Hunter 90626-WH User manual

Tripod Fan
T
ripod FanTripod Fan
Owner’s Manual
English
Model
61810-01
R20210301
90626-WH
90626-ORB
90626-GP
90626-WG

2
TABLE OF CONTENTS
Introduction ............................................................. 3
Safety and Warnings................................................ 3
Fused Plug............................................................... 5
Unpacking............................................................... 6
Fan Assembly........................................................... 6
7
8
Operation................................................................
7
7
Off / Speed Selection
Fan Tilt Adjustment
Maintenance............................................................
Technical Support......................................................9
Troubleshooting ........................................................9
Warranty..................................................................9
61810-01 R20210301

361810-01 R20210301
INTRODUCTION
Thank you for choosing the Hunter Tripod Fan. This
manual gives you complete instructions for assembling
and using your fan. Here are some of the features you
will enjoy with your fan:
An attractive design that enhances any decor
Three speeds to adjust your comfort level
All metal construction
SAFETY AND WARNINGS
READ AND SAVE THESE INSTRUCTIONS! To reduce
When using electrical appliances, basic precautions
should always be taken to reduce the risk electric
shock and personal injury:
Read all instructions before using this fan.
1. Improper installation may result in the risk of
electric shock or personal injury.
2. To prevent the risk of and electric shock, DO
NOT use the unit near windows. Rain and moisture
may create an electrical hazard.
3. The power plug must be removed from the power
socket when not in use, before cleaning, servicing,
maintenance and before moving to another location.
4. DO NOT put fan in a damp place or where humidity
is high, such as a bathroom.
5. The fan should be placed on a stable surface to
avoid overturning.
6. Use fan only for intended use, as described in this
instruction manual.
7. To protect against electrical shock, DO NOT immerse
any part of the unit in water or spray with liquids.
with any solid-state speed control device.
8. Close supervision is necessary when any appliance
is used near children.

461810-01 R20210301
9. NEVER insert pencils or any other objects
through the grill when the fan is running.
10. DO NOT operate any appliance with a damaged
cord or plug, after the appliance malfunctions or has
been dropped or damaged in any manner. Discard
fan or return to an authorized service facility for
examination and/or repair.
11. To disconnect, grip plug and pull from wall outlet.
NEVER yank on cord.
12. ALWAYS use on a dry surface.
13. This product is intended for household use only and
not for commercial or industrial use.
14. DO NOT operate fan in the presence of explosive
15. DO NOT place fan or any parts near an open
cooking or any other heating appliances.
16. DO NOT use near curtains, plants, window
treatments, etc.
17.
1.
2. Children should be supervised to ensure that they do
not play with the appliance.
This appliance is not intended for use by persons
(including children) with reduced physical, sensory, or
intellectual disabilities, and persons with lack of
experience, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
WARNING
This appliance has a polarized plug (one blade is
wider than the other). To reduce the risk of shock,
safety feature.
18. Do not run cord under carpeting. Do not cover cord
with throw rugs, runners, or similar coverings. Do
not route cord under furniture or appliances.
will not be tripped over.

5
Figure 1
Fi 1
This plug is a safety feature. It contains a safety device (fuse)
that should not be removed. Discard the product if the
electric shock and personal injury, DO NOT remove,
replace, repair or tamper with the originally supplied plug.
If the fan does not function properly, it may be due to the
safety device incorporated in this plug.
If the fuse fails, it is generally due to a short circuit or circuit
overload. Replace the fuse as per the instructions below. If
the replacement fuse fails, immediately unplug the unit and
contact our technical support department for assistance.
Warning! Electrical Hazard!
only with 5 Amp, 125 Volt fuse. If the product fails a
second time, immediately unplug it and contact our
technical support at 1-888-880-3267.
Note: If the fuse is not seated properly, the unit will not
function.
1. Grasp plug and remove from the receptacle or other
outlet device. Do not unplug by pulling on cord. Locate
the door on top of the plug. Figure 1
2. Open fuse cover. Slide open fuse access cover on
top of attachment plug towards blades. Figure 2.
3. Turn fuse holder over to remove fuse. Remove
fuse carefully. Figure 3.
4. Gently push the fuse back into the pins that will hold it
in place.
5. Close fuse cover. Slide the fuse cover closed on the
plug.
6. not replace attachment plug. Contains a safety device
(fuse) that should not be removed. Discard product if
the attachment plug is damaged.
Figure 2
Fi
2
FUSED PLUG
61810-01 R20210301
User Servicing Instructions:
Fuse Replacement:
Figure 3
Fi
2

