OPERATING INSTRUCTIONS
HST-MV3
- Original operang instrucons -
Charging staon
HST-MV3-02 / -04 / -04W
Issue date: June 2021
PC software 2.0.2.25 and higher
Firmware: 1.0.1.5 and higher
NOTE
In case of doubt, the original German version
of the operang instrucons applies.
- 2 -
1 Operang principles
1.1 Scope of delivery 4
1.2 General informaon 4
1.3 Structure of the warnings 5
1.4 Intended use 6
1.5 Improper use 6
1.6 FCC compliance 7
1.7 Guarantee and liability 7
1.8 Copyright 8
2 Basic safety instrucons
2.1 Noces in the operang instrucons 9
2.2 Operator‘s responsibility 9
2.2.1 Personnel‘s responsibility 9
2.2.2 Personnel training 9
2.3 Risks when working with the charging staon 9
2.4 Danger from electrical energy 10
2.5 Workplace safety 10
2.6 Electrical safety 11
2.7 Service 11
2.8 Lithium-ion baery 11
2.9 Cleaning and disposal 13
2.10 Set-up 14
2.11 Power supply 14
2.12 Structure 15
3 Start-up and use
3.1 Benets 16
3.2 Addional informaon 16
3.2.1 Charging process 17
3.2.2 Explanaon of the LED signals / funcons 18
3.2.3 Sleep funcon 19
3.3 Safety funcons and special features 19
3.4 Soware 20
3.5 Shut-o criteria 21
4 Technical data
5 Baery adapter
5.1 Changing the baery adapter 25
Table of contents
PAGE
4
PAGE
9
PAGE
16
PAGE
22
PAGE
23
- 3 -
PAGE
27
PAGE
29
PAGE
30
6 Drawings
6.1 4-bay charger staon row form (HST-MV3-04) 27
6.2 4-bay charger staon cube form (HST-MV3-04W) 27
6.3 2-bay charger staon (HST-MV3-02) 28
7 Spare parts list
CE Declaraon of conformity
- 4 -
1 Operang principles
Dear customers,
thank you for choosing a HS-Technik GmbH product.
This quality product „Made in Germany“ fulfils the highest requirements with regard to
performance, quality and accuracy. When used correctly the product will undoubtedly
perform very well for many years.
These operating instructions contain information on safety and for the operation of the
charger. In addition it contains information on the dimensions and technical data. We
would be happy to assist you with additional information or to answer your questions.
Our technical support and our technicians would be happy to assist you.
1.1 Scope of delivery
• Charging staon
• Power supply cord
• Operang instrucons
1.2 General informaon
Read the operating instructions before initial operation. Please pay particular attention
to Chapter 2 „General Safety Notes“.
This operang instrucon should make it easier for the operator to get to know the
charger and to use it for its intended purpose. The operating instructions include
important information related to the safe and proper operation of the charger.
Compliance with these instructions helps you to:
• Avoid hazards
• Avoid repair costs and downtimes
• Increase the reliability and the lifespan of the product.
- 5 -
This operating instructions must be read and applied by every person who is assigned to
conduct work using this charger.
In addition to these operation instructions the applicable regulations on accident
prevention and environmental protection should be observed.
NOTE
Aer reading, keep the operang instrucons in a place accessible to every
operator. If you have any further quesons, please feel free to contact us.
1.3 Structure of the warnings
The warnings are structured as follows:
DANGER
Indicates an immediate dangerous situaon that can lead to serious or even
deadly injuries and/or that could seriously damage or even destroy the charger.
WARNING
Indicates a potenally dangerous situaon that can lead to serious injuries
and/or damage to the charger.
NOTE
Important and useful informaon on using this charger.
- 6 -
1.4 Intended use
The charging station may only be used as described in these instructions, to charge
batteries suitable for the type of charging station.
WARNING
Intended use also includes
• following all indicaons of the operang instrucons and
• observance of inspecon and maintenance works.
