INSTALLATION AND OPERATION MANUAL
for
HDC-2080CS

1
Table of contents
1. Safety Instructions and Notes….......................................................................................................
2. General Descriptions............................................................................……………………………...
3. Supplied Items......................................................................................……………………………...
4. Part names…………………………….…...................................................…………………………...
5. Installation Instructions......................................................................................……………………...
6. Setup Menu ……………............................................................................…………………………...
7. Specifications ………………………………………………..................................................................
8. Dimensional Drawings ……………………………………………............................................................
3
3
4
5
7
9
21
23

2
To prevent fire or shock hazard, do not expose the unit to rain or moisture.
The symbol is intended to alert the user to the presence of important
operating and maintenance(servicing) instructions in the literature
accompanying the unit.
The symbol is intended to alert the user to the presence of
uninsulated "dangerous voltage" within the product's enclosure that
may be of sufficient magnitude to constitute a risk of electric shock
to persons.
Warning(NTSC version) -- This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
Caution -- Any changes or modifications in construction of this device which are not expressly approved by
the party responsible for compliance could void the user's authority to operate the equipment.
Mains power quality should be that of a typical commercial environment. If the user of the model requires
continued operation during power mains interruptions, it is recommended that the model be powered from
an uninterruptible power supply (UPS) or a battery.”
Notice -- The images used in manual are processed to help comprehension and may
differ from actual video of the camera.
WARNING
NEVER USE THIS CAMERA
1. IN AREA WHERE HAS SHOCK OR VIBRATION WHICH RESULTS IN THE
PROBLEM.
Caution
To prevent electric shocks
and risk of fire hazards, do
NOT use other than specific
power source.
WARNING

3
1. Safety Instructions and Notes
•Please read this safety and operating instructions before putting the camera into
operation.
•Keep the manual in a safe place for later reference.
• Pay attention to safety when laying the connection cable and observe that the cable is not
subjected to heavy loads, kinks or damage and no moisture can get in.
• Never open the device such as boards or lens.
The warranty becomes void if repairs are undertaken by unauthorized persons.
• Maintenance and repair have to be carried out only by authorized service centers.
•Use only a mild detergent to clean the housing.
•The camera should never be operated beyond the technical specifications. This can lead
to destruction.
•The camera should never be operated in the water.
2. General Descriptions
FULL HD WDR HD-SDI CAMERA, 1920 x 1080/30p(25p)
Highly detailed pictures can be achieved and color reproducibility deserves attention.
With ICR mechanism,
- Enhances its sensitivity about 10x at night time
- Can accepts the infrared light
With 24VAC/12VDC dual power design,
- Offers the flexibility of installation
- Ensures the reliability
With Intelligent Focus Indicator and FOCUS ADJUST menu,
- Offers easy adjustment of Focus
- Eliminates the mistake of the erratic focus adjustment
Main features are;
•Full HD, 1920 x 1080/30p(25p)
•True Wide Dynamic Range
•Improved Noise figure with the enhanced 3D-NR
•Motion Detect, Privacy Mask, Anti-Fog, Sense-up(x8) , BLC/HLC, Digital Zoom
•Pointing Zoom which enables the flexible zooming at any area.
•Smart Motion Zoom in combining with Pointing Zoom.
•Intelligent Focus Indicator on Screen which helps to get the sharpest focus.
•DUAL Filter Switcher – No Focus Shift at Night.

4
•Day & Night Simulation
•Scale down the image to 720p without loss of field of view
•Top performance at low light sensitivity(Sense-up On)
•LSC(Lens Shade Compensation)
•RS-485(Pelco-D)
•OSD MENU Control
•Easy & Stable Back Focus adjustment.
•CVBS Video output BNC for Easy installation and Maintenance
•Input voltage: 24VAC/12VDC (Dual Power)
•Circuit protection against faulty connection
•Isolated power supply against ground loop problem.
3. Supplied Items
•1x FULL HD Network Camera
•1x Installation and Operating Instructions
•1x Dust protection cap
•1x 3mm Hex L-wrench for Back Focus Adjustment

5
②
①
③
④
⑤
⑥
4. Part Names
4.1 Front view
①Front Body
②
Mount Hole (Top and Bottom)
③
Rear Body
④
Back Focus Adjustment
⑤
Lens connector for auto iris lens
⑥
Dust Protection Cap

