HP ProBook 6450b Notebook PC
1. WWAN antennas (select models) 15. Hard drive activity / HP 3D DriveGuard LED indicator
2. Dual-microphone array with optional webcam only* 16. Battery charging LED indicator
3. WLAN antennas 17. Power/standby LED indicator
4. Webcam LED indicator 18. Wireless on/off LED indicator
5. Optional 2 MP webcam 19. Stereo headphone/line out
6. Volume mute button with LED indicator 20. Stereo microphone/line in
7. Volume down button with LED indicator 21. ExpressCard/54 slot or optional Smart Card Reader
8. Volume up button with LED indicator 22. eSATA/USB combo port
9. Optional pointstick 23. (2) USB 2.0 port
10. Pointstick pick buttons (with optional pointstick) 24. DisplayPort
11. Optional HP Fingerprint Sensor 25. Power button with LED indicator
12. Stereo speakers 26. QuickLook button
13. Touchpad with scroll zone 27. QuickWeb button
14. Touchpad pick buttons 28. Wireless on/off button with LED indicator
* Models without webcam have single integrated microphone on left side of display panel.
QuickSpecs
HP ProBook 6450b Notebook PC
HP ProBook 6550b Notebook PC
Overview
DA - 13616 Canada — Version 17 — February 15, 2012 Page 1

1. Upgrade Bay (optical drive or second hard drive) 6. Lock slot
2. (1) USB 2.0 port 7. RJ-45/Ethernet port
3. Media Card Reader 8. VGA/external monitor connector
4. 1394a port 9. Power connector
5. RJ-11/modem port
1. Battery bay 6. Vents
2. SIM slot for WWAN (select models) – inside battery bay 7. Hard drive bay
3. Battery release latch 8. Memory module compartment
4. Docking connector 9. WLAN/WWAN module compartment (select models)
5. Secondary battery connector 10. Bluetooth module compartment
QuickSpecs
HP ProBook 6450b Notebook PC
HP ProBook 6550b Notebook PC
Overview
DA - 13616 Canada — Version 17 — February 15, 2012 Page 2

HP ProBook 6550b Notebook PC
1. WWAN antennas (select models) 16. Touchpad pick buttons
2. Dual-microphone array with optional webcam only * 17. Hard drive activity / HP 3D DriveGuard LED indicator
3. WLAN antennas 18. Battery charging LED indicator
4. Webcam LED indicator 19. Power/standby LED indicator
5. Optional 2 MP webcam 20. Wireless on/off LED indicator
6. Volume mute button with LED indicator 21. Stereo headphone/line out
7. Volume down button with LED indicator 22. Stereo microphone/line in
8. Volume up button with LED indicator 23. ExpressCard/54 slot or optional Smart Card Reader
9. Calculator button 24. eSATA/USB 2.0 combo port
10. Separate numeric keypad 25. (2) USB 2.0 ports
11. Optional pointstick 26. DisplayPort
12. Pointstick pick buttons (with optional pointstick) 27. Power button with LED indicator
13. Optional HP Fingerprint Sensor 28. QuickLook button
14. Stereo speakers 29. QuickWeb button
15. Touchpad with scroll zone 30. Wireless on/off button with LED indicator
* Models without webcam have single integrated microphone on left side of display panel.
QuickSpecs
HP ProBook 6450b Notebook PC
HP ProBook 6550b Notebook PC
Overview
DA - 13616 Canada — Version 17 — February 15, 2012 Page 3

1. Upgrade Bay (optical drive or second hard drive) 6. Lock slot
2. (1) USB 2.0 port 7. RJ-11/modem port
3. Media Card Reader 8. RJ-45/Ethernet port
4. 1394a port 9. VGA/external monitor connector
5. Serial port 10. Power connector
1. Battery bay 6. Vents
2. SIM slot for WWAN (select models) – inside battery bay 7. Hard drive bay
3. Battery release latch 8. Memory module compartment
4. Docking connector 9. WLAN/WWAN module compartment (select models)
5. Secondary battery connector 10. Bluetooth module compartment
QuickSpecs
HP ProBook 6450b Notebook PC
HP ProBook 6550b Notebook PC
Overview
DA - 13616 Canada — Version 17 — February 15, 2012 Page 4

