HP E1418A 8/16-Channel D/A Converter Service Manual
Edition 1
Click here to return to HP TS-5400 Systems On-Line Manuals Main Contents
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
WARNINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Safety Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Chapter 1, General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Safety Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Warnings and Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Module Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Module Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Module Serial Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Ordering Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Field Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Terminal Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Chapter 2, Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Initial Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Preparation for Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Prepare the Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Prepare the Terminal Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Prepare the Command Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Shipping Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Chapter 3, Operating Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Querying Module Identification and Configuration . . . . . . . . . . . . . . . . . . 19
Preventive Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Cleaning Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Operator’s Checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Chapter 4, Verification Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Test Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
About the Verification Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Functional Verification Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
HP E1418A 8/16-Channel D/A Converter Service Manual Contents 1

Quick Verification Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Performance Verification Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Performance Test Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
About Program Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Functional Verification Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Functional Verification Test Procedure . . . . . . . . . . . . . . . . . . . . . . . . 33
Functional Verification Test Example . . . . . . . . . . . . . . . . . . . . . . . . . 33
Performance Verification Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
DC Voltage Output Verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
DC Voltage Compliance Current . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
DC Voltage Short Circuit Output Current . . . . . . . . . . . . . . . . . . . . . . . 36
DC Current Verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Performance Verification Tests Example . . . . . . . . . . . . . . . . . . . . . . . 38
Performance Test Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Test Limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Measurement Uncertainty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Test Accuracy Ratio (TAR) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Chapter 5, Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Hewlett-Packard Calibration Services . . . . . . . . . . . . . . . . . . . . . . . . . 59
Calibration Interval . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Closed-Cover Electronic Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Calibration Constants and Non-Volatile Memory . . . . . . . . . . . . . . . . . . . 60
Making Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Adjustment Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Voltage Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Current Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Storing the Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Verify the Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Return the Module to Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Example Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Chapter 6, Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Equipment Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Service Aids . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Visual Checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Catastrophic Failures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Self-Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Single Channel Failures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Repair/Maintenance Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Electrostatic Discharge (ESD) Precautions . . . . . . . . . . . . . . . . . . . . . . 79
Surface Mount Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Chapter 7, Replaceable Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Assembly Exchange . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
2 HP E1418A 8/16-Channel D/A Converter Service Manual Contents

To Exchange an Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Chapter 8, Manual Changes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Appendix A, HP E1418A Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
HP E1418A 8/16-Channel D/A Converter Service Manual Contents 3

Notes
4 HP E1418A 8/16-Channel D/A Converter Service Manual Contents

Certification
Hewlett-Packard Company certifies that this product met its published specifications at the time of shipment from the factory. Hewlett-
Packard further certifies that its calibration measurements are traceable to the United States National Institute of Standards and Tech-
nology (formerly National Bureau of Standards), to the extent allowed by that organization’s calibration facility, and to the calibration
facilities of other International Standards Organization members.
Warranty
This Hewlett-Packard product is warranted against defects in materials and workmanship for a period of three years from date of ship-
ment. Duration and conditions of warranty for this product may be superseded when the product is integrated into (becomes a part of)
other HP products. During the warranty period, Hewlett-Packard Company will, at its option, either repair or replace products which
prove to be defective.
For warranty service or repair, this product must be returned to a service facility designated by Hewlett-Packard (HP). Buyer shall pre-
pay shipping charges to HP and HP shall pay shipping charges to return the product to Buyer. However, Buyer shall pay all shipping
charges, duties, and taxes for products returned to HP from another country.
HP warrants that its software and firmware designated by HP for use with a product will execute its programming instructions when
properly installed on that product. HP does not warrant that the operation of the product, or software, or firmware will be uninterrupted
or error free.
Limitation Of Warranty
The foregoing warranty shall not apply to defects resulting from improper or inadequate maintenance by Buyer, Buyer-supplied prod-
ucts or interfacing, unauthorized modification or misuse, operation outside of the environmental specifications for the product, or im-
proper site preparation or maintenance.
The design and implementation of any circuit on this product is the sole responsibility of the Buyer. HP does not warrant the Buyer’s
circuitry or malfunctions of HP products that result from the Buyer’s circuitry. In addition, HP does not warrant any damage that oc-
curs as a result of the Buyer’s circuit or any defects that result from Buyer-supplied products.
NO OTHER WARRANTY IS EXPRESSED OR IMPLIED. HP SPECIFICALLY DISCLAIMS THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
Exclusive Remedies
THE REMEDIES PROVIDED HEREIN ARE BUYER’S SOLE AND EXCLUSIVE REMEDIES. HP SHALL NOT BE LIABLE
FOR ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, WHETHER BASED ON CON-
TRACT, TORT, OR ANY OTHER LEGAL THEORY.
Notice
The information contained in this document is subject to change without notice. HEWLETT-PACKARD (HP) MAKES NO WAR-
RANTY OF ANY KIND WITH REGARD TO THIS MATERIAL, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WAR-
RANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. HP shall not be liable for errors contained
herein or for incidental or consequential damages in connection with the furnishing, performance or use of this material. This docu-
ment contains proprietary information which is protected by copyright. All rights are reserved. No part of this document may be photo-
copied, reproduced, or translated to another language without the prior written consent of Hewlett-Packard Company. HP assumes no
responsibility for the use or reliability of its software on equipment that is not furnished by HP.
U.S. Government Restricted Rights
The Software and Documentation have been developed entirely at private expense. They are delivered and licensed as "commercial com-
puter software" as defined in DFARS 252.227-7013 (Oct 1988), DFARS 252.211-7015 (May 1991) or DFARS 252.227-7014
(Jun 1995), as a "commercial item" as defined in FAR 2.101(a), or as "Restricted computer software" as defined in FAR 52.227-19 (Jun
1987) (or any equivalent agency regulation or contract clause), whichever is applicable. You have only thoserights provided for such Soft-
ware and Documentation by the applicable FAR or DFARS clause or the HP standard software agreement for the product involved.
HP E1418A 8/16 Channel D/A Converter Module Service Manual
Edition 1
Copyright © 1996 Hewlett-Packard Company. All Rights Reserved.
HP E1418A D/A Converter Module Service Manual 5

