Husqvarna 96051009200 Setup guide

ILLUSTRATED PARTS LIST
MODEL NO. 96051009200
CUSTOMER CATALOG NO. CTH 174
PRODUCT NO. 960 51 00-92
586 18 35-26 Rev. 1
47
47

2
TRACTOR - - MODEL NO. CTH 174 (96051009200), PRODUCT NO. 960 51 00-92
DECALS
27
27
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
6
2
1
3
11
4
10
5
9
8
7
wheel_art_1-tex
WHEELS AND TIRES KEY PART
NO. NO. DESCRIPTION
1 532 05 91-92 Cap Valve Tire
2 532 06 51-39 Stem Valve
3 532 13 83-36 Rim Front
4 532 05 99-04 Tube Front (Service Item Only)
5 532 10 62-22 Tire Front 15 x 6-6
6 532 12 49-57 Fitting Grease (Front Wheel Only)
7 532 12 49-59 Bearing Flange (Front Wheel Only)
8 532 17 50-39 Cap Axle Blk 1 50 x 1 00
9 532 42 05-31 Tire Rear 18 x 9.5-8
10 532 12 49-26 Tube Rear (Service Item Only)
11 532 13 83-37 Rim Asm 8" Rear
- - 532 14 43-34 Sealant, Tire (10 oz. Tube)
KEY PART
NO. NO. DESCRIPTION
1 581 57 83-01 Decal Warning Sym. CE
2 581 58 97-01 Decal Warning Eng. Sym.
4 532 44 70-26 Decal Replacement
7 581 62 73-01 Decal Hood
8 532 44 77-72 Decal Side Panel
9 581 57 98-01 Decal Warning Ser/Fire
11 581 57 91-01 Decal Mower Cut Finger Symbol
14 581 57 96-01 Decal Chassis Hot Muffler
21 532 44 11-89 Decal Belt Schematic
- - 581 72 48-01 Decal CRD Bypass
- - 532 44 32-61 Decal Inst. Mulch Plug
- - 532 44 27-44 Decal Battery Door Tex
- - 532 44 14-09 Pad, Footrest Pad LH
- - 532 44 14-10 Pad, Footrest Pad RH
- - 586 18 35-40 Manual Operator's (Euro)
KEY PART
NO. NO. DESCRIPTION
7
14
21
7
1
9
14 4
11
2
11
8

3
M
FUSE
STARTER
SOLENOID
BATTERY
REVERSE SWITCH(NOT IN REVERSE)
SEAT SWITCH (NOT OCCUPIED)
FULL BAG
IGNITION
UNIT
HOUR
METER
CHASSIS HARNESS
CONNECTOR (C1)
(MATING SIDE)
DASH HARNESS
CONNECTOR (C1)
(MATING SIDE)
FUEL
LINE
FUEL SHUT-OFF
SOLENOID
(IF SO EQUIPPED)
C1
SM
B
GL
2
3
1
6
A2A1
M
SPARK
PLUGS GAP
(2 PLUGS ON
TWIN CYL. ENGINES)
(OPTIONAL)
NON-REMOVABLE
CONNECTIONS
REMOVABLE
CONNECTIONS
WIRING INSULATED CLIPS
NOTE: IF WIRING INSULATED
CLIPS WERE REMOVED FOR
SERVICING OF UNIT, THEY
SHOULD BE RE-INSTALLED TO
PROPERLY SECURE YOUR
WIRING.
SCH19
IGNITION SWITCH
CIRCUITPOSITION
OFF B+A1
RUN/OVERRIDE
B+S+A1START
M+G+A1
B+A1RUN
“MAKE”
L+A2
PTO SWITCH
(DISENGAGED)
BLACK
BLACK /WHITE
BLUE
BLUE BLACK
GREEN
BLACK
YELLOW
BLK/WHT
BLACK
BLK/WHT
DER
WHITE
WHITE
GRAY
GRAY
BLACK
YELLOW
POWER OUTLET
(OPTIONAL)
12V
BLACK
BLUE
BLACK
BROWN
HEADLIGHTS
LIGHT SWITCH
ORANGE
CLUTCH/BRAKE
(PEDAL UP)
WHITE
GREEN
GREEN
BLUE RED
BAG PRESENT SWITCH
(BAG ATTACHED)
SHORTING CONNECTOR
BAG FULL SWITCH
(NOT FULL)
9
BUZZER
BLACK
BLACK
BLACK
BLUE BLACK
5
6
C1
4
C1
BROWN
8
C1
DER RED
1
2
3
654
98
123
456
89
ELECTRIC CLUTCH
BLACKRED
REGULATOR STATOR
28 VOLTS AC @ 3600 RPM (REGULATOR DISCONNECTED)
CHARGING SYSTEM OUTPUT
9-16AMPDC@3600 RPM
TRACTOR - - MODEL NO. CTH 174 (96051009200), PRODUCT NO. 960 51 00-92
SCHEMATIC
38
38