At A Glance
Genuine Windows 7 versions or FreeDOS
New Intel vPro Technology for remote manageability
Choice of Intel® Core™ i7, Core i5, or Core i3 processor
ATI Mobility Radeon HD 540v discrete graphics with 512 MB dedicated video memory
or integrated Intel HD Graphics
Widescreen LED-backlit HD or HD+ display
HP ProBook 6450b: 14.0-inch diagonal; HD anti-glare
HP ProBook 6550b: 15.6-inch diagonal; HD anti-glare or HD+ anti-glare
Starting at 5.0 lb/2.26 kg (6450b) or 5.5 lb/2.51 kg (6550b)
Flexible wireless connectivity options:
Integrated HP un2420 EV-DO/HSPA Mobile Broadband Module provides worldwide Gobi mobile Internet technology with
GPS
Integrated Intel Centrino® 802.11 a/b/g/n or b/g/n; Broadcom 802.11 a/b/g/n wireless LAN module
Bluetooth® v2.1+EDR
Touchpad with scroll zone; optional pointstick
Full-sized spill-resistant keyboard with drains; full separate numeric keypad on the HP ProBook 6550b
Touch-sensitive controls for HP QuickLook 3, HP QuickWeb, wireless on/off, mute, volume down, volume up; calculator button
on HP ProBook 6550b
Choice of 9-cell (93 WHr) or 6-cell (55 WHr & 47 WHr) primary battery, or 6-cell (51 WHr) HP Long Life Battery
3-cell (47 WHr) HP Long Life Battery available as after-market option
Optional external batteries: HP Ultra-Capacity Battery, HP Extended Life Battery
Optional integrated 2 MP Webcam with dual-microphone array
Choice of 7200 rpm user-removable hard drive up to 320 GB with HP 3D DriveGuard protection,
or 128 GB Solid State Drive
Upgrade Bay for optical drive
Media Card Reader
New eSATA/USB 2.0 combo port
Reliability with HP 3D DriveGuard, magnesium alloy support structure, HP DuraFinish, and the spill-resistant keyboard with
drains
Security features including HP ProtectTools with Central Management, Computrace LoJack Pro ready, HP SpareKey, HP Disk
Sanitizer, TPM 1.2; * optional Smart Card Reader (replaces ExpressCard slot), optional HP Fingerprint Sensor, and optional HP
Privacy Filter
HP Power Assistant allows you to conserve power, stretch battery run-time, accurately monitor your reported power need, and
report workforce power consumption.
HP QuickLook 3 for instant access to e-mail, calendar, and contacts; HP QuickWeb for fast access to the web
HP DayStarter displays your calendar and battery charge while Windows starts up
HP Support Assistant helps maintain your PC performance and resolve problems with automated updates and tune-ups,
onboard diagnostics, and guided assistance.
Options include HP Advanced Docking Station, HP Docking Station, HP USB 2.0 Docking Station, and HP Essential USB 2.0 Port
Replicator
BFR/PVC-free ** , ENERGY STAR qualified and EPEAT Gold registered in the U.S. EPEAT status varies by country- please see
epeat.net .
* TPM module disabled where not permitted by law (for example, Russia and China).
** This notebook is brominated flame retardant and polyvinyl chloride-free (BFR/PVC-free) on notebooks that are non-WWAN; meeting
the evolving definition of 'BFR/PVC-free' as set forth in the "iNEMI Position Statement on the 'Definition of Low-Halogen' Electronics
(BFR/CFR/PVC-Free)'". Plastic parts contain < 1000 ppm (0.1%) of bromine [if the Br source is from BFRs] and < 1000 ppm (0.1%) of
chlorine [if the Cl source is from CFRs or PVC or PVC copolymers]. Power supply and power cords are not BFR/PVC-free. Service parts
QuickSpecs
HP ProBook 6450b Notebook PC
HP ProBook 6550b Notebook PC
Overview
DA - 13616 Canada — Version 17 — February 15, 2012 Page 5

after purchase may not be BFR/PVC-free.
QuickSpecs
HP ProBook 6450b Notebook PC
HP ProBook 6550b Notebook PC
Overview
DA - 13616 Canada — Version 17 — February 15, 2012 Page 6

