The HP NC380T server adapter is the industry's first PCI Express dual port multifunction network adapter supporting TOE (TCP/IP
Offload Engine) for Windows, and iSCSI (Internet Small Computer System Interface) over a single network connection. Each port on
the NC380T is a four lane (x4) serial device designed for PCI Express slots. The NC380T comes with a total of 184KB onboard
memory.
In addition to its multifunction capabilities, the NC380T ships with all the advanced server features that ProLiant customers have
come to expect, such as support for failover and load balancing, Pre-Boot Execution Environment (PXE), large send offload capability,
multiple VLAN tagging, auto-negotiated 10/100/1000Mbps Ethernet speeds and IPv6 packet transmit and receive support (excluding
all offload capabilities).
Models
ModelsModels
Models
HP NC380T PCI Express Dual Port Multifunction Gigabit Server Adapter
NOTE:
NOTE:NOTE:
NOTE: Supported on a Full Length-Full Height slot only
394795-B21
QuickSpecs
HP NC380T PCI Express Dual Port Multifunction Gigabit
HP NC380T PCI Express Dual Port Multifunction GigabitHP NC380T PCI Express Dual Port Multifunction Gigabit
HP NC380T PCI Express Dual Port Multifunction Gigabit
Server Adapter
Server AdapterServer Adapter
Server Adapter
Overview
DA - 12418 Worldwide — Version 21 — February 16, 2010 Page 1

1.
2.
3.
Kit Contents
Kit ContentsKit Contents
Kit Contents HP NC380T PCI Express Dual Port Multifunction Gigabit Server Adapter in an anti-static bag
Quick install card
Product warranty statement
NOTE:
NOTE:NOTE:
NOTE: For a brief, printer friendly data sheet that describes this product and informs you of the essential capabilities and
specifications, please visit: http://h71028.www7.hp.com/ERC/downloads/5983-0738EN.pdf .
Standard Features
Standard FeaturesStandard Features
Standard Features
Server Support
Server SupportServer Support
Server Support ProLiant DL (rack-optimized)
ProLiant DL (rack-optimized)ProLiant DL (rack-optimized)
ProLiant DL (rack-optimized) :
HP ProLiant DL140 G3
HP ProLiant DL145 G2
HP ProLiant DL145 G3
HP ProLiant DL160 G5
HP ProLiant DL165 G5
HP ProLiant DL180
HP ProLiant DL180 G5
HP ProLiant DL185 G5
HP ProLiant DL320 G3
HP ProLiant DL320 G4
HP ProLiant DL320 G5
HP ProLiant DL320 G5p
HP ProLiant DL360 G4p
HP ProLiant DL360 G5
HP ProLiant DL365
HP ProLiant DL365 G5
HP ProLiant DL380 G4
HP ProLiant DL380 G4 Packaged Cluster with MSA1000
HP ProLiant DL380 G4 Packaged Cluster with MSA500 G2
HP ProLiant DL380 G5
HP ProLiant DL385 G2
HP ProLiant DL580 G4
HP ProLiant DL580 G5
HP ProLiant DL585 G2
HP ProLiant DL585 G5
HP ProLiant DL785 G5
HP ProLiant DL785 G6
ProLiant ML (expansion-optimized)
ProLiant ML (expansion-optimized)ProLiant ML (expansion-optimized)
ProLiant ML (expansion-optimized) :
HP ProLiant ML310 G4
HP ProLiant ML310 G5
HP ProLiant ML310 G5p
HP ProLiant ML350 G4p
HP ProLiant ML350 G5
HP ProLiant ML370 G4
HP ProLiant ML370 G5
HP ProLiant ML570 G3
HP ProLiant ML570 G4
NOTE:
NOTE:NOTE:
NOTE: This is a list of supported servers. Some may be discontinued.
