Hunter 90409 User manual

7" Personal Fan7" Personal Fan
44831-01
20130219
©2013 Hunter Fan Co.
Owner’s Manual
Models
90409
90410
90411
90412
90413
90418
90420
90425
7" Personal Fan
English

2
IMPORTANT SAFETY INFORMATION
WARNING
CAUTION
When using electrical appliances,
basic precautions should always
be taken to reduce the risk of re,
electric shock and personal injury:
1. Read all instructions before
using this fan.
2. Improper installation may
result in the risk of re, electric
shock or personal injury.
3. To prevent the risk of re and
electric shock, DO NOT use
the unit near windows. Rain
and moisture may create an
electrical hazard.
4. The power plug must be
removed from the power
socket when not in use,
before cleaning, servicing,
maintenance and before
moving to another location.
5. DO NOT put fan in a damp
place or where humidity is
high-such as a bathroom.
6. The fan should be placed on a
at, stable surface or tabletop
to avoid overturning.
7. Use fan only for intended
use, as described in this
instruction manual.
8. To protect against electrical
shock, DO NOT immerse unit,
plug or cord in water or spray
with liquids.
9. Close supervision is necessary
when any appliance is used by
or near children.
10. NEVER insert ngers, pencils
or any other objects through the
grill when the fan is running.
11. DO NOT operate any appliance
with a damaged cord or plug,
after the appliance malfunctions
or has been dropped or
damaged in any manner.
12. To disconnect, grip plug and
pull from wall outlet. NEVER
yank on cord.
13. ALWAYS use on a dry surface.
14. This product is intended for
household use only and not for
commercial or industrial use.
15. DO NOT operate fan in the
presence of explosive and/or
ammable fumes.
16. DO NOT place fan or any parts
near an open ame, cooking or
any other heating appliances.
17. DO NOT use near curtains,
plants, window treatments, etc.
18. This appliance has a grounded
three-prong plug and is suitable
for grounded receptacle use
only. An adapter is available
for connecting three-blade
grounding-type plugs to two-slot
receptacles. The adapter must
be properly grounded. DO NOT
attempt to defeat the purpose
of this safely feature.
19. The rubber feet on this product
may interact with wood and
cause damage to furniture. Do
not place on ne wood furniture.
To reduce the risk of re or electrical
shock, DO NOT use this fan with
any solid-state speed control device.
Read & Save ese Instructions

3
Please attach your
receipt or a copy of
your receipt to this manual
for future reference.
WELCOME UNPACKING
As you unpack the fan, save the carton
and packing materials in case you want
to move or ship the unit in the future.
Carefully remove all items from the box.
NOTE: It is best to have someone hold
the box while you lift the fan and the
protective packaging out of the carton.
Make sure all shipping materials are
removed from fan before operating.
Thank you for choosing the Hunter
7" Yoke Fan. This manual gives you
complete instructions for using your
fan. Here are some the features you
will enjoy with your fan:
• An attractive design that
enhances any decor
• A powerful Hunter motor for
maximum air ow
• Three speeds to adjust your
comfort level
Before using your fan, record the
following information for your records
and for warranty assistance.
Model Name _________________
Date Purchased ______________
Where Purchased _____________

4
This appliance is for household
use only and may be plugged into
any 120-volt AC electrical outlet
(ordinary household current). DO
NOT use any other type of outlet.
This unit is suitable for grounded
receptacle use only.
The cord has a grounded plug as
shown in Figure 1. An adapter, as
shown in Figure 2, is available for
connecting three-blade grounding-
type plugs to two-slot receptacles.
The green grounding lug extending
from the adapter must be
connected to a permanent ground
such as a property grounded
outlet box. The adapter should not
be used if a three-slot grounded
receptacle is available.
GROUNDING INSTRUCTIONS
FIGURE 1 FIGURE 2
LINE CORD SAFETY TIPS
1. NEVER pull or yank on the
cord or the appliance.
2. To insert plug, grasp it rmly
and guide it into the outlet.
3. To disconnect the appliance,
grasp the plug and remove it
from the outlet.
4. Before each use, inspect
the line cord for cuts and/or
abrasion marks. If any are
found, the appliance should
be serviced and the line cord
replaced. Please return it
to our Service Department
or to an authorized service
representative.
5. NEVER wrap the cord tightly
around the appliance, as this
could place undue stress on
the cord where it enters the
appliance and could cause it
to fray and break.
6. DO NOT operate appliance
if the line cord shows any
damage, if the appliance
works intermittently or stops
working entirely.
WARNING
Grounded
Plug Adapter
Metal
Screw
Grounding
Pin
Grounding
Means
Grounded Outlet
Box Cover
Grounded Outlet
Box Cover

