Hupfer ISOBOX Mobil Basic Series User manual

91338723_A0
Operating Instructions
ISOBOX® Mobil
Basic

Section 1Introduction
Page 2 Appliance Information
ISOBOX® Mobil
Basic 91338723_A0
1 Introduction
1.1Appliance Information
Appliance name ISOBOX® Mobil
Appliance type/s Basic
Manufacturer HUPFER® Metallwerke GmbH & Co. KG
Dieselstrasse 20
48653 Coesfeld
Germany
Postfach 1463
48634 Coesfeld
Germany
'[phone]
6+49 2541 805 111
www.hupfer.de
[e-mail]
ISOBOX® Mobil
Basic
Read and understand these operating instructions to ensure safe operation and avoid any damage or injury!
Ensure that operating staff have been briefed regarding sources of danger and possible incorrect handling.
Subject to modifications
The products covered by these operating instructions have been developed while taking into account market
requirements and the latest technology. HUPFER®reserves the right to modify the products and related
technical documentation in the interests of technical progress. The data and weights as well as the descrip-
tion of performance and functions assured in the order confirmation as binding are always decisive.
Translation of the original edition
Manual edition
91338723_A0

Introduction Section 1
Table of Contents Page 3
ISOBOX® Mobil
91338723_A0 Basic
1.2Table of Contents
1Introduction 2
1.1 Appliance Information 2
1.2 Table of Contents 3
1.3 List of Abbreviations 5
1.4 Definitions of Terms 6
1.5 Orientation of the Appliance 7
1.6 Notes on Using the Manual 8
1.6.1 Notes on the Manual Structure 8
1.6.2 Notes and their Representation used in all Sections 8
2Safety Instructions 9
2.1 Introduction 9
2.2 Warning Symbols Used 9
2.3 Safety Instructions for Appliance Safety 9
2.4 Safety Instructions for Transport 10
2.5 Safety Instructions for Cleaning and Care 10
2.6 Safety Instructions Regarding Fault Repair 10
3Description and Technical Data 11
3.1 Performance Description 11
3.2 Proper Use 11
3.3 Improper Use 11
3.4 Device description 12
3.4.1 ISOBOX® Mobil Basic 12
3.4.2 Appliance Description 12
3.4.3 Equipment and Optional Accessories 13
3.4.4 Technical Data 13
3.5 Rating Plate 14
4Transport, Initial Operation and Taking out of Service 15
4.1 Transport 15
4.2 Commissioning 15
4.3 Storage and Recycling 16
5Operation 17
5.1 Operation 17
5.2 Tasks to complete at end of working day 17
6Troubleshooting and Repair 18
6.1 Instructions regarding Fault Repair 18
6.2 Fault and Action Table 18

Section 1Introduction
Page 4 Table of Contents
ISOBOX® Mobil
Basic 91338723_A0
7Cleaning and Care 19
7.1 Hygiene Measures 19
7.2 Cleaning and Care 19
7.3 Special Care Instructions for Aluminium Surfaces 19
7.4 Special Care Instructions for Stainless Steel 20
8Spare Parts and Accessories 21

Introduction Section 1
List of Abbreviations Page 5
ISOBOX® Mobil
91338723_A0 Basic
1.3List of Abbreviations
Abbreviation Definition
BGRGerman Employers' Liability Insurance Association rule (Berufsgenossenschaftliche Re-
gel)
BGVGerman Employers' Liability Insurance Association regulations (Berufsgenossenschaft-
liche Vorschrift)
CE Communauté Européene
European Community
DINGerman Institute for Standardisation, technical regulations and technical specifications
E/VSpare or wearing part (Ersatz- bzw. Verschleißteil)
EC European Community
European Community
EN European Standard (Europäische Norm)
Harmonised standard for the EU market
HACCP Hazard Analysis and Critical Control Points
Hazard analysis of critical control points
IP International Protection. The abbreviation IP and a further two-digit index specify the
protection class of a housing.
The first digit: Protection against ingress of solid foreign objects The second digit: Protection against ingress of water
0 No protection against contact, no protec-
tion against ingress of solid foreign
bodies
0 No protection against ingress of water
1 Protection against contact with any large
surface of the body such as the hand,
protection against ingress of foreign
objects Æ>2.0'' (50 mm)
1 Protection against dripping water (verti-
cally falling drops)
2 Protection against contact with the
fingers, protection against ingress of
foreign objects Æ> 0.5'' (12 mm)
2 Protection against dripping water (at any
angle up to 15° from the vertical)
3 Protection against contact with tools,
wires or similar objects of > 0.10'' (2.5
mm),protection against foreign objects
>0.10'' (2.5 mm)
3 Protection against water drips at any
angle up to 60° from the vertical
4 Protection against contact with tools,
wires or similar objects of >0.04'' (1 mm),
protection against foreign objects > 0.04''
(1 mm)
4 Protection against water splashing from
any direction
5 Protection against contact, protection
against dust deposits inside 5 Protection against water jets (projected by a nozzle) at any angle
6 Complete protection against contact,
protection against ingress of dust 6 Protection against rough sea or strong water jets (flood protection)
7 Protection against ingress of water
during temporary immersion
8 Protection against pressurised water
during continuous immersion
LEDLight Emitting Diode
Light diode
LMHV Regulation on the hygiene of foodstuffs
RCD Residual Current Device
Residual current device (RCD)
STBSafety temperature limiter

