Huawei SUN2000-3KTL-M0 User manual

SUN2000-(3KTL-12KTL)-M0
User Manual
Issue
01
Date
2018-12-30
HUAWEI TECHNOLOGIES CO., LTD.

Issue 01 (2018-12-30)
Copyright © Huawei Technologies Co., Ltd.
i
Copyright © Huawei Technologies Co., Ltd. 2018. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior
written consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei and
the customer. All or part of the products, services and features described in this document may not be
within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements,
information, and recommendations in this document are provided "AS IS" without warranties, guarantees or
representations of any kind, either express or implied.
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
Huawei Technologies Co., Ltd.
Address:
Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website:
http://e.huawei.com

SUN2000-(3KTL-12KTL)-M0
User Manual
About This Document
Issue 01 (2018-12-30)
Copyright © Huawei Technologies Co., Ltd.
ii
About This Document
Purpose
This document describes the SUN2000-3KTL-M0, SUN2000-4KTL-M0,
SUN2000-5KTL-M0, SUN2000-6KTL-M0, SUN2000-8KTL-M0, SUN2000-10KTL-M0,
and SUN2000-12KTL-M0 (SUN2000 for short) in terms of installation, electrical connections,
commissioning, maintenance, and troubleshooting. Read this document through, understand
the safety information, and get familiar with the functions and features of the SUN2000
before installing and operating it.
Intended Audience
This document is intended for photovoltaic (PV) power plant personnel and qualified
electrical technicians.
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol
Description
Indicates an imminently hazardous situation which, if
not avoided, will result in serious injury or death.
Indicates a potentially hazardous situation which, if not
avoided, could result in serious injury or death.
Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
Indicates a potentially hazardous situation which, if not
avoided, could result in equipment damage, data loss,
performance deterioration, or unanticipated results.
NOTICE is used to address practices not related to
personal injury.

SUN2000-(3KTL-12KTL)-M0
User Manual
About This Document
Issue 01 (2018-12-30)
Copyright © Huawei Technologies Co., Ltd.
iii
Symbol
Description
Calls attention to important information, best practices
and tips.
NOTE is used to address information not related to
personal injury, equipment damage, or environment
deterioration.
Change History
Changes between document issues are cumulative. The latest document issue contains all
updates made in previous issues.
Issue 01 (2018-12-30)
This issue is used for first office application (FOA).

SUN2000-(3KTL-12KTL)-M0
User Manual
Contents
Issue 01 (2018-12-30)
Copyright © Huawei Technologies Co., Ltd.
iv
Contents
About This Document.................................................................................................................... ii
1 Safety Precautions.........................................................................................................................1
2 Overview.........................................................................................................................................4
2.1 Product Introduction .....................................................................................................................................................4
2.2 Appearance ...................................................................................................................................................................7
2.3 Label Description..........................................................................................................................................................9
2.3.1 Enclosure Labels........................................................................................................................................................9
2.3.2 Product Nameplate...................................................................................................................................................10
2.4 Working Principles...................................................................................................................................................... 11
2.4.1 Circuit Diagram .......................................................................................................................................................11
2.4.2 Working Modes........................................................................................................................................................11
3 Storage...........................................................................................................................................13
4 Installation....................................................................................................................................14
4.1 Checking Before Installation ......................................................................................................................................14
4.2 Tools ...........................................................................................................................................................................14
4.3 Determining the Installation Position .........................................................................................................................16
4.3.1 Environment Requirements .....................................................................................................................................16
4.3.2 Space Requirements.................................................................................................................................................16
4.4 Installing the Mounting Bracket .................................................................................................................................20
4.4.1 Wall-mounted Installation........................................................................................................................................21
4.4.2 Support-mounted Installation ..................................................................................................................................23
5 Electrical Connections................................................................................................................27
5.1 Preparing for Installation ............................................................................................................................................28
5.2 Connecting the PE cable.............................................................................................................................................30
5.3 Connecting the AC Output Power Cable ....................................................................................................................32
5.4 Connecting the DC input power cable........................................................................................................................35
5.5 (Optional) Installing the Smart Dongle.......................................................................................................................39
5.6 (Optional) Installing the Signal Cable ........................................................................................................................40
5.6.1 (Optional) Connecting the RS485 Communications Cable .....................................................................................42
5.6.2 (Optional) Connecting the Smart Power Sensor Signal Cable.................................................................................44
5.6.3 (Optional) Connecting the Power Grid Scheduling Signal Cable............................................................................45