4
TRACTOR - - MODEL NO. CTH 174 (96051009200), PRODUCT NO. 960 51 00-92
ELECTRICAL
32
32
30 33
34
22
79 21
26
40
71
16
TC06S
28
55
With Service Minder Option
4646
43
27
99
25
108
83
107
2
102
105
29
With Charge Indicator Option
142
(+) (-)
143

5
KEY PART
NO. NO. DESCRIPTION
1 532 43 71-57 Battery
2 532 44 09-23 Screw Hex Head Cap M6 x 1.12 mm
16 532 17 61-38 Switch Interlock Push-In
21 532 40 02-52 Harness Socket Light w/4152J
22 532 00 41-52 Bulb Light
25 581 48 98-01 Cable Starter
26 532 17 51-58 Fuse
27 873 51 04-00 Nut Keps Hex 1/4-20 unc
28 581 48 98-02 Cable, Ground
29 532 40 15-45 Switch, Seat
30 532 19 33-50 Switch, Ign.
33 532 41 19-35 Key/Chain
34 532 11 07-12 Switch Light/Reset
40 532 44 80-36 Harness Ign. Dash
43 532 19 25-07 Solenoid
50 532 17 46-51 Switch PTO
55 817 06 05-12 Screw Thdrol. 5/16-18 x 3/4 TYTT
71 532 44 08-20 Harness Ignition Chassis
79 532 17 52-42 Socket Asm. Bulb Twistlock
83 532 43 67-74 Nut Square M6 x 1.8.5 x 11 mm
99 817 72 04-08 Screw Thd. Cut 1/4-20 x 1/2
102 532 44 12-62 Harness Pigtail Tex ROS Tufftorq
105 532 40 75-68 Switch Reverse TT GT
107 532 18 03-79 Switch Full Bagger Indicator
108 532 42 10-62 Switch Snapmount
142 583 85 78-01 Charge Port Pigtail
143 532 44 80-59 Charge Port
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
TRACTOR - - MODEL NO. CTH 174 (96051009200), PRODUCT NO. 960 51 00-92
ELECTRICAL
32
32

6
TRACTOR - - MODEL NO. CTH 174 (96051009200), PRODUCT NO. 960 51 00-92
CHASSIS AND ENCLOSURES
39
39
68
68
68
68
183
183
236
236
34
343
235
235
68
68
213
218
319
180
52
217
228
228
194
340
309
308 342
189
159
339
338
179
156
179
156
189
342
282
162
287
162
284
283
199
194
194
36
36
37
chassis-TexCrd-Gen2_TEX LT HUSQ _8_r1
177
175
176
5
176
176
182
176
130
151
130
150
137
137
214
14
204
25
297
191
15
130
130
18
3
238
239
234
234
205
202
203
206
189
189
152
195
159
310
159311
341
62
334
118
119
118
119

