HP 321 - Notebook PC Manual

Compaq 320 Notebook PC
Compaq 321 Notebook PC
Compaq 420 Notebook PC
Compaq 421 Notebook PC
Compaq 620 Notebook PC
Compaq 621 Notebook PC
HP 420 Notebook PC
HP 620 Notebook PC
Maintenance and Service Guide

Bluetooth is a trademark owned by its
proprietor and used by Hewlett-Packard
Company under license. Intel, Core, and
Celeron are trademarks of Intel Corporation
in the United States and other countries.
Microsoft, Windows, and Windows Vista are
U.S. registered trademarks of Microsoft
Corporation. SD Logo is a trademark of its
proprietor.
The information contained herein is subject
to change without notice. The only
warranties for HP products and services are
set forth in the express warranty statements
accompanying such products and services.
Nothing herein should be construed as
constituting an additional warranty. HP shall
not be liable for technical or editorial errors
or omissions contained herein.
First Edition: April 2010
Document Part Number: 601871-001

MSG revision history
Revision Publication date Description
A October 2010 Updated AC adapter part numbers:
●613149-001–65-W AC adapter for use with computers with UMA graphics
●613150-001–90-W AC adapter for use with computers with discrete graphics
iii

iv MSG revision history

Safety warning notice
WARNING! To reduce the possibility of heat-related injuries or of overheating the computer, do not
place the computer directly on your lap or obstruct the computer air vents. Use the computer only on
a hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft
surface, such as pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to
contact the skin or a soft surface, such as pillows or rugs or clothing, during operation. The computer
and the AC adapter comply with the user-accessible surface temperature limits defined by the
International Standard for Safety of Information Technology Equipment (IEC 60950).
v

vi Safety warning notice

Table of contents
1 Product description ........................................................................................................................................ 1
2 External component identification ................................................................................................................ 9
Top Components .................................................................................................................................. 9
TouchPad ............................................................................................................................ 9
Lights ................................................................................................................................. 10
Buttons, switch, and speaker ............................................................................................. 11
Keys ................................................................................................................................... 12
Front components .............................................................................................................................. 14
Right-side components ....................................................................................................................... 14
Left-side components ......................................................................................................................... 15
Bottom components ........................................................................................................................... 16
Multimedia components ..................................................................................................................... 17
Wireless antennas (select models only) ............................................................................................. 19
Additional hardware components ....................................................................................................... 20
3 Illustrated parts catalog ............................................................................................................................... 21
Service tag ......................................................................................................................................... 21
Computer major components ............................................................................................................. 23
Display assembly components ........................................................................................................... 29
Plastics Kit .......................................................................................................................................... 30
Cables ................................................................................................................................................ 31
Mass storage devices ......................................................................................................................... 33
Miscellaneous parts ............................................................................................................................ 34
Sequential part number listing ............................................................................................................ 35
4 Removal and replacement procedures ....................................................................................................... 42
Preliminary replacement requirements ............................................................................................... 42
Tools required .................................................................................................................... 42
Service considerations ....................................................................................................... 42
Plastic parts ....................................................................................................... 42
Cables and connectors ..................................................................................... 43
Drive handling ................................................................................................... 43
vii

Grounding guidelines ......................................................................................................... 44
Electrostatic discharge damage ........................................................................ 44
Packaging and transporting guidelines ............................................. 45
Workstation guidelines ..................................................................... 45
Equipment guidelines ....................................................................... 46
Component replacement procedures ................................................................................................. 47
Service tag ......................................................................................................................... 47
Computer feet .................................................................................................................... 48
Battery ............................................................................................................................... 49
Service door ....................................................................................................................... 49
Hard drive .......................................................................................................................... 52
Memory module ................................................................................................................. 55
WLAN module .................................................................................................................... 57
Optical drive ....................................................................................................................... 58
Fan ..................................................................................................................................... 60
Heat sink ............................................................................................................................ 61
Processor ........................................................................................................................... 62
Palm rest ............................................................................................................................ 64
Keyboard ........................................................................................................................... 69
Top cover ........................................................................................................................... 73
Power switch board ........................................................................................................... 78
Bluetooth module ............................................................................................................... 80
USB connector assembly .................................................................................................. 81
Speaker ............................................................................................................................. 83
Display assembly ............................................................................................................... 84
System board ..................................................................................................................... 92
Main battery connector ...................................................................................................... 96
RTC battery ....................................................................................................................... 98
Modem module .................................................................................................................. 99
Audio board ..................................................................................................................... 100
5 Computer Setup .......................................................................................................................................... 103
Computer Setup in Windows ............................................................................................................ 103
Starting Computer Setup ................................................................................................. 103
Using Computer Setup .................................................................................................... 103
Navigating and selecting in Computer Setup .................................................. 103
Restoring factory settings in Computer Setup ................................................. 104
Computer Setup menus ................................................................................................... 105
File menu ........................................................................................................ 105
Security menu ................................................................................................. 106
System Configuration menu ............................................................................ 107
Computer Setup in Linux .................................................................................................................. 111
Starting Computer Setup ................................................................................................. 111
viii

