Confidentiality Notice
This manual is provided solely as an installation, operation, and maintenance guide and contains sensitive
business and technical information that is confidential and proprietary to GAI-Tronics. GAI-Tronics
retains all intellectual property and other rights in or to the information contained herein, and such
information may only be used in connection with the operation of your GAI-Tronics product or system.
This manual may not be disclosed in any form, in whole or in part, directly or indirectly, to any third
party.
General Information
The Model 234 RED ALERT Tower Assembly is part of a completely integrated emergency
communications station. The Model 234SBA RED ALERT Broadcast Tower Assembly helps ensure
public safety by combining two-way communication with one-way public-address broadcasting.
The Model 234 RED ALERT Tower and Model 234SBA RED ALERT Broadcast Tower are designed to
house a GAI-Tronics 39xor 27xseries flush-mount telephone and a Model 540-001 or 541-001 strobe.
Both tower assemblies are over 9 feet tall, making them easily located by potential users. The Model
234SBA Tower can be equipped with up to four public address speakers.
GAI-Tronics enhanced emergency telephones are designed for isolated high-risk areas requiring
emergency communication equipment. Emergency telephone users simply press the emergency push
button for immediate connection to a user-programmed central security telephone number.
The strobe creates added visibility to emergency telephone locations by providing a constant-on lamp that
automatically flashes when the emergency button is pressed. A panel light mounted in the tower shines
on the front of the telephone to illuminate the telephone for nighttime use.
The complete emergency communication tower assembly, with or without public address, is shipped in
two stages. The No. 84504-301 Hardware Kit is usually shipped in advance, followed by the remaining
assemblies (No. 84501-201 or No. 84509-201 Tower Body, No. 84502-201 Clear Lens, and No. 84503-
30xLED Panel Light Assembly). Both the Model 234 and Model 234SBA use the same hardware kit.
Tower Components
Each tower model includes components that are shipped separately for field assembly. The included
components are:

Pub. 42004-510C
234/234SBA RED ALERT®Tower Assemblies Page 2 of 14
P:\Standard IOMs - Current Release\42004 Instr. Manuals\42004-510C.docx
11/19
Model 234 Tower
Table 1. Model 234 Tower Components
Qauntity
Part Number
Description
1
84501-301
Tower Body, (bronze color)
1
84502-201
Clear Lens
1
84503-301
or
84503-302
Panel Light Assembly, 120 V ac
or
Panel Light Assembly 10–33 V dc
Model 234SBA Tower
Table 2. Model 234SBA Tower Components
Qauntity
Part Number
Description
1
84509-201
Tower Body, (bronze color)
1
84502-201
Clear Lens
1
84503-301
or
84503-302
Panel Light Assembly, 120 V ac
or
Panel Light Assembly 10–33 V dc
1–4
12538-201
Speaker Kit (quantity of kits
determines audio coverage)
1–4
12538-201
Vacancy Kit (required when a
speaker kit is not utilized; i.e., facing
a building)
The following components must be ordered separately:
Model Description
•540-001 Strobe (120 V ac)
•541-001 Strobe (12–24 V dc)
•84804-301 Installation Kit
Installation
ATTENTION
—Installation should be performed by qualified personnel and only in
accordance with the National Electrical Code and applicable local codes.
The following information provides guidelines to install the various components of the emergency
station. The grounding electrode conductor (not depicted in the illustration) must be constructed in
accordance with the National Electrical Code and applicable local codes.

