The latest 1P rack server, HP ProLiant DL320e Gen8 Server series, is a new entry level rack-optimized platform, ideal for single-
application IT infrastructure, web and edge-of-network applications. The ProLiant DL320e Gen8 Server is not only affordable but is
more powerful by enabling powerful quad-core processor computing performance with larger memory & storage capacity, all in a small
package.
The DL320e Gen8 supports the latest technology, such as Intel® Xeon® E3 Pentium processors, PCI-e Gen3, DDR3 1600MHz memory, up
to 12TB internal storage, RAID solution as well as High Efficiency Hot Plug Redundant Power Supply Kit.
HP ProLiant DL320e Gen8 Server series supports HP iLO Management Engine, a complete set of embedded management features
supporting the complete lifecycle of the server, from initial deployment, through ongoing management, to service alerting and remote
support.
Front View: Rear View:
1. Access Panel 1. Expansion slot 2, PCIe x16
2. Power Supply 2. Expansion slot 1, PCIe x8
3. PCI Riser Cage 3. Power Supply 2
4. Processor 4. Power Supply 1
5. DIMMs 5. Dedicated iLO port
6. Fans 6. UID LED button
7. Optical drive 7. Serial Connector
8. 2 USB Connectors 8. Video Connector
9. UID LED button 9. USB Connectors
10. Health LED 10. NIC Connector 1
11. NIC status LED 11. USB Connectors
12. Power On/Standby button and LED 12. NIC Connector 2
13. Hard Drive Bays
QuickSpecs
HP ProLiant DL320e Generation 8 (Gen8)
Overview
DA - 14326 North America — Version 21 — December 13, 2013 Page 1

NOTE: For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information - Factory
Integrated Models" section.
Processor
One of the following
depending on Model
Entry Processors
Intel® Pentium® G2120 (3.1GHz/2-core/3MB/55W) Processor
NOTE: Intel® Pentium® G2120 Processor supports up to 1600MHz DDR3 memory speeds.
Performance Processors
NOTE: All support up to 1600MHz DDR3 memory speeds.
Intel® Xeon® E3-1220Lv2 (2.3GHz/2-core/3MB/17W, HT)
Intel® Xeon® E3-1220v2 (3.1GHz/4-core/8MB/69W)
Intel® Xeon® E3-1230v2 (3.3GHz/4-core/8MB/69W, HT)
Intel® Xeon® E3-1240v2 (3.4GHz/4-core/8MB/69W, HT)
Intel® Xeon® E3-1270v2 (3.5GHz/4-core/8MB/69W, HT)
Intel® Xeon® E3-1290v2 (3.7GHz/4-core/8MB/87W, HT)
NOTE: HT indicates that the processor model supports Intel® /Hyper-Threading Technology (Depends on
the processor).
NOTE: DDR3 speed is the maximum memory speed of the processor. Actual memory speed may depend on
the quantity and type of DIMMs and CPU installed (options for 1600, 1333, 1066MHz).
Cache Memory
One of the following
depending on Model
8MB (1x8MB) Level 3
NOTE: For Quad-core processors.
3MB (1x3MB) Level 3
NOTE: For Dual-core processors.
Chipset Intel® C204 Series Chipset
NOTE: For more information regarding Intel® chipsets, please see the following URL:
http://www.intel.com/products/server/chipsets/ .
Upgradeability Up to 4 DIMM slots available for higher Memory capacity
Up to 8 bay SFF Hot plug Drive Cage; Or 4 bay LFF Hot plug or Non hot plug Drive Cages
1 PCIe 2.0 expansion slot
1 PCIe 3.0 I/O slot for additional communications and storage expansion (depends on processor)
Redundant Power Supply
Optical Drive Bay
On System Management
Processor
HP iLO (Firmware: HP iLO 4)
NOTE: For more information, visit: http://www.hp.com/go/ilo .
Memory Protection ECC
QuickSpecs
HP ProLiant DL320e Generation 8 (Gen8)
Standard Features
DA - 14326 North America — Version 21 — December 13, 2013 Page 2

Memory
One of the following
depending on Model
Type HP SmartMemory
Unbuffered (UDIMM)
DIMM Slots Available 4 DIMMs (2 Channels/ 2 DIMMs per channel)
Maximum Capacity
(UDIMM)
32GB (4 x 8GB@1600MHz)
NOTE: HP memory from previous generation servers are not fully compatible with the HP ProLiant DL320e
Gen8 Server.
NOTE: To realize the performance memory capabilities listed in this document, HP SmartMemory is
required. For additional information, please see the HP SmartMemory QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/14225_na/14225_na.html
NOTE: Depending on the memory configuration and processor model, the memory speed may run at
1600MHz, 1333MHz, or 1066MHz. Please see Memory Population Table or the Online Memory
Configuration Tool at: www.hp.com/go/ddr3memory-configurator .
Network Controller HP Ethernet 1Gb 2-port 330i Adapter
NOTE: The HP ProLiant DL320e Gen8 server has an embedded dual-port network adapter . The server can
be further upgraded with various networking products
Expansion Slots Expansion
Slots #
Technology Bus
Width *
Connector
Width
Form Factor Notes
1 PCIe 2.0 x4 x8 Low profile slot
2 PCIe 3.0 x16 x16 Half-length, full-
height slot
*Indicates the number of physical electrical lanes running to the connector.
NOTE: PCIe 3.0 support with Intel Xeon E3-1200v2 family only.
HP Server ROM HP ROM (Read Only Memory) is now digitally signed using HP's Corporate Signing Service. This signature is
verified before the flash process starts, reducing accidental programming and preventing malicious efforts
to corrupt system ROM.
HP ROM provides for essential initialization and validation of hardware components before control is
passed to the customer-installed operating system. The ROM also provides the capability of booting from
various fixed media (HDD, CD-ROM) and removable media (USB), to continue operation to the operating
system.
HP ROM performs very early configuration of the video controller, to allow monitoring of initialization
progress via an attached monitor. If configuration or hardware errors are discovered during this early
phase of hardware initialization, suitable messages are now displayed on the connected monitor.
Additionally, these configuration or hardware errors are logged to the Integrated Management Log (IML) to
assist in diagnosis.
HP's ProLiant ROM is used to configure the following:
Processor and chipset status registers
System memory, memory map, and memory initialization
System hardware configuration (Integrated PCI devices and optional PCIe cards).
QuickSpecs
HP ProLiant DL320e Generation 8 (Gen8)
Standard Features
DA - 14326 North America — Version 21 — December 13, 2013 Page 3

