Huawei AR530 Series User manual

Huawei AR530&AR550 Series Industrial Switch
Routers
V200R005C70
Configuration Guide - Device
Management
Issue 01
Date 2014-11-30
HUAWEI TECHNOLOGIES CO., LTD.

Copyright © Huawei Technologies Co., Ltd. 2014. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior written
consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei and the
customer. All or part of the products, services and features described in this document may not be within the
purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information,
and recommendations in this document are provided "AS IS" without warranties, guarantees or representations
of any kind, either express or implied.
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website: http://enterprise.huawei.com
Issue 01 (2014-11-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
i

About This Document
Intended Audience
This document provides the basic concepts, configuration procedures, and configuration
examples in different application scenarios of the device management feature supported by the
device.
This document describes how to configure the device management feature.
This document is intended for:
lData configuration engineers
lCommissioning engineers
lNetwork monitoring engineers
lSystem maintenance engineers
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol Description
Indicates an imminently hazardous situation
which, if not avoided, will result in death or
serious injury.
Indicates a potentially hazardous situation
which, if not avoided, could result in death or
serious injury.
Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderate injury.
Indicates a potentially hazardous situation
which, if not avoided, could result in
equipment damage, data loss, performance
deterioration, or unanticipated results.
NOTICE is used to address practices not
related to personal injury.
Huawei AR530&AR550 Series Industrial Switch Routers
Configuration Guide - Device Management About This Document
Issue 01 (2014-11-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
ii

Symbol Description
NOTE
Calls attention to important information, best
practices and tips.
NOTE is used to address information not
related to personal injury, equipment damage,
and environment deterioration.
Command Conventions
The command conventions that may be found in this document are defined as follows.
Convention Description
Boldface The keywords of a command line are in boldface.
Italic Command arguments are in italics.
[ ] Items (keywords or arguments) in brackets [ ] are optional.
{ x | y | ... } Optional items are grouped in braces and separated by
vertical bars. One item is selected.
[ x | y | ... ] Optional items are grouped in brackets and separated by
vertical bars. One item is selected or no item is selected.
{ x | y | ... }*Optional items are grouped in braces and separated by
vertical bars. A minimum of one item or a maximum of all
items can be selected.
[ x | y | ... ]*Optional items are grouped in brackets and separated by
vertical bars. Several items or no item can be selected.
&<1-n> The parameter before the & sign can be repeated 1 to n times.
# A line starting with the # sign is comments.
Interface Numbering Conventions
Interface numbers used in this manual are examples. In device configuration, use the existing
interface numbers on devices.
Security Conventions
lPassword setting
Huawei AR530&AR550 Series Industrial Switch Routers
Configuration Guide - Device Management About This Document
Issue 01 (2014-11-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
iii

–When configuring a password, the cipher text is recommended. To ensure device
security, change the password periodically.
–When you configure a password in plain text that starts and ends with %@%@ (the
password can be decrypted by the device), the password is displayed in the same manner
as the configured one in the configuration file. Do not use this setting.
–When you configure a password in cipher text, different features cannot use the same
cipher-text password. For example, the cipher-text password set for the AAA feature
cannot be used for other features.
lEncryption algorithm
Currently, the device uses the following encryption algorithms: 3DES, AES, RSA, SHA1,
SHA2, and MD5. 3DES, RSA and AES are reversible, while SHA1, SHA2, and MD5 are
irreversible. The encryption algorithms DES/3DES/RSA (RSA-1024 or lower)/MD5 (in
digital signature scenarios and password encryption)/SHA1 (in digital signature scenarios)
have a low security, which may bring security risks. If protocols allowed, using more secure
encryption algorithms, such as AES/RSA (RSA-2048 or higher)/SHA2/HMAC-SHA2, is
recommended. The encryption algorithm depends on actual networking. The irreversible
encryption algorithm must be used for the administrator password, SHA2 is recommended.
lPersonal data
Some personal data may be obtained or used during operation or fault location of your
purchased products, services, features, so you have an obligation to make privacy policies
and take measures according to the applicable law of the country to protect personal data.
lThe terms mirrored port, port mirroring, traffic mirroring, and mirroing in this manual are
mentioned only to describe the product's function of communication error or failure
detection, and do not involve collection or processing of any personal information or
communication data of users.
Change History
Changes between document issues are cumulative. Therefore, the latest document version
contains all updates made to previous versions.
Changes in Issue 01 (2014-11-30)
Initial commercial release.
Huawei AR530&AR550 Series Industrial Switch Routers
Configuration Guide - Device Management About This Document
Issue 01 (2014-11-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
iv

