Quick Start Guide
S2700, S3700, S5700, and S6700 Series Switches
Issue: 34 (2019-12-02)
Part Number:
31504991

Thank you for purchasing a Huawei S series switch. This guide describes how to install S2700, S3700, S5700, and
S6700 series switches. It also explains how to log in to your switch for the first time.
For more information, see the Hardware Installation and Maintenance Guide for your switch on the Huawei
support website.
The installation, cable connection, and login methods for most S series switches are similar. This guide uses the
S5700-24TP-SI-AC as an example.
Figures in the document are for reference only and may be different from actual devices.
Any procedural differences between models are specified at the start of each section.
1 About This Guide
Chassis (with the product model on the nameplate)
Power cable (Power cables are delivered with the
switch if the switch is equipped with built-in power
supply or pluggable power modules, and are delivered
with power modules in other cases.)
Installation accessory package:
- Open Source Software Notice
- Quick Start Guide
- Rubber pads
- Chassis ground cable
- Warranty Card
- Mounting brackets
- Screws
- Dust plugs
The numbers and types of items in the installation accessory package differ for different product models.
Some switches have dust plugs delivered with them. Keep the dust plugs properly and use them to protect idle optical ports.
NOTE
2 Packing List
3 Safety Guidelines
To ensure personal and equipment safety, observe all the safety precautions on the equipment and in this
document. WARNING and CAUTION items do not cover all the safety precautions and are only supplementary
to the safety precautions.
Follow all the safety precautions and instructions provided by Huawei. The safety precautions outlined in this
document are only requirements of Huawei and do not include general safety requirements. Huawei is not
liable for any consequence that results from violation of regulations pertaining to safe operations or safety
codes pertaining to design, production, and equipment use.
This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be
required to take adequate measures.
Take ESD protection measures during equipment installation and maintenance. For example, wear ESD gloves or an ESD wrist
strap.
Do not place other objects on the chassis.
WARNING
CAUTION
Laser beams will cause eye damage. Do not look into bores of optical modules or optical fibers without eye protection.
Do not install power cables while the power is on.
Do not turn on the power until you have finished installing the chassis and connecting cables.
1

2
4 Site Environment
Do not place this product in an environment with flammable or explosive gases, or smoke.
The installation site must be free from leaking or dripping water, heavy dew, and humidity. If the relative
humidity is high, use dehumidifiers or dehumidifying air conditioners.
The installation site must be well ventilated. Ensure that air vents on the equipment are not blocked.
Do not install the equipment in a dusty environment.
Grounding the switch helps protect it from lightning, electromagnetic interference, and electrostatic discharge,
and is the prerequisite for a PoE switch to provide power for a PD.
Leave at least 50 mm clearance at the rear and both sides of the chassis for heat dissipation.
S series switches use forced, intelligent, or natural heat dissipation mode. If multiple switches are installed in a
cabinet/rack, leave at least 1 U (44.45 mm) distance between each two switches. This distance is
recommended for switches using forced or intelligent heat dissipation, and is required for switches using
natural heat dissipation.
Ensure that the temperature and humidity at the installation site meet the switch operation requirements. For
the specific requirements, see the Hardware Description for your switch on the Huawei support website.
Ethernet cables used outdoors must be buried underground or routed through steel pipes to protect the
switch from lightening. Do not route Ethernet cables overhead.
To protect network ports from lightning, use 8-line surge protectors or Huawei certified 4-line surge
protectors. When installing a network port surge protector, connect the IN ports to network devices and
connect the OUT ports to network ports of the switch.
5 Installing the Chassis
Scenario 1: Desk Mounting
S5710-HI, S6700-EI and S6720-HI series switches cannot be desk mounted.
Do not stack fanless switches on top of or closely next to each other.
Some switch models provide a security slot ( ) near the panel on a side of the chassis. You can install a security
lock (separately purchased) in this slot to protect the switch against theft.
Before You Start
Installation Procedure
Attach four rubber pads to the bottom.
Place the chassis on a desk.
Step 1
Step 2
(Optional) Install a security lock.
Connect the ground cable to the ground point.
Step 3
Step 4
Scenario 2: Wall Mounting
Before drilling holes in a wall, make sure there are no power cables in the wall to avoid electric shock.
Before You Start