Processors Intel Dual-Core Processors
Intel Core i7-620M Processor (2.66 GHz, 35W, 4 MB L3 cache) *
Up to 3.33 GHz with Intel Turbo Boost Technology
Intel Core i5-540M Processor (2.53 GHz, 35W, 3 MB L3 cache) *
Up to 3.06 GHz with Intel Turbo Boost Technology
Intel Core i5-520M Processor (2.40 GHz, 35W, 3 MB L3 cache) *
Up to 2.93 GHz with Intel Turbo Boost Technology
Intel Core i3-350M Processor (2.26 GHz, 35W, 3 MB L3 cache) *
* Intel's numbering is not a measurement of higher performance.
NOTE: Processor speed denotes maximum performance mode; processors will run at lower speeds in
battery optimization mode.
Operating System Preinstalled Genuine Windows 7 Professional Edition 32 *
Genuine Windows 7 Professional Edition 64*
FreeDOS
Supported Genuine Windows 7 Enterprise 32 *
Genuine Windows 7 Enterprise 64 *
Genuine Windows 7 Ultimate 32 *
Genuine Windows 7 Ultimate 64 *
Genuine Windows Vista Enterprise 32 **
Genuine Windows Vista Enterprise 64 **
Certified SuSE Linux Enterprise Desktop 11
* System may require upgraded and/or separately purchased hardware and/or a DVD drive to install the
Windows 7 software and take full advantage of Windows 7 functionality. See
http://www.microsoft.com/windows/windows-7/ for details.
** Certain Windows Vista product features require advanced or additional hardware. See:
http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx and
http://www.microsoft.com/windowsvista/getready/capable.mspx for details. Windows Vista Upgrade
Advisor can help you determine which features of Windows Vista will run on your computer. To download
the tool, visit: http://www.windowsvista.com/upgradeadvisor .
Chipset Mobile Intel QM57 Express Chipset (vPro configurations)
Mobile Intel HM57 Express Chipset (non vPro configurations)
QuickSpecs
HP ProBook 6450b Notebook PC
HP ProBook 6550b Notebook PC
Standard Features (availability may vary by country)
DA - 13616 Canada — Version 17 — February 15, 2012 Page 7

Intel Core i5 with
vPro/Core i7 with vPro
technology capable
Intel Core i5 with vPro and Core i7 with vPro technology is a selectable feature that is available on units
configured with an Intel Centrino® Advanced-N 6200 WLAN module and a preinstalled Windows operating
system. It provides advances in remote manageability, security, energy efficient performance, and
wireless connectivity. Intel Active Management Technology 6.0 (iAMT) offers built-in manageability and
proactive security for networked notebook PCs, even when they are powered off* or when the operating
system is inoperable. It can help identify threats before they reach the network, isolate infected systems,
and update PCs regardless of their power state.
*Requires a Windows operating system, network hardware and software, connection with a power source,
and a direct (non-VPN) corporate network connection which is either cable or wireless LAN.
NOTE: Some functionality of Intel Core i5 with vPro/Core i7 with vPro technology, such as Intel Active
Management technology and Intel Virtualization technology, requires additional 3rd party software in
order to run. Availability of future "virtual appliances" applications for Intel Core i5 with vPro/Core i7 with
vPro technology is dependent on 3rd party software providers. Compatibility with future "virtual
appliances" is yet to be determined.
Graphics Models with discrete graphics:
ATI Mobility Radeon™ HD 540v with 512 MB dedicated video memory
Microsoft DirectX 10.1 (Shader Model 4.1) and OpenGL 2.1 capable
Models with integrated graphics:
Intel HD Graphics
Microsoft DirectX 10 (Shader Model 4.0) and OpenGL 2.0 capable
Display Internal HP ProBook 6450b:
14.0-inch diagonal LED-backlit HD anti-glare (1366 x 768 resolution)
HP ProBook 6550b:
15.6-inch diagonal LED-backlit HD anti-glare (1366 x 768 resolution)
15.6-inch diagonal LED-backlit HD+ WVA anti-glare (1600 x 900 resolution)
HP Privacy Filter support
External Up to 32-bit per pixel color depth
DisplayPort supports resolutions up to 2560 x 1600, 30-bit color depth at 60
Hz, and full HD (1920 x 1080) monitors, 24-bit color depth at 120 Hz
VGA port supports resolutions up to 2048 x 1536 at 75 Hz, and lower
resolutions at up to 100 Hz
DVI-D (single link) video signal available through DVI port in optional HP
Docking Station (sold separately)
supports resolutions up to 1600 x 1200 at both full and reduced
blanking, and 1920 x 1200 at reduced blanking
NOTE: Resolutions are dependent upon monitor capability, and resolution and
color depth settings.
QuickSpecs
HP ProBook 6450b Notebook PC
HP ProBook 6550b Notebook PC
Standard Features (availability may vary by country)
DA - 13616 Canada — Version 17 — February 15, 2012 Page 8

