Huawei HG530 User manual

Installation Instructions
Wireless ADSL2+ Router
Huawei HG530 / HG530u
APRIL 2011Please recycle
24-hour Technical Support Line
If you have any questions or need help before
and after the ADSL installation, call
(Local call rate throughout Greece)

Minimum System Requirements............................................................................................................................................. 3
Package Contents ........................................................................................................................................................................ 4
LEDs ................................................................................................................................................................................................... 5
Ports .................................................................................................................................................................................................. 6
Connecting the ADSL2+ Router ............................................................................................................................................. 7
PSTN Line ................................................................................................................................................................................ 8
ISDN Line ...............................................................................................................................................................................11
Internet Settings .........................................................................................................................................................................14
Wireless Connection ................................................................................................................................................................19
Turning the wireless network On/O /& Reset Router .................................................................................................24
Change the Username & Password for Internet access ................................................................................................25
Equipment Guarantee ..............................................................................................................................................................26
Online Security ............................................................................................................................................................................26
Connection Elements ...............................................................................................................................................................27
1 Pentium 4 Processor
2 Windows XP/Vista/7 or Mac OS 9.x
3 1 GB RAM
4 25 MB free hard disk space
5 10/100 Mbps Ethernet Network Card
Contents
Minimum System Requirements

Minimum System Requirements............................................................................................................................................. 3
Package Contents ........................................................................................................................................................................ 4
LEDs ................................................................................................................................................................................................... 5
Ports .................................................................................................................................................................................................. 6
Connecting the ADSL2+ Router ............................................................................................................................................. 7
PSTN Line ................................................................................................................................................................................ 8
ISDN Line ...............................................................................................................................................................................11
Internet Settings .........................................................................................................................................................................14
Wireless Connection ................................................................................................................................................................19
Turning the wireless network On/O /& Reset Router .................................................................................................24
Change the Username & Password for Internet access ................................................................................................25
Equipment Guarantee ..............................................................................................................................................................26
Online Security ............................................................................................................................................................................26
Connection Elements ...............................................................................................................................................................27
1 Pentium 4 Processor
2 Windows XP/Vista/7 or Mac OS 9.x
3 1 GB RAM
4 25 MB free hard disk space
5 10/100 Mbps Ethernet Network Card
Contents
Minimum System Requirements

1 ADSL2+ Wireless Router
1 Installation CD
Installation Instructions
2 Telephone Cables (RJ-11)
LED
The following LEDs are found on the front side of the ADSL2+ Router.
Review the meaning of each LED below (Figure 1).
Color Status
On
Figure 1
O
Blinking
On
O
Blinking
On
O
Blinking
On
O
Blinking
On
O
Connection established
Connection is not established
Connection being established
Connection established
Connection is not established
Data is transferred over Ethernet
Ethernet connection is established
Ethernet connection is not established
• WAN connection is established
• Data is being transferred
• WAN connection is established
• No data is transferred
WAN connection is not established
• Wireless network mode is being activated
• Data is being transferred over WLAN
• Wireless network mode is active
• No data is being transferred over WLAN
• Wireless network mode is inactive
Meaning
1 Ethernet Cable (RJ-45)
1 Power Transformer
1 Splitter
1 Filter (for PSTN)
Installation Instructions
Wireless ADSL2+ Router
Huawei HG530 / HG530u
Package Contents
LEDs

1 ADSL2+ Wireless Router
1 Installation CD
Installation Instructions
2 Telephone Cables (RJ-11)
LED
The following LEDs are found on the front side of the ADSL2+ Router.
Review the meaning of each LED below (Figure 1).
Color Status
On
Figure 1
O
Blinking
On
O
Blinking
On
O
Blinking
On
O
Blinking
On
O
Connection established
Connection is not established
Connection being established
Connection established
Connection is not established
Data is transferred over Ethernet
Ethernet connection is established
Ethernet connection is not established
• WAN connection is established
• Data is being transferred
• WAN connection is established
• No data is transferred
WAN connection is not established
• Wireless network mode is being activated
• Data is being transferred over WLAN
• Wireless network mode is active
• No data is being transferred over WLAN
• Wireless network mode is inactive
Meaning
1 Ethernet Cable (RJ-45)
1 Power Transformer
1 Splitter
1 Filter (for PSTN)
Installation Instructions
Wireless ADSL2+ Router
Huawei HG530 / HG530u
Package Contents
LEDs

