Huawei AR100 Series User manual

HUAWEI TECHNOLOGIES CO., LTD
Quick Start Guide
Issue: 18 (2019-05-22)
Part Number: 31505422
AR100&AR120&AR150&AR160&AR200&
AR1200&AR2200&AR3200&AR3600 Series
Enterprise Routers

Thank you for purchasing a Huawei AR series router. This guide describes how to install AR100, AR120, AR150,
AR160, AR200, AR1200, AR2200, AR3200, and AR3600 series routers. It also explains how to log in to your router
for the first time.
For more information, see the Hardware Installation and Maintenance Guide for your router on the Huawei
support website.
The installation, cable connection, and login methods for most AR series routers are similar. This guide uses the
AR1220 as an example.
Figures in the document are for reference only and may be different from actual devices.
Any procedural differences between models are specified at the start of each section.
1 About This Guide
Chassis (with the product model on the nameplate)
Power cable
Power adapter (only delivered with the
AR100/AR120/AR150/AR160/AR200 series routers)
Installation accessory package:
- Ground cable
- Quick Start Guide
- Rubber pads
- Console cable
- Warranty Card
- Mounting brackets
- Locking latches
- Screws
The numbers and types of items in the installation accessory package differ for different product models.
The installation accessory package of an AR100/AR120/AR150/AR160/AR200 series router does not include the console cable
and mounting brackets.
The installation accessory package of an AR1200 series router does not include the console cable.
NOTE
2 Packing List
3 Safety Guidelines
To ensure personal and equipment safety, observe all the safety precautions on the equipment and in this
document. WARNING and CAUTION items do not cover all the safety precautions and are only supplementary
to the safety precautions.
Follow all the safety precautions and instructions provided by Huawei. The safety precautions outlined in this
document are only requirements of Huawei and do not include general safety requirements. Huawei is not
liable for any consequence that results from violation of regulations pertaining to safe operations or safety
codes pertaining to design, production, and equipment use.
This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be
required to take adequate measures.
Take ESD protection measures during router installation and maintenance. For example, wear ESD gloves or an ESD wrist strap.
Do not place other objects on the router.
WARNING
CAUTION
Laser beams will cause eye damage. Do not look into bores of optical modules or optical fibers without eye protection.
Do not install power cables while the power is on.
Do not turn on the power until you have finished installing the chassis and connecting cables.
1

2
4 Site Environment
Do not place this product in an environment with flammable or explosive gases, or smoke.
The installation site must be free from leaking or dripping water, heavy dew, and humidity. If the relative
humidity is high, use dehumidifiers or dehumidifying air conditioners.
The installation site must be well ventilated. Ensure that air vents on the equipment are not blocked.
Do not install the equipment in a dusty environment.
Leave at least 50 mm clearance at the rear and both sides of the chassis for heat dissipation.
If multiple routers are installed in a cabinet/rack, leave at least 1 U (44.45 mm) distance between each two
routers.
Ensure that the temperature and humidity at the installation site meet the router operation requirements. For
the specific requirements, see the Hardware Description for your router on the Huawei support website.
5 Installing the Router
Scenario 1: Desk Mounting
Scenario 2: Wall Mounting
The AR100/AR120/AR150/AR160/AR200 and AR1200 series routers can be desk-mounted.
Do not stack routers on top of or closely next to each other.
Some router models provide a security slot ( ) on the panel of the chassis. You can install a security lock
(separately purchased) in this slot to protect the router against theft.
Before You Start
Installation Procedure
Attach four rubber pads to the bottom.
Place the router on a desk.
Step 1
Step 2
(Optional) Install a security lock.
Connect the ground cable to the ground point.
Step 3
Step 4
The AR100/AR120/AR150/AR160/AR200 and AR1200 series routers can be wall-mounted.
Before drilling holes in a wall, make sure there are no power cables in the wall to avoid electric shock.
Ensure that there are no flammable or explosive materials near the router and no obstructions within 100 mm around the router.
The panel with interfaces must face down to protect the interfaces from water.
The distance between two installation holes of the AR100 series, AR129CV, AR129CVW, AR129CGVW-L, AR169CVW, and
AR169CVW-4B4S routers is 120 mm.
The distance between two installation holes of the AR161EW, AR161EW-M1, AR169EW, and AR169EGW-L routers is 185 mm.
The distance between two installation holes of the AR120 (except the AR129CV, AR129CVW, AR129CGVW-L) /AR150/AR200
/AR160 (except the AR169CVW, AR169CVW-4B4S, AR161EW, AR161EW-M1, AR169EW, AR169EGW-L) series routers is 130 mm.
The distance between two installation holes of the AR1200 series routers is 270 mm.
Before You Start
1
2