Memory Standard DDR3 PC3-10600 SDRAM (1333 MHz) *
Two SODIMM slots supporting dual-channel memory
1024 MB, 2048 MB and 4096 MB SODIMMs
Maximum Upgradeable to 8192 MB with 4096 MB SODIMMs in slots 1 and 2
Dual-channel Maximized dual-channel performance requires SODIMMs of the same size and
speed in both memory slots.
* Memory speed is processor dependent.
NOTE: Due to the non-industry standard nature of some third-party memory modules, we recommend HP
branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower
memory speed. Full availability of 4 GB or more of memory requires a Windows 64-bit operating system or
Linux. With Windows 32-bit operating systems, the amount of usable memory is dependent upon your
configuration, so that above 3 GB all memory may not be available due to system resource requirements.
Communications Integrated Intel 82577LM Gigabit * Network Connection (vPro configurations)
Integrated Intel 82577LC Gigabit * Network Connection (non vPro configurations)
56K V.92 modem **
* The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for
Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission,
connection to a Gigabit Ethernet server and network infrastructure is required.
** Designed for downloads from 56K modem compliant sources. Maximum achievable download
transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem availability is
subject to country regulatory approval.
Wireless Devices Support for a broad range of secure, integrated wireless LAN and wireless WAN options featuring support
for the latest industry standards. Broadband Wireless (WWAN) requires a Windows operating system and
is available in select countries as a standard, factory configurable feature only. Integrated Bluetooth is
also available (factory configurable only) and can be combined with any of the supported wireless LAN and
wireless WAN options.
HP un2420 EV-DO/HSPA
Mobile Broadband Module
Integrated mobile broadband module with Gobi global mobile Internet
technology that provides connectivity to both CDMA (EVDO) and UMTS (HSPA)
networks. It also provides GPS functionality for various mapping applications
and security applications such as Computrace LoJack Pro Premium for HP
ProtectTools.
NOTE: Separately purchased mobile network operator service is required.
Two 850/900/1575/1800/1900/2100 MHz antennas integrated in the top of
the display panel support current and future WWAN technologies.
All 802.11 integrated
wireless LAN options
Wi-Fi Certified *
Cisco Compatible Extensions support
Wired Equivalent Privacy (WEP) support up to 128-bit keys
Wi-Fi Protected Access (WPA) and WPA2 support
802.1x authentication support, including EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP-MSCHAPv2, and LEAP
Advanced Encryption Standard (AES) support
Dual antennas integrated in the display enclosure
QuickSpecs
HP ProBook 6450b Notebook PC
HP ProBook 6550b Notebook PC
Standard Features (availability may vary by country)
DA - 13616 Canada — Version 17 — February 15, 2012 Page 9

Intel Centrino Advanced-
N 6200 (2x2)
Integrated support for 802.11a, b, g, and n *
2 transmit, 2 receive antennas
Up to 300 mbps data rate
Intel Centrino Wireless-N
1000 (1x2)
Integrated support for 802.11b, g, and n *
1 transmit, 2 receive antennas
Up to 300 mbps data rate
Broadcom 4322AGN
802.11a/b/g/n
WiFi Adapter
Integrated support for 802.11 a, b, g, and n
Up to 300 mbps data rate
Broadcom 4313GN
802.11b/g/n
WiFi Adapter
Integrated support for 802.11 b, g, and n
Up to 72 mbps data rate
Broadcom 4312G
802.11b/g
WiFi Adapter
(Russia/Ukraine only)
Integrated support for 802.11 b and g
Up to 54 mbps data rate
HP Integrated Module
with Bluetooth 2.1+EDR
Wireless Technology
Bluetooth Specification v2.1+EDR compliant
Works with a wide range of Bluetooth devices
Keyboard The HP spill-resistant keyboard is designed using a thin layer of Mylar film under the keyboard and a drain
system that funnels fluid through a hole in the bottom of the notebook. This minimizes the risk of damage
to sensitive components underneath. The 101/102-key compatible keyboard features a full-pitch key
layout with desktop keyboard features, such as the isolated inverted-T cursor control keys, editing keys,
both left and right control and alt keys, 12 function keys, and 19.05 x 19.05 mm key pitch (center-to-
center spacing). U.S. and International key layouts are available. Other features include hotkeys for instant
access to power conservation and brightness. The HP ProBook 6550b includes a separate numeric keypad.
Touch-sensitive controls Touch-sensitive controls provide easy access to the following features: HP QuickLook 3, HP QuickWeb,
wireless on/off, volume mute, volume down, volume up. The HP ProBook 6550b also features a calculator
button.
Pointing device Touchpad with scroll zone, two pick buttons
Optional pointstick with two additional pointstick buttons
QuickSpecs
HP ProBook 6450b Notebook PC
HP ProBook 6550b Notebook PC
Standard Features (availability may vary by country)
DA - 13616 Canada — Version 17 — February 15, 2012 Page 10