For a wall-mounted switch (S5720-16X-PWH-LI-AC needs to be installed with the port side facing up), take
water-proofing and dust-proofing measures to protect the switch from damage caused by water and dust.
Ensure that there are no flammable or explosive materials near the switch and no obstructions within 100 mm
around the switch.
S3700-HI, S5700-HI, S6720S-EI, and other 420 mm or deeper switches cannot be wall mounted.
The expansion bolts need to be purchased separately.
Use a hammer drill with φ8 drill bit to drill holes
on the wall, and fix the switch on the wall with
expansion bolts.
Connect the ground cable to the ground point.
Step 2
Step 3
Step 1 Use M4 screws to fix the mounting brackets on both sides close to the port side.
Expansion bolt
Port side faces down
Installation Procedure
3
Scenario 3: Top Wall Mounting
Before drilling holes in a wall, make sure there are no power cables in the wall to avoid electric shock.
Only the S5720-16X-PWH-LI-AC can be installed on the top wall.
Expansion bolts and top-mounting brackets must be self-provided.
360 mm
180 mm
Before You Start
Installation Procedure
Mark the positions to drill holes according to the switch's size and positions of top-mounting brackets.
Use M4 screws to attach two top-mounting brackets to the switch.
Use a hammer drill (with φ8 drill bit) to drill holes, and use expansion bolts to secure the switch on the top
wall.
Connect the ground cable to the ground point.
Step 1
Step 2
Step 3
Step 4

When a chassis uses Category-6 or higher Ethernet cables, the distance between the port side and interior side
of the cabinet door must be larger than or equal to 120 mm.
Switches cannot be installed in a 600 mm deep cabinet when they are equipped with 1150 W PoE power
modules.
To install a 250 mm wide switch in a 19-inch cabinet, purchase long mounting brackets.
For the 220 mm deep models of the S2700 and S3700 series, and the S5700-24TP-SI-AC/DC, each mounting
bracket needs to be fixed on the chassis with only two screws. For other switch models, each mounting
bracket needs to be fixed with three screws.
The floating nuts and M6 screws are not delivered with the switch and need to be separately purchased if
needed.
S6700-EI chassis is heavy, so it is recommended that you install guide rails (separately purchased) in the cabinet to support the
chassis.
Scenario 4: Cabinet/Rack Mounting
S series Ethernet switches can be installed in a 19-inch standard cabinet/rack. Cabinets purchased from other
vendors must have enough space for equipment installation.
If the distance between front and rear mounting rails is not within the required range, install guide rails or a
tray in the cabinet/rack to support the chassis. Guide rails or trays are not delivered with the product and must
be purchased separately.
Before You Start
4
Ensure a distance of 418–528 mm or 545–655 mm between the front and rear mounting brackets.
Cable management frames are recommended when many cables are used.
Leave 2 U between the floating nuts on each front mounting rail, and 1 U between those on the rear rails. Ensure the lower
floating nut on each mounting rail is level with those on the other mounting rails.
S5710-HI
Connect the ground cable to the switch.
Use M4 screws to attach a mounting bracket delivered with the switch to each side of the switch.
Determine the mounting method according to the brackets delivered with your switch.
Step 1
Step 2
Installation Procedure
19-inch cabinet 19-inch cabinet 19-inch cabinet 19-inch cabinet
19-inch cabinet 19-inch cabinet 19-inch cabinet 21-inch cabinet

S5710-EI S5720-C-EI S5720-PC-EI S5720-SI (420 mm depth) S5720-HI S5730-HI S5730-SI S5730S-EI S6720-SI
S6720S-SI S6720-EI
Ensure a distance of 335–442 mm or 460–570 mm between the front and rear mounting brackets.
Leave 1 U between the floating nuts on each front mounting rail, and 1 U between those on the rear rails. Ensure the lower
floating nut on each mounting rail is level with those on the other mounting rails.
Ensure a distance of 310–351 mm, 369–410 mm, 438–479 mm, or 497–538 mm between the front and rear mounting brackets.
Leave 1 U between the floating nuts on each front mounting rail, and 1 U between those on the rear rails. Ensure the lower
floating nut on each mounting rail is level with those on the other mounting rails.
5
≥1U
1U
3
4
5
M6 screw
Distance between mounting rails:
545-655 mm and 418-528 mm
Distance between mounting rails:
545-655 mm and 418-528 mm
Distance between
mounting rails:
460-570 mm
Distance between
mounting rails:
335-442 mm
Install four floating nuts on the front mounting rails, two on each side.
Hold bottom of the chassis and push the chassis into the cabinet.
Use M6 screws to secure the chassis onto the cabinet/rack.
Connect the ground cable to the ground point on the cabinet.
Step 3
Step 4
Step 5
Step 6
Distance between mounting rails:
310-351 mm and 438-479 mm
Distance between mounting rails:
369-410 mm and 497-538 mm
Distance between
mounting rails:
438-479 mm and
497-538 mm
Distance between
mounting rails:
310-351 mm and
369-410 mm
Distance between mounting rails:
365-442 mm and 495-570 mm
Distance between mounting rails:
335-380 mm and 460-510 mm
Distance between
mounting rails:
460-570 mm
Distance between
mounting rails:
335-442 mm
S5731-H S5731-H-K S5731-S S5731S-S S5731S-H S5732-H S5732-H-K S5735-L (420 mm depth)
S5735S-L (420 mm depth) S5735-S S5735S-S S6720-HI S6730-H S6730S-H S6730-H-K S6730-S S6730S-S

