B30-LED Series 8" Round Traditional Bollard Installation Instructions
7/29/14 EC 140731001 Status A Part No. 93054328
Tools Required:
qRatchet with 9/16" deep socket q3/16" Hex Key
q1/8” Hex Key q9/16” Open End Wrench
qFlat Blade Screwdriver
!
Base Casting Installation:
Make certain electrical supply is OFF before starting installation.
1. Install the base casting on the pre-set anchor bolts. Use flat washers and hex
nuts both below and above the base casting.
2. Level the top edge of the casting by adjusting the bottom leveling nuts.
Tighten the upper nuts.
3. Connect the circuit ground wire to the grounding lug on the ballast bracket.
4. Connect power supply leads to the driver input leads.
Fixture Installation:
Make certain electrical supply is OFF before starting installation.
1. To protect finish, lay fixture horizontally on soft cloth with open end of
fixture next to installed base casting.
2. Connect fixture ground lead (green) to the short green wire connected to
the grounding lug on the driver bracket.
3. Connect the LED module leads to the driver.
4. Place pole body over base casting and slowly turn until body drops into
retaining slots, then twist clockwise to lock the pole onto the base casting.
5. Tighten the two set screws at the bottom of the pole using a 3/16" hex key.
WARNING: Fixtures must be grounded in accordance with local codes or the National Electrical Code. Failure to do
so may result in serious personal injury.
CAUTION: All wiring must be done by a qualified electrician.
KEEP THIS SHEET FOR FUTURE REFERENCE.
!
16555 East Gale Avenue
City of Industry, CA 91745-1788
626/968-5666 • FAX [phone]
B30-LED
Top Cover/
Lens Assembly
Reflector
Assembly
Base
Assembly
Riser
(Pole Body)
Base Casting
Conduit
(by others)
Anchor Bolt (4)
Concrete
Concrete Pad
Leveling Nut
and Washer (4)
Nut and
Washer (4)
Riser/
Pole Body
Base Casting
Assembly
Earth, Grade
Slopes Away
Final Installation Detail
!
Level
3" Max.
Grade
Base Casting Assembly
Fixture Installation

© 2014 KIM LIGHTING 16555 E. Gale Ave., City of Industry, CA 91745-1788, 626-968-5666, FAX: [phone] PAGE 2
B30-LED Series 8” Round Traditional Bollard Installation Instructions
FOR OPTIONAL BATTERY BACKUP
Driver assembly and base casting looks
like image above. Connect the circuit
ground wire to the green wire connected
to the green wire connected to the
grounding lug lead on the driver bracket.
Connect the power supply leads to the
driver input leads, white-to-common and
black-to-voltage, black “Un-switched to
AC Power” lead to an un-switched AC
power source of 100-277V AC.
Fixture
Housing 30 mA Max
Gray Dimming Lead (-)
Standard Input Black (+)
Unswitched Input Black (+)
White (-)
Green (GND)
Purple Dimming Lead (+)
BATTERY BACKUP
If your fixture includes Battery Backup
Option, an additional power wire is included
labeled “Unswitched Power”. This lead must
be connected to an unswitched power
source running 120-277 VAC to function
properly.
0-10V DIMMING
Driver has a 0-10V dimming interface with
a dimming range of 10-100%. Is compat-
ible with most control systems including
Hubbell Building Automation wiHUBB™.
Approved dimmers include Lutron Diva
AVTV, Lutron Nova NFTV and NTFTV. Note:
Not compatible with current sourcing dim-
mers. Controls compatible via Gray and
Purple dimming lead.

© 2014 KIM LIGHTING 16555 E. Gale Ave., City of Industry, CA 91745-1788, 626-968-5666, FAX: [phone] PAGE 3
B30-LED Series 8” Round Traditional Bollard Installation Instructions
LED BOLLARD WARRANTY
When properly installed and under normal conditions of use, Kim Lighting warrants LED Bollard products (“Product(s)”)
sold by Kim Lighting to be free from defects in material and workmanship for (i) a period of five (5) years for metal
parts, (ii) a period of ten (10) years for exterior housing paint finish(s), and, (iii) a period of six (6) years for LED Light
Engines () and, (iv) a period of five (5) years for LED power components (LED Driver), from the date of sale of such
goods to the buyer as specified in Kim Lighting shipment documents for each Product(s). The buyer agrees to make
all claims regarding defects or deficiencies in the Product(s) according to the terms of Kim Lighting’s official warranty.
Warranty claims must be made in writing according to Kim Lighting procedures existing at the time of the claim. Valid
warranty claims must be made within the warranty period specified herein above, and submitted within thirty (30) days
of discovery of the damage or defect. No FIELD labor, repair, DISMANTLE, or installation charges are included with this
warranty. Kim Lighting may repair or replace any Product(s) covered by this warranty at its sole discretion and in accor-
dance with its procedure. Any unauthorized return, repair, replacement or modification of the Product(s) shall avoid this
warranty. This warranty applies only to the use of the Product(s) as intended by Kim Lighting and does not cover any
misapplication or misuse of said Product(s), or installation in hazardous or corrosive environments. In no event shall Kim
Lighting’s total liability for any reason arising hereunder exceed the purchase price paid to Kim Lighting for the product
purchased by the buyer hereunder. Contact Kim Lighting for complete warranty language, exceptions, and limitations.
General Product Limited Warranty Coverage
All material and component parts used in the manufacture of Kim Products, are warranted to be free from defects of
material and/or workmanship for a period of 1 year from date of sale, with the following exceptions:
Auxiliary Equipment
All auxiliary equipment (such as drivers and battery backup) provided by and/or included in Kim Products shall carry
the component manufacturer’s warranty.
Aluminum Landscape Components
Aluminum Landscape fixture components not in direct contact with soil, shall be warranted against defects of material
and/or workmanship for a period of 3 years from date of sale. Aluminum fixture components in direct contact with soil
shall be warranted from defects of material and failure from corrosion for a period of 1 year from date of sale.
Limit of Liability and General Conditions
Only products which are installed, used and maintained in accordance with applicable Kim instructions, specifications
and accepted trade practices, are covered by the Kim Warranty. During the warranty period, with proof of purchase,
Kim will repair or replace with the same or similar product, at Kim’s option, without charge. Labor costs are the owner’s
responsibility and are excluded from this warranty. This warranty is void if the product is modified, tampered with, mis-
applied, poorly installed, improperly maintained, or subjected to abnormal conditions.
Repair or replacement as provided under this warranty is the exclusive remedy of the purchaser. This warranty is in lieu
of all other warranties, expressed or implied, including any implied warranty of fitness for a particular application. Kim
Lighting shall not be liable to the purchaser for indirect or consequential damages.
