HP StorageWorks 2405 - Disk System User manual

hp StorageWorks
disk system 2405
Edition E0902
.
user’s guide

Notice
© Hewlett-Packard Company, 2002. All rights
reserved.
A6250-96020
Hewlett-Packard Company makes no warranty of
any kind with regard to this material, including, but
not limited to, the implied warranties of
merchantability and fitness for a particular purpose.
Hewlett-Packard shall not be liable for errors
contained herein or for incidental or consequential
damages in connection with the furnishing,
performance, or use of this material.
This document contains proprietary information,
which is protected by copyright. No part of this
document may be photocopied, reproduced, or
translated into another language without the prior
written consent of Hewlett-Packard. The
information contained in this document is subject to
change without notice.
Format Conventions
WARNING Identifies a hazard that can cause
personal injury
Caution Identifies a hazard that can cause
hardware or software damage
Note Identifies significant concepts or
operating instructions
this font - used for all text to be typed
verbatim: all commands, path names, file names,
and directory names also, text displayed on the
screen
<this font> - used for variables used in commands
this font - used for GUI menu options and screen
controls
Trademark Information
Red Hat is a registered trademark of Red Hat Co.
C.A. UniCenter TNG is a registered trademark of
Computer Associates International, Inc.
Microsoft, Windows NT, and Windows 2000 are
registered trademarks of Microsoft Corporation
HP, HP-UX are registered trademarks of Hewlett-
Packard Company. Command View, Secure
Manager, Business Copy, Auto Path, Smart Plug-
Ins are trademarks of Hewlett-Packard Company
Adobe and Acrobat are trademarks of Adobe
Systems Inc.
Java and Java Virtual Machine are trademarks of
Sun Microsystems Inc.
NetWare is a trademark of Novell, Inc.
AIX is a registered trademark of International
Business Machines, Inc.
Tru64 and OpenVMS are registered trademarks of
Compaq Corporation.

Revision History
First Edition March 2002
Second Edition June 2002
Third Edition Sept 2002

5
1Product Description 13
General Description 13
Features 14
Status Indicators 15
Power/Standby Switch 15
High Availability 15
Upgradability 16
Environmental Services 16
Components 17
Disks and Disk Fillers 17
LCCs 18
Power Supply/Fan Module 21
Hardware/Software Requirements 23
Topologies 23
Single Host Basic Configuration 24
Single Host PV Links Configuration 25
Two Host High Availability Configuration 26
Four Host Hub Configuration 27
Definitions 28
2Installation 31
Preparation 31
Electrical Requirements 31
Choosing PDUs 32
Installing PDU/PDRUs 34
Software Requirements 37
Step 1: Gather Tools 38
Step 2: Unpack the Product 38
contents

6
Step 3: Install the device 41
Installing the Storage Device into a Rack System/E 41
Installing the storage device into an HP Computer Cabinet 49
Installing the Storage Device into a Rittal-Style Rack 56
Install the Disk System 63
Step 4: Configure LCCs 64
Step 5: Set LCC Switches 66
Step 6: Connect FC and Power Cables 72
Step 7: Install Disk Modules 75
Step 8: Turn on the Disk System 76
Step 9: Verify Devices on the Host 78
Sample IOSCAN 78
Where do you go from here? 79
3Configuration 81
Viewing a Disk System in IOSCAN 81
Sample IOSCAN 81
Interpreting the Hardware Path 83
Loop IDs and Hardware Paths by Enclosure ID 84
Setting Up the Hardware Event Monitor 88
Aliasing Devices (HP-Qualified Only) 88
Using SAM 88
Using STM (HP-Qualified Only) 88
Updating Firmware (HP-Qualified Only) 90
4Troubleshooting 93
Overview 93
Event Notification 93
Status LEDs 96
Online Status Information 98
Viewing Component Status in SAM 98
Viewing the STM Information Log 99
Interpreting Status Values 100
Checking the Fibre Channel Link 102
Isolating Causes 104

