Huawei V600R019C00 Technical specifications

HUAWEI Board
V600R019C00
Product Description
Issue
02
Date
2018
-10-22
HUAWEI TECHNOLOGIES CO., LTD.

Issue 02 (2018-10-22)
Copyright © Huawei Technologies Co., Ltd.
i
Copyright © Huawei Technologies Co., Ltd. 2018. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior
written consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei and
the customer. All or part of the products, services and features described in this document may not be
within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements,
information, and recommendations in this document are provided "AS IS" without warranties, guarantees or
representations of any kind, either express or implied.
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website: http://e.huawei.com

HUAWEI Board
Product Description
About This Document
Issue 02 (2018-10-22)
Copyright © Huawei Technologies Co., Ltd.
ii
About This Document
Purpose
This document describes the positioning, highlights, networking schemes, structure, features
and functions, security and reliability, operations, administration, and maintenance (OAM),
and technical specifications of HUAWEI Board (abbreviated as "the Board" or "the endpoint"
in this document).
Intended Audience
This document is intended for:
Enterprise customers
Agents
Huawei sales engineers
Huawei technical support engineers
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol Description
Indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
Indicates a potentially hazardous situation which, if not
avoided, could result in equipment damage, data loss,
performance deterioration, or unanticipated results.
NOTICE is used to address practices not related to
personal injury.
Calls attention to important information, best practices
and tips.

HUAWEI Board
Product Description
About This Document
Issue 02 (2018-10-22)
Copyright © Huawei Technologies Co., Ltd.
iii
Symbol Description
NOTE is used to address information not related to
personal injury, equipment damage, and environment
deterioration.
Change History
Changes between document issues are cumulative. The latest document issue contains all the
changes made in earlier issues.
Issue 02 (2018-10-22)
This issue is the second official release.
Modified 5.2 Intelligent Voice Assistant.
Modfied 7.1.1 Touchscreen.
Modfied 7.1.2 Touch.
Modfied 7.2.4 Upgrade.
Issue 01 (2018-08-31)
This issue is the first official release.

HUAWEI Board
Product Description
Contents
Issue 02 (2018-10-22)
Copyright © Huawei Technologies Co., Ltd.
iv
Contents
About This Document.................................................................................................................... ii
1 Product Positioning ......................................................................................................................1
2 Product Highlights........................................................................................................................2
3 Networking Schemes ...................................................................................................................3
3.1 On-Premises/IMS Hosted/SP Hosted Networking Scheme .......................................................................................... 3
3.2 eSight-based Networking Scheme ................................................................................................................................ 4
4 Product Structure...........................................................................................................................5
4.1 Appearance ................................................................................................................................................................... 5
4.2 Front Panel and Rear Panel........................................................................................................................................... 5
4.3 Indicator........................................................................................................................................................................ 8
4.4 HUAWEI Touch............................................................................................................................................................ 9
4.5 Microphone Array....................................................................................................................................................... 10
5 Functions and Features ..............................................................................................................11
5.1 Connections and Convergence.................................................................................................................................... 11
5.1.1 Connecting to the Huawei Cloud Video Conferencing Service............................................................................... 11
5.1.2 Hardware-Software Synergy.................................................................................................................................... 11
5.2 Intelligent Voice Assistant........................................................................................................................................... 12
5.3 Joining or Initiating a Meeting.................................................................................................................................... 13
5.4 H.265 4K Ultra-HD Video.......................................................................................................................................... 13
5.5 Collaboration with Data Conferencing ....................................................................................................................... 14
5.6 Split-Screen Display ................................................................................................................................................... 16
5.7 Interoperability Between Data Collaboration and Content Sharing............................................................................ 17
5.8 Controlling Meetings .................................................................................................................................................. 17
5.9 Network Address Book............................................................................................................................................... 20
5.10 Globalization............................................................................................................................................................. 20
5.11 High-Quality Audio and Video ................................................................................................................................. 21
5.11.1 Intelligent Navigation ............................................................................................................................................ 21
5.11.2 Hi-Fi Audio ............................................................................................................................................................ 21
5.11.3 Multiple Layouts.................................................................................................................................................... 21
5.11.4 Network Adaptability............................................................................................................................................. 21
5.12 Wireless Connections................................................................................................................................................ 22

