HP ProCurve 5400zl Series User manual

HP ProCurve 5400zl Switches
Installation and Getting Started Guide
Power over Ethernet

HP ProCurve 5400zl Switches
Installation and Getting Started Guide

Hewlett-Packard Company
8000 Foothills Boulevard, m/s 5552
Roseville, California 95747-5552
http://www.procurve.com
© Copyright 2005 - 2010 Hewlett-Packard Development 
Company, L.P.
Publication Number
5900-0281
January 2010
Applicable Products
Disclaimer
HEWLETT-PACKARD COMPANY MAKES NO WARRANTY
OF ANY KIND WITH REGARD TO THIS MATERIAL,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE. Hewlett-Packard shall not
be liable for errors contained herein or for incidental or
consequential damages in connection with the furnishing,
performance, or use of this material.
The information contained herein is subject to change 
without notice.The only warranties for HP products and
services are set forth in the express warranty statements
accompanying such products and services. Nothing herein
should be construed as constituting an additional warranty.
HP shall not be liable for technical or editorial errors or
omissions contained herein.
Hewlett-Packard assumes no responsibility for the use or
reliability of its software on equipment that is not furnished
by Hewlett-Packard.
Warranty
See the Customer Support/Warranty booklet included with
the product.
A copy of the specific warranty terms applicable to your
Hewlett-Packard products and replacement parts can be
obtained from your HP Sales and Service Office or
authorized dealer.
Safety
Before installing and operating these products, please read
the “Installation Precautions” in chapter 2, “Installing the
5400zl Switches”, and the safety statements in Appendix C,
“Safety and Regulatory Statements”.
HP ProCurve 5406zl Switch J8697A
HP ProCurve 5406zl-48G Switch J8699A
HP ProCurve 5406zl-48G-PoE+ Switch J9447A
HP ProCurve 5412zl Switch J8698A
HP ProCurve 5412zl-96G Switch J8700A
HP ProCurve 5412zl-96G-PoE+ Switch J9448A
Two-Post Rack Mounting Kit for 5406zl 5069-8561
Two-Post Rack Mounting Kit for 5412zl 5069-8562
8200zl/5400zl 10K Rack RailKit Assembly 5070-0145
Switch zl Power Supply Shelf J8714A
Switch zl Power Supply Shelf Rack Mounting Kit 5070-3028
Switch 1500W PoE+ zl Power Supply J9306A
Switch zl 875W Power Supply J8712A
Switch zl 1500W Power Supply J8713A
Switch 5406zl Fan Tray J8697-60005
Switch 5412zl Fan Tray J8698-60005
5400zl Management Module J8726A
5400zl Management Module without CF card J8726-61001
CompactFlash Kit for 5400zl Management Module 5070-1056
24-port Gig-T zl Module J8702A
20-port Gig-T/SFP zl Module J8705A
24-port mini-GBIC zl Module J8706A
4-port 10Gig-X2 zl Module J8707A
4-port 10Gig-CX4 zl Module J8708A
24-Port 10/100/1000 PoE+ zl Module J9307A
20-Port 10/100/1000 PoE+/4-Port MiniGBIC zl Module J9308A
4-Port 10GbE SFP+ zl Module J9309A
24-Port 10/100 PoE+ zl Module J9478A
Wireless Edge Services zl Module J9051A
Redundant Wireless Services zl Module J9052A
ONE Services zl Module J9154A
ONE Advanced Services zl Module J9545A

iii
Contents
1 Introducing the HP ProCurve 5400zl Switches
Overview of 5400zl Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
5406zl Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
5412zl Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
HP ProCurve 5406zl Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
HP ProCurve 5406zl-48G Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
HP ProCurve 5406zl-48G-PoE+ Switch . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
HP ProCurve 5412zl Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
HP ProCurve 5412zl-96G Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
HP ProCurve 5412zl-96G-PoE+ Switch . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Network Connectivity, Speeds and Technologies . . . . . . . . . . . . . . . . . . . . 1-7
Front of the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
LED Mode Select Button and Indicator LEDs . . . . . . . . . . . . . . . . . . . 1-13
Console Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-14
Reset Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-14
Clear Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-14
Back of the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-16
Power Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-16
Redundant Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-17
Switch Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-18
Switch Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-19
2 Installing the 5400zl Switches
Included Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Accessory Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Power Cords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Installation Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