Customer-specific BIOS configuration (using the HP ROM-Based Setup Utility (RBSU).
NOTE: For further information, please refer to HP's RBSU (ROM based setup utility) user guide:
www.hp.com/support/rbsu .
Storage Controller
One of the following
depending on Model
Entry Models
(Non hot plug)
HP Dynamic Smart Array B120i Controller
NOTE: Supports 3.0Gb/s SATA.
NOTE: Supports RAID 0/1/10 only. It does not have FBWC support so cannot
support advanced RAID (5 onwards). For FBWC, a standup Smart Array
Controller card must be configured.
Base Models
(Hot plug)
HP Dynamic Smart Array B120i Controller
NOTE: Supports 3.0Gb/s SATA.
NOTE: Supports RAID 0/1/10 only. It does not have FBWC support so cannot
support advanced RAID (5 onwards). For FBWC, a standup Smart Array
Controller card must be configured.
Performance Models
(Hot plug)
HP Smart Array P222/512MB FBWC controller
NOTE: P222 can support RAID 0/1/10/5/5+0/6/6+0.
NOTE: HP Smart Array Advanced Pack (SAAP 2.0) is no longer required to
enable RAID 6 & 60 (Advanced Data Guarding). However, controller must be in
firmware version 4.68 (or later).
NOTE: The DL320e Gen8 can support other advanced controllers as well, depending on model and
configuration
NOTE: For set up instructions for HP Smart Array B120i SATA Controller please refer to the HP ProLiant
DL300 series server user guide.
NOTE: For general information about HP Smart Array B120i SATA RAID Controller, please visit:
http://h18004.www1.hp.com/products/servers/proliantstorage/arraycontrollers
/dynamicsmartarray/index.html
Internal Storage Devices Diskette Drive None
Optical Drive Optional
DVD-ROM, DVD-RW
Hard Drives
One of the following
depending on Model
None ship standard (Base Models and Performance Models)
1x NHP 500GB SATA 3.5" drive (Entry Models)
Hard Drive Bays 8 SFF drive bays or 4 LFF Non hot plug/Hot plug
NOTE: HP ProLiant DL320e Series servers offer both SFF, and LFF versions in
CTO. The Optical Drive bay is available with both models.
NOTE: LFF versions are not an upgradeable option from SFF models, or vice
versa, also between Non Hot Plug LFF and Hot Plug LFF.
NOTE: All Pre-configured Models come populated with some hard drive blanks
installed. Should the customer need additional hard drive blanks, they can
order more using either P/N 666987-B21: HP SFF Gen8 Hard Drive Blank Kit or
P/N 666986-B21: HP LFF Gen8 Hard Drive Blank Kit. These part numbers for
single HDD blanks below are also provided should the customer require
replacement HDD blanks for their server.
QuickSpecs
HP ProLiant DL320e Generation 8 (Gen8)
Standard Features
DA - 14326 North America — Version 21 — December 13, 2013 Page 4

Maximum Internal
Storage
Hot Plug SFF SAS 9.6TB 8 x 1.2TB
Hot Plug SFF SATA 8.0TB 8 x 1TB
Hot Plug LFF SAS 16.0TB 4 x 4TB
Hot Plug LFF SATA 16.0TB 4 x 4TB
Hot Plug SFF SAS SSD 6.4TB 8 x 800GB
Hot Plug SFF SATA SSD 6.4TB 8 x 800GB
Hot Plug LFF SATA SSD 3.2TB 4 x 800GB
Non-Hot Plug LFF SATA 12.0 TB 4 x 3TB
Interfaces Serial 1
Video 1 Rear standard video
HP iLO Remote
Management Network Port
1Gb Dedicated
SD slot 1 Internal
NOTE: The SD slot is not a hot-pluggable device. Customers should not
attempt to plug an SD card into the SD slot while the server is powered.
USB 2.0 Ports 7 total: 4 rear, 2 front, 1 internal (Optional)
Industry Standard
Compliance
ACPI 2.0b Compliant
PCIe 3.0
PXE Support
WOL Support
USB 2.0 Compliant
Server Power Cords All Pre-configured Models servers ship with a high voltage server to PDU power cord.
NOTE: HP ProLiant DL servers no longer ship standard with a 12-foot NEMA 5-15P to C13 power cords
(227099-001) that allow connection to 110V US wall outlets in a home or office. ProLiant DL servers are
primarily connected to PDU's in data center racks so they now ship standard with only a PDU 6-foot C-14
to C13 power cord (142258-001). If a user wishes to power a ProLiant DL server using a110V receptacle
(NEMA-15), the 12-foot NEMA 5-15 to C13 power cord must be ordered separately. See Power Cords
section for Worldwide Power Cord options.
Power Specifications To review typical system power ratings use the HP Power Advisor which is available via the online tool
located at URL: www.hp.com/go/proliant-energy-efficient or www.hp.com/go/hppoweradvisor .
NOTE: Power Specification and Technical Content for supported power supplies can be found at:
http://h18000.www1.hp.com/products/quickspecs/14209_na/14209_na.html
QuickSpecs
HP ProLiant DL320e Generation 8 (Gen8)
Standard Features
DA - 14326 North America — Version 21 — December 13, 2013 Page 5