Pub. 42004-510C
234/234SBA RED ALERT® Tower Assemblies Page 3 of 14
P:\Standard IOMs - Current Release\42004 Instr. Manuals\42004-510C.docx
11/19
A concrete pier is required to support the tower assembly. The pier must be strong enough to support the
9-1/2 feet tall structure that weighs 250 pounds. The specific GAI-Tronics installation requirements
outlined in this manual provide a 140-mph wind speed rating (VULT). *Reference AASHTO LTS6 Risk
Category II International Building Code.
The GAI-Tronics No. 84504-301 Hardware Kit contains four anchor mounting bolts, a mounting
template, and mounting nuts and washers needed for installation. Additional materials required to install
the pier are not provided by GAI-Tronics but are shown in the installation drawings for reference.
Determine all conduit entries before pouring the pier.
Figure 1. Model 234 & Model 234SBA shown
Tower assembly installation requires the construction of a concrete pier with a rebar reinforcement cage
using 3,000 psi minimum grade concrete. Installation of the anchor bolts within the concrete is simplified
by using the provided template. Once the concrete has properly cured, the tower body is installed with
the nuts and washers included in the hardware kit. Leveling and spacing of the tower body is required for
proper installation. Detailed information on each of these items is provided in this manual.

Pub. 42004-510C
234/234SBA RED ALERT® Tower Assemblies Page 4 of 14
P:\Standard IOMs - Current Release\42004 Instr. Manuals\42004-510C.docx
11/19
Pier Foundation Depth and Conduit Entry
The pier should protrude a minimum of one inch above the finished grade when the surrounding area is
not concrete or asphalt. Determine the required length of concrete form tube by adding the height desired
above grade to the required 42-inch below grade pier depth.
Install conduits in the pier as needed for installation.
 Conduit is not supplied by GAI-Tronics.
 Consideration for power, Ethernet, telephone, 75-ohm RG6 cable, and any other customer wiring
determines the number and size of the conduit entries (see Figure 2 for typical conduit arrangements).
Figure 2. Sample conduit arrangements within tower
Concrete Form Construction
1. Place the 24-inch diameter concrete form tube on a bed of crushed stone in the excavated hole.
2. Place an 18-inch diameter by 38-inch long rebar reinforcement cage into the concrete form tube
before pouring the concrete.
The following materials are necessary to construct the reinforcement cage:
 Four 38-inch long #4 rebar rods
 Three 18-inch diameter #4 rebar stirrups
 Precut wire ties
To construct the reinforcement cage:
1. Tie a horizontal stirrup at the center of the four 38-inch rebar rods.
2. Tie the two remaining horizontal stirrups 18 inches above and below the center point (see Figure 3).
3. Place the cage on one-inch block spacers, centering the cage within the concrete form tube.
The top of the cage should be at least three inches below the top of the pier.

Pub. 42004-510C
234/234SBA RED ALERT® Tower Assemblies Page 5 of 14
P:\Standard IOMs - Current Release\42004 Instr. Manuals\42004-510C.docx
11/19
Figure 3. Reinforcement Cage Detail

Pub. 42004-510C
234/234SBA RED ALERT® Tower Assemblies Page 6 of 14
P:\Standard IOMs - Current Release\42004 Instr. Manuals\42004-510C.docx
11/19
Anchor Bolt Location
ATTENTION —Embed the anchor bolts a minimum of nine inches into the concrete. Anchor
bolt positioning is critical for tower body mounting.
1. Immediately submerge the anchor bolts into the concrete pier after pouring the concrete.
2. Use the template provided in the hardware kit to position the anchor bolts at the correct height and in
the proper locations (see Figure 4).
Figure 4. Anchor Bolt Location—Pier Top View

Pub. 42004-510C
234/234SBA RED ALERT® Tower Assemblies Page 7 of 14
P:\Standard IOMs - Current Release\42004 Instr. Manuals\42004-510C.docx
11/19
3. Install the four anchor bolts so that they extend at least three inches above the top surface of the pier
(see Figure 5 for the bolt protrusion dimension).
Figure 5. Concrete Pier Cross Section
Tower Mounting
ATTENTION —Do not mount the tower body until the concrete has been allowed to cure for
a minimum of 24 hours.
1. Thread the ¾-inch hex nuts onto the anchor bolts until the tops of the nuts are 1-1/8 to 1-3/8 inches
above the top of the pier.
Verify that the nuts are level.
2. Place one washer over each nut (see Figure 6).
3. Place the tower on top of the four level hex nuts with washers.

