit X X
Management Processor
Card
HP Management Processor Card X X
Redundant Power Supply Redundant Hotswap Power Supply X X
Rack and Tower Options
(must order 1)
Workstation Field Rack Kit X X
Workstation Factory Rack Kit X X
Workstation Tower Kit X X
QuickSpecs
HP Workstation zx6000
Configure to order options (custom configurations)
DA - 11664 Canada — Version 18 — August 31, 2004 Page 9

HP-UX Linux
Second Processor
(must be same frequency as
primary processor)
Intel Itanium 2, 1.3 GHz, 3.0 MB integrated cache X X A9666A
Intel Itanium 2, 1.5 GHz, 6.0 MB integrated cache X X A9667A
Processor Upgrades Upgrade kit: Intel Itanium 2, 1.3 GHz, 3.0 MB integrated cache X X A9666A
Upgrade kit: Intel Itanium 2, 1.5 GHz, 6.0 MB integrated cache X X A9666A
Return credit for Intel Itanium 2, 1 GHz, 3.0 MB integrated cache X X A7848AN
Operating System HP-UX 11i MTOE, License-to-use X B6867AA
HP-UX 11i TCOE, License-to-use X B6868AA
HP-UX 11i MTOE media kit X B9000AA
HP-UX 11i TCOE media kit X B9001AA
Linux Enablement Kit for HP Itanium-based workstation X T1502AA
Red Hat Linux Advanced WS for zx6000 X T2381AA
Red Hat Linux Adv. WS for zx (0D1 only) X T2379AA
HP Linux Installation Kit T2170A
Red Hat Linux Advanced Workstation for zx6000 License-to-use X T2381AA
Memory 512MB PC2100 DDR SDRAM memory kit (2x256MB DIMMs) X X A7840A
1GB PC2100 DDR SDRAM memory kit
(2x512MB DIMMs)
X X A7841A
2GB PC2100 DDR SDRAM memory kit
(2x1GB DIMMs)
X X A7842A
4GB PC2100 DDR SDRAM memory kit
(2x2GB DIMMs)
X X A7843A
Monitors HP p1230 22-inch (20.0-inch vis) Performance Natural-flat CRT
Monitor
X X P9613#ABA
HP L1925 19-inch TFT Flat Panel Display – Analog/Digital X X P9626A#ABA
HP L2035 20-inch TFT Flat Panel Display Analog mode
only
X P9614A#ABA
HP L2335 23-inch TFT Widescreen Flat Panel Display 1600x1200
or lower
resolution
only
X P9615A#ABA
Graphics ATI RADEON 7000 (32 MB, dual display, AGP) X X A8049B
ATI FireGL Z1-128p (128MB, dual display, AGP 8X) X X A9654A
NVIDIA Quadro4 980 XGL (128 MB, dual display, AGP 8X) X A9655A
ATI FireGL X1-256p* (256 MB, dual display, AGP 8X) X X A9653A
NOTE: ATI FireGL graphics cards occupy 2 physical slots in the system.
QuickSpecs
HP Workstation zx6000
After market options/Standalone accessories
DA - 11664 Canada — Version 18 — August 31, 2004 Page 10