Frame or chassis ground terminal—typi-
cally connects to the equipment’s metal
frame.
Alternating current (AC).
Direct current (DC).
Indicates hazardous voltages.
Calls attention to a procedure, practice, or
condition that could cause bodily injury or
death.
Calls attention to a procedure, practice, or con-
dition that could possibly cause damage to
equipment or permanent loss of data.
Indicates the field wiring terminal that must
be connected to earth ground before operat-
ing the equipment—protects against electri-
cal shock in case of fault.
Instruction manual symbol affixed to prod-
uct. Indicates that the user must refer to the
manual for specific WARNING or CAU-
TION information to avoid personal injury
or damage to the product.
or
WARNINGS
The following general safety precautions must be observed during all phases of operation, service, and repair of this product.
Failure to comply with these precautions or with specific warnings elsewhere in this manual violates safety standards of design,
manufacture, and intended use of the product. Hewlett-Packard Company assumes no liability for the customer’s failure to
comply with these requirements.
Ground the equipment: For Safety Class 1 equipment (equipment having a protective earth terminal), an uninterruptible safety earth
ground must be provided from the mains power source to the product input wiring terminals or supplied power cable.
DO NOT operate the product in an explosive atmosphere or in the presence of flammable gases or fumes.
For continued protection against fire, replace the line fuse(s) only with fuse(s) of the same voltage and current rating and type.
DO NOT use repaired fuses or short-circuited fuse holders.
Keep away from live circuits: Operating personnel must not remove equipment covers or shields. Procedures involving the removal
of covers or shields are for use by service-trained personnel only. Under certain conditions, dangerous voltages may exist even with the
equipment switched off. To avoid dangerous electrical shock, DO NOT perform procedures involving cover or shield removal unless
you are qualified to do so.
DO NOT operate damaged equipment: Whenever it is possible that the safety protection features built into this product have been im-
paired, either through physical damage, excessive moisture, or any other reason, REMOVE POWER and do not use the product until
safe operation can be verified by service-trained personnel. If necessary, return the product to a Hewlett-Packard Sales and Service Of-
fice for service and repair to ensure that safety features are maintained.
DO NOT service or adjust alone: Do not attempt internal service or adjustment unless another person, capable of rendering first aid
and resuscitation, is present.
DO NOT substitute parts or modify equipment: Because of the danger of introducing additional hazards, do not install substitute
parts or perform any unauthorized modification to the product. Return the product to a Hewlett-Packard Sales and Service Office for
service and repair to ensure that safety features are maintained.
WARNING
CAUTION
Documentation History
All Editions and Updates of this manual and their creation date are listed below. The first Edition of the manual is Edition 1. The Edi-
tion number increments by 1 whenever the manual is revised. Updates, which are issued between Editions, contain replacement pages
to correct or add additional information to the current Edition of the manual. Whenever a new Edition is created, it will contain all of
the Update information for the previous Edition. Each new Edition or Update also includes a revised copy of this documentation his-
tory page.
Edition 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . August 1996
Safety Symbols
6 HP E1418A D/A Converter Module Service Manual