HUAWEI Board
Product Description
Contents
Issue 02 (2018-10-22)
Copyright © Huawei Technologies Co., Ltd.
v
5.13 Content Sharing ........................................................................................................................................................ 22
5.14 OAM......................................................................................................................................................................... 23
5.14.1 Quick Setup ........................................................................................................................................................... 23
5.14.2 Connection to eSight.............................................................................................................................................. 23
5.15 Remote Video Monitoring ........................................................................................................................................ 24
5.16 APIs for Third-Party Integration ............................................................................................................................... 24
6 Security and Reliability .............................................................................................................26
6.1 Operating System Security ......................................................................................................................................... 26
6.2 Network Layer Security.............................................................................................................................................. 26
6.3 Firewall Technology (NAT)........................................................................................................................................ 26
6.4 Traversal Between Public and Private Networks ........................................................................................................ 27
6.5 Email Security ............................................................................................................................................................ 27
6.6 Web Request Authentication....................................................................................................................................... 27
6.7 Protocol Anti-Attack Measures................................................................................................................................... 27
6.8 Protection of Sensitive Data ....................................................................................................................................... 28
6.9 Protection of AI Voice Commands.............................................................................................................................. 28
6.10 System Management and Maintenance Security ...................................................................................................... 28
6.11 Security Design......................................................................................................................................................... 28
6.12 Disaster Recovery..................................................................................................................................................... 29
7 Operations and Maintenance....................................................................................................30
7.1 UIs .............................................................................................................................................................................. 30
7.1.1 Touchscreen ............................................................................................................................................................. 30
7.1.2 Touch ....................................................................................................................................................................... 31
7.1.3 AirPresence Mobile/PC Client................................................................................................................................. 32
7.1.4 Web Interface........................................................................................................................................................... 34
7.2 Maintenance and Upgrade .......................................................................................................................................... 35
7.2.1 Log Management ..................................................................................................................................................... 35
7.2.2 System Diagnostics.................................................................................................................................................. 35
7.2.3 Inspection................................................................................................................................................................. 36
7.2.4 Upgrade ................................................................................................................................................................... 37
7.3 CHR Data Collection.................................................................................................................................................. 37
8 Technical Specifications ............................................................................................................38
8.1 Physical Specifications ............................................................................................................................................... 38
8.2 Performance Specifications ........................................................................................................................................ 40
8.3 Ports and Protocols ..................................................................................................................................................... 42
8.4 Standards Compliance ................................................................................................................................................ 43
A Glossary .......................................................................................................................................45

HUAWEI Board
Product Description
1 Product Positioning
Issue 02 (2018-10-22)
Copyright © Huawei Technologies Co., Ltd.
1
1 Product Positioning
The Board is Huawei's next-generation ultra-HD video conferencing endpoint that facilitates
collaboration through integrated whiteboarding, content sharing, and audio and video
functions. The Board supports collaborative sharing of local and remote whiteboards, allows
content sharing and reverse control over the content source from the Board, and features a
built-in intelligent camera for close-up of focus areas and speakers. These functions can be
accessed through the Board's touchscreen or voice commands recognized by its AI voice
assistant. In summary, the Board is an ideal solution for a collaborative office.
The Board can be deployed in meeting rooms smaller than 30 m2that accommodate 10 people,
such as, small- and medium-sized meeting rooms, open office areas, and senior executives'
offices.
The Board has two models Board-65A (capacitive touchscreen) and Board-65 (infrared
touchscreen). In this document, "the Board" alone refers to both models unless otherwise
specified.

