Huawei IPC1601 User manual

IPC1601&2602&5602&5603
V100R001C03SPC600
User Guide
Issue
12
Date
2014-06-12
HUAWEI TECHNOLOGIES CO., LTD.

Issue 12 (2014-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
i
Copyright © Huawei Technologies Co., Ltd. 2014. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior
written consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd. All other
trademarks and trade names mentioned in this document are the property of their respective holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei and
the customer. All or part of the products, services and features described in this document may not be
within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements,
information, and recommendations in this document are provided "AS IS" without warranties, guarantees
or representations of any kind, either express or implied.
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
Huawei Technologies Co., Ltd.
Address:
Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website:
http://enterprise.huawei.com

IPC1601&2602&5602&5603
User Guide
About This Document
Issue 12 (2014-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
ii
About This Document
Purpose
This document is a user manual for IP box cameras, including the product features, hardware
installation, network access, network configuration, daily maintenance, and troubleshooting.
This document applies to IPC5602, IPC1601, IPC5603, and IPC2602.
Intended Audience
This document is intended for:
Technical support engineers
Maintenance engineers
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol
Description
Indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
Indicates a potentially hazardous situation which, if not
avoided, could result in equipment damage, data loss,
performance deterioration, or unanticipated results.
NOTICE is used to address practices not related to personal
injury.
Calls attention to important information, best practices and
tips.
NOTE is used to address information not related to personal
injury, equipment damage, and environment deterioration.

IPC1601&2602&5602&5603
User Guide
About This Document
Issue 12 (2014-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
iii
Change History
Changes between document issues are cumulative. The latest document issue contains all the
changes made in earlier issues.
Updates in Issue 12 (2014-06-12)
This issue is the twelfth official release, compared to issue 11:
Modified
9.1 Configuring the Date and Time
Modified the Date&Time page and description.
Updates in Issue 11 (2014-02-25)
This issue is the eleventh official release, compared to issue 10:
Added
4.1 Login and Logout
Added notes of login and logout.
5.10 Configuring the SD Card
Added notes of configuring the SD card.
Modified
1 Safety Precautions
Modified the safety precautions.
4.3 Browsing Videos
Modified the browsing video notes.
5.4 Setting OSD Parameters
Modified the OSD page and description of OSD parameters.
5.8 Configuring the System Language
Modified the system language page and procedure.
5.9 Configuring the Privacy Mask Function
Modified the privacy masking page.
6.1 Setting Local Network Parameters
Modified the local network page and description of parameters.
Deleted
9.3.1 Configuring a Permission Group
Deleted the permission group parameters table.

IPC1601&2602&5602&5603
User Guide
About This Document
Issue 12 (2014-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
iv
Updates in Issue 10 (2013-09-30)
This issue is the tenth official release, compared to issue 09:
Modified
Modified all the related web page with Reset.
About This Document
Modified the suitable model.
Updates in Issue 09 (2013-08-31)
This issue is the ninth official release, compared to issue 08:
Modified
5.4 Setting OSD Parameters
Modified the OSD page and description.Deleted
2.1 Product Overview
Deleted the GND symbol of the rear panel.
Updates in Issue 08 (2013-07-31)
This issue is the eighth official release, compared to issue 07:
Modified
2.2 Features
Modified image processing features.
4.1 Login and Logout
Modified the caution.
4.2 Main Page Layout
Modified the web configuration page.
4.3 Browsing Videos
Modified description about sensor configuration.
6.3.3 Setting Protocol Parameters
Modified Setting Protocol Parameters.
7.2 Setting I/O Alarm Linkage Parameters
Modified Schedule Time Setting page.
7.3 Setting Motion DetectionAlarm Linkage Parameters
Modified Setting Motion Detection Alarm Linkage Parameters
7.4.1 Configuring the Alarm Reporting Interval
Modified the motion detection alarm latch.
9.2 Querying Device Logs