Declaration of Conformity
according to ISO/IEC Guide 22 and EN 45014
Manufacturer’s Name: Hewlett-Packard Company
Loveland Manufacturing Center
Manufacturer’s Address: 815 14th Street S.W.
Loveland, Colorado 80537
declares, that the product:
Product Name: 16 Channel 16 Bit D/A Converter
Model Number(s): HP E1418A
Product Options: All
conforms to the following Product Specifications:
Safety: IEC 1010-1 (1990) Incl. Amend 1 (1992)/EN61010-1 (1993)
CSA C22.2 #1010.1 (1992)
UL 3111
EMC: CISPR 11:1990/EN55011 (1991): Group1 Class A
IEC 801-2:1991/EN50082-1 (1992): 4kVCD, 8kVAD
IEC 801-3:1984/EN50082-1 (1992): 3 V/m
IEC 801-4:1988/EN50082-1 (1992): 1kV Power Line, 0.5kV Signal Lines
Supplementary Information: The product herewith complies with the requirements of the Low Voltage Directive
73/23/EEC and the EMC Directive 89/336/EEC (inclusive 93/68/EEC) and carries the "CE" marking accordingly.
Tested in a typical configuration in an HP C-size VXI mainframe.
European contact: Your local Hewlett-Packard Sales and Service Office or Hewlett-Packard GmbH, Department
HQ-TRE, Herrenberger Straße 130, D-71034 Böblingen, Germany (FAX [phone]).
November 6, 1995 Jim White, QA Manager
HP E1418A D/A Converter Module Service Manual 7

Notes
8 HP E1418A D/A Converter Module Service Manual

Chapter 1
General Information
Introduction
This manual contains information required to test, troubleshoot, and repair
the HP E1418A 8/16 Channel D/A Converter Module. See the HP E1418A
User’s Manual for additional module information. Figure 1-1 shows the
HP E1418A module.
Safety Considerations
This product is a Safety Class I instrument that is provided with a protective
earth terminal when installed in the mainframe. The instrument, mainframe,
and all related documentation should be reviewed for familiarization with
safety markings and instructions before operation or service.
Refer to the WARNINGS page (page 6) in this manual for a summary of
safety information. Safety information for preventive maintenance, testing,
adjusting, and service follows and is also found throughout this manual.
Figure 1-1. HP E1418A D/A Converter Module
Chapter 1 General Information 9

Warnings and
Cautions This section contains WARNINGS which must be followed for your
protection and CAUTIONS which must be followed to avoid damage
to the equipment when performing instrument maintenance or repair.
WARNING SERVICE-TRAINED PERSONNEL ONLY. The information in this
manual is for service-trained personnel who are familiar with
electronic circuitry and are aware of the hazards involved. To
avoid personal injury or damage to the instrument, do not
perform procedures in this manual or do any servicing unless
you are qualified to do so.
CHECK MAINFRAME POWER SETTINGS. Before applying
power, verify that the mainframe setting matches the line
voltage and that the correct fuse is installed. An uninterruptible
safety earth ground must be provided from the main power
source to the supplied power cord set.
GROUNDING REQUIREMENTS. Interruption of the protective
(grounding) conductor (inside or outside the mainframe) or
disconnecting the protective earth terminal will cause a
potential shock hazard that could result in personal injury.
(Grounding one conductor of a two-conductor outlet is not
sufficient protection.)
IMPAIRED PROTECTION. Whenever it is likely that instrument
protection has been impaired, the mainframe must be made
inoperative and be secured against any unintended operation.
REMOVE POWER IF POSSIBLE. Some procedures in this
manual may be performed with power supplied to the
mainframe while protective covers are removed. Energy
available at many points may, if contacted, result in personal
injury. (If maintenance can be performed without power applied,
the power should be removed.)
10 General Information Chapter 1

