HP Compaq NC6140 User manual

1. Volume Mute Button with LED 13. PC Card Slots
2. Volume Down Button 14. IEEE 1394 Port
3. Volume Up Button 15. RJ-45 Port (NIC)
4. 6-in-1 Media Reader 16 RJ-11 Port (Modem)
5. Stereo Speakers 17 VGA/External Monitor Connector
6. Touchpad with Scroll Zone 18. 2 USB 2.0 Ports
7. Hard Drive Activity LED 19. Power Button with LED
8. Battery Charging LED 20. HP Info Center Button
9. Power/Standby LED 21. Wireless On/Off Button with LED
10. Wireless On/Off 22. Presentation Mode Button
11. Fast Infrared Port 23. Dual-band Wireless LAN Antennas
12. PC Card Eject Button 24 WWAN Antennas
QuickSpecs
HP Compaq nc6140 Notebook PC
Overview
DA - 12375 North America — Version 6 — September 6, 2006 Page 1

1. Headphone Jack 6. Serial Port
2. Microphone Jack 7. Kensington Lock Slot
3. 2 USB 2.0 Ports 8. DC Power Connector
4. Optical Drive 9. Parallel Port
5. Optical Drive Button 10. S-Video TV Out
At A Glance
Genuine Windows XP Professional
Intel® Pentium® M processors 750 or 760*
Sleek industrial design starting at 6.06 lb/2.75 kg and 1.2-inch/30.3 mm thin at front
Mobile Intel 915GM Express Chipset
512-MB DDR SDRAM, upgradeable to 2048-MB maximum
Up to 60-GB 5400 rpm hard drive
Choice of optical drive: DVD/CD-RW Combo, DVD+/-RW with Double Layer Technology
Intel Graphics Media Accelerator 900
Integrated 802.11a/b/g wireless LAN module
Integrated HP ev2200 1xEV-DO Broadband Wireless module
Intel Centrino™ mobile technology
Integrated Bluetooth®
6-in-1 Media Reader
NetXtreme Gigabit Ethernet Controller
Touchpad with scroll zone
Support for HP docking solutions and HP Travel Battery
Security features:
HP ProtectTools
HP Drivelock
Kensington lock slot
Ease of use features
HP Mobile Print Driver for on-the-go printing
HP Wireless Assistant
HP Info Center
HP Fast Charge technology
Up to 4 hours of battery life
Integrated reliability features:
QuickSpecs
HP Compaq nc6140 Notebook PC
Overview
DA - 12375 North America — Version 6 — September 6, 2006 Page 2

HP Mobile Data Protection System
HP Panel Protection System
Scratch-resistant keyboard using In-mold Lamination
HP spill-resistant keyboard with Mylar film
Protected by a three-year, standard parts and labor warranty – certain restrictions and exclusions apply
*Intel's numbering system is not a measurement of performance.
QuickSpecs
HP Compaq nc6140 Notebook PC
Overview
DA - 12375 North America — Version 6 — September 6, 2006 Page 3

