HP StorageWorks SSL1016 User instructions

Introduction
IntroductionIntroduction
Introduction
The HP StorageWorks SSL1016 tape autoloader combines library features and capacity in the compact form of an autoloader. Ideal
for replicated systems, the web-based management feature reduces dependence on local IT resources allowing multiple sites to be
supported centrally. With a native capacity of up to 3.2 TB, the SSL1016 easily replaces a small library for many applications. At 2U
in height, it provides a large amount of storage without consuming a large amount of valuable rack space.
What's New
What's NewWhat's New
What's New
Allows HP Factory Express racking capability through the use of a factory integration option (#0D1)
Models
ModelsModels
Models
HP StorageWorks
HP StorageWorksHP StorageWorks
HP StorageWorks
SSL1016 Tape
SSL1016 TapeSSL1016 Tape
SSL1016 Tape
Autoloader Models
Autoloader ModelsAutoloader Models
Autoloader Models
SSL1016 Ultrium 460 Tape Autoloader
NOTE:
NOTE:NOTE:
NOTE: One Ultrium 460 drive, 16-slot autoloader, rack-ready model; includes
remote management card, barcode reader and tabletop conversion kit.
330821-B21
SSL1016 SDLT 320 Tape Autoloader
NOTE:
NOTE:NOTE:
NOTE: One SDLT 320 drive, 16-slot autoloader, rack-ready model; includes remote
management card, barcode reader and tabletop conversion kit.
330816-B21
Key Features
Key FeaturesKey Features
Key Features Remote web management
Native capacity up to 3.2 TB with Ultrium 460 tape drive
Native data transfer rate up to 30 MB/s with Ultrium 460 tape drive
2U form factor (rack mount or tabletop)
16 cartridge capacity with user-selectable import/export slot
Integrated bar code reader
Two eight-cartridge removable magazines
Modular design for easier maintenance and upgrade capabilities
Two 8-cartridge removable magazines
QuickSpecs
HP StorageWorks SSL1016 Tape Autoloader
HP StorageWorks SSL1016 Tape AutoloaderHP StorageWorks SSL1016 Tape Autoloader
HP StorageWorks SSL1016 Tape Autoloader
Overview
DA - 11839 North America — Version 13 — September 16, 2005 Page 1

Customer Benefits
Customer BenefitsCustomer Benefits
Customer Benefits Manageable
ManageableManageable
Manageable : web-based remote manageability allows monitoring and management from
anywhere in the world
Automated
AutomatedAutomated
Automated : features a standard bar code reader for improved media management
Compact
CompactCompact
Compact : saves valuable rack space with 2U form factor
High-capacity
High-capacityHigh-capacity
High-capacity : stores up to 3.2 TB (native) of data with Ultrium 460 technology
Efficient
EfficientEfficient
Efficient : uses two removable eight-slot magazines for bulk-loading of tape media
Affordable
AffordableAffordable
Affordable : provides library features in the form factor and price range of a tape autoloader
Diverse
DiverseDiverse
Diverse : supports Ultrium 460 and SDLT 320 drive technologies
Reliable
ReliableReliable
Reliable : modular design allows quick repair to reduce product downtime
Integrated:
Integrated:Integrated:
Integrated: ability to factory rack integrate with other HP products such as HP ProLiant Servers
Compatible
CompatibleCompatible
Compatible : runs with leading servers, operating systems and backup software
Family Comparison
Family ComparisonFamily Comparison
Family Comparison SSL1016 Ultrium 460
SSL1016 Ultrium 460SSL1016 Ultrium 460
SSL1016 Ultrium 460
Tape Autoloader
Tape AutoloaderTape Autoloader
Tape Autoloader
SSL1016 SDLT 320
SSL1016 SDLT 320SSL1016 SDLT 320
SSL1016 SDLT 320
Tape Autoloader
Tape AutoloaderTape Autoloader
Tape Autoloader
Drive Technology
Drive TechnologyDrive Technology
Drive Technology Ultrium 460 SDLT 320
Capacity (native)
Capacity (native)Capacity (native)
Capacity (native) 3.2 TB 2.56 TB
Maximum Data Transfer
Maximum Data TransferMaximum Data Transfer
Maximum Data Transfer
(native)
(native)(native)
(native)
30 MB/s 16 MB/s
SCSI Interface
SCSI InterfaceSCSI Interface
SCSI Interface Ultra3 SCSI LVD/SE Ultra2 SCSI LVD/SE
QuickSpecs
HP StorageWorks SSL1016 Tape Autoloader
HP StorageWorks SSL1016 Tape AutoloaderHP StorageWorks SSL1016 Tape Autoloader
HP StorageWorks SSL1016 Tape Autoloader
Overview
DA - 11839 North America — Version 13 — September 16, 2005 Page 2

