HP Pavilion dv4000 - notebook pc Quick setup guide

15.4 inch display
Quick launch buttons
Power button
Wireless on/off buttons
Volume Control buttons
isplay Switch
Touchpad
Touchpad scroll zone
Right touchpad buttonLeft touchpad button
©2005 Hewlett-Packard evelopment Company, L.P. All rights reserved. Intel, Pentium, Intel Inside, and the Intel Inside logo are trademarks
or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Microsoft, Windows, and the
Windows Logo are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries.
Printed in Singapore Rev 1, M08/2005
P/N: 5983-0928EEP
Intel® Centrino™ Mobile Technology
Intel® Pentium® M processor 725A* - 1.6GHz, 2MB L2 cache, 400MHz Front Side Bus (FSB)
Intel® Pentium® M processor 740* - 1.73GHz, 2MB L2 cache, 533MHz Front Side Bus (FSB)
Intel® Pentium® M processor 750* - 1.86GHz, 2MB L2 cache, 533MHz Front Side Bus (FSB)
Intel® Pentium® M processor 760* - 2.0GHz, 2MB L2 cache, 533MHz Front Side Bus (FSB)
Microsoft® Windows® XP Home edition
Also available:
Intel® Celeron® M processor 360* - 1.4GHz, 1MB L2 cache, 400MHz Front Side Bus (FSB)
Intel® Celeron® M processor 370* - 1.5GHz, 1MB L2 cache, 400MHz Front Side Bus (FSB)
Intel® Celeron® M processor 380* - 1.6GHz, 1MB L2 cache, 400MHz Front Side Bus (FSB)
* Intel's numbering is not a measurement of higher performance
Intel® 915 GM:
Intel® Graphics Media Accelerator 900, up to 64MB shared with less than 512MB system memory or up to 128MB
shared with equal or more than 512MB system memory
Intel® 915 PM:
ATI Mobility™ Radeon® X700 with 128MB video memory
15.4" WXGA; 15.4" WXGA with BrightView
2 SO IMM slots, 533MHz R 2, 256MB up to 2GB
40, 60, 80, 100GB - 4200rpm
V /C -RW combo
V ±RW/R and C -RW combo ouble layer support
V ±RW/R and C -RW Combo ouble Layer with LightScribe
High speed 56K modem, integrated 10/100 LAN, Intel® Pro/Wireless 2200 802.11b/g, Bluetooth® (selected models)
1 Type I/II PC card slots, 16-bit PCMCIA and 32-bit Cardbus, ExpressCard /54 slot, Integrated 6-in-1 digital memory
reader slot (x , S , MMC, Memory Stick, Memory Stick PRO, and Smart Media)
VGA, USB 2.0(4), IEEE1394, RJ-11, RJ-45, headphone (1), microphone jack (1), AC adaptor, S-video out, Kensington
lock, Expansion port for HP Notebook Expansion Base xb2000, integrated HP mobile remote control
HP xc2000 All-in-One Media Cable
( ocking cable, AC power jack, USB 2.0 port, S-Video jack, S/P IF, RCA jack, Analog line out)
6-cell Li-ion, 12-cell Li-ion
65W AC adapter (3-wire plug), 90W
Adobe® Acrobat® Reader, HP ImageZone Plus, HP QuickPlay, InterVideo Home Theatre, InterVideo Win V Player,
iTunes Player, Microsoft® Encarta (available for AUNZ only), Microsoft® Money (available for AP, AUNZ and Thai
only), Microsoft® Windows® Media Player, Microsoft® Works (available for AP, AUNZ and Thai only), Muvee
AutoProducer, Sonic igital Media Plus, Symantec™ Norton AntiVirus™ , Sun Java™
2.95kg (6.5lbs) with 6-cell battery
35.85 x 25.78 x 3.35cm (14.1 x 10.1 x 1.3in)
+may vary depending on configuration.
