Owner’s Guide and Installation Manual
Lifetime Limited Warranty
If purchased from our authorized dealer, this ceiling fan is warranted to the original purchaser by Casablanca Fan Company against defects in materials and workmanship for the following: Motor excluding Electronics...........................................................................................................................................................................................Lifetime Component Parts, Electronic or Manual Control, Blades, Light Fixture, and Finish...........................................................................................................One Year
Light bulbs ..........................................................................................................................................................................................................No Warranty During the warranty period, we repair (or, at our option, replace at no charge) a defective product. For details, contact Casablanca at 1-888-227-2178 or visit us on the Web at www.CasablancaFanCo.com. HOW TO OBTAIN SERVICE: Contact Casablanca for the name of the nearest Authorized Service Center or refer to the Authorized Service Centers list included with this Owner’s Manual. Do not return your fan without approval from Casablanca Fan Company. Should it become necessary to return your fan to an Authorized Service Center, make sure it is packaged properly to avoid in-transit damage, which is not covered by this warranty.
WHAT IS NOT COVERED:
Casablanca Fan Company requires the use of genuine Casablanca accessories with this fan.
Where a failure of this fan is caused by the use of accessories not supplied by Casablanca, this warranty is void.
This warranty does not apply if the product has been damaged by improper installation, neglect, accident, misuse, exposure to extremes of heat or humidity, or as a result of
service or modication by other than a Casablanca Authorized Service Center. In addition, this warranty does not cover minor variations in plated metal nishes due to the
imperfect nature of the plating and nishing process. Handblown glass may contain blisters, seeds, or thin lines. These characteristics are not defects, but substantiate that this
is hand blown and handcrafted glass. All costs of installing, removing, and reinstalling the product are the responsibility of the owner. Under-warranty motors requiring repair
must be shipped to the factory for replacement. Casablanca will pay for shipping charges incurred in sending the defective product from the customer to Casablanca Fan
Company as well as for return UPS shipment. No other expressed warranty is given. The repair or replacement of a product is the consumer’s exclusive remedy.
Any implied warranty of merchantability or tness is limited for consequential or incidental damages. IN-HOME SERVICE: Casablanca offers In-Home Service where available as follows: Within the rst 120 days, Casablanca will send a eld service representative to repair or replace the part or parts deemed to be defective from the factory. Most Service Center contracts cover up to a 30-mile radius from their place of business. Casablanca will not cover repairs caused by improper installation. After the 120-day period, the consumer will be charged for the service call and labor. Casablanca will pay for all defective parts through the duration of the parts warranty. NOTE: Service Centers are required to submit a Proof of Purchase with each warranty claim. The consumer must provide a copy of the Proof of Purchase at the time of service. If no in-home service is available, the consumer has the option of sending an in-warranty fan to Casablanca Fan Company in Memphis, TN, for repair. The fan must be packaged properly, shipped freight prepaid, and include a copy of the Proof of Purchase. The fan will be repaired and returned at no charge to the consumer, freight prepaid.
WhitmanWhitmanWhitman
1.888.227.2178
IMPORTANT!
______________________________
Model Number
______________________________
Date Purchased
______________________________
Where Purchased
Read and Save These Instructions
The information below will make
communication MUCH easier
should you ever need to contact
customer service.
If parts are missing,
DO NOT RETURN THIS ITEM
TO THE STORE!
For assistance call 1-888-227-2178
www.CasablancaFanCo.com
All manuals and user guides at all-guides.com
all-guides.com

5
7
20
28
24
#Item# in Parts List
Spare Parts Bag
Hardware drawn to scale
For your convenience, you may receive extra fasteners.
Casablanca Fan Company • 7130 Goodlett Farms Parkway #400 • Memphis, TN 38016 • www.CasablancaFanCo.com • 98000-03-172 • 04-04-2013 • ©2013
90
80
92
76
51
Included Accessories
56 26
Pre-installed Parts
125
65
60 61
124
18 126
77
106108
97
98
96
100
9381 140
104101
Parts List
MODEL # 59059 59061
DRAWING # K1277-01 K1277-02
Weight ±2 lbs 23.7 lbs (10.7 kg) 23.7 lbs (10.7 kg)
FINISH Brushed Nickel Bronze Pana
Item# Item Name Qty. Part# Part#
1Hanging System Kit 1 K0319-01 K0319-01
5Ceiling Bracket 1
7Canopy 1
18 Canopy Screw 3
20 Wood Screw 3” 2
24 Flat Washer 2
26 Mounng Isolator 4
28 Wire Connector 4
50 Hardware Kit 1 K1277-00-860 K1277-00-861
51 Blade Assembly Screw 16
56 Setscrew 1
60 Light Kit Screw 3
61 Wire Connector (ceramic) 2
65 Light Fixture Screw 3
76 Light Kit Assembly 1 K1316-01 K1316-01
77 Light Fixture Assembly 1 K1317-01 K1317-01
78 Reverse Switch Assembly (not shown) 1 K0283-01 K0283-01
80 Globe/Shade 1 K1298-01-045 K1298-01-045
81 E12 Bulb 5 76323-01 76323-01
90 Finial Cap 1 76413-01 76413-01
92 Finial 1 76414-01 76414-01
93 Halogen Bulb 2 63852-05 63852-05
96 Blade Iron Set 1 K1301-05 K1301-05
97 Blade Medallion Set 1 K1302-05 K1302-05
98 Blade Set 1 K0586-25-144 K0586-25-145
100 Blade Ring 1 K1300-01 K1300-01
101 Blade Ring Screw 6 K0335-03 K0335-03
104 Blade Iron Armature Screw 11 76874-01 76874-01
106 Remote Control Receiver 1 K0219-02 K0219-02
108 Wall Control 1 K0223-01 K0223-01
124 Downrod Assembly 1 K0071-07 K0071-07
125 Adapter Cover 1 K1321-01 K1321-01
126 Adapter Cover Screw 3 K0062-11 K0062-11
140 Balancing Kit 1 K0118-01 K0118-01
PARTS GUIDE