iv
Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
1. Prepare the Installation Site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Cabling Infrastructure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Installation Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
2. Install Switch Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
3. (Optional) Install Another Power Supply . . . . . . . . . . . . . . . . . . . . . 2-10
4. Verify the Switch Passes Self Test . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
LED Behavior: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
5. Mount the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15
Rack or Cabinet Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15
Horizontal Surface Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-18
6. Install the Grounding Wire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-18
7. Connect the Switch to a Power Source . . . . . . . . . . . . . . . . . . . . . . 2-19
8. (Optional) Connect a Power Supply Shelf
to the switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-19
EPS Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-20
Operating Characteristics of the EPS (J8714A) . . . . . . . . . . . . . . 2-20
Power Supply Shelf LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
Connecting the Power Supply Shelf . . . . . . . . . . . . . . . . . . . . . . . 2-22
9. Connect the Network Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-23
10. (Optional) Connect a Console to the Switch . . . . . . . . . . . . . . . . . 2-24
Terminal Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-24
Direct Console Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-25
Telnet Console Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-25
Hot Swapping Switch Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-26
Adding or Replacing Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-26
Changing the Module Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-26
Example Network Topologies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-27
Basic Connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-27
Use as an Edge Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-28
Optimizing the 10-GbE Port Configuration . . . . . . . . . . . . . . . . . . . . . 2-29
3 Getting Started With Switch Configuration
Recommended Minimal Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

v
Using the Switch Setup Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Where to Go From Here . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Using the IP Address for Remote Switch Management . . . . . . . . . . . . . . . . 3-5
Starting a Telnet Session . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Starting a Web Browser Session . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Configuring the ProCurve Wireless Edge Services zl Modules (J9051A,
J9052A) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Configuring an IP Address for the Module . . . . . . . . . . . . . . . . . . . . . . . 3-7
Configuring VLANs on the zl Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
Determining a Module Configuration Backup Process . . . . . . . . . . . . 3-9
Configuring Wireless LAN Services . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
4 Replacing Components
Replacing Power Supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Replacing Fan Trays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Replacing the Management Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Replacing the Management Module Compact Flash Card . . . . . . . . . . . . . 4-6
Installing a Compact Flash Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Replacing the Management Module Battery . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
Installing a New Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
Perchlorate Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Replacing the J9289A ONE Services zl Module Compact Flash Card . . . . 4-9
Installing a Compact Flash Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
Replacing the J9289A ONE Services zl Module Disk Drive . . . . . . . . . . . 4-10
Installing a Disk Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10

vi
5 Troubleshooting
Basic Troubleshooting Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Diagnosing with the LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
Proactive Networking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9
Hardware Diagnostic Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
Reasons for Resetting the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
Methods of Resetting the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
Testing the Switch by Resetting It . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11
Checking the Switch LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11
Checking Console Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11
Testing Twisted-Pair Cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-12
Testing Switch-to-Device Network Communications . . . . . . . . . . . . 5-12
Testing End-to-End Network Communications . . . . . . . . . . . . . . . . . 5-12
Restoring the Factory Default Configuration . . . . . . . . . . . . . . . . . . . . . . . 5-13
Downloading New Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-14
HP Customer Support Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-14
Before Calling Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-14
A Specifications
Physical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Environmental . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
Acoustic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
Switch 5400zl, 5406zl-48G and 5406zl-48G-PoE+: . . . . . . . . . . . . A-2
Switch 5412zl, 5412zl-96G and 5412zl-96G-PoE+: . . . . . . . . . . . . A-2
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3
Technology Standards and Safety Compliance . . . . . . . . . . . . . . . . . . A-3
B Cabling and Technology Information
Cabling and Technology Information Specifications . . . . . . . . . . . . B-1
Technology Distance Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . B-2

