8340B/8341B Synthesized Sweeper Manual Change 16
08340-90243Ch16
December 1990

HP 8340B
HP 8341B
SYNTHESIZED
SWEEPERS
• •• • ..... • LJ oo DULJLJ
LJUJLJ oooao oo UUUO i
^JULJ o OOQ ^^ oo UCJUU I
ULJL3I-) :LJLJLJL.J UU Ol-l ULIUU {
HEWLETT
PACKARD

HP 8340B
SYNTHESIZED SWEEPER
(Including Options 001, 004,
005, 006, and 007)
HP 8341B
SYNTHESIZED SWEEPER
(Including Option 004)
SERIAL NUMBERS
This manual applies directly to the HP 8340B Synthesized
Sweeper having a serial number prefix of 2624A and the HP 8341 B
Synthesized Sweeper prefixed 2624A.
For additional Information about serial numbers, refer to
INSTRUMENTS COVERED BY THE MANUAL In Section I.
• Manual Changes Supplement Print Date: 03 DEC 1990 Rev, 15
Change Documents
Prefix Change Documents Prefix Change Documents Prefix
2634A
2643A
2650A
2730A
2802A
2804A
2812A
2819A
291 OA
10
11
12
13
14
15
16
2920A
2928A
3006A
3008A
301 OA
3009A
3018A
3050A
© Copyright HEWLETT-PACKARD COMPANY 1986
1400 POUNTAINGROVE PARKWAY, SANTA ROSA, CA 95401 U.S.A.
MANUAL PART NO. 08340-90243
Microfiche Part Number 08340-90244 Printed: AUGUST 1986
i'a HEWLETT
PACKARD

VOLUME 2
TABLE OF CONTENTS
SECTION IV PERFORMANCE TESTS
Introduction .........................
Calibration Cycle .....................
Recommended Test Equipment .........
4-1.
4-2. Internal Time Base Aging Rate .....
Frequency Range and
CW Mode Accuracy .............
Sweep Time Accuracy ............
4-3.
4-4.
4-5.
4-6.
4-7.
Swept Frequency Accuracy ........
Maximum Leveled Output Power
and Power Accuracy Test ........
External Leveling ................
Spurious Signals Test
(10 MHz to 22 GHz - HP 8340B only)
(10 MHz to 20 GHz - HP 8341 B) ....
Spurious Signals Test, 22 to 26.5 GHz
4-8.
4-9.
4-10.
4-11.
4-12.
4-13.
4-14.
4-15.
4-16.
4-17.
(Applies only to HP 8340B) ........
Single Sideband Phase Noise ......
Power Sweep Test ...............
Pulse Modulation On/Off Ratio Test .
Pulse Modulation
Rise and Fall Time Test ..........
Pulse Modulation Accuracy Test ....
Pulse Modulation Video
Feedthrough Test ...............
Amplitude Modulation Test .........
FM Accuracy and Flatness .........
HP 8340B/41B HP-IB Operation
Verification Test ................
Test Record ......................
AUTOMATED TEST PROCEDURES
SECTION V ADJUSTMENTS
Introduction ......................
Safety Considerations ..............
. 4-1
. 4-1
. 4-3
. 4-9
4-13
4-19
4-21
4-25
4-33
4-37
4-41
4-45
4-53
4-55
4-57
4-63
4-67
4-71
4-75
4-83
4-89
5-1
5-1
Equipment Required ...................
Adjustment Tools .....................
Factory Selected Components ...........
Related Adjustments ...................
Location of Test Points and Adjustments ..
Accessing and Storing Calibration Constants
Introduction .........................
Procedure to Access Calibration Constants
Procedure to Store the Calibration Constants
5-1. +22 VDC Power Supply, A35 ......
5-2. 10 MHz Standard Adjustment, A51
5-3. 100 MHz Voltage-Controlled
Crystal Oscillator (VCXO), A30 .....
5-4, M/N Loop, A32, A33, and A32A1 ....
5-5. 20/30 Loop Phase Lock, A36, A38,
A39, A40, and A43 ......„....,.-
5-6. YO Pretune DAC, A54 ............
5-7. YO Main Driver, A55 ....... ....
5-8. YO Loop Adjustments ............
5-9. FM Accuracy and FM
Overmod Adjustment ............
5-10. YO Delay Compensation, A54 ......
5-11. 3.7 GHz Oscillator, A8 ............
5-12. Marker/Bandcross, A57 .........
5-13. Sweep Generator, A58 ...........
5-14. Unleveled RF Output Adjustments ...
5-15. ALC Adjustments ................
5-16. Leveled RF Output Adjustments ...
5-17. RF Output Power
Flatness Adjustment .............
5-18. Pulse Adjustments ...............
5-19. External Module
Leveling Adjustment .............
HP 8340B/41B Table of Contents

Section IV: Performance Tests
INTRODUCTION
The procedures in this section test the HP 8340B and HP 8341 B's electrical performance using the
specifications given in Section I as the performance standards. These tests are intended for use in
incoming inspection, calibration verification, and post-repair performance verification. All tests can be
performed without access to the interior of the instrument. An HP-IB Operation Verification procedure
is also provided at the end of this section to verify proper HP-IB operation of the instrument.
RECOMMENDED TEST EQUIPMENT
Table 4-2 is a complete list of all required equipment for the tests and adjustments supplied in Section
IV, Performance Tests, and Section V, Adjustments. Test equipment other than that noted in the table
may be substituted if it meets or exceeds the critical specifications indicated in the table.
TEST RECORD
Results of the Performance Test procedures may be tabulated on the test record card located at the
end of this section. Each test lists all of the tested specifications and their acceptable limits. The
results recorded at incoming inspection can be used for comparison in periodic maintenance and
troubleshooting and after repairs or adjustments have been made.
CALIBRATION CYCLE
This instrument requires periodic verification of performance. The instrument should be checked
using the following performance tests at least once every year.
NOTE
The acronym "DUT" (Device Under Test) is used to describe the HP
8340B or 8341B (HP 8340B/41B) under test. The acronym "LO" is used to
describe the Local Oscillator.
Options 001, 005, 006, and 007 apply only to HP 8340B's.
HP 8340B/41B Performance Tests 4-1

Table 4-1. List of Manual Performance Tests1
Test Number
4-1
4-2
4-3
4-4
4-5
4-6
4-7
4-8
4-9
4-10
4-111
4-121
4-131
4-14'
4-15
4-16
4-172
1. This test Is not applicable to instruments equipped with Option 006, Delete Pulse Modulation.
2. This is not a Performance Test. It is included as an additional aid to determine that the HP-IB circuitry is operating properly.
Performance Test Title
Internal Time Base Aging Rate
Frequency Range and CW Mode Accuracy
Sweep Time Accuracy
Swept Frequency Accuracy
Maximum Leveled Output Power and Power Accuracy
External Leveling
Spurious Signals Test (10 MHz to 22 GHz - HP 8340B)
(10 MHz to 20 GHz - HP 8341 B)
Spurious Signals Test (22 to 26.5 GHz - HP8340B only)
Single Sideband Phase Noise
Power Sweep Test
Pulse Modulation ON/OFF Ratio Test
Pulse Modulation Rise and Fall Time Test
Pulse Modulation Accuracy Test
Pulse Modulation Video Peedthrough Test
Amplitude Modulation Test
FM Accuracy and Flatness
HP-IB Operation Verification Test
Page
4-9
4-13
4-19
4-21
4-25
4-33
4-37
4-41
4-45
4-53
4-55
4-57
4-63
4-67
4-71
4-75
4-83
Performance Tests HP 8340B/41B
