HP StorageWorks D2D Backup System
release notes
Part number: EH880-90963
1st edition: February 2008

Description
This document outlines the functional changes and defect fixesfortheHPStorageWorksD2DBackup
System introduced between firmware kn77 (001.395) and kn7B (001.559).
Update recommendation Recommended
Supersedes These release notes (part number EH880-90963) supersede those dated September 2007.
Product models
EH880A -- HP D2D110 Backup System
EH923A -- HP D2D110 Backup System with Data Protector Express SW Kit
EH884A -- HP D2D120 Backup System
EH924A -- HP D2D120 Backup System with Data Protector Express SW Kit
EH881A -- HP D2D110 Backup Sys/Ultr 448 Tape Drive
EH885A -- HP D2D120 Backup Sys/Ultr 920 Tape Drive
DW085A -- Ultrium 448 SAS Tape Drive for D2D110
EH847A -- Ultrium 920 SAS Tape Drive for D2D120
Operating systems
Cross operating system (BIOS, Firmware, Diagnostics, etc.)
Languages
Chinese (Simplified)
Chinese (Traditional)
English
French
German
Greek
Italian
Japanese
Korean
Polish
Portuguese
Russian
Spanish
Enhancements
•Increased maximum number of emulated target devices from four to six.
•Changed default emulation type for tape drive devices from Ultrium 2 to Ultrium 3.
•Added Ultrium 4 to tape attach support matrix.
•Included more error messages that generate email alerts.
HP StorageWorks D2D Backup System release notes 3

Fixes
•Firmware in attached tape drives can be updated.
Prerequisites
Requires Microsoft Internet Explorer 6.x or higher or Mozilla Firefox 1.5 or 2.x.
Installation instructions
NOTE:
During the update the HP D2D Backup System will reboot. After the update all configuration settings
on the HP D2D Backup System will be retained.
1. Save the firmware image file on a server or PC that is connected to the same subnet as the HP
D2D Backup System.
2. From a Web Browser, launch the HP StorageWorks D2D Backup System Web Management Interface
by typing in the IP address of the HP D2D Backup System to be updated.
3. Ensure that there are no current or scheduled backup jobs that will occur during the firmware update
period, because the HP D2D Backup System will reboot during the update process.
4. Log in and navigate to the Firmware Page.
5. Select the Browse button in order to locate the firmware image on the host system.
6. Select Upload update the firmware.
NOTE:
Do NOT navigate away from the firmware page.
7. The LEDs on the HP D2D Backup System will flash a firmware update pattern (alternate amber
and green).
8. After a few seconds the HP D2D Backup System will reboot, completion of the reboot is indicated by
all LEDs returning to current system status (generally all green).
9. Reconnect to the Web Management interface to observe that the upgrade has completed successfully.
10. Manually log back on to the HP D2D Backup System iSCSI targets via the iSCSI initiator from each
system. Use the HP D2D Backup System as a backup target. Alternatively, if targets have been made
persistent (restore automatically on reboot), simply reboot the host systems.
11 . To make use of new autoloader functionality any previously configured autoloaders should have
their emulation type changed to the new HP 1x8 G2 Autoloader emulation. To do this, use the
devices page from the web management interface.
Determining current version
From a Web Browser, launch the HP StorageWorks D2D Backup System Web Management Interface
by typing in the IP address of the HP D2D Backup System to be updated. Navigate to the Firmware
Pagewhich displays the current firmware version.
Effective date
February 11, 2008