Common Slot Power
Supply
NOTE: The default power supply for DL320e Gen8 server is a 350W Non Hot Plug, Non Redundant (ATX)
power supply with 85% efficiency.
NOTE: To choose a Redundant Common Slot Power Supply option for the DL320e Gen8 server, a Factory
Integrated Model must be chosen, beginning with a CTO server. Also, an HP DL320e Gen8 RPS Enablement
FIO Kit (675451-B21) is required.
HP's Common Slot (CS) power supplies allow for commonality of power supplies across a wide range of
ProLiant and Integrity servers, as well as HP Storage solutions, and are designed to provide the highest
power supply efficiency without degrading system performance. HP CS power supplies are tested by the
Electric Power Research Institute (EPRI) and certified through the ECOS 80 Plus power supply program.
The 460W HP CS power supply option provides an efficiency rating of up to 94%. All HP Common Slot
power sources are UL, CE Mark Compliant, hot-plug and support redundant configurations.
NOTE: Mixing of power supplies (for instance Common Slot Platinum Plus power supplies and Common
Slot Gold power supplies) in the same server is not supported. All power supplies must be of the same
output and efficiency rating. If non-matched power supplies are inserted you will get errors and operation
will fail.
HP CS Platinum Plus power supplies are required when enabling HP's Intelligent Power Discovery (IPD)
solution. IPD is the first technology to create an automated, energy-aware network between IT systems
and facilities. This allows your company to reclaim millions of dollars in wasted power capacity and
downtime costs across data centers. For more information on HP's IPD solution, go to
www.hp.com/go/ipd .
It is highly recommended that you use the HP Power Advisor in defining the "Right-Size" power supply for
your needs. HP Power Advisor can be accessed at: www.hp.com/go/hppoweradvisor .
NOTE: The 80 PLUS program is a unique forum that unites electric utilities, the computer industry, and
consumers in an effort to bring energy efficient technology solutions to the marketplace. 80 Plus
independently tests power supply efficiency and publicly posts the results on 80Plus.org.
Redundant Power: Optional (1+1 or n+n redundant) power supplies can be purchased through power
supply option kits (see Power Supplies for part numbers).
NOTE: Power Specification and Technical Content for supported power supplies can be found at:
http://h18000.www1.hp.com/products/quickspecs/14209_na/14209_na.html
System Fans 4 fan modules ship standard, non-redundant
Operating Systems and
Virtualization Software
Support for ProLiant
Servers
Microsoft Windows Server
Red Hat Enterprise Linux (RHEL)
SUSE Linux Enterprise Server (SLES)
VMware
NOTE: For more information on HP's Certified and Supported ProLiant Servers for OS and Virtualization
Software and latest listing of software drivers available for your server including how to purchase from
HP, please visit our OS Support Site at: http://www.hp.com/go/ossupport and our driver download page:
http://www.hp.com/support/DL320eGen8 .
QuickSpecs
HP ProLiant DL320e Generation 8 (Gen8)
Standard Features
DA - 14326 North America — Version 21 — December 13, 2013 Page 6

Graphics Integrated Matrox G200 video standard
1280 x 1024 (32 bpp)
1920 x 1200 (16 bpp)
HP iLO 4 On System Management Memory
16 MB Flash
256 MB DDR 3 with ECC (112 MB after ECC and video)
Form Factor
One of the following
depending on Model
1U Rack form factor
8 SFF Drive Bay Version:
1.7" (4.32cm) Height x 17.11" (43.46cm) Width x 27.5" (69.90cm) Length
4 LFF Drive Bay Version:
1.7" (4.32cm) Height x 17.11" (43.46cm) Width x 29.5" (75.00cm) Length
On System Management HP iLO Management
Engine
HP iLO Management Engine is a comprehensive set of embedded management
features supporting the complete lifecycle of the server, from initial
deployment, through ongoing management, to service alerting and remote
support. HP iLO Management Engine comes standard on all HP ProLiant Gen8
servers. The HP iLO Management Engine portfolio includes:
HP iLO: The HP iLO (Integrated Lights-Out) management processor is
the core foundation for the HP iLO Management Engine
HP Agentless Management: Provides built in server health monitoring
and alerting capability without OS agents, that starts working the
moment a power cord and an Ethernet cable are connected.
HP Active Health System: Always on, continuous monitoring for
increased stability and shorter downtimes; 100% configuration history;
Health and service alerts and easy export and upload to Service and
Support.
HP Intelligent Provisioning: Lets customers provision and configure a
single server without any separate media. No more SmartStart CDs or
Smart Update Firmware DVD are needed.
To start Intelligent Provisioning:
Press the F10 key during the ProLiant Gen8 server boot
process (also known as power on self test or POST).
Please go to the Intelligent Provisioning website at
www.hp.com/go/intelligentprovisioning for additional
information and to view usage videos.
Use the Service Pack for ProLiant (SPP) at
www.hp.com/go/spp to get firmware and software
updates.
HP iLO Mobile App: Enables the ability to access, deploy, and manage
your server anytime from anywhere from select smartphones and
mobile devices. For additional information please visit:
www.hp.com/go/ilo/mobileapp
NOTE: For more information, visit: http://www.hp.com/go/ilo or HP iLO
QuickSpecs
HP ProLiant DL320e Generation 8 (Gen8)
Standard Features
DA - 14326 North America — Version 21 — December 13, 2013 Page 7