Section 1Introduction
Page 6 Definitions of Terms
ISOBOX® Mobil
Basic 91338723_A0
1.4Definitions of Terms
Term Definition
Authorised specialist An authorised specialist is a specialist that has been trained by the manufacturer, an
authorised service dealer or a company assigned by the manufacturer.
Check, inspect Compare with certain conditions and/or characteristics such as damage, leaks, filling
levels and heat.
Cleaning system-resistant The suitability of the appliance for cleaning in an automated cleaning system is lim-
ited. It is possible to achieve a flawless, reproducible cleaning and drying result, but it
cannot be guaranteed.
The exterior and interior housing are produced to standard specifications. Water
ingressing hollow spaces resulting from the design of the appliance can run off without
hindrance. Water collection in hollow spaces is avoided. Installed electrical compo-
nents and electrical wiring are protected by appropriate sealing (for example, labyrinth
edges, sealing profiles, cable channels) against any form of penetration by water.
Protection class IPX6 (powerful pressurised water) to DIN EN 60529 (VDE 0470) is
guaranteed. It is possible that water remains and is carried over following the drying
process.
Convection Physical properties or mass transfer (e.g. heat or cold) through currents in gases and
liquids.
Cook&Chill Kitchens "Cook and Chill": Kitchens where warm food is chilled as quickly as possible after
being cooked.
Cook&Serve Kitchens "Cook and Serve": Kitchens where warm food is served immediately after being
cooked or kept warm until it is consumed.
Corrosion The chemical reaction of a metallic material with its surroundings, e.g. rust.
Cover A bell-shaped cover for keeping food warm on plates and dishes.
Element formation Also: contact corrosion. Occurs when different noble metals are in close contact with
each other. This happens when a corrosive medium is between both metals, such as
water or even normal air moisture.
EM field Electrical, magnetic or electromagnetic field that is defined by its field intensity and
phase formation.
EN tray A European standard tray is a tray in a standard size.
EN 1/1 corresponds to 20.9x14.6'' (530×370 mm), EN 1/2 corresponds to 14.6x10.4''
(370×265 mm).
Gastronorm Gastronorm is a measurement system used worldwide in places such as food pro-
cessing plants or large-scale kitchens. The use of standardised sizes makes it possi-
ble to exchange food pans. The basic size of the Gastronorm (GN) 1/1 is 12.8 x 20.9''
(530 × 325 mm). Items are available in different depths.
GN tray A Gastronorm standard tray is a standard-size tray.
GN 1/1 corresponds to 20.9x12.8'' (530×325 mm), GN 1/2 corresponds to 12.8x10.4''
(325×265 mm).
H1 Hygienic standard (NSF/USDA) for lubricants that are suitable for incidental and
technically unavoidable contact with foodstuffs.
HACCP The HACCP concept is a preventive system that should ensure the safety of foods
and consumers.
Instructed person An instructed person is a person who has been instructed on the possible risks result-
ing from improper behaviour when carrying out an assigned task and regarding the
necessary protective equipment and protective measures, and who has been trained
for this task, if necessary.
Lift A movement, for example a vertical movement of the guide basket from bottom to top.
LMHV German Regulations on the Hygiene of Foodstuffs Regulations regarding hygiene
requirements for producing, handling and placing food on the market
Machine safety The term machine safety refers to all the measures used to avert injury to persons.
The basis for machine safety is directives and laws for protecting users of technical
devices and systems valid nationally and across the EC.
Passive layer A non-metallic protective layer on a metallic material that prevents or slows down
material corrosion.