vii
Mode Conditioning Patch Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-4
Installing the Patch Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-4
Twisted-Pair Cable/Connector Pin-Outs . . . . . . . . . . . . . . . . . . . . . . . . . . . B-6
Straight-Through Twisted-Pair Cable for
10 Mbps or 100 Mbps Network Connections . . . . . . . . . . . . . . . . . . . . B-8
Cable Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-8
Pin Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-8
Crossover Twisted-Pair Cable for
10 Mbps or 100 Mbps Network Connection . . . . . . . . . . . . . . . . . . . . . B-9
Cable Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-9
Pin Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-9
Straight-Through Twisted-Pair Cable for
1000 Mbps Network Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-10
Cable Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-10
Pin Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-10
C Safety and Regulatory Statements
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-1
Informations concernant la sécurité . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-2
Hinweise zur Sicherheit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-3
Considerazioni sulla sicurezza . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-4
Consideraciones sobre seguridad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-5
Safety Information (Japan) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-6
Safety Information (China) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-7
EMC Regulatory Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-8
U.S.A. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-8
Canada . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-8
Australia/New Zealand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-8
Japan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-8
Korea . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-9
Taiwan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-9
Regulatory Model Identification Number . . . . . . . . . . . . . . . . . . . . . . C-9
European Community . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-10
China Regulatory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-11

D Recycle Statements
Waste Electrical and Electronic Equipment (WEEE) Statements . . . . . . D-1
Index

1-1
Introducing the HP ProCurve
5400zl Switches
1
Introducing the HP ProCurve 5400zl Switches
The HP ProCurve 5400zl Switches include the Switch 5406zl, 5412zl and their
bundles, the Switch 5406zl-48G and Switch 5412zl-96G. They are multiport
modular switches that provide Layer 3 routing features, and that feature low
latency for high-speed networking.
This chapter describes your 5400zl switches, including:
■Overview of 5400zl Switches, page 1-2
■Network Connectivity, Speeds and Technologies, page 1-7
■Front of the Switches, page 1-8
■Back of the Switch, page 1-16
■Switch Accessories, page 1-18
■Switch Features, page 1-19

1-2
Introducing the HP ProCurve 5400zl Switches
Overview of 5400zl Switches
Introducing the HP ProCurve
5400zl Switches
Overview of 5400zl Switches
5406zl Switches
5406zl Switch, 5406zl-48G Switch, and 5406zl-48G-PoE+ Switch.
1. The HP ProcCurve 5406zl switch is available as an open 6-slot chassis
(J8697A).
2. The HP ProcCurve 5406zl-48G switch bundle (J8699A) ships with the
5406zl, 6-slot chassis and the following modules and power supply:
• Two 24-port 10/100/1000-T zl Modules (J8702A)
• One 875 W PoE Power Supply (J8712A) pre-installed.
3. The HP ProcCurve 5406zl-48G-PoE+ switch bundle (J9447A) ships with
the 5406zl, 6-slot chassis and the following modules.
• One 24-port 10/100/1000-T PoE+ zl Modules (J9307A)
• One 20-port 10/100/1000-T PoE+ & 4-port mini-GBIC zl Module
(J9308A)
• One 1500W PoE+ zl Power Supply (J9306A)
5412zl Switches
Switch 5412zl, Switch 5412zl-96G and 5412zl-96G-PoE+.
1. The HP ProcCurve 5412zl switch is available as an open 12-slot chassis
(J8698A).
2. The HP ProcCurve 5412zl-96G switch bundle (J8700A) ships with the
5412zl, 12 slot chassis and the following modules and power supply:
• Four 24-port 10/100/1000-T zl Modules (J8702A)
• One 875 W PoE Power Supply (J8712A) pre-installed.
3. The HP ProcCurve 5412zl-96G-PoE+ switch bundle (J9448A) ships with
the 5412zl, 12 slot chassis and the following modules and power supply.
• Three 24-port 10/100/1000-T PoE+ zl Modules (J9307A)
• One 20-port 10/100/1000-T PoE+ & 4-port mini-GBIC zl Module
(J9308A)
• Two 1500W PoE+ zl Power Supplies (J9306A)
See “Switch Features” on page 1-19 for a list of the switch modules that can
be installed in the HP ProCurve 5400zl switches.