Management Engine technologies whitepaper
HP Insight Management HP Service Pack for
ProLiant
HP Service Pack for ProLiant (SPP) and HP Smart Update Manager (HP SUM)
provide a comprehensive approach to firmware and system software
maintenance. Together they provide better operating stability and ensure
maximum uptime. The SPP will be updated at a predictable cadence, typically
coinciding with new HP server hardware launches. By enabling firmware to be
updated online and integrating firmware and system software updates in one
operation, HP SUM and the SPP offer faster updates of individual servers and
dramatically faster updates of entire BladeSystem enclosures. Further
improving system uptime and stability is the fact that HP provides 12 months
of support for each Service Pack for ProLiant release.
The user experience around HP SUM and the SPP has been improved in several
ways, starting with the web download. A single web page provides access to a
single download containing both the latest version of HP SUM and the latest
SPP. Optional smaller subsets with only specific types of servers or specific
operating systems are offered to save on download time. The HP SUM
application provides a straightforward, intuitive user interface that guides the
user through the steps of discovery, analyses and update, providing
comprehensive information on available updates, criticality and
interdependencies. This information is also available in reports. By providing
the option of multiple local or shared repositories which can be easily updated
from hp.com, HP SUM provides the tools to optimize stability and consistency
throughout the company. While HP SUM and the SPP recommend the
combinations of firmware and system software that HP has found to be the
best practice, the application gives customers the flexibility to set their own
specific baseline.
The Service Pack for ProLiant has been rigorously tested with specific
attention for interaction between firmware, drivers and agents both within the
server as well as in interaction with the BladeSystem enclosure components
(Onboard Administrator and Virtual Connect). This testing ensures the highest
quality as well as providing the input for HP SUM to deploy updates taking into
account all interdepencies, when determining the correct updates and order of
update deployment.
NOTE: The Service Pack for ProLiant (which includes HP SUM) can be
downloaded from www.hp.com/go/spp/download . More information can be
found: http://www.hp.com/go/SmartUpdate , www.hp.com/go/spp and
http://www.hp.com/go/hpsum
Security Power-on password
Administrator's password
QuickSpecs
HP ProLiant DL320e Generation 8 (Gen8)
Standard Features
DA - 14326 North America — Version 21 — December 13, 2013 Page 8

Warranty This product is covered by a global limited warranty and supported by HP Services and a worldwide
network of HP Authorized Channel Partners resellers. Hardware diagnostic support and repair is available
for three years from date of purchase. Support for software and initial setup is available for 90 days from
date of purchase. Enhancements to warranty services are available through HP Care Pack services or
customized service agreements. Hard drives have either a one year or three year warranty; refer to the
specific hard drive QuickSpecs for details.
NOTE: Server Warranty includes 1-Year Parts, 1-Year Labor, 1-Year Onsite support with next business day
response. Warranty repairs may be accomplished through the use of Customer Self Repair (CSR) parts.
These parts fall into two categories: 1) Mandatory CSR parts are designed for easy replacement. A travel
and labor charge will result when customers decline to replace a Mandatory CSR part; 2) Optional CSR
parts are also designed for easy replacement but may involve added complexity. Customers may choose
to have HP replace Optional CSR parts at no charge. Additional information regarding worldwide limited
warranty and technical support is available at:
http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html
QuickSpecs
HP ProLiant DL320e Generation 8 (Gen8)
Standard Features
DA - 14326 North America — Version 21 — December 13, 2013 Page 9

HP Insight management
software
HP Insight Control HP Insight Control, a product option, delivers essential infrastructure
management that can help save time and money by making it easy to deploy,
migrate, monitor, remote control, and optimize your IT infrastructure through
a single, simple management console. HP Insight Control also supports
Location and Power Discovery Services to automate many configuration, asset
tracking, and power management tasks to speed implementation and prevent
downtime. For more information, see http://www.hp.com/go/insightcontrol .
HP Insight Control includes one year of 24 x 7 HP Software Technical Support
and Update Service ensuring rapid access to HP support staff and proactive
delivery of software updates. For more information about this service, see:
http://www.hp.com/services/insight .
HP iLO Essentials HP iLO Essentials license ideal for small and medium business customers. The
specially created HP iLO Essentials (a subset of iLO Advanced functionality)
saves SMB customers time and money, by ease of remote server set up
through the interactive virtual media, lowering operational costs with remote
access via the Integrated Remote Console, and faster time to resolution with
email-based proactive notifications. With this newly designed HP iLO
Essentials license SMB customers now have the option of a server
management package solely design and priced just right for their IT
environments. HP iLO Essentials is available on all HP ProLiant Gen8 e-series
making this an ideal solution for small business owners. For more
information, see: http://www.hp.com/go/iLO/essentials
HP iLO Advanced HP Integrated Lights-Out Advanced License a product option, providing smart
remote server management without compromise. iLO Advanced unlocks the
full set of remote administration functionality for all HP ProLiant servers by
activating the full Virtual Keyboard Video and Mouse remote console, multi-
user collaboration, console record and replay, GUI-based and scripted virtual
media and virtual folders, and enhanced security and power management
functionality. For more information, see: http://www.hp.com/go/iloadvance
HP Matrix Operating
Environment
The HP Matrix Operating Environment (Matrix OE) for ProLiant and Integrity
servers is an integrated command center that helps you instantly adjust to
dynamic business demands. This advanced infrastructure management
software lets you reduce the cost of common data center tasks by up to 40
percent while keeping pace with your changing business.
The HP Matrix OE includes the automated provisioning, optimization, and
recovery management capabilities for HP CloudSystem Matrix, the ideal
platform for private cloud and Infrastructure as a Service (IaaS).
NOTE: For more information, visit: http://www.hp.com/go/matrixoe
QuickSpecs
HP ProLiant DL320e Generation 8 (Gen8)
Optional Features
DA - 14326 North America — Version 21 — December 13, 2013 Page 10

