Hunter 90437 User manual

Classic Tripod FanClassic Tripod FanClassic Tripod Fan
44834-01
20130305
©2013 Hunter Fan Co.
Owner’s Manual
English
Model
90437
90440

2
TABLE OF CONTENTS
Introduction ............................................................. 3
Safety and Warnings................................................ 3
Grounding............................................................... 5
Fused Plug............................................................... 6
Unpacking............................................................... 7
Base Assembly......................................................... 7
Motor Assembly....................................................... 7
Grill Assembly ......................................................... 8
Operation.............................................................. 10
Off / Speed Selection
Oscillation
Maintenance.......................................................... 11
Technical Support................................................... 12
Warranty............................................................... 12

3
INTRODUCTION
To reduce the risk of fire or electrical shock, DO NOT use
this fan with any solid-state speed control device.
When using electrical appliances, basic precautions
should always be taken to reduce the risk of fire, electric
shock and personal injury:
Read all instructions before using this fan.
1. Improper installation may result in the risk of fire,
electric shock or personal injury.
2. To prevent the risk of fire and electric shock, DO
NOT use the unit near windows. Rain and moisture
may create an electrical hazard.
3. The power plug must be removed from the power
socket when not in use, before cleaning, servicing,
maintenance and before moving to another location.
4. DO NOT put fan in a damp place or where humidity
is high, such as a bathroom.
5. The fan should be placed on a flat, stable surface to
avoid overturning.
6. Use fan only for intended use, as described in this
instruction manual.
7. To protect against electrical shock, DO NOT immerse
any part of the unit in water or spray with liquids.
Thank you for choosing the Hunter Oscillating Stand
Fan. This manual gives you complete instructions for
assembling and using your fan. Here are some the
features you will enjoy with your fan:
3An attractive design that enhances any decor
3A powerful motor for maximum air flow
3Three speeds to adjust your comfort level
3All metal construction
3Parts of this fan, including the blades and the grill,
have been treated with Hunter’s Dust Armor Protection,
making them less likely to attract dust and dirt.
SAFETY AND WARNINGS

4
8. Close supervision is necessary when any appliance
is used near children.
9. NEVER insert fingers, pencils or any other objects
through the grill when the fan is running.
10. DO NOT operate any appliance with a damaged
cord or plug, after the appliance malfunctions or has
been dropped or damaged in any manner.
11. To disconnect, grip plug and pull from wall outlet.
NEVER yank on cord.
12. ALWAYS use on a dry surface.
13. This product is intended for household use only and
not for commercial or industrial use.
14. DO NOT operate fan in the presence of explosive
and/or flammable fumes.
15. DO NOT place fan or any parts near an open flame,
cooking or any other heating appliances.
16. DO NOT use near curtains, plants, window
treatments, etc.
17. This appliance has a grounded three-prong plug
and is suitable for grounded receptacle use only.
An adapter is available for connecting three-blade
grounding-type plugs to two-slot receptacles. The
adapter must be properly grounded. DO NOT
attempt to defeat the purpose of this safely feature.
18. The rubber feet on this product may interact with
wood and cause damage to furniture. Do not place
on fine wood furniture.

5
Figure 1
This appliance is for household use only and may be
plugged into any 120-volt AC electrical outlet (ordinary
household current). DO NOT use any other type of outlet.
This unit is suitable for grounded receptacle use only.
The power cord has a grounded plug as shown in
Figure 1, and must be used with an electrical outlet that
can accommodate the grounding pin. If your electrical
outlet can not accommodate the grounding pin, then you
must purchase and install one of the two types of adapters
shown in Figure 2.
NOTE: The adapters ARE NOT supplied with this fan.
Read, follow, and save the instructions that are included
with the adapter you choose. Do not use an adapter if
your electrical outlet can accommodate the grounding pin.
LINE CORD SAFETY TIPS
1. NEVER pull or yank on the cord or the appliance.
2. To insert plug, grasp it rmly and guide it into the outlet.
3. To disconnect the appliance, grasp the plug and
remove it from the outlet.
4. Before each use, inspect the line cord for cuts and/
or abrasion marks. If any are found, the appliance
should be serviced and the line cord replaced. Please
return it to our Service Department or to an authorized
service representative.
5. NEVER wrap the cord tightly around the
appliance, as this could place undue stress on the
cord where it enters the appliance and could cause
it to fray and break.
6. DO NOT operate appliance if the line cord shows any
damage, if the appliance works intermittently or stops
working entirely.
Grounded
Plug
Grounding Pin
Grounded Outlet
Box Cover
WARNING
Figure 2
Grounded Outlet
Box Cover
Metal
Screw
Adapter
Grounding
Means
GROUNDING