WARNING USING AUTOTRANSFORMERS. If the mainframe is to be
energized via an autotransformer (for voltage reduction) make
sure the common terminal is connected to neutral (that is, the
grounded side of the main’s supply).
CAPACITOR VOLTAGES. Capacitors inside the mainframe may
remain charged even when the mainframe has been
disconnected from its source of supply.
USE PROPER FUSES. For continued protection against fire
hazard, replace the line fuses only with fuses of the same
current rating and type (such as normal blow, time delay, etc.).
Do not use repaired fuses or short-circuited fuseholders.
SHOCK HAZARD. Only service-trained personnel who are
aware of the hazards involved should install, remove, or
configure the module. Before you remove any installed module,
disconnect AC power from the mainframe and from other
modules that may be connected to the module.
CHANNEL WIRING INSULATION. All channels that have a
common connection must be insulated so that the user is
protected from electrical shock. This means wiring for all
channels must be insulated as though each channel carries the
voltage of the highest voltage channel.
CAUTION MAXIMUM VOLTAGE. The maximum voltage that can be applied to
any channel is 42 V Peak/42 Vdc. The maximum voltage from any
channel to ground is 42 V Peak/42 Vdc.
STATIC ELECTRICITY. Static electricity is a major cause of
component failure. To prevent damage to the electrical components in
the module, observe anti-static techniques whenever working on the
device.
PARTS REMOVAL. This module uses a surface mount printed circuit
assembly. Special soldering equipment is required for parts removal or
replacement. Use of standard soldering equipment will cause damage
to the printed circuit board and is not covered under warranty.
Chapter 1 General Information 11

Module Description
The HP E1418A is an 8 or 16 channel digital-to-analog converter module
for use in a VXIbus C-size mainframe. The module is a register based
device. The module can be programmed via direct register access or, with
the appropriate driver, by high level commands. This manual describes
programming the module using SCPI (Standard Commands for
Programmable Instruments) and the SCPI driver.
Each HP E1418A module is a unique instrument having its own output
buffer and error queue. Multiple modules can not be combined into a
single instrument.
Each channel can be configured to either voltage or current output mode.
When configured for voltage output, voltages in the range of -16.0 V to
+16.0 V can be set. When configured for current output, current in the
range of -0.02 to + 0.02 Amps can be set. The channel output mode can
be programmatically set, or, can be forced to either voltage or current by
mechanical jumpers on the terminal block.
Each output channel is individually configurable to be either an isolated
output or a non-isolated output. Channel configuration to isolated or
non-isolated is made by individual plug-on modules for each channel.
Module
Specifications Specifications are listed in Appendix A of this manual and in the
HP E1418A User’s Manual. These specifications are the performance
standards or limits against which the module may be tested.
Module Serial
Numbers Devices covered by this manual are identified by a serial number prefix
listed on the title page. Hewlett-Packard uses a two-part serial number in
the form USXXXXYYYYY, where US is the country of origin, XXXX is
the serial prefix, and YYYYY is the serial suffix. The serial number prefix
identifies a series of identical instruments. The serial number suffix is
assigned sequentially to each instrument. The serial number plate is located
on the right-hand shield near the backplane connectors.
12 General Information Chapter 1

Ordering Options The module may be ordered from Hewlett-Packard in a variety of
configurations. As ordered, the module may have the following options:
Description
HP E1418A 8-Channel D/A Converter with Non-Isolated Outputs
HP E1418A
Option 001 16-Channel D/A Converter with Non-Isolated Outputs
HP E1418A
Option 002 8-Channel D/A Converter with Isolated Outputs
HP E1418A
Option 003 16-Channel D/A Converter with Isolated Outputs
Field Kits The module can also be user configured. The following field expansion
and configuration kits are available. Each field kit contains installation
instructions.
Description Use
HP E1523A Single Channel Isolated
plug-on module To change a single channel from non-isolated to isolated
output.
HP E1524A Expansion kit, 8-Channel
Non-Isolated Outputs To add 8 additional non-isolated channels to an
existing 8-channel module.
HP E1525A Expansion kit, 8-Channel
Isolated Outputs To add 8 additional isolated channels to an existing
8-channel module.
Terminal Modules The standard HP E1418A Terminal Module provides screw terminals for
connections. Two other terminal options are available with the HP E1418A:
•Crimp and Insert (Option A3E)
•Ribbon Cable (Option A3H)
Chapter 1 General Information 13

