HP E1418A User manual

Contents
HP E1418A 8/16-Channel D/A Converter Module
Edition 2
Click here to Return to HP TS-5400 Systems on-Line Manuals Main Contents
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
WARNINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Safety Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Reader Comment Sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Chapter 1. Module Setup and Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Using This Chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Module Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Ordering Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Field Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Terminal Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Front Panel Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Setting the Logical Address Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Module Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Installation in a Mainframe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Terminal Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Screw-Type Terminal Module (Standard) . . . . . . . . . . . . . . . . . . . . . . 22
Wiring the Terminal Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Attaching the Terminal Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Removing the Terminal Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Terminal Module Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Option A3E . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Option A3H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Option 135 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Terminal Module Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Configuring the Terminal Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
P/J Jumper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
V/I Jumper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Terminal Module Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Voltage and Current Output Connections . . . . . . . . . . . . . . . . . . . . . . 33
Combining Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Connecting an External Trigger Source . . . . . . . . . . . . . . . . . . . . . . . 35
Using the CAL Output Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Initial Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Device Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Module Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
HP E1418A 8/16-Channel D/A Converter Module Contents 1

Chapter 2. Programming Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Using This Chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Program Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Querying Module Identification and Configuration . . . . . . . . . . . . . . . . . . . . 40
Configuration Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
APPLy Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Error Checking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
I/O Error Checking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
SCPI Error Checking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
SOURce Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Setting the Output Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Controlling the Output Relay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Triggering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Using *OPC? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Combining Output Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Chapter 3. HP E1418A SCPI Command Reference . . . . . . . . . . . . . . . . . . . . . . 58
Using This Chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Command Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Common Command Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
SCPI Command Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Linking Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
SCPI Command Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
ABORt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
APPLy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
APPLyn:CURRent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
APPLyn:VOLTage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
CALibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
CALibration:CONDition? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
CALibration:CONFigure:RESistance? . . . . . . . . . . . . . . . . . . . . . . . . 67
CALibration:RESet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
CALibration:STORe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
CALibration:TEST? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
CALibration:VALue:RESistance . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
CALibrationn:CONFigure:CURRent? . . . . . . . . . . . . . . . . . . . . . . . . 70
CALibrationn:CONFigure:VOLTage? . . . . . . . . . . . . . . . . . . . . . . . . 71
CALibrationn:VALue:CURRent? . . . . . . . . . . . . . . . . . . . . . . . . . . 72
CALibrationn:VALue:VOLTage? . . . . . . . . . . . . . . . . . . . . . . . . . . 73
DIAGnostic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
DIAGnostic:CALibration:OUTPut[:MODE] . . . . . . . . . . . . . . . . . . . . 75
DIAGnostic:CALibration:OUTPut[:MODE]? . . . . . . . . . . . . . . . . . . . . 76
DIAGnostic:CONFigure? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
DIAGnostic:OUTPut:ALL[:STATe] . . . . . . . . . . . . . . . . . . . . . . . . . 77
DIAGnostic:SOURcen:FUNCtion:MODE . . . . . . . . . . . . . . . . . . . . . . 77
DIAGnostic:TRIGgered? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
INITiate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
INITiate[:IMMediate] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
OUTPut . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
OUTPut:TTLTrgn[:STATe] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
2 Contents HP E1418A 8/16-Channel D/A Converter Module