Expansion card slots ExpressCard/54 slot Supports ExpressCard/54 and ExpressCard/34
or
Optional Integrated
Smart Card Reader
(replaces ExpressCard/54
slot)
Compatible with ISO 7816 compliant Smart Cards
PC/SC interface support
Media Card Reader Supports SD (Secure Digital), HC-SD (High Capacity Secure Digital), MultiMedia
Card, HS-MultiMedia Card (MultiMedia Card Plus), Sony Memory Stick, Sony
Memory Stick Pro, Memory Stick Duo * , Picture card
Additionally, the following cards are supported via passive adapters (sold
separately): Mini-Secure Digital (Mini-SD), Transflash (Micro-SD), Reduced size
Multimedia card (RS-MultiMedia Card), Reduced size Dual voltage Multimedia
card, MultiMedia Card Mobile Cards, MultiMedia Card Micro Cards, Memory
Stick Duo (MS Duo) * , Memory Stick Duo Pro (MS Duo Pro) * , Memory Stick M2
Micro
* Memory Stick Duo Adapters are required and sold separately. Inserting a Memory Stick Duo Card directly
into your notebook could damage the memory card and/or notebook.
Internal Storage Hard drives 160/250/320 GB 7200 rpm SMART SATA II
320 GB 7200 rpm SMART SATA II Self Encrypting Drive
NOTE: These hard drives are customer removable and will withstand multiple insertion/removal cycles. Up
to 10 GB is reserved for the system recovery software.
HP 3D DriveGuard
(Windows only)
The hard drive is mounted directly to the notebook frame, reducing the
transmission of shock to the hard drive. Uses three-axis digital motion
detection with intelligent sensitivity to help protect the hard drive during
normal use from shock and vibration. The digital accelerometer temporarily
halts all data transfer and parks the hard drive when abrupt motion is
detected.
Solid State Drive* 128 GB
* Installation of a Solid State Drive on systems with Windows 7 requires system memory of 2 GB or more.
Upgrade Bay Fixed 12.7 mm SATA
optical drive
DVD+/-RW SuperMulti DL LightScribe Drive
DVD-ROM Drive
Weight saver
QuickSpecs
HP ProBook 6450b Notebook PC
HP ProBook 6550b Notebook PC
Standard Features (availability may vary by country)
DA - 13616 Canada — Version 17 — February 15, 2012 Page 11

Interfaces ExpressCard/54 slot One (or optional Smart Card Reader)
External monitor Two - (1) DisplayPort, (1) VGA
1394a One
Stereo microphone in One
Stereo headphone/line
out
One
Power connector One
RJ-11/modem One
RJ-45/Ethernet One
USB 2.0 Three
eSATA/USB 2.0 combo One
Serial port One (HP ProBook 6550b only)
Docking connector One
Secondary battery
connector
One
Audio/Visual HD audio (HP Premier Sound)
Integrated stereo speakers
Integrated microphone (dual-microphone array when equipped with optional 2 MP webcam)
Touch-sensitive controls for volume up, volume down, and mute
Stereo headphone/line out
Stereo microphone/line in
Optional 2 MP webcam
Supports videoconferencing and still image capture
Large image sensor for excellent colour matching and good low light sensitivity
Up to 30 frames/sec
Fixed focus lens
Video capture at VGA, 1.3 Mpixel, and 2 Mpixel resolutions
16-bit true colour (camera sensors output YCrCb format among others)
QuickSpecs
HP ProBook 6450b Notebook PC
HP ProBook 6550b Notebook PC
Standard Features (availability may vary by country)
DA - 13616 Canada — Version 17 — February 15, 2012 Page 12