Use the marker to mark installation hole positions. The distance between two installation holes is 270 mm.
Fix M4 mounting screws against the wall and leave 2 mm distance away from the wall.
Hang the router on the mounting screws.
Connect the ground cable to the ground point.
Step 1
Step 2
Step 3
Step 4
Installation Procedure
3
Scenario 3: Cabinet/Rack Mounting
AR series routers can be installed in a 19-inch standard cabinet/rack. Cabinets purchased from other vendors
must have enough space for equipment installation.
If the distance between front and rear mounting rails is not within the required range, install guide rails or a
tray in the cabinet/rack to support the chassis. Guide rails or trays are not delivered with the product and must
be purchased separately.
Cabinet mounting is not recommended for Wi-Fi-capable routers.
If routers with the 3G or LTE function are installed in a cabinet, use indoor remote antennas for the routers.
Install indoor remote antennas on the primary 3G or LTE interfaces on the routers.
The AR100 series, AR129CV, AR129CVW, AR129CGVW-L, AR169CVW, and AR169CVW-4B4S routers cannot
be installed in a cabinet.
In this document, AR2204E series refer to AR2204-51GE-P, AR2204-51GE, AR2204-51GE-R, AR2204-48GE-P,
AR2204-27GE-P, AR2204-27GE, AR2204-24GE, AR2204E, AR2204XE, AR2204XE-DC, AR2204E-D-27GE, and
AR2204E-D.
Before You Start
Some router models have specific installation requirements. Refer to the following table for
details about your router model.
Chassis is heavy, so it is recommended that you install guide rails (separately purchased) in the cabinet to support the chassis.
AR2204/AR2220E/AR2204E series
AR2220/AR2240/AR2240C/AR3260/AR3670
Ensure a distance of 375–454 mm or 507–566 mm between the front and rear mounting brackets.
Leave 1 U between the floating nuts on each front mounting rail, and 1 U between those on the rear rails. Ensure the lower
floating nut on each mounting rail is level with those on the other mounting rails.
2 mm
270 mm
1
2
3

4
Attach mounting brackets to the router with M4 screws. Determine the mounting method
according to the brackets delivered with your router.
Step 1
Installation Procedure
Install four floating nuts on front mounting rails, two on each side. Install the floating nuts in two
mounting holes with one hole between them.
Hold bottom of the router and push the router into the cabinet.
Use M6 screws to secure the router onto the cabinet/rack.
Connect the ground cable to the ground point.
Step 2
Step 3
Step 4
Step 5
Applicable to AR120/AR150/AR160
/AR200 series
Applicable to AR2201-48FE/AR2202-48FE
Applicable to AR1200 series
Applicable to AR2220 Applicable to AR2240/AR2240C Applicable to AR3260/AR3670
3
4
1 U
2
M6 screw
Distance between mounting rails:
507 mm-566 mm
Distance between mounting rails:
375 mm-454 mm
Applicable to AR2204/AR2220E/
AR2204E series

5
6 Installing Cards
Before You Start
The methods for installing SIC, WSIC, XSIC, and SRU cards into SIC, WSIC, XSIC, and SRU slots are the same.
The procedure in scenario 1 installs a SIC card into a SIC slot without removing the guide rail.
Slots can be combined into a bigger slot on an AR router. The procedure in scenario 2 installs a WSIC card into
two SIC slots with the guide rail removed.
For information about the cards supported by your model, see Cards in the Hardware Description of your
router on the Huawei support website.
All cards are hot swappable.
Before installing a card, wear an ESD wrist strap or ESD gloves.
When installing a card, slowly push it into the slot. If you feel resistance or find the card inclined, pull the card
out and push it into the slot again. Do not push the card with force; otherwise, the connectors on the card
and router backplane may be damaged.
Install filler panels in vacant slots.
Installation Procedure
Use a Phillips screwdriver to loosen the captive screw on the filler panel counterclockwise.
Pull the filler panel out by the captive screw. Keep the filler panel for future use.
Turn the eject lever of the card 45 degrees outward. Push the card into the chassis with your thumbs.
Rotate the ejector lever inward to lock the card after the card is completely in the chassis.
Use the Phillips screwdriver to fasten the captive screws clockwise.
Step 1
Step 2
Step 3
Step 4
Step 5
Scenario 1: Not Removing Guide Rails
1
2
4
35