7
3 581 05 63-01 Logo
5 585 52 98-04 Dash
14 532 44 12-67 Hood
15 532 44 14-28 Lens LH
18 532 44 13-68 Grille
25 532 44 14-27 Lens RH
34 580 91 09-01 Plate Engine
36 817 06 05-12 Screw 5/16-18 x 3/4
37 532 44 13-69 Fender
52 873 68 05-00 Nut Crownlock 5/16-18
62 872 11 06-08 Bolt RDHD SQNK 3/8-16 x 1
68 817 49 05-08 Screw Thdrol. 5/16-18 x 1/2
118 819 13 13-16 Washer 13/32 x 13/16 x 16
119 873 68 06-00 Nut Crownlock 3/8-16 unc
130 532 41 63-58 Screw #10 x .750 BOS Thread
137 532 40 75-90 Bumper Dash
150 532 40 75-37 Air Duct
151 532 40 78-07 Bracket Pivot
152 532 19 95-35 Shield Browning
156 872 14 06-14 Bolt 3/8-16 unc x 1-3/4
159 817 00 06-12 Screw 3/8-16 x 3/4
162 532 14 24-32 Screw Hex Wsh. Hi-Lo 1/4 x 1/2 unc
175 532 19 94-72 Crossmember
176 532 40 07-76 Screw 10-24 x 5/8
177 532 19 52-28 Bushing Steering
179 532 16 89-37 Nut Push
180 581 18 71-01 Chassis
182 532 40 71-76 Dash Lower
183 874 52 05-20 Bolt 5/16-18 x 1-1/4
189 817 00 05-12 Screw 5/16-18 x 3/4
191 532 41 65-01 Insert Reflective RH
194 873 90 05-00 Nut Lock Hex Flange 5/16-18
195 532 43 99-76 Plug Dash
199 532 41 87-39 Plate Deck Lift
202 532 44 13-42 Vent Side Hood RH NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
KEY PART
NO. NO. DESCRIPTION
KEY PART
NO. NO. DESCRIPTION
TRACTOR - - MODEL NO. CTH 174 (96051009200), PRODUCT NO. 960 51 00-92
CHASSIS AND ENCLOSURES
39
39
203 532 44 13-43 Vent Side Hood LH
204 532 44 13-75 Vent Top Hood
205 532 44 13-44 Skirt Side RH
206 532 44 13-45 Skirt Side LH
213 874 76 05-12 Bolt Hex HD 5/16-18 unc 3/4
214 532 19 91-45 Clip Retainer
217 532 40 91-67 Rod Pivot Hood
218 532 19 63-95 X-Piece Hood Stop
228 532 19 51-61 Stud Fastener
234 532 40 47-42 Bumper Hood
235 532 40 61-29 Spacer Fender
236 873 93 05 00 Nut Center Lock 5/16-18 unc
238 532 44 13-74 Trim
239 532 40 48-83 Clip Tinnerman
282 532 41 41-10 Clip Retainer
283 532 44 05-31 Console Deck Lift
284 532 44 05-30 Console Shift RH
287 817 60 04-06 Screw Hex Washead. 1/4-20 x 3/8
297 532 40 66-65 Insert Reflective LH
308 532 17 18-77 Bolt 5/16-18 unc x 3/4
309 584 44 11-01 Backplate
310 532 44 66-36 Bracket Hangbar Bag LH
311 532 44 66-37 Bracket Hangbar Bag RH
319 532 17 46-62 Bracket Actuator Bagger
338 532 43 66-40 Bolt Shoulder
334 532 44 25-37 Bracket Engine
339 532 43 66-41 Lever Bagger Full
340 532 44 09-31 Door Battery Tray
341 532 43 66-38 Latch Batter Tray
342 532 43 59-38 Support Fender
343 532 44 07-49 Clip

8
TRACTOR - - MODEL NO. CTH 174 (96051009200), PRODUCT NO. 960 51 00-92
DRIVE
40
40
351
116
103
161
116
195
227
143
64
159
160
188
167
42
143
17
35
184 221
drive-tex CRD_K46_pedal_25
335
362
362
315
315
315
352 353
56
160
210
214
211
215
166
211
222
160
163
29
15
159
6
203
30
185
125
355
339
339
226
125
125
61
320
1
33
205
183
37
2
205
205
37
2
205
33
183
*
319
319
73
315
362
335
280
364
186
189
49
314
52
51
50
90
99
197
196
38 175
360
279
360
311 312
140
313
143
125
125
309 143

