HP Stream Notebook-14-z010nr User manual

Layout of the HP Stream Laptop
User Guide developed and adapted from:
Hewlett-Packard Development Company, L.P. (2014, October). HP Stream Notebook-14-z010nr (Energy Star) User Guide. Retrieved from:
http://support.hp.com/us-en/product/HP-Stream-14-Notebook-PC/7296828/model/7415863/manuals
Microsoft (2015). Windows Tutorial. Retrieved from: 1
http://windows.microsoft.com/en-gb/windows-8/start-screen-tutorial
Layout of the HP Stream
Right-side
1. Power light
a. When the light shows, the computer is on.
b. When the light is blinking, the computer is in the Sleep state.
c. When the light is off, the computer is off or in a Hibernations states.
*Hibernation is a power-saving state that uses the least amount of power.
2. Audio-out (headphone)/Audio-in (microphone) jack
a. Connects optional speakers, headphones, earbuds, or a headset.
b. This jack does not support optional microphone only devices.
3. USB 2.0 port
a. Connects an optional USB device
b. Examples: mouse, external drive, printer, scanner or USB hub.
4. USB 3.0 port
a. Connects an optional USB device
b. Examples: mouse, external drive, printer, scanner or USB hub.
5. HDMI port
a. Connects an optional video or audio device
a. Examples: high definition television, any compatible digital or audio component, or a
high-speed HDMI device.

Layout of the HP Stream Laptop
User Guide developed and adapted from:
Hewlett-Packard Development Company, L.P. (2014, October). HP Stream Notebook-14-z010nr (Energy Star) User Guide. Retrieved from:
http://support.hp.com/us-en/product/HP-Stream-14-Notebook-PC/7296828/model/7415863/manuals
Microsoft (2015). Windows Tutorial. Retrieved from: 2
http://windows.microsoft.com/en-gb/windows-8/start-screen-tutorial
Left-side
1. Security Cable Slot
a. Attaches an optional security cable to the computer
2. Power connector
a. Connects an AC adapter
3. AC Adapter Light
a. White: The AC adapter is connected and the battery is charged.
b. Amber: The AC adapter is connected and the battery is charging.
c. Off: The computer is using battery power.
4. SIM Card Slot (not available on this model)
5. Memory card reader
a. Reads optional memory cards that store, manage, share, or access information.
Bottom
Speakers –Produce sound

Layout of the HP Stream Laptop
User Guide developed and adapted from:
Hewlett-Packard Development Company, L.P. (2014, October). HP Stream Notebook-14-z010nr (Energy Star) User Guide. Retrieved from:
http://support.hp.com/us-en/product/HP-Stream-14-Notebook-PC/7296828/model/7415863/manuals
Microsoft (2015). Windows Tutorial. Retrieved from: 3
http://windows.microsoft.com/en-gb/windows-8/start-screen-tutorial
Display
1. Internal microphones
a. Record sound
2. Webcam light
a. On: The webcam is in use.
3. Webcam
a. Records video and captures photographs.
b. To use the webcam, from the Start screen, type camera, and then select Camera from
the list of applications.

Layout of the HP Stream Laptop
User Guide developed and adapted from:
Hewlett-Packard Development Company, L.P. (2014, October). HP Stream Notebook-14-z010nr (Energy Star) User Guide. Retrieved from:
http://support.hp.com/us-en/product/HP-Stream-14-Notebook-PC/7296828/model/7415863/manuals
Microsoft (2015). Windows Tutorial. Retrieved from: 4
http://windows.microsoft.com/en-gb/windows-8/start-screen-tutorial
Touchpad
1. Touchpad Zone –
a. Reads your finger gestures to move the pointer or activate items on the screen.
2. Left Touchpad Button
a. Functions like the left button of an external mouse
3. Right Touchpad Button
a. Functions like the right button of an external mouse
Lights

Layout of the HP Stream Laptop
User Guide developed and adapted from:
Hewlett-Packard Development Company, L.P. (2014, October). HP Stream Notebook-14-z010nr (Energy Star) User Guide. Retrieved from:
http://support.hp.com/us-en/product/HP-Stream-14-Notebook-PC/7296828/model/7415863/manuals
Microsoft (2015). Windows Tutorial. Retrieved from: 5
http://windows.microsoft.com/en-gb/windows-8/start-screen-tutorial
1. Power light
a. On: The computer is on
b. Blinking: The computer is in the Sleep state
c. Off: The computer is off or in Hibernation.
2. Caps Lock Light
a. On: Caps lock is on, which switches all the keys to capital letters.
3. Mute Light
a. Amber: Computer sound is off
b. Off: Computer sound is on.
Power Button
1. When the computer is off, press the button to turn on the computer.
2. When the computer is on, press the button briefly to initiate sleep.
3. When the computer is in Hibernation, press the button to briefly to exit Hibernation.