Introduction Section 1
Orientation of the Appliance Page 7
ISOBOX® Mobil
91338723_A0 Basic
Term Definition
Porcelain Standard Porcelain Standard is a measurement system for porcelain plates devised by
HUPFER®.
The basic size of Porcelain Standard (PN) 1/1 is 8.7 x 6.3'' (220x160 mm) (1/2 PN
conforms to 4.3x6.3'' (110x160 mm), 1/4 PN conforms to 6.3x3.1'' (160x80 mm)). The
fitting lids have the following dimensions: 1/1 PN 9x6.6'' (228x168mm), 1/2 PN
4.4x6.3'' (111x161mm), 1/4 PN 4.4x3.2'' (111x81mm).
Protection class 0 ¯
I
II
III
Qualified person,
qualified personnel Qualified personnel are persons who due to their professional training, experience, instruction and their knowledge of relevant standards, guidelines, accident prevention
regulations and operating conditions have been authorised by a person responsible
for system safety to carry out required activities and can recognise and prevent any
potential hazards (definition of specialists according to IEC 364).
Schuko® The abbreviation of the German term "Protective contact" indicates a system of do-
mestic plugs and sockets equipped with protective earthed contacts used in most of
Europe.
Specialist A specialist is a person who can assess work assigned and can recognise possible
hazards themselves based on their professional training, skills, experience and
knowledge of the respective guidelines.
Suitable for washing devices The appliance is suitable for cleaning in an automated cleaning system without re-
strictions. Following agreement with the manufacturer the cleaning system must
achieve a hygienic, constant cleaning and drying result, which is to be approved by a
third party (client).
The exterior and interior housing are manufactured to a standard guaranteeing her-
metic sealing. It is not possible for water jets to ingress into hollow spaces in the
appliance. Installed electrical components and electrical wiring are protected by ap-
propriate sealing against any form of penetration by water. Protection class IPX6
(powerful pressurised water) to DIN EN 60529 (VDE 0470) is guaranteed. No water
remains or is carried over following the drying process.
Verify, test Compare with certain values such as weight, torque, content or temperature.
VESKA standard Trays as per the VESKA standard are items used for distributing food in hospitals,
principally in Switzerland; they measure 20.9x14.6'' (530x375 mm).
1.5Orientation of the Appliance
The front
"The front" refers to the side where the appliance is loaded.
The rear
"The rear" refers to the opposite side to the front.
The right
"The right" refers to the right hand side when viewed from the front side (front).
The left
"The left" refers to the left hand side when viewed from the front side (front).

Section 1Introduction
Page 8 Notes on Using the Manual
ISOBOX® Mobil
Basic 91338723_A0
1.6Notes on Using the Manual
1.6.1 Notes on the Manual Structure
This manual is divided into function- and task-focused sections.
1.6.2 Notes and their Representation used in all Sections
The warnings and notes are separated from the other text and particularly marked by corresponding icons.
The icon cannot, however, replace the text of the safety instructions. Therefore, always read thoroughly the
full text of the safety instructions. The warnings and notes are separated in these operating instructions as
follows and categorised by the following danger levels by means of various symbols.
DANGER Brief description of hazard
There is an imminent threat to life and physical well-being for the user and / or
third parties if instructions are not followed precisely or the circumstances
described are not taken into account.
The type of hazard is indicated by a symbol and explained in the accompany-
ing text in more detail. The general symbol for danger is used in this example.
WARNING Brief description of hazard
There is an indirect threat to life and physical well-being for the user and / or
third parties if the instructions are not followed precisely or the circumstances
described are not taken into account.
The type of hazard is indicated by a symbol and explained in the accompany-
ing text in more detail. The general symbol for danger is used in this example.
CAUTION Brief description of hazard
There is a potential risk of injury or property damage if the instructions are not
followed precisely or the circumstances described are not taken into account.
The type of hazard is indicated by a general symbol and explained in the
accompanying text in more detail. The general symbol for danger is used in
this example.
NOTE Brief description of additional information
Attention is pointed to special conditions or additional important information on
the topic concerned.
INFO Short title
It contains additional information on work ease or recommendations on the
topic concerned.