Capacity
CapacityCapacity
Capacity The SSL1016 Tape Autoloader family offers different capacity points:
The SSL1016 Ultrium 460 Tape Autoloader supports 16 data cartridges for a total capacity of 3.2
TB (native).
The SSL1016 SDLT 320 Tape Autoloader supports 16 data cartridges for a total capacity of 2.56
TB (native).
Easy Installation
Easy InstallationEasy Installation
Easy Installation The SSL1016 Tape Autoloader is shipped as a rack-ready unit; ready for installation in a standard 19"
rack. A tabletop conversion kit is also included in the box for those customers who choose to use the
autoloader on a desktop.
HP Factory Express
HP Factory ExpressHP Factory Express
HP Factory Express
Capability
CapabilityCapability
Capability
HP Factory Express gives the customer the flexibility to choose from a full menu of factory capabilities all
in one manufacturing facility, in one process, with one touch. It gives the customer full control and
access to HP's world-class manufacturing facilities anytime. This approach provides the customer with the
speed to deploy his or her IT needs, with total quality assurance, reliability and predictability to lower the
total cost of ownership; allowing HP to install, rack and customize the software and hardware options the
customer has chosen.
Manageability
ManageabilityManageability
Manageability The SSL1016 Tape Autoloader allows web-based remote manageability; the unit can be monitored and
managed from across the room or across the globe. Functions included in the management tool include:
Status information on the drive and system
System configuration operations and reporting
System error and status logs
Library and drive firmware upload capabilities
Language support through firmware upgrades
Diagnostic tests and information
Cartridge movement for maintenance and management purposes
Cleaning cartridge support
Security and access control
SNMP support for IP communications
LTO Ultrium Technology
LTO Ultrium TechnologyLTO Ultrium Technology
LTO Ultrium Technology HP StorageWorks LTO (Linear Tape Open) Ultrium Tape Drives use best of breed technology. By taking
the best features from other tape technologies and combining them into a single new technology,
Ultrium tape drives are in a league of their own. Inclusion of innovative features such as Adaptive Tape
Speed (ATS) ensure that Ultrium drives can meet the performance and reliability demands of a library
environment. LTO technology is an open industry standard format; thus data written on HP
StorageWorks Ultrium Tape Drives can be interchanged directly with Ultrium Tape Drives from other
vendors.
Performance
PerformancePerformance
Performance The SSL1016 Tape Autoloader family offers different performance points:
Utilizing an HP StorageWorks Ultrium 460 drive, the SSL1016 Tape Autoloader can transfer data
at 30 MB/s or 108 GB/hr (native).
Utilizing an HP StorageWorks SDLT 320 drive, the SSL1016 Tape Autoloader can transfer data at
16 MB/s or 57.6 GB/hr (native).
QuickSpecs
HP StorageWorks SSL1016 Tape Autoloader
HP StorageWorks SSL1016 Tape AutoloaderHP StorageWorks SSL1016 Tape Autoloader
HP StorageWorks SSL1016 Tape Autoloader
Product Highlights
DA - 11839 North America — Version 13 — September 16, 2005 Page 3

