Kera sit2sit hygiene hoist
Technical Manual

KERA SIT2SIT TECHNICAL DOCUMENT
www.htsystems.com.au Page 2 of 30
CONTENTS
CONTENTS 2
AT A GLANCE 3
FEATURES AND BENEFITS 4
TECHNICAL SPECIFICATIONS 7
CONFIGURATION OPTIONS 8
ACCESSORIES 9
SCRIPTING 10
GENERAL INFORMATION 12
KERA SIT2SIT FAQ 13
TIPS AND TRICKS FOR A BETTER TRANSFER 15
DAILY CHECKLIST 19
SERVICING AND MAINTENANCE 20
ABOUT HT SYSTEMS 22
CONTACT DETAILS 23
APPENDIX 1 –STOCK LIST 24
APPENDIX 2 - ASSEMBLY 27

KERA SIT2SIT TECHNICAL DOCUMENT
www.htsystems.com.au Page 3 of 30
The new way for a single caregiver to
transfer a non-weight bearing person
SOLVE YOUR TRANSFER ISSUES WITH THE KERA SIT2SIT
The Kera sit2sit’s unique design uses an easy to
fit Backstrap and Chestpad to securely hold a
person during the transfer process.
Now it’s possible for a single caregiver to quickly
and safely transfer and perform hygiene
processes for people that have no standing
strength or balance.
No more multiple transfers to remove clothing
and perform hygiene processes, no more
uncomfortable and unsafe hoist transfers,
eliminate the temptation of manual transfers …
give back time, energy, and dignity to people
living with a disability.
✓Replacement for a standing or sling hoist
(no holding on, no standing/sitting strength or balance required)
✓No weight bearing ability needed
(users are held firmly by the upper body—users include amputees and
quadriplegics)
✓Access to clothing eliminates multiple transfers and enables hygiene processes
✓Only 1 caregiver needed
✓Minimal pressure on the user’s knees
✓Reposition deep into a chair
✓Improved safety and productivity for caregivers
✓Proven by people living with MD, MND, MS, stroke, amputees and spinal injury
and many other conditions

KERA SIT2SIT TECHNICAL DOCUMENT
www.htsystems.com.au Page 4 of 30
FEATURES AND BENEFITS
KEY FEATURES
Unique Backstrap
and Chestpad
combination
•Holds the user comfortably,
safely, and securely
throughout the transfer
•Enables the Kera sit2sit to
safely transfer people with no
weight bearing ability or
stability
•No wasting time or energy or
risking injury trying to fit a
sling under the user’s body
•Allows easy access to lower
clothing; no need for multiple
transfers to remove clothing
and facilitates quick and easy
hygiene processes
Patented and
innovative transfer
position
•Tipping the user onto their
chest is a low force operation
for the caregiver
•Totally manual operation,
meaning no waiting for
batteries to charge
•Allows easy access to the
lower clothing and body, ideal
for hygiene processes and
dressings
•Stable and comfortable
transfer position for the user
•Preserves hip angle
throughout the transfer
Unique moving
Knee Supports
•Takes pressure of the knees
during the lift
•Relieves pressure on the
hamstrings and joints during
the transfer
•Pushes the lower body back
into deep chairs for the best
seating position

KERA SIT2SIT TECHNICAL DOCUMENT
www.htsystems.com.au Page 5 of 30
AT A GLANCE
INTENDED USE
The Kera sit2sit assists a single caregiver to safely and securely
transfer people, who have little or no standing strength, between
seated positions.
It is intended to be used on level surfaces for the transfer of
immobile users in hospitals, care facilities or domestic homes.
It is not intended for users to be in the transit position for long
periods of time.
QUICK TRANSFERS
BETWEEN SEATS
No need to attach a sling –Backstrap slides behind the clients back.
Quick and easy, manually powered, transfer operation.
SINGLE CAREGIVER
Unique Backstrap and Chestpad combination, comfortably, safely
and securely holds the client during the whole procedure - allowing
use by only 1 caregiver
Large high-quality castors for best-in-class manoeuvrability
FULLY MANUAL
No power just clever design –no need to store next to a power
plug or wait for it to charge up.
USER (PERSON BEING
TRANSFERRED)
SUITABILITY
Limited standing strength or balance through to non-weight
bearing or no sitting balance.
The Kera sit2sit has been used to transfer tetraplegics and double
amputees.
USER HEIGHTS AND
WEIGHTS
Clients weighing up to 120Kg and up to 190cm tall.
Adaptations available for children or smaller adults from 130cm
tall.
CONTRAINDICATIONS
Restricted breathing –This depends on the individual. The Kera
sit2sit has been used with people using a CPAP.
Thighstrap can be used to reduce the Backstrap tightness needed
to complete a transfer.
Flexibility - The person does not need to be weight bearing but will
require some level of flexibility in their lower joints to be
comfortably lifted using this device.