Processors Intel Pentium M processor 760* (2.0-GHz, 533-MHz FSB, 2-MB L2 cache)
Intel Pentium M processor 750* (1.87-GHz, 533-MHz FSB, 2-MB L2 cache)
* Intel's numbering is not a measurement of higher performance.
NOTE: Intel Pentium M processors support enhanced Intel SpeedStep™ technology. Processor speed
denotes maximum performance mode; Intel Pentium M processors will run at approximately 800 MHz in
battery optimization mode.
Operating System Genuine Windows XP Professional SP2
Windows Vista Capable - Not all Windows Vista features are available for use on all Windows Vista Capable
PCs. All Windows Vista Capable PCs will run the core experiences of Windows Vista, such as innovations in
organizing and finding information, security, and reliability. Some features available in premium editions
of Windows Vista -- like the new Windows Aero™ user interface -- require advanced or additional
hardware.
Check http://www.windowsvista.com/getready for details.
NOTE: Microsoft Windows 2000 Professional is not available pre-installed, but drivers for it are
downloadable from http://www.hp.com .
Chipset Mobile Intel 915GM Express Chipset
Graphics Intel Graphics Media Accelerator 900 with up to 128-MB shared system memory
Display Internal 15.0-inch TFT XGA (1024 x 768 resolution and 16 M colors)
15.0-inch TFT SXGA+wva (1400 x 1050 resolution and 16 M colors)
External Up to 32-bit per pixel color depth
VGA port supports resolutions up to 2048 x 1536 at 75 Hz, and
lower resolutions at up to 100 Hz
DVI port in optional HP Docking Station (sold separately) supports
resolutions up to 1600 x 1200 at both full and reduced blanking,
and 1920 x 1200 at reduced blanking
NOTE: Resolutions are dependent upon monitor capability, and resolution and
color depth settings.
Memory Standard 512-MB or 1024-MB 333-MHz DDR SDRAM; two SODIMM slots
Maximum Upgradeable to 2048-MB maximum (1024-MB SODIMM in slots 1 and 2)
NOTE: Due to the non-industry standard nature of some third-party memory modules, we recommend HP
branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower
memory speed.
QuickSpecs
HP Compaq nc6140 Notebook PC
Standard Features
DA - 12375 North America — Version 6 — September 6, 2006 Page 4

Communications NetXtreme Gigabit Ethernet Controller (10/100/1000 NIC)*
56K modem** with digital line guard
* The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for
Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission,
connection to a Gigabit Ethernet server and network infrastructure is required.
** Designed for downloads from 56K modem compliant sources. Maximum achievable download
transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem availability is
subject to country regulatory approval.
Wireless Devices Integrated wireless WAN, integrated wireless LAN, and integrated Bluetooth are Standard features.
HP ev2200 1xEV-DO
Broadband Wireless
Module
Integrated dual band 800-MHz (cellular) and 1900-MHz (PCS) WWAN module
connects to the Verizon Wireless BroadbandAccess and NationalAccess
networks
Supports CDMA 1xEV-DO, 1xRTT connections
NOTE: Separately purchased Verizon Wireless service is required. For details,
go to http://www.hp.com/go/broadbandwireless .
Two 800/1900-MHz antennas integrated in the top of the display panel for
optimal reception
Intel PRO/Wireless
2915ABG 802.11 a/b/g
WLAN
Intel Centrino mobile technology
Integrated support for 802.11a, b and g
Up to 54-mbps data rate
Wi-Fi certified
Supports 64- and 128-bit WEP, WPA, WPA2,
hardware-accelerated AES, 802.1x authentication types
EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-MSCHAPv2, LEAP,
EAP-FAST
Support for Cisco Security Features -- proven compatibility with
Cisco Aironet infrastructure products through the Cisco
Compatible Extensions (version 3) Program
Dual antennas integrated in the display enclosure
Integrated Bluetooth Bluetooth Specification v2.0 compliant
Works with a wide range of Bluetooth devices
Keyboard The 101/102-key compatible keyboard features an industry standard, full-pitch key layout with desktop
keyboard features, such as the isolated inverted-T cursor control keys, editing keys, both left and right
control and alt keys, and 12 function keys. Other features include an integrated numeric keypad, hotkeys
for instant access to power conservation, brightness, and other features, 19-mm x 19-mm key pitch
(center-to-center spacing), 2.5-mm stroke, comfort-dished keycaps, and bright key legends for improved
visibility in low light conditions.
One-Touch Productivity
Buttons
Provide one-touch access to the following features: HP Info Center, Wireless On/Off, Presentation Mode,
Volume Up, Volume Down, and Volume Mute
QuickSpecs
HP Compaq nc6140 Notebook PC
Standard Features
DA - 12375 North America — Version 6 — September 6, 2006 Page 5