Hard Drives Ultra320 SCSI Drives
36 GB Ultra320 SCSI, 10,000 rpm, hot plug X X A7835B
36 GB Ultra320 SCSI, 15,000 rpm, hot plug X X A7836A
73 GB Ultra320 SCSI, 15,000 rpm, hot plug X X A7838A
146 GB Ultra320 SCSI, 10,000 rpm, hot plug X X A7839A
Storage Controllers Ultra160 SCSI Adapter for HP-UX, 1-channel X A6828A
Ultra160 SCSI Adapter for HP-UX, 2-channel X A6829A
Fibre Channel Adapter, for Linux - No Boot
for 1.3GHx and 1.5GHz models only
X AB234A
Fibre Channel Adapter, 2GB, for HP-UX X A6795A
FWD SCSI adapter, 2-channel (does not support boot) X A5159A
Ultra160 SCSI Adapter for Linux, 1-channel X A7059A
Ultra160 SCSI Adapter for Linux, 2-channel X A7060A
Optical Drives 4.7GB DVD+RW, 4X Max, Slimline Drive X AB616A
DVD-ROM Drive, 8X Max, Slimline, Carbon X X A7850A
CD-RW/DVD-ROM Combo Drive, 12X/8X Max, Slimline, Carbon X X A7851A
Network Adapters 1000BaseTX PCI LAN Adapter for HP-UX X A6825A
1000BaseSX (Fibre) PCI LAN Adapter for HP-UX X A6847A
100BaseT PCI LAN Adapter for HP-UX X B5509BA
100BaseT PCI LAN Adapter, Quad Port X A5506B
HyperFabric2 PCI Fiber Adapter for HP-UX X A6386A
1000BaseTX PCI LAN Adapter for Linux X A7061A
1000BaseSX (Fibre) PCI LAN Adapter for Linux X A7073A
LAN, MUX, 8-port (1.3 and 1.5GHz models only) X A6748A
I/O and Networking Documentation kit X X A520
Input Devices Keyboard Kit, USB, PC-104/105, Carbon black; includes USB
keyboard and USB Scroll Mouse.
X X A7861C
USB to PS/2 adapter (allows the use of a PS/2 keyboard and mouse,
or KVM switch)
X X A7782A
SpaceBall 5000, Serial Interface X X AB602A
Audio Adaptor, PCI-1xU, Audio, FM801 X X A7784A
Management Processor
Card
HP Management Processor Card X X A6875A
Redundant Power Supply Redundant Hotswap Power Supply X X A6874A
Rack and Tower Kits Rack to Tower Conversion Kit X X A8718A
Tower to Rack Conversion Kit X X A8082A
QuickSpecs
HP Workstation zx6000
After market options/Standalone accessories
DA - 11664 Canada — Version 18 — August 31, 2004 Page 11

ECC PC2100 DDR-266 memory
Memory must be installed in pairs of the same size. Memory upgrade kits come in pairs.
This chart does not represent all possible memory configurations.
Minimum Memory
512-MB (2x256-MB)
Maximum Memory
24-GB (12x2-GB)
Memory Slot 1 Slot 2 Slot 3 Slot 4 Slot 5 Slot 6
Minimum 512 MB 256 MB 256 MB
Maximum 24 GB 2 GB 2 GB 2 GB 2 GB 2 GB 2 GB
Memory Slot 7 Slot 8 Slot 9 Slot 10 Slot 11 Slot 12
Minimum 512 MB
Maximum 24 GB 2 GB 2 GB 2 GB 2 GB 2 GB 2 GB
QuickSpecs
HP Workstation zx6000
Memory
DA - 11664 Canada — Version 18 — August 31, 2004 Page 12

Drive Bay Locations
Drive Support
Quantity
Supported
Position
Supported Controller
Optical Drives
Slimline DVD+RW Drive Up to 1 1 Integrated EIDE
Slimline DVD-ROM Drive Up to 1 1 Integrated EIDE
Slimline DVD-ROM/CD-RW
Combo Drive
Up to 1 1 Integrated EIDE
Hard Drives
Ultra320 SCSI Drives
1-inch Up to 3 2, 3, 4 Optional Ultra160 SCSI Controller or
Fibre Channel Adapter for Linux - no boot
36 GB Ultra320 SCSI (10K
rpm)
73 GB Ultra320 SCSI (15K
rpm)
146 GB Ultra320 SCSI (10K
rpm)
Maximum Storage
Capacity
438 GB
(SCSI)
QuickSpecs
HP Workstation zx6000
Storage
DA - 11664 Canada — Version 18 — August 31, 2004 Page 13

