Clinician Adjustable
Lift Assist Salon Top
Shown with optional
Adjustable Side Arm Rests
and Universal Table Extender
ASSEMBLY & OPERATION INSTRUCTIONS
Lift Assist Backrest Top
Flat Top
INSTRUCTION MANUAL
www.oakworks.com · 717.235.6807

ASSEMBLY INSTRUCTIONS
WARNINGS
TABLE ASSEMBLY INSTRUCTIONS
1
STEP 1
Place the table top upside down on the floor.
STEP 2
Place the shelf upside down on top of the table skirt.
(Fig. 1) Each leg has a number by the top bolt that
corresponds with a number on the inside corners of
the table’s base.
STEP 3
Place the top leg bolt through the metal
corner bracket in one corner of the table skirt. (Fig.
1 inset) For flex top models, it may be necessary to
raise the foot section to install the leg.
Parts Included:
1 - Wrench 8 - Washers 8 - Nylock
Nuts
1 - Table Top
1 - Shelf
4 - Main Legs
w/extensions
Shelf Assembly
Table Top &
Skirt Assembly
Leg Assembly
Figure 1
Nylock Nut &
Washer (4 ea.)
Figure 2
(As viewed from underside)
STEP 4
Lift the same corner of the table shelf and place the
bottom leg bolt through the metal corner brackets on
the shelf.
STEP 5
Place a flat washer and nut on each bolt. Do not
tighten. (If cabinet is included, please go to step 1
below.)
STEP 6
Repeat steps 3-5 on remaining corners, installing the
remaining three leg assemblies to the skirt and shelf.
STEP 7
Using the included wrench, or a 1/2” wrench, tighten
all eight nuts securely. When tight, assembled unit
should look like figure 2.

WARNINGS
2
CABINET OPTION INSTALLATION INSTRUCTIONS
ASSEMBLY INSTRUCTIONS
STEP 2
Place end panel in position. Insert supplied
screws (2) into the hole in the legs on both
sides of the end panel. Tighten screw until end
panel is secured. Do not over tighten. Tighten
just enough to hold end panel in position.
Repeat for other end panel.
STEP 1
Tighten all four nuts on the bottom shelf, and upright
the table with assistance from another person.
STEP 3
Remove lower door track on shelf with supplied
screw driver. Lay doors on shelf in the position they
will be installed.
STEP 4
At an angle, install the top of the two doors into the upper door track. Place the
lower track on the bottom of the two doors. Slide the lower track into the final
location and replace the screws in the lower track.
picture not available
not
available
not
available
STEP 5
Slide the doors back and forth to insure easy movement.
Repeat on other side.

WARNINGS
3
OPERATION INSTRUCTIONS
OPERATING THE MANUAL TOP (IF EQUIPPED)
Back Rest
Control
To Raise the Back Rest:
Raise the backrest by pressing the lever under the head section and lifting up to the desired height. It
is recommended that the client takes some of their weight off the backrest while you lift.
To Lower the Back Rest:
Press the lever under the head section and push the backrest down. Release the lever and the backrest
will stay in place.
To change position of the backrest lever:
The backrest lever can be moved to the opposite side of the backrest by removing the screws and
relocating the hand lever to the opposite side of the top into the four pre-drilled holes.
BACK REST
To Raise the Leg Rest:
Raise the leg rest by pulling the handle on the side of the leg section and raise to the desired height.
It is recommended that the client takes some of their weight off the leg rest while you lift.
To Lower the Leg Rest:
Pull the handle on the side of the leg section and push the leg section down. Release the handle once
leg rest is at desired location and the leg section will stay in place.
To change position of the leg rest handle:
The leg rest handle can be moved to the opposite side of the table. First, remove the screws from the
handle and replace just the screws. Move handle to the opposite side of the table. Remove the screws
that are there and mount handle.
LEG REST
Leg Rest
Control

WARNINGS
4
ARM REST INSTRUCTIONS
ARM REST INSTALLATION AND ADJUSTMENT INSTRUCTIONS
OPTIONAL ACCESSORY
AVAILABLE ON SALON TOP ONLY
Manicure Arm RestsAdjustable Side Arm Rests
1. Insert end of arm rest into
hole in backrest while holding
arm rest at 60° angle.
2. Push end all the way into hole and drop arm rest into horizontal
position. Tug slightly to make sure the armrest is fully locked to
the table (for patient safety).
To remove the arm rest, simply reverse the procedure above.
TO INSTALL THE ARM REST:
The arm rests adjust automatically as the table’s back support moves to remain parallel to the floor in any position.
They are designed to be strong and will take a reasonable amount of weight, but they are not designed to be used to
sustain a person’s weight when getting on or off the table.
CAUTION: Do not use the arm rest
for customer weight support during the
mounting or dismounting of the table.
The arm rest is not designed to support
the patient’s weight.
The arm rest height is adjusted to level at the factory. When in use, some of the new
parts will wear, and you may see some sagging of the arm rest over time. If the arm
rest is too low the height can easily be adjusted using the enclosed Allen wrench.
1. Loosen bottom 2 set screws
(turn counter-clockwise).
2. Turn side set screw in (clock-
wise) while lightly raising the arm
rest with your other hand (to make
the adjustment easier).
3. When you have achieved the desired
height, tighten the two bottom set screws
(turn clockwise).
1. Loosen bottom 2 set screws
(turn counter-clockwise).
2. Turn side set screw out (turn
counter-clockwise).
3. When you have achieved the desired
height, tighten the two bottom set screws
(turn clockwise).
To Raise the Arm Rest
To Lower the Arm Rest
TO LEVEL THE ARM REST:

WARNINGS
5
THIS PAGE INTENTIONALLY LEFT BLANK
NOTES:

WARNINGS
6
THIS PAGE INTENTIONALLY LEFT BLANK
NOTES:

European Compliance for CE Information:
Emergo Europe
Molenstraat 15
The Hague, 2513 BH Netherlands
[email protected]
Manual Part Number MMMNST0023
Revision date: 02.01.12
Edition 1 - February 2012
Printed in English
Printed in USA
CONTACT INFORMATION:
Oakworks®Inc.
923 East Wellspring Road
New Freedom, PA 17349
Phone: [phone]
FAX: [phone]
www.oakworks.com
Clinician Adjustable
ASSEMBLY & OPERATION INSTRUCTIONS
Maximum Working
Load Rating:
500 LBS. (227 KG.)
CAUTION