SDLT Technology
SDLT TechnologySDLT Technology
SDLT Technology DLT (digital linear tape) uses a proven linear recording technology, a highly accurate tape guide system,
and a read after write correction system to provide high-capacity, high reliability data backup and
restoration. DLT has fast become the industry-standard secondary storage tape format for departmental
and enterprise backup. The new generation SDLT tape drive, provides enhanced capacity and backup
performance and includes several new features such as laser guided magnetic recoding (LGMR)
technology, pivoting optical servo (POS), magneto-resistive cluster heads (MRC), partial response
maximum likelihood (PRML) channel technology and backward-read compatibility with earlier
generations of DLT drives (to be able to read media written in DLT type IV format).
Serviceability
ServiceabilityServiceability
Serviceability Modular in construction, the SSL1016 Tape Autoloader has easily replaceable components minimizing
the Mean-Time-to-Repair on the unit. Replaceable components include the drive/power supply/controller
board, the magazines, and the chassis/robot.
HP StorageWorks Library and Tape Tools (L&TT) provides easy access to the SSL1016 Tape Autoloader
error log, generates support tickets, and enables firmware downloads. L&TT can be downloaded for free
at http://www.hp.com/support/tapetools
QuickSpecs
HP StorageWorks SSL1016 Tape Autoloader
HP StorageWorks SSL1016 Tape AutoloaderHP StorageWorks SSL1016 Tape Autoloader
HP StorageWorks SSL1016 Tape Autoloader
Product Highlights
DA - 11839 North America — Version 13 — September 16, 2005 Page 4

HP StorageWorks Library
HP StorageWorks LibraryHP StorageWorks Library
HP StorageWorks Library
and Tape Tools
and Tape Toolsand Tape Tools
and Tape Tools
The SSL1016 Tape Autoloader is supported on HP's industry-leading diagnostic tool - HP StorageWorks
Library and Tape Tools (L&TT). L&TT is a single, convenient program that's a snap to install and simple to
operate. L&TT's intuitive user interface eliminates the need for training and deploys in less than five
minutes. This robust diagnostic tool is designed for both the experienced professional and the untrained
administrator. It ensures product integrity through self-diagnostics and fast resolution to device concerns.
Additional information on L&TT plus download information can be found at
http://www.hp.com/support/tapetools .
Insight Manager
Insight ManagerInsight Manager
Insight Manager The SSL1016 Tape Autoloader is supported for use with Insight Manager 7.0 and above.
QuickSpecs
HP StorageWorks SSL1016 Tape Autoloader
HP StorageWorks SSL1016 Tape AutoloaderHP StorageWorks SSL1016 Tape Autoloader
HP StorageWorks SSL1016 Tape Autoloader
Software Components
DA - 11839 North America — Version 13 — September 16, 2005 Page 5

HP's extensive compatibility testing program assures that your HP StorageWorks SSL1016 Tape Autoloader works with leading
servers, operating systems, and backup applications - and not just those sold by HP. The SSL1016 Tape Autoloader works
seamlessly in many environments, making them especially suitable if you have a mixed system environment. For the latest list of
servers, workstations, operating systems, and backup software that support HP StorageWorks SSL1016 Tape Autoloader, check the
tape backup compatibility pages on our web site at http://www.hp.com/go/ebs .
HP Server Compatibility
HP Server CompatibilityHP Server Compatibility
HP Server Compatibility The HP StorageWorks SSL1016 Tape Autoloader is supported on a wide range of HP systems. For details
of which SSL1016 Tape Autoloader works with which systems, including third-party systems, reference the
EBS compatibility matrix at http://www.hp.com/go/ebs for the latest hardware compatibility information.
OS Support
OS SupportOS Support
OS Support Reference the EBS compatibility matrix for the most up-to-date OS compatibility information at
http://www.hp.com/go/ebs .
Software Support
Software SupportSoftware Support
Software Support Reference the EBS compatibility matrix for the most up-to-date software compatibility information at
http://www.hp.com/go/ebs .
QuickSpecs
HP StorageWorks SSL1016 Tape Autoloader
HP StorageWorks SSL1016 Tape AutoloaderHP StorageWorks SSL1016 Tape Autoloader
HP StorageWorks SSL1016 Tape Autoloader
Compatibility
DA - 11839 North America — Version 13 — September 16, 2005 Page 6