The ADSL2+ Router has the following buttons and ports (Figure 2):
PORT LABEL DESCRIPTION OPERATION
POWER Power Port This port is used for
the 220V power transformer
RESETFactory setting reset button Resets factory settings
LAN 4 (STB) Ethernet Port for decoder Connects to OTE’s Cable Television
over Internet Service
LAN 1-3 Ethernet Ports
for PC connection
They allow for the connection of
up to three PCs for access to the Internet
and local network creation
ADSL Port for telephone
cable connection
Connects to the telephone socket
or the splitter
WLAN WLAN Button It turns the WLAN on/o
ON/OFFPower button It is used to power the device on/o
Figure 2
Follow the following instructions to connect the ADSL2+ Router
over a PSTN or ISDN telephone line.
Connecting the ADSL2+ Router
Ports
Connecting the ADSL2+ Router

The ADSL2+ Router has the following buttons and ports (Figure 2):
PORT LABEL DESCRIPTION OPERATION
POWER Power Port This port is used for
the 220V power transformer
RESETFactory setting reset button Resets factory settings
LAN 4 (STB) Ethernet Port for decoder Connects to OTE’s Cable Television
over Internet Service
LAN 1-3 Ethernet Ports
for PC connection
They allow for the connection of
up to three PCs for access to the Internet
and local network creation
ADSL Port for telephone
cable connection
Connects to the telephone socket
or the splitter
WLAN WLAN Button It turns the WLAN on/o
ON/OFFPower button It is used to power the device on/o
Figure 2
Follow the following instructions to connect the ADSL2+ Router
over a PSTN or ISDN telephone line.
Connecting the ADSL2+ Router
Ports
Connecting the ADSL2+ Router

PSTN Line
If you have a PSTN
telephone line (plain analog line),
connect the ADSL2+ Router
as shown below.
Using the blue cable, connect the blue port
on the splitter to the telephone socket.
Use the yellow cable to connect the network port (ETHERNET)
of your computer to one of the three rst yellow ports on the
Conn-x equipment.
WARNING: The purple port labeled STB is used exclusively to
connect the set-top-box required to receive OTE's Cable Television
over Internet service.
A. Use the grey cable to connect the grey
port on the splitter to the grey port on
the Conn-x equipment.
B. Next, connect the cable of your telephone
device to the black port on the splitter.
If you have a telephone set connected to the telephone socket,
you must disconnect it.
PSTN Line

PSTN Line
If you have a PSTN
telephone line (plain analog line),
connect the ADSL2+ Router
as shown below.
Using the blue cable, connect the blue port
on the splitter to the telephone socket.
Use the yellow cable to connect the network port (ETHERNET)
of your computer to one of the three rst yellow ports on the
Conn-x equipment.
WARNING: The purple port labeled STB is used exclusively to
connect the set-top-box required to receive OTE's Cable Television
over Internet service.
A. Use the grey cable to connect the grey
port on the splitter to the grey port on
the Conn-x equipment.
B. Next, connect the cable of your telephone
device to the black port on the splitter.
If you have a telephone set connected to the telephone socket,
you must disconnect it.
PSTN Line

PSTN Line
ISDN Line
Connect the power transformer to the power port on the
Conn-x equipment and plug it to the mains socket.
Press the ON/OFF power button located on the side of the
equipment, to turn on your equipment.
The Power, ADSL, Internet, LΑΝ and WLAN LEDs will light.
To connect additional telephone sets to other sockets, each set
must be connected to a lter. Connect your telephone set to the
lter and the lter to the socket.
Note: If your telephone network is connected to any device
(alarm, telephone exchange, etc.), you must use an additional
ADSL lter or splitter. Please contact a specialized installer.
If you have an ISDN telephone line,
connect the ADSL2+ Router
as shown below.

PSTN Line
ISDN Line
Connect the power transformer to the power port on the
Conn-x equipment and plug it to the mains socket.
Press the ON/OFF power button located on the side of the
equipment, to turn on your equipment.
The Power, ADSL, Internet, LΑΝ and WLAN LEDs will light.
To connect additional telephone sets to other sockets, each set
must be connected to a lter. Connect your telephone set to the
lter and the lter to the socket.
Note: If your telephone network is connected to any device
(alarm, telephone exchange, etc.), you must use an additional
ADSL lter or splitter. Please contact a specialized installer.
If you have an ISDN telephone line,
connect the ADSL2+ Router
as shown below.

ISDN Line
ISDN Line
Disconnect the cable that connects the telephone
set to the ISDN equipment (N.T. 1) from the telephone
socket and connect it to the black port on the splitter.
Use the yellow cable to connect the network port (ETHERNET)
of your computer to one of the three rst yellow ports on the
Conn-x equipment.
WARNING: The purple port labeled STB is used exclusively to
connect the set-top-box required to receive OTE's Cable Television
over Internet service.
Connect the power transformer to the power port on the
Conn-x equipment and plug it to the mains socket.
Press the ON/OFF power button located on the side of the
equipment, to turn on your equipment.
The Power, ADSL, Internet, LΑΝ and WLAN LEDs will light.
Note: If your telephone network is connected to any device
(alarm, telephone exchange, etc.), you must use an additional
ADSL lter or splitter. Please contact a specialized installer.
A. Using the blue cable, connect the blue port on the
splitter to the telephone socket.
B. Next, use the grey cable to connect the grey port
on the splitter to the grey port on the Conn-x equipment.