Contents
About This Document.....................................................................................................................ii
1 Displaying the Device Status......................................................................................................1
1.1 Displaying Information About the device......................................................................................................................2
1.2 Displaying the ESN........................................................................................................................................................2
1.3 Displaying Versions.......................................................................................................................................................2
1.4 Displaying the Temperature...........................................................................................................................................3
1.5 Displaying CPU Usage...................................................................................................................................................3
1.6 Displaying Memory Usage.............................................................................................................................................4
1.7 Displaying Interface Status.............................................................................................................................................4
1.8 Displaying Electronic Labels..........................................................................................................................................5
1.9 Displaying the Current Configuration............................................................................................................................5
1.10 Displaying Diagnostic Information..............................................................................................................................6
1.11 Displaying Health Status..............................................................................................................................................6
2 Hardware Management................................................................................................................7
2.1 Hardware Management Overview..................................................................................................................................8
2.2 Configuring the Alarm Function for Optical Modules...................................................................................................8
2.3 Configuring the CPU Usage Alarm Threshold...............................................................................................................9
2.4 Configuring the Memory Usage Alarm Threshold.......................................................................................................10
2.5 Backing Up Electronic Labels......................................................................................................................................11
3 Information Center Configuration...........................................................................................12
3.1 Information Center Overview.......................................................................................................................................13
3.2 Principles......................................................................................................................................................................13
3.2.1 Information Classification.........................................................................................................................................13
3.2.2 Information Hierarchy...............................................................................................................................................14
3.2.3 Information Output....................................................................................................................................................15
3.2.4 Information Filtering.................................................................................................................................................16
3.2.5 Information Output Format.......................................................................................................................................17
3.3 Applications..................................................................................................................................................................19
3.4 Default Configuration...................................................................................................................................................21
3.5 Configuring Information Center...................................................................................................................................23
3.5.1 Configuring Log Output............................................................................................................................................23
Huawei AR530&AR550 Series Industrial Switch Routers
Configuration Guide - Device Management Contents
Issue 01 (2014-11-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
v

