HP ZX2000 User manual

OpenGL implementation guide
for HP-UX 11.X (IPF version)
Document Part Number: 5969-3152
june 2003

© 2003 Hewlett-Packard Company
ATI™ is used under license and are registered trademarks of ATI Technologies Inc. in the United States and other
countries.
UNIX® is a registered trademark of The Open Group.
Intel® Itanium™ Processor Family is a trademark of Intel Corporation in the U.S. and other countries and is used
under license.
X/Open® is a registered trademark, and the X device is a trademark of X/Open Company Ltd. in the UK and
other countries.
Hewlett-Packard Company shall not be liable for technical or editorial errors or omissions contained herein or for
incidental or consequential damages in connection with the furnishing, performance, or use of this material. The
information in this document is provided “as is” without warranty of any kind, including, but not limited to, the
implied warranties of merchantability and fitness for a particular purpose, and is subject to change without notice.
The warranties for HP products are set forth in the express limited warranty statements accompanying such
products. Nothing herein should be construed as constituting an additional warranty.
This document contains proprietary information that is protected by copyright. No part of this document may be
photocopied, reproduced, or translated to another language without the prior written consent of Hewlett-Packard
Company.
ÅWARNING: Text set off in this manner indicates that failure to follow directions could result in bodily
harm or loss of life.
ÄCAUTION: Text set off in this manner indicates that failure to follow directions could result in damage to
equipment or loss of information.
OpenGL implementation guide
for HP-UX 11.X (IPF version)
First Edition (june 2003)
Document Part Number: 5969-3152

OpenGL Implementation Guide iii
contents
1 overview of OpenGL
introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–1
the OpenGL product. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–1
hp’s implementation of OpenGL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–2
standard OpenGL product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–6
mixing of OpenGL and Xlib . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–7
gamma correction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–7
OpenGL extensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–8
draw array set extension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–8
3D texture extension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–8
occlusion extension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–12
visibility test extension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–14
texture autogen MIPmap extension. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–16
X Window extensions for hp’s implementation of OpenGL. . . . . . . . . . . . . . . . . . . . . . . . . . . 1–16
rendering details. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–19
default visuals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–19
EXP and EXP2 fogging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–19
vertices outside of a begin/end pair. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–19
index mode dithering. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–19
environment variables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–20
2 installation and setup
verification instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–1
is your system software preloaded with instant ignition? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–1
verify that OpenGL is on your workstation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–1
installing OpenGL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–2
1. read this entire procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–2
2. install OpenGL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–2
3. check log file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–3
4. verify the product. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–3
the OpenGL file structure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–3
3 running OpenGL programs
virtual GLX (VGL) mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–1
visual support for the VGL mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–1
special considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–1
running hp's implementation of the OpenGL stereo application . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–2

iv OpenGL Implementation Guide
Contents
4 compiling and linking programs
overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–1
including header files. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–2
linking shared libraries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–2
compiling 32-bit and 64-bit applications for OpenGL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–3
OpenGL procedure calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–3
5 programming hints
OpenGL correctness hints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–1
4D values. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–1
texture coordinates. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–1
OpenGL performance hints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–1
display list performance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–2
texture downloading performance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–5
selection performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–5
state change . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–5
optimization of lighting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–6
occlusion culling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–6
high frame rate applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–6
rescaling normals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–7

OpenGL implementation guide 1–1
1
overview of OpenGL
OpenGL is a hardware-independent application programming interface (API) that provides an
interface to graphics operations. HP’s implementation of OpenGL converts API commands to
graphical images via hardware and/or software functionality.
The information in this manual is valid only for OpenGL on IPF. For information on OpenGL on
PA-RISC, refer to the PA-RISC version of the OpenGL Implementation Guide.
introduction
The OpenGL interface consists of a set of commands that allow applications to define and
manipulate three-dimensional objects. The commands include:
■geometric primitive definitions
■viewing operations
■lighting specifications
■primitive attributes
■pipeline control
■rasterization control
OpenGL has been implemented on a large number of vendor platforms where the graphics
hardware supports a wide range of capabilities (for example, frame buffer only devices, fully
accelerated devices, devices without a frame buffer, and so on).
For more information on OpenGL, refer to these documents, published by Addison-Wesley and
shipped with HP’s implementation of OpenGL:
■OpenGL Programming Guide
Instruction on programming in OpenGL, offered in a tutorial format.
■OpenGL Reference Manual
A reference that contains details on all standard OpenGL functions, as well as utility (GLU)
functions and X Window (GLX) functions.
■OpenGL Programming for the X Window System
Instruction on interfacing OpenGL with the X Window system.
the OpenGL product
This section provides information about HP’s implementation of the OpenGL product, as well as
information about the standard OpenGL product.