7
5Removal and Replacement 109
Disk Module 111
Preparation 111
To Determine If a Volume Group or Physical Volume Group Is
Active 111
To Determine If the Physical Volume Is Attached 112
To Replace Attached Physical Volumes 112
To Replace Unattached Physical Volumes 114
Tools 115
Procedure 115
LCC 117
Tools 117
Procedure 117
Power Supply 120
Tools 120
Procedure 120
Disk System 122
Tools 122
Procedure 122
Top Cover (HP-Qualified Only) 124
Tools 124
Procedure 124
Midplane (HP-Qualified Only) 126
Tools 126
Procedure 126
6Reference 129
Product Models and Options 129
Upgrade Products 130
PDU/PDRU Products 131
Replaceable Parts 132
Specifications 132
Dimensions 132
Weight 133
AC Power Input 133
DC Power Output 133

8
Heat Output 133
Environment 134
Acoustics 134
Safety Certifications 134
EMC Compliance 135
Regulatory Statements 136
A. FCC Statement (For U.S.A. Only) 136
B. IEC Statement (Worldwide) 136
C. Spécification ATI Classe A (France) 137
D. Product Noise Declaration (Germany) 137
E. VCCI Statement (Japan) 138
Harmonics Conformance (Japan) 138
F. BSMI EMC Statement (Taiwan) 138
G. Declaration of Conformity 139
Product Web Site 140
Related Documents 140

9
Figure 1 Disk System Front View 14
Figure 2 Disk System Back View 14
Figure 3 Disk Module 18
Figure 4 LCC 19
Figure 5 Power Supply/Fan Module 21
Figure 6 Single Initiator Basic Configuration 24
Figure 7 Single Host PV Links Configuration 25
Figure 8 Two Host High Availability Configuration 26
Figure 9 Four Host Hub Configuration 27
Figure 10 PDRU Placement in 1.6-Meter Rack 35
Figure 11 PDRU Placement in a 2.0-Meter Rack 36
Figure 12 Disk System Accessories 39
Figure 13 Disk System Contents 40
Figure 14 HP Rack System/E Rail Kit Contents 41
Figure 15 HP Rack System/E Installation Overview 42
Figure 16 Locating the site for the device installation in a System/E
rack 44
Figure 17 Installing clipnuts for an HP Rack System/E 44
Figure 18 Installing rails in an HP Rack System/E 45
Figure 19 Installing the enclosure clipnut in anHP Rack System/E 46
Figure 20 Installing the storage device in the Rack System/E 47
Figure 21 Installing enclosure rail clamps in an HP Rack
System/E 48
Figure 22 HP Computer Cabinet Rail Kit Contents 49
Figure 23 HP Computer Cabinet Installation Overview 50
Figure 24 Locating the site for the device installation in an HP
Computer Cabinet 51
Figure 25 Installing rail clip nuts in the HP Computer Cabinet 51
Figure 26 Installing rails in the HP Computer Cabinet 52
Figure 27 Installing enclosure retention clipnuts in an HP Computer
Cabinet 53
Figure 28 Installing the storage device in an HP Computer
Cabinet 54
figures