Pub. 42004-510C
234/234SBA RED ALERT® Tower Assemblies Page 8 of 14
P:\Standard IOMs - Current Release\42004 Instr. Manuals\42004-510C.docx
11/19
Figure 6. Exploded View
4. Verify that a ¼-inch minimum air gap exists between the base of the tower and the top of the concrete
pier (see Figure 7).
NOTE: The air gap must not be obstructed with soil, mulch, stone, etc. Failure to maintain the air gap
will cause moisture entrapment that will result in corrosion.
Figure 7. Assembled View

Pub. 42004-510C
234/234SBA RED ALERT® Tower Assemblies Page 9 of 14
P:\Standard IOMs - Current Release\42004 Instr. Manuals\42004-510C.docx
11/19
5. Entering through the rear access panel cutout, place the four remaining washers on the anchor bolts
and secure with the ¾-inch hex nuts.
6. Torque the 3/4-inch hex nuts to 85 ftlb.
NOTE: The unit must be installed and grounded in accordance with national and local electrical codes.
Increased Windspeed Rating (Optional)
Increase the buried concrete pier depth from 42 inches to 48 inches to obtain a wind speed rating (VULT) of
160mph.
Model 54 X -001 Strobe and No. 84502-201 Lens Cover Installation
NOTE: A ¾-inch by ¾-inch M/F extension is provided for installation of the 540-001 or 541-001 strobe.
It is highly recommended that this extension be installed. The extension increases the
installation height of the LED strobe for maximum visibility.
1. Thread the extension onto
the tower and tighten.
2. Insert the strobe’s 15-foot
wires through the
extension (when installed)
and the tower’s threaded
nipple and allow the wires
to extend to the base of the
tower (see Figure 8).
3. Screw the strobe onto the
threaded nipple/extension.
4. Apply a small amount of
clear RTV silicone sealant
or equivalent to the
threads of each security
screw to reduce the
possibility of rust forming
in the screw threads.
5. Secure the No. 84502-201
Lens Cover with the four
security screws.
6. Refer to GAI-Tronics Pub.
42004-499 (Model 540-
001) or 42004-529 (Model
541-001) for detailed
strobe installation
instructions (see Figure 11
and Figure 12 for general
wiring instructions).
NOTE: Pay careful attention to the wire colors for correct wiring.
Figure 8. Strobe Assembly

Pub. 42004-510C
234/234SBA RED ALERT® Tower Assemblies Page 10 of 14
P:\Standard IOMs - Current Release\42004 Instr. Manuals\42004-510C.docx
11/19
Model 84503-30x Tower Panel Light
1. Align the panel light assembly inside the tower
(see Figure 9).
2. Model 84503-301 (120 V ac): Extend the black
(hot), the white (neutral), and the green (ground)
wires to the base of the tower (these wires, along
with the strobe wires, will be connected later to
the incoming power conductors in accordance
with applicable electrical codes).
Model 84503-302 (10–33 V dc): Extend the black
(−) and the white (+) wires to the base of the
tower (these wires, along with the strobe wires,
will be connected later to the incoming power
conductors in accordance with applicable
electrical codes).
3. Apply a small amount of clear RTV silicone
sealant or equivalent to the mounting screw
threads to reduce the possibility of rust forming in
the threads.
4. Secure the light assembly with the two mounting
screws provided.
Figure 9 Panel Light Assembly