System Unit Tower Dimensions
(HxWxD)
19.5 x 11.7 x 26.5 in (49.5 x 29.7 x 67.3 cm)
Weight
(tower configuration)
Minimum Tower Configuration 49.4 lb (22.4 kg)
Maximum Tower Configuration 56.3 lb (25.5 kg)
Rack Dimensions (HxWxD) 3.4 x 19.0 x 26.8 in (8.6 x 48.3 x 68.1 cm)
EIA Units 2U (20 units possible per 2 meter rack)
Weight (rack configuration) Minimum Rack Configuration 38.6 lb (17.5 kg)
Maximum Rack Configuration 49.0 lb (22.2 kg)
Power Supply Input current (autoranging) 8.0A max @ 100-127V, 3.9A max @ 200-240V
Line Frequency 50- 60 Hz
Maximum Power Input 714 W
Temperature Operating 41° to 95° F (5° to 35° C)
Non-operating -40° to 158° F (-40° to 70° C)
Humidity
(non-condensing)
Operating 15% to 80% relative
Maximum Altitude
(non-pressurized)
Operating 10,000 ft (3,048 m)
Non-operating 15,000 ft (4572 m)
HP Keyboard Dimensions (HxWxD) 18.82 x 7.3 x 1.85 in (47.8 x 18.6 x 4.7 cm)
Weight Approx.1.2 kg ± 0.1 kg
Electrical Operating Voltage + 5VDC ± 5%
Power Consumption 60 mA maximum (with 3 LEDs on)
System Interface USB connector
ESD CE level 4, 15 kV air discharge
EMI-RFI Conforms to FCC rules for a Class B computing device
PC98 Functionally compliant
Mechanical Languages 12 available
Keycaps Standard profile design
Switch Actuation 55 g nominal peak force with tactile feedback
Switch Life 20 million keystrokes (using Hasco modified tester)
Switch Type Contamination resistant membrane
Key Leveling Mechanism For all double wide and greater length keys
Cable Length 2.9 m
PC98-99 Mechanically compliant
Acoustics 65 dBA for spacebar, 55 dBA for all others maximum
sound pressure level
Environmental Operating Temperature 41° to 95° F (5° to 35° C)
Non-operating Temperature -40° to 140° F (-40° to 60° C)
Operating Humidity 10% to 80% (non condensing at ambient)
Non-operating Humidity 10% to 90% (non condensing at ambient)
Operating Shock 40 g, 6 surfaces
Non-operating Shock 80 g, 6 surfaces
Operating Vibration 2 g peak acceleration
Non-operating Vibration 4 g peak acceleration
QuickSpecs
HP Workstation zx6000
Technical Specifications
DA - 11664 Canada — Version 18 — August 31, 2004 Page 14

SpaceBall 5000 Dimensions (HxWxD) 3.0 x 6.0 x 8.4 in (7.6 x 15.2 x 21.3 cm)
Ball Diameter 2.2 in (5.6 cm)
Weight 2.1 lb (9.94 kg)
Features Six degrees of freedom motion control through the X, Y, Z axis
(pitch, roll, yaw)
Device sensitivity adjustable to preference
Certified for leading CAD and DCC applications
Environmental Operating Temperature 50° to 104° F (10° to 40° C)
Non-operating Temperature 43° to 140° F (6° to 60° C)
Operating Humidity 8% to 80% (non-condensing at ambient
Non-operating Humidity 5% to 80% (non-condensing at ambient)
Mechanical Buttons 12 programmable (unshifted)
23 programmable (shifted)
Ball Force range 0.5 - 8.2N (1.8 - 29.5 oz)
Ball Torque range 0.085 - 0.33 oz-in. (6.91 Nmm)
Resolution 10 bits
Serial Specifications Connector 9-pin D-subminiature receptacle (DB9S)
Cable Length 12.8 ft. (3.9 m)
Data rate 9600 bps
Flow control Xon/Xoff
System Requirements 10 Megabytes free disk space for driver and plug-in installation
CD-ROM device required
Software Drivers Unix drivers for HP-UX
Red Hat Linux
Regulatory Approvals Compliant UL, cUL, EN 950, EN 60950, CSA, FCC, CE Mark, TUV,
CISPR 22, EN 50082, IEC 1000 4-2, IEC 1000-4-3,
AS/NZS, VCCI, BSMI, C-Tick, PCI, MIC
HP 3-Button Mouse Dimensions/Weight Height 1.42 in (3.6 cm)
Length 4.17 in (10.7 cm)
Width 2.87 in (7.4 cm)
Weight 5.20 oz (150 g)
Environmental Operating Temperature 32° to 104° F (0° to 40° C)
Non-operating Temperature -4° to 140° F (-20° to 60° C)
Operating Humidity 10% to 90% (non condensing at ambient)
Mechanical Resolution 400 ± 20% DPI
Tracking Speed 10 in/s Maximum
Switch Life 1,000,000 operations (using Hasco modified tester)
Switch Type Micro-switches
Tracking Mechanism Life 155 miles (250 km) at average speed of 10 in/s
Cable Length 6 ft (1.8 m)
PC98-99 Mechanically compliant
Regulatory Approvals Compliant UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI, BSMI, C-
Tick
QuickSpecs
HP Workstation zx6000
Technical Specifications
DA - 11664 Canada — Version 18 — August 31, 2004 Page 15