Recommended
Test Equipment Table 1-1 lists the test equipment recommended for testing and servicing
the module. Essential requirements for each piece of test equipment are
described in the Requirements column.
Table 1-1. Recommended Test Equipment
Instrument Requirements Recommended
Model Use*
Controller, HP-IB HP-IB compatibility as defined by
IEEE Standard 488-1988 and the
identical ANSI Standard MC1.1:
SH1, AH1, T2, TE0, L2, LE0, SR0,
RL0, PP0, DC0, DT0, and C1, 2, 3, 4, 5.
HP 9000 Series 300 F,O,P,T
Mainframe Compatible with the HP E1418A E1400B/T,
E1401A/T, or
E1401B
F,O,P,T
Command
Module, VXILink,
EPC7 Embedded
Controller
Compatible with Module
Resource manager in Slot 0
Logical address 0
Typical HP-IB address 9
Requires the downloaded driver
“E1418”
E1405B or E1406A/B F,O,P,T
Digital Multimeter
5 1/2 or 6 1/2 digit Voltage measurements to ±16.8 Vdc Current measurements to ±0.02 A
Four-wire resistance measurements
from 50 Ωto 500 Ω
HP 3458A or
HP 34401A O, P, T
Terminal Module Compatible with the HP E1418A HP E1418-60101 O, P,T
Resistor 10 kΩ, 1%, 0.25 W, metal film Any available
supplier meeting the
requirements
P
Resistor 600 Ω, 1%, 0.25 W, metal film P
User’s Manual E1418-90001 F,O,P,T
*F = Functional Verification Tests, O = Operation Verification Tests, P = Performance Verification Tests, T = Troubleshooting
14 General Information Chapter 1

Chapter 2
Installation
Introduction
This chapter contains the following topics:
•Initial Inspection
•Preparation for Use
•Environment
•Shipping Guidelines
Initial Inspection
Inspect the shipping container for damage. If the shipping container or
cushioning material is damaged, keep the container until the shipment
contents have been checked and the module has been checked mechanically
and electrically. Chapter 4 of this manual gives procedures to check the
electrical performance.
WARNING To avoid possible hazardous electrical shock, do not perform
electrical tests if there are signs of shipping damage to any
portion of the outer enclosure (covers, panels, etc.).
If the contents are incomplete, if there is mechanical damage or defect, or if
the module does not pass the electrical performance tests, notify your
nearest Hewlett-Packard Sales and Service Office. If the shipping container
is damaged or the cushioning material shows signs of stress, notify the
carrier as well as Hewlett-Packard. Keep the shipping materials for the
carrier’s inspection.
Chapter 2 Installation 15

Preparation for Use
Chapter 1 of the HP E1418A User’s Manual contains complete instructions
for installing the module in a mainframe and installing a terminal module.
Refer to the mainframe user’s manual, command module user’s manual, and
the Installing Device Drivers installation note to prepare the mainframe.
Prepare the Module Verify or set the module’s logical address. Refer to the HP E1418A User’s
Manual for instructions. In this manual the factory default logical address
of 72 is used.
To prepare the module for the adjustment procedures in Chapter 5, set or
verify the position of the CAL Secure Enable Jumper before installing the
module in the mainframe. (The jumper is factory set to CAL.) Figure 5-2 on
page 62 shows this jumper.
Prepare the
Terminal Module The procedures in this manual show the screw-type terminal module. To
prepare this terminal module, you will need to set the jumpers and make
connections. If you are using other types of terminal modules, consult the
HP E1418A User’s Manual for proper connections.
Terminal Module
Jumpers The screw-type terminal module contains jumpers that control how the
HP E1418A operates. To prepare the module for the Verification Tests in
Chapter 4 and Adjustments in Chapter 5, the terminal module jumpers must
be set to allow the module to be programmed from the backplane. The
HP E1418A will operate without any jumpers installed. Figure 2-1 shows
the jumper locations and example settings.
There are two jumpers for each channel; a P/J jumper and a V/I jumper.
The two jumpers work together.
The P/J jumper sets the channel output mode to be either Program
Selectable or Jumper Selectable. When the jumper is in the program
selectable position, the channel output mode can be set via programming
commands. The program selectable position is recommended for the
Verification Tests and Adjustment procedures in this manual. In the jumper
selectable position, the channel output mode is set via the V/I jumper.
The V/I jumper sets the channel output mode to either voltage or current
when the P/J jumper is set to the Jumper Selectable position. When the P/J
jumper is set to Program Selectable, this jumper has no effect.
16 Installation Chapter 2