HUAWEI Board
Product Description
2 Product Highlights
Issue 02 (2018-10-22)
Copyright © Huawei Technologies Co., Ltd.
2
2 Product Highlights
This chapter describes the highlights of the Board.
All-in-One Device for All Conference Types
All-in-one built-in 65-inch touchscreen, 5K ultra-HD camera, microphone array, codec,
speakers, and pens, for easier collaboration in meeting rooms
65-inch touchscreen, satisfying requirements for presentations, local discussions, and
remote interaction and collaboration in small- and medium-sized meeting rooms and
spaces
Built-in microphone array, picking up sounds within six meters
Quick wireless content sharing using the AirPresence or AirPresence Key
Powerful AI Engine
Intelligent voice conference assistant: allows users to manage meetings through voice
interaction, including setting up a meeting, joining a meeting, calling a site, viewing a
site, and sharing content
Intelligent speaker tracking: detects active speakers in real time and automatically
provides close-up images of the speakers
Core Audio and Video Capabilities for Optimal Collaboration in Meetings
New H.265 core codec capability: provides 1080p 30 fps video and 4K 3 fps data for
clearer content display
New beam sound pickup technology: uses the built-in microphone array to pick up
sounds, presenting speakers' voices using an intelligent algorithm
Huawei's next-generation Video Motion Enhancement (VME) technology: guarantees
clear images even if the bandwidth is low
Simple and User-Friendly UI
Lightweight interactive UI: displays core functions directly on the UI with others
displayed under lower-level menus
Hardware buttons for key functions, ensuring convenient operations
Pens: automatically displays a whiteboard when a user takes a pen from its dock
Split-screen mode: displays content sources in two windows and supports simultaneous
operations and annotations

HUAWEI Board
Product Description
3 Networking Schemes
Issue 02 (2018-10-22)
Copyright © Huawei Technologies Co., Ltd.
3
3 Networking Schemes
3.1 On-Premises/IMS Hosted/SP Hosted Networking
Scheme
The Board connects to on-premises, IMS hosted, or SP hosted CloudEC networks, enabling
video communication for enterprises and carriers.
Figure 3-1 Networking scheme
In this networking scheme:
The Board connects to an on-premises network through the H.323 or SIP protocol, or
connects to an IMS hosted or SP hosted network through the SIP protocol.
Audio and video calling, content sharing, and data collaboration can be implemented
between the Board and various types of terminals and conference clients.
To learn more, visit http://support.huawei.com/enterprise/en/index.html or
http://support.huawei.com/carrier/en/hwe/index.html and search for the solution's
product documentation name (for example, CloudEC V600R019C00 Product
Documentation).

HUAWEI Board
Product Description
3 Networking Schemes
Issue 02 (2018-10-22)
Copyright © Huawei Technologies Co., Ltd.
4
3.2 eSight-based Networking Scheme
Technical Report 069 (TR-069) is a standard device management protocol developed from the
CPE WAN Management Protocol (CWMP) published by the Broadband Forum. Through the
TR-069 protocol, eSight can remotely manage the connected Board.
Figure 3-2 shows a Board connecting to eSight.
Figure 3-2 Connecting to eSight
In this networking scheme:
eSight integrates the profile server and Simple Traversal of UDP through NAT (STUN)
server.
The profile server enables the Board to upload and download configuration files and
upgrade software packages through HTTPS.
The STUN server is used for traversal between public and private networks to ensure
that eSight manages all devices on both networks.
The Board can report session Call History Record (CHR) and media CHR data files to
eSight.

HUAWEI Board
Product Description
4 Product Structure
Issue 02 (2018-10-22)
Copyright © Huawei Technologies Co., Ltd.
5
4 Product Structure
4.1 Appearance
The Board features a 6-in-1 design that integrates the codec, intelligent tracking camera,
microphone, speaker, touchscreen, and pen.
As shown in Figure 4-1, the Board comes in two models: Board-65A and Board-65. The
Board-65A has a capacitive touchscreen and the Board-65 has an infrared touchscreen.
Figure 4-1 Appearance of the Board
4.2 Front Panel and Rear Panel
Front Panel
Figure 4-2 shows the components on the Board's front panel and lower-right side panel, and
Table 4-1 describes the functions of each component.

