HP procurve radio port 220 User manual

Installation and
Getting Started Guide
www.procurve.com
ProCurve Radio Port 220

© Copyright 2006 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without
notice.
This document contains proprietary information, which is
protected by copyright. No part of this document may be
photocopied, reproduced, or translated into another
language without the prior written consent of Hewlett-
Packard.
Publication Number 5991-3779
Applicable Products
Trademark Credits
Windows NT®, Windows®, and MS Windows® are US
registered trademarks of Microsoft Corporation.
Disclaimer
HEWLETT-PACKARD COMPANY MAKES NO WARRANTY
OF ANY KIND WITH REGARD TO THIS MATERIAL,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE. Hewlett-Packard shall not
be liable for errors contained herein or for incidental or
consequential damages in connection with the furnishing,
performance, or use of this material.
The only warranties for HP products and services are set
forth in the express warranty statements accompanying
such products and services. Nothing herein should be
construed as constituting an additional warranty. HP shall
not be liable for technical or editorial errors or omissions
contained herein.
Hewlett-Packard assumes no responsibility for the use or
reliability of its software on equipment that is not furnished
by Hewlett-Packard.
Warranty
See the Customer Support/Warranty booklet included with
the product.
A copy of the specific warranty terms applicable to your
Hewlett-Packard products and replacement parts can be
obtained from your HP Sales and Service Office or
authorized dealer.
ProCurve Radio Port 220 (J9005A)

3
Introduction
Introduction
The ProCurve Radio Port 220, a component of the ProCurve Wireless LAN
System, links wireless 802.11a/b/g devices to the Ethernet network through a
wireless services-enabled switch. This device is to be used with the ProCurve
Switch 5300xl, with a ProCurve Wireless EDGE Services xl Module, or other
compatible wireless services-enabled switch product. These Radio Ports are
designed to be simple plug-and-play devices that require no individual device
configuration before being installed into a network. All Radio Port configu-
ration, including country-specific settings, radio channel, radio power, SSID
settings, security settings, management information, and Radio Port firmware
is provided through the wireless services-enabled switch.
NOTE Before installing this Radio Port, a wireless services-enabled switch (such as
the ProCurve Switch 5300xl with Wireless EDGE Services xl Module installed)
should be deployed, configured, and operating in a Normal mode. See the
"ProCurve Wireless EDGE Services xl Module Getting Started Guide" for
details.
ProCurve Radio Port 220 Package Contents
ProCurve Radio Port 220 with external antenna connectors (Plenum Rated)
NOTE External Antennae must be purchased separately.
■Two wall mount screws
■Two wall anchors
■Light pipe extender
■Badge for light pipe extender
■Label for badge
■Radio Port Install Guide
■Customer Support/Warranty booklet
Description
The ProCurve Radio Port 220 is a dual-radio IEEE 802.11-compliant device
supporting simultaneous 802.11a and 802.11b/g wireless Ethernet connec-
tions. The unit supports up to four external antennas, including up to two 2.4
GHz diversity antennas and up to two 5 GHz diversity antennas. Supported
Antennas are listed below under the section entitled Supported Antennas.

4
Introduction
The Radio Port 220 is designed for installation in either office or plenum
environments, using the mounting slots built into the underside of the metal
case. The Radio Port has one RJ-45 connector supporting 10/100 Ethernet and
requires power from any UL-listed, 802.3af-compatible Power over Ethernet
(PoE) switch or power injector.
RSMA Antenna Connectors
2.4 Ghz Primary5 Ghz Primary
2.4 Ghz Secondary5 Ghz Secondary
RSMA Antenna Connectors
LEDs
Top View
Mount Slots
Light Pipe Clip Slots
Bottom View

5
Introduction
Lock Port
The lock port, compatible with laptop-style security cables, is on the side of
the case.
Front View
Rear View RJ-45
Lock Port