3.5.1.1 Enabling the Information Center............................................................................................................................24
3.5.1.2 (Optional) Naming an Information Channel..........................................................................................................25
3.5.1.3 (Optional) Configuring Log Filtering.....................................................................................................................25
3.5.1.4 (Optional) Setting the Timestamp Format of Logs ...............................................................................................26
3.5.1.5 Configuring the Device to Output Logs to the Log Buffer....................................................................................27
3.5.1.6 Configuring the Device to Output Logs to a Log File............................................................................................27
3.5.1.7 Configuring the Device to Output Logs to the Console.........................................................................................29
3.5.1.8 Configuring the Device to Output Logs to a Terminal...........................................................................................29
3.5.1.9 Configuring the Device to Output Logs to a Log Host..........................................................................................30
3.5.1.10 Checking the Configuration..................................................................................................................................31
3.5.2 Configuring Trap Output...........................................................................................................................................32
3.5.2.1 Enabling the Information Center............................................................................................................................33
3.5.2.2 (Optional) Naming an Information Channel..........................................................................................................34
3.5.2.3 (Optional) Configuring Trap Filtering....................................................................................................................34
3.5.2.4 (Optional) Setting the Timestamp Format of Traps...............................................................................................35
3.5.2.5 Configuring the Device to Output Traps to the Trap Buffer..................................................................................36
3.5.2.6 Configuring the Device to Output Traps to a Log File...........................................................................................36
3.5.2.7 Configuring the Device to Output Traps to the Console........................................................................................38
3.5.2.8 Configuring the Device to Output Traps to a Terminal..........................................................................................38
3.5.2.9 Configuring the Device to Output Traps to a Log Host.........................................................................................39
3.5.2.10 Checking the Configuration..................................................................................................................................40
3.5.3 Configuring Debugging Message Output..................................................................................................................41
3.5.3.1 Enabling the Information Center............................................................................................................................42
3.5.3.2 (Optional) Naming an Information Channel..........................................................................................................43
3.5.3.3 (Optional) Setting the Timestamp Format of Debugging Messages......................................................................44
3.5.3.4 Configuring the Device to Output Debugging Messages to the Log File..............................................................44
3.5.3.5 Configuring the Device to Output Debugging Messages to the Console...............................................................45
3.5.3.6 Configuring the Device to Output Debugging Messages to the Terminal.............................................................46
3.5.3.7 Configuring the Device to Output Debugging Messages to the Log Host.............................................................47
3.5.3.8 Checking the Configuration....................................................................................................................................48
3.6 Maintaining the Information Center.............................................................................................................................48
3.6.1 Clearing Statistics......................................................................................................................................................48
3.6.2 Monitoring the Information Center...........................................................................................................................49
3.7 Configuration Examples...............................................................................................................................................49
3.7.1 Example for Outputting Logs to the Log File...........................................................................................................49
3.7.2 Example for Outputting Logs to a Log Host.............................................................................................................51
3.7.3 Example for Outputting Traps to the Console...........................................................................................................54
4 NTP Configuration......................................................................................................................56
4.1 NTP Overview..............................................................................................................................................................57
4.2 Principles......................................................................................................................................................................58
4.2.1 Operating Principle....................................................................................................................................................58
Huawei AR530&AR550 Series Industrial Switch Routers
Configuration Guide - Device Management Contents
Issue 01 (2014-11-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
vi

4.2.2 Network Architecture................................................................................................................................................60
4.2.3 Operating Mode.........................................................................................................................................................61
4.2.4 NTP Access Control..................................................................................................................................................66
4.3 Application...................................................................................................................................................................67
4.4 Default Configuration...................................................................................................................................................69
4.5 Configuring the NTP....................................................................................................................................................69
4.5.1 Configuring Basic NTP Functions............................................................................................................................69
4.5.1.1 Configuring an NTP primary clock........................................................................................................................70
4.5.1.2 Configuring NTP Operating Modes.......................................................................................................................71
4.5.1.3 Checking the Configuration....................................................................................................................................76
4.5.2 Configuring the Local Source Interface for Sending and Receiving NTP Packets...................................................77
4.5.3 Limit on the Number of Local Dynamic Sessions....................................................................................................77
4.5.4 Configuring NTP Access Control..............................................................................................................................78
4.5.4.1 Disabling a Specified Interface from Receiving NTP Packets...............................................................................78
4.5.4.2 Disabling the NTP Service Function......................................................................................................................79
4.5.4.3 Configuring NTP Access Control Authority..........................................................................................................80
4.5.4.4 Configuring KOD...................................................................................................................................................82
4.5.4.5 Configuring NTP Authentication...........................................................................................................................83
4.5.4.6 Checking the Configuration....................................................................................................................................84
4.6 Maintaining NTP..........................................................................................................................................................84
4.6.1 Monitoring the Running Status of NTP.....................................................................................................................84
4.7 Configuration Examples...............................................................................................................................................85
4.7.1 Example for Configuring Authenticated NTP Unicast Server/Client Mode.............................................................85
4.7.2 Example for Configuring NTP Symmetric Peer Mode.............................................................................................89
4.7.3 Example for Configuring Authenticated NTP Broadcast Mode................................................................................92
4.7.4 Example for Configuring NTP Multicast Mode........................................................................................................95
4.8 Reference......................................................................................................................................................................98
5 Fault Management Configuration............................................................................................99
5.1 Introduction to Fault Management.............................................................................................................................100
5.2 Principles....................................................................................................................................................................100
5.2.1 Concepts..................................................................................................................................................................100
5.2.2 Principles.................................................................................................................................................................101
5.2.3 Alarm Severity.........................................................................................................................................................101
5.2.4 Alarm Correlation....................................................................................................................................................102
5.3 Default Configuration.................................................................................................................................................103
5.4 Configuring Fault Management..................................................................................................................................103
5.4.1 Configuring Alarm Management.............................................................................................................................103
5.4.1.1 Setting the Alarm Severity...................................................................................................................................104
5.4.1.2 Configuring the Alarm Reporting Delay Function...............................................................................................105
5.4.1.3 Checking the Configuration..................................................................................................................................106
5.4.2 Configuring the Event Reporting Delay Function...................................................................................................106
Huawei AR530&AR550 Series Industrial Switch Routers
Configuration Guide - Device Management Contents
Issue 01 (2014-11-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
vii