Safety Instructions Section 2
Introduction Page 9
ISOBOX® Mobil
91338723_A0 Basic
2 Safety Instructions
2.1Introduction
The section on safety instructions describes the risks associated with the appliance in terms of product liabil-
ity (according to the EU Directives).
The safety instructions are meant to warn of hazards and help to avoid damage to persons, the environment
and property. Please make sure that you have read and understood all the safety instructions given in this
section.
The valid national and international Safety at Work Regulations must be complied with. The manufacturer is
responsible for the valid regulations he/she has to provide. He/she must acquaint himself/herself and the op-
erator with the new regulations.
In addition to these operating instructions, comply with the Health and Safety rules of the German Federation
of the Statutory Accident Insurance Institutions for the Industrial Sector, especially with those that concern
the handling of hot items and risks involved (BGR 110 "Protection of health and safety at work in restaurants"
and BGR 111 "Protection of health and safety at work in large-scale kitchens").
2.2 Warning Symbols Used
Symbols are used in these operating instructions to indicate the dangers that may occur while operating or
cleaning the appliance. In both cases, the symbol provides information on the type and circumstances of
hazards.
The following symbols may be used:
General hazard area
2.3Safety Instructions for Appliance Safety
The appliance is operated safely if it is used correctly and carefully. Negligent handling of the appliance can
lead to a threat to life and physical well-being for the user and / or third parties as well as hazards for the ap-
pliance itself and the operator's other property.
The following points are to be observed to ensure the appliance safety:
§The appliance may only be operated as intended, when it is in perfect condition with regards to tech-
nical standards, with awareness of safety and hazards and in accordance with the operating instruc-
tions.
§All operating and actuating elements must be in a perfect and fail-safe condition with regards to tech-
nical standards.
§Before putting the appliance into operation, the appliance must be checked for external visible dam-
age and defects. In case of damage, immediately inform the competent bodies and switch off the ap-
pliance.
§Modifications or retrofits to the equipment are only permitted after consultation with the manufacturer
and upon receipt of their consent in writing.
§The appliances can only be operated under continuous supervision.
§Move the appliance only with the doors closed. Unless the doors are properly closed, they may open
during transport and cause damage or lead to injuries.
§Release both total locks before moving the appliance. Moving the appliance when the total locks are
engaged can damage the chassis.
§The appliance may only be transported over level floors. Moving the appliance over very uneven
floors and stair steps can damage the chassis.

Section 2Safety Instructions
Page 10 Safety Instructions for Transport
ISOBOX® Mobil
Basic 91338723_A0
§Do not brake the appliance by applying the total locks. The total locks are designed to prevent the
appliance from moving of its own accord. Do not park the appliance on sloping floors.Secure the ap-
pliance against rolling away by applying both total locks after parking.
§When approaching walls and moving round obstacles, always be aware for persons in your path. Risk
of injury.
§When transporting the appliance, hold the push handles or push bars with your hands. Never let go of
the appliance while moving it.
§Move no faster than at walking pace when transporting the appliance. Heavily laden appliances are
difficult to brake and steer. If necessary, ask for assistance when transporting the appliance.
§Never try to catch the appliance with your hands if it tips over due to carelessness or external circum-
stances. Risk of injury.
2.4 Safety Instructions for Transport
The following aspects are to be taken into account when transporting the appliance:
§When loading, use only hoistsand load lifting devices approved for the weight of the appliance to be
lifted.
§The appliances have to be safely secured when transported off site inside a vehicle such as a truck.
The total locks are not suitable for securing the appliances when they are transported in a vehicle.
§Only use transport vehicles that are approved to carry the weight of the appliance.
§Do not put a defective appliance into operation under any circumstances and inform the supplier im-
mediately in such a case.
2.5 Safety Instructions for Cleaning and Care
The following aspects must be taken into account when performing any cleaning and care tasks:
§ISOBOX® Mobil can be cleaned in an automated cleaning system. The appliance design ensures
that cleaning agents are able to reach and clean the entire surface of the appliance and guarantee a
perfectly hygienic, reproducible end result after cleaning and drying.
§Cleaning instructions must be strictly observed for reasons of hygiene.
2.6 Safety Instructions Regarding Fault Repair
The following aspects must be taken into account when carrying out any troubleshooting work:
§The local Accident Prevention Regulations in force must be observed.
§Observe the valid product safety regulations for the product when handling oils, greases and other
chemical substances.
§Only authorised specialists may repair any faults or malfunctions.
§Only use original spare parts to replace defective components.