Pointing Device Touchpad with scroll zone, two soft-touch buttons
Expansion Card Slots
Two Type I/II PC Card
slots or one Type III PC
Card slot
Supports 32-bit CardBus and 16-bit PC Cards
Media Slots 6-in-1 Media Reader Supports SD (Secure Digital), MultiMediaCard, Memory Stick, Memory Stick
Pro, Smart Media, Picture card
CAUTION: This notebook PC does not support Memory Stick Duo Cards or
Memory Stick Duo Adapters. Inserting one of these cards or adapters into your
notebook can damage the memory card or adapter and/or the notebook PC.
Storage Hard Drives 40-, 60-GB 5400 rpm SMART
NOTE: These hard drives are customer removable and will withstand multiple insertion/removal cycles.
Optical Drives Integrated (12.7-mm) DVD/CD-RW Combo
DVD+/-RW with Double Layer Technology
Interfaces PC Card Slot (s) Two Type I/II or One Type III
External Monitor One – VGA
IEEE 1394 Port One
External Microphone One
Headphone/Line out One
Power Connector One
RJ-11 (Modem) One
RJ-45 (NIC) One
Fast Infrared Port One (4-Mb/s support)
IrDA 4-MB compliant; IR performance will vary depending on performance of
IR peripherals and application used.
Serial Port One
S-Video TV Out One (Support for NTSC/PAL)
Parallel Port One
USB 2.0 Four
Docking Connector One
Travel Battery Connector One
LED Status Indicators Thirteen
QuickSpecs
HP Compaq nc6140 Notebook PC
Standard Features
DA - 12375 North America — Version 6 — September 6, 2006 Page 6

Audio ADI AC '97 CODEC
Integrated 16-bit Sound Blaster Pro compatible audio
Integrated stereo speakers
External volume up, volume down, and mute buttons
Stereo headphone/line out
Stereo microphone in
Software Preinstalled Software for
Microsoft Windows XP
Verizon VZAccess Manager
HP Wireless Assistant
Bluetooth for Windows
Preloaded Software for
Microsoft Windows XP
Adobe Acrobat Reader
HP Local Recovery provided by Altiris*
HP Easy Access Buttons Software
HP Mobile Print Driver
Synaptics Touchpad Driver
HP Help and Support
HP ProtectTools Security Manager:
BIOS Configuration for HP ProtectTools
Credential Manager for HP ProtectTools
Sonic RecordNow! (for optional DVD+/-RW and DVD/CDRW drives)*
Symantec Norton Antivirus with complimentary 60-day live update
Intervideo WinDVD – DVD Player (for optional DVD+/-RW, DVD/CDRW and DVD
drives)*
Software on CD Intervideo WinDVD Creator – DVD Authoring (for optional DVD+/-RW drives)
Additional software
available from the Web
HP Client Manager Software
HP ProtectTools Security Manager:
Smart Card Security for HP ProtectTools
* Software is loaded on the hard drive and must be installed by running the Software Setup utility.
System Recovery for
Microsoft Windows XP
systems only
Each unit is shipped with a recovery kit containing Operating System Recovery and Driver/Application
Recovery discs. These discs allow users to either recover or repair the notebook operating system and
select drivers without losing personal data. The Operating System disc also provides the option of
reinstalling the operating system software provided with the notebook.
Client Management
Software
HP Client Manager Software (CMS) provides asset tracking, alerting, diagnostics, and SoftPaq distribution
for HP business desktops, notebooks, and workstations. HP CMS is the foundation for HP Client
Management Solutions. For more information and to download HP Client Manager Software, please refer
to the HP website at http://www.hp.com/go/easydeploy .
QuickSpecs
HP Compaq nc6140 Notebook PC
Standard Features
DA - 12375 North America — Version 6 — September 6, 2006 Page 7