1–2 OpenGL implementation guide
overview of OpenGL
hp’s implementation of OpenGL
Topics covered in this section are:
■HP’s implementation of the OpenGL libraries
■supported graphics devices
■supported visuals
■visual support for other graphics devices
■buffer sharing between multiple processes
■support for 64-bit programming
■support for threads
hp’s implementation of the OpenGL libraries
The OpenGL product does not support archived libraries.
HP’s implementation of OpenGL provides the following libraries:
■libGL.so.2: Stub library that loads the appropriate rendering library
■libXfGL.so.2: OpenGL library for use with XFree86
■libGLU.so.2: OpenGL utilities library
There are two sets of libraries:
■The path for the 32-bit libraries is:
/opt/graphics/OpenGL/lib/hpux32
■The path for the 64-bit libraries is:
/opt/graphics/OpenGL/lib/hpux64
supported graphics devices
The graphics devices that support OpenGL on IPF are ATI™Fire GL4, ATI FireGL X1, and ATI
FireGL Z1.

OpenGL implementation guide 1–3
overview of OpenGL
supported visuals
In this section, each visual table will have a graphics device associated with it. For information
on visual support for graphics devices not in the above list, read the subsequent section “visual
support for other graphics devices” on page 1-4.
Visual Table for ATI Fire GL4
Visual Table for ATI FireGL X1 and ATI FireGL Z1
X Visual Information OpenGL GLX Information
Class Depth Color
Map
Size
Buffer
Size
Overlay=1
or
Image=0
RGBA=1
or
Index=0
Double
Buffer
# Aux.
Buffers
Color
Buffer
Stencil Accumulation
Buffer
RGBA Z R G B A
PseudoColor 8 256 8 1 0 0 0 0000 0 0 0 0 0 0
PseudoColor 8 256 8 1 0 1 0 0000 0 0 0 0 0 0
TrueColor 24 256 24 0 1 0 0 8880 24 4 16 16 16 0
TrueColor 24 256 24 0 1 1 0 8880 24 4 16 16 16 0
TrueColor 24 256 32 0 1 0 0 8888 24 4 16 16 16 16
TrueColor 24 256 32 0 1 1 0 8888 24 4 16 16 16 16
X Visual Information OpenGL GLX Information
Class Depth Color
Map
Size
Buffer
Size
Overlay=1
or
Image=0
RGBA=1
or
Index=0
Double
Buffer
# Aux.
Buffers
Color
Buffer
Stencil Accumulation
Buffer
RGBA Z R G B A
PseudoColor 8 256 8 1 0 0 0 0000 0 0 0 0 0 0
PseudoColor 8 256 8 1 0 1 0 0000 0 0 0 0 0 0
TrueColor 24 256 24 0 1 0 0 8880 24 8 16 16 16 0
TrueColor 24 256 24 0 1 1 0 8880 24 8 16 16 16 0
TrueColor 24 256 32 0 1 0 0 8888 24 8 16 16 16 16
TrueColor 24 256 32 0 1 1 0 8888 24 8 16 16 16 16