Description and Technical Data Section 3
Performance Description Page 11
ISOBOX® Mobil
91338723_A0 Basic
3 Description and Technical Data
3.1Performance Description
Appliances in the ISOBOX® Mobil Basic model range are designed for transporting and serving foodstuffs in
large-scale kitchens, catering operations, refectories and works canteens. They carry prepared meals in
Gastronorm containers or baskets and on grids.
All models can be adapted on an individual basis, i.e. the layout and features, such as the box layout, col-
ours or casters, can be flexibly matched to respective requirements and adapted to needs.
3.2 Proper Use
The appliances are intended to transport meals in Gastronorm containers or portioned meals on grids, in
baskets or on trays.
Appliances with a circumferential gallery may transport objects that have a firm base and are placed on the
non-slip pad to protect them against falling off (such as crockery, cutlery and napkins in suitable transport
containers or on trays). The appliance lid has a maximum load bearing capacity of 10 kg
Proper use includes observing specified procedures, compliance with the technical specifications and use of
supplied or optional original accessories.
Any other use of the appliance is considered as unintended use.
3.3 Improper Use
The following is also considered as improper use of the appliance:
§Any change to the appliance's performance parameters beyond the guaranteed values.
§Operating a defective appliance.
§Improper installation, commissioning, operation or maintenance of the appliance.
§Inserting objects which severely impede the functioning of the appliance.
§Transporting or carrying persons. Under no circumstances may people sit down or stand in or on the
appliance.
§Transporting open containers with hot liquids.
§Appliances without a circumferential gallery are not intended to be used as a storing surface for items.
§Moving the appliance with the doors open.
Any other use is not permitted and it is considered as improper use. The manufacturer and suppliers are not
liable for any consequential damage resulting from unintended use. No liability is assumed and no warranty
claims can be submitted for damages caused by improper use.

Section 3Description and Technical Data
Page 12 Device description
ISOBOX® Mobil
Basic 91338723_A0
3.4Device description
3.4.1 ISOBOX® Mobil Basic
Figure 1 ISOBOX® Mobil Basic
1 Guards 6 Disc bumper
2 Magnetic fastener 7 Door lock
3 Push bar 8 Support rails
4 Fixed caster 9 Gallery (Accessories)
5 Swivel caster with total lock
3.4.2 Appliance Description
The appliances in the ISOBOX® Mobil Basic model range can be configured in a wide variety of ways and
may be fitted with optional accessories.
The main body of the appliance may consist of one or two boxes. If two boxes are used, they can be placed
in a vertical or horizontal layout.
Doors, rear and side panels are made of powder-coated aluminium. You can obtain information on available
colours from HUPFER® or consult our website.
The interior casing features seamlessly deep-drawn tray beads. The bead walls and interior panelling can be
made of plastic or stainless steel. Large radii and smooth surfaces without undercut contours ensure that the
interior can be easily cleaned. The trays are inserted in longitudinal direction from the front. The hinged
doors can pivot 270°. They can be locked and also held in position by a magnet when open.
The push bars and lightweight design provide optimum ergonomic characteristics and perfect handling. All
models are equipped with disc bumpers and bumper pads as impact protection.

Description and Technical Data Section 3
Device description Page 13
ISOBOX® Mobil
91338723_A0 Basic
3.4.3 Equipment and Optional Accessories
The appliances can be configured as required and supplemented with optional accessories:
§Colour door panels and side panels:
You can obtain information on available colours from HUPFER®or consult our website.
§Casters:
Made of stainless steel, fixed casters, swivel casters with or without total lock, Ø 4.92'' (125 mm).
§Gallery:
The gallery on the top of trolley ensures that items such as crockery baskets are safely transported.
The gallery is optionally available in a continuous version (open on all four sides) or closed on three
sides.
§Paper clamp.
§Label holder:
Available in A5 landscape and A4 portrait format.
§HGV skirting protection:
The HGV skirting protection is designed to protect and secure appliances whenever they are being
transported by a machine (type 2).
§Cover sheet, top:
(type 1, type 2, type 3)
The item code for the special accessories can be found in the spare parts catalogue and the online order
lists.
3.4.4 Technical Data
Dim. Model 1 Model 2
1/30 2/30
Width in (mm) 21.6'' (549) 21.6'' (549)
Depth in (mm) 28.6'' (726) 28.6'' (726)
Height (125 caster) in (mm) 58.5'' (1486) 64.5'' (1638)
Tare weight
(without accessories) lbs (kg) 19.5(43) 24.0 (53)
Payload lbs (kg) 40.8(90) 40.8(90)
Number of beads 1x30 2x15
Tray interspace width in (mm) 1.5'' (37.5) 1.5'' (37.5)
Arrangement of the
boxes top/bottom top/bottom
Tray insertion lengthwise lengthwise