KERA SIT2SIT TECHNICAL DOCUMENT
www.htsystems.com.au Page 6 of 30
PEG/SPC –The Kera sit2sit has been used with both a PEG and
SPC.
Contact HT Systems for advice about customising the Chestpad, if
too much pressure is felt.
Additionally, Thighstrap used to reduce pressure on the upper
body.
ENVIRONMENT
The Kera sit2sit fits well in home environments, even in tight
locations and with heavy carpet.
Similarly, the Kera sit2sit was designed with facilities in mind and
changes instantly to transfer a number of residents with different
body types and abilities.
WEAKNESSES
Standing rehab –The Kera sit2sit does not lift the client into a
standing position.
Off a bed - Similar to standing hoists the client needs to be sitting
stably upright on the bed.
Off the floor - Similar to standing hoists the client needs to be
seated in a chair or bed.
WARRANTY
1-year limited warranty on or replace defective components or
faulty workmanship.
Spare parts will be stocked for at least 7 years.
REGULATORY
Independently laboratory tested to meet international hoist
standards (AU/NZS ISO 10535)
Registered as a Class 1 Medical Device with MedSafe (WAND)
Entered in the ARTG (388973), Australia
...with the Kera, you don't even need use
of your arms or legs.
—Steve, MND

KERA SIT2SIT TECHNICAL DOCUMENT
www.htsystems.com.au Page 7 of 30
TECHNICAL SPECIFICATIONS
PRODUCT INFORMATION
KERA80
KERA120
Product weight
35Kg
35Kg
Outside Width
605mm
605mm
Minimum internal width (legs closed)
415mm
415mm
Maximum internal width (legs open)
1100mm
1100mm
Length –handle upright
950mm
950mm
Length –handle down
1230mm
1580mm
Handle height (upright)
1300mm
1550mm
USER RECOMENDATIONS
KERA80
KERA120
User Weight
Up to 80Kg
Up to 120Kg
User Height
From 130cm to 190cm+
From 130cm to 190cm+

KERA SIT2SIT TECHNICAL DOCUMENT
www.htsystems.com.au Page 8 of 30
CONFIGURATION OPTIONS
The Kera sit2sit comes in four interchangeable configuration options to best suit the user and environment.
Option
Description
User weight
Suits seat Heights
Order code
Kera120 Low
1: Kera 120 Low
Long handle Kera sit2sit for transferring
heavier people between standard seats
such as manual wheelchairs.
Up to 120Kg
Standard seats
(380mm to 550mm)
KSI-120S
Kera 120 High*
Long handle Kera sit2sit for transferring
heavier people between taller seats such as
power wheelchairs.
Higher seats
(500mm to 650mm)
KSI-120H
Kera 80 Low
2: Kera 80 Low
Short handle Kera sit2sit for transferring
lighter people (ideal for children) between
standard seats such as manual wheelchairs.
Up to 80Kg
Standard seats
(380mm to 550mm)
KSI-80S
Kera 80 High*
Short handle Kera sit2sit for transferring
lighter people (ideal for children) between
taller seats such as power wheelchairs.
Higher seats
(500mm to 650mm)
KSI-120H
KERA SIT2SIT HIGH
The higher version of the Kera sit2sit is raised by 80mm which makes transfers between higher seats more comfortable and
efficient. The Kera sit2sit low models can be used on higher seat heights and vice versa but the transfer is typically not as
comfortable for the user.