5.5 Maintenance................................................................................................................................................................107
5.5.1 Clearing Alarms and Events....................................................................................................................................107
5.5.2 Monitoring Alarms and Events................................................................................................................................108
5.6 References..................................................................................................................................................................108
Huawei AR530&AR550 Series Industrial Switch Routers
Configuration Guide - Device Management Contents
Issue 01 (2014-11-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
viii

1 Displaying the Device Status
About This Chapter
This chapter describes the functions of display commands and how to use the display commands
to view the device running status.
1.1 Displaying Information About the device
You can use the display commands to view component information about the device.
1.2 Displaying the ESN
You can use the display commands to view the ESN.
1.3 Displaying Versions
You can use the display commands to view version information about the device.
1.4 Displaying the Temperature
You can use the display commands to view the temperature of the device.
1.5 Displaying CPU Usage
You can use the display commands to view CPU usage statistics and configurations.
1.6 Displaying Memory Usage
You can use the display commands to view memory usage statistics and threshold.
1.7 Displaying Interface Status
You can use the display commands to view the configuration and status of a specified interface.
1.8 Displaying Electronic Labels
You can use the display commands to view electronic labels.
1.9 Displaying the Current Configuration
You can use the display commands to view the current configuration of the device.
1.10 Displaying Diagnostic Information
You can use the display commands to view diagnostic information for fault location.
1.11 Displaying Health Status
You can use the display commands to view the health status of the device.
Huawei AR530&AR550 Series Industrial Switch Routers
Configuration Guide - Device Management 1 Displaying the Device Status
Issue 01 (2014-11-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1

1.1 Displaying Information About the device
You can use the display commands to view component information about the device.
Context
When a fault occurs on the device, you can view device information to check whether the device
is working properly.
Procedure
lRun
display device [ slot slot-id ]
The component information and device status are displayed.
----End
1.2 Displaying the ESN
You can use the display commands to view the ESN.
Context
A device has a unique Equipment Serial Number (ESN). During the request for a license, the
ESN is required.
Procedure
lRun:
display esn
The ESN of the device is displayed.
----End
1.3 Displaying Versions
You can use the display commands to view version information about the device.
Context
You can view version information about the device to determine whether the device needs to be
upgraded or whether the upgrade succeeds.
Procedure
lRun:
display version [ slot slot-id ]
Huawei AR530&AR550 Series Industrial Switch Routers
Configuration Guide - Device Management 1 Displaying the Device Status
Issue 01 (2014-11-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
2