OUTPut:TTLTrgn[:STATe]? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
OUTPutn[:STATe] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
OUTPutn[:STATe]? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
SOURce . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
SOURcen:CURRent[:LEVel][:IMMediate][:AMPLitude] . . . . . . . . . . . . . 84
SOURcen:CURRent[:LEVel][:IMMediate][:AMPLitude]? . . . . . . . . . . . . . 85
SOURcen:CURRent[:LEVel]:TRIGgered[:AMPLitude] . . . . . . . . . . . . . . 86
SOURcen:CURRent[:LEVel]:TRIGgered[:AMPLitude]? . . . . . . . . . . . . . . 87
SOURcen:FUNCtion:MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
SOURcen:FUNCtion:MODE? . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
SOURcen:VOLTage[:LEVel][:IMMediate][:AMPLitude] . . . . . . . . . . . . . 90
SOURcen:VOLTage[:LEVel][:IMMediate][:AMPLitude]? . . . . . . . . . . . . . 91
SOURcen:VOLTage[:LEVel]:TRIGgered[:AMPLitude] . . . . . . . . . . . . . . 92
SOURcen:VOLTage[:LEVel]:TRIGgered[:AMPLitude]? . . . . . . . . . . . . . . 93
STATus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
STATus:OPERation:CONDition? . . . . . . . . . . . . . . . . . . . . . . . . . . 95
STATus:OPERation:ENABle . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
STATus:OPERation:ENABle? . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
STATus:OPERation[:EVENt]? . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
STATus:PRESet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
STATus:QUEStionable:CONDition? . . . . . . . . . . . . . . . . . . . . . . . . 97
STATus:QUEStionable:ENABle . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
STATus:QUEStionable:ENABle? . . . . . . . . . . . . . . . . . . . . . . . . . . 98
STATus:QUEStionable[:EVENt]? . . . . . . . . . . . . . . . . . . . . . . . . . . 98
SYSTem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
SYSTem:ERRor? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
SYSTem:VERSion? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
TEST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
TEST:NUMBer? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
TEST:TST[:RESults]? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
*TST? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
TRIGger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
TRIGger[:IMMediate] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
TRIGger:SOURce . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
TRIGger:SOURce? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
IEEE-488.2 Common Command Quick Reference . . . . . . . . . . . . . . . . . . . . 106
HP E1418A Command Quick Reference . . . . . . . . . . . . . . . . . . . . . . . . . 107
Appendix A. HP E1418A Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
DC Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
DC Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
General Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Cooling Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
HP E1418A 8/16-Channel D/A Converter Module Contents 3

Appendix B. HP E1418A Register-Based Programming . . . . . . . . . . . . . . . . . . . 114
Addressing the Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
A16 Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
A24 Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
The Base Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
Register Offset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Reset and Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Register Maps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
A16/A24 REGISTERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
A24 REGISTERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Register Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Manufacturer ID Register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Logical Address Register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Device Type Register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
VXI Status/Control Register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
VXI Offset Register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
Calibration Control Register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Card Configuration Register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Software Trigger Register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
Trigger Control Register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
Interrupt Status Register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Isolation Status Register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Channel Program Jumper Register . . . . . . . . . . . . . . . . . . . . . . . . . . 138
Channel Trigger Register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
Channel Mode Register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
Channel Relay Control Register . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
Card Control Register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
Main_DAC Immediate Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . 142
Main_DAC Triggered Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . 142
Offset_DAC Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
Gain_DAC Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
Undefined Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
Channel Voltage Offset Calibration Registers . . . . . . . . . . . . . . . . . . . . 144
Channel Voltage Gain Calibration Registers . . . . . . . . . . . . . . . . . . . . . 145
Channel Current Offset Calibration Registers . . . . . . . . . . . . . . . . . . . . 146
Channel Current Gain Calibration Registers . . . . . . . . . . . . . . . . . . . . . 147
Calibration Resistor Value Registers . . . . . . . . . . . . . . . . . . . . . . . . . 148
Voltage Calibration Status Register . . . . . . . . . . . . . . . . . . . . . . . . . 148
Current Calibration Status Register . . . . . . . . . . . . . . . . . . . . . . . . . . 149
Calibration Isolation Status Register . . . . . . . . . . . . . . . . . . . . . . . . . 150
Calibration Card Configuration Register . . . . . . . . . . . . . . . . . . . . . . . 151
Calibration Checksum Register . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
Module Serial Number Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
Register Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
4 Contents HP E1418A 8/16-Channel D/A Converter Module

Appendix C. HP E1418A Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
Error Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
Appendix D. Voltage/Current Output Adjustment . . . . . . . . . . . . . . . . . . . . . . 158
Using This Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158
Calibration Constants and Non-Volatile Memory . . . . . . . . . . . . . . . . . . . . . 159
Equipment Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159
Making Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159
Adjustment Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160
Voltage Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161
Current Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
Storing the Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166
Return the Module to Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
Example Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
Appendix E. Configuration and Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . 171
Using This Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
Checking Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
Changing Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172
Adding 8 Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173
Installing Isolated/Non-Isolated Plug-on Modules . . . . . . . . . . . . . . . . . . 176
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178
Isolating an Assembly (Self-Test) . . . . . . . . . . . . . . . . . . . . . . . . . . 178
Assembly Exchange . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
To Exchange an Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181
HP E1418A 8/16-Channel D/A Converter Module Contents 5