6
Installation Procedure
Use a Phillips screwdriver to loosen the captive screws on the filler panels on the two SIC
slots counterclockwise.
Pull the filler panel out by the captive screw. Keep the filler panel for future use.
Use the Phillips screwdriver to loosen the screw on the guide rail.
Remove the guide rail in the middle of the chassis.
Turn the eject lever of the card 45 degrees outward. Push the card into the chassis with your thumbs.
Rotate the ejector lever inward to lock the card after the card is completely in the chassis.
Use the Phillips screwdriver to fasten the captive screws clockwise.
Step 1
Step 2
Step 3
Step 4
Step 5
Step 6
Step 7
Scenario 2: Removing a Guide Rail
3 54
7
1
2
6

7
7 Connecting Cables
Power cables must be more than 10 cm away from signal cables.
Optical fibers must be used with optical modules.
The bend radius of optical fibers must be larger than 40 mm.
For the ground cable, attach the M4 lug to the router and the M6 lug to the ground point.
If your router uses AC power supply, use AC power cables in compliance with local standards.
If your router uses DC power supply, ensure that the positive and negative cables are connected to the positive
and negative poles correctly.
Antennas need to be installed for routers that provide the Wi-Fi or LTE/3G functions.
Before You Start
ACT RST
SYS WAN
7 7
No.
1 5
2
3
4
6
7
Item Connect To No. Item Connect To
Ground cable
AC power cable
Ethernet cable
Ethernet cable
USB port
Console cable
Protection ground
External power source
Switch or PC
Upstream network device
Operation terminal
(usually a PC)
USB flash drive
Ethernet cable
Operation terminal
(usually a PC)
~100-240V;50/60Hz;2A
FE0 FE1 FE2 FE3 FE4 FE5 FE6 FE7 GE0 GE1
CON/AUX
EN EN
2 1
management
13
MGMT
network
2456

8
8.1 Using the default web login settings
8 Logging In to the Router for the First Time
Before You Start
Login Procedure
RST
SYS WAN
ACT
Use a network cable to connect a PC to the management interface marked with the Management
silkscreen on the router.
Step 2
Step 3
Step 1 Turn on the power switch on the external power supply and log in to the router after the SYS indicator
blinks once every 2 seconds (indicating that the router is running properly).
RST
SYS
~100-240V;50/60Hz;2A
FE0 FE1 FE2 FE3 FE4 FE5 FE6 FE7 GE0 GE1
CON/AUX
EN EN
2 1
management
OFF
Network cable
GE0
management
Network port
If the Management silkscreen is not found on the panel of the router, find the corresponding
management interface based on the router model.
AR150 series: FE3 (Ethernet0/0/3).
AR160 series: GE0 (GigabitEthernet0/0/0).
AR200 series: FE6 (Ethernet0/0/6).
Assign the PC with an IP address on the same network segment as the router IP address. The available IP
addresses are in the range from 192.168.1.2 to 192.168.1.254, and the subnet mask is 255.255.255.0.
If the web page is displayed abnormally, the browser version may be too low. Upgrade the browser and log in
to the web platform using Mozilla Firefox 12.0 or later, Google Chrome 23 or later, or Internet Explorer 8.0 or
later.
The login page varies according to version.
You can also scan the QR code on the right to watch the video introducing the procedure for logging in to
routers in web mode.
NOTE