Any other use or use beyond that is considered improper use. HS-Technik GmbH is not
liable for any damage resulting from this.
NOTE
These charging stations are solely suitable for charging Ni-Cd, Ni-MH and Li-
Ion batteries (nominal voltage 3.6 - 43.2 V).
Not suitable for all battery types!
On page 23, you will find the corresponding battery adapter and its charging
functions.
1.5 Improper use
We accept no liability for damage and malfunctions resulting from non-observance of
these operating instructions and improper use.
1.6 FCC compliance
Changes or modicaons not expressly approved by HS-Technik could void the user‘s au-
thority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class A digi-
tal device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protecon against harmful interference when the equipment is operated in
- 7 -
a commercial environment. This equipment generates, uses, and can radiate radio fre-
quency energy and, if not installed and used in accordance with the instrucon manual,
may cause harmful interference to radio communicaons. Operaon of this equipment
in a residenal area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
1.7 Guarantee and liability
Guarantee and liability claims for personal injury and property damage are excluded, if
caused by one or more of the following:
• improper use
• failure to observe these operating instructions
• improper installation, commissioning, operation and maintenance of the device
• Operating the device with defective safety devices or improperly installed, or non-
functioning safety and protective devices
• Failure to observe the information in the operating instructions regarding transport,
storage, assembly, commissioning, operation and maintenance of the device
• unauthorised structural modifications to the device
• improperly performed repairs
• catastrophes due to external influences and acts of God
- 8 -
1.8 Copyright
These operating instructions are intended solely for the operator and its personnel.
They contain guidelines and information which may not be fully, or partially
• reproduced
• distributed or
• otherwise shared.
The copyright of these operating instructions is retained by HS-Technik GmbH.
Manufacturer’s address:
Im Martelacker 12
D-79588 Efringen-Kirchen
Telephone: +49 (0)7628 - 91 11-0
Fax: +49 (0)7628 - 91 11-90
E-mail: [email protected]
Internet: www.hs-technik.com
- 9 -
2 Basic safety instrucons
2.1 Noces in the operang instrucons
The basic requirement for safe and proper use and fault-free operaon is knowledge of
the basic safety instrucons and safety regulaons. In addion, the rules and regulaons
for the place of use must be followed.
2.2 Operator‘s responsibility
The operator is obligated to only allow persons to work with this charging staon who
are familiar with the basic regulaons for work safety and accident prevenon and are
trained in how to use the charging staon. Safety-conscious work of the personnel must
be checked at regular intervals.
2.2.1 Personnel‘s responsibility
All persons working with this charging staon are obligated to comply with the basic regu-
laons for work safety and accident prevenon prior to starng work.
2.2.2 Personnel training
Only trained and qualied personnel may work with this charging staon. The
responsibilies of the personnel for the assembly, commissioning, operaon, maintenance
and servicing must be clearly dened. Personnel-in-training may only operate the charging
staon in the presence of an experienced person.
2.3 Risks when working with the charging staon
Faults that may hinder safety must be immediately rectified.
- 10 -
WARNING
The charging station was built in accordance with the state of the art in
technology and the approved safety regulations. Still, when using it, risks to
life and limb of the user or third parties can arise.
WARNING
Only use the charging station
• for the proper intended use
• in working order with regards to safety
2.4 Danger from electrical energy
DANGER
Only allow a qualied electrician to perform work on this charging staon.
The electrical equipment of the charging staon must be regularly inspected.
Loose connecons and charred cables must be immediately repaired. If work
on the charging staon is necessary, the device must be disconnected from
the power supply prior to opening it.
WARNING
The charging station must be kept closed at all times. Access to internal
parts is only permitted for authorized persons.
2.5 Workplace safety
a) Keep your workspace clean and well lit. Disorder or poorly lit workspaces can lead to
accidents.
b)
Do not use the charging staon in an explosive environment, in which
ammable
liquids, gases or dusts are located.
c) Take environmental inuences into account. Never subject charging staons to rain.