Notes
6 Contents HP E1418A 8/16-Channel D/A Converter Module

Certification
Hewlett-Packard Company certifies that this product met its published specifications at the time of shipment from the factory. Hewlett-
Packard further certifies that its calibration measurements are traceable to the United States National Institute of Standards and Technol-
ogy (formerly National Bureau of Standards), to the extent allowed by that organization’s calibration facility, and to the calibration
facilities of other International Standards Organization members.
Warranty
This Hewlett-Packard product is warranted against defects in materials and workmanship for a period of three years from date of ship-
ment. Duration and conditions of warranty for this product may be superseded when the product is integrated into (becomes a part of)
other HP products. During the warranty period, Hewlett-Packard Company will, at its option, either repair or replace products which
prove to be defective.
For warranty service or repair, this product must be returned to a service facility designated by Hewlett-Packard (HP). Buyer shall pre-
pay shipping charges to HP and HP shall pay shipping charges to return the product to Buyer. However, Buyer shall pay all shipping
charges, duties, and taxes for products returned to HP from another country.
HP warrants that its software and firmware designated by HP for use with a product will execute its programming instructions when
properly installed on that product. HP does not warrant that the operation of the product, or software, or firmware will be uninterrupted
or error free.
Limitation Of Warranty
The foregoing warranty shall not apply to defects resulting from improper or inadequate maintenance by Buyer, Buyer-supplied prod-
ucts or interfacing, unauthorized modification or misuse, operation outside of the environmental specifications for the product, or im-
proper site preparation or maintenance.
The design and implementation of any circuit on this product is the sole responsibility of the Buyer. HP does not warrant the Buyer’s
circuitry or malfunctions of HP products that result from the Buyer’s circuitry. In addition, HP does not warrant any damage that oc-
curs as a result of the Buyer’s circuit or any defects that result from Buyer-supplied products.
NO OTHER WARRANTY IS EXPRESSED OR IMPLIED. HP SPECIFICALLY DISCLAIMS THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
Exclusive Remedies
THE REMEDIES PROVIDED HEREIN ARE BUYER’S SOLE AND EXCLUSIVE REMEDIES. HP SHALL NOT BE LIABLE
FOR ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, WHETHER BASED ON CON-
TRACT, TORT, OR ANY OTHER LEGAL THEORY.
Notice
The information contained in this document is subject to change without notice. HEWLETT-PACKARD (HP) MAKES NO WAR-
RANTY OF ANY KIND WITH REGARD TO THIS MATERIAL, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WAR-
RANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. HP shall not be liable for errors contained
herein or for incidental or consequential damages in connection with the furnishing, performance or use of this material. This docu-
ment contains proprietary information which is protected by copyright. All rights are reserved. No part of this document may be photo-
copied, reproduced, or translated to another language without the prior written consent of Hewlett-Packard Company. HP assumes no
responsibility for the use or reliability of its software on equipment that is not furnished by HP.
U.S. Government Restricted Rights
The Software and Documentation have been developed entirely at private expense. They are delivered and licensed as "commercial
computer software" as defined in DFARS 252.227-7013 (October 1988), DFARS 252.211.7015 (May 1991) or DFARS 252.227-7014
(June 1995), as a "commercial item" as defined in FAR 2.101(a), or as "Restricted computer software" as defined in FAR 52.227-19
(June 1987) (or any equivalent agency regulation or contract clause), whichever is applicable. You have only those rights provided for
such Software and Documentation by the applicable FAR or DFARS clause or the HP standard software agreement for the product involved.
HP E1418A User’s Manual
Edition 2
Copyright © 1996 Hewlett-Packard Company. All Rights Reserved.
HP E1418A User’s Manual 7

