HPRT MPT-III User manual

-1-
-4--3-
-2-
Mobile Thermal Printer
User Manual
Precauons
1) Be sure to use the specified baery and power source provided by our
company. Connecon to an improper power source may cause fire,
explosion or damage to the printer.
2) Don’t put the baery into fire or water, don’t disassemble or modify the
baery, don’t be short circuit, otherwise may result in injury or fire or even
explosion.
3) If the printer would not be used for a long me, be sure to take off the
baery, otherwise the baery may leak liquid which is corrosive, if
improper operaon causes baery leak, and the liquid is spaered on
the skin or clothes, please wash it with water, if spaered into the eyes, please
rinse them with water thoroughly and see a doctor.
4) Please do not open the paper case cover when it is prinngor just when
prinng is over, donot touch the print head with hand or body, overheat
may cause scald.
1) Water or other liquid should not spill into the printer, also the printer should
not be expose to the rain, or else may cause printer damage.
2) Please do not open the paper case cover when it is prinng, otherwise the
printer may work improperly.
3) If print with serial interface, should not unplug the interface cable in the
course of prinng, or else some prinng data may be lost.
4) When print in Ir or IrDA mode, be sure the Ir window of the host
equipment face rightly the Ir window of the printer, the distance should
be within the range of 50cm,and the angle should be within the range of
30 .
5) When print with Bluetooth interface, the communicaon distance
should be within 10 m eters, otherwise the printer doesn’t print or prints
rubbish codes.
6) Too high ( 40℃) or too low (0℃) temperature and too high (85%) or too low
(20%) relave humidity both effect the print quality.
7) The print paper in poor quality or stored for too long me also may
reduce the print quality even damage the printer.
8) In the black mark detecng mode, the printer requires that the
preprinted black mark is accordant with the black mark specificaons
(details please refer to 4.2), otherwise the black mark can not be detected
correctly.
9) Be sure to use up the power of the baery before charge it, as it can ensure
the using life of the baery.
3.Storage Precauons
1) The printer should be placed in such an environment that the
temperature is between -20℃ and 70℃,and the relave humidity is
between 5% and 95%.
2) If the printer will be stored for a long me, pleas be sure to take out the
baery, otherwise may damage the baery and printer.
3) Normal thermal paper can’t be kept too long, if you need to keep the receipt
for a long period, please choose long term effecve thermal paper.
4) The print paper should be keep away from high temperature environment
and point-blank sunshine.
4.Baery Safety Precauons
Be sure to read the user manual carefully before using the product.
Ignore the following instrucons may cause baery overheang, fire,
explosion, damage and/or performance, and reduced product life.
1) Do not allow water, sea water from entering or leaking into the
baery. If the baeries internal safety device burn, when charging it, it
may produce abnormal current and/or voltage, or abnormal chemical
reacon when charging it, then may cause the baery overheang, fire
and / or explosion.
2) Do not use or place the baerynearby the stoveor other high
temperature places. Excessive heat maybe damage the resin shell and/or
the insulaon materials, there by cause short-circuit inside the
baery, then the baery may be overheated, burning and/or
explosion.
3) When charging, use a specified charger. Other condions (high
temperature, high pressure/high current, using the modified
baery charger,etc.) excluded here may result in overcharging the baery
and abnormal current and/or voltage, cause abnormal chemical reacon ,
and may cause the baery overheat, lightand/or explosion.
4) Baery clearly marks with posive and negave. When connect the
baery with the charger and/or printer, besure to verify the correct baery
orientaon. Reverse inseron will cause the reverse charging and may cause
abnormal chemical reacon,and then may cause the baeryoverheat, ignite, and
/or explosion.
5) Do not make the baery contact with the power outlet and/or car cigaree
lighter socket.This may cause high pressure and excessive current , and
lead to the baery overheat, burning and/or explosion.
6) Do not heat the baery or put the baery into fire. This may melt
insulaon material and/or damage safety devices or safety equipment,
then ignite electrolyc soluon,and cause the baery overheat,
burning and/or explosion.
7) Do not use the baery with contrary (+) and (-) locaon. In the charging
process,this will cause the reverse charging and may cause abnormal
chemical reacon. During use, may appear unpredictable current
excepon, and cause the baery overheat, ignite, and/or explosion.
8) Do not make the baery (+) and (-) contact with any metal. Also, do not
carry along or store baeries with metal objects, such as necklaces, hair
clips and so on. Baery internal short circuit may cause excessive current,
and lead to the baery overheat, ignite, and/or explosion and the adjacent
metal objects(necklaces, hairpins, etc.) may be overheang.