10
Figure 29 Installing a filler panel in an HP Computer Cabinet 55
Figure 30 Rittal-Style Rail Kit Contents 56
Figure 31 Rail Alignment 57
Figure 32 Front Screw Installation 57
Figure 33 Rear Slide Extension 58
Figure 34 Center Nut Tightening 59
Figure 35 Installing a Disk System into the Rittal-Style Rack 60
Figure 36 Moving a Disk System Retention Bracket 61
Figure 37 Bolting the Disk System to the Front Column of the
Rack 62
Figure 38 LCC Internal Configuration Switch 64
Figure 39 LCC Installation 65
Figure 40 Fiber Optic Cabling and Address Switch Settings with 1
Disk System 66
Figure 41 Fiber Optic Cabling and Address Switch Settings with 2
Disk Systems 67
Figure 42 Fiber Optic Cabling and Address Switch Settings with 3
Disk Systems 68
Figure 43 Fiber Optic Cabling and Address Switch Settings with 4
Disk Systems 69
Figure 44 Fiber Optic Cabling and Address Switch Settings with 5
Disk Systems 70
Figure 45 Fiber Optic Cabling and Address Switch Settings with 6
Disk Systems 71
Figure 46 Wiring Scheme for 1.6-Meter Rack 73
Figure 47 Wiring Scheme for 2.0-Meter Rack 74
Figure 48 Disk Module Installation 75
Figure 49 Power/Standby Switch and System LEDs 77
Figure 50 Annotate Device Using STM 89
Figure 51 Firmware File Selection Window 90
Figure 52 Firmware Download Confirmation Window 91
Figure 53 Firmware Tool Window 92
Figure 54 Sample Hardware Event Notification 95
Figure 55 LED Status Indicators 96
Figure 56 Disk System Field Replaceable Units (FRUs) 109
Figure 57 Disk Module Removal 116
Figure 58 LCC Removal and Replacement 118
Figure 59 LCC Address Switches and LEDs 119
Figure 60 Power Supply Removal and Replacement 121
Figure 61 Disk System Removal and Replacement 123
Figure 62 Top Cover Assembly 125
Figure 63 Midplane Assembly 128

11
Table 1 Inrush (Surge) Current and Duration 31
Table 2 Maximum Operating Current 32
Table 3 Recommended PDU/PDRUs for Multiple Disk Systems in
HP Legacy Racks 33
Table 4 Recommended PDU/PDRUs for Multiple Disk Systems in
HP System/E Racks 33
Table 5 Disk System Accessories 38
Table 6 Disk System Contents 39
Table 7 Rail Positions for Sequential Disk Systems 43
Table 8 Loop IDs and Hardware Paths by Slot Number and
Enclosure ID 0 - 2 84
Table 9 Loop IDs and Hardware Paths by Slot Number and
Enclosure ID 3 - 4 85
Table 10 Loop IDs and Hardware Paths by Slot Number and
Enclosure ID 5- 6 86
Table 11 LED Functions 96
Table 12 Status Indications 100
Table 13 Troubleshooting Table 104
Table 14 Disk System Field Replaceable Units 110
Table 15 Upgrade Products 130
Table 16 PDU/PDRU Products 131
Table 17 Replacement and Exchange Part Numbers 132
Table 18 Product Weights 133
tables

12

Product Description 13
Product Description
General Description
Hewlett-Packard’s StorageWorks Disk System 2405 (referred to in this guide as
the disk system) is a high-availability Fibre Channel (FC) storage product. Dual
optical fiber ports on dual link controllers provide Fibre Channel connections to
the host. Fifteen slots accept high-speed, high-capacity FC disks connected to a
FC midplane. Data throughput is 200 Mbytes/sec. Thirteen disk systems fill a
2-meter System/E rack. Filled with 18-Gbyte disks, the 2-meter Rack System/E
yields 3.51 Terabytes of storage; with 36-Gbyte disks, 7.02 Terabytes of storage;
and with 73-Gbyte disk, 14.23 Terabytes.
Modular and redundant components are easy to upgrade and maintain. Disks,
power supplies, and link control cards (LCCs) are replaceable parts that plug into
individual slots in the front and back of the disk system. Redundant power
supply/fan modules and LCCs can be removed and replaced without interrupting
storage operations. Disks can be replaced with the system on, and only the
affected file systems taken off-line. Hewlett-Packard technical support is optional
for these procedures.
Special electronics and HP-UX software enable remote monitoring and
diagnostics. Sensors on the LCCs monitor the disk system environment,
including temperature, voltage, fan speed, and component status. Hewlett-
Packard’s Command View SDM reports any changes in environmental status to
user-defined locations. Standard HP-UX diagnostic utilities also report
environmental data for enhanced troubleshooting.
1