Frame or chassis ground terminal—typi-
cally connects to the equipment’s metal
frame.
Alternating current (AC).
Direct current (DC).
Indicates hazardous voltages.
Calls attention to a procedure, practice, or
condition that could cause bodily injury or
death.
Calls attention to a procedure, practice, or con-
dition that could possibly cause damage to
equipment or permanent loss of data.
Indicates the field wiring terminal that must
be connected to earth ground before operat-
ing the equipment—protects against electri-
cal shock in case of fault.
Instruction manual symbol affixed to prod-
uct. Indicates that the user must refer to the
manual for specific WARNING or CAU-
TION information to avoid personal injury
or damage to the product.
or
WARNINGS
The following general safety precautions must be observed during all phases of operation, service, and repair of this product.
Failure to comply with these precautions or with specific warnings elsewhere in this manual violates safety standards of design,
manufacture, and intended use of the product. Hewlett-Packard Company assumes no liability for the customer’s failure to
comply with these requirements.
Ground the equipment: For Safety Class 1 equipment (equipment having a protective earth terminal), an uninterruptible safety earth
ground must be provided from the mains power source to the product input wiring terminals or supplied power cable.
DO NOT operate the product in an explosive atmosphere or in the presence of flammable gases or fumes.
For continued protection against fire, replace the line fuse(s) only with fuse(s) of the same voltage and current rating and type.
DO NOT use repaired fuses or short-circuited fuse holders.
Keep away from live circuits: Operating personnel must not remove equipment covers or shields. Procedures involving the removal
of covers or shields are for use by service-trained personnel only. Under certain conditions, dangerous voltages may exist even with the
equipment switched off. To avoid dangerous electrical shock, DO NOT perform procedures involving cover or shield removal unless
you are qualified to do so.
DO NOT operate damaged equipment: Whenever it is possible that the safety protection features built into this product have been im-
paired, either through physical damage, excessive moisture, or any other reason, REMOVE POWER and do not use the product until
safe operation can be verified by service-trained personnel. If necessary, return the product to a Hewlett-Packard Sales and Service Of-
fice for service and repair to ensure that safety features are maintained.
DO NOT service or adjust alone: Do not attempt internal service or adjustment unless another person, capable of rendering first aid
and resuscitation, is present.
DO NOT substitute parts or modify equipment: Because of the danger of introducing additional hazards, do not install substitute
parts or perform any unauthorized modification to the product. Return the product to a Hewlett-Packard Sales and Service Office for
service and repair to ensure that safety features are maintained.
WARNING
CAUTION
Documentation History
All Editions and Updates of this manual and their creation date are listed below. The first Edition of the manual is Edition 1. The Edi-
tion number increments by 1 whenever the manual is revised. Updates, which are issued between Editions, contain replacement pages
to correct or add additional information to the current Edition of the manual. Whenever a new Edition is created, it will contain all of
the Update information for the previous Edition. Each new Edition or Update also includes a revised copy of this documentation his-
tory page.
Edition 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . October 1995
Edition 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . October 1996
Safety Symbols
8 HP E1418A User’s Manual

Declaration of Conformity
according to ISO/IEC Guide 22 and EN 45014
Manufacturer’s Name: Hewlett-Packard Company
Loveland Manufacturing Center
Manufacturer’s Address: 815 14th Street S.W.
Loveland, Colorado 80537
declares, that the product:
Product Name: 8/16-Channel D/A Converter Module
Model Number: HP E1418A
Product Options: All
conforms to the following Product Specifications:
Safety: IEC 1010-1 (1990) Incl. Amend 1 (1992)/EN61010-1 (1993)
CSA C22.2 #1010.1 (1992)
UL 3111
EMC: CISPR 11:1990/EN55011 (1991): Group 1 Class A
IEC 801-2:1991/EN50082-1 (1992): 4 kVCD, 8 kVAD
IEC 801-3:1984/EN50082-1 (1992): 3 V/m
IEC 801-4:1988/EN50082-1 (1992): 1 kV Power Line
.5 kV Signal Lines
Supplementary Information: The product herewith complies with the requirements of the Low Voltage
Directive 73/23/EEC and the EMC Directive 89/336/EEC (inclusive 93/68/EEC) and carries the "CE" marking
accordingly.
Tested in a typical HP C-Size VXI Mainframe configuration.
European contact: Your local Hewlett-Packard Sales and Service Office or Hewlett-Packard GmbH,
Department HQ-TRE, Herrenberger Straße 130, D-71034 Böblingen, Germany (FAX [phone]).
November 6, 1995 Jim White, QA Manager
HP E1418A User’s Manual 9