HP Local Recovery
Provided by Altiris
Provides data and system file protection for HP business PCs to enable fast recovery of information that is
accidentally deleted or if the system becomes corrupted. Designed for disconnected or seldom-connected
users, Local Recovery protects your HP computer's data and system state by taking scheduled snapshots,
which are then stored in a protected area on the local hard disk. System backup and disaster recovery is
now simple and fast for all users, regardless of connectivity. For more information and to download,
please refer to the HP website at http://www.hp.com/go/easydeploy .
SMBIOS Version 2.3.4 System Management BIOS, previously known as DMI BIOS, is used to store system management
information.
HP ProtectTools Security
Manager
HP ProtectTools Security Manager is the security platform for business notebooks and desktops. The HP
ProtectTools Security Manager is an extensible client security console that delivers enhanced security
capabilities through add-on software modules. Modules currently available are:
- Smart Card Security for HP ProtectTools
- BIOS Configuration for HP ProtectTools
- Credential Manager for HP ProtectTools
Security Standard Features Configuration Control Hardware
Memory Change Alert
Ownership Tag
Setup Password
Power-On Password
Drivelock
Enabled for PC Smart Card options
Kensington Lock Slot
For more information on HP security solutions refer to http://www.hp.com/go/security .
Power Supply External 65-watt slim AC adapter, 6-foot (1.8-meter) power cord included.
Total length including External AC adapter is 12 feet (3.66 meter).
HP Fast Charge technology
Battery Primary Battery 6-cell high capacity Lithium-Ion (52Wh)
Optional Travel Battery 8-cell high capacity Lithium-Ion (52Wh)
QuickSpecs
HP Compaq nc6140 Notebook PC
Standard Features
DA - 12375 North America — Version 6 — September 6, 2006 Page 8

Battery Life Primary Battery Up to 4 hours and 30 minutes (preliminary)
Primary Battery and
optional HP Travel
Battery
Up to 10 hours (preliminary)
NOTE: Battery life will vary depending on the product configuration, product model, applications loaded
on the product, power management settings of the product, and the product features used by the
customer. As with all batteries, the maximum capacity of this battery will decrease with time and usage.
System Standby Time Up to 1 week
Power Conservation Supports enhanced Intel SpeedStep technology with Intel Pentium M processors (allows Battery Optimized
Mode, Maximum Performance Mode, or Automatic mode)
Intel Display Power Saving technology
Hibernation
Standby
ACPI compliance
Docking HP Basic Docking Station
HP Advanced Docking Station
HP Adjustable Notebook Stand
HP Monitor Stand
HP's shared docking solutions provide simple and convenient port replication and cable management.
Features include Gigabit NIC pass through, modem pass through, legacy parallel and serial ports, S-video
TV out, USB 2.0 ports, integrated security mechanism*, integrated MultiBay II and ExpressCard** slots.
These docking solutions are compatible across multiple Business Notebook platforms enabling a lower
total cost of ownership.
* HP/Kensington Cable Lock required (purchased separately)
** HP Advanced Docking Station only
Service and Support HP Services includes a three-year standard parts and labor warranty, pick-up or carry-in, and toll-free 7 x
24 hardware technical phone support (battery carries a one-year warranty). On-site service and warranty
upgrades are also available.
NOTE: Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details.
http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp .
Select Model(s)
QuickSpecs
HP Compaq nc6140 Notebook PC
Standard Features
DA - 12375 North America — Version 6 — September 6, 2006 Page 9