QuickSpecs
HP NC380T PCI Express Dual Port Multifunction Gigabit
HP NC380T PCI Express Dual Port Multifunction GigabitHP NC380T PCI Express Dual Port Multifunction Gigabit
HP NC380T PCI Express Dual Port Multifunction Gigabit
Server Adapter
Server AdapterServer Adapter
Server Adapter
Overview
DA - 12418 Worldwide — Version 21 — February 16, 2010 Page 2

Performance
PerformancePerformance
Performance
Gigabit Ethernet
Gigabit EthernetGigabit Ethernet
Gigabit Ethernet
Throughput
ThroughputThroughput
Throughput
10/100/1000Mbps Ethernet transfer rate delivers outstanding network performance that improves
response time and removes bottlenecks across the entire network.
TCP/IP Protocol
TCP/IP ProtocolTCP/IP Protocol
TCP/IP Protocol
Offloading
OffloadingOffloading
Offloading
TCP/IP Offload Engine (TOE) for Windows moves the processing of data in the TCP protocol stack from
the server CPU to the network card, freeing CPU cycles for other duties. The NC380T supports TOE
when Windows TOE Chimney is installed. With TOE, network communications are improved, and server
efficiency is increased.
Accelerated iSCSI
Accelerated iSCSIAccelerated iSCSI
Accelerated iSCSI Accelerated iSCSI allows the NC380T to multi-function both as a network adapter and as a storage host
bus adapter, thereby providing access to storage boxes and to servers over a single connection.
Additionally, the NC380T offloads the iSCSI software to the hardware for improved performance.
Accelerated iSCSI on 1GbE multifunction server adapters purchased as options ships as a standard
feature, at no additional charge.
Load Balancing
Load BalancingLoad Balancing
Load Balancing Transmit Load Balancing (TLB) and Switch-Assisted Load Balancing (SLB) are two advanced features used
to build a bigger pipe for improved networking bandwidth. These port bonding techniques enable users
to install up to two NC380T adapters in a ProLiant server and aggregate their throughput up to a
theoretical maximum of four Gigabits per second full-duplex transmission. The NC380T can be
configured to work with other NC-series Ethernet server adapter teams supported on ProLiant servers.
Checksum and
Checksum andChecksum and
Checksum and
Segmentation Offloads
Segmentation OffloadsSegmentation Offloads
Segmentation Offloads
and Interrupt Coalescing
and Interrupt Coalescingand Interrupt Coalescing
and Interrupt Coalescing
The NC380T features TCP Checksum Offloads as well as TCP Segmentation Offloads and Interrupt
Coalescence. These features reduce the load on the CPU for overall improved system response. Interrupt
Coalescence is a feature that groups multiple packets and issues a single interrupt to the host. This
process improves host efficiency.
Scalability and Reliability
Scalability and ReliabilityScalability and Reliability
Scalability and Reliability
Tri-Speed Support
Tri-Speed SupportTri-Speed Support
Tri-Speed Support Because the NC380T supports 10Mbps Ethernet and 100Mbps Fast Ethernet in addition to Gigabit
Ethernet, users are guaranteed end-to-end protocol support across their enterprise. Like all HP server
adapters, the NC380T adheres to industry open standards, insuring that it will perform seamlessly with
any network devices that also support IEEE standards.
Network Fault Tolerance
Network Fault ToleranceNetwork Fault Tolerance
Network Fault Tolerance
(NFT)
Network Fault Tolerance, sometimes called "failover" or "NIC redundancy", allows for the installation of
multiple NC380T server adapters or other network adapters so that the active device can be backed up
by a redundant adapter to improve availability. The HP teaming utility also allows users to specify that
when a failed adapter is fixed and replaced, the original adapter resumes its function as the primary
network connection.
QuickSpecs
HP NC380T PCI Express Dual Port Multifunction Gigabit
HP NC380T PCI Express Dual Port Multifunction GigabitHP NC380T PCI Express Dual Port Multifunction Gigabit
HP NC380T PCI Express Dual Port Multifunction Gigabit
Server Adapter
Server AdapterServer Adapter
Server Adapter
Overview
DA - 12418 Worldwide — Version 21 — February 16, 2010 Page 3

Network Management
Network ManagementNetwork Management
Network Management
Auto-negotiation
Auto-negotiationAuto-negotiation
Auto-negotiation The NC380T automatically senses the speed of the device to which it is attached. It also automatically
configures for half or full duplex, depending on the duplex mode of the switch, hub, or router at the
other end of the cable.