9) Do not throw or aack the baery heavily. If internal safety device of the
baeries burn,the baery charging may cause any abnormal current and/
or voltage, and abnormal chemical reacon,and lead to the baery
overheat, ignite, and/or explosion.
1
23
6
5
7
8
9
4
Chapter 1 Brief Introducon
1.1 Appearance
1) Feed On/Off and Blue Status Indicator
2) RS232 Serial Interface
3) Infrared Ray(IR) Interface(oponal)
4) Power Input
5) Power On/Off and Red Power Indicator
1.2 Accessories
Li-ion Baery
Standard accessories
Oponal accessories
Leather Case
Precauons············································································································1
1. Safety Precauons········································································································1
2. Operaon Precauons·································································································1
3. Storage Precauons······································································································2
4. Baery Safety Precauons ··························································································2
Chapter 1 Brief Introducon ································································· ························4
1.1 Appearance ·······································································································4
1.2 Accessories ··········································································································4
Chapter 2 Specificaons ····························································································5
Chapter 3 Operaon Methods·····················································································6
3.1 Preparaon Before Using ··············································································6
3.1.1 Li-ion Baery Loading ···············································································6
3.1.2 Paper Loading ·······················································································6
3.2 Basic Funcon··································································································· 6
3.2.1 Printer On ······························································································ 6
3.2.2 Printer Off ·························································································· 7
3.2.3 Self-test ·································································································7
3.2.4 Paper Loading ···················································································· 7
3.2.5 Baery Charging ················································································ 7
3.3 Interface and Prinng ······················································································ 8
3.3.1 Serial Interface ···················································································8
3.3.2 Infrared Ray(IR)&IrDA Interface ························································8
3.4 LED Indicator and Buzzer Definion ······························································· 9
3.5 Soware Tools of MPT-III ··············································································· 9
Chapter 4 Other Informaon ·························································································10
4.1 Printer Technical Manual ···············································································10
4.2 Preprinted Black Mark Specificaon······························································10
Contents 1.Safety Precauons
2.Operaon Precauons
Power Adapter
Varies by local or region Paper Roll
Serial Interface Cable
6) Top Cover
7) Cover Open Buon
8) Li-ion Baery Cover
9) Buckle
MPT-III
Xiamen Hanin Electronic Technology Co.,Ltd.
Room 305A, Angye Building, Pioneering Park,
Torch High-tech Zone, Xiamen, China 361009
+86—(0)592-5885993
+86—(0)592-5885992
www.hprt.com
ADD:
TEL:
FAX:
WEB:
CD
User Manual
User Manual

-5- -6- -7-
-10--9-
-8-
Chapter 2 Specificaons Chapter 3 Operaon Methods
3.1 Preparaon Before Using
3.1.1 Li-ion Baery Loading
1) Refer to the picture, put the baery in the baery slot, pls pay
aenon to the correct posive and negave.
2) Close the baery case.
3.1.2 Paper Loading
Top Cover
Rubber Roller
Cover Open Buon
Direcon
3.2 Basic Funcon
3.2.1 Printer On
The printer is powered on by pressing the power buon; the
power indicator is on with red color whenever the printer ison.
Noce: when the baery is almost exhausted, the LED
3.3 Interface and Prinng
3.3.1 Serial Interface
This model of printer uses DB-9 serial interface cable (one end is D
model standard serial interface socket, connected to host
computer, the other end is PS/2 socket, connected to printer).
3.3.2 Infrared Ray (IR) & IrDA Interface
MPT-III can be connected to your main device through IR, RAW-IR
and IrDA can not be available at the same me. Reset the printer
if it is not the model you want.When prinng through RAW-IR and
IrDA, make infrared ray of main device right towards to infrared ray
window of printer, distance should be less than 50mm (varies with
main device), angel should be less than 30°.
3.4 LED Indicator and Buzzer Definion
There are one buzzer and two LED indicators to indicate the
printer status. LED indicators indicate current status and buzzer
indicates the changes of status.
Chapter 4 Other Informaon
4.1 Printer Technical Manual
Pls refer to MPT-III Series technical manual.
4.2 Preprinted Black Mark Specificaon
If user wants to locate receipt by detecng preprinted black
mark, it shall accord to the following specificaon for the
black mark, otherwise it may cause printer can’t recognize the
black mark.
