Huawei AR200-S Series User manual

Huawei AR200-S Series Enterprise Routers
V200R002C00
Quick Start Guide
Issue 01
Date 2011-12-30
HUAWEI TECHNOLOGIES CO., LTD.

Copyright © Huawei Technologies Co., Ltd. 2011. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior written
consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei and the
customer. All or part of the products, services and features described in this document may not be within the
purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information,
and recommendations in this document are provided "AS IS" without warranties, guarantees or representations
of any kind, either express or implied.
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute the warranty of any kind, express or implied.
Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website: http://www.huawei.com
Email: [email protected]
Issue 01 (2011-12-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
i

About This Document
Intended Audience
This document provides an overall description of the AR200-S, details about each chassis and
board, cables available to the device, lists of components and basic configuration.
This document is intended for:
lNetwork planning engineers
lHardware installation engineers
lCommissioning engineers
lOn-site maintenance engineers
lSystem maintenance engineers
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol Description
DANGER
Indicates a hazard with a high level of risk, which if not
avoided, will result in death or serious injury.
WARNING
Indicates a hazard with a medium or low level of risk, which
if not avoided, could result in minor or moderate injury.
CAUTION
Indicates a potentially hazardous situation, which if not
avoided, could result in equipment damage, data loss,
performance degradation, or unexpected results.
TIP
Indicates a tip that may help you solve a problem or save
time.
NOTE
Provides additional information to emphasize or supplement
important points of the main text.
Huawei AR200-S Series Enterprise Routers
Quick Start Guide About This Document
Issue 01 (2011-12-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
ii

Change History
Changes between document issues are cumulative. Therefore, the latest document issue contains
all the changes in previous issues.
Changes in Issue 01 (2011-12-30)
Initial commercial release.
Huawei AR200-S Series Enterprise Routers
Quick Start Guide About This Document
Issue 01 (2011-12-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
iii

Contents
About This Document.....................................................................................................................ii
1 AR200-S Overview........................................................................................................................1
1.1 Naming Rule.......................................................................................................................................................2
1.2 Device Structure.................................................................................................................................................2
1.3 Indicator Description..........................................................................................................................................3
1.4 Physical Specifications.......................................................................................................................................6
2 Installation Product.......................................................................................................................8
2.1 Installation Preparations.....................................................................................................................................9
2.2 Installing the Device...........................................................................................................................................9
2.3 Connecting Device...........................................................................................................................................14
2.4 Powering on the Device....................................................................................................................................15
3 Logging In to the Router............................................................................................................17
3.1 Logging In to the Router Through the Console Port........................................................................................18
3.2 Logging In to the Router Using Telnet.............................................................................................................20
4 Connecting to the Internet.........................................................................................................21
4.1 Connecting to the Internet Using an xDSL Interface.......................................................................................22
4.2 Connecting to the Internet Through an Ethernet Interface...............................................................................24
5 How to Obtain Documentation and Technical Support......................................................27
6 FAQs...............................................................................................................................................28
Huawei AR200-S Series Enterprise Routers
Quick Start Guide Contents
Issue 01 (2011-12-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
iv

1 AR200-S Overview
About This Chapter
This section describes the naming rule, appearance and structure, indicators, and physical
specifications of the AR200-S.
1.1 Naming Rule
This section describes the meanings of the AR200-S names.
1.2 Device Structure
This section describes the structure of the AR200-S.
1.3 Indicator Description
This section describes the indicators on the AR200-S front panel.
1.4 Physical Specifications
This section describes the physical specifications and system configuration of the AR200-S.
Huawei AR200-S Series Enterprise Routers
Quick Start Guide 1 AR200-S Overview
Issue 01 (2011-12-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1