ISDN Line
ISDN Line
Disconnect the cable that connects the telephone
set to the ISDN equipment (N.T. 1) from the telephone
socket and connect it to the black port on the splitter.
Use the yellow cable to connect the network port (ETHERNET)
of your computer to one of the three rst yellow ports on the
Conn-x equipment.
WARNING: The purple port labeled STB is used exclusively to
connect the set-top-box required to receive OTE's Cable Television
over Internet service.
Connect the power transformer to the power port on the
Conn-x equipment and plug it to the mains socket.
Press the ON/OFF power button located on the side of the
equipment, to turn on your equipment.
The Power, ADSL, Internet, LΑΝ and WLAN LEDs will light.
Note: If your telephone network is connected to any device
(alarm, telephone exchange, etc.), you must use an additional
ADSL lter or splitter. Please contact a specialized installer.
A. Using the blue cable, connect the blue port on the
splitter to the telephone socket.
B. Next, use the grey cable to connect the grey port
on the splitter to the grey port on the Conn-x equipment.

Internet Settings
Internet Settings
To install the ADSL2+ Router, insert the CD in the CD-ROM drive.
The CD must start automatically. If the CD fails to start automatically,
go to Windows Explorer, select the CD-ROM drive where the CD is
located, double click on setup.exe and follow the instructions.
If you cannot install the ADSL2+ Router using the installation CD,
follow the instructions given below:
Internet Settings
Open your Browser.
At the address line type
http://192.168.1.1
and press Enter.
The screen shown on the
side will appear:
The ADSL, ATM, and Internet
Status LEDs must be green.
If one of the LEDs is red,
check the connections and
try again.

Internet Settings
Internet Settings
To install the ADSL2+ Router, insert the CD in the CD-ROM drive.
The CD must start automatically. If the CD fails to start automatically,
go to Windows Explorer, select the CD-ROM drive where the CD is
located, double click on setup.exe and follow the instructions.
If you cannot install the ADSL2+ Router using the installation CD,
follow the instructions given below:
Internet Settings
Open your Browser.
At the address line type
http://192.168.1.1
and press Enter.
The screen shown on the
side will appear:
The ADSL, ATM, and Internet
Status LEDs must be green.
If one of the LEDs is red,
check the connections and
try again.

Internet Settings
Internet Settings
Click on Administration.
The screen shown on
the side will appear:
Enter admin in the Username eld. In the Password eld
enter the password you will nd on the label on the back
of your ADSL2+ Router and click on ΟΚ.
Note the Username and Password on the last page of the
brochure.

Internet Settings
Internet Settings
Click on Administration.
The screen shown on
the side will appear:
Enter admin in the Username eld. In the Password eld
enter the password you will nd on the label on the back
of your ADSL2+ Router and click on ΟΚ.
Note the Username and Password on the last page of the
brochure.

Internet Settings
Wireless Connection
The screen shown on the
side will appear:
In the Username eld
enter the username you
were given at the time
of purchase of your
Conn-x package
followed by @otenet.gr
In the Password eld
enter the password you
were given at the time
of purchase of your
Conn-x package. Click on
Apply to save the settings.
Now you are connected
to the Internet!
Close the Browser.
Follow the instructions below to connect wirelessly to the Internet.
Wireless Connection

Internet Settings
Wireless Connection
The screen shown on the
side will appear:
In the Username eld
enter the username you
were given at the time
of purchase of your
Conn-x package
followed by @otenet.gr
In the Password eld
enter the password you
were given at the time
of purchase of your
Conn-x package. Click on
Apply to save the settings.
Now you are connected
to the Internet!
Close the Browser.
Follow the instructions below to connect wirelessly to the Internet.
Wireless Connection

Wireless Connection
Wireless Connection
To connect wirelessly to the Internet you must have completed the Internet Settings.
If you wish to connect from a desktop computer, you must have installed and activated the
wireless USB stick or wireless network card on your computer.
If you wish to connect wirelessly from a laptop you must have activated the wireless mode
(see the user manual that came with your laptop).
For easier installation, it is recommended to keep the factory settings. You can change them
later using the wireless network settings menu (see the user manual on the CD).
Double click on the wireless network icon on your computer to display
available wireless networks.