HUAWEI Board
Product Description
4 Product Structure
Issue 02 (2018-10-22)
Copyright © Huawei Technologies Co., Ltd.
6
Figure 4-2 Components on the Board's front panel and lower-right side panel
Table 4-1 Function description
No. Component Function
Front Panel
1 Built-in camera 3x digital zoom and ultra-wide angle
Image capture for local participants with voice tracking
and face detection
2 Microphones Local sound pickup within a 180-degree pattern at a
maximum distance of 6 meters
Located on the left and right sides of the camera
3 Touchscreen 65-inch Liquid Crystal Display (LCD) with a resolution
of up to 4K 60 fps
Capacitive or infrared touchscreen with multi-touch
supported
4 Pens Used for whiteboard writing and drawing
Two pens, placed on two docks under the touchscreen
When you take a pen from its dock for the first time, the
touchscreen automatically displays a whiteboard. After
you put the pen back to its dock, you must wait for at
least 10s before using it again.
5 Speakers Audio output with a maximum distance of 6 meters
Located on the left and right sides of the Home button
6 Home button Tap the Home button to return to the home screen.
Components on the lower-right side panel
1 Mute button Mutes or unmutes the microphone.
2 Volume Up/Down
button
Increases or decreases the speaker volume.
3
Soft power button

Press and hold the button to put the Board in sleep

HUAWEI Board
Product Description
4 Product Structure
Issue 02 (2018-10-22)
Copyright © Huawei Technologies Co., Ltd.
7
No. Component Function
and indicator
mode, restart it, or shut it down.
Press the button to put the Board in sleep mode or wake
it up.
The indicator, located at the center of the button, shows
whether the Board is running, sleeping, faulty, or
upgrading.
4 USB Type-A port Connects to a USB device, such as a USB flash drive or a
wireless keyboard.
Rear Panel
Figure 4-3 shows the components on the Board's rear panel, and Table 4-2 describes the
functions of each component.
Figure 4-3 Components on the Board's rear panel
Table 4-2 Function description
No. Component Function
1 Power switch Powers the Board on or off.
NOTICE
Connect all necessary cables before powering on the
Board.
2 Power input port (100-240
V AC, 50/60 Hz, 4.5 A)
Connects to a power supply.
3 Ground stud Connects to a ground cable.
4 RESET button During startup, press and hold this button for 10s
to restore the A/B system.
When the Board is running, press and hold this
button for 10s to reset it to factory settings.
5 LAN port Ethernet port, which supports 10/100/1000 Mbit/s
full duplex and half duplex
6 Touch port Connects to the Touch and supplies power to it.
7 COM port (dual-mode
serial communication port)
Connects to a camera control cable and can be used
for diagnostics and maintenance.
A camera connected to the Board can be upgraded
through this port or the HD-VI port.

HUAWEI Board
Product Description
4 Product Structure
Issue 02 (2018-10-22)
Copyright © Huawei Technologies Co., Ltd.
8
No. Component Function
8 USB Type-B port Connects to a computer and controls it during
content sharing.
9 USB Type-A port Connects to a USB device, such as a USB flash
drive or a wireless keyboard.
10 HDMI port (HD video
output port)
Connects to another screen to display the whiteboard
content or local site image at a resolution of up to
4K x 2K 60 fps.
11 HDMI port (HD video
input port)
Connects to a local computer or an external camera
as the third video input at a resolution of up to 4K x
2K 30 fps. This is the default port used for input of
shared content.
12 VGA port Connects to a content source, such as a local
computer, as the second input at a resolution of up to
1080p 60 fps.
13 HD-VI port Connects to a HUAWEI VPC620/VPC600/VPC800
HD camera or HUAWEI VPT300 intelligent camera
as the first input, at a resolution of up to 4K x 2K 30
fps. This port supports video input, power supply,
and infrared control and also functions as a serial
port.
A camera connected to the Board can be upgraded
through this port or the COM port.
14 HD-AI port (audio input
port)
Connects to a microphone array, such as the
HUAWEI VPM220. Only one VPM220 can be
connected.
15 3.5 mm audio input port Connects to an audio input source such as a
computer.
16 3.5 mm audio output port Connects to a headset or speaker for audio output.
4.3 Indicator
By checking the status of the indicator on a Board, you can determine its operating status and
ensure that it is working properly with other videoconferencing devices.
Table 4-3 shows the Board status corresponding to each indicator status.
Table 4-3 Indicator statuses and corresponding Board statuses
Indicator Status Board Status
Off Powered off
Blinking green twice per second Powering on