6
Introduction
Technical Specifications
Dimensions & Weight
Features
■High-performance 802.11-compliant radios
■Two Reverse SMA (RSMA) connectors for 2.4-2.5Ghz antennas and two
Reverse SMA (RSMA) connectors for 4.9-5.825Ghz antenna connection
■Supports a single antenna or dual antennas in diversity mode for both
802.11b/g (2.4 GHz) and 802.11a (5GHz) bands
■Integrated 10/100 Base-TX Ethernet RJ-45 port
■Two redundant sets of LED indicators, top and bottom of Radio Port
■Lightpipe Extender for making LED indicators visible when Radio Port is
installed above a ceiling tile
■Safety wire tie point (post)
■Laptop-style lock port
■Slots for wall mounting
Operating Voltage 48VDC (from 802.3af-compliant
power source)
Operating Current 148mA (typical)
Power 7W (typical)
Operating Temperature -4 to 122° F (-20 to 50° C)
Non-Operating/Storage
Temperature -40°F to 158°F (-40 to 70°C )
Operating Humidity 5 to 95% (non-condensing)
Non-Operating/Storage
Humidity 5 to 95% (non-condensing)
Operating Altitude (max) 10,000 ft (3,048 m)
Non-Operating/Storage
Altitude 15,000ft.(4,572 m)
Plenum Rated UL 2043 - suitable for use in air
handling spaces
Length 237.2mm (9.34in.)
Width 139.6mm (5.50in.)
Height 25.4mm (1.0in.)
Weight 0.73kg (1.6lbs)

7
Introduction
Radio Characteristics
The ProCurve Radio Port 220 contains two IEEE 802.11-compliant radios: (1)
an 802.11b/g radio operating in the 2.4 to 2.5 GHz band and (2) an 802.11a radio
operating in the 4.9 to 5.875Ghz band. The Radio Port accepts a broad range
of 2.4-2.5GHz and 4.9-5.875GHz external antennas that can be connected to
the Radio Port's two pairs of R-SMA antenna connectors. The following table
lists the 802.11-compliant operating modes for each radio. The three sup-
ported 802.11g operating modes are simultaneous CCK and OFDM, CCK only,
or OFDM only.
Integrated RJ-45 Port
The ProCurve Radio Port 220 has one RJ-45 connector supporting a full-duplex
10/100Base-TX Ethernet port and requires IEEE 802.3af-compliant Power-
over-Ethernet (PoE) from an external source such as a Power-over-Ethernet
(PoE) switch or power injector. Installers can use of a single CAT-5 cable to
supply both Ethernet connectivity and power to the Radio Port, allowing these
Radio Ports to be installed up to 100 m (300 ft.) from a PoE-compliant 10/100
Ethernet port. There is no additional power supply required.
LED Indicators
The Radio Port 220 has LED indicators on the front of the case that visually
display the status of the device. When the Radio Port is mounted above a
suspended ceiling, an additional set of LED indicators on the back of the unit
can be extended through the ceiling tile using a provided lightpipe extender,
making the Radio Port location and status visible from below the ceiling.
Device Mbps Data Rate Support Utilizing
Diversity GHz
802.11a 6, 9, 12, 18, 24, 36, 48, 54
OFDM Transmit and receive 4.9 to 5.875 range
802.11b/g 1, 2, 5.5, 11 CCK
6, 9, 12, 18, 24, 36, 48, 54
OFDM
Transmit and
receive 2.4 to 2.5 ISM range

8
Introduction
Wall Mount.
Above Ceiling Mount.
The LED indicators display connection status and error conditions, as well as
network activity for each of the two radios. Operation is as follows:
Start-up:
Radio Port Startup occurs immediately following the application of PoE
power, or following a power or software reset.
1. Both GREEN and AMBER LEDs light steadily for several seconds while
the Radio Port performs an internal self-test.
2. The AMBER LED then flashes 3 times per second, while the GREEN LED
is off. This indicates that the Radio Port is attempting to communicate to
a compatible wireless services-enabled switch.
3. Both LEDs then go off for a moment, followed by both LEDs lighting
steadily for a few seconds.
RSMA Antenna Connectors
2.4 Ghz Primary5 Ghz Primary
2.4 Ghz Secondary5 Ghz Secondary
RSMA Antenna Connectors
LEDs
Top View