Section 3Description and Technical Data
Page 14 Rating Plate
ISOBOX® Mobil
Basic 91338723_A0
Dim. Model 3 Model 4
1/15 2/30
Width in (mm) 21.6'' (549) 38.3'' (972)
Depth in (mm) 28.6'' (726) 28.6'' (726)
Height (125 caster) in (mm) 36.2'' (920) 36.2'' (920)
Tare weight
(without accessories) lbs (kg) 12.7(28) 25.4(56)
Payload lbs (kg) 22.7(50) 40.8(90)
Number of beads 1x15 2x15
Tray interspace width in (mm) 1.5'' (37.5) 1.5'' (37.5)
Arrangement of the
boxes left/right
Tray insertion lengthwise lengthwise
3.5Rating Plate
Figure 2 Rating plate
1 Disposal of old appliances 9 Nominal current
2 Certification mark 10 Frequency
3 Protection class 11 Nominal voltage
4 Refrigeration capacity 12 Payload
5 Refrigerant 13 Tare weight
6 Induction frequency 14 Serial number/Order number
7 Electrical serial number 15 Item and brief description
8 Electric power 16 Manufacturer

Transport, Initial Operation and Taking out of Service Section 4
Transport Page 15
ISOBOX® Mobil
91338723_A0 Basic
4 Transport, Initial Operation and Taking out of Service
4.1Transport
CAUTION Damage to appliances caused by improper transport
Appliances should be safely secured when transported off site inside a vehicle
such as a truck. The total locks are not suitable for securing the appliances
when they are transported in a vehicle.
If the appliances are not secured properly, there is a risk of property damage
and personal damage caused by squashing.
Secure each individual separate appliance using suitable transport securing
devices.
The appliance is delivered fully assembled.
When loading, use only hoists and load lifting devices approved for the weight of the appliance. Transport
vehicles which are approved for the weight of the appliance may also be used.
The scope of delivery is specified in the shipping documents in accordance with the valid purchase agree-
ment and included with the delivery item.
4.2 Commissioning
Remove the original packaging and check whether the appliance is complete and undamaged. Do not put a
defective appliance into operation under any circumstances and inform the supplier immediately in such a
case.
Always place the appliance on firm, level floors when unpacking and operating it. Apply the total locks on
both swivel casters to secure the appliance against rolling away.
INFO Disposal of packing material
The packing consists of recyclable materials and can be disposed of accord-
ingly. The different materials should be separated and disposed of in an envi-
ronmentally friendly manner. The local agencies responsible for disposal must
be contacted regarding removal
The appliance should be thoroughly cleaned with a soft cloth before putting it into operation for the first time.
Ensure that the appliance is clean and dry before putting it into operation. You must always ensure that there
is a minimum gap of 30 cm between the rear of the appliance and the wall, so that hot air can be expelled
when putting the appliance into operation for the first time and during normal operation.
The following appliance functions must be checked before putting it into operation:
§ The total lock function.

Section 4Transport, Initial Operation and Taking out of Service
Page 16 Storage and Recycling
ISOBOX® Mobil
Basic 91338723_A0
4.3Storage and Recycling
Appliances must be kept in a dry, frost-free environment when placed in temporary storage. The appliance
must be kept covered with a suitable covering material to be protected against dust ingress.
The appliance must be checked for damage and corrosion every 6 months while in the storage location.
NOTE Condensation
Ensure that there is sufficient ventilation and no major variations in tempera-
ture in the storage location to prevent condensation from forming.
Before the appliance is taken back into operation, it must be clean and dry.
If the appliance is to be recycled, all the operating and auxiliary materials must be disposed in an environ-
mentally compatible manner. Recyclable materials must be properly separated and disposed of in an envi-
ronmentally compatible manner in accordance with local Waste Disposal Regulations. The local agencies
responsible for disposal must be contacted regarding removal. Separate the reusable materials of the appli-
ance (casters and plastic parts) before disposing of or send the appliance to a recycling centre.
We offer our customers to dispose of their waste appliances. Please contact us or one of our distribution
partners.
Packaging and packing material can be sent to the recycling centre by indicating the waste disposal contract
number. If you do not have the valid waste disposal contract number, you can request it fromHUPFER®-
Service.