6
6 Installing a Power Module
The installation methods for different power modules are the same.
For information about the power module supported by your model, see Power Module in the Hardware
Description of your switch on the Huawei support website.
All the power modules are hot swappable (except the 870 W PoE power module).
When installing a power module, slowly push it into the slot. If you feel resistance or find the module inclined,
pull the module out and push it into the slot again. Do not push the module with force; otherwise, the
connectors on the module and backplane may be damaged.
If only one power module is installed, install a power module filler panel in the empty power module slot.
It is recommended that you install two power modules in a switch to enhance power reliability if the switch
supports double power modules.
7 Installing Cards
Before You Start
The installation methods for different pluggable cards are the same.
For information about the cards supported by your model, see Cards in the Hardware Description of your
switch on the Huawei support website.
Only switch models S5700-SI, S5710-LI, and S5700-EI do not support hot swappable cards.
Cards that do not support hot swappable cannot be installed when the switch is running. You must power off
the switch, install the cards, and then power on the switch to activate the cards.
To use a front 4xGE or 4x10GE optical interface card on the S5700-SI, S5710-LI and S5700-EI, you must also
install an extended rear card ES5D00ETPB00. Otherwise, only two ports instead of four ports on this optical
interface card are available.
When installing a card, slowly push it into the slot. If you feel resistance or find the card inclined, pull the card
out and push it into the slot again. Do not push the card with force; otherwise, the connectors on the card
and backplane may be damaged.
Install filler panels in vacant slots.
Installation Procedure
Use a Phillips screwdriver to loosen the captive screw on the filler panel.
Pull the filler panel out by the captive screw. Keep the filler panel for future use.
Turn the ejector lever of the card 45 degrees outward. Push the card into the chassis with your thumbs
(below the captive screws), until the screw on the front panel is completely in the chassis. Front cards for
the S3700-HI, S5700-HI, and S5710-HI have no screws, but the installation method is the same.
Rotate the ejector lever inward to lock the card after the screw is completely in the chassis.
Use the Phillips screwdriver to fasten the captive screws.
Step 1
Step 2
Step 3
Step 4
Step 5

7
8 Connecting Cables
Before You Start
Connecting Cables
CONSOLE ETH USB
PWR
RPS
SYS
SPEED
PWR
-12V;5A
ON
OFF
-100-240V;50/60 Hz 1.5A
+
-
Quidway S5700 Series
1 2 3 44 5 6
7
Management
network
2.5 Gbit/s: Ethernet cable of Cat5e or higher category
5 Gbit/s: shielded cable of Cat5e or higher category (unshielded cable not recommended)
10 Gbit/s: shielded cable of Cat6a or higher category
Choose an Ethernet cable for an electrical port depending on the port speed required:
CAUTION
Ground cable
Ethernet cable
Some models provide a Mini USB port to connect to a console for onsite configuration. The Mini USB port and
console port cannot be used together. Select either of them according to your needs. When both the two
ports are connected, only the Mini USB port is active.
The switch must be reliably grounded.
Attach the M4 lug to the switch and the M6 lug to the ground point.
Optical fiber
Optical fibers must be used with optical modules.
The bend radius of optical fibers must be larger than 40 mm.
Power cable
Power cables must be more than 10 cm away from signal cables.
If your switch uses AC power supply, use AC power cables in compliance with local standards.
If your switch uses DC power supply, ensure that the positive and negative cables are connected to the positive and negative
poles correctly.