IPC1601&2602&5602&5603
User Guide
About This Document
Issue 12 (2014-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
v
Modified description about download log.
9.4 Upgrading Devices
Modified description about Upgrading Devices.
Deleted
2.2 Features
Deleted SD card storages.
Updates in Issue 07 (2013-06-30)
This issue is the seventh official release, compared to issue 06:
Modified
5.4 Setting OSD Parameters
Modified the description about OSD.
5.9 Configuring the Privacy Mask Function
Modified the Privacy Masking page.
5.10 Configuring the SD Card
Modified the SD Card page and description.
7.1 Setting I/O Alarm Parameters
Modified the alarm I/O page and parameters description.
9.3.1 Configuring a Permission Group
Modified the Reset Service Password page.
Updates in Issue 06 (2013-05-30)
This issue is the sixth official release, compared to issue 05:
Added
4.3 Browsing Videos
Added description about live view.
Updates in Issue 05 (2013-03-30)
This issue is the fifth official release, compared to issue 04:
Modified
About This Document
Modified special notices.
2.2 Features
Modified description about the security features.
3.1 Preparing Installation Tools
Modified preparing installation tools.

IPC1601&2602&5602&5603
User Guide
About This Document
Issue 12 (2014-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
vi
5.4 Setting OSD Parameters
Modified description about OSD.
9.5 Resetting the System Service Password
Modified the Reset Service Password page
Chapter 11 Technical Specifications
Modified the technical specifications.
Updates in Issue 04 (2013-02-15)
This issue is the fourth official release, compared to issue 03:
Added
2.1 Product Overview
Added the diagram of SD card slots.
5.2 Setting Video and Audio Stream Parameters
Added description about the recommended bit rate.
Modified
3.2 Installing a Lens
Modified the installation procedure of the iris.
9.7 Restoring a Device to Factory Settings
Modified the procedure for restoring to the factory defaults.
Deleted
Chapter 11 Technical Specifications
Deleted the stream range.
Updates in Issue 03 (2012-12-30)
This issue is the third official release, compared to issue 02:
Added
Chapter 1 Security Precautions
Added description about lightening protection measures and working high above the ground.
2.2 Features
Added description about the security features.
6.3.2 Setting SecurityAuthentication
Added description about security authentication.
Modified
9.4 Upgrading Devices
Modified description about device upgrade.

IPC1601&2602&5602&5603
User Guide
About This Document
Issue 12 (2014-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
vii
Deleted
5.10.2 Configuring a Recording Directory
Deleted the NAS and FTP directories where video files are stored.
Updates in Issue 02 (2012-09-30)
This issue is the second official release, compared to issue 01:
Modified
Chapter 10 Troubleshooting
Modified the steps for deleting browser cache.
Issue 01 (2012-07-15)
This issue is the first official release.
Special Notices
You are required to comply with applicable laws and regulations for using and maintaining video surveillance
services. It is forbidden to illegally install video surveillance devices in offices to monitor employee
behaviors or work efficiency or to use video surveillance devices with illegitimate purposes, for example,
snooping others' privacy.
The device may be upgraded without prior notice. To download the latest program and
supplementaty documentation, visit http://support.huawei.com/enterprise Product
Support > Unified Communications and Collaboration > Video Surveillance > Cameras >
Specialty Cameras > IPE