1-3
Introducing the HP ProCurve 5400zl Switches
Overview of 5400zl Switches
Introducing the HP ProCurve
5400zl Switches
HP ProCurve 5406zl Switch
The HP ProcCurve 5406zl switch ships with the 5400zl Management Module
and open, 6-slot chassis (J8697A). The switch needs at least one power supply
to operate.
Figure 1-1. HP ProCurve 5406zl Switch (J8697A)

1-4
Introducing the HP ProCurve 5400zl Switches
Overview of 5400zl Switches
Introducing the HP ProCurve
5400zl Switches
HP ProCurve 5406zl-48G Switch
The HP ProcCurve 5406zl-48G switch bundle (J8699A) ships with the 5406zl,
6-slot chassis and the following modules and power supply:
• Two 24-port 10/100/1000-T zl Modules (J8702A)
• One 875 W PoE Power Supply (J8712A) pre-installed.
Figure 1-2. HP ProCurve 5406zl-48G Switch bundle (J8699A) with two
10/100/1000-T zl Modules
HP ProCurve 5406zl-48G-PoE+ Switch
The HP ProCurve 5406zl-48G-PoE+ switch bundle (J9447A) ships with the
5406zl, 6-slot chassis and the following modules.
• One 24-port 10/100/1000-T PoE+ zl Modules (J9307A)
• One 20-port 10/100/1000-T PoE+ & 4-port mini-GBIC zl Module
(J9308A)
• One 1500W PoE+ zl Power Supply (J9306A)

1-5
Introducing the HP ProCurve 5400zl Switches
Overview of 5400zl Switches
Introducing the HP ProCurve
5400zl Switches
HP ProCurve 5412zl Switch
The HP ProcCurve 5412zl switch ships with the 5400zl Management Module
and open, 12-slot chassis (J8698A). It does not ship with any power supplies.
The switch needs at least one power supply to operate.
Figure 1-3. HP ProCurve 5412zl Switch (J8698A)

1-6
Introducing the HP ProCurve 5400zl Switches
Overview of 5400zl Switches
Introducing the HP ProCurve
5400zl Switches
HP ProCurve 5412zl-96G Switch
The HP ProcCurve 5412zl-96G switch bundle (J8700A) ships with the 5412zl,
12 slot chassis and the following modules and power supply:
• Four 24-port 10/100/1000-T zl Modules (J8702A)
• One 875 W PoE Power Supply (J8712A) pre-installed.
Figure 1-4. HP ProCurve 5412zl-96G Switch (J8700A)
HP ProCurve 5412zl-96G-PoE+ Switch
The HP ProcCurve 5412zl-96G-PoE+ switch bundle (J9448A) ships with the
5412zl, 12-slot chassis and the following modules.
• Three 24-port 10/100/1000-T PoE+ zl Modules (J9307A)
• One 20-port 10/100/1000-T PoE+ & 4-port mini-GBIC zl Module
(J9308A)
• Two 1500W PoE+ zl Power Supplies (J9306A)

1-7
Introducing the HP ProCurve 5400zl Switches
Network Connectivity, Speeds and Technologies
Introducing the HP ProCurve
5400zl Switches
Network Connectivity, Speeds and
Technologies
These products support optional network connectivity with the following
speeds and technologies.
Table 1-1. Optional Network Connectivity, Speeds and Technologies
Transceiver Form-Factor and Connector
Speed Technology Cabling1SFP ("mini-GBIC")
Connector
X2
Connector
SFP+
Connector
100 Mbps 100-FX Fiber (multimode) LC
100-BX Fiber (single mode) LC
1 Gbps
1000-T Copper (twisted-pair) RJ-45
1000-SX Fiber (multimode) LC
1000-LX Fiber (multimode or single mode) LC
1000-LH Fiber (single mode) LC
1000-BX Fiber (single mode) LC
10 Gbps
10-Gig CX4 Copper (twinaxial) CX4
10-Gig
Direct Attach
Copper (twinaxial) Not
Applicable
10-Gig SR Fiber (multimode) SC LC
10-Gig LRM Fiber (multimode) SC LC
10-Gig LR Fiber (single mode) SC LC
10-Gig ER Fiber (single mode) SC
1For supported transceivers, see www.procurve.com/faqs. Both ProCurve 10-GbE Transceivers and ProCurve Mini-
GBICs and SFPs have links to a list of supported products (first question in the "General product information" category).
For technical details of cabling and technologies see "Cabling and Technology Information" in the appendices.