HP 2-button Scroll Mouse Scroll Wheel 8 mm
Maximum Rotation Speed 30 mm/s
Switch Type Light force micro-switch
Switch Life 1 million operations
Mechanical Life Minimum 200,000 revolutions
Environmental Operating Temperature 50° to 122° F (10° to 50° C)
Non-operating Temperature -22° to 140° F (-30° to 60° C)
Operating Humidity 10% to 90% (non condensing at ambient)
Non-operating Humidity 20% to 80% (non condensing at ambient)
Operating Shock 40 g, 6 surfaces
Non-operating Shock 80 g, 6 surfaces
Operating Vibration 2 g peak acceleration
Non-operating Vibration 4 g peak acceleration
Electrical Operating Voltage + 5VDC ± 10%
Power Consumption 15mA
System Consumption USB connector
ESD CE level 4, 15 kV air discharge
EMI-RFI Conforms to FCC rules for a Class B computing device
PC98 Functionally compliant
Mechanical Resolution 400 ± 20% DPI
Tracking Speed 10 in/s Maximum
Acceleration 100 in/s
Switch Actuation 85 g nominal peak force
Switch Life 1,000,000 operations (using Hasco modified tester)
Cable Length 2 m
PC98-99 Mechanically compliant
Regulatory Approvals UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI, BCIQ, C -Tick
LSI Logic Ultra320 SCSI
Dual Channel host adapter
Bus architecture PCI-X (backward compatible to PCI)
Number of supported
devices
30
Interface protocol 64-bit PCI-X bus-master
Host bus transfer rate Up to 133 MB/s
SCSI data transfer rate Up to 640 MB/s
Bus width 64-bit (fits both 32-bit and 64-bit bus widths)
Internal SCSI connectors Two 68-pin HD
External SCSI connector Two 68-pin VHDCI
Total connectors 4
Plug and Play Support Yes
Dimensions (H x L) 6.7 x 4.2 in (17.3 x 11.4 cm)
Approvals/
environmental
CE, VCCI, Canada, C-Tick, FCC class B, UL 94VO, BSMI, MIC
Operating system support Red Hat Enterprise Linux Workstation 3.0
QuickSpecs
HP Workstation zx6000
Technical Specifications
DA - 11664 Canada — Version 18 — August 31, 2004 Page 16

Ultra320 SCSI Hard Drives 146 GB, 10K rpm Nominal Capacity 146.8 GB
Dimensions (HxWxD) 1.00 x 4.00 x 5.75 in (2.54 x 10.16 x 14.61 cm)
Interface Ultra320 SCSI
Transfer rate
synchronous (maximum)
320 MB/s
Seek time
(typical reads, including
settling)
Single track: 0.35 ms
Average: 4.7 ms
Full-stroke: 10.0 ms
Average rotational latency 2.99 ms
Rotational speed 10,000 rpm
Logical blocks 289,749,488
Operating temperature 41° to 131° F (5° to 55° C)
73 GB, 15K rpm Nominal Capacity 73.4 GB
Dimensions (HxWxD) 1.00 x 4.00 x 5.75 in (2.54 x 10.16 x 14.61 cm)
Interface Ultra320 SCSI
Transfer rate
synchronous (maximum)
320 MB/s
Seek time
(typical reads, including
settling)
Single track: 0.35 ms
Average: 4.7 ms
Full-stroke: 10.0 ms
Average rotational latency 2.99 ms
Rotational speed 10,000 rpm
Logical blocks 289,749,488
Operating temperature 41° to 131° F (5° to 55° C)
36 GB, 15K rpm Nominal Capacity 36.4 GB
Dimensions (HxWxD) 1.00 x 4.00 x 5.75 in (2.54 x 10.16 x 14.61 cm)
Interface Ultra320 SCSI
Transfer rate
synchronous (maximum)
320 MB/s
Seek time
(typical reads, including
settling)
Single track: 35 ms
Average: 4.7 ms
Full-stroke: 10.0 ms
Average rotational latency 2.99 ms
Rotational speed 15,000 rpm
Logical blocks 71,132,960
Operating temperature 41° to 131° F (5° to 55° C)
QuickSpecs
HP Workstation zx6000
Technical Specifications
DA - 11664 Canada — Version 18 — August 31, 2004 Page 17