SUN2000-(3KTL-12KTL)-M0
User Manual
Contents
Issue 01 (2018-12-30)
Copyright © Huawei Technologies Co., Ltd.
v
6 Commissioning............................................................................................................................47
6.1 Check Before Power-On.............................................................................................................................................47
6.2 Powering On the System.............................................................................................................................................48
6.3 Powering Off the System............................................................................................................................................48
7 Maintenance.................................................................................................................................49
7.1 Routine Maintenance..................................................................................................................................................49
7.2 Troubleshooting..........................................................................................................................................................50
8 Handling the Inverter.................................................................................................................58
8.1 Removing the SUN2000.............................................................................................................................................58
8.2 Packing the SUN2000.................................................................................................................................................58
8.3 Disposing of the SUN2000.........................................................................................................................................58
9 Technical Data .............................................................................................................................59
A Grid Codes...................................................................................................................................64
B Starting Built-in PID Repair.....................................................................................................67
C Acronyms and Abbreviations..................................................................................................68

SUN2000-(3KTL-12KTL)-M0
User Manual
1 Safety Precautions
Issue 01 (2018-12-30)
Copyright © Huawei Technologies Co., Ltd.
1
1 Safety Precautions
General Safety Precautions
Before performing operations, read through this manual and follow all the precautions to
prevent accidents. The DANGER, WARNING, CAUTION, and NOTICE marks in this
document do not represent all the safety instructions. They are only supplements to the
safety instructions.
Only certified electricians are allowed to install, connect cables for, commission, maintain,
and troubleshoot the SUN2000, and they must understand basic safety precautions to
avoid hazards.
When operating Huawei products and devices, in addition to following the general
precautions in this document, follow the specific safety instructions given by Huawei. Huawei
will not be liable for any consequence caused by the violation of the safety operation
regulations and design, production, and usage standards.
Disclaimer
Huawei shall not be liable for any consequence caused by any of the following events:
Damage during transportation
Storage conditions that do not meet the requirements specified in this document.
Incorrect storage, installation, or use
Installation or use by unqualified personnel
Failure to obey the operation instructions and safety precautions in this document
Operation in extreme environments which are not covered in this document
Operation of the SUN2000 beyond specified parameter ranges
Unauthorized modifications to the product or software code or removal of the product
Device damage due to abnormal natural factors (force majeure, such as lightning strike,
earthquake, fire, and storm)
Warranty expiration without extension of the warranty service
Installation or use in environments which are not specified in related international
standards

SUN2000-(3KTL-12KTL)-M0
User Manual
1 Safety Precautions
Issue 01 (2018-12-30)
Copyright © Huawei Technologies Co., Ltd.
2
Personnel Requirements
Only certified electricians are allowed to install, connect cables for, commission, maintain,
troubleshoot, and replace the SUN2000. Operators need to meet the following requirements.
Be properly trained.
Read through this manual and master related safety precautions.
Be familiar with related safety regulations on electrical systems.
Understand the components and functioning of a grid-tied PV power system and relevant
local standards.
Wear proper PPE all the time.
Protecting Labels
Do not scrawl, damage, or block any warning label and nameplate on the SUN2000 enclosure.
System Installation
Do not install the SUN2000 with the power on.
Ensure that the SUN2000 is not connected to a power supply or powered on before the
installation is complete.
Ensure that the SUN2000 is installed in a ventilated environment.
Ensure that the heat sinks are free of blockage.
Do not open the front panel of the SUN2000.
Do not remove the terminals at the bottom of the SUN2000.
Grounding
When installing a device, install the ground cable first. When removing a device, remove
the ground cable at last.
Do not damage the ground conductor.
Electrical Connections
Before connecting cables, ensure that the SUN2000 is secured in position and not damaged in
any way. Otherwise, electric shocks or fire may occur.
Ensure that all electrical connections comply with local electrical standards.
Obtain approval from the local utility company before using the SUN2000 in grid-tied
mode.
Ensure that the cables used in a grid-tied PV power system are properly connected and
insulated and meet specifications.