IPC1601&2602&5602&5603
User Guide
Contents
Issue 12 (2014-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
viii
Contents
About This Document.................................................................................................................... ii
1 Safety Precautions.........................................................................................................................1
2 Overview.........................................................................................................................................4
2.1 Product Overview.........................................................................................................................................................4
2.2 Features.........................................................................................................................................................................6
3 Hardware Installation ..................................................................................................................8
3.1 Preparing Installation Tools..........................................................................................................................................8
3.2 Installing a Lens............................................................................................................................................................8
3.2.1 Installing an Auto Aperture and Manual focus Lens..................................................................................................9
3.2.2 Installing a Manual Aperture and Manual focus Lens ...............................................................................................9
3.2.3 Uninstalling a Lens..................................................................................................................................................10
3.3 Connecting Other Devices to the Camera Through the Ports on the Rear Panel........................................................10
4 Quick Access ................................................................................................................................12
4.1 Login and Logout .......................................................................................................................................................12
4.2 Main Page Layout.......................................................................................................................................................13
4.3 Browsing Videos.........................................................................................................................................................15
4.4 Controlling and Configuring the PTZ.........................................................................................................................18
5 Device Configuration.................................................................................................................21
5.1 Configuring the Device Information...........................................................................................................................21
5.2 Setting Video and Audio Stream Parameters ..............................................................................................................22
5.3 Setting the Channel Name, Video System, and Source Resolution ............................................................................26
5.4 Setting OSD Parameters .............................................................................................................................................27
5.5 Configuring the Microphone ......................................................................................................................................30
5.6 Configuring the Dome PTZ Address ..........................................................................................................................31
5.7 Enabling the Analog Output Function ........................................................................................................................32
5.8 Configuring the System Language and web mode .....................................................................................................33
5.9 Configuring the Privacy Mask Function.....................................................................................................................34
5.10 Configuring the SD Card..........................................................................................................................................35
6 Network Configuration .............................................................................................................37
6.1 Setting Local Network Parameters .............................................................................................................................37

IPC1601&2602&5602&5603
User Guide
Contents
Issue 12 (2014-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
ix
6.2 Configuring Device Ports ...........................................................................................................................................39
6.3 Setting Platform Parameters .......................................................................................................................................41
6.3.1 Checking Protocol Information ...............................................................................................................................41
6.3.2 Setting Security Authentication ...............................................................................................................................41
6.3.3 Setting Protocol Parameters.....................................................................................................................................42
6.4 Viewing the ADSL Network Parameters ....................................................................................................................44
6.5 Setting PPPoE Parameters..........................................................................................................................................45
6.6 Setting DDNS Parameters ..........................................................................................................................................46
7 Alarm Configuration ..................................................................................................................48
7.1 Setting I/O Alarm Parameters.....................................................................................................................................48
7.2 Setting I/O Alarm Linkage Parameters.......................................................................................................................50
7.3 Setting Motion Detection Alarm Linkage Parameters................................................................................................52
7.4 Processing Alarms ......................................................................................................................................................55
7.4.1 Configuring the Alarm Reporting Interval...............................................................................................................55
7.4.2 Configuring the Alarm Center .................................................................................................................................55
7.4.3 Setting SMTP Parameters........................................................................................................................................56
8 External Device Configuration.................................................................................................59
8.1 Setting External PTZ Parameters................................................................................................................................59
8.2 Setting External PTZ Keyboard Parameters...............................................................................................................61
9 Daily Maintenance......................................................................................................................63
9.1 Configuring the Date and Time ..................................................................................................................................63
9.2 Querying Device Logs................................................................................................................................................66
9.2.1 Querying Operation Logs ........................................................................................................................................66
9.2.2 Querying Alarm Logs ..............................................................................................................................................67
9.3 Configuring User Permissions....................................................................................................................................68
9.3.1 Configuring a Permission Group .............................................................................................................................68
9.3.2 Configuring a User ..................................................................................................................................................70
9.4 Upgrading Devices .....................................................................................................................................................72
9.5 Resetting the System Service Password .....................................................................................................................72
9.6 Restarting a Device.....................................................................................................................................................73
9.7 Restoring a Device to Factory Settings.......................................................................................................................74
9.8 Collecting Logs...........................................................................................................................................................75
10 Troubleshooting........................................................................................................................77
11 Technical Specifications ..........................................................................................................79