Warranty
WarrantyWarranty
Warranty The warranty for this product consists of 1-year parts exchange.
Warranty Upgrade
Warranty UpgradeWarranty Upgrade
Warranty Upgrade
Options
OptionsOptions
Options
Response - Upgrade on-site response from next business day to same day 4 hours
Coverage - Extend hours of coverage from 13 hours x 5 days to 24 hours x 7 days
Duration - Select duration of coverage for a period of 1 or 3 years
HP Care Pack Information
HP Care Pack InformationHP Care Pack Information
HP Care Pack Information HP Care Pack is defined as an upgrade to the product warranty attribute, available for a specific
duration and hours of coverage
HP Care Pack is not available for less than the product's warranty duration
HP Care Pack is available for sale anytime during the warranty period for most products, but the
commencement date will be the same as the Warranty Start Date (delivery date to end user
customer). Proof of purchase may be required
HP Care Pack services are prepaid
For additional HP Care Pack (hardware and software) information, as well as orderable part
numbers, please refer to the URL listed below:
http://www.hp.com/hps/carepack/
Software Product Services
Software Product ServicesSoftware Product Services
Software Product Services Standalone telephone support
Media and documentation updates
Hardware Product
Hardware ProductHardware Product
Hardware Product
Services
ServicesServices
Services
Installation services
On-site maintenance (includes warranty support)
Response time upgrades during the warranty period
Post-warranty coverage
For additional hardware installation and maintenance information, please refer to the URL listed below:
http://www.hp.com/hps/hardware/
Support Services
Support ServicesSupport Services
Support Services HP Services provides a three-year, limited warranty, fully supported by a worldwide network of resellers
and service providers and 9x5 hardware technical phone support during the warranty period. In
addition, available service offerings include a full range of optional packaged hardware and software
services:
Installation and start up
Extended coverage hours and enhanced response times
System management and performance services
Availability and recovery services
Components
ComponentsComponents
Components The following brick level options/components do not have individual HP Care Pack Services. These items
will be included in product HP Care Pack Services into which they are installed.
Disk Drives Tape Drives CD/DVD ROM SCSI Hubs in SBBs Adapters
Bus Converters Backplane RAID
Controllers
Power Supplies Cabling Fans
QuickSpecs
HP StorageWorks SSL1016 Tape Autoloader
HP StorageWorks SSL1016 Tape AutoloaderHP StorageWorks SSL1016 Tape Autoloader
HP StorageWorks SSL1016 Tape Autoloader
Service and Support, HP Care Pack and Warranty Information
DA - 11839 North America — Version 13 — September 16, 2005 Page 7

NOTE:
NOTE:NOTE:
NOTE: The HP StorageWorks SSL1016 Tape Autoloader comes standard as a one drive, 16-slot unit which is shipped rack-ready. A
power cord and tabletop installation kit is included in the box.
Step 1 - SSL1016 Tape Autoloader-Base Configuration
Step 1 - SSL1016 Tape Autoloader-Base ConfigurationStep 1 - SSL1016 Tape Autoloader-Base Configuration
Step 1 - SSL1016 Tape Autoloader-Base Configuration
Select one:
Select one:Select one:
Select one:
Model Name
Model NameModel Name
Model Name Model Description
Model DescriptionModel Description
Model Description Part Number
Part NumberPart Number
Part Number
SSL1016 Ultrium 460 HP StorageWorks SSL1016 Ultrium 460 Tape Autoloader 330821-B21
SSL1016 SDLT 320 HP StorageWorks SSL1016 SDLT 320 Tape Autoloader 330816-B21
Kit Contents (for each autoloader):
Kit Contents (for each autoloader):Kit Contents (for each autoloader):
Kit Contents (for each autoloader):
(1) 6' power cord (IEC320-C13 to NEMA 5-15P)
(1) data cartridge (specific to tape drive)
(1) 2.5M VHDCI to VHDCI SCSI cable
(1) RJ-45 Ethernet cable
(1) VHDCI SCSI terminator
(1) tabletop installation kit
(1) rackmount installation kit (for use with HP E series rack or HP 10000 rack cabinet)
Bar code label sample pack specific to drive type (label quantity varies by drive type)
Documentation kit including manual (CD), quick start poster, warranty card, safety
card, HP OpenView Storage Data Protector flier
Step 2: Required Options
Step 2: Required OptionsStep 2: Required Options
Step 2: Required Options
Select each required option with quantities specified:
Select each required option with quantities specified:Select each required option with quantities specified:
Select each required option with quantities specified:
Power Cord
Power CordPower Cord
Power Cord Description with Parts Shipped
Description with Parts ShippedDescription with Parts Shipped
Description with Parts Shipped Quantity
QuantityQuantity
Quantity Part Number
Part NumberPart Number
Part Number
NOTE:
NOTE:NOTE:
NOTE: One power cord is required.
WARNING:
WARNING:WARNING:
WARNING: This product can ONLY be used with an HP approved power cord. Use of a non-HP
approved power cord may result in: 1) not meeting safety requirements; 2) insufficient conductor
ampacity that could result in overheating with potential personal injury and/or property damage; and 3)
an unapproved power cord could fracture resulting in the internal contacts being exposed, which
potentially could subject the user to a shock hazard. HP disclaims all liability in the event a non-HP
approved power cord is used.
QuickSpecs
HP StorageWorks SSL1016 Tape Autoloader
HP StorageWorks SSL1016 Tape AutoloaderHP StorageWorks SSL1016 Tape Autoloader
HP StorageWorks SSL1016 Tape Autoloader
Configuration Information
DA - 11839 North America — Version 13 — September 16, 2005 Page 8