Management Support
Management SupportManagement Support
Management Support Like all HP server adapters, the NC380T ships with drivers and agents that can be managed from all
versions of HP Systems Insight Manager, as well as using any management application that supports
SNMP.
Server Integration
Server IntegrationServer Integration
Server Integration HP Systems Insight Manager can recognize the NC380T individually or in port-bonded teams, and can
collect and report SNMP statistics on the adapter events. Additionally, Integrated Management Log (IML)
support is provided by the NC380T for critical event logging on HP servers.
Configuration Utilities
Configuration UtilitiesConfiguration Utilities
Configuration Utilities Each NC380T ships with a set of utilities that allow the user to:
Enable initial diagnostics within Windows, Linux, and DOS operating systems.
Configure network adapter teaming in a Windows environment. The Windows adapter teaming
configuration utility includes a patented teaming GUI for Microsoft Windows 2000 and 2003
operating systems. Support for scripted installations of teams in a Microsoft Windows environment
allow for unattended OS installations.
LED Indicators
LED IndicatorsLED Indicators
LED Indicators Bracket LED indicators show link integrity, network activity, and network speed for easy troubleshooting.
QuickSpecs
HP NC380T PCI Express Dual Port Multifunction Gigabit
HP NC380T PCI Express Dual Port Multifunction GigabitHP NC380T PCI Express Dual Port Multifunction Gigabit
HP NC380T PCI Express Dual Port Multifunction Gigabit
Server Adapter
Server AdapterServer Adapter
Server Adapter
Overview
DA - 12418 Worldwide — Version 21 — February 16, 2010 Page 4

Warranty
WarrantyWarranty
Warranty Additional information regarding worldwide limited warranty and technical support is available at:
http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html
Support Services
Support ServicesSupport Services
Support Services Care Pack services provide a range of life cycle support options that let you choose the service levels that
meet your business requirements, from basic to mission-critical.
A full range of HP Care Pack hardware and software services are available including:
Installation and start up
Education courses
Extended onsite hardware coverage hours from same business day 13 ours, 5 day to 24 hours, 7
days call window with options including 4-hour response or 6-hour Call-To-Repair.
Comprehensive range of software technical support for Microsoft, Linux, ProLiant Essentials, and
VMWare-based IT solutions helping to deliver high level of application availability. Response times
ranging from 30 minutes for critical problems to 2 hours.
System Management, Performance Services and Mission Critical Support Solution
NOTE:
NOTE:NOTE:
NOTE: For more information on HP Care Pack services, contact any of our worldwide sales offices or
resellers or visit our worldwide Web site on the internet at: http://www.hp.com/hps/carepack
NOTE:
NOTE:NOTE:
NOTE: For more complete information on HP Services offerings, customers and resellers, please visit us
at: http://www.hp.com/hps
NOTE:
NOTE:NOTE:
NOTE: Additional information regarding worldwide limited warranty and technical support is available
at: http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html
QuickSpecs
HP NC380T PCI Express Dual Port Multifunction Gigabit
HP NC380T PCI Express Dual Port Multifunction GigabitHP NC380T PCI Express Dual Port Multifunction Gigabit
HP NC380T PCI Express Dual Port Multifunction Gigabit
Server Adapter
Server AdapterServer Adapter
Server Adapter
Service and Support, HP Care Pack, and Warranty Information
DA - 12418 Worldwide — Version 21 — February 16, 2010 Page 5

Gigabit Server Adapters
Gigabit Server AdaptersGigabit Server Adapters
Gigabit Server Adapters HP NC110T PCI Express Gigabit Server Adapter 434905-B21
HP NC112T PCIe Gigabit Server Adapter 503746-B21
HP NC360T PCI Express Dual Port Gigabit Server Adapter 412648-B21
HP NC364T PCI Express Quad Port Gigabit Server Adapter 435508-B21
HP NC373F PCI Express Multifunction Gigabit Server Adapter 394793-B21
HP NC373T PCI Express Multifunction Gigabit Server Adapter 394791-B21
HP NC375T PCI Express Quad Port Gigabit Server Adapter 538696-B21
HP NC382T PCI Express Dual Port Multifunction Gigabit Server Adapter 458492-B21
10 Gigabit Server
10 Gigabit Server10 Gigabit Server
10 Gigabit Server
Adapter
AdapterAdapter
Adapter
HP NC522SFP Dual Port 10GbE Server Adapter
NOTE:
NOTE:NOTE:
NOTE: A minimum of two Gigabytes (2 GB) of server memory is required per each
NC522SFP adapter.