High Performance
Clusters
HP Cluster Platforms HP Cluster Platforms are specifically engineered, factory-integrated large-
scale ProLiant clusters optimized for High Performance Computing, with a
choice of servers, networks and software. Operating system options include
specially priced offerings for Red Hat Enterprise Linux and SUSE Linux
Enterprise Server, as well as Microsoft Windows HPC Server. A Cluster
Platform Configurator simplifies ordering. http://www.hp.com/go/clusters .
HP HPC Interconnects High Performance Computing (HPC) interconnect technologies are available
for this server as part of the HP Cluster Platform portfolio. These high-speed
InfiniBand and Gigabit interconnects are fully supported by HP when
integrated within an HP cluster. Flexible, validated solutions can be defined
with the help of configuration tools.
http://www.hp.com/techservers/clusters/ucp/index.html
HP Insight Cluster
Management Utility
HP Insight Cluster Management Utility (CMU) is an HP-licensed and HP-
supported suite of tools that are used for lifecycle management of hyperscale
clusters of Linux ProLiant systems. CMU includes software for the centralized
provisioning, management and monitoring of nodes. CMU makes the
administration of clusters user friendly, efficient, and effective.
http://www.hp.com/go/cmu
Storage Software Whether you need to solve a specific data protection, archiving, or storage command and control
challenge, or deliver on strategic consolidation, compliance, or continuity initiatives, look no further than
HP storage software. Our storage software helps you reduce costs, simplify storage infrastructure,
protect vital assets and respond faster to business opportunities.
Storage software that gets the job done:
Data Protection and Recovery Software
Whether you're a large enterprise or a smaller business, HP data protection and recovery software
will cost-effectively protect you against disaster and ensure business continuity.
Data Archive and Migration Software
HP's storage software enables you to comply with data retention and retrieval requirements,
improve application performance, and reduce costs by efficiently migrating infrequently accessed
or less valuable data to lower cost storage.
Storage Resource Management Software (SRM)
HP's storage resource management software reduces operational costs and provides the command
and control foundation you need to efficiently manage and visualize your physical and virtual
environments.
Data Replication Software
HP offers array-based and host-based replication software for use in disaster recovery, testing,
application development and reporting.
Storage Device Management Software
Maximize your investment in HP storage and networking with software that enables hardware-
specific configuration, performance tuning and connectivity management.
HP StoreVirtual VSA
With HP StoreVirtual VSA you can use the power of virtualization to turn a set of heterogeneous and
disconnected physical disk drives in your servers and storage devices into a single pool of logical
storage capacity.
NOTE: For more information available Storage Software including QuickSpecs, please see:
www.hp.com/go/storage/software .
QuickSpecs
HP ProLiant DL320e Generation 8 (Gen8)
Optional Features
DA - 14326 North America — Version 21 — December 13, 2013 Page 11

HP Insight Online HP Insight Online is a new addition to the HP Support Center for one stop, secure access to product and HP
support information personalized to your IT environment. Insight Online can automatically display devices
remotely monitored by HP Insight Remote Support. With Insight Online's easy navigation you can
efficiently track your IT support contracts and device status from anywhere and at anytime.
www.hp.com/go/insightonline
HP Proactive Insight
experience
Prevent problems with innovative, automated monitoring tools and proactive services. The HP Proactive
Insight experience consist of using Insight Online, Insight Remote Support, and Proactive Care Support
Service as one integrated solution. The Proactive Insight experience provides you with expert advice and
personalized, cloud-based automated IT support, helping to prevent unplanned down time and solve
problems quickly. For more information, visit: www.hp.com/go/proactiveinsightexperience
Factory Express Portfolio
for Servers and Storage
HP Factory Express offers configuration, customization, integration and deployment services for HP
servers and storage products. Customers can choose how their factory solutions are built, tested,
integrated, shipped and deployed.
Factory Express offers service packages for simple configuration, racking, installation, complex
configuration and design services as well as individual factory services, such as image loading, asset
tagging, and custom packaging. HP products supported through Factory Express include a wide array of
servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades, HP BladeSystem, HP 9000
servers as well as the MSAxxxx, VA7xxx, EVA, XP, rackable tape libraries and configurable network
switches.
For more information on Factory Express services for your specific server model please contact your sales
representative or go to: http://www.hp.com/go/factory-express .
HP Simple Configurator SCE is a guided self service tool to help sales and non technical people provide customers with initial
configurations in 3 to 5 minutes. You may then send the configuration on for configuration help, or use in
your existing ordering processes. If you require "custom" rack configuration or configuration for products
not available in SCE, please contact HP's Customer Business Center or an Authorized Partner for
assistance. http://www.hp.com/products/configurator
QuickSpecs
HP ProLiant DL320e Generation 8 (Gen8)
Optional Features
DA - 14326 North America — Version 21 — December 13, 2013 Page 12

Service and Support HP Technology Services for Industry Standard Servers and BladeSystem
Capitalizing on HP ProLiant server and HP BladeSystem capabilities requires a service partner who
understands your increasingly complex business technology environment. That's why it makes sense to
team up with the people who know HP infrastructure hardware and software best - the experienced
professionals at HP Services.
What HP ProLiant and BladeSystem Services can do for you
HP ProLiant and BladeSystem Services can help you design, deploy, test, integrate, support, and manage
IT and infrastructure solutions. This way, HP proposes services solutions that include more than just uplift
of base warranty. Foundation Care services deliver scalable support-packages for HP industry-standard
servers and software. You can choose the type and level of service that is most suitable for their business
needs. New to this portfolio is HP Collaborative Support. If you are running business critical environments,
HP offers Proactive Care or Critical Advantage. These services help deliver high levels of application
availability through proactive service management and advanced technical response
You can get the support you need by choosing from one of a number of service packaged solutions we
have designed to address wider set of customer support needs.
HP Technology Services meets business challenges with services offered in three support
recommendations - Optimized Care, Standard Care, and Basic Care - available for each product group.
Such support solutions enable customers to optimize technology operations, minimize risk and drive
better business outcomes with easy-to-buy, easy-to-use scalable support recommendations for servers,
storage, networking and software designed to meet your specific needs.
All three service recommendations include support services from the broader portfolio of Foundation Care
and Proactive Care services.
Optimized Care Optimized Care: Supports maintaining servers at optimum performance availability
HP ProLiant Server Hardware Installation
Provides for the basic hardware installation of HP branded servers, storage devices and networking
options to assist you in bringing your new hardware into operation in a timely and professional manner
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-9356EN.pdf
HP Installation and Startup for Insight Control Software / HP SIM
Provides for the deployment and basic configuration of HP Insight Control or HP SIM (Systems Insight
Manager) on HP ProLiant ML and DL series servers or HP BladeSystem servers
http://h20195.www2.hp.com/v2/GetPDF.aspx/4AA0-9972ENW.pdf
3-Year HP 24x7 4 hour Response, Proactive Care
Helps optimize your systems and delivers high levels of application availability through proactive service
management and advanced technical response. A skilled Technical Manager will own your call and end to
end until resolved, delivering a single point of contact for you. Helping you to resolve your hardware and
software issues and minimizing downtime in your business critical environment.
Additional Services: Factory Express, Education Services, Proactive Select - 30 Credit Package
QuickSpecs
HP ProLiant DL320e Generation 8 (Gen8)
Service and Support
DA - 14326 North America — Version 21 — December 13, 2013 Page 13

