HP 2211x User manual

HP 2211x 21.5-inch LED Monitor
Designed with style, high screen performance and
environmental features for home, work and everything in
between.
• Full HD 1920 X 1080 resolution
• 3,000,000:1 Dynamic Contrast Ratio
• LED backlighting
• Ultra-slim 21.5-inch diagonal monitor
The Wonder of LED
Imagine a sleek, 21.5-inch diagonal, ultra-slim monitor
combined with high screen performance and benefits to
help you “go green”. That’s the power of
LED backlighting. See how the 2211x LED monitor
delivers an eye-catching view for your home computing
and entertainment needs.
• As small solid state devices, LED (Light Emitting Diode)
backlighting reduces the number and overall size of
components for an exceptionally thin monitor
• Helps create deeper blacks for high dynamic contrast
ratio
• Enables faster on/off switching time than CCFL panels
• Helps reduce our environmental impact
Designed with Dazzling Screen Appeal
Take in the sharp, detailed, Full HD(1) view while surfing
the Internet, working on projects, editing videos, or
streaming shows online. High screen performance features
include:
• 3,000,000:1 Dynamic Contrast Ratio(3)
• Full HD(1) 1920 X 1080 resolution
• QuickView modes optimized to match screen
performance with the content of your choice
• 250 nits of Brightness
• 5 ms on/off response time reduces blur
Inspired/THINspired for your Digital Lifestyle
The HP 2211x monitor delivers a chic, strikingly-thin
profile to look perfect on any desktop in your home. This
sleek design utilizes minimal desktop space with
convenient features for your digital life:
• Ultra-slim 21.5-inch diagonal LED monitor
(approximately1-inch deep) looks perfect on any
desktop
• VGA and HDCP Supported DVI-D inputs easily connect
to your HP PC or notebook
• Stylish, sleek exterior with tilt and slide adjustment for a
comfortable view
• 170/160 degree viewing angles
Green Commitment
Developing more responsible monitors is one way HP
strives to help you “go green”. The HP 2211x monitor
includes an array of environmental features:
• Mercury-free LED backlighting helps lower power
consumption
• Arsenic-free(2) display glass
• Recyclable plastics and packaging
• Ultra-thin profile and detachable base allow smaller
packaging to fit more product on a truck, thereby
helping to lower fuel use and CO2 emissions
• ENERGY STAR®5.0 qualified
• EPEAT®Silver registered
• SmartWaySM Transport Partnership (USA only)
HP Peace of Mind
Relax knowing you are backed by award-winning HP
worldwide service and support. The HP 2211x monitor is
fully tested and has a limited warranty that includes parts,
labor, toll-free technical support and real-time chat.

HP 2211x 21.5-inch LED Monitor
All specifications represent the typical specifications provided by HP’s component manufacturers; actual performance may vary either higher or lower.
(1) HD content required to view HD images. (2) Arsenic and its compounds were not detected using US EPA Test Methods 3052 & 3052/6010b by ICP or ICP-AES. (3) Dynamic Contrast Ratios* during video playback only, depending on series of frames or time duration.
11/19_r2 kh Product Number: XP601AA#ABA
VISIT WWW.HP.COM FOR MORE DETAILS!
MONITOR SPECIFICATIONS
LCD PANEL TYPE • TN
NATIVE
RESOLUTION
(RECOMMENDED)
• 1920 x 1080
DYNAMIC
CONTRAST RATIO • 3,000,000:1(3)
CONTRAST RATIO
(TYPICAL) • 1,000:1 (typical)
BRIGHTNESS
(TYPICAL) • 250 nits
COLOR GAMUT
(TYPICAL) • 68% minimum
PIXEL PITCH • 0.248 mm
RESPONSE TIME
(TYPICAL) • 5 ms On/Off
SIGNAL INPUT
CONNECTORS • VGA • DVI-D (with HDCP)
RESOLUTION
FORMATS • 1920 X 1080 @ 60 Hz • 1680 X 1050 @ 60 Hz
• 1440 X 900 @ 60 Hz
• 1280 X 1024 @ 60 Hz
• 1280 X 720 @ 60 Hz
• 1280 X 960 @ 60 Hz
• 1024 X 768 @ 60 Hz
• 800 X 600 @ 60 Hz
• 720 X 400 @ 70 Hz
• 640 X 480 @ 60 Hz
POWER SUPPLY • External Power Supply
MAXIMUM POWER
RATING • 29 watts
ENERGY SAVING
MODE • Power Saving <0.5 watt • Power Off <0.5 watt
TILT • Yes (-5 to +25 degrees)
DETACHABLE BASE •Yes, with thumb screw
VESA MOUNTING • No
UNPACKAGED
DIMENSIONS • 15.60"(h) x 20.45"(w) x 6.26"(d)
UNPACKAGED
WEIGHT • 7.72 lbs
PACKAGED
DIMENSIONS • 15.75"(h) x 23.00"(w) x 4.96"(d)
PACKAGED WEIGHT • 11.68 lbs
LANGUAGES • Dutch, English, French, German, Italian, Japanese,
Portuguese, Spanish, Simplified Chinese,
Traditional Chinese
CERTIFICATIONS • ENERGY STAR®5.0 qualified
• EPEAT®Silver registered
ACCESSORIES, WARRANTY & AGENCY APPROVALS
SUPPLIED
ACCESSORIES • External power supply (36-40W) • AC power cord (1.9m) 6.2 ft
• VGA cable (1.8m) 5.9 ft
• DVI-D cable (1.8m) 5.9 ft
• Cable management clip
• CD (includes U.G., warranty, drivers)
• Service phone list card
• Hard copy warranty booklet (country specific)
• Additional Signal Cables in selected SKUs
AGENCY
APPROVALS •Monitor: CB,CE,TUV mark, ISO9241-307, FCC, S mark, CCC, CEL, CECP, VCCI, KC, E-stand, C-tick,
BSMI
•External Power Supply: WW use: FCC, Safety
mark, VCCI, GS, S mark, NOM/NYCE, PSE, cUL,
CE, C-Tick, CCC, GOST, BSMI, Cambodia, WEEE,
PSB, KC
LIMITED WARRANTY • Limited 1 year warranty. Availabilty varies by
region. Certain restrictions and exclusions apply.
ADDITIONAL INFORMATION
PRODUCT NUMBER • XP601AA#ABA
AD EMBARGO DATE • 12/11/2010
UPC CODE •885631750452
COUNTRY OF
ORIGIN • China
TARIFF NUMBER • 8528510000