Pub. 42004-510C
234/234SBA RED ALERT® Tower Assemblies Page 11 of 14
P:\Standard IOMs - Current Release\42004 Instr. Manuals\42004-510C.docx
11/19
Model 40201-010 Battery (Model 234SBA Only)
Refer to Pub. 42004-415, Model 10458-10x Electronics Paging Module Manual, for detailed
interconnection and installation instructions.
1. Make the wiring connection to the electronics paging module before placing the batteries into the
tower.
NOTE: Leave the wires from the paging module to the batteries disconnected until ready to power up
the unit.
2. Secure the batteries into the L-brackets inside tower under the telephone opening or at the base of the
tower (see Figure 10).
NOTE: If the tower body does not have any L-brackets, the battery must be set in the bottom of the
tower to the side, away from the conduit entries and clear of the access panel.
Figure 10. Battery Installation Locations

Pub. 42004-510C
234/234SBA RED ALERT® Tower Assemblies Page 12 of 14
P:\Standard IOMs - Current Release\42004 Instr. Manuals\42004-510C.docx
11/19
Power Connections
For all component wiring, refer to the specific equipment manual and the interconnection diagrams (see
Figure 11 and Figure 12).
Figure 11. Interconnection Diagram with AC-Powered Strobe
Figure 12. Interconnection Diagram with DC-Powered Strobe

Pub. 42004-510C
234/234SBA RED ALERT®Tower Assemblies Page 13 of 14
P:\Standard IOMs - Current Release\42004 Instr. Manuals\42004-510C.docx
11/19
All wiring connections should now be complete, except for the tower panel light and strobe wire
connections to the incoming power lines. All connections must be made in accordance with the NEC
(National Electrical Code) in the United States or the CEC (Canadian Electrical Codes) in Canada.
1. Terminate the customer ground conductor to the ground stud connection located inside the rear access
panel.
2. Terminate the power conductors (see Figure 11 for ac installations or Figure 12 for dc installations).
3. Replace the access panel cover on the tower base using the security screws.
Maintenance
Repairing Surface Damage to Powder-Coated Towers
Scratch Repair
1. Carefully sand the damaged area to clean and score the base metal, taking care to minimize any
additional damage to the surrounding powder coating.
2. Wipe the sanded area with a cleaning solvent, such as DuPont “PrepSol.” Allow the area to dry. This
type of product is available at auto parts stores. Denatured alcohol can also be used.
3. Prepare the bare metal surface for painting by treating it with a phosphoric acid solution intended for
this purpose. Allow the area to dry.
4. Using a cotton swab or small brush, paint the prepared surface with an automotive enamel or oil base
polyurethane enamel such as Red Devil®or Rustoleum®. DO NOT USE Krylon-type paints.
Carefully blend the repair enamel into the powder coating at the edges.
NOTE:EXACT color matches may not be attainable.
Decal Repair
1. Use a sharp instrument, such as a razor blade, to loosen and lift a corner edge of the damaged decal.
2. Carefully peel back and remove the loosened decal.
3. Wipe the area clean with denatured alcohol. Allow the area to dry.
4. Prior to attaching a new decal, dampen the target area with a fine mist of water (fine spray from a
plant misting bottle is ideal).
5. Peel the backing from the replacement decal, leaving the decal’s front cover material attached, and
carefully align it with the target area.
6. With the cover material still attached, press the replacement decal in place, then squeegee any water
from under the new decal starting at the center and working toward the edges.
7. Peel off the front cover material, being careful not to tear or lift the decal. If the decal lifts as the
cover material is being removed, push down on the uncovered decal, and squeegee as necessary to
remove any large air bubbles; small air bubbles will disappear as the decal dries.

Pub. 42004-510C
234/234SBA RED ALERT®Tower Assemblies Page 14 of 14
P:\Standard IOMs - Current Release\42004 Instr. Manuals\42004-510C.docx
11/19
Replacement Parts and Accessories
Table 3. Parts and Accessories
Model
Description
25398-001
EMERGENCY standard label, white
25398-002
EMERGENCY reflective label, white
25398-003
EMERGENCY standard label, cardinal red
25398-013
EMERGENCY standard label, black
25398-015
HELP large label, white
540-001
Strobe, 120 V ac
541-001
Strobe, 12–24 V dc
84504-301
Hardware Kit
Specifications
Dimensions .........................................................................114 H × 10 W × 10 D in (2.89 × 0.25 × 0.25 m)
Wall thickness......................................................................................................................................3/16 in
Finish ..............................................................................................................................powder-coated steel
Power rating:
Model 84503-301 AC Panel Light Assembly.............................................25 mA @ 120–230 V ac
Model 84503-302 DC Panel Light Assembly..................................................40 mA @10–33 V dc