Software Preinstalled software
with Windows operating
system
HP Recovery Manager (available with Windows 7 or Vista only)
HP Support Assistant (available with Windows 7 or Vista only)
HP ProtectTools Security Manager
HP ProtectTools for Central Management
HP Quick Launch Buttons Software
HP QuickLook 3
HP QuickWeb
HP Power Assistant
HP Connection Manager 3.1
HP Wireless Assistant
HP DayStarter
Microsoft Office 2010 preloaded (purchase of a Product
Key required to activate a full Office 2010 suite)*
McAfee Total Protection *
PDF Complete Special Edition**
Intervideo WinDVD – DVD Player (select models)
Roxio Creator Business (select models)
HP Webcam Software (select models)
Skype
WinZip 14.5 trial
Additional software
available from the web
HP SoftPaq Download Manager
* Microsoft Office 2010 Preloaded includes reduced functionality versions of Word and Excel. Purchase of
Product Key required to activate full Office 2010 suite available at participating resellers/retailers and
http://www.office.com .
** 60 day trial period for McAfee Total Protection for Small Business software. Internet access required to
receive updates. First update included. Subscription required for updates thereafter.
*** 60 day trial; purchase license afterwards for full functionality.
HP Recovery Manager Models shipped with Windows 7 or Windows Vista include HP Recovery Manager. HP Recovery Manager
enables fast recovery of the factory preinstalled image if the system becomes corrupted or if important
system files are accidentally deleted. Up to 10 GB of the hard drive is reserved for the system recovery
software.
QuickSpecs
HP ProBook 6450b Notebook PC
HP ProBook 6550b Notebook PC
Standard Features (availability may vary by country)
DA - 13616 Canada — Version 17 — February 15, 2012 Page 13

Security Standard Features HP ProtectTools Security Manager
Enhanced Pre-Boot Security
HP SpareKey
One-Step Logon
Setup Password
TPM 1.2 Embedded Security Chip *
TPM Enhanced DriveLock *
HP Disk Sanitizer
Lock slot
Support for Computrace ** LoJack Pro for HP ProtectTools
Optional Features Smart Card Reader
(replaces ExpressCard/54
slot)
Compatible with ISO 7816 compliant Smart Cards
PC/SC interface support
HP Fingerprint Sensor Enhanced sensor scans the fingerprint to uniquely
identify and authenticate a person.
HP Privacy Filter Narrows viewing area so that screen data is
visible only to persons directly in front of the
monitor.
Computrace ** LoJack Pro
Premium for HP
ProtectTools with GPS
Tracking
Subscription based security solution providing the
ability to track, initiate physical recovery, conduct
asset management, and perform remote data
delete by utilizing GPS technology. GPS
functionality requires HP un2420 EV-DO/HSPA
Mobile Broadband Module.
* TPM module disabled where use is restricted by law; for example, Russia and China.
** The Computrace agent is shipped turned off, and must be activated by customers when they purchase a
subscription with terms ranging from one to five years.
For more information on HP security solutions refer to: http://www.hp.com/go/security .
HP ProtectTools Security
Manager with Central
Management
HP ProtectTools Security Manager is the security platform for business notebooks and desktops. The HP
ProtectTools Security Manager is an extensible client security console that delivers enhanced security
capabilities through add-on software modules. The following modules are available on the hard drive (also
downloadable from the web) and can be configured in Software Setup:
Credential Manager for HP ProtectTools
Device Access Manager for HP ProtectTools
Drive Encryption for HP ProtectTools
File Sanitizer for HP ProtectTools
Privacy Manager for HP ProtectTools (Chat & Sign)
Embedded Security for HP ProtectTools
Computrace LoJack Pro for HP ProtectTools
HP ProtectTools is now capable of being centrally managed from a single control point. HP ProtectTools is
management ready out of the box, in partnership with Digital Persona, and provides features that
customers expect from a centrally managed security solution, such as user provisioning, credential reset,
and system and network revocation . Central Management is available in two feature levels:
Digital Persona Pro Enterprise: Designed for environments with Active Directory. For large
businesses, as well as smaller businesses utilizing an active directory based infrastructure. Gives IT
QuickSpecs
HP ProBook 6450b Notebook PC
HP ProBook 6550b Notebook PC
Standard Features (availability may vary by country)
DA - 13616 Canada — Version 17 — February 15, 2012 Page 14

