Huawei S5720I-6X-PWH-SI-AC User manual

HUAWEI TECHNOLOGIES CO., LTD.
Quick Start Guide
S5720I-6X-PWH-SI-AC
and S5720I-10X-PWH-SI-AC
Issue: 02 (2018-10-30)
Part Number: 31500ACG

CAUTION
Chassis
Installation accessory package:
Switches can be pole- or wall-mounted outdoors.
The temperature and humidity in the site must be within the operating temperature and humidity ranges
required for the switches. For the operating temperature and relative humidity ranges required for the switches,
see the S5700 Hardware Description.
Grounding the switch helps protect it from lightning, electromagnetic interference, and electrostatic discharge.
For a PoE-capable switch, grounding the switch also ensures that it can properly supply power to powered
devices (PDs).
- Warranty Card - Open Source Software Notice- Quick Start Guide - Screws
- Hose clamps- OT terminals
- Power connector
- Key to the maintenance compartment- Positioning sticker - Installation kit
2 Safety Guidelines
3 Site Environment
To ensure personal and equipment safety, observe all the safety precautions on the equipment and in this
document. WARNING and CAUTION items do not cover all the safety precautions and are only supplementary
to the safety precautions.
Follow all the safety precautions and instructions provided by Huawei. The safety precautions outlined in this
document are only requirements of Huawei and do not include general safety requirements. Huawei is not
liable for any consequence that results from violation of regulations pertaining to safe operations or safety
codes pertaining to design, production, and equipment use.
This is a class A product. In a domestic environment, this product may cause radio interference. In such an environment, the
user is required to take adequate safety measures.
Class A products are products that have received EMC Class A certification.
During equipment transport and installation, prevent the equipment from colliding with objects like doors, walls, or shelves.
4 Surge Protection
1
Network cables used outdoors must be buried underground or routed through steel pipes to protect the
switches from lightening. Do not route network cables overhead.
If the network ports on the switches are connected to devices on a street pole, no surge protector needs to be
installed. If the network ports are connected to devices on a tower, a network port surge protector must be
installed.
To protect network ports from lightning, use 8-line surge protectors or Huawei certified 4-line surge protectors.
When installing a network port surge protector, connect the IN ports to network devices and connect the OUT
ports to network ports of the switches.
If fiber reinforcing ribs are used, ensure that they are properly grounded to protect the switches from lightning.
To prevent the switch or the interconnected device from being damaged, ground the switch before powering it
on. The ground resistance must be less than 10 ohms.
1 Packing List
NOTE
Figures in the document are for reference only and may be different from actual devices.

5 Commissioning the Switch
2
5.1 Using the Web Management System for the First Login
If you do not save the configuration in 10 minutes after entering the initial configuration mode, the system will
exit this mode and restore the factory settings.
If the web pages cannot be displayed normally, your web browser may need an upgrade. For details about the
web browser requirements, see the Web-based Configuration Guide of the switch.
Before You Start
Power on the switch.
Connect your computer to any Ethernet port of the switch using an Ethernet cable.
Hold down the MODE button for 6 seconds or longer. When the PoE mode indicator turns green, the switch
enters the initial configuration mode. In this mode, the IP address of the switch is set to 192.168.1.253/24,
and the admin user level is set to 15 automatically.
Configure an IP address for the computer, which is in the same network segment as the default IP address
of the switch.
Start the web browser on the computer, enter https://192.168.1.253 in the address box, and press Enter to
display the initial login page. Enter the default user name admin and default password [email protected]
and select the language on the login page. Then click GO or press Enter.
Step 1
Step 2
Step 3
Step 4
Step 5
Login Procedure
Configure the switch. The web-based configuration page provides basic and optional configuration items.
The basic configuration enables you to log in to the switch using the web management system, and the
optional configuration enables you to log in to the switch using Telnet or STelnet. Only parameters for the
basic configuration are described below. For details about the optional configuration and more information
about the product, see the Configuration Guide for your switch on the Huawei support website.
Step 6
If the switch needs to be commissioned, do so before it is pole- or wall-mounted.