1–4 OpenGL implementation guide
overview of OpenGL
stereo visual support for ATI Fire GL4
When a monitor is configured in a stereo capable mode, ATI Fire GL4 will have the following
additional stereo visuals available. For more information on OpenGL stereo, read the section
“running hp's implementation of the OpenGL stereo application” on page 3-2.
Stereo Visual Support for ATI Fire GL4
stereo visual support for ATI Fire GL4
Stereo is not supported in the initial release of the FireGL X1/Z1 driver. It will be supported in a
future release.
visual support for other graphics devices
The OpenGL product can also be used with the Virtual Memory Driver (VMD) in Virtual GLX
mode (VGL). VMD allows you to use many X11 drawables (local or remote) as “virtual devices”
for three-dimensional graphics with OpenGL. This includes rendering to X terminals and other
non-GLX extended X Servers.
Visual Table for VMD/VGL
X Visual InformationOpenGL GLX Information
Class Depth Color
Map
Size
Buffer
Size
Overlay=1
or
Image=0
RGBA=1
or
Index=0
Double
Buffer
Stereo # Aux.
Buffers
Color Buffer Stencil Accumulation
Buffer
RGBAZ R G B A
TrueColor 24 256 24 0 1 1 1 0 8 8 8 0 24 4 16 16 16 0
TrueColor 24 256 32 0 1 1 1 0 8 8 8 8 24 4 16 16 16 16
X Visual Information OpenGL GLX Information
Class Depth Color
Map
Size
Buffer
Size
Overlay=1
or Image=0
RGBA=1
or
Index=0
Double
Buffer
# Aux.
Buffers
Color Buffer Stencil Accumulation
Buffer
RGBA Z R G B A
PseudoColor 8 256 8 0 0 * 0 0000 24 4 0 0 0 0
PseudoColor 8 256 8 0 0 * 0 0000 0 0 0 0 0 0
TrueColor 8 256 8 1 1 * 0 3320 24 4 16 16 16 0
TrueColor 24 256 24 0 1 * 0 888** 24 4 16 16 16 16
*Double buffering is set to True (1) if the X visual supports the X double-buffering extension (DBE).
**Alpha will only work correctly on 12- and 24-bit TrueColor and DirectColor visuals when the X Server does not use the
high-order nybble/byte in the X visual. Also, note that when alpha is present, Buffer Size will be 16 for the 12-bit visuals
and 32 for the 24-bit visuals.

OpenGL implementation guide 1–5
overview of OpenGL
threads support
OpenGL supports Level 2 threads. This means HP OpenGL can be used in threaded applications,
and more than one thread can use OpenGL.
Using OpenGL graphics in a kernel threaded application requires that the application link with
libpthread.so (not the archived version, libpthread.a).
OpenGL libraries are not cancel safe or fork safe.
A given context can only be current in one thread at a time.
Enable your X11 library to use threads by calling XInitThreads () in your program. An example
of a threaded OpenGL program is given in /opt/graphics/OpenGL/demos/threads.
additional documentation
For more information on using threads, see the following documentation:
■The http://docs.hp.com Web site (search for “Threads” and “Multiprocessing”)
■The OpenGL Programming Guide
■The OpenGL Reference Manual
■Threadtime by S. Norton and M. Dipasquale

1–6 OpenGL implementation guide
overview of OpenGL
64-bit programming
For information on porting your application to take advantage of 64-bit capabilities, see the
http://docs.hp.com Web site. Search for “64-bit Computing” to find the topic on “Porting.”
64-bit OpenGL allows “large data space” because the pointers are now 64-bit. But, the OpenGL
data types themselves are the same as the 32-bit library. For example, GLint is a 32-bit integer,
not a 64-bit long.
All 64-bit OpenGL libraries are located in /opt/graphics/OpenGL/lib/hpux64. The
following sample compile and link lines may help you to build your application once it has been
ported to take advantage of 64-bit capabilities:
Sample 32-bit compile and link:
cc -Ae -I/opt/graphics/OpenGL/include \
-I/usr/include/X11R6 -o cube.32 cube.c \
-L/opt/graphics/OpenGL/lib/hpux32 \
-L/usr/lib/hpux32/X11R6 -lGLU -lGL -lXhp11 -lXext -lX11 -lm
Sample 64-bit compile and link:
cc -Aa +DD64
-I/opt/graphics/OpenGL/include -I/usr/include/X11R6 -o cube.64 \
cube.c -L/opt/graphics/OpenGL/lib/hpux64 \
-L/usr/lib/hpux64/X11R6 -L/usr/lib/hpux64 -L/usr/lib \
-lGLU -lGL -lXhp11 -lXext -lX11 -lm
standard OpenGL product
This section covers the following topics:
■the OpenGL utilities library (GLU)
■input and output routines
■the OpenGL extensions for the X Window system (GLX)
OpenGL Utilities Library (GLU)
The OpenGL Utilities Library (GLU) provides a useful set of drawing routines that perform such
tasks as:
■generating texture coordinates
■transforming coordinates
■tessellating polygons
■rendering surfaces
■providing descriptions of curves and surfaces (NURBS)
■handling errors
For a detailed description of these routines, refer to the Reference section or the OpenGL
Reference Manual.
input and output routines
OpenGL was designed to be independent of operating systems and window systems, therefore, it
does not have commands that perform such tasks as opening a window. To obtain these
capabilities, you will need to use X Windows routines (those whose names start with “glX”).