Note With no jumpers installed, the module will be in the Program Selectable
output mode.
•If you are using a terminal module dedicated to testing the HP E1418A,
you can remove all the jumpers or put the jumpers in the storage
position.
•If you are using the end-user’s terminal module, record the positions of
the jumpers. Set the P/J jumpers to the programmable position. Before
returning the module to use, restore the P/J jumpers to their original
position.
Terminal Module
Connections The Verification Tests require four-wire connections at each channel. The
Adjustment procedures can be performed using a single connections at the
CAL terminals. Additional connection information is given in the
procedures in Chapters 4 and 5 of this manual.
Prepare the
Command Module All verification and adjustment procedures in this manual use SCPI
(Standard Commands for Programmable Instruments). Prepare the
command module by downloading the SCPI driver named “E1418".
Downloading instructions are given in the Installing Device Drivers
installation note.
Figure 2-1. P/J and V/I Jumpers
Chapter 2 Installation 17

Environment
The recommended operating altitude for the module is 2000 m (6000 ft) or less.
The recommended operating environment for the module is:
Environment Temperature Humidity
Operating 0
oC to + 55 oC <65% relative (0 oC to + 40 oC)
non condensing
Storage and
Shipment – 40 oC to + 75 oC <65% relative (0 oC to + 40 oC)
non condensing
Shipping Guidelines
If you need to return the HP E1418A to Hewlett-Packard, first remove any
terminal modules before packaging for shipment. Attach a tag to the module
identifying the owner and indicating the service or repair required. Mark the
shipping container “FRAGILE”. If you are exchanging a module, read
Assembly Exchange beginning on page 85.
In any correspondence, refer to the module by model number and full serial
number.
Hewlett-Packard recommends using shipping containers and materials
identical to those used by the factory. These materials are available through
Hewlett-Packard Sales and Service Offices.
If you use commercially available shipping materials, place the module in
an anti-static bag and wrap the module in heavy paper or plastic. Use a
strong shipping container. A double wall carton of 2400 Pa (350 psi) test
material is adequate.
Use enough shock-absorbing material (layer at least 75 mm to 110 mm,
3 in to 4 in) around the module to provide firm cushion and to prevent
movement in the container. Protect the front panel with cardboard. Seal the
container securely and mark the container “FRAGILE”.
18 Installation Chapter 2

Chapter 3
Operating Information
Introduction
This chapter provides operating information, preventive maintenance
instructions, and operators checks.
Operation
The HP E1418A User’s Guide is your reference for module operation.
The User’s Guide contains information about module setup, application
examples, and a complete SCPI command reference.
Querying Module
Identification and
Configuration
This example will query the module for the identification string and
determine the module configuration.
The module identification is obtained using the IEEE-488 Command
Command *IDN?.
/* Send query to the module*/
*IDN?
/* Enter a string*/
The string returned will be similar to one of the following:
HEWLETT-PACKARD,E1418A_8CH,xxxxxxxxxx,A.01.00
or
HEWLETT-PACKARD,E1418A_16CH,xxxxxxxxxx,A.01.00
The xxxxxxxxxx portion of the response string is the module serial number.
The number of channels in the module (8 or 16) is indicated by the
E1418A_8CH or E1418A_16CH portion of the returned string.
Chapter 3 Operating Information 19

The module configuration is obtained using the
DIAGnostic:CONFiguration? query.
/* Send query to the module*/
DIAG:CONF?
/* Enter six integers and decode the integers*/
The DIAG:CONF? query returns six integers. The six integers returned
contain the module configuration and have the following meaning.
Integer
Returned Meaning
1st Expansion Board ID in the form: 0 = present, 7 = none
(expansion board contains channels 9 through 16)
2nd Terminal Module ID in the form
0 = screw type, 7 = none or other
3rd Isolated/Non-isolated Channel status
A bit set to 0 indicates an isolated channel
A bit set to 1 indicates a non-isolated channel or no plug-on
module installed (DO NOT operate the module without a plug-on
module)
Bits 0 – 15 correspond to channels 1 – 16, respectively*
4th Channel Mode
A bit set to 0 indicates a current output channel
A bit set to 1 indicates a voltage output channel
Bits 0 – 15 correspond to channels 1 – 16, respectively*
5th Channel Output State
A bit set to 0 indicates the channel output relay is closed
A bit set to 1 indicates the channel output relay is open
Bits 0 – 15 correspond to channels 1 – 16, respectively*
6th Channel Mode Programmable State (P/J Jumper)
A bit set to 0 indicates a channel is not mode programmable
A bit set to 1 indicates a channel is mode programmable
Bits 0 – 15 correspond to channels 1 – 16, respectively*
* For 8-channel configurations, the upper 8 bits of integers 3, 4, 5, and 6 are set to 1’s.
20 Operating Information Chapter 3
