User’s Guide
1825 Flat Panel Monitor
Document Part Number: 305223-001
August 2002

© 2002 Hewlett-Packard Company
Compaq and the Compaq logo are trademarks of Compaq Information
Technologies Group, L.P. in the U.S. and other countries.
All other product names mentioned herein may be trademarks of their
respective companies.
Hewlett-Packard Company shall not be liable for technical or editorial
errors or omissions contained herein or for incidental or consequential
damages in connection with the furnishing, performance, or use of this
material. The information in this document is provided “as is” without
warranty of any kind, including, but not limited to, the implied warranties
of merchantability and fitness for a particular purpose, and is subject to
change without notice. The warranties for HP products are set forth in the
express limited warranty statements accompanying such products. Nothing
herein should be construed as constituting an additional warranty.
This document contains proprietary information that is protected by
copyright. No part of this document may be photocopied, reproduced, or
translated to another language without the prior written consent of
Hewlett-Packard Company.
ÅWARNING: Text set off in this manner indicates that failure to
follow directions could result in bodily harm or loss of life.
ÄCAUTION: Text set off in this manner indicates that failure to follow
directions could result in damage to equipment or loss of information.
User’s Guide
1825 Flat Panel Monitor
First Edition (August 2002)
Document Part Number: 305223-001

User’s Guide 1
Product Features
The 1825 Flat Panel Display has an active matrix, thin-film
transistor (TFT), liquid crystal display (LCD). The monitor
features include:
■Large 18.1-inch (45.9 cm) viewable area display.
■1280 × 1024 native resolution, plus full-screen support for
lower resolutions.
■Wide viewing angle to allow viewing from a sitting or
standing position, or moving side-to-side.
■Tilt and swivel adjustment capabilities.
■Removable base for flexible mounting solutions.
■Multiple video inputs supported:
❏VGA Analog
❏DVI-I supports either Analog or Digital signal input
■VGA analog and DVI-Digital signal cables included.
■Plug and play capability if supported by your system.
■On-Screen Display (OSD) adjustments in English, French,
German, Italian, Spanish, and Simplified Chinese for ease of
set-up and screen optimization.
■Software and Reference Library CD includes an information
file (INF), Image Color Matching file (ICM), and product
documentation.
■Energy Saver feature for Energy Star compliance.
■AssetControl
■Compliant with the following regulated specifications:
❏EPA ENERGY STAR
❏European Union CE Directives

2 User’s Guide
❏Swedish MPR II 1990
❏Swedish TCO '99
Installing the Information Files
The CD-ROM included with this monitor contains two
information files to be installed onto your computer; an .INF file
and an .ICM file.
■The .INF file defines monitor resources and provides
specifications used by most operating systems to install
support software for certain hardware devices. The .INF file
ensures monitor compatibility and optimization with your
computer’s graphics adapter. INF files are downloadable by
clicking on: www.hp.com/go/support and selecting the desired
monitor.
■The .ICM file provides color matching consistency from
monitor screen to printer and is activated from within
graphics programs that have this feature.
To install these files on your computer, insert the Software and
Reference Library CD in your computer CD-ROM drive. When
the CD menu launches, select Install INF and ICM Files and
follow the on-screen instructions.
Setting Up the Monitor
To set up the monitor, ensure that the power is turned off to the
monitor, computer system, and other attached devices, then
follow these steps:
1. Place the monitor in a convenient, well-ventilated location
near your computer.
2. Connect the monitor signal cable to the video connector on
the rear panel of the computer.

User’s Guide 3
✎The DVI-D cable supplied with this monitor is for digital-
to-digital connection only. Your computer must have a
DVI-compatible graphics card installed for use with this cable.
When connecting the DVI-D signal cable to the DVI connector
on the monitor, you must connect the other end of the DVI-D
cable to the DVI connector on the computer.
3. Connect the monitor signal cable to the back of the monitor.
4. Connect the power cable to the back of the monitor.
5. Connect the power cable to an electrical wall outlet.

4 User’s Guide
6. Adjust the monitor as needed for your comfort using the
monitor’s tilt, swivel, and height adjustment capabilities.
✎You can change your monitor’s viewing position to portrait. To
rotate your display to the portrait position, you will need to install
the Pivot software, which is contained on the CD included with
your monitor.

User’s Guide 5

6 User’s Guide
ÅWARNING: To reduce the risk of electric shock or damage to your
equipment: Do not disable the power cord grounding plug. The
grounding plug is an important safety feature.
Plug the power cord into a grounded (earthed) electrical outlet that is
easily accessible at all times.
Disconnect power from the monitor by unplugging the power cord
from the electrical outlet.
Do not place anything on power cords or cables. Arrange them so
that no one may accidentally step on or trip over them. Do not pull on
a cord or cable. When unplugging from the electrical outlet, grasp
the cord by the plug.
ÄCAUTION: Burn-in image damage may occur on monitors that
display the same static image on screen for a prolonged period of
time. To avoid burn-in image damage on your monitor screen, you
should always activate a screen saver application or turn off the
monitor when it is not in use for a prolonged period of time.
Selecting the Signal Connectors and Cables
There are two signal input connectors: one VGA connector and
one DVI-I connector. The monitor will automatically determine
which inputs have valid video signals. The inputs can be selected
via the On-Screen Display (OSD) feature or by pressing the
Signal Input Selection control on the monitor front bezel.
The video mode supported by the DVI-I connector is determined
by the video cable used. For digital operation, use the DVI-D to
DVI-D signal cable provided. For analog operation, a DVI-I to
VGA signal cable must be attached to the DVI-I input (not
provided with the monitor).