1-8
Introducing the HP ProCurve 5400zl Switches
Front of the Switch
Introducing the HP ProCurve
5400zl Switches
Front of the Switch
Figure 1-5. Front of 5406zl-48G Switch
This illustration shows the 5406zl-48G (J8699A), but the labeling and descrip-
tions apply to all of the ProCurve Series 5400zl switches.
LED Mode Select button
and indicator LEDs
Switch Modules and slots
with Link and Mode LEDs for each port located on each module
Power
and Fault
LEDs
Locator LED
Status LEDs for the
Fans, Power Supplies,
and Switch Modules
Reset and Clear
buttons
Auxiliary Port
Console
Port
Module Link
and Mode LEDs
Self Test LED

1-9
Introducing the HP ProCurve 5400zl Switches
Front of the Switch
Introducing the HP ProCurve
5400zl Switches
LEDs
As described in the next two tables, there are LEDs on the switch chassis and
on the switch modules that keep you informed of the status of the switch and
the network connections.
Table 1-2. Switch Chassis LEDs
LEDs State Meaning
Power
(green) On The switch is receiving power.
Off The switch is NOT receiving power.
Fault
(orange) Off The normal state; indicates that there are no fault conditions on the switch.
Blinking1A fault has occurred on the switch, one of the switch modules, an individual port, apower
supply, or a fan. The Status LED for the module or other device with the fault will flash
simultaneously.
On On briefly at the beginning of switch self test after the switch is powered on or reset. If
on for a prolonged time, the switch has encountered a fatal hardware failure, or has
failed its self test. See chapter 4, “Troubleshooting” for more information.
Locator
(blue)
On
Blinking
Off
The Locator LED is used to locate a specific chassis in a area full of chassis. The LED
can be set to be on solid or blink for a specified number of minutes (1-1440). The default
is 30 minutes. Use the command “chassislocate”.
Test
(green/Orange) Off The normal operational state; the switch is not undergoing self test.
On The switch self test and initialization are in progress after you have power cycled or
reset the switch. The switch is not operational until this LED goes off. The Self Test LED
also comes on briefly when you “hot swap” a module into the switch and the module is
automatically self tested.
Blinking1A component of the switch has failed its self test. The Status LED for that component,
for example a switch module, and the switch Fault LED will flash simultaneously.
DIMM
(green/Orange) On DIMM status is known and fault free.
Off DIMM status is unknown.
Blinking1If DIMM, Fault, and Self Test LEDs are blinking, DIMM failed self-test.
If DIMM and Fault LEDs are blinking, an operational fault has occurred.
If fast blinking (400ms On and 400ms Off), an operational alert occurred and is
unresolved.
Chas
(green)/Orange Reserved for future releases.
Flash
(green/Orange) On Flash Card status is known and fault free
Off Flash Card status is unknown.

1-10
Introducing the HP ProCurve 5400zl Switches
Front of the Switch
Introducing the HP ProCurve
5400zl Switches
Blinking1If Flash, Fault, and Self Test LEDs are blinking, Compact Flash failed self-test.
If Flash and Fault LEDs are blinking, an operational fault has occurred.
If fast blinking (400ms On and 400ms Off), an operational alert occurred and is unresolved
(for example, the Compact Flash is not present).
Mgmt
(green/Orange) On
Off
Blinking1
A Management module is present and fault free.
The switch is powered off.
There is a fault on the Management module.
PoE
(green/Orange) On
Off
If any PoE modules are installed.
If no PoE modules are installed.
Blinking1
Blinking2Internal PoE fault. External load fault or denied PoE power.
Temp
(green/Orange) Off Switch temperature is normal.
Blinking1An over temperature condition has been detected.
Fan
(green/Orange) On The cooling fans are operating normally.
Blinking1One or more of the cooling fans have failed. The switch Fault LED will be blinking
simultaneously.
Internal Power
(green/Orange -
numbers
corresponding to
the power supply
positions)
On A power supply is installed in the position in the back of the switch corresponding to the
number, and the supply is plugged in to an active AC power source. As shipped, the
switch has a single power supply in position 1.
Off A power supply is not installed in the position corresponding to the number.
Blinking1The power supply installed in the position corresponding to the number is not plugged
in to an active AC power source, or has experienced a fault. The switch Fault LED will
be blinking simultaneously.
EPS
(green/Orange) On
Off
An External Power Supply is connected.
No External Power Supply is connected.
Blinking1The External Power Supply has a fault, or is connected but not plugged into AC power.
LEDs State Meaning