Product Description 15
Product Description
Status Indicators
LEDs on the disk system enable you to detect and replace failed components and
thereby prevent or minimize users’ downtime. For additional information about
LEDs, see chapter 4, Troubleshooting.
On the front of the disk system, a pair of LEDs indicates the status of the disk
system, and an LED for each slot shows disk I/O activity:
■The system power LED (B in Figure 1) indicates that power is on or off.
■The system fault LED (C in Figure 1) indicates whether or not a fault has
occurred anywhere in the disk system.
■At the bottom of each disk module, the left LED (D in Figure 1) indicates the
presence of I/O activity on the disk.
■The right LED, at the bottom of each disk module (E in Figure 1), can be
flashed to help a customer engineer (CE) locate the disk for physical
inspection or removal.
LEDs (G and J in Figure 2) on the back of the disk system indicate the status of
replaceable components. See chapter 4, Troubleshooting, for specific LED
information.
Power/Standby Switch
Located in the upper right corner of the front of the disk system, the power switch
(A in Figure 1) interrupts power from the power supplies to the LCCs and other
internal components. Power to the power supplies is controlled by the power
cords and the AC source.
High Availability
High availability is a general term describing computer systems that are designed
to minimize unplanned downtime. The disk system supports high availability
requirements through the following features:
■Hot-pluggable, high-capacity, high-speed disks
■Redundant, hot-pluggable, user-replaceable power supplies and LCCs
■Support for mirrored disks in the HP-UX environment
■Online firmware upgrades
■Hardware event monitoring and real-time error reporting

16 Product Description
Upgradability
You can increase disk system storage capacity by:
■Replacing disk drives with higher-capacity disk drives
■Adding disks in unused slots
■Adding another disk system to a FC loop
None of these actions require shutting down the product, but some may require
the use of system utilities to manage file systems.
Disk and LCC firmware is downloadable using the supported tools.
Environmental Services
Environmental services circuitry monitors the following elements:
■Fan rotation
■Power supply output
■Power supply and fan status
■Disk drive status, including fault conditions
■LCC status
■Temperature
■Self-test results
Each LCC reports the status of all elements in the disk system, even if the LCC
does not have direct access to the element.
Additionally, the EEPROM on each LCC stores 2 Kbytes of configuration
information and user-defined data, including the manufacturer serial number and
product number.

Product Description 17
Product Description
Components
User-replaceable components enable high availability and easy maintenance.
This section describes the following components:
■Disks and disk fillers
■LCCs
■Power supply/fan modules
Disks and Disk Fillers
Disks, shown in Figure 3, are 3.5-inch Low Profile disks in open metal carriers.
Disks are Fibre Channel.
The open carrier design requires careful handling to avoid disk damage by
breakage and static electricity. Avoid personal contact with hot surfaces.
WARNING Touching exposed circuits can cause electrical discharge and
disable the disk. Disks require careful handling and ESD
precautions.
The plastic parts of the disk are safe to touch:
■Extraction handle (A in Figure 3)
■Latch tab (B in Figure 3)
The initial disk options for this product are 73-Gbyte, 36-GByte and 18-GByte
drives. A label on the disk carrier shows the storage capacity and rotational speed
of the installed disk. Obtain information about the latest disk options from HP
sales representatives.
Disk fillers occupy unused slots to balance the air flow.
Caution Fillers must be installed in unused slots in order to maintain even
cooling around the remaining slots.

Product Description 19
Product Description
Figure 4. LCC
Other features of the LCC are:
■LEDs (D) indicating LCC status and bus configuration
■Rotary switch (E)
■Configuration switch with four settings:
1 Link Speed (1.0625 Gb/s or 2.125 Gb/s)
2 Reserved
3 Reserved
4 Power fail warning (enable/disable)
■Locking screws (F)
■Cam levers (G)

20 Product Description
LCC circuitry provides the following functions:
■System fault detection
■Disk address generation
Caution If an LCC fails, do not remove it from the disk system until you
are ready to replace it with a new one. The failed LCC should
remain installed to assure proper cooling for the disk system.