Using Computer Setup .................................................................................................... 112
Navigating and selecting in Computer Setup .................................................. 112
Restoring factory settings in Computer Setup ................................................. 112
Computer Setup menus ................................................................................................... 113
File menu ........................................................................................................ 113
Security menu ................................................................................................. 114
Diagnostics menu ............................................................................................ 114
System Configuration menu ............................................................................ 115
6 Specifications .............................................................................................................................................. 117
Computer specifications ................................................................................................................... 117
39.6-cm (15.6-in) display specifications ........................................................................................... 118
35.6-cm (14.0-in) display specifications ........................................................................................... 119
33.8-cm (13.3-in) display specifications ........................................................................................... 120
Hard drive specifications .................................................................................................................. 121
DVD-ROM Drive specifications ........................................................................................................ 122
DVD±RW Double-Layer Combo Drive specifications ....................................................................... 123
7 Backup and recovery .................................................................................................................................. 124
Backup and recovery in Windows 7 ................................................................................................. 124
Overview .......................................................................................................................... 124
Backing up your information ............................................................................................ 124
Performing a recovery ..................................................................................................... 126
Using the Windows recovery tools ................................................................................... 126
Using f11 .......................................................................................................................... 127
Using a Windows 7 operating system DVD (purchased separately) ............................... 127
Backup and recovery in Windows Vista ........................................................................................... 128
Overview .......................................................................................................................... 128
Backing up your information ............................................................................................ 128
Performing a recovery ..................................................................................................... 129
Using the Windows recovery tools ................................................................................... 130
Using f11 .......................................................................................................................... 130
Using a Windows Vista operating system DVD (purchased separately) ......................... 131
Backup and recovery in Windows XP .............................................................................................. 132
Overview .......................................................................................................................... 132
Backing up your information ............................................................................................ 132
Performing a recovery ..................................................................................................... 133
Recovering your information ........................................................................... 133
Recovering the operating system and programs ............................................ 133
8 Connector pin assignments ....................................................................................................................... 134
Audio-in (microphone) ...................................................................................................................... 134
Audio-out (headphone) ..................................................................................................................... 134
ix

External monitor ............................................................................................................................... 135
HDMI ................................................................................................................................................ 136
RJ-11 (modem) ................................................................................................................................ 137
RJ-45 (network) ................................................................................................................................ 138
Universal Serial Bus ......................................................................................................................... 138
9 Power cord set requirements .................................................................................................................... 139
Requirements for all countries and regions ...................................................................................... 139
Requirements for specific countries and regions ............................................................................. 140
10 Recycling ................................................................................................................................................... 141
Battery .............................................................................................................................................. 141
Display .............................................................................................................................................. 141
Index .................................................................................................................................................................147
x