6
FAN ASSEMBLY
Figure 5
Figure 6
1.
UNPACKING
As you unpack the fan, save the carton and packing
Follow below steps to attach the fan head to the tripod.
materials in case you want to move or ship the unit in the
future. Carefully remove all items from the box.
NOTE: It is best to have someone hold the box while
you lift the fan and the protective packaging out of the
carton. Make sure all shipping materials are removed
from fan before operating.
N
OTE: It is
b
est to
h
ave someone
h
o
ld
t
h
e
b
ox w
h
i
l
e
y
ou lift the fan and the protective packaging out of the
carton. Ma
k
e sure a
ll
s
h
ipping materia
l
s are remove
d
f
rom
f
an be
f
ore operating.
Figure 4
level surface. (Figure 4)
2. Remove the bolt cover from the top of tripod
adapter, then loosen the bolt and the nut by turning
the nut counter-clockwise. (Figure 5)
4. Place the bolt cover back onto the tripod. (Figure 7)
3. Turn the fan head perpendicular to the fan head
slot of the tripod adapter, making sure the hole on
the fan head bracket align with the hole on the
tripod adapter. Insert the bolt through the aligned
holes and tighten with the nut to secure the fan head
in position. (Figure 6)
61810-01 R20210301
Figure 7
Bolt Cover
Bolt Cover
Bolt
Bolt
Fan Head
Bracket
Fan Head
Nut
Nut

Figure 9
OPERATION
Turn the fan “ON” or “OFF” by rotating the power/speed
knob at the back of the fan head. The power should
always be OFF before unplugging the fan. To select the
speed, turn speed control from OFF to the desired speed
setting: 0 (off), 1 (low), 2 (medium), 3 (high). (Figure 8)
Off / Speed Selection
Fan Tilt Adjustment
adjusted the fan head manually to the desired angle.
(Figure 9)
61810-01 R202103017
0
2
3
1
Figure 8

MAINTENANCE
This fan is permanently lubricated and will not require
additional lubrication (oil) for the life of the fan.
This fan requires little maintenance and contains
if servicing is needed.
outlet. Wipe off excess dust with a lint-free cloth. To ensure
adequate air circulation to the motor, keep vents located
at the rear of the motor free from dust accumulation. A
vacuum cleaner hose can be used to clean these vents.
DO NOT immerse the fan in water or any other liquid.
CLEANING THE FAN:
1. Turn the fan off and unplug from the electrical outlet.
2.
Use a dry or slightly damp lint-free cloth to clean
Use a soft, slightly damp cloth to wipe the remaining
fan parts.
DO NOT allow water or any other liquid to get into
the motor housing or base.
DO NOT plug the fan into an electrical outlet until it
has been fully reassembled.
the fan.
Before cleaning, turn the fan off and unplug from electrical
61810-01 R202103018