OpenGL implementation guide 1–7
overview of OpenGL
the OpenGL extensions for the X Window system (GLX)
HP’s OpenGL implementation currently supports version 1.2 of the glx extension.
The OpenGL Extension to the X Window System (GLX) provide routines for:
■choosing a visual
■managing the OpenGL rendering context
■off-screen rendering
■double buffering
■using X fonts
For a detailed description of these routines, refer to the Reference section or the OpenGL
Reference Manual.
mixing of OpenGL and Xlib
The OpenGL implementation conforms to the specification definition for mixing Xlib and
OpenGL rendering to the same drawable. The following points should be considered when
mixing Xlib and OpenGL:
■OpenGL and Xlib renderers are implemented through separate pipelines and control streams.
Thus, rendering synchronization must be performed as necessary by the user’s application
via the GLX glXWaitX() and glXWaitGL() function calls.
■Xlib rendering does not affect the Z-buffer, so rendering in X and then OpenGL would result
in the OpenGL rendering replacing the Xlib rendering. This is true if the last OpenGL
rendering to the Z-buffer at that location resulted in the depth test passing. Xlib rendering is
always to the visible buffer (front buffer).
Note that mixing Xlib rendering with OpenGL rendering as well as with VMD, when using alpha
buffers, can produce unexpected side effects and should be avoided.
gamma correction
Gamma correction is used to alter hardware colormaps to compensate for the non-linearities in
the phosphor brightness of monitors. Gamma correction can be used to improve the “ropy” or
modulated appearance of antialiased lines. Gamma correction is also used to improve the
appearance of shaded graphics images, as well as scanned photographic images that have not
already been gamma corrected. A utility for adjusting the display’s gamma correction is provided
at /opt/graphics/common/bin/gamma.
For details on this feature, read the section “Gamma Correction” found in the Graphics
Administration Guide.

1–8 OpenGL implementation guide
overview of OpenGL
OpenGL extensions
The extensions listed in this section are extensions that HP has created; that is, in addition to
those standard functions described in the OpenGL Programming Guide, OpenGL Reference
Manual, and OpenGL Programming for the X Window System.
draw array set extension
For additional information, see Chapter 5, “programming hints.”
3D texture extension
The 3D-texture extension is useful for volumetric rendering of solid surfaces such as a marble
vase, or for rendering images where geometric alignment is important (such as an MRI medical
image). For this extension, the texture maps have width and height as they did for 2D, but also an
additional dimension depth not included in 2D. The third coordinate forms a right-handed
coordinate system, as the following illustration shows.
Right-Handed Coordinate System for 3D Texturing
Each MIPmap level consists of a block of data (see Each MIPmap is a Block in 3-D Texturing
below). Each MIPmap level of the texture map is treated as being arranged in a sequence of
adjacent rectangles. Each rectangle is a 2-dimensional image, so each MIPmap level is a (2m +
2b) (2n + 2b) (2l + 2b) block where b is a border width of either 0 or 1, and m, n and l are
non-negative integers.
Each MIPmap is a Block in 3-D Texturing
r (depth)
t (height)
s (width)