HUAWEI Board
Product Description
4 Product Structure
Issue 02 (2018-10-22)
Copyright © Huawei Technologies Co., Ltd.
9
Indicator Status Board Status
Blinking green four times per second Upgrading
Steadily lit (green) Working properly
Blinking green (on for 1s, off for 2s, fading
in and out)
On standby
Blinking red once every 5s Faulty hardware
Blinking red four times per second Faulty software
Blinking red once every 2.5s Overheated
Blinking red once per second Faulty touchscreen
4.4 HUAWEI Touch
The Touch is an optional component for the Board. Featuring an all-new UI, the Touch runs
the Huawei Telepresence system. The calling and conference control functions are easy to use
and can be accessed with just a tap.
Figure 4-4 shows the appearance of the Touch and its rear components. Table 4-4 describes
the function of each component.
Figure 4-4 Front and rear appearance of the Touch
Table 4-4 Functions of the Touch's power button and rear components
No. Component Function
1 Power button Press to lock or wake up the screen.
Press and hold to turn the Touch on or off.
2 USB Type-C
port
Connects to the power adapter that comes with the Touch to
power the Touch.
3 PoE port Connects to the Touch port on a Board.
Connects to the PoE or common network port on a switch.

Connects to the PoE port on a Board or a switch to power

HUAWEI Board
Product Description
4 Product Structure
Issue 02 (2018-10-22)
Copyright © Huawei Technologies Co., Ltd.
10
No. Component Function
the Touch.
4 Kensington
lock hole
Connects to a Kensington lock (not included with the Touch) to
secure the Touch.
4.5 Microphone Array
The Board can connect to the HUAWEI VPM220 microphone array shown in Figure 4-5. The
VPM220 provides dual-channel wideband audio, delivering a superior audio experience.
Figure 4-5 VPM220
High-quality audio
The VPM220 supports a sampling rate of up to 48 kHz and a full frequency range. It is
able to sample sound at rates lower than 22 kHz, which means that it can completely
pick up any sound recognized by human ears. The VPM220 significantly reduces signal
loss caused by analog transmission cables, while offering a hi-fi stereo experience. These
capabilities are made possible through the integrated digital signal processing and
transmission technology and the Acoustic Echo Cancellation (AEC), Automatic Gain
Control (AGC), and Automatic Noise Suppression (ANS) functions.
Superior sound experience
Embedded with three heart-shaped microphones, a single VPM220 supports 360-degree
sound pickup with an optimal range of six meters. This allows participants at the local
site to hear every sound nuance coming from participants at the remote site.
Power saving
Highly energy-efficient, the VPM220 requires no more than 2.5 W of power when
running.