The version information of the device is displayed.
----End
1.4 Displaying the Temperature
You can use the display commands to view the temperature of the device.
Context
A high or low temperature may damage the hardware. To learn about the temperature of the
device, use the display commands to view the temperature.
Procedure
lRun:
display temperature { all | slot slot-id }
The temperature of the device is displayed.
----End
1.5 Displaying CPU Usage
You can use the display commands to view CPU usage statistics and configurations.
Context
CPU usage is an important index to evaluate device performance. A high CPU usage will cause
service faults, for example, BGP route flapping, frequent VRRP active/standby switchover, and
even failed device login. You can use the display commands to view CPU usage statistics and
configurations to check whether devices are working properly.
CPU usage configurations include the CPU usage alarm threshold and recovery threshold.
lWhen CPU usage reaches the alarm threshold, the system generates a CPU usage alarm.
lWhen CPU usage falls within the recovery threshold, the system generates a clear alarm.
Procedure
lRun:
display cpu-usage
The CPU usage statistics of the main control board is displayed.
lRun:
display cpu-usage configuration
The CPU usage configurations of the main control board are displayed.
----End
Huawei AR530&AR550 Series Industrial Switch Routers
Configuration Guide - Device Management 1 Displaying the Device Status
Issue 01 (2014-11-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
3

1.6 Displaying Memory Usage
You can use the display commands to view memory usage statistics and threshold.
Context
Memory usage is an important index to evaluate device performance. A high memory usage will
cause service faults. You can use the display commands to view memory usage to check whether
devices are working properly.
You can view the memory usage alarm threshold to learn about the conditions for triggering
alarms.
lWhen memory usage reaches the alarm threshold, the system generates an alarm.
lWhen memory usage falls within the alarm threshold, the system generates a clear alarm.
Procedure
lRun:
display memory-usage
The memory usage statistics is displayed.
lRun:
display memory-usage threshold [ all ]
The memory usage threshold is displayed.
----End
1.7 Displaying Interface Status
You can use the display commands to view the configuration and status of a specified interface.
Context
View the configuration of an interface.
lAfter performing operations in a interface view, you can view the configuration about this
interface to check whether the configuration is correct.
View the status of an interface.
lYou can view the status of an interface to monitor the interface or locate interface faults.
Procedure
lView the configuration of a specified interface.
1. Run:
system-view
The system view is displayed.
2. Run:
interface interface-type interface-number
Huawei AR530&AR550 Series Industrial Switch Routers
Configuration Guide - Device Management 1 Displaying the Device Status
Issue 01 (2014-11-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
4

The interface view is displayed.
3. Run:
display this
The configuration of the current interface is displayed.
lView the status of an interface using either of the following methods.
Method 1:
1. Run:
display interface [ interface-type [ interface-number ] ]
The status of the specified interface is displayed.
Method 2:
1. Run:
system-view
The system view is displayed.
2. Run:
interface interface-type interface-number
The interface view is displayed.
3. Run:
display this interface
The status of the specified interface is displayed.
----End
1.8 Displaying Electronic Labels
You can use the display commands to view electronic labels.
Context
Electronic labels identify the hardware of devices.
Procedure
lRun:
display elabel [ slot-id ] [ brief ]
The electronic labels of the device is displayed.
----End
1.9 Displaying the Current Configuration
You can use the display commands to view the current configuration of the device.
Context
To learn about services currently running on the device, run the following command to view the
device configuration.
Huawei AR530&AR550 Series Industrial Switch Routers
Configuration Guide - Device Management 1 Displaying the Device Status
Issue 01 (2014-11-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5