9
Installation Instructions
4. After this sequence, assuming no error conditions have occurred, the
Radio Port will enter Normal operation mode. This means that the Radio
Port has successfully communicated with and been adopted by a wireless
services-enabled switch. If this startup sequence repeats itself, then it is
likely that the Radio Port is unable to contact a compatible wireless
services -enabled switch, and the installer should review the Trouble-
shooting section below.
Normal Operation:
Once the Radio Port has established a connection to a compatible wireless
services-enabled switch the Radio Port will begin normal operation. During
normal operation, the GREEN LED indicates status of the 802.11 b/g radio,
and the AMBER LED indicates status of the 802.11a radio.
■Without Wireless Traffic: Each LED will briefly flash once every 5 seconds,
to indicate that power is on, and the Radio Port is communicating nor-
mally to its wireless services-enabled switch. The flashing may not be
synchronous between the two LED indicators.
■With Wireless Traffic: Each LED will briefly flash more frequently than
once every 5 seconds, and in an irregular fashion, to represent traffic on
that radio.
Radio Error Mode:
■The GREEN LED flashes on and off steadily once per second if an error
prevents the 802.11b/g radio from operating normally.
■The AMBER LED flashes on and off steadily once per second if an error
prevents the 802.11a radio from operating normally.
Installation Instructions
The ProCurve Radio Port 220 can be mounted either on a wall or other
mounting point, or above a suspended ceiling. This Radio Port is not designed
for mounting on a desk.
To prepare for installation, perform the following steps:
1. Review site survey and network analysis reports to determine the location
and mounting position for the ProCurve Radio Port 220. Verify the
recommended external antenna type and antenna mounting configura-
tion.
2. Match the Radio Port model number on the purchase order with the model
numbers in the packing list and on the case of the device shipped.

10
Installation Instructions
3. Verify that the contents of the box include the intended ProCurve Radio
Port 220 and mounting hardware:
4. Verify that you have the recommended external antenna model and type
for the desired installation. External antennas must be purchased sepa-
rately. For a list of Supported Antennas for this Radio Port, see 'Supported
Antennas' below.
5. Connect a CAT-5 cable to a compatible 802.3af power source and run the
cable to the installation site. Ensure that there is sufficient slack on the
cable to perform the installation steps.
Radio Port Item Notes
220 J9005A 802.11a & 802.11b/g radios with external connectors.
This radio port is configurated with two pairs of
RSMA connectors

11
Installation Instructions
Wall Mount
Wall mounting consists of hanging the ProCurve Radio Port 220 along its width
or length using the pair of wide-shoulder mounting screws provided, and
mounting slots on the bottom of the unit. The ProCurve Radio Port 220 can
be mounted onto any wood, plaster, or cement wall surface using the provided
wall anchors when necessary. The illustration shows a vertical mount.
Wall Mount Hardware
■Two Phillips pan head self-tapping screws
■Two wall anchors
■Safety wire (recommended) and security cable (optional)
Note In the event that the original mounting screws are lost, the following screws
can be used instead: ANSI Standard) #6-18 X 0.875in. Type A or AB Self-
Tapping Screw, or (ANSI Standard Metric) M3.5 X 0.6 X 20mm Type D Self-
Tapping Screw
Wall Mount Procedure
1. If the antennas being used with the Radio Port 220 require special mount-
ing provisions or mounting locations, mount these antennas in their
desired locations first, using the appropriate mounting hardware provided
with the antenna. Antenna mounting position is the most critical element
of Radio Port installation. If necessary, the mounting location of the Radio
Port 220 should be adjusted to ensure that the antenna leads from the
antenna mounting location can reach it.

12
Installation Instructions
2. For a horizontal Radio Port installation, lightly mark a horizontal line on
the wall at the location where the midline of the Radio Port is to be located.
For a vertical installation, lightly mark a vertical line on the wall at the
location where the midline of the Radio Port is to be located.
3. Using the alignment arrows on one edge of the Radio Port case as guides,
place the edge of the Radio Port along the midline from step 1. and mark
the two points on the midline for the location of the mounting screws.
4. At each of the two points, drill a hole in the wall, insert an anchor (if
required), screw the wall mounting screw into the anchor and stop when
there is 1mm remaining between the screw head and the wall.
Note When pre-drilling holes, the recommended hole size is 3mm (0.125 or 1/8 in.)
if the screws are going directly into the wall and 6mm (0.25 or 1/4 in.) if the
provided wall anchors are being used.
5. If required, loop a safety wire, between 1.5mm (.06in.) and 2.5mm (.10in.)
in diameter, around the safety wire tie post on the Radio Port and secure
the loop. Attach the opposite end of the safety wire to a secure point on
the wall.
6. If required, install and attach a security cable to the Radio Port's lock port.
The lock port, compatible with laptop-style security cables, is on the side
of the case. Attach the opposite end of the security cable to a secure,
stationary point.
7. Attach the appropriate antennas to the Radio Port's antenna connectors.
Pay close attention to ensure that the appropriate antenna for each
frequency band is attached to the appropriate antenna connector for that
frequency band on the Radio Port. For single (non-diversity) antennas,
attach the antenna to the Radio Port connector marked as Primary for
that frequency band.
8. Plug the Ethernet cable into the Radio Port's RJ-45 port and connect the
opposite end of the cable to a switch with an 802.3af-compatible power
source.
9. Place the large corner of each of the case's mounting slots over the
mounting screw heads.
10. Slide the case down along the mounting surface to hang the Radio Port
mounting slots on the mounting screw heads.
11. Verify the unit has power by observing that the LEDs are lit or flashing.