Standard Care Standard Care: Service recommendation that maintains high level of server availability
HP ProLiant Server Hardware Installation
Provides for the basic hardware installation of HP branded servers, storage devices and networking
options to assist you in bringing your new hardware into operation in a timely and professional manner
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-9356EN.pdf
HP Installation and Startup for Insight Control Software / HP SIM
Provides for the deployment and basic configuration of HP Insight Control or HP SIM (Systems Insight
Manager) on HP ProLiant ML and DL series servers or HP BladeSystem servers
http://h20195.www2.hp.com/v2/GetPDF.aspx/4AA0-9972ENW.pdf
3-Year HP 24x7 4 hour Response, Collaborative Support
Provides problem resolution support across the stack of HW, firmware, and HP and 3rd party SW. In case
the issue is with 3rd party SW, HP does known issue resolution. If HP cannot solve the issue, it will contact
the third-party vendor and create a problem incident on your behalf.
http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA3-8232ENW.pdf
Additional Services: Software support service with 24X7 availability with a 2 hour response, Training
courses on Microsoft, Linux (Red Hat and SUSE), VMware, and HP Insight Software, 10 Proactive Select
Credit package, Factory Express
http://www8.hp.com/us/en/business-services/it-services.html?compURI=1078865
Basic Care Basic Care: delivers minimum recommended support service level
HP ProLiant Server Hardware Installation
Provides for the basic hardware installation of HP branded servers, storage devices and networking
options to assist you in bringing your new hardware into operation in a timely and professional manner
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-9356EN.pdf
3-Year HP 24x7 4 hour Response, Hardware Support Onsite Service
Provides you with rapid remote support and if required an HP authorized technical engineer will be on site
24X7 begin hardware maintenance service within 4 hours of the service request being logged
http://h20195.www2.hp.com/V2/GetPDF.aspx/5982-6547EEE.pdf
3-Year , HP 24x7 Software Support for Insight Control
Provides remote 3-year software support service that delivers comprehensive software services, including
access to HP technical resources and software updates
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-6645EEE.pdf
Additional Services: Factory Express, Education Services, Proactive Select - 10 Credits
Insight Remote Support Provides 24 X 7 remote monitoring, proactive notifications, and problem resolution. Learn more
http://www.hp.com/go/insightremotesupport
QuickSpecs
HP ProLiant DL320e Generation 8 (Gen8)
Service and Support
DA - 14326 North America — Version 21 — December 13, 2013 Page 14

HP Support Center Personalized online support portal with access to information, tools and experts to support HP business
products. Submit support cases online, chat with HP experts, access support resources or collaborate with
peers. Learn more http://www.hp.com/go/hpsc
HP's Support Center Mobile App * allows you to resolve issues yourself or quickly connect to an agent for
live support. Now, you can get access to personalized IT support anywhere, anytime.
HP Insight Remote Support and HP Support Center are available at no additional cost with a HP warranty,
HP Care Pack or HP contractual support agreement.
*HP' Support Center Mobile App is subject to local availability
Warranty / Service
Coverage
For ProLiant servers and storage systems, the services cover HP-branded hardware options qualified for
the server, purchased at the same time or afterward, internal to the enclosure, as well as external
monitors up to 22" and tower UPS products; these items will be covered at the same service level and for
the same coverage period as the server unless the maximum supported lifetime and/or the maximum
usage limitation has been exceeded. Coverage of the UPS battery is not included; standard warranty terms
and conditions apply.
The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives
replaced by HP due to malfunction. It does not apply to any exchange of Disk or SSD/Flash Drives that
have not failed. SSD/Flash Drives that are specified by HP as consumable parts and/or that have exceeded
maximum supported lifetime and/or the maximum usage limit as set forth in the manufacturer's operating
manual or the technical data sheet are not eligible for the defective media retention service feature option.
For more information To learn more on HP ProLiant servers and HP BladeSystem servers, please contact your HP sales
representative or HP Authorized Channel Partner. Or visit: http://www.hp.com/services/proliant
QuickSpecs
HP ProLiant DL320e Generation 8 (Gen8)
Service and Support
DA - 14326 North America — Version 21 — December 13, 2013 Page 15

NOTE: For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information - Factory
Integrated Models" section.
NOTE: Pre-configured models ship with the configurations below. Options can be selected from the Core or Additional options section
of this QuickSpecs.
NOTE: HP does not allow factory integration of options into pre-configured models. Any additional options purchased will be shipped
separately.
NOTE: If you desire a custom configuration please see "Configuration Information - Factory Integrated Models" section of this
QuickSpecs.
NOTE: Maximum speed supported depends on the CPU installed. Entry model will support maximum speed of 1600 MHz.
Please see Memory Population Table or the Online Memory Configuration Tool at: www.hp.com/go/ddr3memory-configurator .
NOTE: All Pre-configured Models come populated with some hard drive blanks installed. Should the customer need additional hard
drive blanks, they can order more using either P/N 666987-B21: HP SFF Gen8 Hard Drive Blank Kit or P/N 666986-B21: HP LFF Gen8
Hard Drive Blank Kit.
Base Models
HP ProLiant DL320e Gen8
E3-1220v2 1P 4GB-U Hot
Plug 4 LFF 350W PS Server
675421-001
Processor(s) (1) Intel® Xeon® E3-1220v2 (3.1GHz/4-core/8MB/69W, HT) Processor
Cache Memory 8MB (1x8MB) Level3
Memory 4GB (1 x 4GB) Unbuffered DIMMs PC3-12800E (1600MHz)
Network Controller HP Ethernet 1Gb 2-port 330i Adapter
Storage Controller HP Dynamic Smart Array B120i Controller
Hard Drive None ship standard
NOTE: Only SATA 3 Gbit/s data transmission guaranteed without HP Smart
Array Card.
Internal Storage 4 bay LFF Hot Plug Drive Cage; includes 3 LFF hard drive blanks
Optical Drive Bay None ships standard
PCI-Express Slots 1 PCIe3 x16 and 1 PCIe2 x8
Power Supply 350 Watts Non-Hot Plug, Non redundant Power Supply
NOTE: The 350 Watts Non-Hot Plug Non redundant Power Supply is rated at
85% efficiency.
Fans 4 fan modules ship standard, non-redundant
Management HP iLO Management Engine (standard)
Optional: HP iLO Essentials or HP Insight Control
Form Factor 1U, HP Friction Rail Kit
Warranty Server Warranty includes 1-Year Parts, 1-Year Labor, 1-Year Onsite support
with next business day response.
QuickSpecs
HP ProLiant DL320e Generation 8 (Gen8)
Pre-configured Models
DA - 14326 North America — Version 21 — December 13, 2013 Page 16