6
Figure 3
This plug is a safety feature. It contains a safety device
(fuse) that should not be removed. Discard product if the
attachment plug is damaged. To reduce the risk of fire,
electric shock and personal injury, DO NOT remove,
replace, repair or tamper with the originally supplied
plug. If the Fan does not function properly, it may be due
to the safety device incorporated in this plug.
If the fuse fails, it is generally due to a short circuit or
circuit overload. Replace the fuse as per the instructions
below. If the replacement fuse fails, immediately
unplug the unit and contact our technical support
department for assistance.
Fuse Replacement:
1. To replace the fuse, first turn the unit it off and unplug
it from the wall. Locate the door on top of the plug.
Figure 3.
2. Slide the door on top of the plug towards the blades.
Figure 4.
3. Carefully remove the fuse from the clips holding it on
the top and bottom. Figure 5.
Warning! Electrical Hazard! Only replace with a
fuse type and rating matching what was removed from
the product.
4. Gently push the fuse back into the pins that will hold
it in place.
Note: If the fuse is not seated properly, the unit will not
function.
5. Slide the Door back over the fuse box in the plug.
6. Plug the fan back in and resume use.
FUSED PLUG
Figure 4
Figure 5

7
TRIPOD ASSEMBLY
Figure 7
1. Fully extend the legs and install the three lower bolts
and the nuts that secure them. Figure 6.
2. Tighten all upper and lower screws using two 10 mm
wrenches.
3. Remove the setscrew from the plastic package.
Extend the inner pole and install the setscrew into the
screw hole on the inner pole. Figure 7.
UNPACKING
As you unpack the fan, save the carton and packing
materials in case you want to move or ship the unit in the
future. Carefully remove all items from the box.
NOTE: It is best to have someone hold the box while
you lift the fan and the protective packaging out of the
carton. Make sure all shipping materials are removed
from fan before operating.
Setscrew
Inner Pole
ATTACHING ASSEMBLY TO POLE
Figure 8
Clip Button
1. Press the clip buttons in completely while sliding the
pole from the motor housing assembly into the inner
pole until the clip buttons appear through the hole in
the inner pole. Figure 8.
Figure 6
Lower Bolt
Upper Bolt

8
Figure 9
Figure 8
Figure 10
Figure 11 Figure 12
GRILL ASSEMBLY
Grill Lines
Grill
Mounting
Screw
Top Tabs
11a
Motor
Notch
Fan Blade
Note: The trim ring may be attached to the front and rear
grills for shipping purposes. If so, remove the trim ring by
loosening the trim ring screw.
1. Remove the four grill mounting screws from the
motor housing. Figure 8.
2. Make sure that the grill is positioned so that three
of the grill lines are completely between the top
tabs. Then place the Back Grill against the Motor
Housing, Figure 9., and line up the four tabs on the
back of the grill to the four screw holes on the front
of the motor.
3. To attach the Back Grill to the Motor Housing
partially install the four grill mounting screws.
Tighten all four screws. Figure 10.
Note: One of the grill mounting screws will have a star
washer on it, for grounding purposes. The other 3 screws
will not have a washer.
4. Loosen the screw on the back of the Blade assembly.
Figure 11a. Slide the Blade assembly onto the
motor shaft. Figure 11.
5. Tighten the Screw on the Blade assembly to secure it
to the Motor. Make sure that the end of the screw is
positioned within the notch on the shaft. Figure 12.
Caution: Ensure when tightening the screw on the back
of the fan blade, you tighten it on the flat part of the
motor shaft.
123

9
Figure 14
Figure 13
Figure 15
GRILL ASSEMBLY (CONT.)
Front Grill
Hunter Logo
Grill
Ring
Screw
Screw
Back Grill
6. Remove the grill ring from the front grill by loosening
the screw holding it.
7. Place the front grill against the back grill so that the
Hunter logo faces right side up and push together until
the tabs on the grills hold them together. Figure 13.
8. Expand the grill ring by loosening the screw that
secures it. Figure 14.
9. Slide the grill ring over both front and back grills
turning the ring so that the screw that secures it, is
on the bottom. Figure 14.
10. Tighten the screw to secure the grill ring over both
the front and back grill. Figure 15.

10
Figure 17
High
Medium
Low
Off
Figure 18
OPERATION
To turn the fan on and off or to control the speed, turn the
speed knob on the top of the motor housing to the proper
setting. Figure 17.
Off / Speed Selection
Oscillation
To allow the fan to oscillate, push the knob beside the fan
speed control down. Pull up on the knob if oscillation is
not desired. Figure 18.
Oscillation
Knob
