  9. Humanscale Horizon Task Light Installation instructions

Humanscale Horizon Task Light Installation instructions

Tools RequiredComponents for Breakdown
Safety Glasses
Arm
Head
Base
Flat Screwdriver
Standard and Metric
Hex Key Set
Base Page 1
Head Page 3
Arm Page 4
Disassembly InstructionsHorizon Task Light
REV-00
Some components may not be recyclable in your area.
Waste Electrical products should not be
disposed of with household waste. Please
recycle where facilities exist. Check with your
Local Authority or retailer for recycling advice.
Base
Step 1
Remove screws from bottem to
remove baseplate
Step 2
Remove all screws and dissasemble
entire base
Step 3
Remove screws to dissasemble ball
joint and release arm
Tools Required
Safety Glasses
ABS
>ABS<
Steel
1
3
2
Page 1
Iron
ABS
>ABS<
Standard and Metric
Hex Key Set
Disassembly InstructionsHorizon Task Light
REV-00
Some components may not be recyclable in your area.
Base (Horizon 2.0)
Step 1
Remove screws from bottem to
remove baseplate
Step 2
Remove all screws and dissasemble
entire base
Step 3
Remove screws to dissasemble ball
joint and release arm
Tools Required
Safety Glasses
ABS
>ABS<
Steel
Steel
1
2
Page 1
ABS
>ABS<
Standard and Metric
Hex Key Set
Disassembly InstructionsHorizon Task Light
REV-00
Some components may not be recyclable in your area.
3
Base (cont.)
Step 1
Remove set screws to release ball from arm
Step 2
Remove arm from base plate
Tools Required
Safety Glasses
1
2
Page 2
ABS
>ABS<
Standard and Metric
Hex Key Set
Steel
Disassembly InstructionsHorizon Task Light
REV-00
Some components may not be recyclable in your area.
Head
Tools Required
Safety Glasses
Step 1
Remove all components by prying head
apart with a flathead screwdriver
Step 2
Remove arm from head components
Flat Screwdriver
Page 3
>PC<
Steel
Aluminum
Acrylic
Polycarbonate
Disassembly InstructionsHorizon Task Light
REV-00
Some components may not be recyclable in your area.
Arm
Tools Required
Safety Glasses
Step 1
Remove all componants to fully dissasemble arm
Flat Screwdriver
Page 4
Steel
Steel
Aluminum
POM
>POM<
Standard and Metric
Hex Key Set
Disassembly InstructionsHorizon Task Light
REV-00
Some components may not be recyclable in your area.