1 Product description
Category Description UMA graphics,
GL40 chipset
UMA graphics,
GM45 chipset
Discrete
graphics,
PM45 chipset
Product Name Compaq 320 Notebook PC √√
Compaq 321 Notebook PC √
Compaq 420 Notebook PC √√
Compaq 421 Notebook PC √
Compaq 620 Notebook PC √√
Compaq 621 Notebook PC √
HP 420 Notebook PC √√
HP 620 Notebook PC √√
Processors Intel® Celeron® processors
T3300, 2.00-GHz, 800-MHz FSB, 1-MB
cache
√√
T3100, 1.90-GHz, 800-MHz FSB, 1-MB
cache
√√
T1700, 1.83-GHz, 667-MHz FSB, 1-MB
cache
√√
T1600, 1.66-GHz, 667-MHz FSB, 1-MB
cache
√√
900, 2.20-GHz, 800-MHz FSB, 1-MB cache √√
Intel® Pentium® processor
T4400, 2.20-GHz, 800-MHz FSB, TJ 100 √√ √
T4300, 2.10-GHz, 800-MHz FSB, TJ 100 √√ √
T4200, 2.00-GHz, 800-MHz FSB, TJ 100 √√ √
Intel® Core™ 2 Duo processor
T5870, 2.00-GHz, 800-MHz FSB, 2-MB
cache
√for 39.6-cm
(15.6-in) only
√√
P7570, 2.26-GHz, 1066-MHz FSB, 3-MB
cache
√√
1

Category Description UMA graphics,
GL40 chipset
UMA graphics,
GM45 chipset
Discrete
graphics,
PM45 chipset
P7370, 2.00-GHz, 1066-MHz FSB, 3-MB
cache
√√
T6670, 2.20-GHz, 800-MHz FSB, 2-MB
cache
√√
T6570, 2.10-GHz, 800-MHz FSB, 2-MB
cache
√√
Chipsets Intel GL40 with 667-MH FSB √
Intel GM45 with up to 1066-MHz FSB √
Intel PM45 with up to 1066-MHz FSB √
ICH-9M Southbridge √√ √
Graphics Intel GMA 4500M Universal Memory
Architecture (UMA) graphics subsystem
integrated with shared video memory
(dynamically allocated)
√
Intel GMA 4500MHD Universal Memory
Architecture (UMA) graphics subsystem
integrated with shared video memory
(dynamically allocated)
√
ATI Mobility Radeon HD 530v with 512-MB
memory
√
Panels All display assemblies support privacy filter √√ √
33.8-cm (13.3-in) HD LED backlight panel:
●1366×768 AntiGlare
●1366×768 AntiGlare for webcam
●1366×768 BrightView
●1366×768 BrightView for Webcam
√√ √
35.6-cm (14.0-in) HD LED backlight panel:
●1366×768 AntiGlare
●1366×768 AntiGlare for webcam
●1366×768 BrightView
●1366×768 BrightView for Webcam
√√ √
39.6-cm (15.6-in) HD LED backlight panel:
●1366×768 AntiGlare
●1366×768 AntiGlare for webcam
●1366×768 BrightView
●1366×768 BrightView for Webcam
√√ √
Memory 2 customer-accessible/upgradable memory
module slots
√√ √
2 Chapter 1 Product description

Category Description UMA graphics,
GL40 chipset
UMA graphics,
GM45 chipset
Discrete
graphics,
PM45 chipset
Supports dual-channel memory √√ √
Supports up to 4 GB of system RAM √√ √
PC3-10600, 1333-MHz, DDR3 √√ √
Supports the following configurations in all
countries and regions:
●4096-MB total system memory (4096-
MB × 1)
●4096-MB total system memory (2048-
MB× 2, dual-channel)
●3072-MB total system memory (2048-
MB + 1024-MB, dual-channel)
●2048-MB total system memory (2048-
MB × 1)
●2048-MB total system memory (1024-
MB × 2, dual-channel)
●1024-MB total system memory (1024-
MB × 1)
√√ √
Hard drives Supports 9.5-mm, 6.35-cm (2.50-in) hard
drives
√√ √
Customer-accessible √√ √
Serial ATA √√ √
Supports the following drives:
●500-GB, 7200-rpm
●500-GB, 5400-rpm
●320-GB, 7200-rpm
●320-GB, 5400-rpm
●250-GB, 7200-rpm
●250-GB, 5400-rpm
●160-GB, 7200-rpm
●160-GB, 5400-rpm
√√ √
HP DriveGuard (not available on Linux) √√ √
Optical drives Fixed, no modular requirements √√ √
SATA 12.7-mm tray load √√ √
Supports option of no optical drive √√ √
3