6
ⓐ
ⓑ
ⓒ
ⓔ
ⓓ
- Lens Connector for Auto-iris lens (DC Drive)
4.2 Rear side view
5. Installation and commissioning Instructions
•Make sure the power is removed before the installation.
•After all connections are finished properly, follow the order for applying power.
First, connect the low voltage (AC24V or DC12V), then plug the AC adapter to AC outlets to avoid an
improper reset from power jitter and a damage from the surge voltage when no load.
PIN No
DC Iris
1
Damp(-)
2
Damp(+)
3
Drive(+)
4
GND
PIN 4 PIN 2
PIN 3 PIN 1
ⓐOSD menu switches (Up/ Down/ Left/ Right / Enter)
ⓑ
Video Output Connector (BNC)
ⓒ
Power Input Terminal
ⓓ
RS-485 / IR Connector
ⓔ
HD-SDI Output Connector

7
5.1. Attaching the lens
•Remove the Dust Protection cap from the lens mount
•Screw the lens onto the camera firmly.
•Plug the lens plug into the lens connector
5.2. Setting the back focus
The proper back focus adjustment is essential for the motorized zoom lens to get the all time sharp focus
when zooming in and out by the remote control.
For easier and better adjustment, this camera provides FOCUS ADJUST menu which prevents from the
mistake of the focus adjustment.
With enabling FOCUS ADJUST menu, follow the procedure to get the best back focus adjustment.
1. Set the lens for the zoom position to WIDE and the focus position to INFINITE(
∞
)
2. Shoot the object departing from about 10Meters.
3. Adjust
⑤
Back focus Adjustment with 3mm Hex L-wrench until the optimum focus is achieved.
4. Set the lens for zoom position to TELE and adjust the lens focus for best focus.
5. Set the lens for zoom position to WIDE again, check if the focus adjustment was the best.
If not, re-adjust
⑤
Back focus Adjustment slightly.
5.3. Installation
The camera has a 1/4” thread insert on its top and bottom side for mounting the camera to a tripod or the
wall or ceiling with a corresponding mount.

8
5.4 Commissioning
•Connect power supply to the power terminal on the rear panel of camera firstly
•Plug the power adaptor to the mains supply secondly
•Power indicator LED will be lit
•The camera is ready for operation
5.5 Power Supply Connections
Camera can work with either 24VAC or 12VDC, dual voltage power. It does NOT require the polarity-
matched connection for 12VDC supply. Primary and secondary grounds are completely isolated to avoid
the possible ground-loop problems. Its excellently wide operating voltage range of 10.5V-30V for DC and
12-28.8V for AC gives an extra flexibility at the installation.

9
6. Setup Menu
Setup menu can be accessed and controlled by OSD control joy stick at the back of camera.
Five commands are available with the joy stick.
Picture of OSD may differ by the models.
In the menu,
use ▲,▼to move menu, ◀,▶to change the settings and press
☟
to select or enter.
The actual value of FACTORY DEFAULT may differ from this manual due to further technical improvements.
Joy stick
SYMBOL descriptions for joystick operation;
-▲,▼,◀,▶denotes the directions of Joystick
lever operation.
-
☟
denotes the long press down straightly
for about 1.5 seconds.
D-Zoom Adjustment
(Only works when OSD Menu is not operating &
IP is not connected)
▲D-Zoom In
▼D-Zoom Out

10
6.2 MAIN menu
Press ● to enter the setup menu for about 1 second.
MENU V3.01
1. EXPOSURE
2. LENS
3. FOCUS ADJ.
4. SCENE ENHANCE
5. 3D-NR
6. DAY/NIGHT
7. PICT ADJUST
8. SPECIAL
9. SYSTEM
A. EXIT
↵
DC
↵
↵
NORMAL
MID
AUTO
↵
↵
↵
↵
SAVE&EXIT
MAIN Default Descriptions
EXPOSURE Sets EXPOSURE MODE, BRIGHTNESS, SENS-UP and AGC.
See ‘6.3 EXPOSURE’ for detail.
LENS DC Sets Lens type and See ‘6.4 LENS’ for detail.
FOCUS ADJ See ‘6.5 ZOOM/FOCUS’ for detail.
SCENE
ENHANCE NORMAL
NORMAL – Optimized for the normal indoor and outdoor in the good
lighting condition.
WDR – Improves the visibility for the high bright area and the dark area
by the double captures of image with LONG and SHORT exposures.
With WDR ON, the frame rate becomes half by the double captures.
WDR level can be selected from LOW, MID and HIGH.
Care should be taken to select this mode because video may lose its
quality in some environments by the over compensation.
D-WDR – Improves the visibility by compensating the video gain for the
dark area. Noise can increase in the dark area accordingly.
BLC – Improves the visibility for the dark object by the bright back light.
Outside area of BLC window can over saturate.
BLC has a target window for compensation and its size and position
can be set by H-POS, V-POS, H-SIZE and V-SIZE.
HLC – Cuts out the highlight area with black mask and excludes it from
compensation. Lower HLC LEVEL cut out video from the lower level.
3D-NR MID
Enables to set OFF, LOW, MID and HIGH.
3D-NR is a very sophisticated and powerful time-based noise reduction
technology by monitoring the noise for the several video frames and defining
and eliminating them consecutively at low light.
Higher setting reduces noise much more but results in losing the sharpness
and the tail effect or the motion blur for the fast moving target at low light.