9
TROUBLESHOOTING
1. Problem
Cannot adjust the angle of the fan.
Solution
Loosen the screws on the side of the fan head bracket.
Adjust to the desired angle and tighten the screws.
W
W
W
WARRANTY
Hunter Home Comfort makes the following limited
warranty to the user or consumer purchaser of this Hunter
Portable Fan:
If your Hunter Portable Fan motor fails at any time
within one year after the date of sale due to a defect in
material or workmanship, labor to repair the defect will
be provided free of charge at our nearest service center
will be responsible for labor costs after this one-year
period. The foregoing limited warranty applies only to
the motor itself, and does not apply to electronic controls
such as remote controls, remote control receivers or
transmitters used in conjunction with the motor. These
electronic control items are included in the one year
limited warranty below.
If any part of your Hunter Portable Fan other than the
motor fails at any time within one year after the date of
or our Service Department in Kennesaw, Georgia. You
TECHNICAL SUPPORT
If you need any assistance with setup, operation, or parts
for your new Hunter Portable Fan, please call us. Our
technical support staff is ready to help! We are open
24 hours a day, 7 days a week.
You may also reach us online at
www.HunterHomeComfort.com.
An electronic copy of this user manual can also be
obtained online at www.HunterHomeComfort.com.
USA: 1-888-880-3267 (FANS)
[email protected]
61810-01 R20210301

10
W
W
W
sale due to a defect in material or workmanship, we
will repair or, at our option, replace the defective part
free of charge for parts and labor performed at our
nearest service center or at our Service Department in
Kennesaw, Georgia.
IF THE USER OR CONSUMER PURCHASER CEASES TO
OWN THE FAN, THIS WARRANTY AND ANY IMPLIED
WARRANTY WHICH THEN REMAINS IN EFFECT,
INCLUDING BUT NOT LIMITED TO ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, ARE VOIDED. NO WARRANTY,
EXPRESSED OR IMPLIED, INCLUDING ANY WARRANTY
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE, IS MADE IN RESPECT TO THE GLASS GLOBES
OR LIGHT BULBS OR THE FINISH ON ANY METAL
PORTION OF THE FAN. THIS WARRANTY IS IN LIEU
OF ALL OTHER EXPRESS WARRANTIES. THE DURATION
OF ANY IMPLIED WARRANTY, INCLUDING, BUT
NOT LIMITED TO ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE, IN RESPECT TO ANY HUNTER FAN MOTOR
OR OTHER FAN PART, IS EXPRESSLY LIMITED TO THE
PERIOD OF THE EXPRESS WARRANTY SET FORTH
ABOVE FOR SUCH MOTORS AND OTHER PARTS.
This warranty is voided if your Hunter Fan is not
purchased and used in the contiguous United States.
This warranty excludes and does not cover defects,
malfunctions or failures of any Hunter Portable fan
which were caused by repairs by persons not authorized
by us, use of parts or accessories not authorized by
us, mishandling, improper installation,
or damage to the Hunter Portable fan while in your
possession, or unreasonable use, including failure to
provide reasonable and necessary maintenance.
To obtain servicing, contact the nearest Hunter
authorized service center or the Hunter Home Comfort
service center. We will return your Hunter Fan freight
avoid damage in transit since we will not be responsible
before shipping your fan tous. Ifwe authorize you to
ship it to us, you will be responsible for all insurance and
prepaid. Your portable fan should be properly packed to
freight or other transportation charges to our factory
Service Department, 980 Cobb Place Boulevard NW,
Suite 100, Kennesaw, GA 30144. Please contact us
61810-01 R20210301

11
Hunter is a trademark of the Hunter Fan Company
and is used under license to Hunter Home Comfort.
W
W
W
for any such damage. Proof of purchase is required
when requesting warranty service. The purchaser must
present sales receipt or other document that establishes
proof of purchase.
FOR CONSEQUENTIALORINCIDENTAL DAMAGES.
SOME STATES DO NOT ALLOW LIMITATIONS ON
HOW LONG AN IMPLIED WARRANTY LASTS OR
THE EXCLUSION OR LIMITATION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES SO THE ABOVE
LIMITATION MAY NOT APPLY TO YOU.
THE WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS
AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH
VARY FROM STATE TO STATE.
Printed in China
IN NO EVENT SHALL HUNTER HOME COMFORT BE LIABLE
980 Cobb Place Boulevard NW, Suite 100,
Kennesaw, GA 30144
61810-01 R20210301