13
Installation Instructions
Suspended Ceiling Tile (Plenum) Mount
Mounting the Radio Port 220 above a suspended ceiling (in the plenum)
consists of placing the ProCurve Radio Port 220 above a suspended ceiling
and making the appropriate safety wire, antenna, and Ethernet connections.
If desired, the light pipe extender provided with the Radio Port can be used
to make the Radio Port's location and status visible from below the suspended
ceiling. The procedure below outlines the installation using the light pipe
extender
WARNING Do not mount the ProCurve Radio Port 220 directly to any suspended
ceiling tile with a thickness less than 12.7mm (0.5in.) or a suspended
ceiling tile with an unsupported span greater than 660mm (26in.).
The Radio Port 220 case is equipped with a safety wire tie point. To
prevent accidental damage or injury, HP strongly recommends that
installers secure the ProCurve Radio Port 220 with a safety wire
suitable for the specific installation. The safety wire should be a
standard ceiling suspension cable or equivalent steel wire between
1.59mm (.062in.) and 2.5mm (.10in.) in diameter.
Alignment Arrows

14
Installation Instructions
Ceiling Mount Hardware
■Light pipe extender
■Badge for light pipe extender
■Label for light pipe badge
■Safety wire (recommended) and security cable (optional)
Ceiling Mount Procedure
1. If possible, remove the ceiling tile from its frame and place it, finished side
down, on a work surface.
2. Mark a point on the upper or unfinished side of the tile where the light
pipe extender will be installed. It is best to leave at least 5 cm (2 in.) or
more between the edge of the ceiling tile and the center of the light pipe
to allow clearance for placement of the Radio Port and antenna connec-
tions above the ceiling tile.
3. Drill two 6 mm (1/4 inch) holes adjacent to each other through the ceiling
tile to accommodate the twin shafts of the light pipe extender.
4. Snap the clips of the light pipe extender into the bottom of the Radio Port
case.
5. Place the Radio Port and light pipe extender over the hole on the unfin-
ished side of the ceiling tile . Fit the light pipe extender through the hole
to project through on the finished side of the ceiling tile.
6. Place the label for the light pipe badge over the hub on the back of the
badge and press the badge onto the light pipe extender from the finished
side of the ceiling tile.
7. If required, install a safety wire, between 1.5mm (.06in.) and 2.5mm
(.10in.) in diameter, to a secure, stationary point in the ceiling space.
8. If required, attach a security cable to a secure, stationary point in the
ceiling space.
9. Attach the appropriate antennas to the Radio Port's antenna connectors.
If the antennas are intended to be mounted below the ceiling tile, it may
be convenient to make provision for this installation in the same ceiling
tile as the Radio Port and light pipe extender.
10. Bring the ceiling tile into the ceiling space.
11. Attach the end of the safety wire from Step 7. to the safety wire tie point
on the Radio Port.

15
Supported Antennas
12. Attach the end of the security cable from Step 8. to the Radio Port's lock
port located on one end of the Radio Port.
13. Plug the Ethernet cable into the Radio Port's RJ-45 port and to a switch
with an 802.3af-compatible power source.
14. Verify the Radio Port has power by observing the LEDs.
15. Place the ceiling tile back in its frame to complete the installation.
Supported Antennas
The following is a list of available antennas for the ProCurve Radio Port 220:
Diversity means that the antenna has two cables connecting it to the Radio
Port 220. (Antenna J8997A has a diversity feature). A 2.4 GHz diversity antenna
will have one cable connecting to the "2.4 GHz Primary" connector, and the
second cable connecting to the connector labeled "2.4 GHz"; a 5 GHz diversity
antenna will connect to the "5 GHz Primary" and "5GHz" connectors. All of the
other antennas have a single cable which would typically connect to either
the "2.4 GHz Primary" or "5GHz Primary" antenna connector as appropriate.
ProCurve
Product
Number
Frequency
Range (GHZ Antenna Type/ Coverage Diversity Actual Gain w/ specified cable
(dBi)
J8441A 2.4 Indoor/Outdoor
Omni-Directional
(dipole)
No 4.4
J8444A 2.4 Outdoor Omni-
directional (dipole) No 7.4
J8448A 2.4 Directional point-
to-point (Yagi) No 13.8
J8997A 2.4/5.0 Omni-directional
(ceiling-mount
panel)
Yes 3.0/4.0
J8998A 5.0 Indoor/Outdoor
Omni-directional
(dipole)
No 6.3
J8999A 2.4/5.0 60-degree
Directional (panel) No 6.9/7.7
J9000A 5.0 25- degree
Directional (panel) No 13.3