User’s Guide 7
Removing the Monitor Base
You can remove the monitor base to mount the monitor on a wall,
a swing arm or other mounting fixture. To remove the monitor
from the base, read the caution and warning below before
beginning the procedure.
ÄCAUTION: Before beginning to disassemble the monitor, be sure
the monitor is turned off and the power and signal cables are both
disconnected.
Lay the front bezel down on a soft area to prevent it from getting
scratched, defaced, or broken
ÅWARNING: Do not remove the base from the monitor while the
monitor is in the upright position. Before removing the monitor from
the base, ensure that the monitor is lying flat, front bezel down, and
that the base is set to the maximum base extension. Attempting to
remove the monitor from the base while upright in the minimum base
extension may result in injury to the user.
1. Disconnect and remove the signal and power cables from the
back of the monitor.

8 User’s Guide
2. Remove the four screws as shown in the following
illustration.
ÄCAUTION: Ensure that the bottom of the monitor base is positioned
over a table or desktop before removing the base from the monitor.
3. Remove the monitor base from the monitor.
Mounting the Monitor
1. Remove the monitor base. Refer to “Removing the Monitor
Base” steps in the previous section.
When the base is removed, four threaded mounting holes are
exposed on the monitor panel to be used for mounting purposes.
These mounting holes are spaced 100 mm apart and are
compliant with the Video Electronics Standards Association
(VESA) standard for mounting flat panel displays.

User’s Guide 9
2. Mount the monitor to a swing arm or other mounting fixture
by following the instructions included with the mounting
fixture to be used.
Operating the Monitor
Front Panel Controls
No. Control Function
1Auto button Automatically adjusts the
displayed image
2Input button Allows you to switch to and from
the VGA and DVI-I video signal
inputs when the OSD is off.
3Menu Navigates through the OSD
option icons and adjusts settings.

10 User’s Guide
4Brightness • Adjust brightness up and
down (when the OSD is off).
• Use the up and down buttons
to navigate through the OSD
menus when the OSD is on.
5Power LED Illuminates green when the
monitor is on and turns amber
when the monitor is in a power
saver mode.
6Power Switch Turns the monitor on and off
Front Panel Controls
No. Control Function

User’s Guide 11
On-Screen Display Settings
The adjustments for screen settings are located in the on-screen
display (OSD). Press the menu button on the monitor's front panel
to view the OSD menu in one of seven available languages. The
following table shows the menus and their functions at each level:
OSD Menu Levels
Menu Level
1
Menu Level
2
Menu Level
3
Menu Level
4
Adjust Position Horizontal
Vertical
Brightness &
Contrast
Brightness
Contrast
Video Noise Phase
Clock
Adjust Color Original Panel
Color
9300K for
CAD/CAM
6500K for
Management
User Preset Red
Green
Blue
OSD Settings Horizontal
Vertical
Product
Information
Serial No.
Resolution

12 User’s Guide
✎The Video Noise OSD selection is not available when the monitor
is operating in the DVI-D (digital) mode.
Adjusting Monitor Settings
On the front panel controls of your monitor, once you press the
menu button, the On Screen Display (OSD) Main Controls
window will pop up and you can now start making adjustments to
your monitor’s various features. Use the left, right, up, and down
arrow keys in the menu window to make your adjustments.
Video Input
Reset to Factory
Setting
No
Yes
Input Selection Analog (D-Sub)
Digital (DVI)
Analog (DVI)
Exit Main
Controls
OSD Menu Levels
Menu Level
1
Menu Level
2
Menu Level
3
Menu Level
4

User’s Guide 13
Adjusting Screen Quality
Allow the monitor to warm up for 20 minutes before performing
the following procedures.
The Auto Adjustment feature automatically fine-tunes the image
quality each time a new video mode is utilized. If additional
improvement is desired, select the Auto Adjust control on the
front bezel.
For more precise adjustments, use the adjustment pattern
provided on the CD-ROM, and adjust the clock and phase
settings (accessed from the OSD menu) as described in the
following section.