NOTE:
NOTE:NOTE:
NOTE: Direct Attach Cable (DAC) for copper environments or fiber transceivers and
cables for fiber-optic environments must be purchased separately.
468332-B21
HP NC524SFP Dual Port 10GbE Server Adapter
NOTE:
NOTE:NOTE:
NOTE: A minimum of two Gigabytes (2 GB) of server memory is required per each
NC524SFP module.
NOTE:
NOTE:NOTE:
NOTE: Direct Attach Cable (DAC) for copper environments or fiber transceivers and
cables for fiber-optic environments must be purchased separately.
489892-B21
QuickSpecs
HP NC380T PCI Express Dual Port Multifunction Gigabit
HP NC380T PCI Express Dual Port Multifunction GigabitHP NC380T PCI Express Dual Port Multifunction Gigabit
HP NC380T PCI Express Dual Port Multifunction Gigabit
Server Adapter
Server AdapterServer Adapter
Server Adapter
Related Options
DA - 12418 Worldwide — Version 21 — February 16, 2010 Page 6

Compliance
ComplianceCompliance
Compliance IEEE 802.3-2002, 802.3ab, 802.3ad, 802.1Q
PCI Express ver 1.0a
ACPI ver 2.0
General Specifications
General SpecificationsGeneral Specifications
General Specifications Communications
CommunicationsCommunications
Communications
Processors
ProcessorsProcessors
Processors
Broadcom 5706 (two)
On-board memory
On-board memoryOn-board memory
On-board memory 184KB
Data rate
Data rateData rate
Data rate 10/100/1000 Mbps, Half- and full-duplex
Data path
Data pathData path
Data path Four lane (x4) PCI Express compatible with x1, x4, x8, and x16 PCI Express
slots
Interrupt levels
Interrupt levelsInterrupt levels
Interrupt levels INTA
Connectors
ConnectorsConnectors
Connectors RJ-45 (two)
NOTE:
NOTE:NOTE:
NOTE: Port enumeration on NC380T is bottom up i.e. the port nearest to
the gold teeth is port #1 and the port near the top of the adapter is port #2.
Distance
DistanceDistance
Distance Up to 328 ft (100 m)
Wiring
WiringWiring
Wiring Category 5 or better UTP
Dimensions
DimensionsDimensions
Dimensions (L x W) 7.44 x 4.37 in (18.9 x 11.1 cm) without bracket
NOTE:
NOTE:NOTE:
NOTE: Supported on a Full Length-Full Height slot only.