nc6140
EQ638AA#ABA
Smart Buy
Processor Intel Pentium M processor 750* (1.87-GHz, 533-MHz FSB, 2-MB L2 cache)
Operating System Genuine Windows XP Professional
System Memory 512-MB 333-MHz DDR SDRAM (512-MB SODIMM in slot 1)
Hard Drive 40-GB 5400 rpm
Display 15.0-inch TFT XGA with 1024 x 768 resolution (up to 16 M colors internal)
Graphics Intel Graphics Media Accelerator 900
Video Memory Up to 128 MB of shared video memory
Audio ADI AC '97 CODEC, Line out/headphone and microphone jacks
Optical Drive DVD/CD-RW Combo
Communications 56K Fax/Modem,
Integrated NetXtreme Ethernet Controller
(10/100/1000 NIC)
Integrated Wireless HP ev2200 1xEV-DO Broadband Wireless Module WWAN,
Intel PRO/Wireless 2915ABG 802.11 a/b/g WLAN,
Bluetooth
Pointing Device Touchpad with scroll zone
Battery 6-cell high capacity Lithium-Ion (52Wh)
Power External 65W adapter
Warranty** 3/3/0
nc6140
EQ639AA#ABA
Processor Intel Pentium M processor 760* (2.0-GHz, 533-MHz FSB, 2-MB L2 cache)
Operating System Genuine Windows XP Professional
System Memory 1024-MB 333-MHz DDR SDRAM (512-MB SODIMMs in slots 1 and 2)
Hard Drive 60-GB 5400 rpm
Display 15.0-inch TFT SXGA+wva (1400 x 1050 resolution and 16 M colors)
Graphics Intel Graphics Media Accelerator 900
Video Memory Up to 128 MB of shared video memory
Audio ADI AC '97 CODEC, Line out/headphone and microphone jacks
Optical Drive DVD+/-RW with Double Layer Technology
Communications 56K Fax/Modem,
Integrated NetXtreme Ethernet Controller
(10/100/1000 NIC)
Integrated Wireless HP ev2200 1xEV-DO Broadband Wireless Module WWAN,
Intel PRO/Wireless 2915ABG 802.11 a/b/g WLAN,
Bluetooth
Pointing Device Touchpad with scroll zone
Battery 6-cell high capacity Lithium-Ion (52Wh)
Power External 65W adapter
Warranty** 3/3/0
* Intel's numbering is not a measurement of higher performance.
** Certain restrictions and exclusions apply.
QuickSpecs
HP Compaq nc6140 Notebook PC
Standard Features
DA - 12375 North America — Version 6 — September 6, 2006 Page 10

Memory 256-MB 333-MHz DDR SDRAM DC389B
512-MB 333-MHz DDR SDRAM PA525A
1024-MB 333-MHz DDR SDRAM DC890B
Storage 60-GB 5400 rpm Primary Hard Drive PA852A
80-GB 5400 rpm Primary Hard Drive EH424AA
USB Diskette Drive DC361B
HP USB Digital Drive + 256-MB Secure Digital Card DL702AA
HP 40-GB Mobile USB Hard Drive DQ549A
MultiBay II Storage
(9.5-mm)
NOTE: Requires HP
External MultiBay II or HP
Advanced Docking Station
8X DVD-ROM MultiBay II Drive PA849A
24X Combo DVD/CD-RW MultiBay II Drive PA850A
2X DVD+/-RW Dual Format MultiBay II Drive PA851A
80-GB 5400 rpm MultiBay II Hard Drive PH357A
Communications Intel PRO/Wireless 2200BG 802.11b/g wLAN Option Kit PF952AA#ABA
Intel PRO/Wireless 2915ABG 802.11a/b/g wLAN Option Kit PN302AA#ABA
Expansion Solutions HP Basic Docking Station PA286A#ABA
HP Advanced Docking Station PA287A#ABA
HP 3-in-1 NAS Docking Station EM537AA#ABA
HP External MultiBay II PA509A#ABA
HP Monitor Stand PA507A
HP Adjustable Notebook Stand PA508A
HP 4-port USB 2.0 Hub DG954A
Power
NOTE: HP Battery Charging
Stations require use of
Battery Adapter Kit.
HP 2-bay Battery Charging Station DT533A#ABA
HP 10-bay Battery Charging Station DT534A#ABA
Battery Adapter kit #1 PK402A
65W AC Adapter DC359A#ABA
90W AC Adapter DC895B#ABA
90W Auto Adapter DC303B
90W Air/Auto/AC Combo Adapter DV574A#ABA
90W Aircraft Cables DC899A
Primary 6-cell Battery Pack PB994A
HP Common Travel Battery PB993A
QuickSpecs
HP Compaq nc6140 Notebook PC
Options
DA - 12375 North America — Version 6 — September 6, 2006 Page 11

Carrying Cases HP Entry Value Case DL617A
HP Top Load Nylon DC915A
HP Executive Leather case PA847A
HP Sport Backpack DG102A
Security PC Card Smart Card Reader DC350B
HP/Kensington Cable Lock PC766A
Input/Output Devices USB/PS2 Keyboard DC852A#ABA
USB/PS2 Optical Mouse DC369A
HP USB Optical Travel Mouse F2100A
QuickSpecs
HP Compaq nc6140 Notebook PC
Options
DA - 12375 North America — Version 6 — September 6, 2006 Page 12