No.
1 4
2
3
4
5
6
7
Item Connect To No. Item Connect To
Ground cable
AC power cable
Ethernet cable
Ethernet cable
Optical fiber
Ethernet cable
USB port
Console cable
Protection ground
External power source
Switch or PC
Upstream network device
Upstream network device
Operation terminal
(usually a PC)
Operation terminal
(usually a PC)
USB flash drive
8
9.1 Using the Web System for the First Login
9 Logging In to the Switch for the First Time
Before You Start
You can directly connect the PC to the ETH management interface or press and hold down the MODE button
to log in to the device through the web system for the first time:
For a device with the ETH management interface, you can directly connect the PC to the ETH management
interface to log in to the device through the web system for the first time.
For a device with the MODE button, you can press and hold down the MODE button to log in to the device
through the web system for the first time.
The following series switches (running V200R012C00 or a later version) support first login through the web
system by directly connecting the PC to the ETH management interface:
S5700S-X-LI, S5710-X-LI, S5720-SI, S5720S-SI, S5720-EI (only the models with the ETH management
interface), S5720-HI, S5730 series, S5730S series, S5731 series, S5731S series, S5732 series, S5735 series,
S5735S series, S6720 series, S6720S series, S6730 series, S6730S series.
The following series switches support first login through the web system by pressing and holding down the
MODE button:
S2720, S2750, S5700-LI, S5700S-LI, S5720-LI, S5720S-LI, S5710-X-LI, S5720-SI, S5720S-SI, S5720-EI (only the
models with the MODE button), S5720-HI, S5730 series, S5730S series, S5731 series, S5731S series, S5735
series, S5735S series, S6720 (only the models with the MODE button), and S6720S series. To support this
function, the S2750, S5700-LI, S5700S-LI, and S5720-HI must run V200R007C00 or a later version.
The following series switches do not support first login using the web system:
S2700-SI, S2700-EI, S2710-SI, S3700, S5710-C-LI, S5700-SI, S5700-EI, S5710-EI, S5700-HI, S6700-EI and
S5720-EI that does not provide a MODE button (S5720-50X-EI-AC, S5720-50X-EI-DC, S5720-50X-EI-46S-AC,
S5720-50X-EI-46S-DC)
You can use console ports to log in to the switches that do not support first login using the web system for
the first time. For details, see 9.2 Using the Console Port for the First Login.
If the web pages cannot be displayed normally, your web browser may need an upgrade. For details about the
web browser requirements, see the Web-based Configuration Guide of the switch.
The login page may differ slightly in different versions.
Login Procedure
Connect a PC to the device and the device enters the initial configuration mode.
Directly connect the PC to the ETH management interface to log in to the device for the first time.
The default IP address of the ETH management interface on a device is 192.168.1.253/24. Directly connect
the PC to the ETH management interface on the device using network cables.
Step 1
(Mode 1)

Configure an IP address for the computer, which is in the same network segment as the default IP address
of the switch.
Start the web browser on the computer, enter https://192.168.1.253 in the address box, and press Enter to
display the initial login page. Enter the default user name admin and default password [email protected]
and select the language on the login page. Then click GO or press Enter.
Step 2
Step 3
9
Configuration Item
Management IP Address
Mask
Old Password
WEB User Password
Confirm Password
WEB User Level
Description
Mandatory. Enter the management IP address of the switch, in dotted decimal notation.
Mandatory. Select a subnet mask from the drop-down list box.
Mandatory. Enter the old password for the default web user.
Mandatory. Enter a new password for the default web user.
To ensure password strength, the password must contain at least two types of the following:
lowercase letters, uppercase letters, digits, and special characters (such as ! $ # %), and cannot
contain any space or single quotation mark.
Mandatory. Enter the new password again.
Optional. Select a user level from the drop-down list box. The user of level 3 or higher has
management rights.
Hold down the MODE button to log in to the device for the first time.
If all interfaces on the device are optical interfaces, you need to connect the PC to the management
interface using network cables. Press and hold down the MODE button for 6 seconds or longer. When all
indicators on the device are steady green, the device enters the initial configuration mode, and the default
IP address configured for the ETH management interface of the device is 192.168.1.253/24.
If the device has Ethernet interfaces, connect the PC to any Ethernet interface excluding the ETH
management interface using network cables. Press and hold down the MODE button for 6 seconds or
longer. When all indicators on the device are steady green, the device enters the initial configuration
mode, and the default IP address configured for Vlanif1 of the device is 192.168.1.253/24.
(Mode 2)
Users can log in to a device for the first time using the web system only when the device is in factory default state. In this case,
do not log in to the device through the console interface, because any operation on the console interface leads to the failure of
the first login using the web system.
If you do not save the configuration in 10 minutes after entering the initial configuration mode, the system will exit from this
mode and restore the factory settings.
If the device in the factory settings has just started or has been configured through the console interface when users press and
hold down the MODE button for 6 seconds, the device may fail to enter the initial configuration state. When all indicators blink
fast for 10s, the device restores to the factory default state.
If you have logged in to the device for the first time by holding down the MODE button for 6 seconds or longer and saved the
configuration, default configurations of the ETH management interface are cleared and you cannot log in to the device for the
first time through the ETH management interface. You are advised to preferentially log in to the device for the first time through
the ETH management interface.
NOTE