1) Prinng posion: black mark shall preprint at the le side of
receipt.
2) Width range: ≥7mm
3) Height: 4mm≤height≤6mm
4) Reflecon rate to IR: <10% (reflecon rate to the black mark on
paper>65% )
5) Hps: Hps indicates the distance from down edge of detecng mark
from beginning line. (0mm≤Hps≤1mm)
Width
Height
Hps
3.2.3 Self-test
The self-test checks the printer’s current sengs, status and
whether the printer has any problem. Hold down the [FEED]
buon while press [POWER] buon about 3 seconds, the selest
begins.
The printer is ready to receive data as soon as it completes the
self-test.
3.2.4 Paper Feeding
When printer works under non-blackmark mode, user could
use [FEED] buon to feed paper manually. Printer will stop
feeding when reaching max feeding distance. Max feeding
distance could be set by the PC soware “MPTTools”, please
refer to your distributor for more technical informaon of
“MPTTools”.
3.2.5 Baery Charging
When li-ion baery runs out of power, blue LED indicator flash
slowly and buzzer will give up warning. It will power off
automacally when connues prinng. If you want to go on,
please charge it.
Charging method: Plugin socket (220V, 50Hz) with power adapter.
1) Power-off charging : LED light will always indicate blue color
and goes off when fully charged.
2) Power-on charging: LED light will keep blinking in blue color,
and will stop blinking when fully changed. Printer could be in use
when charging.
Notes: Please use the manufacturers supplied baery and power
The printer is off aer press the [POWER] buon last for 2
seconds. All the indicators are off whenever the printer is
off.
3.2.2 Printer Off
There is soware which called MPTTools. It’s soware to set the
printer parameters, it used to set the baud rate of serial port,
Infrared mode, RAW-IR and VIR, it also support seng the
printer Bluetooth device name and password.
The instrucons pls refer to MPTTools Guide.
3.5 Soware Tools of MPT-III
Item Parameter
Prinng
Prinng Method
Resoluon
Prinng Speed
Valid Prinng Width
Power Saving
Resident Fonts
Barcode
Graphics
Detecon
LED Indicator
Power
Paper
Interface
Sleep Mode
1D
2D
Sensors
Power Indicator
Error Indicator
Baery
Paper Type
Paper Width
Paper Thickness
Paper Roller Diameter
Paper Loading
Power Supply
Direct Thermal Line Prinng
203dpi (8dots/mm)
RS232, USB (oponal)
UPC-A, UP C-E, EAN8, EAN13,
CODE39, ITF,CODEBAR, CODE128, CODE93
Support bitmap prinngwith different
density and user defined bitmap
prinng(Max. 40K for per bitmap,
and Max. 64K for total)
Paper out detecon, cover open detecon
1500mAh/7.4V
rechargeable Li-ion baery
Easy loading mechanism
Max.70mm/s
72mm
YES
QR code
Red
Blue
12V 1.0A
Receipt paper
80mm
0.05~0.12mm
≤40mm
Physical
Characteriscs
Working Condion
Storage Condion
0°C~40°C , 20%~85%RH
-20°C~70°C, 5%~95%RH
Dimension
Weight
102.5(L)*110(W)*50(H)mm
325G (Without paper roll)
Soware
Emulaon
Driver Windows XP/Vista/Win7/Win8/Win10
ESC/POS
1) Pull to open the top cover.
2) Put the paper into the paper case, pay aenon to the direcon of
the paper. If loaded reversely, it won’t print.
3) Pull paper out of paper case.
4) Make sure paper in the center then close top cover.
adapter, otherwise cause to printer damage and baery leakage,
light and/or explosion.
indicator blinks with blue color, in this case, you must charge
the baery by using the adaptor. The method of charging
the baery, please refer to 3.2.5.
GBK 16×16, 24×24dots
ASCII 8×16, 12×24dots
Status Indicator
(Blue)
Power Indicator
(Red)
Buzzer Status
ON
OFF
Once
Power-on,ready
Flash
Flash
Twice
Cover open
Flash
Flash
Once
Paper end
Flash OFF Silent Standby
OFF
Flash
Once
Power-on charging
OFF
ON
Silent
Power-offcharging
OFF ON Three mes Power-on charging,
baery full
OFF OFF Silent Power-offcharging,
baery full
ON OFF Once Press [FEED] buon
OFF OFF Twice Power off
Chinese
Alphanumeric
User-defined
Codepage
YES
46
SDK WinCE, Win Mobile, Android