Do not use charging staons in moist or wet environments.
- 11 -
2.6 Electrical safety
a)
Avoid physical contact with grounded surfaces such as pipes, radiators, etc
. There
is an increased risk due to electrical shock, if your body is grounded.
b) Keep the device away from rain or moisture. Water penetrang into charging staon
increases the risk of an electrical shock.
c) Keep the charging staon away from heat, oil, sharp edges or moving device parts.
2.7 Service
NOTE
Only allow your charging staon to be repaired by a qualied technician
using only original replacement parts, available from HS-Technik GmbH. This
ensures that the safety of your device is maintained.
2.8 Lithium-ion baery
NOTE
Please make sure to follow the following instrucons for using lithium-ion
baeries!
a) Only charge the batteries in suitable chargers
if the battery is not used in a suitable
charger, it may be permanently damaged
.
b)
If the battery is not used for a longer period of time, it must not remain on the
charger or on the tool.
If a work break of more than 3 hours is expected, the battery
must be removed from the tool. Otherwise, the battery may be permanently damaged.
c)
The lithium-ion battery should not remain on the charger for longer than 36 hours
for safety reasons. Remove the battery from the charger immediately after the
charging process is completed.
d)
An empty battery should not be in contact with the tool or a charger that is
disconnected from the mains
for a longer period of time. In both cases, currents
can flow that
deep discharge the battery and can permanently damage it.
- 12 -
e)
Recharge the lithium-ion batteries immediately and
never store them when empty.
If the battery is stored while disconnected from the tool
and the charger, it will
maintain a constant capacity over a long period of time. (Loss approx. 5 % per year)
f)
Do not subject the lithium-ion battery to high temperatures (+ 50°C) or direct
sunlight. If the battery gets warmer than 50°C during operation (charging or
discharging), it must be removed from the charger or tool immediately.
g)
Keep the unused battery away from paper clips, coins, keys, nails,
screws or other
small metal objects which might bridge the contacts. Do not open the battery and do
not short-circuit it.
A short-circuit between the battery contacts can lead to burns, fire
or explosions.
h)
Under extreme use or temperature conditions, batteries can leak.
Avoid contact
with the skin or eyes if the battery leaks.
The battery fluid is acidic and can cause
chemical burns on tissue.
If the fluid comes into contact with skin, immediately wash it
with soap and water and then
rinse it with lemon juice or vinegar. If the fluid gets into
the eyes,
flush with water for at least 10 minutes and immediately go to the doctor.
i)
Make sure that the Li-Ion battery does not fall down or is subject to vibrations and
impacts.
j)
Clean the contacts on the batteries and charging station regularly with a cloth
soaked in high-percentage alcohol
or alternatively with a cotton swab.
NOTE
Lithium-ion baeries have nearly no self-discharge and do not have a memory
eect. If properly used, they will reliably supply your tool with power for
several years (approx. 800 - 1,200 charge cycles).
In general the following applies:
Avoid deep discharging or overcharging the lithium-ion baery under any
circumstances. It will be permanently damaged from this.
- 13 -
2.9 Cleaning and disposal
Substances and materials used must be handled and disposed of properly, parcularly
when cleaning with solvents.
Disposal
Power tools, batteries, accessories and packaging must be disposed of at an
environmentally-compatible recycling facility. Power tools and batteries do not go into
the household trash.
NOTE
Do not throw the used baery into the household waste, re or water, instead
have it professional disposed of by a specialist or the manufacturer.
Only for EU countries:
• Directive 2002/96/EG: Defective power tools must be collected separately and disposed
of at an environmentally-compatible recycling facility.
• Directive 2006/66/EG: Defective or drained batteries must be collected separately and
disposed of at an environmentally-compatible recycling facility. Drained batteries can
be disposed of directly:
Germany:
Recyclingzentrum Elektrowerkzeuge
Osteroder Landstraße 3
37589 Kalefeld
- 14 -
2.10 Set-up
The charging station is only suitable for operation in a dry room. All ventilation slits must
be unobstructed. If possible, set up the charging station up away from heaters and sun
radiation as an ambient temperature of more than 35° C can result in significantly longer
charging times.