36 GB, 10K Nominal Capacity 36.4 GB
Dimensions (HxWxD) 1.00 x 4.00 x 5.75 in (2.54 x 10.16 x 14.61 cm)
Interface Ultra320 SCSI
Transfer rate
synchronous (maximum)
320 MB/s
Seek time
(typical reads, including
settling)
Single track: 35 ms
Average: 4.7 ms
Full-stroke: 10.0 ms
Average rotational latency 2.99 ms
Rotational speed 10,000 rpm
Logical blocks 71,132,960
Operating temperature 41° to 131° F (5° to 55° C)
HP 4.7GB DVD+RW Slimline
Drive
Capacity 4.7 GB DVD disc/700 MB CD disc
Dimensions (HxWxD) 0.5 x 5.22 x 5.46 in (1.35 x 13.28 x 13.88 cm)
Weight 0.551 lb (250 g)
Interface ATAPI/EIDE
Mounting Orientation Horizontal or vertical (within 15 degrees)
Data Transfer Rates - Read Digital audio extraction
(minimum)
1,200 KB/s (8X)
CD read Up to 3,600 KB/s (24X)
DVD read Up to 8,100 KB/s (8X)
Media and Formats - Read CD formats CD-DA (Red Book), CD-ROM (Modes 1 and 2 - Yellow
Book), CD-ROM XA (Mode 2, Forms 1 and 2), CD-I
(FMV), Photo CD (single and multi-session), Video CD,
CD-Text, CD Extra
CD media Stamped, CD-R, CD-RW
DVD formats DVD-ROM, DVD-Video (with application support)
DVD media Stamped (single or dual layer, single sided), DVD+RW,
DVD+R
Data Transfer Rates -
Write
DVD+R write 5.54 MB/s (4X)
DVD+RW write or rewrite 3.32 MB/s (2.4X)
CD-R write 1200 KB/s (8X)
CD-R write 1800 KB/s (12X)
CD-R write 2,400 KB/s (10X)
CD-RW write 600 KB/s (4X)
CD-RW write 1500 KB/s (10X)
Media and Formats - Write CD formats CD-DA (Red Book), CD-ROM (Modes 1 and 2 - Yellow
Book), CD-ROM XA (Mode 2, Forms 1 and 2), CD-I
(FMV), Photo CD (single and multi-session), Video CD,
CD-Text, CD Extra
CD media CD-R, CD-RW
DVD formats DVD-ROM, DVD-Video (with application support)
DVD media DVD+RW, DVD+R
QuickSpecs
HP Workstation zx6000
Technical Specifications
DA - 11664 Canada — Version 18 — August 31, 2004 Page 18

Write Methods Disc-at-once, track-at-once, incremental fixed and variable packet, random access
write (DVD+RW only), sequential write (DVD +R, +RW). Writing method is application
dependant.
Data Transfer Mode ATA PIO mode 4-16.6-Mbps, ATA UltraDMA mode 2-33-Mbps (default)
Access Times
(typical)
DVD-ROM Single Layer Random 150 ms typical
CD-ROM Random 140 ms typical
CD-ROM Full stroke 200 ms typical
Start-up Time (typical) DVD-ROM 9.5 s typical (time from disk insertion to drive
ready)
CD-ROM 8.0 s typical (time from disk insertion to drive
ready)
Stop Time (typical) < 9 s
Write Buffer Size 2 MB (minimum)
Audio Output 16 bit data output Through ATA interface
Volume Control Software controlled
Operating Conditions Temperature (Read) 41° to 122° F (5° to 50° C)
Humidity (Write) 41° to 113° F (5° to 45° C)
Approvals/
Environmental
UL 1950 (US and Canada), CE, FDA, FCC (B), TUV, C-TICK (B)
Operating Systems Supported Red Hat LINUX Advanced Workstation version 2.1
Supplied Software Ahead Nero Enterprise Edition, including the Nero5 Express basic user interface and
the Nero5 Burning ROM advanced user interface.
Slimline CD-RW/
DVD-ROM Combo Drive
Drive Manual tray-load
Orientation Horizontal or vertical
Interface Type ATAPI
Dimensions
(W x H x D)
5.23 x 0.5 x 5.46 in (13.28 x 1.27 x 13.87 cm)
Disc Diametre 12 cm, 8 cm
Disc Thickness 1.2 mm
Track Pitch 1.6 µm (CD-ROM); 0.74 m m (DVD-ROM)
Disc Centre Hole Diametre 15 mm
Reference Scanning
Velocity
1.2 m/s (CD); 3.49 m/s (DVD SL); 3.84 m/s (DVD DL)
Read Only Disc
Parametres
Formats and Modes
Supported
CD-ROM—Mode 1; CD-ROM XA—Mode 2 (forms 1 and
2); CD digital audio; CD Extra; CD-I—Mode 2 (forms 1
and 2) and CD-I-Ready; Photo CD (single and multi-
session); video CD; DVD (single and doublelayer);
DVD-R 3.95 GB; DVD-R 4.7 GB; DVD-RW 4.7 GB;
DVD+ RW 4.7 GB
Capacity 550 MB (Mode 1, 12 cm); 650 MB (Mode 1, 12 cm); 630
MB (Mode 2, 12 cm); 740 MB (Mode 2, 12 cm); 700 MB
(CD-ROM 80 min); 180 MB (CD-ROM 8 cm) 4.7 GB
(DVD-5); 8.54 GB (DVD-9); 9.4 GB (DVD-10)
Block Size Mode 1—2,048 and 2,352 bytes; mode 2, form
1—2,048; 2,328; 2,336; 2,340 and 2,352 bytes; mode
2, form 2—2,328; 2,336; 2,340 and 2,352 bytes; CD-
DA—2,352 and 2,368 bytes; DVD—2,048 bytes
Writeable Disc Parametres Disc Type CD-R and CD-RW
Write Methods Disc at Once, Track at Once, Session at Once,
Variable Packet, Fixed Packet
Format and Modes CD-ROM (mode 1); CD-ROM XA (mode 2, forms 1 and
QuickSpecs
HP Workstation zx6000
Technical Specifications
DA - 11664 Canada — Version 18 — August 31, 2004 Page 19