9
Step 4 Start the browser, enter the URL https://192.168.1.1 in the address box, and press Enter to access the login
page.
Step 5 Enter the user name and password, and click Login to access the web page.
On the web page, you can configure the router. To switch between the Classics web system and the
EasyOperation web system, click Switch Version in the upper right corner. For more information, see the
Web-based Configuration of the product.
If you fail to log in to the web platform, the current software version of the router does not support login using
the default web login settings. In this case, try the method in 8.2 Using the configured web login settings.
8.2 Using the configured web login settings
Use a console cable to connect a PC to the Console interface of the router.
Start the terminal simulation software, create a connection, configure the connected port, and set
communication parameters as follows.
Step 1
Step 2
Press Enter until the following information is displayed. (The following information is only for reference)Step 3
Install third-party terminal simulation software on the PC by referring to user manual or online help.
The password entered in interactive mode is not displayed on the screen.
Before You Start
Login Procedure
Transmission rate: 9600
Data bit (B): 8
Parity bit: None
Stop bit (S): 1
Flow control mode: None
In V200R005C30 or a later version, the system will prompt you to enter the default password.
Login authentication
Username:admin
Password:
Info:The entered password is the same as the default. You are advised to
change it to ensure security.
For V300R019C00 and later versions, the default user name is admin and the default password is
[email protected].
For the other versions, the default user name is admin and the default password is Admin@huawei.
NOTE
NOTE
For V300R019C00 and later versions, the default user name is admin and the default password is
[email protected].
For the other versions, the default user name is admin and the default password is Admin@huawei.

10
Use a network cable to connect the PC to the management interface of the router.
Configure a management IP address for the router.
The following example sets the management IP address to 192.168.1.1 and mask length to 24 on GE0/0/0.
Step 4
Step 5
Enable the Web server function.Step 6
Please configure the login password (8-128)
Enter Password:
Confirm Password:
In a version earlier than V200R005C30, the system will prompt you to configure a password.
After successful login, you can configure the router on the command line interface. For more information, see the
CLI-based Configuration.
To configure the router using the web-based management system, perform the following steps.
After a login password is configured, this password will be required upon the next login if password
authentication is used on this user interface.
If you forget the login password, restore the password according to the Troubleshooting.
NOTE
<Huawei> system-view
[Huawei] interface gigabitethernet 0/0/0
[Huawei-GigabitEthernet0/0/0] ip address 192.168.1.1 24
[Huawei-GigabitEthernet0/0/0] quit
[Huawei] http server enable
Configure an HTTPS user and set the user level.Step 7
[Huawei] aaa
[Huawei-aaa] local-user admin password cipher Admin@huawei
[Huawei-aaa] local-user admin privilege level 15
[Huawei-aaa] local-user admin service-type http
[Huawei-aaa] quit
[Huawei] quit
<Huawei> save
Start your browser, enter the URL https://192.168.1.1 in the address box, and press Enter to display the
login page.
Step 8
Enter account information.
Enter the user name and password configured in step 7 to log in to the router.
Step 9
You can use the web-based management system to configure the router. For details, see Web-based
Configuration.

11
Log in to Huawei enterprise technical support website
(http://support.huawei.com/enterprise), and select a specific product model and version to
find its documentation.
Log in to Huawei enterprise support community (http://support.huawei.com/ecommunity)
and post your questions in the community.
9 Obtaining Product Documentation and Technical Support
Huawei Enterprise
Technical Support
In V200R005C20 and later versions, you can open the web login page of your router, and click Open Source
Software Notice at the lower right corner of the page to view details about the open source software notice.
10 Open Source Software Notice
Hereby, Huawei Technologies Co., Ltd. declares that the radio equipment type is in compliance with Directive
2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address:
www.huawei.com/en/product-certification.
11 Declaration of Conformity
Unique Identifier: trade name: HUAWEI; product name: Router;
model number: AR100&AR120&AR150&AR160&AR200&AR1200&AR2200&AR3200&AR3600 series routers
Responsible Party- U.S. Contact Information
Huawei Technologies USA Inc.
5700 Tennyson Parkway, Suite 500
Plano, Texas 75024
Main: 214-919-6000 / TAC Hotline: [phone]
FCC Compliance Statement ( for products subject to Part 15)
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
12 Supplier’s Declaration of Conformity (SDoC)
Copyright © Huawei Technologies Co., Ltd. 2019. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by
any means without prior written consent of Huawei Technologies Co., Ltd.
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the
property of their respective holders.
Qualification Card
PASS
Qualification Card
13 Trademarks and Permissions
