HP ProCurve Networking J8462A User manual

61195864L1-13B, April 2005 www.procurve.com Copyright 2005 Hewlett-Packard Development Company, LP
Quick Start Guide 5991-2108
ProCurve Secure Router dl Analog Modem Backup Module
J8462A
SPECIFICATIONS
Features ITU V.90 Compliant
Async
Standards FCC Part 15 Class A, EN 55022 Class A, EN 61000-3-2,
EN 61000-3-3
ETSI TBR 21, IC CS-03, ACTA/FCC Part 68, AS/ACIF S002
UL/CUL 60950, AS/NZS 60950, EN 60950, IEC 60950
Physical Dimensions: 6.35cm (2.5 in) W x 9.53cm (3.75 in) D
Operating Temperature: 0°C to 50°C (32°F to 122°F)
Relative Humidity: Up to 95 percent, noncondensing at 30°C
(86°F)
Non-Operating Temperature: -20°C to 70°C (-4°F to 158°F)
Non-Operating Relative Humidity: Up to 95 percent,
noncondensing at 30°C (86°F)
Altitude: Up to 3.05 km (10,000 ft)
Eth 0/1
Eth 0/2
dl
3
P/N: J8462A
US: PNBMM04AJ8462
IC: 2250A-J8462
ITE
32F8
P/N: J8462A
US: PNBMM04AJ8462
IC: 2250A-J8462
ITE
32F8
2
P/N:J8462A
US:PNBMM04AJ8462
IC:2250A-J8462
ITE
32F8
1
INSTALLATION INSTRUCTIONS
1. Remove power from the base unit.
2. If the ProCurve Router interface module is already installed in the
ProCurve Secure Router chassis, release the screws at both
edges of the module front panel and slide the module out of the
chassis.
3. Carefully align the P1 connector on the interface module with the
J1 connector on the backup module. Using only fingertip pressure
so that neither circuit board bends or flexes, ensure that the
connectors are firmly seated. Secure the backup module to the
interface module using the screws and standoff posts supplied.
4. Slide the interface module with the backup module attached into
the ProCurve Secure Router option slot until the module is firmly
seated against the chassis.
5. Secure the screws at both edges of the module.
6. Connect the cables to the associated device(s).
7. Complete installation of the base unit.
8. Restore power to the base unit.
ANALOG MODEM BACKUP (RJ-11) CONNECTION PINOUT
Pin Name Description
1-3 — Unused
4 R Network-Ring
5TNetwork-Tip
6-8 — Unused
Note For safety information for the routers and all modules,
please refer to the safety and ESD precautions in the
ProCurve Secure Router Installation Guide included
in your router shipment.

61195864L1-13B, April 2005 Printed in the USA Copyright 2005 Hewlett-Packard Development Company, LP
Quick Start Guide 5991-2108
ProCurve Secure Router dl Analog Modem Backup
Module
ANALOG MODEM BACKUP MODULE COMMANDS
alias <text>
Comment line to provide the text name assigned by the SNMP network
management system.
caller-id override always <number>
Forces a replacement of the incoming caller ID number with the number
given. The received caller ID, if any, is discarded, and the given override
number is used to connect the incoming call to a circuit of the same number.
Use no caller-id override (default) to disable any caller ID overrides.
caller-id override if-no-CID <number>
Allows a replacement of the received caller ID number, but only if there is no
caller ID available on the incoming call. The received caller ID, if available,
is used to connect the call. However, if no caller ID is received, the given
override number is used to connect the incoming call to a circuit of the same
number.
description <text>
Comment line to provide an identifier for this interface (for example, circuit
ID, contact information, etc.).
<text> Shows up to 80 alphanumeric characters.
dialin
Enables the modem for remote console dialin disabling the use of the
modem for backup.
init-string <string>
Specifies an initialization string for the modem using standard AT
commands.
<string> Initialization string using standard AT
commands. The default string is
ATE0Q0V1X4\N0.
shutdown
Turns off the interface. By default, all interfaces are disabled. Use the no
shutdown command to enable the interface and allow it to pass data.
Note This command list is an illustration of available
commands. For complete command descriptions and
default values, refer to the SROS Command Line
Interface Reference Guide provided on your ProCurve
SROS Documentation CD.