Supported 2); CD digital audio, CD-I (mode 2, forms 1 and 2);
video CD
Capacity 550 MB (Mode 1, 12 cm); 650 MB (Mode 1, 12 cm); 630
MB (Mode 2, 12 cm); 740 MB (Mode 2, 12 cm); 700 MB
(CD-ROM 80 min); 180 MB (8 cm)
Block Size Mode 1—2,048 bytes; mode 2, form 1—2,048 and
2,352 bytes; mode 2, form 2—2,352 bytes; CD-DA
—2,353 bytes
Access Times (typical) Random DVD < 130 ms
Random CD < 110 ms
Full Stroke DVD < 225 ms
Full Stroke CD < 210 ms
Data Transfer Rates Maximum – CD-R Write 3600 KB/s (24X CAV)
Sustained — CD-RW Write 1500 KB/s (10X CLV)
Minimum — CD-R Read 3600 KB/s (24X ZCLV)
Minimum — CD-ROM Read 3600 KB/s (24X CAV)
Minimum — DVD-ROM
Read
10800 KB/s (8X CAV)
Minimum — Digital Audio
Extraction
1200 KB/s (8X CLV)
Data Transfer Modes ATA PIO mode 4 (16.7 MB/s); ATA Multi-word DMA mode 2 (16.7 MB/s)
Bus Rate 16.6 MB/s (burst) with DMA support
Cache Buffer 2 MB (minimum)
Startup Time (single) < 9 seconds (typical)
Startup Time (multi-session) < 30 seconds (typical)
Stop Time < 6 seconds
Power Source Four-pin, DC power receptacle
DC Power Requirement 5 VDC ± 5%—100 mV ripple p-p
DC Current < 800 mA read (typical at Outer Diametre)
< 900 mA write (typical at Outer Diametre)
< 1600 mA (maximum excluding spike current
< 1 ms duration)
< 1600 mA (maximum excluding spike current < 1 ms
duration)
< 100 mA (low power mode)
< 70 mA (sleep mode)
Total Drive Power
(standby mode)
< 70 mA
Audio Output Level 0.7 – 0.9 Vrms
Configuration Jumper
Block
Cable select mode
Data Interface Connector 68-pin interface connector
Environmental
(all conditions non-
condensing)
Temperature (operating) 41° to 122° F (5° to 50° C)
Relative Humidity
(operating)
10% to 80%
Maximum Wet Bulb
Temperature (operating)
84° F (29° C)
Certifications,
Requirements
Multi-read requirements, ACA AS/NZS 3548, ANSI C63.4–1992 CB Test Certificate for
IEC 60950, CFR 47 part 15, CSA C22.2 No. 60950, DHSS/FDA - 1040, EN55022,
EN55024, EN60 950:2000, IEC 68, 908, 61000-4, ISO 9660, 10149, 13346,TUV or VDE
EN60 950, UL 60950, ICES-003 class B, CE Mark
QuickSpecs
HP Workstation zx6000
Technical Specifications
DA - 11664 Canada — Version 18 — August 31, 2004 Page 20