1.1 Naming Rule
This section describes the meanings of the AR200-S names.
Figure 1-1 shows the AR200-S naming rule.
Figure 1-1 AR200-S Naming rule
【AR】【B1 B2 B3 B4】【C1】【-D1】
AR 207 - S
Example:
Table 1-1 explains the AR200-S naming rule.
Table 1-1 AR200-S naming rule
Field Description
B1 0 (AR200-S): indicates a low-end case-shaped product.
B2 Fixed at 2, indicating an enterprise access router.
B3 Fixed as 0, indicating a case-shaped product that does not provide
subcards.
B4 When B1 is 0, B4 indicates the type of the fixed uplink interfaces on
the AR200-S (enterprise access gateway). The meanings of B4 values
are:
l1: FE/GE
l7: ADSL-A
C1 C1 consists of one or two uppercase letters.
lW: WLAN
lV: voice
D1 lA: AC power supply (This is the default configuration. You can
change the power type based on the actual requirements.)
lD: DC power supply
lS: small office and home office (SOHO)
1.2 Device Structure
This section describes the structure of the AR200-S.
Huawei AR200-S Series Enterprise Routers
Quick Start Guide 1 AR200-S Overview
Issue 01 (2011-12-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
2

Figure 1-2 shows the AR200-S models.
Figure 1-2 AR200-S models
AR200-S
Series
Product
Series Model WAN
Port
LAN
Port Appearance
AR
201-S 1 FE 8 FE
AR
207-S 8 FE
1AD
SL2+
Anne
xA/M
1 2 4 53
7
6
1
2
4 53
76
1: CON/AUX port 2: WAN port
lAR201-S: WAN FE
lAR207-S: ADSL
3: LAN FE port
AR201-S and AR207-S: 8
FE ports
NOTE
FE0 can be used as a WAN port
so that double WAN ports can
be provided.
4: RESET
CAUTION
The Reset button is used for
resetting the device manually.
lPress and hold down: Restore
the Factory Settings.
lPress: Reset the system.
Resetting the device will cause
service interruption; therefore,
confirm the action before you reset
the device.
5: DC power jack
NOTE
The AR200-S is powered by a 12
V external power adapter .
6: Silkscreen
7: Ground screw
1.3 Indicator Description
This section describes the indicators on the AR200-S front panel.
Huawei AR200-S Series Enterprise Routers
Quick Start Guide 1 AR200-S Overview
Issue 01 (2011-12-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
3

Indicators
The indicators on the AR200-S front panels vary according to the product models. Table 1-2
lists the indicator differences.
Table 1-2 AR200-SIndicator differences
Difference Description
WAN port silkscreen lAR201-S: WAN FE
lAR207-S: ADSL
Indicator Description
NOTE
lThe front panels of AR201-S and AR207-S are the same except for the WAN port indicator silkscreen.
Figure 1-3 AR201-S front panel
12 3 4 5 67
8
Figure 1-4 AR207-S front panel
21
Huawei AR200-S Series Enterprise Routers
Quick Start Guide 1 AR200-S Overview
Issue 01 (2011-12-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
4

Table 1-3 Indicator description
Numbe
r
Indicator Color Description
1PWR Green If the indicator is steady on, the system power
supply is normal.
If the indicator is off, no system power supply is
available.
2 SYS Red and
green
If the indicator blinks green once every 2s (0.5
Hz), the system is running properly.
If the indicator blinks green once every 0.25s (4
Hz), the system is powering on or restarting.
If the indicator is red, a fault that affects services
has occurred and cannot be rectified
automatically. The fault needs to be rectified
manually.
If the indicator is off, the software is not running
or is being reset.
3 USB Red and
green
If the indicator is green, devices have been
deployed by using the USB disk.
If the indicator blinks green, the router is being
deployed using the USB disk.
If the indicator is red, the router is failed to be
deployed using the USB disk.
If the indicator is off, the USB disk is not inserted,
the USB interface fails, or the indicator fails.
4 PPP Green If the indicator is steady on, a PPP connection is
set up.
If the indicator is off, no PPP connection is set up.
5 VPN Green If the indicator is steady on, the VPN service is
available.
If the indicator is off, the VPN service is
unavailable.
6 LINK Green If the indicator is steady on, a link is connected to
the WAN port.
If the indicator is off, no link is connected to the
WAN port.
ACT Green If the indicator blinks green, the WAN port is
transmitting or receiving data.
If the indicator is off, the WAN port is not
transmitting or receiving data.
Huawei AR200-S Series Enterprise Routers
Quick Start Guide 1 AR200-S Overview
Issue 01 (2011-12-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5