OpenGL implementation guide 1–9
overview of OpenGL
GL_LINEAR_MIPMAP_LINEAR Filtering may use Two Blocks
Enumerated Types for 3D Texturing
steps for 3D texturing programming
To use the 3D texture extension (see sample program below):
1. Enable the 3D texture extension using glEnable(GL_TEXTURE_3D_EXT);
2. Create a 3D texture using glTexImage3DEXT;
3. Specify or generate the s, t and r texture coordinates using glTexGen or glTexCoord3*;
4. Specify other parameters such as filters just as you would for 2D texturing, but use
GL_TEXTURE_3D_EXT for the target.
Extended Area Enumerated Type Description
Pixel Storage GL_[UN]PACK_IMAGE_HEIGHT_EXT
Default: 0 for each
The height of the image from which the
texture is created; it supersedes the value of
the height passed into glTexImage3DEXT.
Pixel Storage GL_[UN]PACK_SKIP_IMAGES_EXT
Default: 0 for each
The initial skip of contiguous rectangles of
the texture.
Texture Wrap Modes GL_TEXTURE_WRAP_R_EXT
Default: GL_REPEAT
The wrap mode applied to the r texture
coordinate.
Enable/Disable GL_MAX_3D_TEXTURE_SIZE_EXT,
GL_TEXTURE_BINDING_3D_EXT
Default: N/A
The method to enable/disable 3D
texturing.
Get Formats GL_MAX_3D_TEXTURE_SIZE_EXT,
GL_TEXTURE_BINDING_3D_EXT
Default: N/A
The maximum size of the 3D texture
allowed; bind query
Proxy GL_PROXY_TEXTURE_3D_EXT
Default: N/A
The proxy texture that can be used to query
the configurations.

1–10 OpenGL implementation guide
overview of OpenGL
3D texture program fragments
This program draws four layers in the base MIPmap level, and a diagonal slice through the base
MIPmap level.
/* Allocate texture levels separately, then concat to get 3D
texture */
GLubyte texture1[TEXTURE_WIDTH][TEXTURE_HEIGHT][4];
GLubyte texture2[TEXTURE_WIDTH][TEXTURE_HEIGHT][4];
GLubyte texture3[TEXTURE_WIDTH][TEXTURE_HEIGHT][4];
GLubyte texture4[TEXTURE_WIDTH][TEXTURE_HEIGHT][4];
GLubyte
textureConcat[TEXTURE_DEPTH][TEXTURE_WIDTH][TEXTURE_HEIGHT][4];
/* The checkerPattern procedure fills a texture of width and
height with a period of Checker_period alternating between
firstColor and secondColor, Texture should be declared prior to
calling checkerPattern. */
static void checkerPattern(int width, int height,
GLubyte *firstColor,
GLubyte *secondColor,
GLubyte *texture,
int Checker_period)
{
int texelX, texelY;
int index, fromIndex;
GLubyte *p = texture;
index = 0;
for (texelY = 0; texelY < height; texelY++) {
for (texelX = 0; texelX < width; texelX++) {
if (((texelX/Checker_period)% 2) ^
((texelY/Checker_period)% 2)) {
*p++ = firstColor[0]; /* red */
*p++ = firstColor[1]; /* green */
*p++ = firstColor[2]; /* blue */
*p++ = firstColor[3]; /* alpha */
} else {
*p++ = secondColor[0]; /* red */
*p++ = secondColor[1]; /* green */
*p++ = secondColor[2]; /* blue */
*p++ = secondColor[3]; /* alpha */
}
}
}
GLubyte blackRGBA[] = {0.0, 0.0, 0.0, 255.0};
GLubyte whiteRGBA[] = {255.0, 255.0, 255.0, 255.0};
GLubyte redRGBA[] = {255.0, 0.0, 0.0, 255.0};
GLubyte greenRGBA[] = {0.0, 255.0, 0.0, 255.0};
GLubyte blueRGBA[] = {0.0, 0.0, 255.0, 255.0};
GLubyte yellowRGBA[]= {255.0, 255.0, 0.0, 255.0};