16
Troubleshooting Radio Port Installation
Caution When using antennas outdoors, a lightning arrestor is required for lightning
protection. Consider placing the lightning arrestor immediately before the
antenna cable enters the building. ProCurve offers a lightning arrestor as an
accessory; it is orderable under ProCurve product numberJ8996A.
All ProCurve devices are designed to be compliant with the rules and regula-
tions in locations they are sold and will be labeled as required. Any changes
or modifications to ProCurve Equipment, not expressly approved by
ProCurve, could void the user's authority to operate this device. Use only
antennas approved for use with this device.
Unauthorized antennas, modifications, or attachments could cause damage
and may violate local radio regulations in your region.
This device Is to be used only with ProCurve Switch 5300xl with a ProCurve
Wireless EDGE Services xl Module installed, or other compatible controller
device. When using external antennas, users must ensure that the combined
transmit power and antenna gain does not violate the maximum Equivalent
Isotropic Radiated Power (EIRP)) for your region.
Information on configuration this device to operate in a compliant manner
can be found in the ProCurve Wireless EDGE Services xl Module Installation
Guide.
Troubleshooting Radio Port Installation
This section describes how to troubleshoot the installation of your ProCurve
Radio Port primarily from a hardware perspective. You can perform more in-
depth troubleshooting of your wireless LAN system from the console or web
UI on your wireless services-enabled ProCurve switch. For more information
on software configuration or troubleshooting, see the "ProCurve Wireless
EDGE Services xl Module Getting Started Guide" for details.
Basic troubleshooting relies on the LED indicators to diagnose the condition
of the Radio Port. The table below shows LED patterns on the Radio Port that
indicate problem conditions.

17
Troubleshooting Radio Port Installation
Startup Error Checklist
Startup errors occur when the Radio Port is unable to communicate with a
compatible wireless services-enable switch, or when the Radio Port success-
fully communicates to a compatible switch but the switch is not able to adopt
and manage the Radio Port. The following steps can be used to determine the
different circumstances that may be preventing the Radio Port from being
adopted by the switch and operating normally.
1. The network connection between the Radio Port and the wireless ser-
vices-enabled switch has been disrupted. Verify that network connectivity
between the Ethernet cable and the wireless services-enabled switch by
connecting another device, such as a laptop, to the Ethernet cable and
confirming network connectivity to the switch. Verify that the Ethernet
port to which the Radio Port is connected has not been disabled, and if
802.1x port security is turned on, that the 802.1x Port security is compat-
ible with the Radio Port's 802.1x settings.
2. The network between the Radio Port and the wireless services-enabled
switch has a Layer 3compatibility issue (e.g. the two devices are on
different subnets.)
LED Error Indicators
GREEN LED AMBER LED Diagnostic Tips
Off steadily while Ethernet cable is
linked to a PoE source. Remains off
even when Radio Port is disconnected
from Ethernet cable and reconnected.
Off steadily while Ethernet cable is
linked to a PoE source. Remains off
even when Radio Port is disconnected
from Ethernet cable and reconnected.
Radio Port is not receiving PoE power. Verify that the Ethernet
cable is connected directly to an IEEE 802.3af-compatible PoE
source, and that all cable connections are tight and secure.
Verify that the PoE source device is powered on, and that the
PoE function has been administratively enabled on the source
port connected to the Radio Port. Verify that the network cable
is functioning properly, or try a different cable. Try plugging
the Radio Port into another PoE power source, or connect
another PoE device to the port to confirm if the PoE source is
functioning appropriately.
Both GREEN and AMBER LED Indicators light steadily for several seconds,
followed by the AMBER LED flashing steadily on and off three times a second for
several seconds, then this cycle repeats itself continuously.
The Radio Port is encountering a Startup Error, and is unable to
successfully communicate with or be adopted by a compatible
wireless services-enabled switch. See the Startup Error
checklist below for further diagnostic tips.
Flashes on and off steadily once per
second * The Radio Port has encountered an error that prevents the 802.11b/g radio from operating normally.
* Flashes on and off steadily once per
second
(Radio Port 230 only) The Radio Port has encountered an error
that prevents the 802.11a radio from operating normally.
*This LED Indicator is not important for this diagnosis