Numbe
r
Indicator Color Description
7LAN green If the indicator is steady on, a link is connected to
the LAN port.
If the indicator blinks green, the LAN port is
transmitting or receiving data.
If the indicator is off, no link is connected to the
LAN port.
8 USB port -
NOTE
lNumber 6 : The WAN port indicators have different silkscreens (such as WAN FE and ADSL).
lNumber 7 : FE0 can be used as a WAN port so that double WAN ports can be provided.
1.4 Physical Specifications
This section describes the physical specifications and system configuration of the AR200-S.
Table 1-4 Physical specifications
Item Description
Dimensions (width x depth x height) Without rack-mounting ears installed: 300.0 mm x
216.4 mm x 44.0 mm
With rack-mounting ears installed: 482.6 mm x
216.4 mm x 44.0 mm
Maximum power consumption lAR201-S: 12.5 W
lAR207-S: 15.6 W
Weight 2.2 kg
Operating temperature 0°C-40°C
Relative humidity 5% RH to 90% RH, non-condensing
Altitude 0 m-3000 m
AC input
voltage
Rated voltage 100 V AC-240 V AC, 50/60 Hz
Maximum voltage
range
90 V AC-264 V AC, 47/63 Hz
Huawei AR200-S Series Enterprise Routers
Quick Start Guide 1 AR200-S Overview
Issue 01 (2011-12-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
6

Table 1-5 System configuration
Product Name Processor Memory Flash Memory
AR201-S Dual-core 533 MHz 512 MB 512 MB
AR207-S Dual-core 533 MHz 512 MB 512 MB
Huawei AR200-S Series Enterprise Routers
Quick Start Guide 1 AR200-S Overview
Issue 01 (2011-12-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
7

2 Installation Product
About This Chapter
This section describes the method of installing and connectingAR200-S series products.
2.1 Installation Preparations
This section lists the tools and accessories for installing the AR200-S.
2.2 Installing the Device
This section describes AR200-S installation scenarios and installation methods.
2.3 Connecting Device
This section describes how to connect AR200-S series products.
2.4 Powering on the Device
This section provides the checklist used to check the AR200-S before powering on it.
Huawei AR200-S Series Enterprise Routers
Quick Start Guide 2 Installation Product
Issue 01 (2011-12-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
8

2.1 Installation Preparations
This section lists the tools and accessories for installing the AR200-S.
Tools
Claw hammer Utility knife COAX crimping tool
Diagonal pliers RJ45 crimping tool Wire stripper
Network cable tester Multimeter Measuring tape
Ladder Hammer drill Vacuum cleaner
ESD wrist strap Level Floating nut mounting bar
Flat-head screwdriverPhilips screwdriverMarker pen
Accessories
Rubber pad Floating nut M4 screw: fixes brackets to
chassis
M6 screw: fixes chassis into
cabinet Bracket Ground cable
2.2 Installing the Device
This section describes AR200-S installation scenarios and installation methods.
Huawei AR200-S Series Enterprise Routers
Quick Start Guide 2 Installation Product
Issue 01 (2011-12-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
9

NOTE
All AR200-S series products have the same installation scenarios, installation methods, and cable
connections. This section uses AR207-S as an example.
Placing Chassis on the Desktop
Before placing the AR200-S on the desktop, attach rubber pads onto each of the four recessed
corner areas on the bottom of the chassis.
AR207-S
Wall-Mounting the Chassis
CAUTION
lWhen wall-mounting the AR200-S, do not attach rubber pads to the chassis. If the rubber
pads have been attached, remove them.
lIt is inconvenient to connect ground cables and network cables after mounting the AR200-
S chassis on the wall. Therefore, it is recommended that you connect cables before mounting
the chassis on the wall. If the chassis has been mounted on the wall, hold the chassis when
connecting cables, preventing it from being detached from the wall. For the method of
connecting cables, see 2.3 Connecting Device.
lWhen connecting cables, do not make the front plastic panel of the chassis touch the ground
to avoid damage.
lIt is recommended that you wall-mount the AR200-S with its front panel (with indicators)
facing up and its rear panel (with interfaces) facing down.
lUse a ladder when mounting the chassis on the wall.
1. Use the template on the last page to mark the location for the two mounting screws and the
upper, left, and right edges of the chassis on the wall.
Huawei AR200-S Series Enterprise Routers
Quick Start Guide 2 Installation Product
Issue 01 (2011-12-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
10

