RTN XMC ODU V200
Quick Installation Guide
Issue: 05
Part Number: 31506440
Date : 2017-09-15

1
Copyright ©Huawei Technologies Co., Ltd. 2017. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior
written consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei
and the customer. All or part of the products, services and features described in this document may not
be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all
statements, information, and recommendations in this document are provided "AS IS" without
warranties, guarantees or representations of any kind, either express or implied.
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
Address:
Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website:
http://www.huawei.com
Email:
[e-mail]

2
About This Document
Overview
This document is intended to provide guidelines for hardware quick installation.
Product Version
The following table lists the product version related to this document.
The functions of Fixed Service (FS) for this device are restricted to use and put
into service due to the need for a spectrum license and/or the conditions
attached to authorisation for the use of frequencies within all European Union
countries ( BE / BG / CZ / DK / DE / EE / IE / EL / ES / FR / HR / IT / CY / LV /
LT / LU / HU / MT / NL / AT / PL / PT / RO / SI / SK / FI / SE / UK ).
Product Name
Product Version
RTN XMC ODU V200
V200R001

3
Contents
Safety Precautions
Installation Tools
Installing the ODU
Components of the ODU
Installation Scenarios
Installation Procedure
Changing Polarization Direction of the Antenna
Installing the ODU on the Antenna
Installing the Hybrid coupler on the Antenna
Installing the ODU on the Hybrid coupler
Installing the ODU Separate Mounting Bracket on the Pole
Installing the ODU on the ODU Separate Mounting Bracket
Installing the Hybrid Coupler on the ODU Separate Mounting Bracket
Installing the Flexible Waveguide
Installing the Flexible Waveguide Support Fixture
Installing the Antenna Adapter on the Antenna
Installing the ODU on the Antenna Adapter
Installing the Hybrid coupler on the Antenna Adapter
Installing the OMT
Installing the ODU on the OMT
Installing ODU Cables
Installing IF Cable
Installing the PGND Cable of the ODU
Installing the Surge Protector and Its PGND Cable (Optional)
Grounding the IF Cable
Installation Check
Items to be Checked for the Antenna, Hybrid Coupler, and ODU
Items to be Checked for Separate Mounting Components
Items to be Checked for the ODU Cables
Parts Replacement
Replacing the ODU
Replacing the Hybrid coupler
Appendix
Terminating the IF Cable with the N Connectors
Terminating the IF Cable with the TNC Connectors
Waterproofing Outdoor Connectors
BNC Voltage (for RSSI) and Receive Signal Level Look Up Table
4
5
6
6
9
10
14
15
17
19
20
21
21
22
23
26
27
28
29
31
32
32
39
40
41
43
43
43
44
45
45
45
46
46
47
48
49

4
Safety Precautions
This document is intended to provide guidelines for hardware quick installation.
Thunderstorm
Do not perform operations on towers or poles with high voltage and AC power
during thunderstorms.
Working at Heights
When working at heights, be careful about objects falling down from a height.
Hoisting Heavy Objects
When heavy objects are hoisted, do not stand or walk under the boom or the
objects.
Microwave
High power radio-frequency signals are harmful to human body. Do not stay too
close to the antenna in the emitting direction of the antenna when the microwave
communication equipment is working. When installing or maintaining an antenna
on the tower or pole installed with more than one antenna, avoid the strong
radiation from the other antennas.
IF Cable
Before installing or removing an IF cable, turn off the ODU power switch.

5
Installation Tools
Tape measure
Philips
Screwdriver Flat-head
Screwdriver
Adjustable
Wrenches
Level carpenters
Socket Wrench Torque Wrench Allen Wrench
Cable Cutter
Diagonal Cutters
Needle-nose Pliers
Pliers
Bayonet Wrench
Utility Knife
Claw Hammer
Marker Pen
Ladder
Compass
Lifting Rope
Lifting Hook
Antistatic Gloves
Multimeter PVC TapeFile Waterproof
Insulation Tape

6
Antenna interface
Extension tributary interface
Main tributary interface
Front
Top
b Appearance and Interfaces of the Hybrid Coupler
a Appearance and Interfaces of the ODU
Components of the ODU
Installing the ODU
Grounding screw IF interface
Antenna interface RSSI interface
Interface Name Interface Label
Main tributary interface MAIN
Extension tributary interface STD BY

7
c Appearance of the ODU Separate Mounting Bracket
Components of the ODU
Main bracket
Auxiliary bracket
Transfer component
d Appearance of the Antenna Adapter
Polarization identifier
Interface on the ODU/
hybrid coupler side
Guide trough
Interface on the
antenna side
Installing the ODU