9
KEY PART
NO. NO. DESCRIPTION
KEY PART
NO. NO. DESCRIPTION
*Parts supplied by manufacturer
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
1 – – – – – – Transaxle, TUFFTORQ K46DF
(446488)(Order parts from
transxle manufacturer.)
2 532 12 35-83 Key Square
6 532 12 40-28 Bushing
15 819 13 16-16 Washer 13/32 x 1 x 16 Ga.
17 532 43 62-27 Spring, Brake
29 532 43 58-81 Rod, Brake
30 819 13 13-16 Washer 13/32 x 13/16 x 16
33 812 00 00-01 Ring E
35 532 40 10-31 Rod, Brake, Park
37 532 18 89-67 Washer Hardened
38 532 16 96-13 Nyliner Snap-In 5/8
42 532 12 48-72 Cover, Foot Pedal
49 872 11 06-14 Bolt 3/8-16 unc
50 532 19 43-27 Idler Flat
51 873 90 06-00 Lock Nut 3/8-16
52 532 19 43-26 Idler V-Groove
56 532 44 18-34 V-Belt, Drive
61 532 43 77-88 Pulley Transaxle
64 532 19 78-65 Shaft Asm. Pedal Brake Control
73 874 49 05-56 Bolt Flanged
90 532 44 36-05 Keeper Belt Clutching
99 532 44 39-47 Rod Bypass TEX CRD
103 873 35 05-00 Nut
116 873 90 05-00 Nut Lock Hex Flange 5/16-18
125 817 00 05-12 Screw 5/16-18 x 3/4
140 810 04 04-00 Washer Lock Hvy. Helical 1/4
143 817 49 05-08 Screw Thdrol 5/16-18 x 1/2 TYTT
159 876 02 04-12 Pin Cotter 1/8 x 3/4
160 532 16 94-84 Retainer Clip
161 532 10 57-09 Spring, Return, Clutch
163 532 43 66-32 Rod Control Shift Pedal
166 532 42 91-64 Nut Push .625
167 532 40 52-57 Latch Brake Parking
175 532 42 93-59 Shaft Asm. Crosshift
183 532 13 70-57 Spacer Axle
184 532 44 14-07 Handle Parking Brake
185 872 00 06-22 Bolt 3/8-16 unc x 2-3/4
186 532 19 43-21 Spacer Retainer
TRACTOR - - MODEL NO. CTH 174 (96051009200), PRODUCT NO. 960 51 00-92
DRIVE
40
40
188 532 19 43-23 Link Clutch Ground Drive
189 532 43 36-11 Bellcrank GRND DR CRD
195 580 45 69-01 Bracket Brake Rod
196 532 19 58-04 Link Clutch Anti-Rotation
197 817 00 06-16 Screw
203 819 11 11-16 Washer 11/32 x 11/16 x 16 Ga.
205 532 12 17-48 Washer 25/32 x 1-5/8 16 Ga.
210 532 40 09-80 Rocker Asm. Pedal
211 532 12 01-83 Bearing Nylon
214 532 42 12-63 Pedal Forward Pads
215 532 41 94-82 Pad Pedal Reverse
221 532 40 31-87 Retainer Spring
222 879 21 20-10 Washer 21/32 x 1-1/4
226 532 40 15-64 Bracket Mount Torque
227 817 49 05-12 Screw
279 532 44 42-83 Subasm Link and Stud
280 819 11 10-12 Washer 11/32 x 5/8 x 12 Ga.
309 532 16 55-81 Plate FSTNR Crosshift
311 532 16 98-45 Washer Nylon
312 532 16 56-14 Hub Tapered Round CRD
313 874 78 04-16 Bolt Hex Fin 1/4-20 x 1
314 532 44 47-13 Retainer, Belt
315 817 58 05-20 Screw Thdrol 5/16-18 x 4.25
335 532 19 95-34 Pulley V-Idler GRND DR
319 532 43 67-94 Spacer Transaxle Tex CRD
320 532 18 76-90 Washer Spacer
339 532 43 68-67 Strap Torue K46 CRD Tex
351 532 43 69-98 Bracket 97 CRD Deck Sway
352 532 43 58-19 Bracket Idler
353 532 43 65-77 Bracket Idler RH
355 532 43 56-69 Strap Torque K46 CRD
360 532 44 47-14 Nut
362 532 43 68-12 Idler Flat
364 532 44 30-32 Bracket Idler

