Huawei OptiXstar B671G User manual

OptiXstar B671G Quick Start
Issue
04
Date
2023-10-30
HUAWEI TECHNOLOGIES CO., LTD.

Issue 04 (2023-10-30)
Copyright © Huawei Technologies Co., Ltd.
i
Copyright © Huawei Technologies Co., Ltd. 2023. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior
written consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei and
the customer. All or part of the products, services and features described in this document may not be
within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements,
information, and recommendations in this document are provided "AS IS" without warranties, guarantees or
representations of any kind, either express or implied.
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
Huawei Technologies Co., Ltd.
Address:
Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website:
https://www.huawei.com
Email:
[email protected]

Issue 04 (2023-10-30)
Copyright © Huawei Technologies Co., Ltd.
ii
Security Declaration
Vulnerability
Huawei's regulations on product vulnerability management are subject to “Vul. Response Process”. For
details about the policy, see the following website:
https://www.huawei.com/en/psirt/vul-response-process
For enterprise customers who need to obtain vulnerability information, visit:
https://securitybulletin.huawei.com/enterprise/en/security-advisory

OptiXstar B671G Quick Start
Contents
Issue 04 (2023-10-30)
Copyright © Huawei Technologies Co., Ltd.
iii
Contents
1 Device Appearance .......................................................................................................................1
2 Networking Scenario....................................................................................................................3
3 Determining the Installation Position ......................................................................................4
4 Installing the Device ....................................................................................................................6
4.1 Ceiling-mounted/Wall-mounted Installation (7mm Thick)...........................................................................................6
4.2 Indoor T-Rail Installation (7mm Thick)........................................................................................................................9
4.3 Ceiling-mounted/Wall-mounted Installation (15mm Thick)....................................................................................... 11
4.4 Indoor T-Rail Installation (15mm Thick)....................................................................................................................14
5 Removing the Device .................................................................................................................18
6 Connecting Cables to the B671G..............................................................................................19
7 B671G indicator description......................................................................................................22
8 Technical Specifications ............................................................................................................24
9 FAQs ..............................................................................................................................................25

OptiXstar B671G Quick Start
1 Device Appearance
Issue 04 (2023-10-30)
Copyright © Huawei Technologies Co., Ltd.
1
1 Device Appearance
The appearances shown in this document may differ from the actual appearances of the products. The
actual products prevail.
Port/Butto
n
Description
Power
supply
Connects to the power adapter.
GE port
10/100/1000 Mbits/s ports are used to connect to the wired Ethernet.
Optical port
Supports GPON upstream access. The optical port also supports power over
fiber (POF) input.
Reset
button
Indicates the reset button. Press the button for a short time to restart the
device. Press and hold the button for more than 10s to restore the factory
settings and restart the device.
NOTE
Exercise caution when pressing the reset button. After the device is reset, Internet
access may become unavailable. If you cannot access the Internet after the reset,
contact your service provider for help.

OptiXstar B671G Quick Start
1 Device Appearance
Issue 04 (2023-10-30)
Copyright © Huawei Technologies Co., Ltd.
2
Use a power adapter that complies with related safety standards or has passed the CE certification.
Otherwise, the device may be damaged.

OptiXstar B671G Quick Start
2 Networking Scenario
Issue 04 (2023-10-30)
Copyright © Huawei Technologies Co., Ltd.
3
2 Networking Scenario
The main FTTR and a sub FTTR are connected using an FTTR ADU and PoF cable.
Automatic networking between the main FTTR and sub FTTR, and plug-and-play
In the FTTR for SME scenario, sub FTTRs must be used together with a main FTTR and FTTR ADUs.
Figure 2-1 Huawei FTTR gigabit enterprise networking

