HP 2711x 27-inch LED Monitor
Bigger just got better with a breathtaking 27-inch screen
fused with high screen performance.
• Full HD 1920 X 1080 resolution
• 3,000,000:1 Dynamic Contrast Ratio
• LED backlighting
• Ultra-slim 27-inch diagonal montor
Maximize Your Visual Experience
Envision a 27-inch panoramic view, a strikingly thin
monitor combined with high screen performance and
features to help you be environmentally responsible.
Inspiration becomes a reality with the HP 2711x 27-inch
diagonal LED monitor. Bigger can be better with this
dazzling monitor and convenient attributes:
• Ultra-slim 27-inch LED monitor (approximately1-inch
deep) looks perfect on any desktop
• VGA and HDCP Supported DVI-D and HDMI inputs
easily connect to all your digital applications, HP PC or
notebook
• Stylish, sleek exterior with tilt and slide adjustment for a
comfortable view
• 170/160 degree viewing angles
The Advantages of LED
As small solid state devices, LED (Light Emitting Diode)
backlighting delivers a variety of benefits over traditional
CCFL (cold cathode fluorescent lamp) panels:
• Reduces the number and overall size of components for
an exceptionally thin monitor
• Creates deeper blacks for ultra-high dynamic contrast
ratio
• LED backlights turn on quicker than CCFL panels
• Helps reduce our environmental impact
Spectacular Screen Appeal
Take in sharp, detailed imagery in Full HD(1) while surfing
the Internet, working on projects, editing videos, or
streaming shows online with screen performance features
that include:
• 3,000,000:1 Dynamic Contrast Ratio(3)
• Full HD(1) 1920 X 1080 resolution
• BrightView technology to help reduce glare
• QuickView modes optimized to match screen
performance with the content of your choice
• 300 nits of Brightness (maximum)
• 5 ms on/off response time reduces blur
• 72% color gamut
Designed with the Environment in Mind
The HP 2711x monitor provides a variety of solutions to
help you reduce your environmental impact. Take steps to
“go green” with:
• Mercury-free LED backlighting helps lower power
consumption
• Arsenic-free(2) display glass
• Recyclable plastics and packaging to reduce our
environmental impact
• Ultra-thin profile and detachable base allow smaller
packaging to fit more product on a truck, thereby
helping to lower fuel use and CO2 emissions
• ENERGY STAR® 5.0 qualified
• EPEAT® Silver registered
• SmartWaySM Transport Partnership
Relax with HP Reliability
Backed by award-winning HP worldwide service and
support, your needs are covered. The HP 2711x monitor
is fully tested and has a limited warranty that includes
parts, labor, toll-free technical support and real-time chat.

HP 2711x 27-inch LED Monitor
All specifications represent the typical specifications provided by HP’s component manufacturers; actual performance may vary either higher or lower.
(1) HD content required to view HD images. (2) Arsenic and its compounds were not detected using US EPA Test Methods 3052 & 3052/6010b by ICP or ICP-AES. (3) Dynamic Contrast Ratios* during video playback only, depending on series of frames or time duration.
11/19_r2 kh Product Number: XP600AA#ABA
VISIT WWW.HP.COM FOR MORE DETAILS!
MONITOR SPECIFICATIONS
LCD PANEL TYPE • TN
NATIVE
RESOLUTION
(RECOMMENDED)
• 1920 x 1080
DYNAMIC
CONTRAST RATIO • 3,000,000:1(3)
CONTRAST RATIO
(TYPICAL) • 1,000:1 (typical)
BRIGHTNESS
(TYPICAL) • 300 nits
COLOR GAMUT
(TYPICAL) • 72% of NTSC
PIXEL PITCH • 0.3114 mm
RESPONSE TIME
(TYPICAL) • 5 ms on/off
SIGNAL INPUT
CONNECTORS • VGA • DVI-D (with HDCP)
• HDMI (with HDCP)
RESOLUTION
FORMATS • 1920 X 1080 @ 60 Hz • 1680 X 1050 @ 60 Hz
• 1440 X 900 @ 60 Hz
• 1280 X 1024 @ 60 Hz
• 1280 X 720 @ 60 Hz
• 1024 X 768 @ 60 Hz
• 800 X 600 @ 60 Hz
• 720 X 400 @ 70 Hz
• 640 X 480 @ 60 Hz
POWER SUPPLY • External Power Supply
MAXIMUM POWER
RATING • 40 watts
ENERGY SAVING
MODE • Power Saving <1 watt • Power Off <0.5 watt
TILT • Yes (-5 to +25 degrees)
DETACHABLE BASE •Yes, with thumb screw
VESA MOUNTING • No
UNPACKAGED
DIMENSIONS • 25.75"(h) x 18.54"(w) x 7.26"(d)
UNPACKAGED
WEIGHT • 12.57 lbs
PACKAGED
DIMENSIONS • 29.13"(h) x 5.51"(w) x 20.47"(d)
PACKAGED WEIGHT • 16.98 lbs
LANGUAGES • Dutch, English, French, German, Italian, Japanese,
Portuguese, Spanish, Simplified Chinese,
Traditional Chinese
CERTIFICATIONS • ENERGY STAR® 5.0 qualified
• EPEAT® Silver registered
ACCESSORIES, WARRANTY & AGENCY APPROVALS
SUPPLIED
ACCESSORIES • External power supply (50 W) • AC power cord (1.9 m / 6.23 ft)
• DVI-D cable (1.8 m/5.9 ft)
• VGA cable (1.8m/5.9 ft)
• Cable management clip
• CD (includes U.G., warranty, drivers)
• Service phone list card
• Hard copy warranty booklet
AGENCY
APPROVALS •Monitor: FCC, CE, CSA, GOST, S mark, TuV Bauart, WEEE, ENERGY STAR 5.0, CCC, CEL,
CECP, VCCI, KC, E-stand, C-Tick
•External Power Supply: WW use: FCC, Safety
mark, VCCI, GS, S mark, NOM/NYCE, PSE, cUL,
CE, C-Tick, CCC, GOST, BSMI, Cambodia, WEEE,
KC
LIMITED WARRANTY • Limited 1 year warranty. Availabilty varies by
region. Certain restrictions and exclusions apply.
ADDITIONAL INFORMATION
PRODUCT NUMBER • XP5600AA#ABA
AD EMBARGO DATE •12/19/2010
UPC CODE •885631750421
COUNTRY OF
ORIGIN • China
TARIFF NUMBER • 8528510000