14 User’s Guide
Optimizing Digital Conversion
This monitor contains advanced circuitry that allows the flat
panel screen to function like a standard monitor. Two controls in
the on-screen display can be adjusted to improve image
performance: Clock and Clock Phase. Use these controls only
when the auto adjust function does not provide a satisfactory
image.
✎The Clock must first be set correctly since the Clock Phase
settings are dependent on the main Clock setting.
■Clock—Increase/decrease the value to minimize any vertical
bars or stripes visible on the screen background.
■Clock Phase—Increase/decrease the value to minimize video
distortion or video jitter.
✎When using the controls, you will obtain the best results by using
the adjustment pattern application provided on the CD-ROM.
✎When adjusting the Clock and Clock Phase values, if the monitor
images become distorted, continue adjusting the values until the
distortion disappears. To restore the factory settings, select Yes
from the Factory Reset menu in the on-screen display.
Recognizing Preset Display Resolutions
The display resolutions listed below are the most commonly used
modes and are set as factory defaults. This monitor automatically
recognizes these preset modes and they will appear properly sized
and centered on the screen.

User’s Guide 15
Entering User Modes
The video controller signal may occasionally call for a mode that
is not preset if:
■You are not using a standard graphics adapter.
■You are not using a preset mode.
If this occurs, you may need to readjust the parameters of the
monitor screen by using the on-screen display. Your changes can
be made to any or all of these modes and saved in memory. The
monitor automatically stores the new setting, then recognizes the
Factory Preset Display Modes
Preset Pixel Format Horz Freq (kHz) Vert Freq (Hz)
1 640 x 350 31.5 70.0
2 720 x 400 31.5 70.0
3 640 x 480 31.5 60.0
4640x480 37.9 72.0
5640x480 37.5 75.0
6800x600 35.2 56.0
7 800 x 600 37.9 60.0
8 800 x 600 46.9 75.0
9832x624 49.7 75.0
10 1024 x 768 48.4 60.0
11 1024 x 768 60.0 75.0
12 1152 x 870 69.0 75.0
13 1280 x 1024 63.9 60.0
14 1280 x 1024 80.0 75.0
15 1600 x 1200 75.0 60.0

16 User’s Guide
new mode just as it does a preset mode. In addition to the 15
factory preset modes, there are four user modes that can be
entered and stored.
Energy Saver Feature
When the monitor is in its normal operating mode, the monitor
uses less than 60 watts of power and the Power light is green.
The monitor also supports a reduced power state. The reduced
power state will be entered into if the monitor detects the absence
of either the horizontal sync signal and/or the vertical sync signal.
Upon detecting the absence of these signals, the monitor screen is
blanked, the backlight is turned off, and the Power light is turned
amber. When the monitor is in the reduced power state, the
monitor will utilize less than 5 watts of power. There is a brief
warm up period before the monitor will return to its normal
operating mode.
Refer to your computer manual for instructions on setting energy
saver features (sometimes called power management features).
✎The above energy saver feature only works when connected to
computers that have energy saver features.
By selecting settings in the monitor’s Energy Saver utility, you
can also program the monitor to enter into the reduced power
state at a predetermined time. When the monitor’s Energy Saver
utility causes the monitor to enter the reduced power state, the
Power light blinks amber.
Care and Maintenance
Use the following guidelines to care for and maintain your
monitor during normal everyday use.

User’s Guide 17
Protecting the Monitor
To protect your monitor from overheating and other types of
damage:
■Use only a power source and connection appropriate for this
monitor, as indicated on the marking label/back plate and the
AC adapter.
■If an extension cord or power strip is used, make sure that the
cord or strip is rated for the product and that the total ampere
ratings of all products plugged into the extension cord or
power strip do not exceed 80% of the extension cord or strip
ampere ratings limit.
■Do not overload an electrical outlet, power strip, or
convenience receptacle. The overall system load must not
exceed 80% of the branch circuit rating. If power strips are
used, the load should not exceed 80% of the power strip input
rating.
■Install the monitor near an outlet that you can easily reach.
Disconnect the product by grasping the plug firmly and
pulling it from the outlet. Never disconnect it by pulling the
cord.
■Unplug the monitor from the wall outlet before cleaning. Do
not use liquid cleaners or aerosol cleaners.
■Slots and openings in the cabinet are provided for ventilation.
These openings must not be blocked or covered. Never push
objects of any kind into cabinet slots or other openings.
■Do not drop the monitor or place it on an unstable surface.
■Do not allow anything to rest on the power cord. Do not walk
on the cord.

18 User’s Guide
■Keep the monitor in a well-ventilated area, away from
excessive light, heat, and moisture. Keep the monitor away
from high capacity transformers, electric motors, and other
strong magnetic fields.
■Do not open the monitor cabinet or attempt to service this
product yourself. Adjust only those controls that are covered
by the operating instructions. If the monitor is not operating
properly or has been dropped or damaged, contact your
authorized dealer, reseller, or service provider.
Cleaning the Monitor
To clean the monitor, follow these steps:
1. Turn off the monitor and the computer.
2. Dust the monitor by wiping the screen and the cabinet with a
soft, clean cloth.
If the screen requires additional cleaning, use a clean cloth
dampened with isopropyl alcohol.
ÄCAUTION: Do not use benzene, thinner, ammonia, or any volatile
substance to clean the monitor screen or cabinet. These chemicals
may damage the monitor. Never use water to clean an LCD screen.
Shipping the Monitor
Keep the original packing box in a storage area. You may need it
later if you move or ship your monitor.