OptiXstar B671G Quick Start
3 Determining the Installation Position
Issue 04 (2023-10-30)
Copyright © Huawei Technologies Co., Ltd.
4
3 Determining the Installation Position
Installation personnel need to manually record the MAC addresses and deployment positions of devices
for commissioning engineers to configure. For example, the location information can be recorded on the
package as a reference for changing the alias by scanning a bar code using WeFTTR app.
You can scan the QR code on the back of the device to obtain the quick start guide.
Generally, the device is installed on a wall or ceiling by using a mounting bracket. The
installation position is determined by the site survey. At least 200 mm clearance must be
reserved between the cable outlet of the device and the wall. Figure 3-1 shows the installation
clearance requirements.
Figure 3-1 Installation reference diagram
When determining the installation position, comply with the following rules:
Minimize the number of obstacles (such as walls) between the device and STAs.

OptiXstar B671G Quick Start
3 Determining the Installation Position
Issue 04 (2023-10-30)
Copyright © Huawei Technologies Co., Ltd.
5
The device can be installed on the ceiling (recommended, the ceiling height does not
exceed 5 m) or on a wall (about 3 m above the floor).
Keep the device away from electronic devices that may cause radio interference, such as
microwave ovens, APs, and antennas. For details, see Table 3-1.
The installation position should be as concealed as possible to avoid disturbing daily
work and life.
Install the device in a site that is free from leaking or dripping water, heavy dew, and
humidity, and take protective measures to prevent water from flowing into the device
along the cable.
Do not install the device in an environment with high temperature, dust, poisonous gases,
flammable or explosive objects, electromagnetic interference (from a radar station, radio
station, or substation), unstable voltage, violent shakes, or strong noise.
Table 3-1 General requirements for antenna anti-interference deployment distance
Scenario
Deployment Distance Requirement
Indoor
installation
scenario
Distance between antennas: > 7 m
Distance from 4G antennas of an operator: > 5 m
Far away from other electronic devices (such as microwave ovens)
that may cause antenna interference
For a device with a built-in antenna, the distance requirement for the antenna is the distance requirement
for the device.

OptiXstar B671G Quick Start
4 Installing the Device
Issue 04 (2023-10-30)
Copyright © Huawei Technologies Co., Ltd.
6
4 Installing the Device
4.1 Ceiling-mounted/Wall-mounted Installation (7mm Thick)
4.2 Indoor T-Rail Installation (7mm Thick)
4.3 Ceiling-mounted/Wall-mounted Installation (15mm Thick)
4.4 Indoor T-Rail Installation (15mm Thick)
4.1 Ceiling-mounted/Wall-mounted Installation (7mm
Thick)
The methods for ceiling-mounted and wall-mounted installations are the same.
Ceiling-mounted installation is recommended.
Select an installation mode based on the mounting bracket.
A wall for installing the device needs to meet the following requirements:
The wall can bear the weight of four times the total weight of the device and mounting bracket
without damage. When the total weight of the device and mounting brackets is less than 1.25 kg, the
load-bearing capability of the wall must be greater than or equal to 50 N.
When the tightening torque of a screw reaches 3.5 N·m, the screw still properly works, without
crack or damage on the wall.
Mounting brackets and expansion screws are required to install the device in ceiling-mounted
mode. The procedures are as follows:
When fixing the mounting bracket, ensure that the arrows of point upwards.
1. Attach the mounting bracket against the wall and adjust its position properly. Mark
positions of the mounting holes with a marker, as shown in the following figure.

OptiXstar B671G Quick Start
4 Installing the Device
Issue 04 (2023-10-30)
Copyright © Huawei Technologies Co., Ltd.
7
2. Use a 6 mm drill bit to drill 35 mm to 40 mm deep holes in the marked positions.
Hammer the expansion tubes into the holes until the expansion tubes are flush with the
wall.
3. Attach the mounting bracket to the wall, and use the Phillips screwdriver to fasten three
expansion screws into the expansion tubes to secure the mounting bracket to the wall.