KERA SIT2SIT TECHNICAL DOCUMENT
www.htsystems.com.au Page 9 of 30
ACCESSORIES
The Kera sit2sit can be customised to suit the user’s unique requirements with a range of
specialist accessories.
Accessory
Description
Order code
Footboxes
Specially designed Kera
sit2sit footboxes, which
are easily fitted, to hold
the user’s feet in place.
Sold as a pair, complete
with footbox straps and
toe guards.
KSI-FBX
Thighstrap
The Thighstrap is easily
added to the Kera sit2sit
and reduces the tightness
required from the
Backstrap.
KSI-TS
Riser
blocks
Add these EVA riser
blocks (60mm or 110mm)
when the user’s feet don’t
reach the footplates.
Designed to be used with
Kera sit2sit footboxes.
KSI-
RISER60
KSI-
RISER110
Knee
Foam
Pack
4 x foam packers
designed to fit behind the
Kera sit2sit Knee Support
Covers.
(4 x 10mm x 230mm x
230mm)
KSI-FOAM
Spare and replacement parts are available and further details are included in Appendix 2.

KERA SIT2SIT TECHNICAL DOCUMENT
www.htsystems.com.au Page 10 of 30
SCRIPTING

KERA SIT2SIT TECHNICAL DOCUMENT
www.htsystems.com.au Page 11 of 30
SCRIPT STEP 1. BASE UNIT
Investigate the user’s typical seats i.e. wheelchair, commode, day chair.
Measure the seat heights from the floor to the middle of the seat cushion.
A. If the seat heights are between 500 - 630mm from the ground?
A Kera sit2sit High is the best model for the user. It is set up with a raised base frame to work
best for higher chairs such as power chairs.
B. Is your seat height less than 500mm?
The Kera sit2sit Low model is more comfortable and easier to lift a person from a lower height
chairs.
SCRIPT STEP 2. USER WEIGHT
What is the weight of the person being transferred?
A. User is greater than 80Kg
The Kera120 has a “longer” handle for increased leverage (note that the maximum caregiver force is 1/5th of the user’s weight)
B. Is your seat height less than 500mm?
The Kera80 has a “shorter” handle which also results in a smaller footprint (note that the maximum caregiver force is 1/4th of the user’s
weight)
SCRIPT STEP 3. CUSTOMISED ACCESSORIES
Select the accessories required to adapt the Kera to the user’s specific needs.

KERA SIT2SIT TECHNICAL DOCUMENT
www.htsystems.com.au Page 12 of 30
GENERAL INFORMATION
USER AND CAREGIVER ASSESSMENT
A clinical assessment of the person being transferred and their suitability for use with the Kera
sit2sit should be carried out by a qualified health professional. The user does not need to be
weight bearing but will require some level of flexibility in their lower joints to be comfortably
lifted using this device.
Before each transfer the caregiver should be aware of the user’s current medical, physical, and
mental condition and not attempt a transfer if they are concerned that the transfer would
endanger the user or the caregiver’s own safety.
The Kera sit2sit was designed to minimise the load on caregivers however please be aware of
your physical ability to complete the transfer and do not attempt a transfer that would
endanger the user or the caregiver’s own safety.
INSPECTION AND CLEANING
To clean the Kera sit2sit, wipe it down with a damp cloth using warm water and a disinfectant
cleaner. Do not use harsh solvents such as phenol and chlorine as it may damage the device’s
finish. Follow laundering instructions on the Backstrap. Do not submerge any other
components for cleaning.
It is recommended that the Kera sit2sit and its accessories are regularly cleaned and/or
disinfected between each use.
MAINTENANCE AND USER INSPECTIONS
The caregiver should always inspect the device for hygiene, wear, and damage before each use
to ensure the safety of all users.
Every 12 months a more detailed inspection should be carried out by a suitably qualified
technician.
Contact HT Systems if you have any concerns about the condition or safety of the device.
The lifetime of this product in normal use is 8 years if all maintenance and servicing is carried
out in accordance with the manufacturer’s instructions and demonstrably recorded.
WARRANTY INFORMATION
HT Systems, at its sole discretion, warrants that it will repair or replace defective components
or faulty workmanship for a warranty period of one (1) year from the date of manufacture of
the product.
A warranty claim may not be accepted where:
•Notice has not been given within four (4) weeks of the defect or faulty workmanship
being first noticed.
•Damage is caused by negligence, accident or deliberate abuse, product modification,
incorrect use, incorrect storage, or maintenance and continued use of the part after the
defect or faulty workmanship is first noticed.
We reserve the right to substitute components of equal or better quality on the particular
items being repaired or replaced.
There will be no extensions to the original warranty period for any product that has been
repaired or replaced.