8
Components of the ODU
f Cables
RG-8U cable or 1/2-inch cable
5D cable
RF coaxial cable connector,
N-type, male
RF coaxial cable connector,
TNC-type, male
Grounding bar
Naked crimping connector (OT type)
PGND cable of the ODU
e Appearance of the Flexible Waveguide
Installing the ODU
PGND cable of the ODU(NA)
Naked crimping connector (OT type)
Grounding clip base

9
a Installing the ODU on a Single-Polarized Antenna
Installation Scenarios
b Installing the ODU on a Dual-Polarized Antenna
One ODU installed on one antenna Two ODUs installed on one antenna
1. Direct Mounting Mode
2. Separate Mounting Mode
Installing the ODU
One ODU installed on one antenna Two ODUs installed on one antenna
Use a hybrid coupler adaptive to the XMC ODU if two ODUs are configured with only one antenna installed in direct-mounting
mode.

1010
Direct Mounting Mode
a Installing the ODU on a Single-Polarized Antenna
Installation Procedure
Change the antenna
polarization
Start
Install the
antenna compatible to
the XMCODU?
Install the antenna adapter
on the antenna
Install the hybrid coupler on
the antenna or the antenna
adapter
Install the ODUon the
antenna or the antenna
adapter
Install the ODUon the hybrid
coupler
Install the ODU cables
End
Two
ODUs intalled on one
antenna?
Y
N
N
Y
P17 or P28
P19
P32~P42
P15 or P27
P26
Install the antenna
Referring to the
instructions for the antenna
Referring to the
instructions for the
antenna and Page 14
Apply vertical
polarization in the
network planning?
Y
N
Installing the ODU

1111
Separate Mounting Mode
a Installing the ODU on a Single-Polarized Antenna
Installation Procedure
Start
Install the ODU separate
mounting bracket
Install the ODU on the
ODU separate mounting
bracket
Install the ODU cables
End
Two
ODUs intalled on one
antenna? N
Y
Install the antenna
Install the hybrid coupler on
the ODU separate mounting
bracket
Install the ODUon the
hybrid coupler
Install the flexible
waveguide
P20
P22
P21
P21
P32-42
P19
Change the antenna
polarization
Referring to the
instructions for the
antenna and Page14
10
Apply vertical
polarization in the
network planning?
Y
N
Referring to the
instructions for the antenna
Installing the ODU

1212
Installation Procedure
Installing the ODU on a Dual-Polarized Antenna
b
Installing the ODU
Start
Install theODU separate
mounting bracket
Install the ODU on
the ODU separate
mounting bracket
Install the ODU cables
End
N
Y
Install the antenna
Install the hybrid coupler on
the ODU separate mounting
bracket
Install the ODU on the hybrid
coupler
Install the flexible waveguide
P20
P22
Referring to the instructions for
the antenna
P21
P21
P32-42
P19
Two
ODUs installed on one
feederboom?
Separate Mounting Mode

131313
Installation Procedure
Installing the ODU on a Dual-Polarized Antenna
b
Installing the ODU
Start
Install the OMT
Install the ODU cables
End
Install the antenna
Install the ODUon the OMT
P29
Referring to the instructions for
the antenna
P18
P32~P42
P31
Direct Mounting Mode
Do not install the ODU under harsh weather conditions, such as windy, rainy, or stormy weather.
After the ODU is unpacked or powered off, it must be powered on within 24 hours to avoid moisture
accumulation in it.
Do not damage the coating when you install or replace an ODU.
In case of operating in the sea or around the coast area (within 3.7 km from coastline) or 3 km away
from inland pollution sources (including coal mines, metallurgic plant, thermal power plant , and chemical
plant), measure must be taken for the ODU against salt damage. Please contact HUAWEI for the
countermeasure.

1414
Changing Polarization Direction of the Antenna
The antennas are available in multiple types. This procedure for changing the antenna polarization direction is provided for
reference only. In actual installation, follow the instructions delivered with the antenna.
By default, the antenna applies vertical polarization. If the antenna requires horizontal polarization in the network plan, the
polarization direction of the antenna should be changed.
1. Loosen the fastening screw ④on feed boom ③so that the feed boom can rotate freely.
2. Rotate the feed boom ①90 degrees in a clockwise direction or an anticlockwise direction to ensure that the red
polarization identifier on the feed boom is aligned with the H identification line.
3. Adjust feed boom ①to align the four feed booms tabs ③with the holes in the feed boom, and then tighten
fastening screw ④on the feed boom.
Single-polarized antenna-vertically polarized Single-polarized antenna-horizontally polarized
Dual-polarized antenna-the feed
boom on the left is vertically polarized Dual-polarized antenna-the feed
boom on the left is horizontally polarized
Installing the ODU
③
④
①
②