Configure the switch. The web-based configuration page provides basic and optional configuration items.
The basic configuration enables you to log in to the switch using the web system, and the optional
configuration enables you to log in to the switch using Telnet or STelnet. Only parameters for the basic
configuration are described below. For details about the optional configuration and more information
about the product, see the Configuration Guide for your switch on the Huawei support website.
Step 4
Click Apply to save the configuration. When you exit from the initial login page, either of the following
situations will occur depending on the management IP address you configured:
Step 5
If the management IP address is in the same network segment as 192.168.1.253/24, the system jumps to the web login
page directly.
If the management IP address is not in the same network segment as 192.168.1.253/24, you cannot log in to the
switch again using the web system. You need to configure another IP address for your computer to make the computer
and switch reachable from each other.
The Quick Config function has been added to the web EasyOperation edition since V200R010. You can quickly finish
the configurations of VLAN isolation and interconnection by selecting the Switching and Routing options.
Now, you can log in to the switch using the web system, Telnet, or STelnet to maintain the switch.
10
9.2 Using the Console Port for the First Login
The S5700-LI, S5700S-LI, S5710-EI, S5720-EI and S5720-HI series switches also support login through the Mini
USB port. For details about this login method, see the Configuration Guide of the product. This document
describes how to log in to the switch through the console port.
In the S5720-EI series, the S5720-50X-EI-AC, S5720-50X-EI-DC, S5720-50X-EI-46S-AC and
S5720-50X-EI-46S-DC models do not have a Mini USB port.
The console cable is not delivered with the switch and needs to be separately purchased if needed.
The display information may differ on different product models.
Install third-party terminal simulation software on the PC by referring to user manual or online help.
Before You Start

Copyright © Huawei Technologies Co., Ltd. 2019. All rights reserved.
No part of this document may be reproduced or transmitted in
any form or by any means without prior written consent of
Huawei Technologies Co., Ltd.
and other Huawei trademarks are trademarks of
Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned
in this document are the property of their
respective holders.
Supplier’s Declaration of Conformity (SDoC)
Unique Identifier: trade name: HUAWEI; product name: Switch;
model number: S2700&3700&5700&6700 series switches
Responsible Party- U.S. Contact Information
Huawei Technologies USA Inc.
5700 Tennyson Parkway, Suite 500
Plano, Texas 75024
Main: 214-919-6000 / TAC Hotline: [phone]
FCC Compliance Statement ( for products subject to Part 15)
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause
undesired operation.
You can run commands to configure the device. Enter a question mark (?) whenever you need help. For more
information, see the Configuration Guide for your switch on the Huawei support website.
Use a console cable to connect the switch to a PC.
Start the terminal simulation software, create a connection, select a serial port, and set communication
parameters in consistent with the default configuration of the switch's console port, as listed below:
Step 1
Step 2
Press Enter in subsequent steps until the following information is displayed on the terminal simulation
software, and then enter a password. The default user name for the first login is admin and the default
password is [email protected]. You must change the password after login.
Step 3
Login authentication
Username:admin
Password:
Warning: The default password poses security risks.
The password needs to be changed. Change now? [Y/N]: y
Please enter old password:
Please enter new password:
Please confirm new password:
The password has been changed successfully
<HUAWEI>
Login Procedure
Transmission rate: 9600
Data bit (B): 8
Parity bit: None
Stop bit (S): 1
Flow control mode: None
The password entered in interactive mode is not displayed on the screen.
If you do not change the authentication mode and password after entering the user view, the authentication password
used for next login is the one configured during the first login.
11
Log in to Huawei enterprise technical support website (http://support.huawei.com/enterprise),
and select a specific product model and version to find its documentation.
Log in to Huawei enterprise support community
(https://forum.huawei.com/enterprise/en/index.html) and post your questions in the
community.
10 Obtaining Product Documentation and Technical Support
Trademarks and Permissions
Huawei Enterprise
Technical Support
Qualification Card
PASS