Procedure
lRun:
display current-configuration
The information of the current configuration is displayed.
----End
1.10 Displaying Diagnostic Information
You can use the display commands to view diagnostic information for fault location.
Context
When a fault occurs in the system or during routine maintenance, you can run the display
commands to collect the running information about all modules.
NOTICE
Viewing diagnostic information helps locate faults but may affect system performance. For
example, CPU usage may become high. Therefore, do not view diagnostic information when
the system is running properly.
Procedure
lRun:
display diagnostic-information [ file-name ]
The diagnostic information is displayed.
----End
1.11 Displaying Health Status
You can use the display commands to view the health status of the device.
Context
To learn about the device temperature, power supply, fan information, power, CPU usage,
memory usage, and storage medium, use the fallowing command to view the health status.
Procedure
lRun:
display health
The health status of the device is displayed.
----End
Huawei AR530&AR550 Series Industrial Switch Routers
Configuration Guide - Device Management 1 Displaying the Device Status
Issue 01 (2014-11-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
6

2 Hardware Management
About This Chapter
Scientific hardware management reduces the operations performed on hardware resources,
including inserting, removing, installing and uninstalling the hardware, and improves hardware
resource reliability.
2.1 Hardware Management Overview
Scientific hardware management allows you to use commands to operate and manage hardware
resources, for example, reset boards, back up electronic labels, and power on or off the hardware
resources.
2.2 Configuring the Alarm Function for Optical Modules
You can choose an appropriate alarm mode for optical modules.
2.3 Configuring the CPU Usage Alarm Threshold
You can configure the CPU usage alarm threshold to monitor CPU usage.
2.4 Configuring the Memory Usage Alarm Threshold
You can configure the memory usage alarm threshold to monitor memory usage.
2.5 Backing Up Electronic Labels
Backing up electronic labels helps improve efficiency in network maintenance.
Huawei AR530&AR550 Series Industrial Switch Routers
Configuration Guide - Device Management 2 Hardware Management
Issue 01 (2014-11-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
7

2.1 Hardware Management Overview
Scientific hardware management allows you to use commands to operate and manage hardware
resources, for example, reset boards, back up electronic labels, and power on or off the hardware
resources.
Scientific hardware management reduces the operations performed on hardware resources,
including inserting, removing, installing and uninstalling the hardware, and improves hardware
resource reliability.
2.2 Configuring the Alarm Function for Optical Modules
You can choose an appropriate alarm mode for optical modules.
Context
You can configure the alarm thresholds for the power of optical modules to shield unnecessary
alarms.
To check alarm information, diagnostic information, and manufacturing information about an
optical module, run the display transceiver command.
Procedure
l(Optional) Run:
display transceiver [ interface interface-type interface-number | slot slot-
id ] [ verbose ]
Conventional, manufacturing, and alarm information about the optical module on an
interface is displayed.
lEnable/Disable the optical module alarm function.
1. Run:
system-view
The system view is displayed.
2. Run:
set transceiver-monitoring { enable | disable
The optical module alarm function is enabled or disabled.
By default, the optical module alarm function is enabled.
lConfigure alarm thresholds for optical modules.
1. Run:
system-view
The system view is displayed.
2. Run:
interface interface-type interface-number
The interface view is displayed.
Huawei AR530&AR550 Series Industrial Switch Routers
Configuration Guide - Device Management 2 Hardware Management
Issue 01 (2014-11-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
8

3. Run:
set transceiver { transmit-power | receive-power } { upper-threshold |
lower-threshold } threshold
Upper and lower alarm thresholds are set for the transmit and receive power of optical
modules. When the transmit or receive power of an optical module exceeds the
threshold, an alarm is generated.
lConfigure the interval for reporting optical module alarms.
1. Run:
system-view
The system view is displayed.
2. Run:
set transceiver-monitoring interval interval
The interval for reporting optical module alarms is configured.
By default, optical module alarms are reported every 10 seconds.
----End
2.3 Configuring the CPU Usage Alarm Threshold
You can configure the CPU usage alarm threshold to monitor CPU usage.
Context
The CPU is the core of a device. When the system has a large number of routes, many CPU
resources will be used. This degrades system performance and results in the delay in processing
data or causes high packet loss. During data processing, if the device can generate an alarm when
high CPU usage occurs, you can effectively monitor CPU usage and optimize system
performance to ensure system stability.
lCPU usage alarm threshold
When CPU usage reaches this threshold, the system generates an alarm.
lCPU usage alarm recovery threshold
When CPU usage falls below this threshold, the system clears the alarm.
Procedure
Step 1 (Optional) Run:
display cpu-usage configuration
The CPU usage configurations are displayed.
Step 2 Run:
system-view
The system view is displayed.
Step 3 Run:
set cpu-usage threshold threshold-value [ restore restore-threshold-value ]
The CPU usage alarm threshold and CPU usage alarm recovery threshold are set.
Huawei AR530&AR550 Series Industrial Switch Routers
Configuration Guide - Device Management 2 Hardware Management
Issue 01 (2014-11-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
9