Factory Racking
Factory RackingFactory Racking
Factory Racking Factory integrate the SSL1016 Tape Autoloader with other HP products such as HP ProLiant Servers.
NOTE:
NOTE:NOTE:
NOTE: #0D1 will appear after the 1/8 Tape Autoloader part number on the sales order if HP factory
integration is indicated.
Magazine Kits
Magazine KitsMagazine Kits
Magazine Kits Additional 8-slot magazine for use in the SSL1016 Ultrium 460 Tape Autoloader 330823-B21
Additional 8-slot magazine for use in the SSL1016 SDLT 320 or DLT1 Tape
Autoloader
268664-B22
Media
MediaMedia
Media HP Ultrium 400 GB data cartridge (1 pack) C7972A
HP Ultrium universal cleaning cartridge (1 pack) C7978A
HP Ultrium 2 bar code labels (100 pack) Q2002A
HP Ultrium 400GB prelabeled data cartridge, 20pk C7972AL
HP SDLT 320 GB data cartridge (1 pack) C7980A
HP SDLT cleaning cartridge (1 pack) C7982A
HP SDLT bar code labels (100 pack) Q2003A
HP SDLT prelabeled data cartridge, 20pk C7980AL
Rack Cabinets
Rack CabinetsRack Cabinets
Rack Cabinets 10622 (22U) Rack Cabinet - Shock Pallet 245163-B22
10636 (36U) Rack Cabinet - Shock Pallet 245162-B22
10642 (42U) Rack Cabinet - Shock Pallet 245161-B22
NOTE:
NOTE:NOTE:
NOTE: The SSL1016 Tape Autoloader is certified to ship in HP 10000 series racks
which include a shock pallet. It is mandatory to use a shock pallet in order to ship
racks with equipment installed.
5642 (42U) Rack Cabinet 358254-B21
NOTE:
NOTE:NOTE:
NOTE: This rack ships unassembled and boxed on a standard size pallet. It is an
industry standard 19" wide rack with side panels and rear doors; does not ship with
the front door or casters.
Host Bus Adapters
Host Bus AdaptersHost Bus Adapters
Host Bus Adapters Reference the EBS matrix for the most up-to-date SCSI HBA compatibility information
at http://www.hp.com/go/ebs
Cable Kits
Cable KitsCable Kits
Cable Kits Reference the Data Cable data sheets for the most up-to-date cable information at:
http://iss.tsgonline.hp.com/Document_Storage/collateral/ds_scsimultimode.pdf
QuickSpecs
HP StorageWorks SSL1016 Tape Autoloader
HP StorageWorks SSL1016 Tape AutoloaderHP StorageWorks SSL1016 Tape Autoloader
HP StorageWorks SSL1016 Tape Autoloader
Related Options
DA - 11839 North America — Version 13 — September 16, 2005 Page 9