Up to 2048 MB of 333-MHz DDR SDRAM
Two DIMM slots (user accessible – one under keyboard deck, one via panel on bottom of unit)
DIMM sizes supported: 256 MB, 512 MB, or 1024 MB
Standard Memory 512 MB (512 MB x 1)
1024 MB (512 MB x 2)
Optional Memory
Upgrades
Support for up to 2048 MB of memory is available (with the installation of optional DDR SDRAM memory
kits). Both memory slots are user accessible. Please refer to the Hardware and Software Guide for
installation procedures.
Up to Slot 1 Slot 2
768 MB 512 MB 256 MB
1024 MB 1024 MB Empty
1024 MB 512 MB 512 MB
1280 MB 1024 MB 256 MB
1536 MB 1024 MB 512 MB
2048 MB 1024 MB 1024 MB
NOTE: This chart does not represent all possible memory configurations. Due to the non-industry standard
nature of some third-party memory modules, we strongly recommend using only HP branded memory
modules to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory
speed.
Memory Upgrades 1024-MB 333-MHz DDR SDRAM DC890B
512-MB 333-MHz DDR SDRAM PA525A
256-MB 333-MHz DDR SDRAM DC389B
QuickSpecs
HP Compaq nc6140 Notebook PC
Memory
DA - 12375 North America — Version 6 — September 6, 2006 Page 13

Removable Media Drive Support
Quantity Supported Drive Bay
DVD+/-RW Drive with Double Layer
Technology
One Fixed optical drive bay
DVD/CD-RW Combo Drive One Fixed optical drive bay
Hard Drive Support
Quantity Supported Drive Bay
60-GB 5400 rpm SMART Hard Drive One Dedicated hard drive bay
40-GB 5400 rpm SMART Hard Drive One Dedicated hard drive bay
QuickSpecs
HP Compaq nc6140 Notebook PC
Storage
DA - 12375 North America — Version 6 — September 6, 2006 Page 14

System Unit Dimensions (HxWxD) 1.2 in (at front) x 12.9 in x 10.8 in
30.3 mm (at front) x 328.6 mm x 274.3 mm
Weight 6.06 lb (2.75 kg)
NOTE: Height varies depending upon where on the notebook the measurement is made. Weight varies by
configuration and components. Weight includes 6-cell battery, 40-GB hard drive, 512-MB memory, and
DVD/CD-RW Combo drive. Weight varies by configuration and components.
Stand-Alone Power
Requirements
Nominal Operating Voltage 18.5 V
Average Operating Power 21 W
Max Operating Power < 65 W
Temperature Operating 32° to 95° F (0° to 35° C) (not writing optical)
41° to 95° F (5° to 35° C) (writing optical)
Non-operating -4° to 140° F (-20° to 60° C)
Relative Humidity Operating 10% to 90% relative humidity, non-condensing
Non-operating 5% to 95%, 101.6° F (38.7° C) maximum wet bulb
temperature
Shock Operating 125 G, 2 ms, half-sine
Non-operating 200G, 2 ms, half-sine
Random Vibration Operating 0.75 grms
Non-operating 1.50 grms
Altitude
(unpressurized)
Operating -50 to 10,000 ft (-15.24 to 3,048 m)
Non-operating -50 to 40,000 ft (-15.24 to 12,192 m)
Industry Standard
Certifications
Blue Angel No
UL Yes
Energy Star Yes
Canadian Safety Yes
CSA (Canada) Yes
ICES Yes
TUV GS No
Nordic Safety No
Mexican Safety Yes
Poland Compliance Yes
Australia / NZ Compliance Yes
CCC Yes
Japan Compliance Yes
MIC Yes
BSMI Yes
CE Marking Compliance Yes
KONCAR Yes
GOST Yes
SASO Yes
SABS Yes
QuickSpecs
HP Compaq nc6140 Notebook PC
Technical Specifications
DA - 12375 North America — Version 6 — September 6, 2006 Page 15