Managers the ability to create role based security policies, provision users, and create login policies
based on passwords, biometrics or smart cards. Management features also include remote
credential recovery in case the user forgets the password, loses the smart card, or cannot use the
fingerprint reader for any reason. In addition, advanced auditing capabilities are also built in.
Digital Persona Workgroup Manager: Designed for environments without Active Directory. This
option can be used by smaller businesses as well as workgroups within large organizations.
Workgroup Manager offers features similar to Digital Persona Pro Enterprise, but without active
directory integration. Workgroup activation is built into HP ProtectTools, and activation of up to 5
seats is completely free.
Power Supply Models with discrete graphics:
External 90-watt Smart AC adapter
Models with integrated graphics:
External 65-watt Smart AC adapter
Power cord included is 6-foot (1.8 meter).
Total length including external AC adapter is 12 feet (3.66 meter).
HP Fast Charge *
*HP Fast Charge recharges your battery up to 90% within 90 minutes when the system is off. HP Fast
Charge does not apply to the 9-cell primary battery, the 12-cell Ultra-Capacity batteries, or the HP Long
Life Battery.
Battery Primary battery HP 9-cell (93 WHr) Li-Ion battery
HP 6-cell (55 WHr) Li-Ion battery
HP Long Life 6-cell (51 WHr) Battery*
Optional HP Long Life
Battery*
3-cell (47 WHr) Li-Ion battery
Optional HP Extended Life
Battery
8-cell (52 WHr) Li-Ion battery
Optional HP Ultra-
Capacity Battery
12-cell (95 WHr) Li-Ion battery
* The 3-year limited warranty on the HP Long Life Battery is only available on platforms with a 3-year
system warranty. The HP Long Life Battery will carry a limited 1-year warranty on platforms with a 1-year
system warranty.
QuickSpecs
HP ProBook 6450b Notebook PC
HP ProBook 6550b Notebook PC
Standard Features (availability may vary by country)
DA - 13616 Canada — Version 17 — February 15, 2012 Page 15

Battery Life Configurations with integrated
graphics
Configurations with
discrete graphics
HP ProBook 6450b
9-cell (93 WHr) Up to 11 hours Up to 9 hours and 30 minutes
with optional
HP Extended Life Battery
Up to 17 hours and 30 minutes Up to 15 hours and 45 minutes
with optional HP
Ultra-Capacity Battery
Up to 22 hours Up to 19 hours and 30 minutes
6-cell (55 WHr) Up to 6 hours and 30 minutes Up to 5 hours and 45 minutes
with optional
HP Extended Life Battery
Up to 13 hours and 15 minutes Up to 12 hours
with optional HP
Ultra-Capacity Battery
Up to 17 hours and 30 minutes Up to 15 hours and 30 minutes
6-cell (51 WHr)
Long Life
Up to 6 hours Up to 5 hours and 15 minutes
HP ProBook 6550b
9-cell (93 WHr) Up to 10 hours Up to 8 hours and 45 minutes
with optional
HP Extended Life Battery
Up to 15 hours and 15 minutes Up to 14 hours
with optional HP
Ultra-Capacity Battery
Up to 20 hours and 30 minutes Up to 18 hours
6-cell (55 WHr) Up to 6 hours and 15 minutes Up to 5 hours and 30 minutes
with optional
HP Extended Life Battery
Up to 11 hours and 45 minutes Up to 10 hours and 15 minutes
with optional HP
Ultra-Capacity Battery
Up to 16 hours and 30 minutes Up to 14 hours and 30 minutes
6-cell (51 WHr)
Long Life
Up to 5 hours and 15 minutes Up to 4 hours and 30 minutes
NOTE: Battery life will vary depending on the product model, configuration, loaded applications, features,
use, wireless functionality and power management settings. The maximum capacity of the battery will
naturally decrease with time and usage. See MobileMark07 battery benchmark
www.bapco.com/products/mobilemark2007 for additional details.
System Standby Time Up to 1 week
Power Conservation ATI PowerPlay technology
Hibernation
Standby
ACPI compliance
QuickSpecs
HP ProBook 6450b Notebook PC
HP ProBook 6550b Notebook PC
Standard Features (availability may vary by country)
DA - 13616 Canada — Version 17 — February 15, 2012 Page 16

Docking and Stands HP 90W Docking Station
HP 120W Advanced Docking Station
HP USB 2.0 Docking Station
HP Essential USB 2.0 Port Replicator
HP Dual Hinge Notebook Stand
HP Display & Notebook Stand
HP Adjustable Display Stand
HP Adjustable Dual Display Stand
NOTE: Some HP Docking stations may not support every feature of some HP Notebook models. Please
refer to the individual docking station documentation for specific information about supported features.
Service and Support HP Services offers limited 3-year, 1-year and 90-day warranty options depending on country. On-site
service and warranty upgrades are also available. HP Care Pack Services extend service contracts beyond
the standard warranties. To choose the right level of service for your HP product, use the HP Care Pack
Services Lookup Tool at: http://www.hp.com/go/lookuptool . Additional HP Care Pack Services information
by product is available at: http://www.hp.com/hps/carepack .
NOTE: Certain restrictions and exclusions apply. Consult the HP Customer Support Centre for details.
http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp .
QuickSpecs
HP ProBook 6450b Notebook PC
HP ProBook 6550b Notebook PC
Standard Features (availability may vary by country)
DA - 13616 Canada — Version 17 — February 15, 2012 Page 17