KERA SIT2SIT TECHNICAL DOCUMENT
www.htsystems.com.au Page 13 of 30
KERA SIT2SIT FAQ
Is the Kera sit2sit a standing hoist?
No, the Kera sit2sit is an innovative, new type of hoist
that can replace a standing hoist or sling hoist.
The Kera sit2sit can eliminate the problems
experienced by users on a standing hoist, such as
passive users being strangled under the arms and
knees being dragged into the knee pads.
Does the user require weight
bearing/standing strength?
No, the user does not require any weight bearing
ability.
The unique combination of a Backstrap and Chestpad
completely supports the user, holding them
comfortably, safely, and securely, during the transfer.
Does the user have to hold on?
No, the user does not have to hold on.
The unique combination of a Backstrap and Chestpad
completely supports the user, holding them
comfortably, safely, and securely, during the transfer.
What about breathing issues?
Breathing issues should be assessed on a case-by-
case basis by a health professional.
We have had users with a CPAP device using the Kera
sit2sit.
The Backstrap does loosen off after the lift, in the
transfer position, and the user is lying on their chest,
generally able to breath normally.
What about vertigo?
Vertigo and psychological conditions should be
assessed on a case-by-case basis by a health
professional.
The user reaction to the Kera sit2sit transfer position
is varied and unpredictable. Most users find the
transfer position, natural and comfortable.
In the transfer position, the user’s head remains
above their heart.
Does the caregiver need to be strong?
The patented design of the Kera sit2sit uses leverage
advantage to assist the caregiver to manually lift the
user.
Forces have been designed to be low (approx. 1/5th of
the user weight –long handle) but the caregiver still
needs to be fit to care.
We recommend that, before a transfer, the caregiver
assesses their physical capability to complete the
transfer and not to attempt a transfer that would
endanger the user or their own safety.

KERA SIT2SIT TECHNICAL DOCUMENT
www.htsystems.com.au Page 14 of 30
What is the weight limit of the user?
The safe working load of the person being transferred
is:
•Kera120 = 120Kg
•Kera80 = 80Kg
What height chairs does it suit?
The Kera sit2sit standard can be comfortably used to
transfer users between chairs with seat heights over
400mm.
If the seat heights are between 500 - 630mm from the
ground, then a Kera sit2sit high is the best model for
the user. It is set up with a raised base frame to work
best for higher chairs such as power chairs.
How tight do I need to do the straps?
As tight as possible while still comfortable.
If the Backstrap is too loose, the Chestpad will slip up
the user’s front until it reaches enough tightness to
lift the user.
The good news is that, although the lift will be
uncomfortable, it won’t drop the user. This can easily
be fixed by lowering the user, repositioning the
Backstrap and tightening to an appropriate level.
How far over do I have to tip
someone?
The further forward onto their chest the better.
You will notice that the handle goes weightless (about
at your waist level) and any point after this is a secure
and a safe position.
However, it is generally more comfortable for the
user to be resting almost flat on their chest rather
further back and the Backstrap holding them up.
Can I transport the Kera sit2sit in a
car?
Whilst we don’t recommend it, the Kera sit2sit is able
to be transported in the back of a hatchback with the
seats down. Refer to the instructions in this manual.
Care should be taken combined with a two person lift
as the Kera sit2sit is heavy (35Kg) and awkward.
Where is the Kera made?
The Kera sit2sit is made in our factory in
Christchurch, New Zealand using welded components
manufactured by our partners, Tuki Design.