HP Pavilion dv4000 Notebook PC HP Pavilion dv4000 Notebook PC
HP recommends Microsoft® Windows® XP Professional
Wireless LE
(if configured)
Vent
Optical drive
S-Video jack
LE Badge &
Consumer IR
Speakers
isplay release button
VGA monitor port
Security
cable slot
Additional
USB 2.0 ports
Microphone
jack
Headphone
jack ExpressCard slot
USB 2.0 port
Type I/II PC card slot
RJ-45
Network jack
IEEE 1394
igital video port
AC power input
ExpressCard slot
6-in1
igital Memory
Reader slot
RJ-11 Phone jack
Take a trip to the theatre
without leaving home
HP Pavilion dv4000
Notebook PC
Rear view
Front view
Right view Left view
Processor
Chipset/Graphics
Display Panel
Standard Memory
Hard Drive
Optical Drive
Networking/Wireless
External Card Expansion
I/O Ports
Optional Accessory
Battery
Power
Software
Approximate Weight +
Dimensions (LxWxH) +

Wider
and
smarter
Brighter
and
richer
See more details on
15.4” Widescreen
Why should you miss anything? Be smart and take in every detail
of the movie with a wide format LC display. And enjoy exceptionally
bright and colour-enhanced images with BrightView technology.
BrightView
Without BrightView
Ease into your favourite couch
and thrill your senses
like never before.
Everything about the Pavilion dv4000 notebook is designed to give you
and your family the ultimate digital entertainment experience. Starting
with its smart 15.4" Widescreen display with BrightView technology that
actually lets you see more, and do more. So you'll not only catch all the
details of the latest V movies produced in wide screen format, but
enjoy them in brighter, sharper clarity.
And thanks to the innovative HP QuickPlay, loading a new sound track
or V movie only takes a mere 15 seconds without the need for
a standard boot up! Together with built-in speakers, your living room will
reverberate with true-to-life sounds with true-to-life picture quality that
gives your whole family a 'live' theatre experience like no other.
There's a smarter way to catch the latest movie
blockbuster in town or that 'live' orchestra you've
been yearning to attend - just stay at home with
the whole family. Because the best seats in the
theatre are found in your living room! The HP
Pavilion dv4000 notebook PC is set to transform
your home into a 'live' digital theatre haven that
resonates with crystal clear sounds and stunning
visual quality. You'll feel like you're in the theatre.
Except that you own it.
HP Pavilion dv4000 Notebook PC
A view to inspire!
Because most movies are produced in wide screen format, you'll enjoy
them the way the filmakers meant them to be with a 15.4" Widescreen,
colourfully-enhanced with BrightView technology. You can also afford
the luxury of space to display two multimedia applications like your photo
album and music side by side to bring out a complete digital experience
like no other.
Ready in 15 seconds!
HP QuickPlay loads your favourite V or music C in seconds without
the need for a standard boot up. Saves you time, and saves you precious
power. You'll also save yourself the hassle of getting out of your couch
with an integrated remote that puts total digital entertainment at your
fingertips.
Ultimate viewing experience!
Giving you the best-in-class user experience, the integrated ATI Mobility™
Radeon® X700 is the perfect platform to view all your intensive
communications applications, or even the latest 3 action games. Be
immersed in the ultimate viewing experience!
Real music to your ears!
Even the most discerning audiophiles will be impressed by the amazing
theatre quality that the built-in Altec Lansing speakers generate. Listen to
every single beat with complete clarity, and elevate your senses to greater
heights of enjoyment.
Transfer to the future!
The HP Pavilion dv4000 comes with the latest ExpressCard to support
the future of wireless networking, storage and security features. Not only
is it smaller and sleeker, it gives you a faster transfer rate of up to 5000MB/s
in a package up to 40% smaller.
Thanks for the memory!
The hot-swappable, built-in 6-in-1 digital memory reader lets you share
digital photos, movies and music between a wide range of memory cards,
from Secure igital, MultiMedia, Memory Stick, MS-Pro Memory Stick
to SmartMedia memory cards. Plenty of great memories with one digital
memory reader!
Multiple connections,
one powerful cable
From now on, the smart HP All-in-One
Media Cable is all you need to connect your
notebook to various home entertainment systems
effortlessly. Play music on your stereo system
and PC speakers, enjoy true-to-life digital albums
on your plasma TV, connect to your VCR,
A/V receiver or olby igital decoder to watch
the latest movies, and any USB-enabled devices
for a complete digital experience!
(Selected countries only)