1515
Installing the ODU on the Antenna
1. Observe the position of the ODU guide pin . It is attached to the inner side of the ODU handle by default.
When the antenna is installed in horizontally polarized mode, secure guide pin ①to identifier H. Before
securing the guide pin, you should screw out the plastic screw ②at identifier H. When the antenna is installed
in vertically polarized mode, secure guide pin ①to identifier V. Before securing the guide pin, you should screw
out the plastic screw ②at identifier V. The following describes how to install the guide pin for horizontal-
polarized antennas.
The guide pin is used together with the guide through to facilitate the installation of the ODU.
Apply anti-seize grease to the screws on the guide pin.
2. Remove the dust-proof caps ①from the antenna port of the ODU and the antenna feed boom.
Installing the ODU
①
①
①
②

The direction of the waveguide cavity of the
ODU must be the same as that of the
waveguide cavity of the antenna feeder.
1616
3. Installing the ODU on the Antenna
3.1. Apply lubricant on gasket ⑥of the antenna interface on the ODU. (Note: Do not apply lubricant on end face ⑤.)
3.2. Apply anti-seize grease to the four M6 captive screws ①on the ODU.
3.3. Lift the ODU to slide guide pin ②of the ODU into guide trough③facing the antenna direction.
3.4. Install the ODU on the antenna and ensure that the IF interface ④of the ODU faces downwards.
3.5. Screw the four M6 captive screws ①on the ODU part way in and then tighten them cornerwise in sequence.
Installing the ODU on the Antenna
Screwing-stop surface
Installation surface
If the screwing-stop surface of the captive
screw is in complete contact with the
installationsurface of the bolt holes, it indicates
that the screws are tightened.
Installing the ODU
①
②
③
④
Apply lubricant on gasket ⑥.
Do not apply lubricant on end face ⑤.
⑥
⑤

1717
a Changing the Polarization Direction of the Hybrid Coupler
Installing the Hybrid Coupler on the Antenna
The hybrid coupler is available in multiple types. This procedure for changing the polarization direction of the
hybrid coupler is provided for reference only. In actual installation, follow the instructions delivered with the
hybrid coupler.
By default, the hybrid coupler applies vertical polarization. If horizontal polarization is required, change the
polarization direction of the hybrid coupler antenna port.
When adjusting the polarization direction of the hybrid coupler , ensure the seal washer is correctly installed
and intact.
1. Loosen the four hex socket screws ②and remove the polarizer ①. Note: Ensure that the seal washer does not
fall off during this procedure.
2. Align the arrow (↑) on the polarizer ①with the letter H on the antenna by rotating the polarizer ①.
3. Check whether the seal washer is correctly installed and intact before installing the polarizer. Then, install the
polarizer ①and tighten the four hex socket screws ②.
Installing the ODU
①
②

1818
1. Apply lubricant on gasket ⑤of the antenna interface of the hybrid coupler. (Note: End face ④should not be
applied with lubricant.)
2. Apply anti-seize grease to the four M6 captive screws ③of the hybrid coupler.
3. Slide guide pin ②of the hybrid coupler into guide trough ①, and then install the hybrid coupler onto the antenna.
4. Screw the four M6 captive screws ③of the hybrid coupler part way in and then tighten them cornerwise.
b Installing the Hybrid coupler on the Antenna
Installing the Hybrid Coupler on the Antenna
The direction of the waveguide cavity of the antenna feeder
must be the same as that of the waveguide cavity on the
antenna interface of the hybrid coupler.
Installing the ODU
①
③
⑤
④
②
Apply lubricant on gasket ⑤.
Do not apply lubricant on end
face ④.

Apply lubricant on gasket ⑥.
Do not apply lubricant on end face ②.
19
Installing the ODU on the Hybrid Coupler
1. Replace guide pin position ①of the ODU and ensure that it is located at indicator H. Apply anti-seize grease to
the screws on the guide pin.
2 Apply lubricant on gasket ⑥of the antenna interface of the ODU. (Note: End face ②should not be applied with
lubricant.)
3. Apply anti-seize grease to the four M6 captive screws ③of the ODU.
4. Slide guide pin ①of the ODU into guide trough ④of the hybrid coupler, and then install the ODU onto the hybrid
coupler. Ensure that the IF interface ⑤of the ODU faces downwards.
5. Screw the four M6 captive screws ③of the ODU part way in and then them cornerwise.
Two ODU interfaces are available on the hybrid coupler. The main ODU must be installed on the MAIN interface of the hybrid
coupler and the standby ODU must be installed on the STD BY interface of the hybrid coupler.
19
Screwing-stop surface
Installation surface
If the screwing-stop surface of the captive screw is in
complete contact with the installation surface of the
bolt holes, it indicates that the screws are tightened.
Installing the ODU
②①
⑥
④
⑤
③