IPC1601&2602&5602&5603
User Guide
1 Safety Precautions
Issue 12 (2014-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1
1 Safety Precautions
The following safety precautions provide important information to prevent fire and personal
injury caused by improper use of the device. Read this section before installing a device, and
comply with these cautions during use. If you want to install the device in a public place,
provide a conspicuous warning message "You have entered the electronic surveillance area."
The actual device governs, and this document is only for reference.
The device may be upgraded without prior notice.
For the latest programs and supplementary documentation, contact Huawei customer
service center.
If any problems occur during use, contact the supplier or customer service center.
Any loss caused by improper operations is born by the buyer.
Basic Precautions
Install the device in strict accordance with the installation guide.
Never try to dissemble the device on your own. If any fault occurs, contact the specified
maintenance center.
No unit or individual is allowed to change the device structure, safety configuration, and
performance without authorization.
Use this device in accordance with the related laws and with respect for others' legal
rights.
Power Supply Precautions
Use a power adapter meeting Limited Power Source (LPS) requirements and comply
with the local electrical safety standards during device installation.
Use a power adapter matching this device. The power supply voltage must meet the
input voltage requirement.
Never power on the device before installation completes. Before installing or removing a
cable, stop using the device and power it off.

IPC1601&2602&5602&5603
User Guide
1 Safety Precautions
Issue 12 (2014-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
2
Verify that a proper power supply is used before running the device.
Keep the power plug to be clean and dry to prevent electric shock or other risks.
When the device is installed in voltage instability regions, grounding the device and
releasing the surge of high-energy to prevent power equipment burnning out.
Precautions for Use
Avoid heavy weight, violent vibration, soaking during transport, storage, and installation;
otherwise, the device may be damaged. Any damage caused by improper transport of the
assembled device during delivery from or sending back to the manufacture for repair is
out of the warranties.
Never install the device upside down. Hold the device with careful. Never tightly press
any structural parts; otherwise, mechanical breakdown may occur.
Never dissemble the device to repair it. The device must be checked and repaired by
professional maintenance personnel.
Never scratch or abrade the device surface; otherwise, the paint that is dropped down
may cause allergy or device damage. For example, if it drops into the host, electrical
malfunction may occur.
If any exceptions occur, for example, smoke is blown out of the device, the device
sounds abnormally, or peculiar smell is found, stop using the device, power it off, and
remove all cables (such as the power cord and networking cable) connected to the device.
If the device is faulty, contact the specified maintenance center for repair.
Cleaning Precautions
Before cleaning the device, stop using the device and power it off, and then remove all
cables (such as the power cord and network cable) connected to the device.
Use a soft and dry cloth to clean the device. If there is any dirt that is difficult to clean,
place a few drops of mild detergent on a soft and clean cloth before cleaning.After the
dirt is removed, dry the device with a cloth.
Never use any volatile solvents (such as the alcohol, benzene, and thinner) or strong and
abrasive alkaline detergent; otherwise, the device surface may be damaged or the device
performance may be reduced.
Environment Precautions
Never allow any water or other liquid to flow into the device. If any liquid flows into the
device by accident, power the device off, and remove all cables (such as the power cord
and network cable) connected to the device.
Avoid heavy weight, violent vibration, soaking during transport, storage, and installation;
otherwise, the device may be damaged.
Install the device at a place far away from the heat source or ignition source, such as an
electric heater or lighted candle.
Never install or use the device in places where flammable or explosive materials are
saved or in use.
Deploy surge protection devices if the device is installed outside.
When working high above the ground, take security measures, such as wearing helmets
and safety belts and choosing secure elevating apparatus.

IPC1601&2602&5602&5603
User Guide
1 Safety Precautions
Issue 12 (2014-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
3
Personnel Precautions
The device-related installation and maintenance can only be performed by professional
technical engineers or specific installation personnel.