(Rev. 10/06)
Warranty
Equipment. GAI-Tronics warrants for a period of one (1) year from the date of shipment, that any
GAI-Tronics equipment supplied hereunder shall be free of defects in material and workmanship, shall
comply with the then-current product specifications and product literature, and if applicable, shall be fit
for the purpose specified in the agreed-upon quotation or proposal document. If (a) Seller’s goods prove
to be defective in workmanship and/or material under normal and proper usage, or unfit for the purpose
specified and agreed upon, and (b) Buyer’s claim is made within the warranty period set forth above,
Buyer may return such goods to GAI-Tronics’ nearest depot repair facility, freight prepaid, at which time
they will be repaired or replaced, at Seller’s option, without charge to Buyer. Repair or replacement shall
be Buyer’s sole and exclusive remedy. The warranty period on any repaired or replacement equipment
shall be the greater of the ninety (90) day repair warranty or one (1) year from the date the original
equipment was shipped. In no event shall GAI-Tronics warranty obligations with respect to equipment
exceed 100% of the total cost of the equipment supplied hereunder. Buyer may also be entitled to the
manufacturer’s warranty on any third-party goods supplied by GAI-Tronics hereunder. The applicability
of any such third-party warranty will be determined by GAI-Tronics.
Services. Any services GAI-Tronics provides hereunder, whether directly or through subcontractors,
shall be performed in accordance with the standard of care with which such services are normally
provided in the industry. If the services fail to meet the applicable industry standard, GAI-Tronics will
re-perform such services at no cost to buyer to correct said deficiency to Company's satisfaction provided
any and all issues are identified prior to the demobilization of the Contractor’s personnel from the work
site. Re-performance of services shall be Buyer’s sole and exclusive remedy, and in no event shall GAI-
Tronics warranty obligations with respect to services exceed 100% of the total cost of the services
provided hereunder.
Warranty Periods. Every claim by Buyer alleging a defect in the goods and/or services provided
hereunder shall be deemed waived unless such claim is made in writing within the applicable warranty
periods as set forth above. Provided, however, that if the defect complained of is latent and not
discoverable within the above warranty periods, every claim arising on account of such latent defect shall
be deemed waived unless it is made in writing within a reasonable time after such latent defect is or
should have been discovered by Buyer.
Limitations / Exclusions. The warranties herein shall not apply to, and GAI-Tronics shall not be
responsible for, any damage to the goods or failure of the services supplied hereunder, to the extent
caused by Buyer’s neglect, failure to follow operational and maintenance procedures provided with the
equipment, or the use of technicians not specifically authorized by GAI-Tronics to maintain or service the
equipment. THE WARRANTIES AND REMEDIES CONTAINED HEREIN ARE IN LIEU OF AND
EXCLUDE ALL OTHER WARRANTIES AND REMEDIES, WHETHER EXPRESS OR IMPLIED BY
OPERATION OF LAW OR OTHERWISE, INCLUDING ANY WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
Return Policy
If the equipment requires service, contact your Regional Service Center for a return authorization number
(RA#). Equipment should be shipped prepaid to GAI-Tronics with a return authorization number and a
purchase order number. If the equipment is under warranty, repairs or a replacement will be made in
accordance with the warranty policy set forth above. Please include a written explanation of all defects to
assist our technicians in their troubleshooting efforts.
Call 800-492-1212 (inside the USA) or 610-777-1374 (outside the USA) for help identifying the
Regional Service Center closest to you.