NOTE: Options/capabilities listed in the QuickSpecs represent those capabilities available through Base Units or Build to Order
configurations. The various product features and capabilities will vary in terms of configurable vs. aftermarket options (AMOs). There
may be options and capabilities available through CTO that are not available as AMOs.
Memory HP 1 GB (DDR3 1333 MHz) SODIMM AT911AA
HP 2 GB (DDR3 1333 MHz) SODIMM AT912AA
HP 4 GB (DDR3 1333 MHz) SODIMM AT913AA
Storage HP Upgrade Bay SATA DVD+/-RW SuperMulti DL LightScribe Drive AK869AA
HP 250 GB Pocket Media Drive FE477AA
HP External USB Drive CD/DVD R/RW FS943AA
HP Primary SATA 320 GB 7200 rpm Hard Drive AS282AA
Expansion Solutions HP 90W Docking Station VB041AA
HP 120W Advanced Docking Station NZ222AA
HP USB 2.0 Docking Station FQ834AA
HP Essential USB 2.0 Port Replicator AQ731AA
HP Dual Hinge Notebook Stand AW661AA
HP Display & Notebook Stand AW662AA
HP Adjustable Display Stand AW663AA
HP Adjustable Dual Display Stand AW664AA
Power HP Smart 65W Travel AC Adapter AU155AA
HP 90W Smart AC Adapter ED495AA
HP 90W Smart Combo Adapter AJ652AA
HP Long Life 3-Cell Battery AU213AA
HP 6-Cell Li-Ion Primary Battery KU531AA
HP 9-Cell Li-Ion Primary Battery AT908AA
HP Extended Life Battery AJ359AA
HP Ultra-Capacity Battery AT486AA
QuickSpecs
HP ProBook 6450b Notebook PC
HP ProBook 6550b Notebook PC
Options (availability may vary by country)
DA - 13616 Canada — Version 17 — February 15, 2012 Page 18

Carrying Cases HP Basic Carrying Case AJ078AA
HP Value Nylon Case RR314AA
HP Universal Nylon Case RR315AA
HP Professional Slim Top Load Case AY530AA
HP Executive Leather Case RR316AA
HP Deluxe Nylon Backpack RR317AA
HP Deluxe Roller Case GD405AA
HP Basic Backpack AM863AA
HP Merlot Slipcase AU095AA
HP Basic Messenger Carrying Case AP355AA
HP Professional Series Carrying Case AT886AA
HP Professional Series Backpack AT887AA
HP Professional Series Messenger AT888AA
HP Professional Series Designer Tote AT889AA
HP Professional Series Slip Case AT890AA
HP Elite Series Designer Tote AT891AA
HP Elite Series Quick Case AT892AA
Security HP Notebook Combination Lock AY475AA
HP Docking Station Cable Lock AU656AA
HP 14.0-inch Display Privacy Filter AU100AA
HP 15.6-inch Display Privacy Filter AU103AA
HP ExpressCard Smart Card Reader AJ451AA
Input/Output Devices HP PS/2 Keyboard & Mouse Bundle RC464AA
HP USB Keyboard & Mouse Bundle RC465AA
HP USB Optical Travel Mouse RH304AA
HP USB/PS2 Optical 2-Button Scroll Mouse DC369A
HP Wireless Mouse AR085AA
HP BT Headset AR084AA
HP Mobile Audio Speakers FS944AA
HP Mobile Productivity Bundle AQ792AA
HP Bluetooth ExpressCard Mouse GK872AA
HP Migration Cable for Windows 7 AY493AA
HP Premium Autofocus Webcam KQ245AA
Premium Digital Headset KJ270AA
QuickSpecs
HP ProBook 6450b Notebook PC
HP ProBook 6550b Notebook PC
Options (availability may vary by country)
DA - 13616 Canada — Version 17 — February 15, 2012 Page 19

Miscellaneous DisplayPort To DVI-D Adapter FH973AA
Promo USB Graphics Adapter NL571AT
External USB Modem GS023AA
Belkin USB to Serial Adapter EM449AA
Notebook Multi-Purpose Cleaning Kit BL528AA
QuickSpecs
HP ProBook 6450b Notebook PC
HP ProBook 6550b Notebook PC
Options (availability may vary by country)
DA - 13616 Canada — Version 17 — February 15, 2012 Page 20