WARNING
The charging station must not be operated in closed cabinets.
2.11 Power supply
By plugging the power cable into the outlet and toggling the ON/OFF switch on the back,
the charging station is ready to use.
- 15 -
2.12 Structure
1. Casing
2. Status LED charger compartment
3. Battery adapter
4. Wake-up button
5. LED signal description
Versions
HST-MV3-04
4-bay charger station
row form
Battery charger station excl. battery adapters.
HST-MV3-04W
4-bay charger station
cube form
HST-MV3-02
2-bay charger station
3
2
1
4
5
- 16 -
3 Start-up and use
3.1 Benets
• Battery parameters are measured and processed
• Special HST frequency modulation impulse charging process® Anti-memory effect
• Automatic voltage detection
• IFCS - Intelligent Full Charge System for Li-Ion batteries
• Capacity-based charge maintenance mode only for Ni-Cd & NI-MH batteries
• Detection of defective cells
• Protection against reverse polarity
• Can also charge at temperatures > 40° C
• Adapter can be changed in 2 minutes
• Software update via USB
• Suitable for Ni-Cd, Ni-MH and Li-Ion batteries
• With PFC (Power Factor Control)
All common battery types from 3.6 - 43.2 V nominal voltage such as Atlas-Copco, Bosch,
Fein, Makita, Panasonic, Desoutter, HS-Technik etc. can be quickly and reliably charged
with the HST-MV3 charging station.
WARNING
The matching battery adapter and the correct software and firmware must
be mounted/installed to charge the batteries.
3.2 Addional informaon
If the operation voltage is connected and the charging station is switched on, a self test
will automatically start.
After switching on the charger, all of the LEDs will light up and then a signal will sound.
When all of the LEDs go off, the charging station is ready to use. Now batteries can be
inserted for charging.
NOTE
HS-Technik oers updates for the charging staon for download in the course
of further development. The operator is obligated to keep the charging staon
rmware up-to-date. HS-Technik does not assume any liability for defecve
baeries if the charging staon is not operated with up-to-date rmware.
- 17 -
WARNING
Make sure the polarity +/- is correct.
When replacing batteries, make sure the new battery is not inserted until the LEDs have
gone out (red or green).
If a battery is replaced very quickly, the electronics may retain the status of the previous
battery pack.
3.2.1 Charging process
Via an initialization routine, the voltage, temperature, short circuits and reverse polarity
of the inserted battery are checked.
Prior to starting the charging process, the temperature contacts (NTC contact, etc.) are
checked. If the temperature contacts are OK, the battery will be charged.
If the battery is too hot, it can stay in the charging station, and when it has cooled down,
it will automatically start the charging again.
If the red LED lights up, the charging process will start using the special HST frequency
modulation impulse process® and charge the battery based on how depleted the battery is.
During the charging process, the voltage and temperature of the cells and the remaining
charging time are continuously monitored.
Taking all of the parameters into account, the charging current and remaining charging
time varies on a case-by-case basis. The installed fans switch on automatically, as needed
during each charging process.
Every charging process can be recorded on an optional memory chip for subsequent
evaluation.
- 18 -
3.2.2 Explanaon of the LED signals / funcons
LED signals Funcon
Akku defekt
Volt Limit
Temperatur
Temperaturkontakt fehlt
Laden
Akku voll
ON
OFF When the charging staon is not in use, it switches to
sleep mode. In order to be able to charge a baery, the
staon must be acvated by pressing the "wake up"
buon. This is located on the lower le of the front side. If
the buon is lit green, the charging staon is switched on
and baeries can be charged.
battery defective
voltage limit
temperature
temperature contact missing
charging
battery full
ON
OFF
Connuously lit red:
Baery is charging
Connuously lit green:
Baery is fully charged
Blinking blue:
Temperature is too high or too low to charge. If the
temperature of the baery is below 10° C, the LED will
blink blue and the charging staon will only charge
the baery with a low current up to a temperature of
10° C has been reached. From then on, the staon will
charge the baery normally. The same applies when the
temperature of the baery exceeds 55° C; the baery will
also be charged with a low current unl the temperature
of the baery drops below 55° C.