SUN2000-(3KTL-12KTL)-M0
User Manual
1 Safety Precautions
Issue 01 (2018-12-30)
Copyright © Huawei Technologies Co., Ltd.
3
Operation
High voltage generated by the SUN2000 during operation may cause an electric shock, which
could result in death, serious injury, or serious property damage. Perform operations in strict
accordance with safety precautions specified in this document and other relevant documents.
Before operating a device, ensure that it is properly grounded.
Do not touch an energized SUN2000, as the heat sink is hot.
Comply with local laws and regulations when operating a device.
Commissioning
When the SUN2000 is powered on for the first time, only qualified personnel are allowed to
set the parameters on Quick Setting . Incorrect settings may cause the SUN2000 to conflict
with the local certification, which affects the normal operation of the SUN2000.
Maintenance and Replacement
High voltage generated by the SUN2000 during operation may cause an electric shock, which
could result in death, serious injury, or serious property damage. Prior to maintenance, power
off the SUN2000 and strictly comply with the safety precautions in this document and
associated documents to operate the SUN2000.
A faulty SUN2000 requires overall maintenance. Contact your dealer if the SUN2000 is
faulty.
Maintain the SUN2000 with sufficient knowledge of this document, proper tools, and
testing equipment.
Before maintaining the SUN2000, power it off and follow the instructions on the delay
discharge label. Wait for a proper time to operate the SUN2000.
Place temporary warning signs or erect fences to prevent unauthorized access to the
maintenance site.
Rectify any fault that may compromise the SUN2000 security performance before
powering it on again.
Observe ESD precautions during maintenance.

SUN2000-(3KTL-12KTL)-M0
User Manual
2 Overview
Issue 01 (2018-12-30)
Copyright © Huawei Technologies Co., Ltd.
4
2 Overview
2.1 Product Introduction
Function
The SUN2000 is a three-phase grid-tied PV string inverter that converts the DC power
generated by PV strings intoAC power and feeds the power into the power grid.
This document involves the following product models:
SUN2000-3KTL-M0
SUN2000-4KTL-M0
SUN2000-5KTL-M0
SUN2000-6KTL-M0
SUN2000-8KTL-M0
SUN2000-10KTL-M0
SUN2000-12KTL-M0
Figure 2-1 Model description (SUN2000-5KTL-M0 as an example)
Table 2-1 Model description
Icon
Meaning
Description
1
Product
SUN2000: three-phase grid-tied PV string inverter

SUN2000-(3KTL-12KTL)-M0
User Manual
2 Overview
Issue 01 (2018-12-30)
Copyright © Huawei Technologies Co., Ltd.
5
Icon
Meaning
Description
2
Power level
3K: The rated power is 3 kW.
4K: The rated power is 4 kW.
5K: The rated power is 5 kW.
6K: The rated power is 6 kW.
8K: The rated power is 8 kW.
10K: The rated power is 10 kW.
12K: The rated power is 12 kW.
3
Topology
TL: transformerless
4
Product code
M0: the product series with the 1100 V DC input
voltage
Network Application
The SUN2000 applies to grid-tied PV systems for residential rooftops and small ground plants.
Typically, a grid-tied system consists of the PV string, grid-tied inverter, residual current
device (RCD), and power distribution unit.
Figure 2-2 Networking application (optional in dashed boxes)
indicates a power cable, indicates a signal cable, indicates wireless communication.
(A) PV module
(B) DC switch
(C) SUN2000

SUN2000-(3KTL-12KTL)-M0
User Manual
2 Overview
Issue 01 (2018-12-30)
Copyright © Huawei Technologies Co., Ltd.
6
(D) AC switch
(E) ACDU
(F) Smart Power Sensor
(G) Power grid
(H) 4G Smart Dongle
(I) GPRS Smart Dongle
(J) WLAN Smart Dongle
(K) Router
(L) Remote management system
(M) Local app
(N) Load
Supported Power Grids
Power grid types supported by the SUN2000 include TN-S, TN-C, TN-C-S, TT, and IT.
Figure 2-3 Supported power grids
In a TT power grid, the N-PE voltage should be lower than 30 V.
In a TT power grid, you need to set isolation settings to input not grounded, with a transformer,
then the built-in PID repair is disabled.