By default, the CPU usage alarm threshold is 80% and the CPU usage alarm recovery threshold
is 75%.
lWhen the CPU usage alarm threshold is lower than 60%, the default CPU usage alarm
recovery threshold is 1% lower than the CPU usage alarm threshold.
lWhen the CPU usage alarm threshold is higher than or equal to 60%, the default CPU usage
alarm recovery threshold is 5% lower than the CPU usage alarm threshold.
----End
2.4 Configuring the Memory Usage Alarm Threshold
You can configure the memory usage alarm threshold to monitor memory usage.
Context
Memory usage is an important indicator used to evaluate device performance. A high memory
usage will cause service faults. During data processing, if the device can generate an alarm when
high memory usage occurs, you can effectively monitor memory usage and optimize system
performance to ensure system stability.
lMemory usage alarm threshold
When memory usage reaches this threshold, the system generates an alarm.
lMemory usage alarm recovery threshold
When memory usage falls below this threshold, the system clears the alarm.
Procedure
Step 1 (Optional) Run:
display memory-usage threshold [ all ]
The memory usage configuration is displayed.
Step 2 Run:
system-view
The system view is displayed.
Step 3 Run:
set memory-usage threshold threshold-value
The memory usage alarm threshold is set.
By default:
lWhen the memory capacity on the interface board is lower than or equal to 128 MB, the
memory usage threshold is 90%.
lWhen the memory capacity on the interface board is higher than 128 MB, the memory usage
threshold is 95%.
----End
Huawei AR530&AR550 Series Industrial Switch Routers
Configuration Guide - Device Management 2 Hardware Management
Issue 01 (2014-11-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
10

2.5 Backing Up Electronic Labels
Backing up electronic labels helps improve efficiency in network maintenance.
Context
Information in electronic labels help locate network faults and replace hardware in batches.
Therefore, backing up electronic labels is important to improving maintenance efficiency.
lIf a network fault occurs, you can rapidly learn about hardware information using electronic
labels, thereby improving hardware maintenance efficiency. In addition, you can efficiently
analyze and trace hardware defects by analyzing information in electronic labels of the
faulty hardware.
lBefore replacing hardware in batches, you can obtain accurate hardware deployment
information based on information in the electronic labels recorded in the archive systems
of customers' devices. Then you can evaluate the impact of hardware replacement and
define policies to efficiently replace hardware in batches.
Electronic labels can be backed up to a file server or the storage media. Before backing up
electronic labels to the file server, ensure that there are reachable routes between the device and
file server. The file server can be an FTPor TFTP server. .
Procedure
lRun:
backup elabel filename [ slot-id ]
Electronic labels are backed up to the storage media.
lRun:
backup elabel ftp ftp-server-address filename username password [ slot-id ]
Electronic labels are backed up to the FTP server.
lRun:
backup elabel tftp tftp-server-address filename [ slot-id ]
Electronic labels are backed up to the TFTP server.
----End
Huawei AR530&AR550 Series Industrial Switch Routers
Configuration Guide - Device Management 2 Hardware Management
Issue 01 (2014-11-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
11