OptiXstar B671G Quick Start
4 Installing the Device
Issue 04 (2023-10-30)
Copyright © Huawei Technologies Co., Ltd.
8
4. Connect and arrange the cables. For details, see 6 Connecting Cables to the B671G. If
cables need to be routed through the ceiling, the drilling method shown in Figure 4-1 is
recommended.
Figure 4-1 B671G cable connections
When connecting a photoelectric composite cable to a B671G device, ensure that the bending
radius of the optical cable is greater than or equal to 24 mm.
5. Align the rubber feet at the rear of the device with the installation holes on the mounting
bracket, and fasten the device as shown in the figure. When you hear a click, the device
is secured to the lock position.

OptiXstar B671G Quick Start
4 Installing the Device
Issue 04 (2023-10-30)
Copyright © Huawei Technologies Co., Ltd.
9
After the device is installed, ensure that the ejector lever is in position to prevent the device from falling
off. Ensure that the installation space meets the specified requirements to facilitate future maintenance.
4.2 Indoor T-Rail Installation (7mm Thick)
The mounting bracket must be installed on the main T-rail with a strong bearing capacity,
which can bear the weight of four times the total weight of the device and mounting bracket
without damage. When the total weight of the device and mounting bracket is less than 1.25
kg, the load-bearing capability of the T-rail must be greater than or equal to 50 N.
Materials required for installation: two steel wire ropes, used to secure the mounting
bracket to a T-rail.
Procedure
1. Attach the mounting bracket against the ceiling and adjust its position properly. Mark
positions of the mounting holes (group J) with a marker, as shown in the following
figure..
2. Use an electric drill to drill holes on the ceiling based on the marked positions. It is
recommended that the hole diameter be greater than or equal to 3 mml.
3. Lead the steel wire ropes through the group J holes on the mounting bracket and the
holes on the ceiling in sequence, tighten the ropes, and use a hex key to tighten the heads
of ropes. The mounting bracket is secured to the ceiling.

OptiXstar B671G Quick Start
4 Installing the Device
Issue 04 (2023-10-30)
Copyright © Huawei Technologies Co., Ltd.
10
4. Drill a cable hole on the ceiling in front of the mounting bracket. Take cable protection
measures for the cable hole.

OptiXstar B671G Quick Start
4 Installing the Device
Issue 04 (2023-10-30)
Copyright © Huawei Technologies Co., Ltd.
11
5. Connect and arrange the cables. For details, see 6 Connecting Cables to the B671G. If
cables need to be routed through the ceiling, the drilling method shown in Figure 4-2 is
recommended.
Figure 4-2 B671G cable connections
When connecting a photoelectric composite cable to a B671G device, ensure that the bending
radius of the optical cable is greater than or equal to 24 mm.
6. Align the rubber feet at the rear of the device with the installation holes on the mounting
bracket, and fasten the device as shown in the figure. When you hear a click, the device
is secured to the lock position.
After the device is installed, ensure that the ejector lever is in position to prevent the device from falling
off. Ensure that the installation space meets the specified requirements to facilitate future maintenance.
4.3 Ceiling-mounted/Wall-mounted Installation (15mm
Thick)
The methods for ceiling-mounted and wall-mounted installations are the same.
Ceiling-mounted installation is recommended.
Select an installation mode based on the mounting bracket.
A wall for installing the device needs to meet the following requirements:
The wall can bear the weight of four times the total weight of the device and mounting bracket
without damage. When the total weight of the device and mounting brackets is less than 1.25 kg, the
load-bearing capability of the wall must be greater than or equal to 50 N.
When the tightening torque of a screw reaches 3.5 N·m, the screw still properly works, without
crack or damage on the wall.

OptiXstar B671G Quick Start
4 Installing the Device
Issue 04 (2023-10-30)
Copyright © Huawei Technologies Co., Ltd.
12
Mounting brackets and expansion screws are required to install the device in ceiling-mounted
mode. The procedures are as follows:
When fixing the mounting bracket, ensure that the arrows of point upwards.
1. Attach the mounting bracket against the wall and adjust its position properly. Mark
positions of the mounting holes with a marker, as shown in the following figure.
2. Use a 6 mm drill bit to drill 35 mm to 40 mm deep holes in the marked positions.
Hammer the expansion tubes into the holes until the expansion tubes are flush with the
wall.
3. Attach the mounting bracket to the wall, and use the Phillips screwdriver to fasten three
expansion screws into the expansion tubes to secure the mounting bracket to the wall.
4. Connect and arrange the cables. For details, see 6 Connecting Cables to the B671G. If
cables need to be routed through the ceiling, the drilling method shown in Figure 4-3 is
recommended.