Category Description UMA graphics,
GL40 chipset
UMA graphics,
GM45 chipset
Discrete
graphics,
PM45 chipset
Supports the following drives:
●DVD-ROM Drive
●DVD±RW SuperMulti Double-Layer
Combo Drive with Lightscribe
√√ √
Diskette drive Supports external USB diskette drive only √√ √
Audio/Visual IDT 92HD88 √√ √
Integrated microphone √√ √
Single speaker √√ √
Headphone and microphone jacks √√ √
Integrated 2MP camera with fixed focus
(select models only)
√√ √
Modem 56K V.92 3.8 cm (1.5-in) data/fax modem √√ √
Supports no modem option √√ √
For use in all countries and regions except
APJ
√√ √
For use in APJ only √√ √
Modem cable not included √√ √
Ethernet 10/100 Ethernet network interface card (NIC) √√ √
S3/S4/S5 wake on LAN: AC only mode √√ √
Ethernat cable not included √√ √
Wireless Integrated WLAN options by way of MiniPCI card:
2 WLAN antennas built into display assembly √√ √
Supports option for no-WLAN √√ √
Support for the following WLAN formats:
●Broadcom 802.11b/g
●Broadcom 802.11b/g/n (1 x 1)
●Atheros 802.11 b/g/n (1 x 1)
●Realtek 802.11 b/g/n (1 x 1)
●Intel 802.11 b/g/n (1 x 2)
√√ √
Integrated wireless personal area network (WPAN) options by way of Bluetooth® module:
Support option for no-WPAN √√ √
Bluetooth 2.1 √√ √
External media
cards
One ExpressCard/33-mm √√ √
4 Chapter 1 Product description

Category Description UMA graphics,
GL40 chipset
UMA graphics,
GM45 chipset
Discrete
graphics,
PM45 chipset
Media Card Reader supporting Secure
Digital (SD) Memory Card, Secure Digital
High Capacity (SDHC) Memory Card,
MultiMediaCard (MMC) formats
√√ √
Ports Audio-in (microphone) √√ √
Audio-out (stereo headphone) √√ √
RJ-11 (modem) √√ √
RJ-45 (Ethernet, includes link and activity
lights)
√√ √
USB 2.0 (3) √√ √
HP non-Smart adapter √√ √
VGA (Dsub 15-pin) supporting 1600 × 1200
external resolution at 75-GHz (hot plug/
unplug with auto-detect)
√√ √
Multi-pin AC power √√ √
HDMI √√ √
Keyboard/pointing
devices
39.6-cm (15.6-in) keyboard with TouchPad √√ √
35.6-cm (14.0-in)/33.8-cm (13.3-in)
keyboard with TouchPad
√√ √
Suports 2-way scroll with legend and
gestures (taps enabled as default)
√√ √
Power
requirements
65-W non-Smart AC adapter √√
90-W non-Smart AC adapter √
6-cell, 47-Wh Li-ion battery √√ √
9-cell, 93-Wh Li-ion battery √√ √
Security Supports Kensington security lock √√ √
Operating system Preinstalled with Microsoft Office: √√ √
Windows 7 Home Premium 32 with Office
2007 Ready (excludes Japan)
√√ √
Windows 7 Home Premium 32 with Office
2007 Personal (Japan only)
√√ √
Windows 7 Home Premium 32 with Office
2007 Personal with PowerPoint (Japan only)
√√ √
Windows 7 Home Premium 32 with Office
2007 Professional (Japan only)
√√ √
Windows 7 Professional with Office 2007
Ready (excludes Japan)
√√ √
5