OpenGL implementation guide 1–11
overview of OpenGL
GLubyte purpleRGBA[]= {255.0, 0.0, 255.0, 255.0};
GLubyte cyanRGBA[]= {0.0, 255.0, 255.0, 255.0};
GLubyte greyRGBA[] = {125.0, 125.0, 125.0, 255.0};
main(int argc, char *argv[]) {
/* Open window for displaying.Put your favorite code here to open
a window and perform perspective setup */
glEnable(GL_TEXTURE_3D_EXT);
checkerPattern(TEXTURE_WIDTH, TEXTURE_HEIGHT,
blueRGBA, whiteRGBA, &texture1[0][0][0], 4);
checkerPattern(TEXTURE_WIDTH, TEXTURE_HEIGHT,
redRGBA, yellowRGBA, &texture2[0][0][0], 4);
checkerPattern(TEXTURE_WIDTH, TEXTURE_HEIGHT,
greenRGBA, blackRGBA, &texture3[0][0][0], 4);
checkerPattern(TEXTURE_WIDTH, TEXTURE_HEIGHT,
purpleRGBA, cyanRGBA, &texture4[0][0][0], 4);
/* create a 3D texture, textureConcat, which has a different
checker pattern at each depth */
memcpy(&textureConcat[0][0][0], texture1, sizeof(texture1));
memcpy(&textureConcat[1][0][0], texture2, sizeof(texture2));
memcpy(&textureConcat[2][0][0], texture3, sizeof(texture3));
memcpy(&textureConcat[3][0][0], texture4, sizeof(texture4));
glTexParameterf(GL_TEXTURE_3D_EXT, GL_TEXTURE_WRAP_S, GL_CLAMP);
glTexParameterf(GL_TEXTURE_3D_EXT, GL_TEXTURE_WRAP_T, GL_CLAMP);
glTexParameterf(GL_TEXTURE_3D_EXT, GL_TEXTURE_WRAP_R_EXT,
GL_CLAMP);
glTexParameterf(GL_TEXTURE_3D_EXT, GL_TEXTURE_MAG_FILTER,
GL_NEAREST);
glTexParameterf(GL_TEXTURE_3D_EXT, GL_TEXTURE_MIN_FILTER,
GL_NEAREST);
glTexImage3DEXT(GL_TEXTURE_3D_EXT, 0, GL_RGBA, TEXTURE_WIDTH,
TEXTURE_HEIGHT, TEXTURE_DEPTH, 0, GL_RGBA, GL_UNSIGNED_BYTE,
&textureConcat);
/* Fill a quad with depth of r = 0.125, passed into glTexCoord
for every vertex. */ Add your quad code here
/* Fill a quad with depth of r = 0.375, passed into glTexCoord
for every vertex. */ Add your quad code here
/* Fill a quad with depth of r = 0.625, passed into glTexCoord
for every vertex. */ Add your quad code here
/* Fill a quad with depth of r = 0.875, passed into glTexCoord
for every vertex. */ Add your quad code here
/* Now get a slice across the quad. Here’s some quad code for a
sample. Make sure you have appropriate viewing perspectives. */
glBegin(GL_QUADS);
glNormal3f(0., 0., 1.);
glTexCoord3f(0.0, 0.0, 0.0);
glVertex3f(0.5, 0.5, 0.);
glNormal3f(0., 0., 1.);
glTexCoord3f(0.0, 1.0, 0.0);

1–12 OpenGL implementation guide
overview of OpenGL
glVertex3f(0.5, 62.5, 0.);
glNormal3f(0., 0., 1.);
glTexCoord3f(1.0, 1.0, 1.0);
glVertex3f(62.5, 62.5, 0.);
glNormal3f(0., 0., 1.);
glTexCoord3f(1.0, 0.0, 1.0);
glVertex3f(62.5, 0.5, 0.);
glEnd();
}
The results of code fragments are shown in Results from the 3D Texture Program Fragments
below. This figure shows four layers in the base MIPmap level, and a diagonal slice through the
base MIPmap level.
Results from the 3D Texture Program Fragments
For more information on 3D texture, see the functions: glTexImage3DEXT,
glTexSubImage3DEXT, glCopyTexSubImage3DEXT,glEnable, glDisable.
occlusion extension
This occlusion culling extension defines a mechanism whereby an application can determine the
non-visibility of some set of geometry based on whether an encompassing set of geometry is not
visible. In general, this feature does not guarantee that the target geometry is visible when the test
fails, but is accurate with regard to non-visibility.
Typical usage of this feature would include testing the bounding boxes of complex objects for
visibility. If the bounding box is not visible, then it is known that the object is not visible and
need not be rendered.