Performance Models
HP ProLiant DL320e Gen8
E3-1240v2 1P 8GB-U P222
Hot Plug 4 LFF 350W PS
Server
675422 -001
Processor(s) (1) Intel® Xeon® E3-1240v2 (3.4GHz/4-core/8MB/69W, HT) Processor
Cache Memory 8MB (1x8MB) Level3
Memory 8GB (2 x 4GB) Unbuffered DIMMs PC3-12800E (1600MHz)
Network Controller HP Ethernet 1Gb 2-port 330i Adapter
Storage Controller HP Smart Array P222/512MB FBWC Controller
Hard Drive None ship standard
Internal Storage 4 bay LFF Hot Plug Drive Cage; includes 3 LFF hard drive blanks
Optical Drive Bay None ships standard
PCI-Express Slots 1 PCIe2 x8 available
Power Supply 350 Watts Non-Hot Plug, Non redundant Power Supply
NOTE: The 350 Watts Non-Hot Plug Non redundant Power Supply is rated at
85% efficiency.
Fans 4 fan modules ship standard, non-redundant
Management HP iLO Management Engine (standard)
Optional: HP Insight Control
Form Factor 1U, HP Friction Rail Kit
Warranty Server Warranty includes 1-Year Parts, 1-Year Labor, 1-Year Onsite support
with next business day response
QuickSpecs
HP ProLiant DL320e Generation 8 (Gen8)
Pre-configured Models
DA - 14326 North America — Version 21 — December 13, 2013 Page 17

HP ProLiant DL320e Gen8
E3-1220v2 1P 4GB-U Non-
hot Plug 4 LFF 350W PS
Server
687520-S01
Processor(s) (1) Intel® Xeon® E3-1220v2 (3.1GHz/4-core/8MB/69W, HT)
Cache Memory 8MB (1x8MB) Level3
Memory 4GB (1 x 4GB) Unbuffered DIMMs PC3-12800E (1600MHz)
Network Controller HP Ethernet 1Gb 2-port 330i Adapter
Storage Controller HP Dynamic Smart Array B120i Controller
Hard Drive (1) HP 1TB 6G SATA 7.2K rpm LFF (3.5-inch) Midline Hard Drive
Internal Storage 4 LFF HDD Bays; includes 3 LFF hard drive blanks
Optical Drive Bay None ships standard
PCI-Express Slots 1 PCIe2 x16 and 1 PCIe2 x8
Power Supply 350 Watts Non-Hot Plug, Non redundant Power Supply
Fans 4 fan modules ship standard, non-redundant
Management HP iLO Management Engine (standard)
Optional: HP Insight Control
Form Factor 1U, HP Friction Rail Kit
Warranty Server Warranty includes 1-Year Parts, 1-Year Labor, 1-Year Onsite support
with next business day response.
HP ProLiant DL320e Gen8
E3-1240v2 1P 8GB-U Hot
Plug 4 LFF 350W PS Server
687519-S01
Processor(s) Intel® Xeon® E3-1240v2 (3.4GHz/4-core/8MB/69W, HT)
Cache Memory 8MB (1x8MB) Level3
Memory 8GB (2 x 4GB) Unbuffered DIMMs PC3-12800E (1600MHz)
Network Controller HP Ethernet 1Gb 2-port 330i Adapter
Storage Controller HP Dynamic Smart Array B120i Controller
Hard Drive None ship standard
Internal Storage 4 LFF HDD Bays; includes 3 LFF hard drive blanks
Optical Drive Bay None ships standard
PCI-Express Slots 1 PCIe2 x16 and 1 PCIe2 x8
Power Supply 350 Watts Non-Hot Plug, Non redundant Power Supply
Fans 4 fan modules ship standard, non-redundant
Management HP iLO Management Engine (standard)
Optional: HP Insight Control
Form Factor 1U, HP Friction Rail Kit
Warranty Server Warranty includes 1-Year Parts, 1-Year Labor, 1-Year Onsite support
with next business day response.
QuickSpecs
HP ProLiant DL320e Generation 8 (Gen8)
Smart Buys
DA - 14326 North America — Version 21 — December 13, 2013 Page 18