SUN2000-(3KTL-12KTL)-M0
User Manual
2 Overview
Issue 01 (2018-12-30)
Copyright © Huawei Technologies Co., Ltd.
7
2.2 Appearance
Figure 2-4 Appearance
(1) LED indicator
(2) Front panel
(3) Mounting plate
(4) Heat sink
(5) Ventilation valve
(6) Ground screw
(7) AC output port (AC)
(8) Communication port (COM)
(9) Smart Dongle port (GPRS/4G/WLAN)
(10) Battery terminals (BAT+/BAT–)
(reserved)
(11) DC input terminals (PV2+/PV2–)
(12) DC input terminals (PV1+/PV1–)
(13) DC switch (DC SWITCH)
Two M6 screw holes are reserved on the sides of the enclosure for installing an awning.
Table 2-2 LED indicator description
Category
Status
Meaning
Running
LED 1
LED 2
N/A

SUN2000-(3KTL-12KTL)-M0
User Manual
2 Overview
Issue 01 (2018-12-30)
Copyright © Huawei Technologies Co., Ltd.
8
Category
Status
Meaning
indication
Steady green
Steady green
The SUN2000 is operating in
grid-tied mode.
Blinking green at
long intervals (on
for 1s and then
off for 1s)
Off
The DC is on and the AC is
off.
Blinking green at
long intervals (on
for 1s and then
off for 1s)
Blinking green at
long intervals (on
for 1s and then
off for 1s)
The DC is on, the AC is on,
and the SUN2000 is not
exporting power to the power
grid.
Off
Blinking green at
long intervals
DC is off and AC is on (only
for non-China versions).
Off
Off
China version: DC is off,
and AC may be energized
(Ensure that the external
AC switch is OFF).
Non-China versions: DC
is off and AC is on.
Blinking red at
short intervals
(on for 0.2s and
then off for 0.2s)
N/A
DC environmental alarm
N/A
Blinking red at
short intervals
(on for 0.2s and
then off for 0.2s)
AC environmental alarm
Steady red
Steady red
Fault
Communication
indication
LED 3
N/A
Blinking green at short intervals (on
for 0.2s and then off for 0.2s)
Communication is in
progress. (When a mobile
phone is connected to the
SUN2000, the indicator first
indicates that the phone is
connected to the SUN2000):
blinks green at long
intervals.)
Blinking green at long intervals (on
for 1s and then off for 1s)
The mobile phone is
connected to the SUN2000.
Off
There is no communication.

SUN2000-(3KTL-12KTL)-M0
User Manual
2 Overview
Issue 01 (2018-12-30)
Copyright © Huawei Technologies Co., Ltd.
9
2.3 Label Description
2.3.1 Enclosure Labels
Symbol
Name
Meaning
Delayed discharge
Residual voltage exists
after the SUN2000 is
powered off. It takes 5
minutes for the SUN2000
to discharge to the safe
voltage.
Burn warning
Do not touch a running
SUN2000 because it
generates high
temperatures on the shell.
Electric shock warning
label
High voltage exists
after the SUN2000 is
powered on. Only
qualified and trained
electrical technicians
are allowed to perform
operations on the
SUN2000.
High contact current
exists after the
SUN2000 is powered
on. Ensure that the
SUN2000 has been
grounded before
powering on it.
Refer to documentation
Reminds operators to
refer to the documents
shipped with the
SUN2000.
Grounding
Indicates the position for
connecting the protective
earthing (PE) cable.
Operation warning
Do not remove the DC
input connector or the AC
output connector when the
SUN2000 is running.
SUN2000 serial number
(SN) label
Indicates the SUN2000
SN.