Category Description UMA graphics,
GL40 chipset
UMA graphics,
GM45 chipset
Discrete
graphics,
PM45 chipset
Windows 7 Professional with Office 2007
Personal (Japan only)
√√ √
Windows 7 Professional with Office 2007
Personal with PowerPoint (Japan only)
√√ √
Windows 7 Professional with Office 2007
Professional (Japan only)
√√ √
Windows Vista Home Basic 32 with Office
2007 Ready (excludes Japan)
√√ √
Windows Vista Home Basic 32 with Office
2007 Personal (Japan only)
√√ √
Windows Vista Home Basic 32 with Office
2007 Professional and PowerPoint (Japan
only)
√√ √
Windows Vista Home Basic 32 with Office
2007 Ready and 1 year McAffey (People's
Republic of China only)
√√ √
Windows Vista Home Basic 32 with Office
2007 Professional (Japan only)
√√ √
Windows 7 Starter with Office 2007 ready
(excludes Japan)
√√ √
Windows 7 Starter 32 with Office 2007 ready
– EDGI
√√ √
Windows 7 Home Basic 32 with Office 2007
ready (excludes Japan)
√√ √
Windows 7 Home Basic 32 with Office 2007
ready – EDGI
√√ √
Windows 7 Home Premium with Office 2007
ready – EDGI
√√ √
Windows 7 Professional 32 with Office 2007
ready – EDGI
√√ √
Windows 7 Professional 32 with XP Pro
images with Office 2007 ready (excludes
Japan)
√√ √
Windows 7 Professional 32 with XP Pro
images with Office 2007 ready – EDGI
√√ √
Windows 7 Professional 32 with XP Pro
images with Office 2007 Personal (Japan
only)
√√ √
Windows 7 Professional 32 with XP Pro
images with Office 2007 Personal with
PowerPoint (Japan only)
√√ √
Windows 7 Professional 32 with XP Pro
images with Office 2007 Professional (Japan
only)
√√ √
6 Chapter 1 Product description

Category Description UMA graphics,
GL40 chipset
UMA graphics,
GM45 chipset
Discrete
graphics,
PM45 chipset
Preinstalled:
Windows 7 Professional 32 (Japan only) √√ √
Windows 7 Home Premium 32 (Japan only) √√ √
Windows Vista Home Basic 32 with MS
Basics (Japan only)
√√ √
Windows 7 Professional 32 (with XP
Professional images) with MS Basics (Japan
only)
√√ √
FreeDOS √√ √
RedFlag Linux (People's Republic of China
only)
√√ √
SuSE Linux √√ √
Restore media:
Windows 7 Home Basic 32 √√ √
Windows 7 Home Premium 32 √√ √
Windows 7 Home Premium 64 √√ √
Windows 7 Starter4 √√ √
Windows Vista Basic 32 √√ √
Windows 7 Professional 32 √√ √
Windows 7 Professional 64 √√ √
DRDVD Windows 7 – Home Premium/Pro √√ √
DRDVD Windows 7 – Starter/Home Basic √√ √
Windows XP Professional √√ √
SRDVD SuSE Linux √√ √
Red Flag Linux (People's Republic of China
only)
√√ √
DRDVD Windows Vista √√ √
DRDVD Windows XP Pro √√ √
Windows Vista Office Ready DVD √√ √
Certified:
Microsoft® WHQL √√ √
SuSE Linux √√ √
Web Support:
All Windows Vista 64 versions √√ √
Windows 7 Professional 64 versions √√ √
7

Category Description UMA graphics,
GL40 chipset
UMA graphics,
GM45 chipset
Discrete
graphics,
PM45 chipset
SuSE Linux √√ √
Serviceability End-user replaceable parts:
AC adapter √√ √
Battery (system) √√ √
Hard drive √√ √
Memory module √√ √
Keyboard √√ √
Optical drive √√ √
WLAN module √√ √
8 Chapter 1 Product description

2 External component identification
Top Components
TouchPad
Component Description
(1) TouchPad * Moves the pointer and selects or activates items on the screen.
(2) TouchPad button The left and right sides of the single button function like the left
and right buttons on an external mouse.
(3) TouchPad scroll zone Scrolls up or down.
Top Components 9

Lights
NOTE: Refer to the illustration that most closely matches your computer.
Component Description
(1) Caps lock light On: Caps lock is on.
(2) Power light ●On: The computer is on.
●Blinking: The computer is in the Suspend state.
●Off: The computer is off or in Hibernation.
(3) Wireless light ●White: An integrated wireless device, such as a wireless
local area network (WLAN) device is on.
●Amber: All wireless devices are off.
10 Chapter 2 External component identification