NOTE: This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are
ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for information on
configurable product offerings and requirements.
NOTE: Factory Integrated Models must start with a CTO Server.
NOTE: FIO indicates that this option is only available as a factory installable option.
NOTE: All Factory Integrated Models will be populated with sufficient hard drive blanks based on the number of initial hard drives
ordered with the server.
Step 1: Base Configuration (choose one of the following configurable models)
HP Models HP ProLiant DL320e Gen8 Hot Plug 4 LFF Configure-to-order Server
NOTE: All 6G SATA/SAS Drives listed in HDD section are tested and supported for both
3G and 6G speed. A HP Smart Array Controller is required for 6G HDD.
675597-B21
Factory Integrated Model ships with:
1U Chassis with 4 LFF Hot Plug Drive Cage
HP Ethernet 1Gb 2-port 330i Adapter
HP iLO Management Engine (standard)
HP Dynamic Smart Array B120i SATA Controller (RAID 0/1/10)
NOTE: For set up instructions for HP Dynamic Smart Array B120i SATA Controller please
refer to the HP ProLiant DL300 series server user guide
NOTE: For general information about HP Dynamic Smart Array B120i SATA Controller,
please visit:
http://h18004.www1.hp.com/products/servers/proliantstorage/arraycontrollers/
smartarrayb120i/index.html
HP ProLiant DL320e Gen8 Hot Plug 8 SFF Configure-to-order Server 675598-B21
Factory Integrated Model ships with:
1U Chassis with 8 SFF Hot Plug Drive Cage
HP Ethernet 1Gb 2-port 330i Adapter
HP iLO Management Engine (standard)
HP Dynamic Smart Array B120i SATA Controller (RAID 0/1/10)
NOTE: For set up instructions for HP Dynamic Smart Array B120i SATA Controller please
refer to the HP ProLiant DL300 series server user guide
NOTE: For general information about HP Dynamic Smart Array B120i SATA Controller,
please visit:
http://h18004.www1.hp.com/products/servers/proliantstorage/arraycontrollers/
smartarrayb120i/index.html
HP ProLiant DL320e Gen8 Non-hot Plug 4 LFF Configure-to-order Server
NOTE: All 6G SATA/SAS Drives listed in HDD section are tested and supported for both
3G and 6G speed. A HP Smart Array Controller is required for 6G HDD.
675596-B21
Factory Integrated Model ships with:
1U Chassis with 4 LFF Non hot plug Drive Cage
HP Ethernet 1Gb 2-port 330i Adapter
HP iLO Management Engine (standard)
HP Dynamic Smart Array B120i SATA Controller (RAID 0/1/10)
NOTE: For set up instructions for HP Dynamic Smart Array B120i SATA Controller please
refer to the HP ProLiant DL300 series server user guide
NOTE: For general information about HP Dynamic Smart Array B120i SATA Controller,
please visit:
QuickSpecs
HP ProLiant DL320e Generation 8 (Gen8)
Configuration Information - Factory Integrated Models
DA - 14326 North America — Version 21 — December 13, 2013 Page 19

http://h18004.www1.hp.com/products/servers/proliantstorage/arraycontrollers/
smartarrayb120i/index.html
Step 2: Choose Required Options (only one of the following from each list unless otherwise
noted)
HP Processors Entry Processors
NOTE: All support up to1600MHz DDR3 memory speeds.
HP DL320e Gen8 Intel® Pentium® G2120 (3.1GHz/2-core/3MB/55W) FIO Processor Kit 703278-L21
Performance Processors
NOTE: All support up to 1600MHz DDR3 memory speeds.
HP DL320e Gen8 Intel® Xeon® E3-1220Lv2 (2.3GHz/2-core/3MB/17W) FIO Processor Kit 682789-L21
HP DL320e Gen8 Intel® Xeon® E3-1220v2 (3.1GHz/4-core/8MB/69W) FIO Processor Kit 682787-L21
HP DL320e Gen8 Intel® Xeon® E3-1230v2 (3.3GHz/4-core/8MB/69W) FIO Processor Kit 682785-L21
HP DL320e Gen8 Intel® Xeon® E3-1240v2 (3.4GHz/4-core/8MB/69W) FIO Processor Kit 682783-L21
HP DL320e Gen8 Intel® Xeon® E3-1270v2 (3.5GHz/4-core/8MB/69W) FIO Processor Kit 682781-L21
HP DL320e Gen8 Intel® Xeon® E3-1290v2 (3.7GHz/4-core/8MB/87W) FIO Processor Kit 682777-L21
HP Memory NOTE: To realize the performance memory capabilities listed in this document, HP
SmartMemory is required. For additional information, please see the HP SmartMemory
QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/14225_na/14225_na.html
NOTE: HP memory from previous generation servers are not fully compatible with new
Active Health features on the DL320e Gen8 Server.
Unbuffered with ECC DIMMs (UDIMMs)
HP 2GB (1x2GB) Single Rank x8 PC3-12800E (DDR3-1600) Unbuffered CAS-11 Memory
Kit
669320-B21
HP 2GB (1x2GB) Single Rank x8 PC3L-10600E (DDR3-1333) Unbuffered CAS-9 Low
Voltage Memory Kit
647905-B21
HP 2GB (1x2GB) Single Rank x8 PC3L-10600E (DDR3-1333) Unbuffered CAS-9 Low
Voltage Memory Kit/S-Buy
647905-S21
HP 4GB (1x4GB) Dual Rank x8 PC3-12800E (DDR3-1600) Unbuffered CAS-11 Memory
Kit
669322-B21
HP 4GB (1x4GB) Dual Rank x8 PC3L-10600E (DDR3-1333) Unbuffered CAS-9 Low
Voltage Memory Kit
647907-B21
HP 4GB (1x4GB) Dual Rank x8 PC3L-10600E (DDR3-1333) Unbuffered CAS-9 Low
Voltage Memory Kit/S-Buy
647907-S21
HP 8GB (1x8GB) Dual Rank x8 PC3-12800E (DDR3-1600) Unbuffered CAS-11 Memory
Kit
669324-B21
HP 8GB (1x8GB) Dual Rank x8 PC3L-10600E (DDR3-1333) Unbuffered CAS-9 Low
Voltage Memory Kit
647909-B21
NOTE: All DDR3 memory option kits consist of one DIMM per kit. For detailed memory
configuration rules and guidelines, please use the Online DDR3 Memory Configuration
Tool: www.hp.com/go/ddr3memory-configurator .
NOTE: Depending on the memory configuration and processor model, 1600MHz and
QuickSpecs
HP ProLiant DL320e Generation 8 (Gen8)
Configuration Information - Factory Integrated Models
DA - 14326 North America — Version 21 — December 13, 2013 Page 20