Notes
10 HP E1418A User’s Manual

Reader Comment Sheet
HP E1418A User’s Manual
Edition 2
You can help us improve our manuals by sharing your comments and suggestions. In appreciation of your time, we will
enter you in a quarterly drawing for a Hewlett-Packard Palmtop Personal Computer (U.S. government employees
cannot participate in the drawing).
Please list the system controller, operating system, programming language, and plug-in modules you are using.
Please pencil-in one circle for each statement below: Disagree Agree
•Thedocumentationiswellorganized. OOOOO
•
Instructionsareeasytounderstand. OOOOO
•The documentation is clearly written. OOOOO
•Examplesareclearanduseful. OOOOO
•Illustrationsareclearandhelpful. OOOOO
•Thedocumentationmeetsmyoverallexpectations. OOOOO
Please write any comments or suggestions below--be specific.
cut along this line
fold here
Your Name
Company Name
Job Title
Address
City, State/Province
Country
Zip/Postal Code
Telephone Number with Area Code
BUSINESS REPLY MAIL
FIRST CLASS PERMIT NO. 37 LOVELAND, CO
HEWLETT-PACKARD COMPANY
Learning Products Department
P.O. Box 301
Loveland, CO 80539-9984
NO POSTAGE
NECESSARY
IF MAILED
IN THE
UNITED STATES
Measurement Systems Division
fold here
Please fold and tape for mailing

12 HP E1418A User’s Manual

Chapter 1
Module Setup and Installation
Using This Chapter
This chapter provides general module information and tasks you must
perform to install and prepare your module. A procedure to verify your
installation is also given. The chapter is divided into the following sections:
•Module Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 13
•Functional Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 16
•Front Panel Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 18
•Setting the Logical Address Switch. . . . . . . . . . . . . . . . . . . . Page 19
•Module Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 20
•Terminal Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 22
•Wiring the Terminal Module . . . . . . . . . . . . . . . . . . . . . . . . . Page 23
•Attaching the Terminal Module. . . . . . . . . . . . . . . . . . . . . . . Page 25
•Removing the Terminal Module . . . . . . . . . . . . . . . . . . . . . . Page 26
•Terminal Module Options . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 27
•Terminal Module Connectors . . . . . . . . . . . . . . . . . . . . . . . . Page 30
•Configuring the Terminal Module. . . . . . . . . . . . . . . . . . . . . Page 31
•Terminal Module Connections . . . . . . . . . . . . . . . . . . . . . . . Page 33
•Initial Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 37
Module Description
The HP E1418A is an 8 or 16 channel digital-to-analog converter module
for use in a VXIbus C-size mainframe. The module is a register-based
device. The module can be programmed via direct register access or, with
the appropriate driver, by high level commands. This manual describes
programming the module using SCPI (Standard Commands for
Programmable Instruments) and the SCPI driver.
Each HP E1418A module is a unique instrument having its own output
buffer and error queue. Multiple modules cannot be combined into a single
instrument.
Each channel can be configured to either voltage or current output mode.
When configured for voltage output, voltages in the range of -16.0 to
+16.0 Volts can be set. When configured for current output, current in the
range of -0.02 to + 0.02 Amps can be set. The channel output mode can be
programmatically set, or, can be forced to either voltage or current by
mechanical jumpers on the terminal module.
Chapter 1 Module Setup and Installation 13

Each output channel is individually configurable to be either an isolated
output or a non-isolated output. Channel configuration to isolated or
non-isolated is made by individual plug-on modules for each channel.
Figure 1-1 shows the module.
Figure 1-1. The HP E1418A 8/16-Channel D/A Converter
with Terminal Module
14 Module Setup and Installation Chapter 1

Ordering Options The HP E1418A may be ordered from Hewlett-Packard in a variety of
configurations. As ordered, the module has the following options:
Description
HP E1418A 8-Channel D/A Converter with Non-Isolated Outputs
HP E1418A Option 001 16-Channel D/A Converter with Non-Isolated Outputs
HP E1418A Option 002 8-Channel D/A Converter with Isolated Outputs
HP E1418A Option 003 16-Channel D/A Converter with Isolated Outputs
Field Kits The module can also be user configured as described beginning on page 169
of this manual. The following field expansion and configuration kits are
available:
Description Use
HP E1523A Single Channel Isolated
plug-on module To change a single channel from non-isolated to isolated output.
HP E1524A Expansion kit, 8-Channel
Non-Isolated Outputs To add 8 additional non-isolated channels to an existing 8-channel
module.
HP E1525A Expansion kit, 8-Channel
Isolated Outputs To add 8 additional isolated channels to an existing 8-channel module.
Terminal Modules The standard HP E1418A Terminal Module provides screw terminals for
connections. Two other terminal options are available with the HP E1418A:
–Crimp and Insert (Option A3E)
–Ribbon Cable (Option A3H)
–Terminal Module Housing without a terminal module PC board or
connectors included (Option 135)
Chapter 1 Module Setup and Installation 15