IPC1601&2602&5602&5603
User Guide
2 Overview
Issue 12 (2014-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
4
2 Overview
2.1 Product Overview
Product Appearance
Figure 2-1 shows the appearance of an IP box camera.
Figure 2-1 IP box camera
Device Structure
Figure 2-2 shows the ports on the body of an IP box camera. Table 2-1 describes the ports.
Figure 2-2 Ports on the bodyof an IPbox camera

IPC1601&2602&5602&5603
User Guide
2 Overview
Issue 12 (2014-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5
Table 2-1 Ports on the camera body
No.
Port
Description
1
Lens port
Connects to a lens.
NOTE
A CS-mount lens can be installed on the camera through this
port. To install a C-mount lens, use a C/CS mount adapter.
2
Back focusing knob
Adjusting the back focus.
3
Auto aperture port
N/A
Figure 2-3 shows the rear panel of a box camera. Table 2-2describes the ports.
Figure 2-3 Rearpanel of an IP box camera
Table 2-2 Ports on the real panel
Port
Function
VIDEO OUT
Video output port
Sends analog video signals. You can connect the
camera to a TV monitor through this port to
view analog videos.
DC 12V±10%
Power supply
socket
Connects to a 12 V±10% direct current (DC)
power supply.
RUN
Status indicator
Indicates the running status of the camera. The
status is described as follows:
On: The camera is powered on.
Blinking: The camera is restarting.

IPC1601&2602&5602&5603
User Guide
2 Overview
Issue 12 (2014-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
6
Port
Function
ALM
Alarm indicator
N/A
PWR
Power indicator
Indicates the power status.
SD
Secure digital (SD)
card indicator
Indicates the SD card status. The status is
described as follows:
Off: No SD card is inserted.
On: An SD card is inserted.
COM
Alarm input ports
COM: common alarm input port
IN: alarm input port
IN
COM
Alarm output ports
COM: common alarm output port
OUT: alarm output port
OUT
NIC
Network access
port
Connects to a standard Ethernet cable.
RS485
RS485 port
Connects to an external Pan Tilt Zoom (PTZ).
RESET
FACTORY
Reset button
Restores the camera to the factory settings by
pressing and holding this button for more than
five seconds.
AUDIO OUT
Audio output port
Connects to an external audio device such as a
speaker.
AUDIO IN
Audio input port
Receives analog audio signals from devices such
as a sound pickup device.
SD
SD card slot
Installs an SD card.
NOTE
Before installing an SD card, verify that the SD
card is not in the write protection state.
Before removing an SD card, verify that the SD
card is not in the write protection state. Otherwise,
some data may be lost or the SD card may be
damaged.
Before installing or removing an SD card when the
box camera is running, stop video recording first.
2.2 Features
Network Features
Supports the complete TCP/IP protocol suite. Support video, audio, and alarm data.
Provides a built-in web browser and supports access using Microsoft Internet Explorer.

IPC1601&2602&5602&5603
User Guide
2 Overview
Issue 12 (2014-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
7
Supports network data transmission and remote access.
Supports Point-to-Point Protocol over Ethernet (PPPoE), Dynamic Host Configuration
Protocol (DHCP), and Dynamic Domain Name System (DDNS).
Supports Power over Ethernet (PoE) that complies with the IEEE802.3af standard. The
IP camera can connect to a switch or router supporting the PoE function to implement
PoE.
Supports remote upgrade and maintenance.
Image Processing Features
Supports multiple streams. Encoding parameters for the main stream and sub stream can
be configured separately.
Supports dynamic stream parameters based on different image quality requirements.
Supports independent hardware compression and constant bit rate (CBR). Videos can be
compressed using the Motion Joint Photographic Experts Group (MJPEG) or H.264
standard. The frame rate and image quality can be configured.
I/O Features
Support bidirectional intercom and unidirectional broadcast.
Supports RS-485 serial port control and transparent channel transmission.
Provides a 10/100 Mbit/s self-adaptive Ethernet port.
Other Features
Supports the heartbeat function that allows the management host to learn the running
status of the IP camera in real time.
Supports alarm input and output, motion detection alarms and alarm linkage functions.
Supports level-based user rights management.
Security Features
Adopt SSH protocol instead of FTP, Telnet and other unsecure protocols. When
accessing by web browser, HTTPS protocol is used for the security of data transmission.
Authentication mechanism is set for all the ports including the ports used by web
browser, serial port and SSH, etc.
All passwords in the system can meet the complexity requirement.
The system provides encryption protection for all the passwords.
All the opened ports are necessary for system running. All the unsecure communication
ports are closed. The corresponding introductions of the opened communication ports are
introduced in the manual of product communication matrix.
Software packages and upgrade packages have been scanned by anti-virus softwares
(such as Symantec, Trend officeScan, Mcafee, Avira AntiVir, Kaspersky, etc.), and the
scanning results are provided in the version description document.