OptiXstar B671G Quick Start
4 Installing the Device
Issue 04 (2023-10-30)
Copyright © Huawei Technologies Co., Ltd.
13
Figure 4-3 B671G cable connections
When connecting a photoelectric composite cable to a B671G device, ensure that the bending
radius of the optical cable is greater than or equal to 24 mm.
5. Align the rubber feet at the rear of the device with the installation holes on the mounting
bracket, and fasten the device as shown in the figure. When you hear a click, the device
is secured to the lock position.
After the device is installed, ensure that the ejector lever is in position to prevent the device from falling
off. Ensure that the installation space meets the specified requirements to facilitate future maintenance.
If the device is installed in a scenario with strong vibration, use M3x12 screws to secure the device to
the mounting bracket to prevent the device from falling off due to vibration. In normal scenarios, you do
not need to install these screws.

OptiXstar B671G Quick Start
4 Installing the Device
Issue 04 (2023-10-30)
Copyright © Huawei Technologies Co., Ltd.
14
Figure 4-4 Fixing device using screws
4.4 Indoor T-Rail Installation (15mm Thick)
The T-rail can bear the weight of four times the total weight of the device and mounting
bracket without damage. When the total weight of the device and mounting bracket is less
than 1.25 kg, the load-bearing capability of the T-rail must be greater than or equal to 50 N.
1. Determine the model of the T-rail. The following figure shows the specifications of the
T-rail supported by the mounting bracket. The following uses a flat-edge T-rail of 24
mm as an example.
The mounting brackets must be installed on the main rail.
2. Partially tighten the M3x6.2 set screw to the T-rail brackets.

OptiXstar B671G Quick Start
4 Installing the Device
Issue 04 (2023-10-30)
Copyright © Huawei Technologies Co., Ltd.
15
3. Install the flat-edge T-rail mounting brackets a and b along the sliding slot on the
mounting bracket body in the sequence shown in the figure.
1. Flat-edge T-rail mounting
bracket a
2. Flat-edge T-rail mounting bracket b
4. Secure the M3x8 screw through hole 24 marked in the figure, and secure T-rail bracket a.
The T-rails of 15 mm and 38 mm correspond to holes 15 and 38 on the mounting
brackets, respectively.
5. Insert mounting bracket a into the T-rail, and slide mounting bracket b along the slot
until the T-rail is tightened.
6. Secure the M3x8 screw through hole 24 marked in the figure, and secure T-rail mounting
bracket b. Tighten the M3x6.2 set screw for installing the T-rail mounting bracket.

OptiXstar B671G Quick Start
4 Installing the Device
Issue 04 (2023-10-30)
Copyright © Huawei Technologies Co., Ltd.
16
After the set screw is tightened, the mounting brackets may be deformed. This is normal and does not
affect the device installation.
7. Connect and arrange the cables. For details, see 6 Connecting Cables to the B671G. If
cables need to be routed through the ceiling, the drilling method shown in Figure 4-5 is
recommended.
Figure 4-5 B671G cable connections
When connecting a photoelectric composite cable to a B671G device, ensure that the bending
radius of the optical cable is greater than or equal to 24 mm.
8. Align the rubber feet of the device over the mounting slots on the mounting bracket and
vertically push the device. Then press the device downwards to secure it When you hear
a click, the device is secured to the mounting bracket.
After the device is installed, ensure that the ejector lever is in position to prevent the device from falling
off. Ensure that the installation space meets the specified requirements to facilitate future maintenance.