18
HP Customer Service
3. The network between the Radio Port and the wireless services-enabled
switch has a Layer 2compatibility issue (e.g. the two devices are on
different VLANs.)
4. The wireless services-enabled switch may not be configured properly. In
the case of the ProCurve Switch 5300xl, verify that the Wireless EDGE
Services xl Module is properly installed, configured, and operational. In
particular, verify that the wireless services' country-code setting has been
properly configured, as this setting must be configured to enable the
wireless service to function. Refer to the "ProCurve Wireless EDGE
Services xl Module Getting Started Guide" for details.
5. The wireless services-enabled switch may not be functioning normally.
Refer to the "ProCurve Wireless EDGE Services xl Module Getting Started
Guide" for details on verifying operation.
6. The wireless service may have adopted Radio Ports up to it's Authoriza-
tion Level and may not be authorized to adopt additional Radio Ports.
Review the number of Radio Ports the wireless services-enabled switch
has currently adopted and compare this number to the number of Radio
Ports authorized based on the licenses installed.
HP Customer Service
If you are still having trouble with your Radio Port or ProCurve wireless
services-enabled switch, Hewlett-Packard offers support 24 hours a day, seven
days a week through the use of a number of automated electronic services.
See the Customer Support/Warranty booklet that came with your Radio Port
for information on how to use these services to get technical support. The
ProCurve Web site, www.procurve.com also provides up-to-date support
information under product support. In addition, your ProCurve authorized
network reseller can provide you with assistance, both with services that they
offer and with services offered by ProCurve.
Before Calling Support
To make the support process most efficient, before calling your networking
dealer or ProCurve Support, you first should retrieve the following informa-
tion.

19
HP Customer Service
See your Warranty Booklet for the appropriate phone number in your area.
Service Information: For the latest version of this Guide, go to: http://
www.procurve.com
Information Item Information Location
• product identificationfor the Radio Port and
any antennas connected to the Radio Port
• the front of the module,J9005A, and
identifying labels on any connected antennas.
• product identification for the wireless ser-
vices-enabled switch to which the Radio
Port is intended to connect, and any mod-
ules installed in that switch, if any
• the front of the switch
• details about the Radio Port's status and the
status of the wireless services-enabled
switch including the software (OS) version
of the switch and any installed modules, a
copy of the wireless services configuration,
• a copy of the switch Event Log,
• a copy of the switch status
• counters information
• Switch console (Wireless Services Configura-
tion Level): show command
• switch event Log
• Syslog server entry file, if configured
• copy of your network topology map, includ-
ing network addresses assigned to the rel-
evant devices
• your network records

20
Safety and Regulatory Statements
Safety and Regulatory Statements
Safety Information
Grounding
■If your LAN covers an area served by more than one power distribution
system, be sure their safety grounds are securely interconnected.
■LAN cables may occasionally be subject to hazardous transient voltages
(such as lightning or disturbances in the electrical utilities power grid).
Handle exposed metal components of the network with caution.
Servicing
There are no user-serviceable parts inside this product. Any servicing, adjust-
ment, maintenance or repair must be performed only by service trained
personnel.
This product does not have a power switch; it is powered on when the LAN
cable is plugged in.
Regulatory Model Identification Number
For regulatory identification purposes, this product has been assigned a
Regulatory Model Number (RMN). The RMN for your product is RSVLC-0505.
The RMN should not be confused with the marketing name (Radio Port 220)
or the Product Number (J9005A).
Documentation reference symbol. If the product is marked with this symbol, refer to the product
documentation to get more information about the product.
WARNING A WARNING in the manual denotes a hazard that can cause injury or death.
Caution A Caution in the manual denotes a hazard that can damage the equipment or create a non-compli-
ant condition.
Do not proceed beyond a WARNING or Caution notice until you have understood the hazardous
conditions and have taken appropriate steps.