Power and Environmental
Power and EnvironmentalPower and Environmental
Power and Environmental
Specifications
SpecificationsSpecifications
Specifications
Operating
OperatingOperating
Operating Temperature 32° to 131° F (0° to 55° C)
Humidity 10% to 90% non-condensing
Non-operating
Non-operatingNon-operating
Non-operating Temperature -40° to 185° F (-40° to 85° C)
Humidity 5% to 95% non-condensing
Power requirement
Power requirementPower requirement
Power requirement Operating Voltage: 12V +/- 8%
Maximum: 1.05A @ 12V(DC)
Emissions Classifications
Emissions ClassificationsEmissions Classifications
Emissions Classifications FCC Class B
Agency Approvals
Agency ApprovalsAgency Approvals
Agency Approvals USA FCC (CFR 47 part 15) and UL 60950
Canada ICES-003 and CSA60950
Japan VCCI
Korea MIC (RRL), EMC Registration
Australia ACA, AS/NZS3548/EN55022:1998,
EN55024:1998
EU EN55022:1998 (CISPR 22), EN55024:1998,
and IEC60950:1999 (EN60950:2000)
Operating System Support
Operating System SupportOperating System Support
Operating System Support Standard Gigabit Ethernet
Standard Gigabit EthernetStandard Gigabit Ethernet
Standard Gigabit Ethernet Microsoft® Windows 2000 Server
Microsoft Windows HPC Server 2008
Microsoft Windows Server 2003, Standard, and Enterprise
Microsoft Windows Server 2003 x64 edition, Standard and Enterprise
Microsoft certified miniport and teaming drivers
Red Hat Enterprise Linux
SUSE Linux Enterprise Server
SCO OpenServer 6.0.0
SCO UnixWare 7.1.3
SCO UnixWare 7.1.4
Solaris 9
Solaris 10
NDIS 2 for DOS unattended operating system install (43K or less in
QuickSpecs
HP NC380T PCI Express Dual Port Multifunction Gigabit
HP NC380T PCI Express Dual Port Multifunction GigabitHP NC380T PCI Express Dual Port Multifunction Gigabit
HP NC380T PCI Express Dual Port Multifunction Gigabit
Server Adapter
Server AdapterServer Adapter
Server Adapter
Technical Specifications
DA - 12418 Worldwide — Version 21 — February 16, 2010 Page 7

size)
NOTE:
NOTE:NOTE:
NOTE: For more Linux OS support & certification information, please visit
our the ProLiant & BladeSystem Server Linux matrix:
http://h18004.www1.hp.com/products/servers/linux/hplinuxcert.html
TCP/IP Offload
TCP/IP OffloadTCP/IP Offload
TCP/IP Offload Microsoft Windows Server 2008
Microsoft Windows Server 2003, Standard and Enterprise
Microsoft Windows Server 2003 x64 edition,, Standard and Enterprise
Microsoft certified miniport and teaming drivers
Accelerated iSCSI
Accelerated iSCSIAccelerated iSCSI
Accelerated iSCSI Windows Server 2008 Enterprise
Windows Server 2008 x64 Enterprise
Microsoft Windows Server 2003, Standard, and Enterprise
Microsoft Windows Server 2003 x64 edition,, Standard and Enterprise
Microsoft certified miniport and teaming drivers
Environment-friendly
Environment-friendlyEnvironment-friendly
Environment-friendly
Products and Approach
Products and ApproachProducts and Approach
Products and Approach
End-of-life Management
End-of-life ManagementEnd-of-life Management
End-of-life Management
and Recycling
and Recyclingand Recycling
and Recycling
Hewlett-Packard offers end-of-life HP product return, trade-in, and recycling
programs in many geographic areas. For trade-in information, please go to
http://www.hp.com/go/green . To recycle your product, please go to:
http://www.hp.com/go/green or contact your nearest HP sales office.
Products returned to HP will be recycled, recovered or disposed of in a
responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide
treatment information for each product type for use by treatment facilities.
This information (product disassembly instructions) is posted on the Hewlett
Packard web site at: http://www.hp.com/go/green . These instructions may
be used by recyclers and other WEEE treatment facilities as well as HP OEM
customers who integrate and re-sell HP equipment.
© Copyright 2010 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
Windows is a US registered trademark of Microsoft Corporation.
The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and
services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial
errors or omissions contained herein.
QuickSpecs
HP NC380T PCI Express Dual Port Multifunction Gigabit
HP NC380T PCI Express Dual Port Multifunction GigabitHP NC380T PCI Express Dual Port Multifunction Gigabit
HP NC380T PCI Express Dual Port Multifunction Gigabit
Server Adapter
Server AdapterServer Adapter
Server Adapter
Technical Specifications
DA - 12418 Worldwide — Version 21 — February 16, 2010 Page 8