OpenGL implementation guide 1–13
overview of OpenGL
occlusion culling code fragments
The following is a sample code segment that shows a simple usage of occlusion culling.
/* Turn off writes to depth and color buffers */
glDepthMask(GL_FALSE);
glColorMask (GL_FALSE, GL_FALSE, GL_FALSE);
/* Enable Occlusion Culling test */
glEnable(GL_OCCLUSION_TEST_HP);
for (i=0; i < numParts; i++) {
/* Render your favorite bounding box */
renderBoundingBox(i);
/* If bounding box is visible, render part */
glGetBooleanv(GL_OCCLUSION_RESULT_HP, &result);
if (result) {
glColorMask(GL_TRUE, GL_TRUE, GL_TRUE);
glDepthMask(GL_TRUE);
renderPart(i);
glDepthMask(GL_FALSE);
glColorMask (GL_FALSE, GL_FALSE, GL_FALSE);
}
}
/* Disable Occlusion Culling test */
glDisable(GL_OCCLUSION_TEST_HP);
/* Turn on writes to depth and color buffers */
glColorMask(GL_TRUE, GL_TRUE, GL_TRUE);
glDepthMask(GL_TRUE);
The key idea behind occlusion culling is that the bounding box is much simpler (that is, fewer
vertices) than the part itself. Occlusion culling provides a quick means to test non-visibility of a
part by testing its bounding box.
It should also be noted that this occlusion culling functionality is very useful for view frustum
culling. If a part’s bounding box is not visible for any reason (not just because it’s occluded in the
Z-buffer) this test will give correct results.
To maximize the probability that an object is occluded by other objects in a scene, the database
should be sorted and rendered from front to back. Also, the database may be sorted hierarchically
such that the outer objects are rendered first and the inner are rendered last. An example would
be rendering the body of an automobile first and the engine and transmission last. In this way, the
engine would not be rendered due to the bounding box test indicating that the engine is not
visible.
Enumerated Types for Occlusion
For related information, see the functions: glEnable, glDisable, and glIsEnabled.
Extended Area Enumerated Type Description
Enable.Disable/IsEnabled GL_OCCLUSION_TEST_HP
Default: Disabled
pname variable.
Get* GL_OCCLUSION_TEST_RESULT_HP
Default: Zero (0)
pname variable

1–14 OpenGL implementation guide
overview of OpenGL
visibility test extension
The Visibility Test extension provides a way for an application to test whether or not a primitive
or set of primitives are visible against the current contents of the depth buffer. "Visibile" in this
context means that at least one pixel passes the depth test. This differs from previous Occlusion
Culling extensions by allowing the programmer to provide memory for many different Visibility
Test results to be returned at the same time. This feature can be used with the
glNextVisibilityTestHP routine in conjunction with the glVisibilityBufferHP routine.
With glVisibilityBufferHP, the programmer specifies a Boolean array in which to store the results
of the visibility tests; a call to glNextVisibilityTestHP finishes the current test (eventually placing
the results of the test in the current position of the array specified by glVisiblityBufferHP), and
beginning the next test, whose results will be placed in the subsequent entry of the array.
Visibility Testing is enabled by a call to glEnable(VISIBILITY_TEST_HP). Making this call to
glEnable (if VISIBILITY_TEST_HP has not already been enabled) causes Visibility Testing to
begin, and sets the result destination to be the first entry in the buffer specified by
glVisibilityBufferHP.
The glNextVisibilityTest function prototype is defined as:
void glNextVisibilityTestHP( void )
The glVisibilityBufferHP function prototype is defined as:
void glVisibilityBufferHP( GLSizei size, GLboolean *buffer,
GLboolean wait_on_get)
glVisibilityBuffer has three arguments: ‘buffer’, ‘size’ and ‘wait_on_get’. 'buffer' is a pointer to
an array of Boolean values, and 'size' indicates the size of the array. 'buffer' returns values of
GL_TRUE or GL_FALSE for each Visibility Test issued. A Visibility Test begins when a call is
made to glEnable(GL_VISIBILITY_TEST_HP), and ends when a call is made to either
glDisable(GL_VISIBILITY_TEST_HP), or glNextVisibilityTestHP(). When all Visibility Tests
have been performed, glDisable(GL_VISIBILITY_TEST_HP) should be called, followed by a
call to glGet of GL_VISIBILITY_TEST_HP. Calling glGet causes the contents of 'buffer' to be
up to date (based on the value of the 'wait_on_get' parameter, discussed below). A Visibility Test
result of GL_TRUE indicates that some portion of the primitive(s) rendered during that test were
visible. A value of GL_FALSE indicates that no portion of the primitive(s) rendered during the
test was visible.
The third parameter, 'wait_on_get', is intended to allow for potential optimizations during
Visibility Tests. When Visibility Tests are made, there is often some amount of latency between
the time the request is made and when the answer is available. Once a glGet of
GL_VISIBILITY_TEST_HP is called after glDisable(GL_VISIBILITY_TEST_HP), there will
usually be a short delay (perhaps as much as 50 microseconds) before the answer is available. If
the application would prefer to wait until the Visibility Test results are available before
proceeding, then a value of GL_TRUE should be specified for the 'wait_on_get' parameter. If, on
the other hand, the application has some useful work to do during that time, a value of
GL_FALSE can be specified for the 'wait_on_get' parameter, and glGet returns immediately.
However, 'buffer' is not guaranteed to be defined until some time later. To check to see when the
Visibility Test results are complete, the programmer can look at the data returned by a glGet of
GL_VISIBILITY_TEST_HP.
Two Boolean value are returned. The first indicates whether or not GL_VISIBILITY_TEST_HP
is currently enabled. The second indicates if there are any test results pending. If there are no test
results pending, the programmer may conclude that 'buffer' is up to date.