SUN2000-(3KTL-12KTL)-M0
User Manual
2 Overview
Issue 01 (2018-12-30)
Copyright © Huawei Technologies Co., Ltd.
10
Symbol
Name
Meaning
SUN2000 MAC address
label
Indicates the MAC
address.
QR code label for
SUN2000 Wi-Fi
connection
Scan the QR code to
connect to Huawei
SUN2000 Wi-Fi network
(Android) or obtain the
Wi-Fi password (iOS).
2.3.2 Product Nameplate
Figure 2-5 Nameplate (SUN2000-5KTL-M0 as an example)
(1) Trademark and product model
(2) Important technical specifications
(3) Compliance symbols
(4) Company name and country of manufacture
The nameplate figure is for reference only.
Symbol
Name
Meaning
Environmentally friendly
use period (EFUP) mark
The product does not
pollute the environment
during the specified
period.
EU waste electrical and
electronic equipment
(WEEE) mark
Do not dispose of the
product as household
garbage.

SUN2000-(3KTL-12KTL)-M0
User Manual
2 Overview
Issue 01 (2018-12-30)
Copyright © Huawei Technologies Co., Ltd.
11
2.4 Working Principles
2.4.1 Circuit Diagram
Two PV strings connect to the SUN2000, and their maximum power points are tracked by two
maximum power point tracking (MPPT) circuits. The SUN2000 converts DC power into
three-phase AC power through an inverter circuit. Surge protection is supported on both the
DC and AC sides.
Figure 2-6 SUN2000 conceptual diagram
2.4.2 Working Modes
The SUN2000 can work in Standby, Operating, or Shutdown mode.

SUN2000-(3KTL-12KTL)-M0
User Manual
2 Overview
Issue 01 (2018-12-30)
Copyright © Huawei Technologies Co., Ltd.
12
Figure 2-7 Working modes
Table 2-3 Working mode description
Working
Mode
Description
Standby
The SUN2000 enters Standby mode when the external environment does not
meet the operating requirements. In Standby mode:
The SUN2000 continuously performs status check and enters the
Operating mode once the operating requirements are met.
The SUN2000 enters Shutdown mode after detecting a shutdown
command or a fault after startup.
Operating
In Operating mode:
The SUN2000 converts DC power from PV strings into AC power and
feeds the power to the power grid.
The SUN2000 tracks the maximum power point to maximize the PV
string output.
If the SUN2000 detects a fault or a shutdown command, it enters the
Shutdown mode.
The SUN2000 enters Standby mode after detecting that the PV string
output power is not suitable for connecting to the power grid for
generating power.
Shutdown
In Standby or Operating mode, the SUN2000 enters Shutdown mode
after detecting a fault or shutdown command.
In Shutdown mode, the SUN2000 enters Standby mode after detecting a
startup command or that the fault is rectified.

SUN2000-(3KTL-12KTL)-M0
User Manual
3 Storage
Issue 01 (2018-12-30)
Copyright © Huawei Technologies Co., Ltd.
13
3 Storage
The following requirements should be met if the SUN2000 is not put into use directly:
Do not unpack the SUN2000.
Keep the storage temperature at –40°C to +70°C and the humidity at 5%–95% RH.
The SUN2000 should be stored in a clean and dry place and be protected from dust and
water vapor corrosion.
A maximum of eight SUN2000s can be stacked. To avoid personal injury or device
damage, stack SUN2000s with caution to prevent them from falling over.
Periodic inspections are required during the storage. Replace the packing materials if
necessary.
If the SUN2000 has been long-term stored, inspections and tests should be conducted by
qualified personnel before it is put into use.

SUN2000-(3KTL-12KTL)-M0
User Manual
4 Installation
Issue 01 (2018-12-30)
Copyright © Huawei Technologies Co., Ltd.
14
4 Installation
4.1 Checking Before Installation
Outer Packing Materials
Before unpacking the inverter, check the outer packing materials for damage, such as holes
and cracks, and check the inverter model. If any damage is found or the inverter model is not
what you requested, do not unpack the package and contact your supplier as soon as possible.
You are advised to remove the packing materials within 24 hours before installing the inverter.
Package Contents
After unpacking the inverter, check that the contents are intact and complete. If any damage is
found or any component is missing, contact your supplier.
For details about the number of contents, see the Packing List in the packing case.
4.2 Tools
Type
Tool
Install
ation
Tools
Hammer drill
Drill bit: Φ8 mm and
Φ6 mm
Socket wrench set
Torque screwdriver
Phillips head: M3
Diagonal pliers