11
DAY/NIGHT
EXT
for
IR LED
AUTO
for
No IR
LED
Sets DAY / NIGHT to EXT, AUTO, COLOR and B/W.
SMART IR can be set to reduce the saturation by the strong IR illumination
in the night in any menu of EXT, AUTO and B/W(NIGHT)
Setting SMART IR in any menu is identically applied to other menu.
Zero(0) turns off SMART IR and High setting avoids the saturation strongly
but the corners will be darker accordingly.
EXT – DAY or NIGHT is determined by the built-in light photo sensor.
Camera with IR LED must be set to EXT.
AUTO – Used when DAY or NIGHT is determined by light level through
the lens and DAY from/to NIGHT is switched automatically by the
scene brightness.
D<-->N THRESHOLD, D<->N GAP, D<->N DELY and SMART IR can be
set in the menu.(See ‘6.7.2 DAY/NIGHT AUTO’ for detail.)
When EXPOSURE>AGC is less than 10, DAY/NIGHT AUTO is disabled
and forcibly switches to ___(DAY) to avoid the malfunction.
EXT, B/W(NIGHT) and COLOR(DAY) is independent on AGC level.
B/W(NIGHT) – Forcibly removes IR cut filter and switches to B/W
regardless of light level.
COLOR(DAY) – Forcibly DAY/NIGHT is disabled and outputs color video.
PICT ADJUST Sets WHITE BAL, SHARPNESS, COLOR GAIN, GAMMA, SHADING.
See ‘6.8 PICT ADJUST’ for detail.
SPECIAL
Sets MIRROR/FLIP, PRIVACY, MOTION, MOTION ZOOM, PIXEL DEFECT,
TITLE SET, DISPLAY, DEFOG, POINTING ZOOM
TV SYSTEM. See ‘6.8 SPECIAL’ for detail.
SYSTEM Sets TV SYSTEM, RESOLUTION, COMM.SETUP, LANGUAGE and
FACTORY DEFAULT.
EXIT SAVE & EXIT – Exits the menu after saving the parameters.
EXIT – Exits the menu without saving the menu.

12
6.3 EXPOSURE
EXPOSURE
SHUTTER
BRIGHTNESS
SENS-UP
AGC
RETURN
AUTO
|:::::::|::::::| 10
OFF
|::::::::|:::::| 12
RET
↵
2x
EXPOSURE Default Descriptions
SHUTTER AUTO
Can set EXPOSURE MODE to AUTO, MANUAL and Flickerless.
AUTO – Optimizes the video level by controlling the iris and the shutter speed
automatically.
MANUAL – Iris and Shutter can be set to fix.
Flickerless – Reduces the flicker in video when US(60Hz)/EU(50Hz)
mode is used in 50Hz/60Hz fluorescent lighting respectively.
MANUAL and Flickerless modes disable SENS-UP and MOTION BLUR
functions.
BRIGHTNESS 10 Adjusts the brightness of video(0~20).
SENS-UP AUTO
The brighter video can be obtained by increasing the exposure time in the
night with SENS-UP.
SENS-UP is the maximum integrations of frame by DSS(Digital Slow Shutter)
in the low light.
AUTO – SENS-UP(x2~x8) is enabled or disabled automatically by the scene
brightness. Higher SENS-UP can get the brighter video but the
slower frame rates with motion blur and more white pixels.
OFF – Disables SENS-UP.
AGC 12
AGC(0~20) amplifies the video gain for brighter video but noise and white
pixel accordingly.
AGC level less than 10 disables AUTO in DAY/NIGHT.

13
6.4 LENS
DC
MODE
RETURN
OUTDOOR
RET
↵
MANUAL
MODE
RETURN
DEBLUR
RET
↵
Lens Default Descriptions
DC
or
MANUAL
OURDOOR
for
IR LED type
DEBLUR
for
No IR
LED type
Lens can be selected either DC or MANUAL lens.
Lens MUST be set to DC for the best image when DC iris lens is installed.
DC or MANUAL- OUTDOOR, INDOOR, DEBLUR
Select lens mode according to installation place.
Select INDOOR or DEBLUR for indoor installation according to
environment.
DEBLUR enables to reduce the blur in a certain indoor environment.
Noise or color rolling can increase.
Horizontal wave or bar may be seen when MANUAL is selected and the
camera is working under florescent or similar lights.