Layout of the HP Stream Laptop
User Guide developed and adapted from:
Hewlett-Packard Development Company, L.P. (2014, October). HP Stream Notebook-14-z010nr (Energy Star) User Guide. Retrieved from:
http://support.hp.com/us-en/product/HP-Stream-14-Notebook-PC/7296828/model/7415863/manuals
Microsoft (2015). Windows Tutorial. Retrieved from: 6
http://windows.microsoft.com/en-gb/windows-8/start-screen-tutorial
Keys
1. Escape
2. Function-Executes frequently used system functions
3. Windows- Returns you to the Start screen from an open app or the Windows desktop.
4. Windows Help and Support
5. Dim Display Screen Brightness decreases the screen brightness
6. Increase Brightness on the Display Screen increases the screen brightness
7. Project PC Screen only, Duplicate, Extend, Second screen only
8. Mute speaker sound
9. Decrease Speaker Volume
10. Increase Speaker Volume

Layout of the HP Stream Laptop
User Guide developed and adapted from:
Hewlett-Packard Development Company, L.P. (2014, October). HP Stream Notebook-14-z010nr (Energy Star) User Guide. Retrieved from:
http://support.hp.com/us-en/product/HP-Stream-14-Notebook-PC/7296828/model/7415863/manuals
Microsoft (2015). Windows Tutorial. Retrieved from: 7
http://windows.microsoft.com/en-gb/windows-8/start-screen-tutorial
11. Arrows Left Plays the previous track of an audio CD or previous section of a DVD;
12. Arrow Right with Parallel Bars Begins, pauses, or resumes playback of an audio CD or DVD
13. Arrow Right Plays the next track of an audio CD or the next section of a DVD.
14. Airplane Turn Airplane Mode on or off. When Airplane mode is on, wireless connectivity is
not active.
On the Display Screen
Power Meter-To view the remaining battery charge
Wireless-Click to connect to a wireless connection: mcscwinet.
Speakers-Adjust the volume of the speakers.
On the TouchPad
1. Scrolling Useful for moving up, down, or sideways on a page or image.
*Place 2-fingers slightly apart on the TouchPad zone and drag them up, down, left, or right.
2. 2-finger pinch Zoom
2-finger pinch zoom allows you to zoom out or in on images or text.
a. Zoom out-Place 2 fingers apart on the TouchPad Zone and then move your fingers
together.
b. Zoom in-Place 2 fingers together on the TouchPad Zone and then move your fingers
apart.

Layout of the HP Stream Laptop
User Guide developed and adapted from:
Hewlett-Packard Development Company, L.P. (2014, October). HP Stream Notebook-14-z010nr (Energy Star) User Guide. Retrieved from:
http://support.hp.com/us-en/product/HP-Stream-14-Notebook-PC/7296828/model/7415863/manuals
Microsoft (2015). Windows Tutorial. Retrieved from: 8
http://windows.microsoft.com/en-gb/windows-8/start-screen-tutorial
2-finger click
2-finger click allow you to make menu selections for an object on the screen. This is the same action as
using right-click with the mouse to obtain menu such as Save As, and Print.
a. Place 2 fingers on the TouchPad Zone to open the options menu for the selected object.
Edge Swipes
Edge swipes allow you to perform tasks such as changing settings and finding and using apps.
Right-edge swipe
Display and select a charm. Charms allow you to Search, Share, Start Apps, Access Devices, or Change
Settings.

Layout of the HP Stream Laptop
User Guide developed and adapted from:
Hewlett-Packard Development Company, L.P. (2014, October). HP Stream Notebook-14-z010nr (Energy Star) User Guide. Retrieved from:
http://support.hp.com/us-en/product/HP-Stream-14-Notebook-PC/7296828/model/7415863/manuals
Microsoft (2015). Windows Tutorial. Retrieved from: 9
http://windows.microsoft.com/en-gb/windows-8/start-screen-tutorial
1. With your finger, swipe from the right-side of the TouchPad.
2. Scroll up or down to switch between the charms, and then select the charm you want to open.
Left-edge swipe
The left-edge swipe accesses your recently opened apps so that you can switch between them quickly.
1. Swipe your finger gently from the left edge of the TouchPad.
Windows 8.1
Windows 8.1 contains 3 main screens:
1. Desktop
2. Start screen - contains apps in the form of tiles.
3. App screen - shows all of your apps or programs in list form.
*You can switch quickly between the Start screen, Desktop, and the Apps screen.
Desktop
On the desktop, you can use all kinds of apps and programs. You can also pin your favorite apps
and programs to the taskbar, so you can get to them quickly.
To get to the desktop, click the desktop tile on the Start screen
Or
Press the Windows logo key +D on your keyboard.
Getting to the Start Screen
3 Ways to get to Start
1. Click on the Start button in the lower-left corner of the screen.
2. Press the Windows logo key on your keyboard.
3. Open the charms (by sliding a finger from the right-side of the Touchpad), and clicking on
Start.

Layout of the HP Stream Laptop
User Guide developed and adapted from:
Hewlett-Packard Development Company, L.P. (2014, October). HP Stream Notebook-14-z010nr (Energy Star) User Guide. Retrieved from:
http://support.hp.com/us-en/product/HP-Stream-14-Notebook-PC/7296828/model/7415863/manuals
Microsoft (2015). Windows Tutorial. Retrieved from: 10
http://windows.microsoft.com/en-gb/windows-8/start-screen-tutorial
Start Tip: When you are in desktop, you can right-click the start button to get to quick settings like
Search, Shut down or Sign out.
Start Screen
App View
Use the App View to see all your apps and to find all of your apps and programs.
From the Start Screen, click the arrow near the lower-left corner of the Start screen to view apps.
5 Charms