10
TRACTOR - - MODEL NO. CTH 174 (96051009200), PRODUCT NO. 960 51 00-92
ENGINE
24
24
1
29
SPARK ARRESTER KIT
92
45
21 20
94
69
engine-tex_Kohl_46
2
87
37
28
37
79
122
18
15
97
96
12
11
41
42
85
9
90
108
Guard_assembly_54

11
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
1 – – – – – – Engine Kohler Model No. SV530-3212
(438331)(Order parts from engine
manufacturer.)
2 580 53 23-01 Muffler
9 584 90 80-01 Keeper Belt Engine
11 532 40 00-08 Clutch Electric
12 532 40 50-97 Pulley Engine
15 581 28 99-01 Tank Fuel 1.5
18 532 43 02-20 Cap Fuel
20 532 18 38-97 Control Throttle
21 532 41 63-58 Screw #10 x 0.750 BOS Thread
28 532 13 70-40 Fuel Line
29 532 13 71-80 Spark Arrester Kit
37 532 12 34-87 Clamp Hose
41 532 12 61-97 Washer 1-1/2 OD x 15/32 ID x .250
42 810 04 07-00 Lock Washer Hvy. 7/16
45 873 51 04-00 Nut Keps Hex 1/4-20 unc
69 532 18 59-09 Gasket
79 532 19 23-34 Screw Socket HD 5/16-18 x .75
85 532 17 39-37 Bolt Hex 7/16-20 x 4 x Gr. 5-1.5 Thr
87 532 17 18-77 Bolt 5/16-18 unc x 3/4 w/Sems.
90 817 00 06-16 Screw 3/8-16 x 1
92 817 12 06-16 Screw 3/8-16 x 1
94 583 95 53-01 Tube Exhaust
96 819 09 14-16 Washer 9/32 x 7/8 x 16 Ga.
97 817 67 04-12 Screw 1/4-20 x 3/4
108 532 42 30-41 Cover Pulley Engine
122 532 42 19-22 Extension Drain Oil
TRACTOR - - MODEL NO. CTH 174 (96051009200), PRODUCT NO. 960 51 00-92
ENGINE
24
24

12
TRACTOR - - MODEL NO. CTH 174 (96051009200), PRODUCT NO. 960 51 00-92
STEERING ASSEMBLY
41
41
62
35
19
60
59
70
68
69
15
14
61
steering-tex_HUSQSR_26_r2
16
28
28
13
22
64
71
21
45
33
72
4
15
14
1
26
58
5
13
13
53
8
67
67
66
6
6
2
9
87
9
87
20
63
57
63
122
122
118
118
118
118