14
6.5 FOCUS ADJ.
FOCUS ADJ.
DN DWELL
POP ON FOCUS
RETURN
5s
OFF
RET
↵
FOCUS ADJ. Default Descriptions
DN DWELL 5s
ICR switcher switches DAY & NIGHT at the interval of D/N DWELL
to help the EXACT NIDDLE focus at DAY and NIGHT mode.
Further simulations are performed internally during switching.
POP ON FOCUS OFF ON zooms in the center of picture at 2X for better focusing.
FOCUSING
STATUS ON
Shows how exactly focus is set.
When blue bar doesn’t show up, try the lens focus to NEAR and FAR.
The maximum blue bar indicates the best focusing position.
FOCUSING STATUS
Usually cameras are installed in the day time and
they often become OUT OF FOCUS at night time
and IN FOCUS again at next day time.
This problem can occur at any cameras regardless
of types or manufacturers.
FOCUS ADJ. menu is the unique and patented
feature that prevents from the wrong focus and
helps the EXACT NEEDLE focus by simulating
DAY & NIGHT conditions.
Set zoom first and adjust focus to get NEEDLE
FOCUS while switching AT DAY AND NIGHT

15
6.7 PICT ADJUST
WHITE BAL
SHARPNESS
COLOR GAIN
GAMMA
SHADING
RETURN
ATW
|:::::::|::::::| 10
|:::::::|::::::| 10
0.50
OFF
RET
↵
PICTURE Default Descriptions
WHITE BAL ATW
ATW, ATWext, ONE PUSH and MANUAL are available for the white balance
modes.
ATW – White balance is continuously working along with the color
temperature changes in the range of 2,000K~8,500K.
ATWext – White balance is continuously working along with the color
temperature changes in the range of 1,800K~11,000K.
ONE PUSH- White balance works only during ● is pressed.
MANUAL – White balance is fixed to the settings by R_GAIN and
B-GAIN. This mode can be used only when the color temperature
does not vary.
SHARPNESS 10 Adjusts the sharpness of video(0~20).
COLOR GAIN 10 Adjusts the color level of video(0~20).
GAMMA 0.50 Adjusts the gamma of video.
SHADING OFF ON enables to compensate the shade caused by wide lens setting

16
6.8 SPECIAL
MIRROR/FLIP
PRIVACY
MOTION
PIXEL DEFECT
TITLE SET
DISPLAY
DEFOG
POINTING ZOOM
RETURN
OFF
OFF
OFF
OFF
↵
↵
OFF
OFF
RET
↵
SPECIAL Default Descriptions
MIRROR/FLIP OFF
Reverses the video left and right and/or up and down by MIRROR/FLIP.
OFF - Normal display without mirroring or flipping
Hor. – Video is reversed left and right.
Ver. – Video is reversed upside down.
HV – Video is reversed left and right and upside down.
When the video is reversed by Ver. or HV, then the joystick directions are
reversed accordingly. This feature is very useful when a camera in installed in
upside dawn.
PRIVACY OFF
10 Privacy zones which can be enabled individually by ZON DISP are available
to mask the video.
ZONE NUMBER – Set a number to select a privacy zone from 1~10.
ZONE DISP – ON enables a relevant privacy zone.
H-POS, V-POS, H-SIZE and V-SIZE – Adjust the size and position of zone.
COLOR – Select the color used for masking the zone form eight colors(1~8).
TRANSPARENCY – Enables to set OFF, 50%, 75%, 100%.
Defines the transparency for the mask zone.
MOTION OFF
MOTION can detect the changes in the motion window and displays the results
in blocks and/or a text message.
SENSITIVITY – Adjusts the detection sensitivity for motion.
High value increases the sensitivity to detect the small motion easily.
Too low sensitivity will cause the erratic detection by the tree leaves
or the light level changes.
H-POS,V-POS, H-SIZE and V-SIZE - Adjust the size and position of
the detection window.
BLOCK DISP – ON enables to display the blocks for the detected area.
MOTION OSD – ON enables to display a text message, ‘MOTION’,
SMART MOTION ZOOM – ON activates Automatic Zoom IN/OUT when motion
is detected.
Area to be zoomed in by SMART MOTION ZOOM can be set at SPECIAL>
MOTION> SMART MOTION ZOOM.
Adjusting◀,▶(Joystick) varies the viewing angle to be zoomed when the
motion occurs. See ‘6.8.1 SMART MOTION ZOOM’ for detail.
STAY ZOOMING – Sets the duration time for zooming by Motion.