Functional Description
The HP E1418A provides great flexibility in configuration. This functional
description will help you become familiar with the various configurations
and how the module is structured. A functional block diagram is shown in
Figure 1-2.
* Each channel MUST have either an isolated or non-isolated plug-on module installed. Channels may be configured
using any combination of Isolated and Non-Isolated plug-on modules.
Figure 1-2. A Functional Block Diagram
16 Module Setup and Installation Chapter 1

As shown, there are four major assemblies that make up an HP E1418A:
–Channels 1 through 8 main board and VXIbus backplane circuitry.
–Channels 9 through 16 expansion board.
–Isolated or Non-isolated plug-on modules.
–Terminal Module.
Channels 1–8 main board and VXIbus backplane circuitry.
This assembly contains all the VXIbus interface and decoding circuitry.
Isolated and Non-Isolated plug-on modules for channels 1–8 connect to this
assembly. The panel connectors for the terminal module are also mounted
on this assembly.
The optional Channels 9–16 expansion board is electrically connected and
mechanically mounted to the main board. Isolated and Non-Isolated
plug-on modules for channels 9–16 connect to this assembly.
Isolated or Non-isolated plug-on modules are required for every channel.
Eight plug-on modules mount to the main board and 8 plug-on modules
mount to the expansion board. Any combination of isolated or non-isolated
plug-on modules may be used, but every channel must have a plug-on
module installed.
The Terminal Module shown in Figure 1-2 is the standard screw-type
terminal module. This module provides screw connections for each channel
output, the calibration connections, and the external trigger in connections.
This module also contains two jumpers for each channel; one, called the P/J
Jumper, to enable or disable VXIbus programming of the channel mode
(either voltage or current) and one, called the V/I Jumper, to set the channel
mode when the P/J Jumper is in the Jumper position.
Chapter 1 Module Setup and Installation 17

Front Panel Connectors
Figure 1-3 shows the connections at the front panel connectors of the main
module.
Figure 1-3. HP E1418A Front Panel Connector Pinout
18 Module Setup and Installation Chapter 1

Setting the Logical Address Switch
Figure 1-4 shows the logical address switch location and setting. The logical
address switch factory setting is 72. Valid addresses range from 1 to 255.
When used with an HP Command Module the factory set address of
decimal 72 results in a module address of 9 (72 divided by 8). The module
address is used as a secondary address when using HP-IB and a Command
Module. For example, the module address may be 7 09 09, where 7 is the
HP-IB interface address, 09 is the command module address, and 09 is the
HP E1418A address.
The HP E1418A supports dynamic address configuration. When you set the
logical address to 255, the resource manager sets the logical address
programmatically.
Note When using an HP C-size mainframe with the HP E1405/E1406 Command
Modules, the logical address setting must be a multiple of 8.
Figure 1-4. Setting the Logical Address
Chapter 1 Module Setup and Installation 19

Module Installation
To install the module:
1. Verify the position of the CAL Store Enable Jumper for your
application. The Jumper, as shipped, is in the CAL position. In this
position, a calibration may be performed and the results stored in
non-volatile memory. In the Secured position, a calibration may be
performed, but may NOT be stored in non-volatile memory. This
jumper is described in more detail on page 159.
2. Verify or set the logical address switch as shown in Figure 1-4.
3. Install the module in a mainframe as shown in Figure 1-5.
Installation in a
Mainframe The HP E1418A may be installed in any slot (except slot 0) in a C-size
VXIbus mainframe. To install in a mainframe:
1. Set the extraction levers out. Slide the module into any slot (except
slot 0) until the backplane connectors touch.
2. Seat the module by moving the levers toward each other.
3. Tighten the top and bottom screws to secure the module in the
mainframe.
Figure 1-5. Installing the HP E1418A in a VXIbus Mainframe
20 Module Setup and Installation Chapter 1