HUAWEI Board
Product Description
5 Functions and Features
Issue 02 (2018-10-22)
Copyright © Huawei Technologies Co., Ltd.
11
5 Functions and Features
5.1 Connections and Convergence
5.1.1 Connecting to the Huawei Cloud Video Conferencing
Service
To connect a Board to the Huawei cloud video conferencing service, configure the Board on
the uPortal. The uPortal will then generate an activation code and send the code by SMS or
email. After the Board is powered on for the first time, you can activate and access the
Huawei cloud video conferencing service by entering the activation code on the touchscreen
or on the Touch.
5.1.2 Hardware-Software Synergy
The Board works with the AirPresence client (software) or AirPresence Key (hardware) that
allows you to collaborate with your teams via content sharing any time, anywhere.
About the AirPresence client and AirPresence Key:
The AirPresence client is a wireless content sharing client that works with the Board and
can run on a mobile device or PC.
−AirPresence mobile client: runs on an Android or iOS mobile device. To download
this client, you can scan the QR code on the touchscreen or Touch.
−AirPresence PC client: runs on a Windows or Mac PC. You can download this client
from the Board web interface.
The AirPresence Key is a wireless content sharing device.
Hardware-software synergy functions as follows:
You can pair an AirPresence client with a Board using the following methods:
−Entering the projection code on the client (for the AirPresence mobile or PC client)
−Scanning the QR code on the touchscreen or Touch (for the AirPresence mobile
client only)
No pairing from the AirPresence client is allowed when DND is enabled for the Board.
After the pairing succeeds, you can initiate calls and join meetings through the
AirPresence mobile client, touchscreen, or Touch.

HUAWEI Board
Product Description
5 Functions and Features
Issue 02 (2018-10-22)
Copyright © Huawei Technologies Co., Ltd.
12
Using the AirPresence mobile client, you can initiate calls, join meetings, and control the
Board. Board control operations include adjusting the speaker volume, turning on or off
the microphone, and adjusting the camera angle.
Use the AirPresence mobile or PC client or AirPresence Key for content sharing.
5.2 Intelligent Voice Assistant
You can say "Hi, Scotty" or "Hey, Scotty" to the Board or its connected microphone to wake
up "Scotty", the intelligent voice assistant, and then operate the Board using voice commands.
You can determine whether to enable the intelligent voice assistant function on the Board. By default,
this function is disabled.
After the intelligent voice assistant wakes up, you will see the screen shown in Figure 5-1.
Figure 5-1 Intelligent voice assistant wakes up
You can then perform the following operations using voice commands:
Initiating or canceling a call
Creating a meeting
Joining a scheduled meeting
Extending a meeting
Adding participants to a meeting
Viewing participants or continuous presence
Sharing or stopping content sharing over a cable
Adjusting the speaker volume at your site
Muting or unmuting the microphones of other sites

HUAWEI Board
Product Description
5 Functions and Features
Issue 02 (2018-10-22)
Copyright © Huawei Technologies Co., Ltd.
13
Starting device diagnostics
5.3 Joining or Initiating a Meeting
Joining a Meeting
You can join a meeting from the Next Meeting popup box or by entering the meeting ID.
Initiating a Meeting
A meeting can be arranged using any of the following methods:
Creating a meeting: Create a meeting and invite participants to the meeting.
Alternatively, send the meeting ID to participants. They can then dial the meeting ID to
join the meeting.
Starting a multipoint meeting: On the touchscreen or Touch, select multiple contacts to
start a meeting. Set the meeting parameters, such as the chair password and whether to
encrypt the meeting.
Starting a point-to-point (P2P) meeting: On the touchscreen or Touch, you can search
for a participant by keyword and initiate a call, call a participant by entering its number
or IP address, or directly select a participant to make a call.
5.4 H.265 4K Ultra-HD Video
4K provides excellent clarity and lifelike detail, with a resolution four times that of 1080p, on
a larger screen. The Board supports H.265-based encoding and decoding for both video and
content, and can deliver 4K ultra-HD video through Huawei's VME technology.

HUAWEI Board
Product Description
5 Functions and Features
Issue 02 (2018-10-22)
Copyright © Huawei Technologies Co., Ltd.
14
Figure 5-2 H.265 4K ultra-HD video
5.5 Collaboration with Data Conferencing
The Board supports local and remote whiteboarding, including whiteboard writing, annotation,
and sharing. Figure 5-3 shows the whiteboard screen. Table 5-1 describes the whiteboarding
functions.