UKRSERTCOMPUTER Yes
65W External AC Adapter Weight 0.62 lb (0.28 kg) (adapter)
0.29 lb (0.13 kg) (power cord)
Dimensions 4.17 x 1.85 x 1.1 in (10.6 x 4.7 x 2.8 cm)
Input Operating Input Voltage 100 to 240 VAC
Operating Input Current 1.7A at 90 VAC
0.85A at 180 VAC
Operating Frequency
Range
47 to 63 Hz AC
Efficiency 83% minimum at 115 VAC
Output Output Power 65 W
DC Output Current 18.5 V
Environmental Operating Temperature 32° to 104° F (0° to 40° C)
Non-operating (storage)
Temperature
-4° to 149° F (-20° to 65° C)
Altitude 0 to 10,000 ft (0 to 3,048 m)
Humidity 20% to 80%
Storage Humidity 10% to 90%
EMI and Safety
Certifications
CE Mark: full compliance with LVD and EMC directives
Worldwide safety standards: IEC950, EN60950, UL1950, Class2, SELV Agency
approvals: C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22
Class B, CCIB, NOM-1 NYCE
MTBF Over 200,000 hours at 25°C ambient condition
52Wh Primary 6-Cell
Battery
Dimensions (H x W x L) 0.8 x 2.1 x 8.0 in (2.0 x 5.3 x 20.3 cm)
Weight 0.737 lb (0.335 kg)
Cells/Type 6-cell Lithium-Ion
Energy Voltage 10.8V
Watt-hour Capacity 52Wh
Amp-hour Capacity 4.8Ah
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 140° F (–10° to 60° C)
Non-operating –4° to 140° F (–20° to 60° C)
Battery Re-Charge Time System in OFF Mode or
Standby
2.5 hours
System ON 3 to 5 hours (depending on system power
consumption)
HP Fast Charge Technology Charges the battery up to 90% within 1.5 hours
when system is OFF
QuickSpecs
HP Compaq nc6140 Notebook PC
Technical Specifications
DA - 12375 North America — Version 6 — September 6, 2006 Page 16

Optional HP 8-Cell
Extended Life Battery
Dimensions (H x W x L) 1.0 x 3.9 x 8.7 in (2.5 x 10.0 x 22.0 cm)
Weight 1.00 lb (0.455 kg)
Cells/Type 8-cell Lithium-Ion
Energy Voltage 14.4V
Watt-hour Capacity 52Wh
Amp-hour Capacity 3.6Ah
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 140° F (–10° to 60° C)
Non-operating –4° to 140° F (–20° to 60° C)
Battery Re-Charge Time System in OFF mode or
Standby
3 hours
System ON 3 to 5 hours (depending on system power
consumption)
HP Fast Charge Technology Charges the battery up to 90% within 90 minutes
when system is OFF
Fuel Gauge When pressed, LEDs light indicating level of charge remaining on battery
15.0-Inch Color TFT
XGA Display
Active Area (W x H) 12.0 x 9.0 in (30.4 x 22.8 cm)
Diagonal Size 15.0 in (38.0 cm)
Surface Treatment Anti-glare
Number of Colors Up to 16M
Contrast Ratio 300:1 (typical)
Refresh Rate 60 Hz
Brightness 150 nit (typical)
Pixel Resolution Pitch 0.296 mm
Format 1024 x 768
Configuration RGB Stripe
Backlight CCFL
PPI 86
Viewing Angle ±45° Horizontal, ±25° Vertical (typical)
QuickSpecs
HP Compaq nc6140 Notebook PC
Technical Specifications
DA - 12375 North America — Version 6 — September 6, 2006 Page 17