5
Figure 3
This plug is a safety feature. It
contains a safety device (fuse) that
should not be removed. Discard
product if the attachment plug is
damaged. To reduce the risk of re,
electric shock and personal injury,
DO NOT remove, replace, repair or
tamper with the originally supplied
plug. If the Fan does not function
properly, it may be due to the safety
device incorporated in this plug.
If the fuse fails, it is generally
due to a short circuit or circuit
overload. Replace the fuse as
per the instructions below. If the
replacement fuse fails, immediately
unplug the unit and contact our
technical support department for
assistance.
Fuse Replacement:
1. To replace the fuse, rst turn the
unit it off and unplug it from the
wall. Locate the door on top of
the plug. Figure 3.
2. Slide the door on top of the plug
towards the blades. Figure 4.
3. Carefully remove the fuse from
the clips holding it on the top and
bottom. Figure 5.
Warning! Electrical Hazard! Only
replace with a fuse type and rating
matching what was removed from the
product.
4. Gently push the fuse back into
the pins that will hold it in place.
Note: If the fuse is not seated properly,
the unit will not function.
5. Slide the Door back over the fuse
box in the plug.
6. Plug the fan back in and
resume use.
FUSED PLUG
Figure 4
Figure 5

6
OPERATION
This appliance is for household use only.
1. Place the fan on a dry, safe, at
surface where it cannot fall or
be pulled by the cord.
2. Plug the fan into a grounded
120-volt AC electrical outlet
(ordinary household current).
DO NOT use any other type of
outlet. Make sure that the rated
voltage of the fan is the same
as the power source before
plugging it into the power
source.
3. Turn the fan on or off by
pushing the Power/Speed
Switch. The power should
always be OFF before
unplugging the fan.
4. To select the speed, turn the
Power/Speed Switch from OFF
to the desired speed setting:
I (low), O (off), II (high).
5. To control the upward and
downward direction of airow,
loosen the tilt knob on the side
of the fan. Adjust to the desired
angle and tighten the knob.
Handle
Power/Speed
Switch
Tilt Knob
Base
FIGURE 6

7
MAINTENANCE
This fan is permanently lubricated and
will not require additional lubrication (oil)
for the life of the fan.
This fan requires little maintenance and
contains no user serviceable parts. DO
NOT try to repair it yourself. Contact
qualied service personnel
if servicing is needed.
TO CLEAN:
1. Before cleaning, turn fan off
and unplug from electrical
outlet. Wipe off excess dust
with a lint free cloth.
2. To ensure adequate air
circulation to the motor, keep
vents located at the rear of
the motor housing free from
dust accumulation. A vacuum
cleaner hose can be used to
clean these vents.
3. DO NOT immerse the fan in
water or any other liquid.
4. Use a dry or slightly damp lint
free cloth to clean the fan.
5. DO NOT allow water or any
other liquid to get into the motor
housing or base.
6. If necessary, the front or rear
grill may be removed in order to
clean the blades, by removing
the four screws around the front
grill. Figure 7.
7. DO NOT plug fan into an
electrical outlet until it has been
fully reassembled.
FIGURE 7
Screws

8
STORAGE TROUBLESHOOTING
1. Disassemble and clean fan
before storing.
2. Keep the original packaging for
the purpose of storing the fan.
3. ALWAYS store the fan in a
dry place.
4. NEVER store the fan while it is
still plugged in.
5. NEVER wrap the cord tightly
around the fan.
6. DO NOT put any stress on the
cord where it enters the fan, as
it could cause the cord to break.
PROBLEM
• Can not adjust the angle of the fan.
SOLUTION
• Loosen the tilt knobs on the side
of the fan. Adjust to the desired
angle and tighten the screw.
If you have tried these troubleshooting
solutions and still have trouble, call
1-888-830-1326 (For CAN: 1-866-
268-1936) or visit our website at
www.HunterFan.com.