3
On the web management system, you can access Quick Config and then quickly finish the configurations of VLAN
isolation and interconnection by selecting the Switching and Routing options.
Now, you can log in to the switch using the web management system, Telnet, or STelnet to maintain the switch.
5.2 Using the Console Port for the First Login
Power on the switch.
Use a console cable to connect the switch to a PC.
Start the terminal simulation software, create a connection, select a serial port, and set communication
parameters in consistent with the default configuration of the switch's console port, as listed below:
Step 1
Step 2
Step 3
The console cable is not delivered with the switch and needs to be separately purchased if needed.
The display information may differ on different product models.
Install third-party terminal simulation software on the PC by referring to user manual or online help.
Before You Start
Login Procedure
Configuration Item
Management IP Address
Mask
Old Password
WEB User Password
Confirm Password
WEB User Level
Description
Mandatory. Enter the management IP address of the switch, in dotted decimal notation.
Mandatory. Select a subnet mask from the drop-down list box.
Mandatory. Enter the old password for the default web user.
Mandatory. Enter a new password for the default web user.
To ensure password strength, the password must contain at least two types of the following:
lowercase letters, uppercase letters, digits, and special characters (such as ! $ # %), and cannot
contain any space or single quotation mark.
Mandatory. Enter the new password again.
Optional. Select a user level from the drop-down list box. The user of level 3 or higher has
management rights.
Click Apply to save the configuration. When you exit from the initial login page, either of the following
situations will occur depending on the management IP address you configured:
Step 7
If the management IP address is in the same network segment as 192.168.1.253/24, the system jumps to the web login
page directly.
If the management IP address is not in the same network segment as 192.168.1.253/24, you cannot log in to the
switch again using the web management system. You need to configure another IP address for your computer to make
the computer and switch reachable from each other.
Transmission rate: 9600
Data bit (B): 8
Parity bit: None
Stop bit (S): 1
Flow control mode: None

4
Press Enter in subsequent steps until the following information is displayed on the terminal simulation
software, and then enter the user name and password. The default user name for the first login is admin
and the default password is [email protected]. You must change the password after login.
Step 4
Login authentication
Username:admin
Password:
Warning: The default password poses security risks.
The password needs to be changed. Change now? [Y/N]: y
Please enter old password:
Please enter new password:
Please confirm new password:
The password has been changed successfully
<HUAWEI>
You can run commands to configure the device. Enter a question mark (?) whenever you need help. For more
information, see the Configuration Guide for your switch on the Huawei support website.
The password entered in interactive mode is not displayed on the screen.
If you do not change the authentication mode and password after entering the user view, the authentication password
used for next login is the one configured during the first login.
6 Installing the Switch
300 mm
390 mm
100 mm/110 mm
3 N·m
M6
The depth of the S5720I-6X-PWH-SI-AC is 110 mm.
The depth of the S5720I-10X-PWH-SI-AC is 100 mm.
In pole-mounted installation scenarios, the switch must be mounted to a vertical round pole.
When installing the switch, use the installation kit and hose clamps delivered with the switch.
Wear protective gloves during installation.
Never install the switch while the power is on.
Keep the paint coating on the surface of the switch intact. If there is any peeling paint,
re-paint the switch to protect the switch from corrosion.
Before You Start
Scenario 1: Pole Mounting
Installation Procedure
Required Items and Tools
Protective gloves LadderM6 inner hex torque screwdriver
Phillips torque screwdriver (with a shaft of at least 130 mm in length)
Step 1 Use the positioning sticker to mark the
installation position of the installation
kit on the pole.
Step 2 Open the hose clamps.
Cable hole
Positioning sticker
Step 3 Feed the hose clamps through the installation
kit (mounting side).

1 N·m
M4 (4 PCS)
3 N·m
M6 (1 PCS)
3 N·m
M6
UP
5
Scenario 2: Wall Mounting
Before You Start
Required Items and Tools
Protective gloves
M6 inner hex torque screwdriver
Marker
Phillips torque screwdriver (with a shaft of at least 130 mm in length)
Expansion bolts
Socket wrenchLadderHammer drill
Spirit level
Install the installation kit (mounting side) onto the pole. Ensure that the top of the installation kit is flush
with the top of the positioning sticker.
Step 4
A standard hose clamp is used for poles with a
diameter of 48 mm to 114 mm.
Position the hose clamp around the pole and
feed the loose end of the hose clamp into the saddle.
Tighten the hose clamp around the pole and close
the hose clamp.
An optional hose clamp is used for
poles with a diameter of 114 mm
to 380 mm.
Mount the switch onto the pole.
Step 6
Install the installation kit (device side)
onto the switch.
Step 5
Ensure the wall is made of reinforced concrete and is able to bear at least 800 N. Ensure the wall can sustain a
tension of 1.25 kN exerted outwards vertical to the wall without being damaged.
Tighten the screw on the hose clamp using the inner
hex torque screwdriver.

300
≥ 300
≥ 300
1200-1600
≥ 1000
Ø8
3 N·m
M6 (4 PCS)
1 N·m
M4 (4 PCS)
UP
UP
UP
Space Planning
6
Installation Procedure
Mark the four drilling positions on the installation
kit (mounting side).。
Step 1 Drill holes and install expansion bolts. Step 2
Hammer drill
Install the installation kit (mounting side)
onto the wall.
Step 3 Install the installation kit (device side) onto
the switch.
Step 4
Drilling
position
Unit: mm