17
PIXEL DEFECT OFF
Detects and compensates the white pixels which becomes defective.
Once CALIBRATE is selected, the pixel calibration is initiated with lens closed
and can’t cancel.
THRESHOLD – Defines the level of detection and low value detects more
pixels. Be sure to set the value so that the pixels are uniformly blinking
over the entire screen. Too low value will get the bad results because
too many pixels are detected as the bad pixels and the maximum
number of pixels for compensation will be filled by the upper area.
EXECUTE
☟
- Long pressing will execute the pixel calibration for the
detected pixels. Menu will exit automatically after compensation.
TITLE SET -
Camera title(name) can be set and edited up to 15 alpha numeric and symbolic
characters from ASCII codes(ENGLISH only).
▲,▼,◀,▶moves the cursor to choose a character and
● selects it.
The selected characters are added and displayed on the top left
Corner and the cursor moves right automatically for next input.
SP - Space is inserted when pressed ●.
BS – Cursor moves back when pressed ●.
CLR – Clears all the characters on input line when pressed ●.
POS – To be able to set the title position by ▲,▼,◀,▶and ●.
DISPLAY -
Enables or disables to display the OSD.
ID – ON enables to display the camera ID defined by SYSTEM>COMM.
SETUP>CAM ID.
TITLE – ON enables to display the camera title(name) set by SPECIAL>
TITLE SET.
D-ZOOM RATIO – ON enables to display the zoom ratio on the bottom right
corner. DZx.x will display by multiplying the actual digital zoom ratio.
DEFOG OFF
AUTO – Enhance the foggy video automatically according to
status of scene
MANUAL – Sets to enhance the foggy video manually regardless of
status of scene
LEVEL – LOW, MID, HIGH
Video quality can be less in normal environments.
POINTING
ZOOM OFF
ON enables to set off-centered location to be the center of zoom
H-POINTER, V-POINTER- Able to set the location of zoom center
D-Zoom is available DZ X1.0~ X8.0.
See ‘6.8.2 POINTING ZOOM’ for detail.

18
6.8.1 SMART MOTION ZOOM
SMART MOTION ZOOM crops and enlarges the certain area defined by a yellow window to the full sized
image when the motion is detected in the black window.
SMART MOTION ZOOM window can be re-sized by adjusting D-ZOOM RATIO and moved by H-POINTER
and V-POINTER.
UNLIKE the conventional zoom which can zoom in/out the center area of image only, by the flexible zoom
location and area, SMART MOTION ZOOM differentiate its usefulness from others.
That is, a conventional camera installed on the corner of ceiling can zoom the center of the floor in a room
and result in losing the image of door on the side wall.
However, SMART MOTION ZOOM can be set to see the door side and zoom in that area without missing
the IMPORTANT security point.
SMART
MOTION ZOOM Default Descriptions
H-POINTER 10 Moves MOTION ZOOM area(Yellow window) horizontally.
V-POINTER 10 Moves MOTION ZOOM area(Yellow window) vertically.
D-ZOOM
RATIO MZ2.0 Sets the area size to be zoomed when the motion occurs in the black window.
SMART MOTION ZOOM
H-POINTER
V-POINTER
D-ZOOM RATIO
RETURN
10
10
MZ2.0
RET
↵

19
6.8.2 POINTING ZOOM
This camera has a very useful and powerful feature, POINTING ZOOM, which can zoom in/out any area.
UNLIKE the conventional zoom which can zoom in/out the center area of image only, by the flexible zoom
location and area, POINTING ZOOM differentiate its usefulness from others.
That is, a conventional camera installed on the corner of ceiling can zoom the center of the floor in a room
and result in losing the image of door on the side wall.
However, POINTING ZOOM can be set to see the door side and zoom in that area without missing
the IMPORTANT security point.
POINTING ZOOM can be activated by the joystick operations of ▲for zoom in and▼for zoom out,
while SMART MOTION ZOOM is activated by the result of motion detection in the defined area.
POINTING
ZOOM Default Descriptions
H-POINTER 10 Sets the horizontal location of area to be zoomed by POINTING ZOOM.
V-POINTER 10 Sets the vertical location of area to be zoomed by POINTING ZOOM.
POINTING ZOOM
H-POINTER
V-POINTER
RETURN
10
10
RET
↵