KERA SIT2SIT TECHNICAL DOCUMENT
www.htsystems.com.au Page 15 of 30
TIPS AND TRICKS FOR A BETTER TRANSFER
Feet don’t touch the foot plates?
Firstly, check the Kera sit2sit model –A Kera high model has 80mm higher
footplates and should be used for taller seat heights (i.e. over 500mm).
If the right Kera sit2sit model is being used and the user has shorter legs where
their feet don’t reach the footplate, use the Kera sit2sit Riser Blocks (60mm or
110mm height) to raise the footplate level to the user’s feet.
The Riser Blocks should only be used with the Kera sit2sit Footboxes.
Note that a petite Chestpad is also available if the standard Chestpad is too
large.
Set up for children or smaller adults (i.e. feet not reaching the
footplate)
Can’t get the Kera sit2sit close enough to the knees?
Firstly, check that there is no impediment (i.e. wheelchair footplates) getting in
the way of the Kera sit2sit. Try to remove these impediments, if possible.
Secondly, adjust the Chestpad slider to its smallest setting and push the Kera
sit2sit firmly into the user.
Thirdly, foam packs are available to pack out the knees to remove any residual
gap.
Note also that a transfer can still be executed, although not ideally, even if
there is a small gap (3-5cm) to the knee pads.
Getting the right height setting?
Starting with the Chestpad slider at the smallest setting, slide out firmly until
meeting the user’s stomach.
Note that the Chestpad has 9cm of soft foam and can be squished firmly into
the user. Communicate with the user to ensure that the pressure is firm and
comfortable.
The user is really hunched over.
Start with the Backstrap fitted low on the back and make sure it is as tight as
possible.
Try pushing the Chestpad into the user’s stomach by one or two more holes.

KERA SIT2SIT TECHNICAL DOCUMENT
www.htsystems.com.au Page 16 of 30
When in the transfer position, the user should end up less hunched over and
the Backstrap shouldn’t slip up as much.
The user has a stiff knee joint?
After placing the user’s feet on the footplate try to get the knee as close to the
knee pad as possible.
If necessary, use foam packs to pack out the knee to remove the gap.
Next push the Chestpad into the user’s stomach by one or two more holes than
normal.
When in the transfer position, the user should be in a taller position and not
have to bend their knee as much.
The Chestpad is sliding up under their chin?
If the Backstrap is too loose, the Chestpad will slip up the user’s front until it
reaches enough tightness to lift the user.
The good news is that, although the lift will be less comfortable, it won’t drop
the user.
This situation can easily be fixed by lowering the user, repositioning the
Backstrap and tightening to an appropriate level.
If the Backstrap is too tight for the user, then add Thighstrap to take some of
the load.
The Backstrap is sliding up their back? i.e. Backstrap slipping
Too tight around the chest or sore back?
As always, the health of the user should be assessed on a case-by-case basis by
a health professional.
If the Backstrap is too tight for the user, then a Thighstrap may be added to
take some of the user’s weight during the lift.
How to manage higher or lower chairs?
Firstly, ensure that you have got the right Kera sit2sit for the
However, from time to time, a transfer may be required from a chair which is
outside the standard range of the Kera sit2sit. Generally, in these cases a lift
can be completed although it may be less comfortable for the user and present
a different force to the caregiver.