3 N·m
M6
3 N·m
M6
3 N·m
M6 (1 PCS)
1 2 3 4
The cables connected to the switch must be routed along the inner side of the pole.
The ground cable must be purchased separately.
Mount the switch onto the wall.
Step 5
Connect one end of the ground cable to the switch.
Step 1 Connect the other end of the ground
cable to the pole ground bar.
Step 2
7 Cabling the Switch
7.1 Connecting the Ground Cable to the Switch
7.2 Connecting Cables to the Maintenance Compartment
Cable Outlet Diameter Requirements
7
1Optical fiber/
Optical cable
2 Ethernet cable Cat5e and Cat6 Ethernet cables
4AC input power
cable
9.5±0.5 mm (on the left outlet) and 14±0.5 mm
(on the right outlet)
3DC or AC output
power cable 9.3±0.5 mm
8±0.5 mm to 9.6±0.5 mm (on the left outlet) and
13.3±0.5 mm (on the right outlet)
No. Cable Type Supported Cable Outer Diameter
NOTE
Pole ground bar

2.8 N·m
M5 (6 PCS)
1 5
3 4
2 6
Connecting Procedure
8
Open the maintenance compartment door.
Step 1
Connect cables to the maintenance
compartment.
Step 3
Connect power cables to the power connector.
Step 2
1Optical fiber/
Optical cable Optical network
2 Ethernet cable Ethernet or PoE PD
3S5720I-6X-PWH-SI-AC:
AC power cable
S5720I-10X-PWH-SI-AC:
DC power cable
External 24 V device
4 DC power cable External 12 V device, two outputs at most
5 AC power cable External 110 V or 220 V device
6 AC power cable 110 V or 220 V AC power supply that
provides power to the switch
No. Cable Type Connected Network or Device
The key for the maintenance compartment door and the
power connector are included in the installation accessory
package that comes with the switch.
Maximum length of a fiber that can be coiled up in a fiber management tray (FMT): 20 m (for a single bare fiber)
or 1 m (for a single fiber pigtail). If two fibers are used, this length is halved.
The S5720I-6X-PWH-SI-AC does not support 110 V input or 110 V output.
Neutral wire
Screw
Live wire
WARNING
NOTE
NOTE
Never install or remove switches and power cables when the
power is on.
The external power supply system must be connected to a circuit
breaker (20 A is recommended). For safety purposes, do not use a
switch without a circuit breaker.
The internal 110 V or 220 V AC power supply is used only for
external power conversion. It has no circuit breaker, regulated
voltage circuit, or surge protection. Therefore, do not connect
cables when the power is on.
Pay attention to the position of the +/- or L/N labels when
connecting power cables to power sockets. Connect the live wire
of an AC power cable to the socket marked with an L, the neutral
wire to the socket marked with an N, and PE cables to the PE
cable ground terminals in the maintenance compartment.
Ensure no power cables have metal parts exposed to air.
5
3 4
2 61

1. Check whether the installation kit is securely installed and whether all screws are tightly secured.
2. Check whether all cables are reliably connected with correct polarity and no short circuit.
3. Check whether there are any empty screw holes. If there are, install screws in the empty holes.
4. Check whether the waterproof rubber bungs are properly inserted into idle cable outlets.
8 Verifying the Installation
Power on the switch and check indicators on the switch.
If the built-in power supply indicator PWR is steady green, the power module is supplying power.
If the system status indicator SYS blinks green slowly, the system is operating properly.
Check service configurations of the switch, for example, whether the switch is reachable and can be queried on
the NMS.
10 Closing the Maintenance Compartment Door
9
Close the maintenance compartment door, and tighten the captive screws.
(Optional) Install a cable cover (part number: 98010812), which needs to be separately purchased.
Step 1
Step 2
Procedure
9 Power-On Check
For details about different states of the indicators, see the S5700 Hardware Description.
S5720I-10X-PWH-SI-AC is used as an example.
WARNING
NOTE
After the maintenance compartment door is closed, tighten the captive screws on the door. Waterproof rubber bungs must be inserted
into the idle cable outlets to prevent water intrusion.

10
2.8 N·m
M5 (6 PCS)
1.3 N·m
M5 (2 PCS)
Log in to Huawei enterprise technical support website
(http://support.huawei.com/enterprise), and select a specific product model and
version to find its documentation.
Log in to Huawei enterprise support community
(http://forum.huawei.com/enterprise) and post your questions in the community.
11 Obtaining Product Documentation and Technical Support
Huawei Enterprise
Technical Support
Copyright © Huawei Technologies Co., Ltd. 2019. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of
Huawei Technologies Co., Ltd.
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective holders.
I Trademarks and Permissions
Supplier’s Declaration of Conformity (SDoC)
Unique Identifier: trade name: HUAWEI; product name: Switch;
model number: S5720I-6X-PWH-SI-AC, S5720I-10X-PWH-SI-AC
Responsible Party- U.S. Contact Information
Huawei Technologies USA Inc.
5700 Tennyson Parkway, Suite 500
Plano, Texas 75024
Main: 214-919-6000 / TAC Hotline: [phone]
FCC Compliance Statement ( for products subject to Part 15)
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause
undesired operation.