HP Care Pack Options
HP Care Pack OptionsHP Care Pack Options
HP Care Pack Options Same Day Response
Same Day ResponseSame Day Response
Same Day Response
Warranty upgrade to 1-year, 13x5, 4 hour response/onsite U6364A
Warranty upgrade to 1-year, 13x5, 4 hour response/onsite, electronic U6364E
Warranty upgrade to 1-year, 24x7, 4 hour response/onsite U6365A
Warranty upgrade to 1-year, 24x7, 4 hour response/onsite, electronic U6365E
Warranty upgrade to 3-year, 13x5, 4 hour response/onsite H5526A
Warranty upgrade to 3-year, 13x5, 4 hour response/onsite, electronic H5526E
Warranty upgrade to 3-year, 24x7, 4 hour response/onsite H4624A
Warranty upgrade to 3-year, 24x7, 4 hour response/onsite, electronic H4624E
Next Business Day Response
Next Business Day ResponseNext Business Day Response
Next Business Day Response
Warranty upgrade to 3-year next business day/parts exchange H2698A
Warranty upgrade to 3-year next business day/parts exchange, electronic H2698E
Warranty upgrade to 3-year next business day/onsite H4619A
Warranty upgrade to 3-year next business day/onsite, electronic H4619E
Hardware Services
Hardware ServicesHardware Services
Hardware Services
Installation services U2090A
Installation services, electronic U2090E
NOTE:
NOTE:NOTE:
NOTE: 'A' signifies a physical HP Care Pack; 'E' signifies an electronic HP Care Pack.
QuickSpecs
HP StorageWorks SSL1016 Tape Autoloader
HP StorageWorks SSL1016 Tape AutoloaderHP StorageWorks SSL1016 Tape Autoloader
HP StorageWorks SSL1016 Tape Autoloader
Related Options
DA - 11839 North America — Version 13 — September 16, 2005 Page 10

SSL1016 Ultrium 460
SSL1016 Ultrium 460SSL1016 Ultrium 460
SSL1016 Ultrium 460 SSL1016 SDLT 320
SSL1016 SDLT 320SSL1016 SDLT 320
SSL1016 SDLT 320
Drive Technology
Drive TechnologyDrive Technology
Drive Technology Ultrium 460 SDLT 320
Capacity
CapacityCapacity
Capacity 3.2 TB native 2.56 TB native
6.4 TB compressed 5.12 TB compressed
Interface
InterfaceInterface
Interface Ultra3 SCSI LVD/SE Ultra2 SCSI LVD/SE
Maximum Transfer Rate
Maximum Transfer RateMaximum Transfer Rate
Maximum Transfer Rate 30 MB/s (108 GB/hr) -
native
16 MB/s (57.6 GB/hr) - native
60 MB/s (216 GB/hr) -
compressed
32 MB/s (115.2 GB/hr) - compressed
Reliability
ReliabilityReliability
Reliability 1,000,000 mean swaps between failures (MSBF)
Dimensions
DimensionsDimensions
Dimensions (HxWxD) Out-of-Box 3.5 x 17.7 x 29.71 in (8.89 x 44.96 x 75.46 cm)
Shipping 11.75 x 23.5 x 39.5 in (29.8 x 59.7 x 100.3 cm)
Weight
WeightWeight
Weight (HxWxD) Out of Box 50 lb (22.73 kg); not including media
Shipping 68.2 lb (31 kg)
Connectors/Cables
Connectors/CablesConnectors/Cables
Connectors/Cables Connectors (2) 68-pin VHDCI; (1) RJ-45 (both on rear of SSL1016 autoloader)
Cables (1) 2.5M VHDCI to VHDCI SCSI cable
(1) RJ-45 Ethernet cable
Input Requirements
Input RequirementsInput Requirements
Input Requirements 100 to 240 VAC, 50 to 60 Hz, 1.0 Amperes
Inventory Time
Inventory TimeInventory Time
Inventory Time 22 seconds
LED Indicators
LED IndicatorsLED Indicators
LED Indicators
(On Front Panel)
Left (Green) LED shows ready status information
Right (Amber) LED shows fault status information
Power
PowerPower
Power 80 Watts (max)
Relative Humidity
Relative HumidityRelative Humidity
Relative Humidity
(non-condensing)
Operating 20 % to 80%
Shipping 10 % to 90%
Temperature Range
Temperature RangeTemperature Range
Temperature Range Operating 50° to 95° F (10° to 35° C)
Shipping -40° to 149° F (-40° to 65° C)
© Copyright 2003-2005 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and
services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial
errors or omissions contained herein.
QuickSpecs
HP StorageWorks SSL1016 Tape Autoloader
HP StorageWorks SSL1016 Tape AutoloaderHP StorageWorks SSL1016 Tape Autoloader
HP StorageWorks SSL1016 Tape Autoloader
Technical Specifications
DA - 11839 North America — Version 13 — September 16, 2005 Page 11