9
WARRANTY
The Hunter Fan Company makes the
following limited warranty to the user
or consumer purchaser of this Hunter
Portable Fan:
If your Hunter Portable Fan motor
fails at any time within one year
after the date of sale due to a defect
in material or workmanship, labor
to repair the defect will be provided
free of charge at our nearest service
center or our Service Department
in Memphis, Tennessee. You will
be responsible for labor costs after
this one-year period. The foregoing
limited warranty applies only to the
motor itself, and does not apply to
electronic controls such as remote
controls, remote control receivers or
transmitters used in conjunction with
the motor. These electronic control
items are included in the one year
limited warranty below.
If any part of your Hunter Portable
Fan other than the motor fails at any
time within one year after the date of
sale due to a defect in material or
workmanship, we will repair or, at
our option, replace the defective part
free of charge for parts and labor
performed at our nearest service
center or at our Service Department
in Memphis, Tennessee.
IF THE USER OR CONSUMER
PURCHASER CEASES TO OWN THE
FAN, THIS WARRANTY AND ANY
IMPLIED WARRANTY WHICH THEN
REMAINS IN EFFECT, INCLUDING
BUT NOT LIMITED TO ANY IMPLIED
WARRANTY OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR
PURPOSE, ARE VOIDED. NO
WARRANTY, EXPRESSED OR
IMPLIED, INCLUDING ANY
WARRANTY OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR
PURPOSE, IS MADE IN RESPECT
TO THE GLASS GLOBES OR LIGHT
BULBS OR THE FINISH ON ANY
METAL PORTION OF THE FAN.
THIS WARRANTY IS IN LIEU OF ALL
OTHER EXPRESS WARRANTIES. THE
DURATION
OF ANY IMPLIED WARRANTY,
INCLUDING, BUT NOT LIMITED
TO ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE, IN
RESPECT TO ANY HUNTER FAN
MOTOR OR OTHER FAN PART, IS
EXPRESSLY LIMITED TO THE PERIOD
OF THE EXPRESS WARRANTY SET
FORTH ABOVE FOR SUCH MOTORS
AND OTHER PARTS.
This warranty is voided if your Hunter
Fan is not purchased and used in the
USA.
This warranty excludes and does
not cover defects, malfunctions or
failures of any Hunter Portable
fan which were caused by repairs
by persons not authorized by us,
use of parts or accessories not
authorized by us, mishandling,
improper installation, modifications,
or damage to the Hunter Portable
fan while in your possession, or
unreasonable use, including failure
to provide reasonable and necessary
maintenance.

10
To obtain servicing, contact the
nearest Hunter authorized service
center or the Hunter Fan Company
Service Department, 7130 Goodlett
Farms Pkwy. Suite 400, Memphis,
Tennessee 38016. Please contact us
before shipping your fan to us. If we
authorize you to ship it to us, you
will be responsible for all insurance
and freight or other transportation
charges to our factory service
center. We will return your Hunter
Fan freight prepaid. Your portable
fan should be properly packed
to avoid damage in transit since
we will not be responsible for any
such damage. Proof of purchase is
required when requesting warranty
service. The purchaser must present
sales receipt or other document
that establishes proof of purchase.
IN NO EVENT SHALL HUNTER
FAN COMPANY BE LIABLE FOR
CONSEQUENTIAL OR INCIDENTAL
DAMAGES.
SOME STATES DO NOT ALLOW
LIMITATIONS ON HOW LONG
AN IMPLIED WARRANTY
LASTS OR THE EXCLUSION OR
LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES
SO THE ABOVE LIMITATION MAY
NOT APPLY TO YOU.
THE WARRANTY GIVES YOU
SPECIFIC LEGAL RIGHTS AND
YOU MAY ALSO HAVE OTHER
RIGHTS WHICH VARY FROM
STATE TO STATE.