13
KEY PART
NO. NO. DESCRIPTION
1 532 43 97-40 Wheel, Steering Husq SR
2 532 41 35-91 Axle Asm., Front
4 532 40 30-87 Spindle Asm., LH
5 532 40 30-88 Spindle Asm., RH
6 532 12 49-31 Bearing, Race Thrust Hardened
7 532 12 17-48 Washer 25/32 x 1-5/8 x 16 Ga.
8 812 00 00-29 Ring, Clip #T5304-75
9 532 12 12-32 Cap, Spindle
13 532 12 17-49 Washer 25/32 x 1-1/4 x 16 Ga.
14 810 04 06-00 Washer, Lock Hvy. Hlcl. Spr. 3/8
15 873 54 06-00 Nut, Crown Lock 3/8-24 unf
16 532 42 93-73 Shaft Steering
19 532 19 47-29 Plate Steering
20 532 44 14-25 Boot, Steering
21 532 18 67-37 Adapter, Wheel Steering
22 532 42 05-37 Supt., Strg. Lower
26 532 43 97-43 Insert, Wheel Steering Husq SR
28 817 00 06-12 Screw 3/8-16 x 3/4
33 810 04 05-00 Washer Lock 5/16
35 532 19 47-32 Gear, Sector Plate
45 819 11 38-12 Washer 11/32 x 3/8 x 12 Ga.
53 532 18 89-67 Washer Hardened .793 x 1.637 x .060
57 532 40 74-65 Bracket Upstop
58 532 19 47-47 Bolt Shoulder Sector Pivot CFM
59 532 19 47-48 Washer Thrust Sector Steering
60 873 97 10-00 Nut Flange Lock 5/8-11
61 532 19 47-40 Draglink, LH
62 532 19 47-41 Draglink, RH
63 817 00 05-12 Screw 5/16-18 x 3/4
64 532 19 98-49 Retainer Clip Spring Steering
66 871 02 07-48 Bolt Hex Fghd. 7/16-14 x 3 Serr.
67 532 19 47-37 Bushing PM Front Axle
68 873 90 07-00 Nut Lock Flange 7/16-14 Gr. 5
69 532 19 91-62 Washer 1.5 x .505 x .118
70 532 19 61-97 Bracket Deck Susp. Front
71 532 19 07-52 Shaft Extension Steering
72 532 42 89-82 Bolt Fin Hx 5/16-18 x 4 w/Patch
118 532 40 60-13 Bushing Axle Cast
122 532 44 49-62 Cap Gear Sector
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
TRACTOR - - MODEL NO. CTH 174 (96051009200), PRODUCT NO. 960 51 00-92
STEERING ASSEMBLY
41
41

14
TRACTOR - - MODEL NO. CTH 174 (96051009200), PRODUCT NO. 960 51 00-92
MOWER DECK
44
44
32 99
99
72
20
45
33
34 124
85
87
88
86
35
36
132
3
98
98
129
130 131
23
97
75 96
14
115
118
116
84
43
17
16
75
13 14
5
94
100
100
1
76
11
20
20
110
19
121
18
117
117
119
113
114
43
112
17
102
101
115
116
120
11
111
110
101
119
19
tex-deck_CRD_29
128
127
16 91
128
91
127 16
75
95
42
13
16
125
14
27
140
141
137
136
138
139
139
71
255
117 254
253
255
117
255
117 252
105
11
11
80
80
103
11
104
80