OpenGL implementation guide 1–15
overview of OpenGL
The following is a sample code segment of how the visibility test extension might be used.
#define NUMTESTS 1000
GLboolean
visBuffer[NUMTESTS],
visstuff[2];
glVisibilityBufferHP(NUMTESTS,visBuffer,GL_TRUE);
glEnable(GL_VISIBILITY_TEST_HP);
// We don't actually want to touch the Color or Depth buffers...
glDepthMask(GL_FALSE);
glColorMask(GL_FALSE, GL_FALSE,GL_FALSE,GL_FALSE);
for ( [Each object to be tested] )
{
<Render Object's bounding box>
// Move on to the next test
glNextVisibilityTestHP();
}
glDisable(GL_VISIBILITY_TEST_HP);
glGetBooleanv(GL_VISIBILITY_TEST_HP, visstuff);
// Turn these back on for rendering the objects
glDepthMask(GL_TRUE);
glColorMask(GL_TRUE, GL_TRUE,GL_TRUE,GL_TRUE);
for ( i=0; i < [Num Objects Tested] )
{
if (visBuffer[i] )
{
[ Render the ith Object ]
}
}

1–16 OpenGL implementation guide
overview of OpenGL
texture autogen MIPmap extension
The autogen MIPmap extension introduces a side effect to the modification of the base level
texture map. When enabled, any change to the base-level texture map will cause the computation
of a complete MIPmap stack form for that base level. The internal formats and border widths of
the derived MIPmap will match those of the base map, and the dimensions of the derived
MIPmap follow the requirements set forth in OpenGL for a valid MIPmap. A simple 2 x 2 box
filter is used to generate the MIPmap levels.
Enumerated Types for Autogen MIPmap
To use the autogen MIPmap extension, set GL_GENERATE_MIPMAP_EXT to GL_TRUE in
glTexParameter. For example, here is a code fragment that uses this extension:
glTexParameter[if](GL_TEXTURE_2D,GL_GENERATE_MIPMAP_EXT,
GL_TRUE);
For related information on this extension, see the function: glTexParameter.
X Window extensions for hp’s implementation of OpenGL
HP’s implementation of OpenGL includes two GLX extensions that deal with extended GLX
visual information that is not included in the OpenGL 1.1 Standard. These extensions are both
supported by HP’s implementation of the OpenGL API library, but, prior to using them,
glXQueryExtensionsString should be called to verify that the extensions are supported
on the target display.
GLX visual information extension
The GLX_EXT_visual_info extension provides additional GLX visual information and
enhanced control of GLX Visual selection. The enumerated types listed below can be passed to
either glXChooseVisual or glXGetConfig to specify or inquire the visual type or
transparency capabilities.
Extended Area Enumerated Type Description
Texture Parameter GL_GENERATE_MIPMAP_EXT
Default: GL_FALSE
Enables autogen MIPmap