2. The diameter of the mounting screws is 4 mm. Choose an appropriate drill bit according
to the diameter of the mounting screws. Hammer the hollow wall anchors into the drilled
holes. Screw the mounting screws into the wall anchors using a screwdriver. Leave the
screws protruding 2 mm from the wall.
3. Mount the chassis by aligning the mounting brackets on the back of the AR200-S using
mounting screws.
Huawei AR200-S Series Enterprise Routers
Quick Start Guide 2 Installation Product
Issue 01 (2011-12-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
11

4. Connect the power adapter. Place the power adapter on a nearby horizontal surface, but do
not hang it under the equipment.
Installing the Chassis in a Cabinet or Rack
CAUTION
lWhen installing the AR200-S in a cabinet or rack, do not attach rubber pads to the chassis.
If the rubber pads have been attached, remove them.
lThe guide rails or trays are not necessary for the installation in a cabinet or rack because the
AR200-S chassis can be fixed by rack-mounting brackets. Customers need to buy the rack-
mounting brackets.
lIt is recommended that you install the AR200-S with its front panel (providing indicators)
facing inside and its rear panel (providing interfaces) facing outside.
lEnsure that the air exhaust vent is not obstructed in any way. Otherwise, the chassis may
overheat.
1. Install two rack-mounting brackets. It is recommended that you install the rack-mounting
brackets close to the rear panel (providing interfaces).
2. Install two floating nuts on each side of the rack. The AR200-S chassis is 1 U high. The
mounting holes located on the rack-mounting brackets will be fixed to two mounting holes
on the rack.
Huawei AR200-S Series Enterprise Routers
Quick Start Guide 2 Installation Product
Issue 01 (2011-12-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
12

Floating nut
mounting bar
3. Raise and hold the chassis by hands and move the chassis into the cabinet. Insert the panel
screws into the below floating nuts and keep a 2 mm space between the screws and mounting
bar. Insert the rack-mounting ear pre-installation holes into the space.
2mm
AR207-S
4. Hold the chassis with one hand while using the other hand to secure the lower panel screw
and then the upper one with a screwdriver.
Huawei AR200-S Series Enterprise Routers
Quick Start Guide 2 Installation Product
Issue 01 (2011-12-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
13

AR207-S
2.3 Connecting Device
This section describes how to connect AR200-S series products.
Figure 2-1 Connecting the AR200-S to network
3
1
2
4
5
ab
Huawei AR200-S Series Enterprise Routers
Quick Start Guide 2 Installation Product
Issue 01 (2011-12-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
14

1: Console cable
lThe 8-pin RJ45 connector is inserted into the console port (CON/AUX port) of the AR200-
S.
lThe DB9 male connector is connected to the maintenance terminal, such as a computer.
2: WAN port cable that connects the AR200-S to the upper-layer network
lOn an AR201-S router, an FE port functions as the WAN port and connects to a network
cable with RJ45 connectors.
lOn an AR207-S router, an ADSL port functions as the WAN port and connects to a network
cable with RJ11 connectors.
3: LAN port cable, which is connected to a computer with a network cable (RJ45 connectors).
4: Ground cable. The M4 connector is connected to the AR200-S and the M6 connector is
connected to ground. The cable is in yellow and green.
lWhen the AR200-S is placed on the desktop or installed in a cabinet/rack, the ground cable
is connected facing downwards, as shown in Figure 2-1 a. The ground cable cannot
interfere with other devices in the cabinet/rack.
lWhen the AR200-S is wall mounted, the ground cable is connected facing left, as shown
in Figure 2-1 b.
5: external power adapter, which is connected to the AC power supply to output DC power to
the device.
Power adapter output power:
lAR200-S series: 36W
NOTE
The AC power cable must be secured using a latch.
2.4 Powering on the Device
This section provides the checklist used to check the AR200-S before powering on it.
Checklist
No. Item Method
1The power cables and ground cables are copper wires, and
are not spliced or damaged. The cables are safely
connected and in compliance with standards.
View
2 The power cables and ground cables are connected safely.
The spring washers of the ground cable terminals are on
the flat washer.
View
3 All signal cables to be deployed pass the continuity check. Measure
4 No signal cables are near the cabinet's heat vents. View
Huawei AR200-S Series Enterprise Routers
Quick Start Guide 2 Installation Product
Issue 01 (2011-12-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
15