Operation Section 5
Operation Page 17
ISOBOX® Mobil
91338723_A0 Basic
5 Operation
CAUTION Damage to appliances
The appliance must be checked for visible external damage and defects each
time before being operated. The appliance may only be operated when it is in
a technically immaculate condition.
If damage is detected, inform the person or persons responsible immediately.
Do not use the appliance.
5.1Operation
Loading
§Secure the appliance with the total locks to prevent from rolling back.
§Insert containers, trays or grids in the side guide-ways.
§Close the doors.
§Release the total locks.
§Carefully push or pull the appliance to its destination.
Unloading
§Once at the destination, secure the casters with the total locks.
§Unlock the doors.
§Remove containers, trays or grids.
5.2 Tasks to complete at end of working day
Proceed as follows to switch off the appliance:
§Push or pull the appliance to its destination (if required).
§Secure the casters with the total locks.
§Remove inserted containers, trays or grids.

Section 6Troubleshooting and Repair
Page 18 Instructions regarding Fault Repair
ISOBOX® Mobil
Basic 91338723_A0
6 Troubleshooting and Repair
6.1Instructions regarding Fault Repair
Please contact our service partners in the event of a malfunction or complaints within the warranty period.
Even after the warranty period is expired you can have necessary repair work done by our service partners
and certified electricians.
Servicing may be carried out by authorised specialists only.
Defective components should only be replaced with HUPFER®original parts. The modular design simplifies
the replacement of individual components.
Always specify the information and corresponding part number indicated on the rating plate when contacting
the after-sales service or ordering spare parts.
Regular inspection and maintenance of the appliance prevent disruptions to operations and ensure safety.
6.2 Fault and Action Table
Fault Possible cause Remedy
Running noise of swivel casters Defective caster bearings Replace the swivel casters.
Sticky surface of the casters Clean the swivel casters.
The appliance pulls to the right or to
the left when transporting Damaged caster bearings Replace defective casters with new ones.
Rolling resistance of the casters is
higher than when putting the appli-
ance into operation
Damaged caster bearings Replace defective casters with new
ones.
Total locks no longer lock Wear on the locking brake Replace the locking brake or replace
defective casters with new ones.

Cleaning and Care Section 7
Hygiene Measures Page 19
ISOBOX® Mobil
91338723_A0 Basic
7 Cleaning and Care
NOTE Cleaning in the washing device
The appliances in the ISOBOX® Mobil Basic model range can be cleaned in
an automated cleaning system.
7.1Hygiene Measures
It is essential for operating staff to act in the correct manner to ensure optimal hygiene.
All persons must have sufficient knowledge about the locally valid hygiene regulations, observe them and
comply with them.
Use a waterproof plaster to cover wounds on hands and arms.
Never sneeze or cough on clean crockery or meals.
7.2 Cleaning and Care
If the appliance is handled with care, cleaned and maintained on a regular basis, it does not require any ad-
ditional care measures. The boxes should be cleaned regularly after every use to ensure a perfectly hygienic
operation.
For quick and thorough cleaning, wipe the inside of the boxes with a soft cloth. Use a soft cleaning cloth or
an uncoated sponge for cleaning. Use degreasing liquid cleansers that are approved for the food industry.
Never use high-pressure cleaners, chloride-based cleaning agents, abrasive cleaning powder or other dry
cleaning agents, steel wool, steel sponges and/or sharp-edged items.
7.3 Special Care Instructions for Aluminium Surfaces
Pure aluminium reacts slightly to oxygen in the air. A thin, natural layer of oxide forms on the metal surface
due to this reaction between oxygen and aluminium. This uniform oxide layer provides the material with ex-
cellent corrosion protection as it becomes chemically inert.
However, acids and alkalis attack the oxide layer or dissolve it, meaning that the corrosion protection may be
lost. Depending on surface requirements and exposure to stress, further measures such as anodisation or
powder coating are necessary to produce corrosion-resistant, wear-proof aluminium surfaces.
Important instructions for aluminium surface care:
§It is best to use clean water, possibly adding a little pH-neutral cleaning agent, and soft, non-scouring
cloths to clean aluminium.
§Do not damage surfaces. Do not use highly abrasive cleaning materials. Do not use any steel tools as
they may scratch the surface. Abrasive cleaning agents or accessories, such as scouring agents,
steel wool or scouring pads, may damage aluminium surfaces and should not be used.
§Do not treat surfaces with strongly acidic (pH value less than 5) or strongly alkaline (pH value more
than 8.5).
§Wipe with clean water to finish, so that no residues are left on the surface.
§As a basic rule, you should check whether a cleaning agent can be used by trying it out on a non-
visible section or on a sample surface first.
Suitable cleaning agents for cleaning aluminium surfaces:
§Use neutral cleaning agents, such as water with washing-up liquid, to clean off easy-to-remove stains
from coated surfaces.
§Use slightly acidic cleaning agents, such as vinegar and water in equal parts, to remove tougher
stains.
§Remove strong coats of grease with organic solvents, such as ethanol. Keep the exposure time to a
minimum. Rubbing may cause the coating to lose its glossy appearance.