15
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
TRACTOR - - MODEL NO. CTH 174 (96051009200), PRODUCT NO. 960 51 00-92
MOWER DECK
44
44
1 584 40 21-01 Deck Weldment
3 873 90 05-00 Nut Lock Hex Flange 5/16 - 18
5 817 00 05-10 Bolt 5/16-18
11 532 13 77-29 Screw Thd Roll 1/4 - 20 X 5/8
13 872 11 06-12 Bolt Carr Sh 3/8 - 16 X 1 - 1/2 Gr. 5
14 532 15 60-85 Keeper Belt Idler
16 873 90 06-00 Nut Lock FlG 3/8 - 16 unc
17 532 40 02-34 Nut Flange Lock Top
18 532 18 76-90 Washer Spacer Mandrel
19 532 11 04-85 Bearing Ball Mandrel
20 532 17 39-84 Screw Thread Roll
23 817 49 06-28 Screw Thdrol 3/8 - 16 X 1-3/4
27 532 44 58-34 V-Belt Drive
32 532 44 62-05 Spring Drive
33 532 18 72-81 Housing Mandrel 4pt Service
34 532 19 28-72 Shaft Asm Mndrl N/Greaseable38
35 532 42 79-84 Blade Mower LH
36 532 19 30-03 Bolt/Washer Asm 7/16 - 20 unf
42 817 00 05-12 Screw 5/16-18 x 3/4
43 532 19 97-89 Pulley Mandrel
45 532 13 71-52 Housing Mandrel
71 817 67 06-08 Screw Thdrol 3/8-16 x 1/2
72 532 44 68-10 Chute Upper
75 532 13 14-94 Pulley Idler Flat
76 532 43 96-40 Washout Port
80 532 42 30-62 Palnut 1/4
84 532 40 01-40 Keeper Belt Mandrel
85 532 42 79-85 Blade Mower RH
86 532 18 17-13 Bolt 3/8-24 x 1.50 Gr. 8
87 810 03 06-00 Washer Lock Hvy 3/8
88 532 14 02-96 Washer Hard Blade Mower Vented
91 819 13 20-12 Washer 13/32 x 1-1/4 x 12 Ga.
94 532 19 72-50 Bracket Clutch Cable
95 817 00 06-12 Screw 3/8-16 x 3/4
96 532 40 02-71 Spacer
97 532 18 20-61 Shield Idler Mower
98 532 19 51-61 Stud Fastener
99 532 19 51-86 Arm Suspension Mower Rear
100 532 19 65-39 Bolt Shoulder
101 873 68 09-00 Nut Crownlock 9/16 - 18 unc
102 532 40 25-11 Spacer Bearing Swing Plate
103 532 43 69-92 Guard Front Vent
104 532 43 89-68 Mandrel Cover RH
KEY PART
NO. NO. DESCRIPTION
KEY PART
NO. NO. DESCRIPTION
105 532 43 87-44 Mandrel Cover LH
110 532 41 53-56 Gear Output
111 532 43 69-79 Gasket Gearcase
112 532 44 38-52 Shaft Gearcase
113 532 43 85-33 Plug Oil
114 532 43 85-34 Valve Relief
115 818 03 10-16 Screw Torx #10-24 x 1
116 872 11 04-14 Bolt 1/4-20 x 1.75 Gr. 5
117 873 90 04-00 Nut Hex Flange 1/4-20 unc
118 532 43 69-89 Arm Clutching
119 532 43 81-66 Gearcase Subasm
120 532 43 69-91 Keeper Belt RH
121 532 43 69-85 Washer
124 532 43 69-86 Non Greasable Mandrel Shaft
125 532 43 69-94 Bracket Idler Chasses
127 532 19 34-06 Bolt Shoulder 3/8-16 x 3-5/8 Gr. 5
128 532 17 48-73 Wheel Guage
129 532 40 48-51 Rod Anti-Sway
130 819 13 13-12 Washer 13/32 x 13/16 x 12 Ga.
131 532 19 42-08 Pin Cotter 5/16 Bow Tie Lock
132 532 17 88-99 Knob Handle
136 532 43 96-39 Washout Port Remote
137 812 00 00-29 Ring Klip #T5304-75
138 532 44 07-43 Hose 3/8 Long12"
139 532 44 07-42 Hose 3/8 Clamp
140 532 44 86-32 Guard Asm LH French
141 532 44 85-29 Guard Asm RH French
252 585 30 88-05 Plate 97 Left Bolt
253 585 30 90-05 Plate 97 LH Bolt
254 585 30 87-05 Plate 97 RH Bolt
255 539 10 98-00 Carriage Bolt
- - 532 19 28-70 Mandrel Assembly (Includes
Housing (Key #33), Shaft Assem-
bly (Key #34), And Bearing Only
- Pulley/Nut/Washer And Blade
Bolt/Washers Not Included)
- - 586 25 80-01 Replacement Mower Complete

16
2 532 43 69-96 Deck Lift Weldment
3 532 19 52-31 Lever Asm., Lift RH
7 580 96 23-01 Grip, Lever
10 532 19 63-14 Spring Torsion
87 532 19 42-09 Pin Cotter 7/16 Bow Tie Lock
88 532 43 69-95 Spring Lift Assist
89 819 19 19-12 Washer Clear Zinc
90 532 19 42-08 Pin Cotter 5/16 Bow Tie Lock
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
91 532 19 51-81 Link Lift Susp. Mower Rear
97 817 49 06-08 Screw 3/8-16 x 1/2
98 532 19 52-70 Link Lift Susp. Front Mower
100 873 93 06-00 Nut Centerlock 3/8-16
101 532 40-70-03 Link Asm. Lift FXD
KEY PART
NO. NO. DESCRIPTION
TRACTOR - - MODEL NO. CTH 174 (96051009200), PRODUCT NO. 960 51 00-92
MOWER LIFT
45
45
87
2
97
97
88
89
90 98
lift-tex_17_r4 *Key 91 may be substituted for Key 101
91
101*
87
100
7
3
10
89
89
87