Blinking red/blue:
The charging staon cannot nd a temperature contact.
In most cases, the baery contact is defecve or
damaged.
battery defective
voltage limit
temperature
temperature contact missing
charging
battery full
ON
OFF
Blinking red:
The baery is defecve. The charging staon cannot nd
a measurable voltage.
battery defective
voltage limit
temperature
temperature contact missing
charging
battery full
ON
OFF
Blinking yellow:
The baery voltage is too high or too low for the baery
type. This baery cannot be charged.
- 19 -
3.2.3 Sleep funcon
The sleep function defines the time after which the charging station or the boards
switches to sleep mode when it is not charging batteries. The time can be set freely up to
18:12:15 hours via the software. The charging station can be woken up from sleep mode
by pressing the wake-up button on the front or by putting on a battery.
Each board goes into sleep mode seperately after the set time if it is not in use. If the last
board goes in sleep mode the power supply will shut off.
NOTE
Prior to use, always check that the mounted baery adapter is compable
with the baery you wish to charge.
3.3 Safety funcons and special features
The battery is charged using the HST frequency modulation impulse charging process®
until a charging parameter is reached, then the charger switches to charge retention
mode.
A microprocessor monitors and controls every charging box and only supplies the battery
with as much energy as it can effectively absorb (dialog between the battery and charging
station).
This results in low heat development and faster and better storage of the capacity. This
special charging technology ensures the charging process is always extremely gentle on the
battery and guarantees a very long service life of the battery. Furthermore, this dynamic
charging technology automatically regenerates older batteries (that were charged with
other chargers) with reduced capacity, so these batteries can continue to be used.
No "memory effect" for Ni-Cd and Ni-MH batteries, due to the special charging technology,
the residual energy in the cells is shifted which prevents accumulation or crystallization
of the electrolytes. Every time the battery is charged, the cells are reformatted and the
electromechanical balance is rearranged. Thus, the voltage curve when discharging is
significantly higher than with other comparable charging processes. (More energy in the
form of joules can be discharged).
- 20 -
Higher capacity at lower currents.
The charging boxes are completely short-circuit-proof and protected against reverse
polarity so the batteries will not be destroyed. If the polarity is reversed or there is a
short-circuit, the charging box is disconnected from the power supply and a signal will
sound, accompanied by a red blinking LED.
(The highest level of safety is thus ensured.)
The fans are controlled based on need and cool the batteries quickly, even under extreme
stress.
Absolute protection against overloading via voltage monitoring and voltage gradient
evaluation a well as Delta U, charging time limitation and dynamic temperature evaluation.
Automatic dynamic evaluation of the temperature contacts depending on the adapter
type.
NOTE
Only for Ni-Cd and Ni-MH baeries.
3.4 Soware
• Special HST frequency modulaon impulse charging process® (absolutely no memory
eect due to variable frequency-modulated impulse charging current with a high am-
plitude)
• Self diagnosc (test of the internal power circuit)
• Polarity reversal protecon (power is disconnected from the charging box, accompa-
nied by a signal and a red blinking LED, disconnect charging box - baery)
• Special charge mode for Ni-Cd baeries (for deep discharging or dormant baeries)
• No voltage change required (baery voltage is detected automacally)
• Charging at baery temperatures exceeding 40° C (by generang gradients using dyna-
mic temperature evaluaon)
• Automac evaluaon of the temperature contacts (with NTC contact, a dynamic tempe-
rature evaluaon is performed, this depends on the baery adapter.)
This manual suits for next models
2
Table of contents
Other HS-Technik Batteries Charger manuals