Section 7Cleaning and Care
Page 20 Special Care Instructions for Stainless Steel
ISOBOX® Mobil
Basic 91338723_A0
Cleaning anodised aluminium surfaces:
§Carry out care tasks on surfaces on a regular basis by washing with clean water and washing-up liq-
uid and then rinsing. After drying, apply an anodising cleaner sparingly with a soft cloth. Then polish
with a dry, soft cloth to achieve a streak-free surface.
§To remove tough stains, apply anodising cleaner on a cloth and rub briskly onto the surface. Then
polish with a dry, soft cloth.
§There are special anodising touch-up applicators or sprays available from specialist retailers.
Cleaning powder-coated aluminium surfaces:
§Carry out care tasks on surfaces on a regular basis by washing with clean water and washing-up liq-
uid, rinsing and rub with a chamois leather. You can also treat with a suitable polish to preserve the
surface.
§You can also use a suitable abrasive cleaning agent to remove heavier stains after cleaning.
There are special touch-up applicators or sprays available from specialist retailers.
7.4 Special Care Instructions for Stainless Steel
Resistance to corrosion in stainless steel is provided by a passive layer which is formed on the surface when
oxygen is absorbed. The oxygen in air is sufficient to form the passive layer, so that damage caused by
physical action is eliminated automatically.
The passive layer develops or is renewed more quickly when the steel comes into contact with water containing
oxygen. The passive layer can be chemically damaged or breached by agents which have a reducing (oxygen-
consuming) effect when they come into contact with steel at concentrated levels or at high temperatures.
Such aggressive substances include:
§substances containing salt and sulphur
§chlorides (salts)
§seasoning concentrates (e.g. mustard, vinegar essence, seasoning cubes, saline solutions).
Further damages can occur due to:
§extraneous rust (e.g. from other components, tools or rust film)
§iron particles (e.g. grinding dust)
§contact with non-ferrous metals (element formation)
§lack of oxygen (e.g. no admission of air, low-oxygen water).
General working principles for handling appliances made of "refined stainless steel":
§Always keep the surface of appliances made from stainless steel clean and open to air.
§Use cleaning agents suitable for stainless steel. Never use bleaching cleaning agents or any contain-
ing chlorides.
§Remove layers of lime scale, grease, starch and egg-white by cleaning daily. Corrosion may occur
underneath these layers due to lack of air absorption.
§After each cleaning operation remove all cleaning agent residues by wiping thoroughly. The surface
should be thoroughly dried after wiping.
§Do not bring items made of stainless steel into contact with substances such as concentrated acids,
seasonings and salts for longer than is absolutely necessary. Acid fumes emitted when tiles are
cleaned also cause corrosion in "refined stainless steel".
§Avoid damaging the surface of the stainless steel, especially by bringing into contact with metals oth-
er than stainless steel.
§Residues from other metals produce extremely small amounts of chemical elements which can cause
corrosion. Contact with iron and steel must be avoided at all costs, because it will cause extraneous
rust. If stainless steel comes into contact with iron (steel wool, steel particles from pipes, water con-
taining iron), this can trigger corrosion. Therefore, only use refined steel wool or brushes with natural,
plastics or refined steel bristles only for physical cleaning. Steel wool or brushes with unalloyed steel
cause extraneous rust due to abrasion.