15.0-Inch Color TFT
SXGA+wva Display
Active Area (W x H) 12.0 x 9.0 in (30.4 x 22.8 cm)
Diagonal Size 15.0 in (38.0 cm)
Surface Treatment Anti-glare
Number of Colors Up to 16 M
Contrast Ratio 300:1 (typical)
Refresh Rate 60 Hz
Brightness 180 nit (typical)
Pixel Resolution Pitch 0.217 mm
Format 1400 x 1050
Configuration RGB Stripe
Backlight CCFL
PPI 116
Character Display 80 x 25
Total Power Consumption 5.8 W
Viewing Angle ±60° Horizontal, ±50° Vertical (typical)
Hard Drives
60-GB 5400 rpm Drive Weight 0.22 lb (101 g)
Capacity 60 GB
Height 0.37 in (9.5 mm)
Width 2.75 in (70 mm)
Interface ATA-7
Transfer Rate Synchronous (maximum) 100 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track 3 ms
Average 13 ms
Maximum 24 ms
Rotational Speed 5400 rpm
Logical Blocks 117,210,240
Operating Temperature 41° to 131° F (5° to 55° C)
Features ATA Security
QuickSpecs
HP Compaq nc6140 Notebook PC
Technical Specifications
DA - 12375 North America — Version 6 — September 6, 2006 Page 18

40-GB 5400 rpm Drive Weight 0.22 lb (101 g)
Capacity 40 GB
Height 0.37 in (9.5 mm)
Width 2.75 in (70 mm)
Interface ATA-7
Transfer Rate Synchronous (maximum) 100 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track 3 ms
Average 13 ms
Maximum 24 ms
Rotational Speed 5400 rpm
Logical Blocks 78,140,160
Operating Temperature 41° to 131° F (5° to 55° C)
Features ATA Security
Removable Storage Drives – Fixed Bay
DVD/CD-RW Combo Drive Access Times Random <110 ms CD
<130 ms DVD
Max Data Transfer Rate 24X CD-ROM 3,600 KB/s
8X DVD 10,800 KB/s
24X CD-R 3,600 KB/s
24X CD-RW 3,600 KB/s
Transfer Mode Multiword DMA Mode 2
Interface EIDE
Supported Media (read) CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED MODE CD,
CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD (Photo-CD, CD-EXTRA,
Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10,
DVD-18), DVD-R, DVD-RW, DVD+R, DVD+RW
Supported Media (write) CD-R, CD-RW
Max Media Capacity (read) 4.7 GB
Max Media Capacity
(write)
700 MB
Transport Tray loading
QuickSpecs
HP Compaq nc6140 Notebook PC
Technical Specifications
DA - 12375 North America — Version 6 — September 6, 2006 Page 19

DVD+/-RW SuperMulti
with Double Layer
MultiBay II Drive
Dimensions 0.37 x 5.51 x 5.04 in (0.95 x 14.0 x 12.8 cm)
Weight 0.45 lb (205 g)
Access Times Random <150 ms CD
<125 ms DVD
Max Data Transfer Rate 24X CD-ROM 3,600 KB/s
8X DVD 10,800 KB/s
24X CD-R 3,600 KB/s
10X CD-RW 1,500 KB/s
4X DVD+R 5,400 KB/s
2.4X DVD+RW 3,240 KB/s
4X DVD-R 5,400 KB/s
2X DVD-RW 2,700 KB/s
2X DVD-RAM 2,700 KB/s
Transfer Mode Multiword DMA Mode 2
Interface EIDE
Supported Media (read) CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED MODE CD,
CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD (Photo-CD, CD-EXTRA,
Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10,
DVD-18), DVD-R, DVD-RW, DVD+R, DVD+RW
Supported Media (write) CD-R, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RW
Max Media Capacity (read) 8.5 GB
Max Media Capacity
(write)
4.7 GB
Transport Tray Loading
Audio
Hardware Implementation ADI AC ‘97 CODEC
Volume Controls Up, down, and mute buttons
Full Duplex Yes
Sound Blaster Pro
compatible
Yes
Microphone Jack Stereo or mono
Headphone/Line Out Jack Stereo
QuickSpecs
HP Compaq nc6140 Notebook PC
Technical Specifications
DA - 12375 North America — Version 6 — September 6, 2006 Page 20