17
1 532 43 98-22 Seat
2 532 18 01-66 Bracket Pivot Fender
3 532 14 06-75 Strap, Asm. Fender
6 873 80 06-00 Nut, Lock w/Ins. 3/8-16 unc
7 532 12 41-81 Spring, Seat Cprsn.
8 532 17 18-77 Bolt 5/16-18 unc x 3/4 w/Sems.
10 532 19 69-77 Pan, Seat
21 532 17 18-52 Bolt, Shoulder 5/16-18
37 873 80 05-00 Nut, Lock 5/16-18 unc
40 532 19 76-61 Handle
41 532 19 82-00 Spring
43 874 76 06-12 Bolt 3/8-16 unc x 3/4
44 819 13 38-12 Washer 13/32 x 2-3/8 x 12 Ga.
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
KEY PART
NO. NO. DESCRIPTION
TRACTOR - - MODEL NO. CTH 174 (96051009200), PRODUCT NO. 960 51 00-92
SEAT ASSEMBLY
42
42
2
6
1
40
10
37
37
21
21
3
41
7
8
7
8
8
8
seat-tex_6.5SL_2
44
43

18
TRACTOR - - MODEL NO. CTH 174 (96051009200), PRODUCT NO. 960 51 00-92
BAGGER
46
46
14
20
14
23
10
20
14
7
23
4
12
11
7
11
14
12
7
1
19
6
28
27
7
23
7
23
13
9
5
21
15
2
3
8
Bagger_TEX CRD_21_r1
25
25
26
7
37
33
30
32
31
34
38
35
39
36

19
TRACTOR - - MODEL NO. CTH 174 (96051009200), PRODUCT NO. 960 51 00-92
BAGGER
46
46
1 532 42 86-10 Tube Handle Bagger
2 532 44 13-58 Applique
3 532 41 38-08 Nut Push .156
4 532 43 96-12 Frame Asm Bagger Top
5 532 41 76-32 Frame Asm Top Bagger
6 532 12 68-75 Rivet Drilled
7 873 90 04-00 Nut Hex Flange 1/4-20 unc
8 532 44 12-61 Cover Bagger
9 532 41 76-29 Insert Handle Bagger
10 532 43 67-70 Frame Front
11 532 43 67-71 Tubing Brace Bagger
12 532 42 17-93 Nut Square 1/4
13 532 42 17-80 Screw 1/4 x 1.150
14 532 42 18-00 Bolt Shoulder 1/2 x 1.150
15 532 42 18-01 Screw #8 Dlat Head Drill Tip
19 532 19 42-08 Cotter Pin 5/16 Bow Tie
20 585 36 88-01 Screw Hex Cap 1/4-20 x 1.375
21 532 44 83-06 Bag Asm
23 872 04 04-10 Bolt Carr. 1/4-20
25 532 42 16-14 Spring Latch Bagger
26 817 49 04-12 Screw 1/4-20 x 3/4
27 532 42 12-62 Grommet Rubber
28 532 16 57-87 Grip Handle Black
30 532 43 74-52 Plug
31 532 43 58-61 Pin Hinge
32 532 43 74-54 Spring Double Torsion
33 532 43 84-51 Shaft Mulch Plug
34 532 43 79-88 E-Ring 5/16
35 532 43 91-39 Grip Mulch Plug
36 532 43 90-98 Bolt J
37 532 06 91-80 Nut Lock #10-24 unc
38 819 07 08-18 Washer 7/32 x 1/2
39 532 43 92-42 Bungee
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm

12.17.13 JM