IPC1601&2602&5602&5603
User Guide
3 Hardware Installation
Issue 12 (2014-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
8
3 Hardware Installation
3.1 Preparing Installation Tools
Table 3-1 lists installation tools that you must prepare.
Table 3-1 Installation tools
Tool
Description
Phillips screwdriver
Claw hammer
Hammer drill
Level ruler
3.2 Installing a Lens

IPC1601&2602&5602&5603
User Guide
3 Hardware Installation
Issue 12 (2014-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
9
In this manual, the way to use the camera is not recommended for auto focus lens, because
this method used base on RS485 which it is complicated to connect for camera to work. So
there are only two ways installation description in the manual, including auto aperture lens
with manual focus and manual aperture lens with manual focus.
3.2.1 Installing an Auto Aperture and Manual focus Lens
Before installing a lens, remove the front protection cap from the camera first.
Figure 3-1 shows how to install an auto aperture and manual focus lens.
Figure 3-1 Installing an auto aperture and manual focus lens
Step 1 Attach the lens to the camera body and turn the lens clockwise until it locks into place.
Step 2 Insert the cable plug of the lens into the IRIS port on the side of the camera body.
Step 3 After adjust focus, lock the Tele/wide and focus pullers mounted on the lens
----End
3.2.2 Installing a Manual Aperture and Manual focus Lens
Installing a C-Mount Manual Aperture and Manual focus Lens
Before installing a lens, remove the front protection cap from the camera first. Need to use
C/CS adapter ring when connect to the C mount lens.
Step 1 Use the Phillips screwdriver to loosen the screw on the side of the focusing ring.
Turn the focusing ring counterclockwise to extend it for several millimeters and manually
bring the camera into focus.
The camera has been calibrated before delivery. You can also adjust the focusing ring as required to
obtain the required focus.
Step 2 Tighten the screw using the Phillips screwdriver to secure the focusing ring.
Step 3 Install the C/CS mount adapter to the camera.
Step 4 Attach the lens to the camera body and turn the lens clockwise until it locks into place.

IPC1601&2602&5602&5603
User Guide
3 Hardware Installation
Issue 12 (2014-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
10
----End
Installing a CS-Mount Manual Aperture and Manual focus Lens
Before installing a lens, remove the front protection cap from the camera first.
Step 1 Use the Phillips screwdriver to loosen the screw on the side of the focusing ring.Fully turn the
focusing ring counterclockwise and manually bring the camera into focus.
The camera has been calibrated before delivery. You can also adjust the focusing ring as required to
obtain the required focus.
Step 2 Tighten the screw using the Phillips screwdriver to secure the focusing ring.
Step 3 Attach the lens to the camera body and turn the lens clockwise until it locks into place.
----End
3.2.3 Uninstalling a Lens
Step 1 Turn the lens counterclockwise until it is removed.
Step 2 Remove the cable plug of the auto aperture lens from the IRIS port.
If you are removing a manual aperture lens, skip Step 2.
Step 3 If no lens needs to be installed on the camera, mount the front protection cap to protect the
device.
----End
3.3 Connecting Other Devices to the Camera Through the
Ports on the Rear Panel
Figure 3-2 shows how to connect other devices to the camera through the ports on the rear
panel.