KERA SIT2SIT TECHNICAL DOCUMENT
www.htsystems.com.au Page 17 of 30
As always, please risk assess the lift being attempted, and the health of both the
user and caregiver.
If the chair is outside the standard range of the Kera sit2sit, you will note that
the Chestpad will not be parallel to the user’s upper body – this will require
some flexibility and movement of the user to align with the Chestpad position.
Proceed as normal with the process of tightening the Backstrap.
Because the Chestpad is not parallel, you will also note that the Caregiver
Handle may also require further reach and if lifting off a lower chair will require
higher force.
Repositioning someone who has slipped down in their day chair.
The Kera sit2sit is specifically designed to seat a user deep into a chair. If a user
has slouched and slipped in their day chair the Kera sit2sit can be used to sit
them back into a good upright position.
Proceed with all steps as normal although the user’s upper body with not meet
the Chestpad. After attaching the Backstrap hooks, use the mechanical
advantage of the straps to pull the user into sitting and firmly against the
Chestpad.
At this point a standard lift can be performed. Rather than transferring to
another seat the Kera sit2sit can be moved closer to the same chair and the
user placed into an upright position.
Not getting person back far enough into the chair?
Firstly, check that there is no impediment (i.e. wheelchair footplates) getting in
the way of the Kera sit2sit. Try to remove these impediments, if possible.
Secondly, adjust the Chestpad slider into the user’s stomach by one or two
more holes than normal.
Thirdly, foam packs are available to pack out the knees and push the user
deeper into their chair.
Lying to sit transfer on a bed.
Transferring off a bed should only be attempted when the user is sitting stably
on the side of the bed.

KERA SIT2SIT TECHNICAL DOCUMENT
www.htsystems.com.au Page 18 of 30
This stable position can be achieved with two caregivers or using a specially
designed raising bed.
Feet threaten to slip back off the footplates.
In the case of feet that slip off the Footplates or tremors/spasms, it is best to fit
Kera sit2sit Footboxes, to hold the user’s feet in place.
The User has tremors or spasms.
Peg or SPC
The Kera sit2sit has been used with both a PEG and SPC.
Contact HT Systems for advice about customising the Chestpad, if too much
pressure is felt.
Additionally, Thighstrap used to reduce pressure on the upper body.

KERA SIT2SIT TECHNICAL DOCUMENT
www.htsystems.com.au Page 19 of 30
DAILY CHECKLIST
DAILY CHECKLIST
Tick
Inspect the Kera sit2sit for any visible external damage
Ensure that the Caregiver Handle raises and lowers through its full range of
motion
Ensure that the Lock Lever stops the Caregiver Handle from moving
Ensure that the Leg Spreaders move freely
Ensure that the Kera sit2sit moves freely on its castors
When in the lock position, the Foot Brake must stop the Kera sit2sit from moving
The Chestpad should not be damaged
The Chestpad should slide easily
The Backstrap and Thighstrap should not be frayed or displaying other damage.
DO NOT use these supports if damaged
A clinical assessment of the user’s suitability for use with this device has been
carried out by a qualified health professional
The caregiver is fully trained and confident to use of the Kera sit2sit

KERA SIT2SIT TECHNICAL DOCUMENT
www.htsystems.com.au Page 20 of 30
SERVICING AND MAINTENANCE
GENERAL MAINTENANCE
The caregiver should always inspect the device for hygiene, wear, and damage before each use
to ensure the safety of all users.
DAILY CHECKLIST
Tick
Inspect the Kera sit2sit for any visible external damage
Ensure that the Caregiver Handle raises and lowers through its full range of
motion
Ensure that the Lock Lever stops the Caregiver Handle from moving
Ensure that the Leg Spreaders move freely
Ensure that the Kera sit2sit moves freely on its castors
When in the lock position, the foot brakes must stop the Kera sit2sit from moving
The Chestpad should not be damaged
The Chestpad should slide easily
The Backstrap and Thighstrap should not be frayed or displaying other damage.
DO NOT use these supports if damaged
A clinical assessment of the user’s suitability for use with this device has been
carried out by a qualified health professional
The caregiver is fully trained and confident to use of the Kera sit2sit
Every 12 months a more detailed inspection should be carried out by a suitably qualified
technician.
Contact HT Systems if you have any concerns about the condition or safety of the device.
The lifetime of this product in normal use is 8 years if all maintenance and servicing is carried
out in accordance with the manufacturer’s instructions and demonstrably recorded.
CLEANING
To clean the Kera sit2sit, wipe it down with a damp cloth using warm water and a disinfectant
cleaner. Do not use harsh solvents such as phenol and chlorine as it may damage the device’s
finish. Follow laundering instructions on the Backstrap. Do not submerge any other
components for cleaning.
It is recommended that the Kera sit2sit and its accessories are regularly cleaned and/or
disinfected between each use.
